HP Cloudline Overview

HP Cloudline Overview

Infrastructure for Cloud Service Providers

Dave Peterson

2

Open Infrastructure Innovation is driving growth

Scale-out compute growing faster than the market – driving all-new architectures

Traditional

On-premise

SP + HPC

Legacy Enterprise Applications

On-premise Compute

Service Provider – HPC – Big Data

_~50%

~40%

2013

2017

$40B+

Open

Open APIs

Not custom integration

Grassroots

Not vendor driven

Software resiliency

Not hardware based

Basic features

Not enterprise

Open design

Not proprietary

Hyperscale

Not traditional architecture

Open Infrastructure design principles

Open concepts

4

Vision: Innovation through collaboration

Open Infrastructure for Business Model Innovation

Made for

Extreme Scale

Open Design and Cost Focused for Cloud Based Service delivery

HP Cloudline

Purpose built for cloud

scale deployments

Built on

Open Design

Principles

Competitively priced for

Service Providers needs

Delivers

Cost-Focused

Infrastructure

Open design supports

innovation and fast

response

6

Open Infrastructure for Service Providers

HP Cloudline - open and cost-focused platforms for web scale

Innovative,

density optimized platforms

for

2P, 1P and SoC designs to deliver superior

efficiency and

lowest per node cost

Dense multinode

servers

HP Support

& Technical

Services

New, lowest cost rack mount servers in the HP

portfolio that are

cost optimized for

large-scale deployments

Bare iron rack

servers

Full, rack scale platforms optimized for the

HP Cloudline Rackmount Server Family

• Low cost 1U 2P right sized server

• Ideal for front end and web

applications

• Cost optimized for large scale

deployments

• 8 DDR4 DIMMs

• Multipurpose 1U 2P server

• Ideal for cloud, caching, and search

workloads

• 1U 2P rackmount server that can

support up to 16 DDR4 DIMMS for

memory and storage rich applications

• 2U 2P server powerful enough for

hosters & big data workloads with cost

reduction in mind

• Can support 12 LFF drives and 16 DDR4

DIMMs for dense cloud storage support

• Ideal for Hadoop, cloud database,

NoSQL applications

HP Cloudline CL1100

HP Cloudline CL2100

HP Cloudline CL2200

Low-cost for front-end web

Great for cloud compute workloads

Ideal for Hadoop and database applications

8

HP Cloudline CL1100 G3 208S Server

Lowest cost 2P rackmount server

Processor

Base: 2x Intel® Xeon E5-2600 v3 up to 105W

Option Up: 2x Intel Xeon E5-2600 v3 up to

120W

Chipset

Intel® C610 PCH

Memory

8x DDR4 DIMM slots @ up to 2133 MHz

Network Module

Base: 2x1GbE embedded NIC

Option Up: 2x10GbE SFP + w /sideband support,

10GbE OCP Mezz supported

Fan Support

Base: 3, NHP, No redundancy

_{Option Up: 5, N+1 redundancy}

Storage Controller

(2) ports Standard Intel Chipset SATA RAID

IO Expansion

Base: None

_{Option Up: (1) FHHL, (1) 10GbE via OCP Mezz}

Drive Support

(2) LFF/ (2) SFF NHP toolless drives

Management

Base: ASPEED 2400

_{Option Up: KVM Support}

Max Power

Base: 400W Gold (85%) NHP, No PM Bus

Option Up: 500W Platinum (94%) NHP, with PM

HP Cloudline CL2100 G3 407/807S Server

Multi-purpose 1U 2P server for large scale deployments

Processor

2x Intel Xeon E5-2600 v3 up to 120W

Chipset

Intel C610 PCH

Memory

16x DDR4 DIMM slots @ up to 2133 MHz

Network Module

2x 1GbE embedded NIC

_{10GbE SFP + NIC via OCP Mezz}

Fan Support

5,NHP, No redundancy

Storage Controller

(10) ports of SATA 6.0Gb/s, SAS HBA Mezzanine

_{card, up to (8) ports of SAS 6.0Gb/s, Intel C610}

IO Expansion

(1) PCIe x16 Gen3 slot for FHHL add-on card

(1)PCIe x8 Gen3 slot for 10GbE SFP+ OCP card

(1) PCIe x8 Gen3 SAS Mezzanine slot for IDM SAS

HBA card

Drive Support

(4) LFF or (8) SFF hot plug, SAS/SATA

Management

ASPEED 2400, KVM Support

CL2100 G3 407S

10

HP Cloudline CL2200 G3 1211R Server

Multi-purpose 2U 2P server for big data and cloud storage

Processor

2x Intel Xeon E5-2600 v3 up to 120W

Chipset

Intel C610 PCH

Memory

16x DDR4 DIMM slots @ up to 2133 MHz

Network Module

4x 1GbE embedded NIC

_{10GbE SFP+ NIC available via OCP Mezz}

Fan Support

4, NHP, No redundancy

Storage Controller

(10) ports Standard Intel Chipset SATA

_{SAS/SATA,(1) PCIe standup HBA Mezzanine card}

IO Expansion

(3) Storage and OCP Mezz Slots

(1) PCIe x16 Gen3 Low-profile slot

(1) PCIe x8 Gen3 Low-profile slot

(1) PCIe x8 Gen3 FHHL internal add-on card

Drive Support

(12) LFF and (2) SFF hot plug, SAS/ SATA

Management

ASPEED 2400, KVM Support

HP’s Open Compute Infrastructure

Open solutions to accelerate innovation and provide service providers

with the freedom required for rapid, cost effective growth

HP Cloudline CL7100

for Open Rack Server

1/3-width compute sled

HP Cloudline CL7300

for Open Cloud Server

12

HP Cloudline CL7100 Open Rack Server

Processor

2x Intel Xeon E5-2600 v3 up to 120W

Chipset

Intel C610 PCH

Memory

16x DDR4 DIMM slots @ up to 2133 MHz

Network Module

1x 1GbE embedded NIC

_{10GbE SFP + NIC via Mezz}

IO Expansion

(2) PCIe 3.0 LP (1 x8, 1 x16)

_{(1) OCP 10GbE Mezzanine}

Drive Support

Up to 6 SFF NHP SAS/SATA

_{(1) M.2 NGFF module}

Management

ASPEED 2400, IPMI 2.0, KVM Support

Power

12KW power shelf, single zone

Chassis

21” Chassis

HP Cloudline CL7300 Open Cloud Server

Processor

2x Intel Xeon E5-2600 v3 up to 145W

Chipset

Intel C610 PCH

Memory

16x DDR4 DIMM slots @ up to 2133 MHz

Network Module

10GbE or 40GbE via mezz

IO Expansion

(1) Network Mezzanine

(1) PCIe x16 rear connector to tray backplane

(support bifurcation to 4 x4)

(2) 12GbS SAS pass-through headers

PCIe ROC card – via x8 PCIe Slot

Drive Support

(4) LFF and (4) SFF SAS/SATA

_{(2) M.2 NGFF Module}

Management

ASPEED 2400, IPMI 2.0, KVM Support

Power

(6) 1200W PSU’s per 12U Chassis

14

HP Cloudline customers and partners….more to come

“This machine can actually provide us with

better management capabilities, more customization

possibilities, and a much

higher price-performance ratio

. We believe HP Cloudline is the best solution for our cloud implementation.”

Tan Xiao Sheng
