YOUR LIGHTING SOLUTION

(1)

(2)

Chi siamo – About us

Baracos è una realtà giovane e dinamica nata per

soddisfare le nuove richieste del mercato illuminotecnico.

La nostra struttura ha costi contenuti e vanta di un personale altamente qualificato grazie alla lunga esperienza acquisita nel campo dell’illuminazione. I nostri prodotti sono studiati per garantire il massimo effetto in termini di luminosità , brillantezza e giochi di luce.

Ogni linea è curata con passione, i materiali vengono scelti con scrupolosità , i prodotti vengono

sottoposti a lunghi test di durata ed il design è innovativo.

Tutto ciò permette a Baracos di proporre ai suoi clienti prodotti di fascia alta ad un prezzo estremamente competitivo.

Grazie ad una nutrita rete di collaborazioni con diversi fornitori, Baracos è in grado di soddisfare le esigenze personalizzate dei suoi clienti, proponendo soluzioni customizzate nella vasta gamma di articoli disponibili.

Baracos is an innovative and dynamic group, born to satisfy all requirements of today’s lighting market. Our structure bears contained costs and praises a highly qualified staff, with a long-lasting experience acquired in the lighting field.

Our products have been developed to grant extreme performance in terms of brightness, brilliance and color variations.

Each line is cared with passion, and materials are scrupolously selected with long endurance tests, though still offering an innovative design. All these features allow Baracos to offer its Clients top-level articles at extremely competitive costs. Thanks to multiple collaborations with several providers, Baracos can satisfy any taylored needs for its Clients, offering customized solutions within the broad range of articles available.

(3)

Il C.R.I. o indice di resa cromatica di una sorgente luminosa è una misura di quanto appaiano naturali i colori degli oggetti da essa illuminati. Questo parametro, oggi indispensabile per il mercato del lighting, indica la fedeltà della resa del colore dell’oggetto illuminato. Le sorgenti led hanno ormai raggiunto CRI elevati attorno al 85/90 e grazie al continuo sviluppo tecnologico queste possono essere utilizzate anche per illuminare grandi ambienti.

The C.R.I. or Color Rendering Index of a light source indicates the extent to which colours of illuminated objects appear natural. As an indispensable attribute in the lighting market, this parameter defines the degree of fidelity of any illuminated object’s colour.

Led light sources have attained high CRI values close to 85/90. Thanks to the constant technological evolution of LED light sources, they can also be used for illuminating large

environments.

C.R.I. – Color Rendering Index

Temperatura del colore

Color temperatures

3000°k

4500°k

5000°k

Calda

Naturale

Fredda

(4)

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_Mm BIC5050 12 72 300 65 WARM 5000 3500 3000 13 x 5

BIN5050 12 72 300 65 NATUR 5000 4000 4500 13 x 5

BIF5050 12 72 300 65 COLD 5000 4500 6000 13 x 5

BIC5050 - BIN5050 - BIF5050

CODE V dc POWER W N° LED IP COLOR L mm lm TC °k P X H mm BIC 12 24 300 65 WARM 5000 1400 3000 8 x 3 BIN 12 24 300 65 NATUR 5000 1550 4500 8 x 3 BIF 12 24 300 65 COLD 5000 1750 6000 8 x 3

Striscia led flessibile da 60 led/m 3528 EPISTAR con adesivo 3M posteriore, cavi di ingresso 20 cm, divisibile in multipli di 3 led. Confezione una bobina 5 m

Flexible LED strip, 60 EPISTAR led/m 3528 with 3M adhesive on the back, 20 cm input cables. Can be split into multiples of 3 leds. Packing with one 5m reel.

BIC - BIN - BIF

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BIC2 12 48 600 65 WARM 5000 3800 3000 8 X 5

BIN2 12 48 600 65 NATUR 5000 4000 4500 8 X 5

BIF2 12 48 600 65 COLD 5000 4400 6000 8 X 5

BIC2 - BIN2 - BIF2

Flexible LED strip, 60 EPISTAR led/m 5050 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

Flexible LED strip 120 EPISTAR led/m 3528 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

STRISCE LED – LED STRIPES

A

(5)

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BAC2 12 96 1200 20 WARM 5000 6500 3000 16 x 2

BAN2 12 96 1200 20 NATUR 5000 7000 4500 16 x 2

BAF2 12 96 1200 20 COLD 5000 7500 6000 16 x 2

BAC2 - BAN2 - BAF2

CODE V dc POWER W N° LED IP COLOR L mm lm TC °k P X H mm BAC 12 96 600 20 WARM 5000 6000 3000 10 x 2 BAN 12 96 600 20 NATUR 5000 6500 4500 10 x 2 BAF 12 96 600 20 COLD 5000 7000 6000 10 x 2

Flexible LED strip 60 EPISTAR led/m 3020 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

BAC - BAN - BAF

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BAIC2 12 96 1200 65 WARM 5000 6500 3000 17 x 3

BAIN2 12 96 1200 65 NATUR 5000 7000 4500 17 x 3

BAIF2 12 96 1200 65 COLD 5000 7500 6000 17 x 3

BAIC2 - BAIN2 - BAIF2

Flexible LED strip 240 EPISTAR led/m 3528 with adhesive on back side, input cables cm 20. Can be split into multiples of 6 leds. Packing with one 5m reel.

Flexible LED strip 240 EPISTAR led/m 3528 with adhesive on back side, input cables cm 20. Can be split into multiples of 6 led. Packing with one 5m reel.

A

(6)

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BIC50E 12 50 300 65 WARM 5000 3300 3000 13 x 5

BIN50E 12 50 300 65 NATUR 5000 3500 4500 13 x 5

BIF50E 12 50 300 65 COLD 5000 3650 6000 13 x 5

BIC50E - BIN50E - BIF50E

CODE V dc POWER W N° LED IP COLOR L mm lm TC °k P X H mm BICE 12 24 300 65 WARM 5000 9000 3000 8 x 3 BINE 12 24 300 65 NATUR 5000 1000 4500 8 x 3 BIFE 12 24 300 65 COLD 5000 1100 6000 8 x 3

Striscia led flessibile da 60 led/m 3528 con adesivo 3M posteriore, cavi di ingresso 20 cm, divisibile in multipli di 3 led. Confezione una bobina 5 m

Flexible LED strip, 60 led/m 3528 with 3M adhesive on the back, 20 cm input cables. Can be split into multiples of 3 leds. Packing with one 5m reel.

BICE - BINE - BIFE

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BIC2E 12 48 600 65 WARM 5000 1900 3000 8 X 5

BIN2E 12 48 600 65 NATUR 5000 2000 4500 8 X 5

BIF2E 12 48 600 65 COLD 5000 2200 6000 8 X 5

BIC2E - BIN2E - BIF2E

Flexible LED strip, 60 led/m 5050 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

Flexible LED strip 120 led/m 3528 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

STRISCE LED – LED STRIPES

A

(7)

CODE _dcV POWER_W N° LED IP COLOR_mmL lm TC_°k P X H_mm BIM 12 36 150 65 RGB 5000 - MULTIC 13 x 5 BIM2 12 50 300 65 RGB 5000 - MULTIC 13 x 5

BIM – BIM2

CODE V dc POWER W N° LED IP COLOR L mm lm TC °k P X H mm BOC 12 24 300 20 WARM 5000 900 3000 8 x 3 BON 12 24 300 20 NATUR 5000 1000 4500 8 x 3 BOF 12 24 300 20 COLD 5000 1100 6000 8 x 3

Flexible LED strip 60 led/m 3528 with adhesive on back side, input cables cm 20. Can be split into multiples of 3 leds. Packing with one 5m reel.

BOC - BON - BOF

CODE _dcV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BOM 12 36 150 20 RGB 5000 - MULTIC 10 x 2

BOM2 12 50 300 20 RGB 5000 - MULTIC 10 x 2

BOM – BOM2

A

(8)

BSI2

BSI1

SENSORI – SENSOR

A

CODE V in_dc V out_dc Max Load_A IP Max Load_W L x D_mm BSI1 12 0-12 1 20 12 14 x 18

Control dimmer in tensione con Cavo da 100 cm funzione touch con LED blu integrato

Voltage control dimmer with 100 cm cable and integrated blue led

CODE V in_dc V out_dc Max Load_A IP Max Load_W L x P x H_mm BSI2 12 0-12 4 20 48 33 x 44 x 14

Control dimmer in tensione con cavo da 100 cm funzione touch con LED blu integrato

Voltage control dimmer with 100 cm cable and integrated blue led

BSI3

A

CODE V in_ac IP Max Load_A Max Power_W _mmH L x P_mm BSI3 220 20 10 250 20 33 x 82

Sensore PIR switch accensione quando la persona si trova all’interno del range del sensore (<3m) e spegnimento quando la persona si allontana

PIR sensor switch - power on when someone steps into the sensor switch area (<3m) and power off when person moves away

(9)

BSE1

BSI4

SENSORI – SENSOR

A

CODE V in_ac IP RANGE_m Max Load_W _mmH L x D_mm BSE1 220 44 10 250 94 78 x 87 CODE V in ac IP Max Load A Max Power W H mm L x P mm BSI4 220 20 10 250 20 82 x 33

Sensore IR switch - ogni variazione all’interno del range (1-6 cm) di rilevamento determina l’accensione o lo spegnimento della lampada

IR sensor switch - any variation within the detection range (1-6 cm) causes a switch change to ON; switch changes to OFF when a new motion is detected

Sensore IR switch - ogni variazione all’interno del range (10 m) di rilevamento determina l’accensione o lo spegnimento della lampada

IR sensor switch - any variation within the detection range (10m) causes a switch change to ON; switch changes to OFF when a new motion is detected

BSI5

A

CODE V in_dc V out_dc Max Load_A Max Power_W _mmH L x D_mm BSI5 12 0-12 2 48 17 53 x 17

Sensore IR switch - ad ogni variazione all’interno del range (5-10 cm) di rilevamento determina l’accensione o lo spegnimento della lampada

IR sensor switch - any reflection within the detection range(5-10 cm) causes a switch change to ON; switch changes to OFF when a new motion is detected

(10)

BSI7

BSI6

SENSORI – SENSOR

A

CODE V in_dc V out_dc Max Load_A IP Max Load_W L x P x H_mm BSI6 12-24 12-24 3-2 20 36-48 49 x 12 x 3

IR control dimmer con uscita in tensione; led blu indicazione di stato; funzione ON/OFF soft

IR Control dimmer with voltage output; blue led status indicator integrated; soft ON/OFF function

CODE V in_dc V out_dc Max Load_A IP Max Load_W L x P x H_mm BSI7 12-24 12-24 8 20 96-192 44 x 10 x 3

Control dimmer con sensore capacitivo; uscita in tensione; led blu indicazione di stato; funzione ON/OFF soft

Capacitive control dimmer with voltage output; blue led status indicator integrated; soft ON/OFF function

BSI8

A

CODE V in dc V out dc Max Load A IP Max Load W L x P x H mm BSI8 12-24 12-24 8-5 20 96-120 50 x 15 x 6

Control dimmer con sensore capacitivo; uscita in tensione; led blu indicazione di stato; funzione ON/OFF soft

Capacitive control dimmer with voltage output; blue led status indicator integrated; soft ON/OFF function

(11)

BRS2C - BRS2N - BRS2F

CODE V dc POWER W N° LED IP COLOR L mm lm TC °k P x H mm BRS1C 24 5 63 20 WARM 230 400 3000 24 x 4 BRS1N 24 5 63 20 NATUR 230 450 4500 24 x 4 BRS1F 24 5 63 20 COLD 230 500 6000 24 x 4

Circuito da 63 LED 3528 con connettori per il collegamento in serie max 10 pezzi

LED circuit 63 led 3528 linkable for series connection, max 10 pcs

BRS1C - BRS1N - BRS1F

STRISCE LED RIGIDE – RIGID LED STRIPES

A

Circuito da 54 LED 3014 con connettori per il collegamento in serie max 56W

LED circuit 54 led 3014 linkable for series connection, max 56W

BRS4C – BRS4N – BRS4F

A

CODE V ac POWER W N° LED IP COLOR L mm lm TC °k P x H mm BRS4C 230 14 36 20 WARM 155 1400 3000 11 x 3 BRS4N 230 14 36 20 NATUR 155 1500 4500 11 x 3 BRS4F 230 14 36 20 COLD 155 1550 6000 11 x 3

Circuito led 230V 36 led 5630 con filtro di rete integrato e connettori in/out per connessione in serie

Led circuit 230V, 36 LED 5630 with integrated line filter and in/out snap-in connector for serial connection

(12)

Led strip rigida 10 led 5050 larghezza 12mm lunghezza 200 mm Divisibile in due circuiti indipendenti

Rigid Led Strip 12mm 10 led 5050, 200 mm Length; Can be split into two independent circuit

BRS3C - BRS3N - BRS3F

STRISCE LED RIGIDE – RIGID LED STRIPES

A

CODE _dcV POWER_W N° LED IP COLOR _mmL Lm TC_°k P x H_mm BRS5C 24 8 36 20 WARM 470 900 3000 12 x 3

BRS5N 24 8 36 20 NATUR 470 1000 4500 12 x 3

BRS5F 24 8 36 20 COLD 470 1100 6000 12 x 3

Led strip rigida 36 led 5630 larghezza 12mm lunghezza 470 mm Composta da 4 moduli divisibili un modulo neutro

Rigid Led Strip 12mm 36 led 5630, 470 mm Length; It’s composed by 4 modules 1 module without led

BRS5C – BRS5N – BRS5F

A

(13)

Led Emitter 350 mA 3,2 W

3,2 W, 350mA Led Emitter

BM1C – BM1N – BM1F

LED COB – COB LED

A

CODE _mAI POWER_W N° LED IP COLOR _mmL lm TC_°k P x H_mm BM1C 350 3,2 1 20 WARM 50 200 3000 7 x 2

BM1N 350 3,2 1 20 NATUR 50 240 4500 7 x 2

BM1F 350 3,2 1 20 COLD 50 320 6000 7 x 2

Led Emitter 350 mA 3,5 W

3,5 W, 350mA Led Emitter

BM2C – BM2N – BM2F

CODE I mA POWER W N° LED IP COLOR D mm lm TC °k H mm BM2C 350 3,5 1 20 WARM 28 200 3000 3 BM2N 350 3,5 1 20 NATUR 28 240 4500 3 BM2F 350 3,5 1 20 COLD 28 320 6000 3

Micro led con dissipatore costampato fissione a pressione

Micro led molded aluminum heat sink push-in fixing in pipes

A

CODE I mA POWER W N° LED IP COLOR L mm lm TC °k D Mm BM3C 350 2,7 1 20 WARM 20 120 3000 11 BM3N 350 2,7 1 20 NATUR 20 140 4500 11 BM3F 350 2,7 1 20 COLD 20 160 6000 11

BM3C – BM3N – BM3F

(14)

CODE P x H_mm Cover _mmL BRP1T 7 x 18,4 TRASP 2000

BRP1F 7 x 18,4 FROSTED 2000

BRP1O 7 x 18,4 OPAL 2000

Profilo in alluminio satinato. Lunghezza barra 2mt 7x18,4 mm

Silver satin aluminum profile. Length 2 mt 7x18,4 mm

BRP1

PROFILI IN ALLUMINIO – ALUMINIUM PROFILES

CODE P x H_mm Cover _mmL BRP2T 12,3 x 20,5 TRASP 2000

BRP2F 12,3 x 20,5 FROSTED 2000

BRP2O 12,3 x 20,5 OPAL 2000

Profilo in alluminio satinato. Lunghezza barra 2mt 12,3x20,5mm

Silver satin aluminum profile Length 2 mt 12,3x20,5mm

BRP2

CODE P x H_mm Cover _mmL BRP3T 16 x 16 TRASP 2000 BRP3F 16 X 16 FROSTED 2000 BRP3O 16 X 16 OPAL 2000

Profilo in alluminio satinato. Lunghezza barra 2mt 16x16mm

Silver satin aluminum profile Length 2 mt 16x16mm

BRP3

T F O T F O T F O

(15)

CODE P x H_mm Cover _mmL BRP4T 20 x 20 TRASP 2000

BRP4F 20 x 20 FROSTED 2000

BRP4O 20 x 20 OPAL 2000

BRP4

BRP5

BRP6

T F O T F O T F O

(16)

CODE P x H_mm Cover _mmL BRP7T 20 x 20 TRASP 2000

BRP7F 20 x 20 FROSTED 2000

BRP7O 20 x 20 OPAL 2000

BRP7

CODE P x H_mm Cover _mmL BRP8T 19,5 x 20 TRASP 2000 BRP8F 19,5 x 20 FROSTED 2000 BRP8O 19,5 x 20 OPAL 2000

Profilo in alluminio satinato. Lunghezza barra 2mt 19,5x20mm

Silver satin aluminum profile Length 2 mt 19,5x20mm

BRP8

T F O T F O CODE P x H_mm Cover _mmL BRP8T 19,5 x 20 TRASP 2000 BRP8F 19,5 x 20 FROSTED 2000 BRP8O 19,5 x 20 OPAL 2000 CODE P x H_mm Cover _mmL BRP9T 18 x 9 TRASP 2000 BRP9F 18 x 9 FROSTED 2000 BRP9O 18 x 9 OPAL 2000

BRP9

T F O

(17)

BC2M

BKCM

CONTROLLER – CONTROLLER

A

CODE V in dc V out dc Max Load A IP Max Load W L x P x H mm BC2M 12-24 12-24 5x3ch 20 180/360 122x51x29

RGB Controller con uscita in tensione per strip led con telecomando. Funzioni giochi di luce selezione e regolazione intensità

RGB controller with Voltage output for RGB led strip with RF remote control. Color variations function, luminous intensity control and pre-sets. CODE V in_dc V out_dc Max Load_A IP Max Load_W L x P x H_mm BKCM 12-24 12-24 10 20 120/240 90x71x23

KIT RGB Controller con alimentatore per strip led con telecomando. Portata 50 metri. Funzioni giochi di luce, regolazione intensità

RGB controller kit with driver for RGB strip led with RF remote control. 50 meters range. Color variations function, luminous intensity control and pre-sets.

BC1M

A

CODE V in_dc V out Max Load_A IP Max Load_W L x P x H_mm BC1M 12-24 12-24 4x3ch 20 144/288 226x45x29

RGB controller with Voltage output for RGB led strip with RF remote control. Color variations function, luminous intensity control and pre-sets.

(18)

BC4M

BC3M

CONTROLLER – CONTROLLER

A

CODE V in_dc V out_dc Max Load A IP Max Load_W L x P x H_mm BC4M 12-24 12-24 4x3ch 20 144/288 117x64x24

RGB controller with Voltage output for RGB led strip with RF remote control. Color variations function, luminous intensity control and pre-sets. CODE V in_dc V out_dc Max Load_A IP Max Load_W L x P x H_mm BC3M 12-24 12-24 4x3ch 20 144/288 117x66x32

RGB Controller con tecnologia WIFI per strip led con telecomando. Portata 75 metri. Funzioni giochi di luce, selezione e regolazione intensità

WiFi RGB controller with Voltage output for RGB led strip with RF remote control. 75 meters range. Color variations function, luminous intensity control and pre-sets.

BCD1M

A

CODE V in_dc V out Max Load_A IP Max Load_W L x P x H_mm BCD1M 12-24 3 CMOS 4x3ch 20 144/288 155x75x41

RGB Controller DMX512 con uscita in tensione per strip led; possibilità di impostare l’indirizzo DMX, giochi e colori preimpostati

RGB controller DMX512 with Voltage output for RGB strip leds; possibility to set the DMX address, games and preset colors

(19)

BOMK – BOM2K

KIT – KIT

A

KIT RGB Controller con alimentatore e strip led IP20 con telecomando. Portata 30 metri. Funzioni giochi di luce, regolazione intensità

RGB controller kit with driver for RGB and IP20 strip led with RF remote control. 30 meters range. Color variations function, luminous intensity control and pre-sets.

CODE V ac POWER W N° LED IP COLOR L mm lm TC °k P X H mm BOMK 220 36 150 20 RGB 5000 - MULTIC 10 x 2 BOM2K 220 72 300 20 RGB 5000 - MULTIC 10 x 2

BIMK – BIM2K

KIT RGB Controller con alimentatore e strip led IP65 con telecomando. Portata 30 metri. Funzioni giochi di luce, regolazione intensità

RGB controller kit with driver for RGB and IP65 strip led with RF remote control. 30 meters range. Color variations function, luminous intensity control and pre-sets.

CODE _acV POWER_W N° LED IP COLOR _mmL lm TC_°k P X H_mm BIMK 220 36 150 20 RGB 5000 - MULTIC 10 x 2

(20)

CODE V ac POWER W N° LED lm COLOR H mm D mm TC °k BF1C 230 5 1 730 WARM 70 135 3000 BF1F 230 5 1 780 COLD 70 135 6000

Faretto led alta luminosità da incasso orientabile corpo alluminio 5W

Recessed spot led high brightness adjustable aluminium body 5W

BF1C – BF1F

FARETTI LED – SPOT LED

A

CODE V Dc POWER W N° LED lm COLOR H mm D mm TC °k BF2C 12 18 1 1300 WARM 90 182 3000 BF2N 12 18 1 1350 NATUR 90 182 4500 BF2F 12 18 1 1400 COLD 90 182 6000

BF2C – BF2N – BF2F

A

Faretto led alta luminosità da incasso down-light corpo alluminio 18W

Recessed spot led high brightness down-light aluminium body 18W

CODE _DcV POWER_W _LEDN° lm COLOR_mmH _mmD TC_°k BF3C 12 30 1 2000 WARM 111 220 3000

BF3N 12 30 1 2200 NATUR 111 220 4500

BF3F 12 30 1 2400 COLD 111 220 6000

Faretto led alta luminosità da incasso down-light corpo alluminio 30W

Recessed spot led high brightness down-light aluminium body

(21)

FARETTI LED – SPOT LED

Faretto led con attacco MR16, lente da 40°

Spot led with MR16 plug, 40° lens

BF4C – BF4F

A

CODE V Dc POWER W PLUG IP COLOR H x D mm lm TC °k CRI BF4C 12 6 MR16 44 WARM 45x50 350 3000 >80 BF4F 12 6 MR16 44 COLD 45x50 410 6000 >80

A

Modulo AR111 a luce riflessa con un led COB apertura fascio 20°

AR111 LED light reflection with one COB led beam angle 20°

BF5C - BF5N - BF5F

CODE _dcV POWER_W N° LED IP COLOR _mmD lm TC_°k _mmH BF5C 12 15 1 20 WARM 111 780 3000 85

BF5N 12 15 1 20 NATUR 111 800 4500 85

BF5F 12 15 1 20 COLD 111 820 6000 85

A

Modulo AR111 a luce riflessa con un led COB apertura fascio 40°

AR111 LED light reflection with one COB led beam angle 40°

BF6C - BF6N - BF6F

CODE _dcV POWER_W N° LED IP COLOR _mmD lm TC_°k _mmH BF6C 12 17 1 20 WARM 111 1150 3000 85

BF6N 12 17 1 20 NATUR 111 1200 4500 85

(22)

CODE V ac POWER W PLUG IP COLOR H x D mm lm TC °k BF19C 220 7 GU10 20 WARM 54x50 550 3000 BF19N 220 7 GU10 20 NATUR 54x50 580 4500 BF19F 220 7 GU10 20 COLD 54x50 610 6000

Faretto led attacco GU10, lente da 40°

Spot led GU10 plug, 40° lens

BF19C – BF19N – BF19F

A

FARETTI LED – SPOT LED

Faretto led ultra piatto con interruttore touch integato

Ultra-slim spot led with integrated touch switch

A

CODE _dcV POWER_W N° LED IP COLOR _mmH _mmD TC_°k

BF9C 12 2,8 36 20 WARM 7 68 3000

BF9N 12 2,8 36 20 NATUR 7 68 4500

BF9F 12 2,8 36 20 COLD 7 68 6000

(23)

Modulo MR16 completo di lente e dissipatore con 3 led SEUL

MR16 led module with lens and heatsink with 3 SEUL leds

FARETTI LED – SPOT LED

A

CODE _mAI POWER_W N° LED IP COLOR_mmD lm TC_°k CHIP BF7C 350 7,5 3 20 WARM 50 705 3000 SEUL

BF7N 350 7,5 3 20 NATUR 50 735 4500 SEUL

BF7F 350 7,5 3 20 COLD 50 765 6000 SEUL

Modulo AR111 completo di lente e dissipatore con 12 led SEUL

AR111 LED module with lenses and heatsink with 12 SEUL led

BF8C - BF8N - BF8F

CODE _mAI POWER_W N° LED IP COLOR _mmD lm TC_°k _mmH BF8C 350 15 12 20 WARM 110 1630 3000 45

BF8N 350 15 12 20 NATUR 110 1680 4500 45

BF8F 350 15 12 20 COLD 110 1730 6000 45

(24)

BF11C

CODE I mA POWER W N° LED IP COLOR D x H mm lm TC °k BF10C 350 1,4 1 20 WARM 30x8 80 3000

Modulo led 1W, colore grigio fissaggio a scatto lente da 65° Fornito con cavo da 120 cm e connettore maschio

1W LED module, silver gray color, push button anchoring with 65° lens. 120 cm cable with male plug

BF10C

FARETTI LED – SPOT LED

A

++

Modulo led 1W, colore grigio fissaggio a scatto lente da 65° Fornito con cavo da 120 cm e connettore maschio

LED module 1W, silver gray color, push botton fixing with 65° beam angle. 120 cm cable with male plug

CODE _mAI POWER_W N° LED IP COLOR D x H_mm lm TC_°k BF11C 350 1,4 1 20 WARM 30x13 80 3000

BF12C

Modulo led 1W, colore trasparente fissaggio a scatto lente da 65° Fornito con cavo da 120 cm e connettore maschio

LED module 1W, transparent color, push button anchoring with 65° beam angle. 120 cm cable with male plug

CODE I mA POWER W N° LED IP COLOR D x H mm lm TC °k BF12C 350 1,4 1 20 WARM 30x13 80 3000

A

++

A

++

(25)

BF14C – BF14N – BF14F

CODE V dc POWER W N° LED IP COLOR H mm D mm TC °k BF13C 3,2 0,1 1 44 WARM 35 12 3000 BF13F 3,2 0,1 1 44 COLD 35 12 6000

Faretto ad incasso con LED 5mm montato su cover in metallo trattato e verniciato color cromo. Indicato per decorazioni a cielo stellato cavo 1,5m

Recessed spot LED 5mm cover treated and Chrome painted suitable for decoration or starry sky cable 1,5m

BF13C – BF13F

FARETTI LED – SPOT LED

A

Faretto incasso con POWER LED seul P4-07 montato su corpo in policarbonato color cromo

Recessed spot with POWER LED Seul P4-07, treated chrome polycarbonate body.

BF15C – BF15N – BF15F

A

Faretto incasso quadrato con POWER LED Seul P4-07 montato su corpo in policarbonato color cromo

Recessed square spot with POWER LED Seul P4-07 treated chrome polycarbonate body. CODE I mA POWER W N° LED IP COLOR H mm D mm TC °k BF14C 350 1 1 40 WARM 10,5 32 3000 BF14N 350 1 1 40 NATUR 10,5 32 4500 BF14F 350 1 1 40 COLD 10,5 32 6000

CODE _mAI POWER_W N° LED IP COLOR _mmH L x P_mm TC_°k BF15C 350 1 1 40 WARM 19 32x32 3000

BF15N 350 1 1 40 NATUR 19 32x32 4500

(26)

Modulo quadrato ad incasso con cornice a lampade basculanti Lampada AR111 non inclusa

Square recessed downlight with frame for tilting lamps. AR111 lamp not included

BFCL1

FARETTI LED – SPOT LED

CODE I mA POWER W N° LED IP COLOR H mm D mm TC °k BF17M 350 3 1 40 RGB 52 32 MULTI

Faretto ad incasso RGB con LED 5mm montato su cover in metallo trattato e verniciato. Indicato per decorazioni multicolor con cavo RGB 0,3m

Recessed spot RGB LED 5mm cover treated and painted suitable for multicolor decoration cable RGB 0,3m

BF17M

A

CODE PLUG Color LAMP IP MAT L x P_mm _mmH BFCL1 G53 Grey AR111 20 Met/All 338x181 87

Faro led da incasso per controsoffitto con 1 led COB orientabile a 360° orizzontalmente e 90° verticalmente

Recessed spot led for falce ceiling with 1 COB led directable 360° horizontally and 90° vertically

BF16C – BF16N – BF16F

A

CODE _AcV POWER_W N° LED IP COLOR _mmH _mmD TC_°k BF16C 220 30 1 40 WARM 185 126 3000

BF16N 220 30 1 40 NATUR 185 126 4500

(27)

LAMPADINE LED – LED BULBS

Lampadina a filamento led a fiamma angolo di apertura fascio luminoso 320 ° 2W

Led filament bulb flame angle light beam 320° 2W

BL421C

A

CODE _acV POWER_W N° LED PLUG Lumen_mmH _mmD TC_°k BL42C 230 2 2 E14 210 100 35 3000

Lampadina a filamento led angolo di apertura fascio luminoso 320 ° 2W

Led filament bulb angle light beam 320° 2W

BL42C

A

BL46C 230 6 6 E14 470 100 35 3000

BL44F 230 4 4 E14 350 100 35 6000

BL46F 230 6 6 E14 470 100 35 6000

Lampadina a led con angolo di apertura fascio luminoso 120 °

Led bulb angle light, beam angle 120°

BL44C – BL46F – BL44F – BL46F

A

(28)

A

CODE _acV POWER_W PLUG IP COLOR L x D_mm lm TC_°k CRI BL56C 220 6 E27 20 WARM 75x45 460 3000 >80

BL56N 220 6 E27 20 NATUR 75x45 470 4500 >80

BL56F 220 6 E27 20 COLD 75x45 480 6000 >80

A

BL512N 220 12 E27 20 NATUR 108x60 1040 4500 >80

BL512F 220 12 E27 20 COLD 108x60 1050 6000 >80

BL520N 220 20 E27 20 NATUR 136x80 1700 4500 >80

BL520F 220 20 E27 20 COLD 136x80 1800 6000 >80

Lampadina led attacco E27 angolo di apertura fascio luminoso 210 ° 6W

Led bulb angle light E27 plug, beam angle 210° 6W

BL56C – BL56N – BL56F

Led bulb angle light E27 plug beam angle 210° 12W

BL512C – BL512N – BL512F

BL520C – BL520N – BL520F

(29)

A

CODE V ac POWER W PLUG IP COLOR L x D mm lm TC °k CRI BL510C 220 10 E27 20 WARM 133x95780 3000 >80 BL510N 220 10 E27 20 NATUR 133x95810 4500 >80 BL510F 220 10 E27 20 COLD 133x95860 6000 >80

A

CODE V ac POWER W PLUG IP COLOR L x D mm lm TC °k CRI BL58C 220 8 E27 20 WARM 100x63 490 3000 >80 BL58N 220 8 E27 20 NATUR 100x63 500 4500 >80 BL58F 220 8 E27 20 COLD 100x63 510 6000 >80

Lampadina a filamento led attacco E27 angolo di apertura fascio luminoso 320 °

Led filament bulb angle E27 plug light beam 320°

BL5A6C – BL5A8C

A

CODE _acV POWER_W PLUG IP COLOR L x D_mm lm TC_°k CRI BL5A6C 220 6 E27 20 WARM 110x60 650 3000 >80

BL5A8C 220 8 E27 20 WARM 110x60 850 3000 >80

BL510C – BL510N – BL510F

BL58C – BL58N – BL58F

(30)

BL1A4C - BL1A4N - BL1A4F

A

CODE _acV POWER_W lm IP COLOR _mmH _mmD TC_°k BL13C 230 3 210 44 WARM 33 16 3000

BL15C 230 5 410 44 WARM 39 16 3000

Lampadina a led G9 con SMD protezione in silicone

G9 SMD Led bulb, silicone cap

BL13C – BL15C

A

Lampadina a led G9 con COB led angolo di apertura fascio 120° 4W

G9 Led bulb with COB led beam angle 120° 4W

CODE _acV POWER_W lm IP COLOR _mmH _mmD TC_°k BL1A4C 230 4 300 44 WARM 60 18 3000

BL1A4N 230 4 320 44 NATUR 60 18 4500

BL1A4F 230 4 340 44 COLD 60 18 6000

CODE _dcV POWER_W lm IP COLOR_mmH _mmD TC_°k BL12C 12 2 150 44 WARM 40 14 3000

BL12F 12 2 110 44 COLD 40 14 6000

Lampadina a led G4 con SMD protezione in silicone 2W

G4 SMD Led bulb, silicon cap 2W

A

_{BL12C – BL12F}

(31)

BP01AN - BP01BN – BP01CN

PANNELLI LED – LED PANEL

A

BP02N

A

CODE FinishPOWER_W lm IP COLOR_mmH L x P_mm TC_°k BP01AN SILVER 18 1230 44 NATUR 15 300x300 4500

BP01BN SILVER 45 3000 44 NATUR 15 600x600 4500

BP01CN SILVER 45 3000 44 NATUR 15 300x1200 4500

Pannello led ultra piatto, fattore di potenza > 90. Bordo in alluminio Alimentatore non incluso

Super slim Led panel, power factor > 90. Aluminum edge. Led driver not included.

CODE FinishPOWER_W lm IP COLOR_mmH L x P_mm TC_°k BP02N SILVER 45 3000 44 NATUR 35 600x600 4500

Pannello led ultra piatto, fattore di potenza > 90. Alimentatore non incluso

Super slim Led panel, power factor > 90. Led driver not included.

(32)

PANNELLI LED – LED PANEL

Pannello led ultra piatto, disponibile nella versione alluminio satinato o bianco. Driver led incluso

Super slim Led panel, available satin silver or white painted aluminum. Led driver included.

BP03SN - BP03WN

BP03AWN -BP03BWN

A

BP04SN – BP04WN

A

CODE FinishPOWER_W lm IP COLOR_mmH L x P_mm TC_°k BP04SN SATIN 13 800 20 NATUR 13 172x172 4500

BP04WN WHITE 13 800 20 NATUR 13 172x172 4500

Pannello led ultra piatto, disponibile nella versione alluminio satinato o bianco. Driver led incluso

Super slim Led panel, available satin silver or white painted aluminum. Led driver included.

CODE FinishPOWER_W lm IP COLOR _mmH _mmD TC_°k BP03SN SATIN 13 800 20 NATUR 13 174 4500

BP03WN WHITE 13 800 20 NATUR 13 174 4500

BP03AWN WHITE 12 1350 20 NATUR 40 155 4500

(33)

TUBI LED – LED TUBES

BTN15C - BTN15N – BTN15F

A

CODE AnglePOWER_W lm IP COLOR_mmL _mmD TC_°k BTN15C 180 22 3400 20 WARM 1500 26 3000

BTN15N 180 22 3600 20 NATUR 1500 26 4500

BTN15F 180 22 3700 20 COLD 1500 26 6000

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza Led tube aluminium body for indoor use. Replaceble with a fluorescent tube

BTN6C – BTN6N – BTN6F – BTN9N

A

CODE AnglePOWER

W lm IP COLOR L Mm D mm TC °k BTN6C 180 10 1300 20 WARM 600 26 3000 BTN6N 180 10 1400 20 NATUR 600 26 4500 BTN6F 180 10 1500 20 COLD 600 26 6000 BTN9N 180 14 2100 20 NATUR 900 26 4500

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza Led tube aluminium body for indoor use. Replaceable with a fluorescent tube

BTN12C - BTN12N – BTN12F

A

W lm IP COLOR L mm D mm TC °k BTN12C 180 18 2300 20 WARM 1200 26 3000 BTN12N 180 18 2400 20 NATUR 1200 26 4500 BTN12F 180 18 2500 20 COLD 1200 26 6000

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza

Led tube aluminium body for indoor use. Replaceble with a fluorescent tube

(34)

TUBI LED – LED TUBES

BTN15CE - BTN15NE – BTN15FE

A

CODE AnglePOWER_W lm IP COLOR_mmL _mmD TC_°k BTN15CE 180 22 2400 20 WARM 1500 26 3000

BTN15NE 180 22 2500 20 NATUR 1500 26 4500

BTN15FE 180 22 2600 20 COLD 1500 26 6000

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza Led tube aluminium body for indoor use. Replaceble with a fluorescent tube

BTN6CE – BTN6NE

BTN6FE – BTN9NE

A

W lm IP COLOR L mm D mm TC °k BTN6CE 180 10 1180 20 WARM 600 26 3000 BTN6NE 180 10 1200 20 NATUR 600 26 4500 BTN6FE 180 10 1220 20 COLD 600 26 6000 BTN9NE 180 14 1400 20 NATUR 900 26 4500

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza Led tube aluminium body for indoor use. Replaceable with a fluorescent tube

BTN12CE - BTN12NE – BTN12FE

A

W lm IP COLOR L mm D mm TC °k BTN1C2E 180 18 2050 20 WARM 1200 26 3000 BTN12NE 180 18 2100 20 NATUR 1200 26 4500 BTN12FE 180 18 2150 20 COLD 1200 26 6000

Tubo a led con corpo in alluminio per impiego ad uso interno. Sostituibile con tubi a fluorescenza

Led tube aluminium body for indoor use. Replaceble with a fluorescent tube

(35)

Reglette LED T5 ideale per il montaggio nel sottopensile; possibilità di montaggio di 5 corpi in serie

T5 LED reglette for undercabinet mounting. Possibility to connect 5 item series

BRR7C – BRR7N – BRR7F

A

CODE V ac POWER W PLUG IP TC °K L x P mm H mm lm BRR7C 220 7 T5 20 3000 600x25 33 600 BRR7N 220 7 T5 20 4500 600x25 33 630 BRR7F 220 7 T5 20 6000 600x25 33 660

Reglette LED T5 ideale per il montaggio nel sottopensile, possibilità di montaggio di 5 corpi in serie

A

CODE _acV POWER_W PLUG IP TC_°K L x P_mm _mmH lm BRR14C 220 14 T5 20 3000 1200x25 33 1200

BRR14N 220 14 T5 20 4500 1200x25 33 1260

BRR14F 220 14 T5 20 6000 1200x25 33 1300

Reglette LED T8 ideale per il montaggio nel sottopensile, possibilità di montaggio di 5 corpi in serie

A

CODE _acV POWER_W PLUG IP TC_°K L x P_mm _mmH lm BRR16C 220 16 T8 20 3000 1200x31 38 1400

BRR16N 220 16 T8 20 4500 1200x31 38 1440

BRR16F 220 16 T8 20 6000 1200x31 38 1480

BRR14C – BRR14N – BRR14F

BRR16C – BRR16N – BRR16F

(36)

REGLETTE LED – LED REGLETTE

Corpo lampada per

l’installazione di 2 tubi a led T8 Tubo a led non incluso

Lamp body for two T8 led tube installation.

Led tube not included

BRRA12

CODE _acV Color PLUG IP Cover L x P_mm _mmH BRRA12 220 GREY T8 65 POLICARB 1270x110 170

Corpo lampada per l’installazione di un tubo a led T8

Tubo a led non incluso

Lamp body for T8 led tube installation. Led tube not included

BRRB6 - BRRB12 - BRRB15

CODE _acV Color PLUG IP Cover L x P_mm _mmH BRRB6 220 GREY T8 20 POLICARB 625x45 80

BRRB12 220 GREY T8 20 POLICARB 1235x45 80

(37)

PLAFONIERE LED – LED ROOF LAMP

Plafoniera led da soffitto e da parete materiale termoplastico per resistere agli agenti atmosferici

Wall and ceiling led light made of durable weatherproof thermoplastic material.

BE01N

A

BE03

CODE FinishPOWER_W Plug IP _mmH L x P_mm BE03 STEEL - GU10 65 80 156x80

Lampada up and down da parete con attacco GU10 in acciaio INOX AISI 304 Lampadina non inclusa

Up and down ceiling lamp with GU10 plug made of AISI 304 steel . Light bulb not included

CODE FinishPOWER_W lm IP COLOR_mmH _mmD TC_°k BE01N BLACK 12 810 54 NATUR 100 300 4500

Plafoniera led da soffitto e da parete materiale termoplastico per resistere agli agenti atmosferici

Wall and ceiling led light made of durable weatherproof thermoplastic material.

BE02N

A

CODE FinishPOWER_W lm IP COLOR _mmH L x P_mm TC_°k BE02N BLACK 12 840 54 NATUR 100 290x200 4500

(38)

FARETTI LED GIARDINO – GARDEN SPOT LED

BE04

CODE FinishPOWER W Plug IP

H mm

L x P mm BE04 STEEL - GU10 65 95 317x95

Faretto da esterno con picchetto in alluminio. Lampadina non inclusa

Outdoor spotlight with aluminum spike. Bulb not included

BE05

CODE FinishPOWER W Plug IP

H mm

L x P mm BE05 STEEL - GU10 65 95 317x95

Apparecchio di illuminazione di segnalazione da incasso per installazioni in esterni con livello di protezione IP65 calpestabile. Lampadina non inclusa

Lighting appliance with recessed step lighting leds for outdoor istallation with IP65 protection. Bulb not included

(39)

BTTL1

CODE Finish POWER_W Conf_N° IP _mmH L x P_mm BTTL1 PLAST 2 20 40 380 310 x 475

Torcia a led 4 colori 4V/0,5 Ah ricaricabile direttamente da presa. Interruttore a due posizioni per l’utilizzo di 4 o 7 led.

Autonomia 10 ore

Led torch 4 colours 4V/0,5 Ah rechargeble directly from wall socket Led switch with 2 position for the use of 4 or 7 led. Working time 10 h

(40)

PROIETTORI STRADALI – LED STREET LIGHT

A

CODE _acV POWER_W H palo _m IP COLOR CRI lm TC_°k D palo _mm L x P x H_mm BSS130 220 30 6 65 NATUR >80 2800 6000 48/60 560x260x110

BSS160 220 60 7 65 NATUR >80 5306 6000 48/60 560x260x110

Proiettore stradale a led in alluminio fissaggio a palo durata 50.000 ore

Led aluminum street light pole fixing Average 50.000 h

BSS130 – BSS160

BSS1120 220 120 9 65 NATUR >80 10848 6000 60/76 754x280x110

BSS190 – BSS1120

CODE _acV POWER_W H palo _m IP COLOR CRI lm TC_°k D palo _mm L x P x H_mm BSS1150 220 160 11 65 NATUR >80 13470 6000 60/76 595x360x120

(41)

PROIETTORI STRADALI – LED STREET LIGHT

Led Aluminum street light, pole fixing Average life 50.000 h

BSS30 - BSS60

A

BSS90 - BSS120

BSS150

BSS60 220 60 7 65 NATUR >80 5306 6000 48/60 560x260x110

BSS120 220 120 9 65 NATUR >80 10848 6000 60/76 754x280x110

CODE _acV POWER_W H palo _m IP COLOR CRI lm TC_°k D palo _mm L x P x H_mm BSS150 220 160 11 65 NATUR >80 13470 6000 60/76 595x360x120

(42)

RIFLETTORI LED - REFLECTOR LED

CODE V ac POWER W N°

LED IP COLOR CRI lm TC °k L x P x H mm BFL10C 220 10 1 65 WARM >80 800 3000 86x115x89 BFL10F 220 10 1 65 COLD >80 900 6000 86x115x89

Riflettore a led da 10 W con corpo in alluminio, vetro temperato e COB led

10 W LED spotlight with aluminum casting, tempered glass and led COB

BFL10C – BFL10F

A

CODE _acV POWER_W _LEDN° IP COLOR CRI lm TC_°k L x P x H_mm BFL30C 220 30 1 65 WARM >80 2500 3000 185x225x110

BFL30F 220 30 1 65 COLD >80 2600 6000 185x225x110

BFL30C – BFL30F

A

CODE _acV POWER_W _LEDN° IP COLOR CRI lm TC_°k L x P x H_mm BFL50C 220 50 1 65 WARM >80 4000 3000 290x240x168

BLF50F 220 50 1 65 COLD >80 4200 6000 290x240x168

BFL50C – BFL50F

A

(43)

RIFLETTORI LED - REFLECTOR LED

CODE _acV POWER_W N° LED IP COLOR CRI lm L x P x H_mm TC_°k BFLA50C 220 50 MULTI 65 WARM >80 4000 220x190x130 3000

BFLA50F 220 50 MULTI 65 COLD >80 4100 220x190x130 6000

BFLA70C 220 70 MULTI 65 WARM >80 5600 290x235x150 3000

BFLA70F 220 70 MULTI 65 COLD >80 5700 290x235x150 6000

Riflettore a led 50W con corpo in alluminio, vetro temperato e led MULTI CHIP

50 W LED spotlight with aluminum casting, tempered glass and MULTI-CHIP led

BFLA50C – BFLA50F

BFLA70C – BFLA70F

A

Riflettore a led con corpo in alluminio, vetro temperato e led MULTI CHIP

LED spotlight with aluminum casting, tempered glass and MULTI-CHIP led

BFLA150C – BFLA150F

CODE _acV POWER_W N° LED IP COLOR CRI lm L x P x H_mm TC_°k BFLA150C 220 150 MULTI 65 WARM >80 12000 370x285x105 3000

BFLA150F 220 150 MULTI 65 COLD >80 13000 370x285x105 6000

A

Faro industriale a led ad alta luminosità e basso consumo. Ideale per illuminare capannoni industriali

BFI100N – BFI150N

CODE V

ac POWER

W N° LED IP COLOR CRI lm D x H mm TC °k BFI100N 220 100 1 65 NATUR >80 7000 200 x 290 4500 BFI150N 220 150 1 65 NATUR >80 9900 270 x 270 4500

Led Lighthouse hight brightness low comsumption for enlighten industrial sheds

(44)

RIFLETTORI LED - REFLECTOR LED

CODE V ac POWER W N°

LED IP COLOR CRI lm TC °k L x P x H BFLS30C 220 30 1 65 WARM >80 2300 3000 246x225x121 BFLS30F 220 30 1 65 COLD >80 2500 6000 246x225x121

BFLS30C – BFLS30F

A

BFL30SSN

A

Riflettore a led con corpo in alluminio, vetro temperato e COB led sensore di movimento

50 W LED spotlight with aluminum casting, tempered glass, LED COB and motion sensor

Riflettore a led ultra piatto con corpo in alluminio, vetro temperato e COB led

LED spotlight super slim with aluminum casting, tempered glass, LED COB

CODE _acV POWER_W _LEDN° IP COLOR CRI lm TC_°k L x P x H_mm BFL30SSN 220 30 1 65 NATUR >80 2000 3000 185x178x43

(45)

RIFLETTORI LED - REFLECTOR LED

CODE _acV POWER_W _LEDN° Angle_° COLOR CRI lm D x H_mm TC_°k BFB120C 85-240 20 1 80 WARM >80 1700 110 X 98 3000

BFB120F 85-240 20 1 80 COLD >80 1800 110 X 98 6000

Faro led a binario orientabile a 360° corpo in alluminio completo di dissipatore design moderno.

Led spot track 20 W 360° angle adjustable with heatsink original design.

BFB120C – BFB120F

A

CODE V ac POWER W N° LED Angle ° COLOR CRI lm D x H mm TC °k BFB220C 85-240 20 1 120 WARM >80 1700 210 X 98 3000 BFB220F 85-240 20 1 120 COLD >80 1800 210 X 98 6000

Faro led a binario orientabile a 360° corpo in alluminio completo di dissipatore design moderno.

Led spot track 20 W 360° angle adjustable with heatsink original design.

BFB220C – BFB220F

CODE P x H_mm COLOR _mmL BFB03N 34 x 20 BLACK 1000

BFB03B 34 x 20 WHITE 1000

Accessori per binario

Track accessories

BFB03N - BFB03B

CODE P x H_mm COLOR Shape BFB04TN 34 x 20 BLACK T BFB04TB 34 x 20 WHITE T BFB04IN 34 x 20 BLACK I BFB04IB 34 x 20 WHITE I BFB04LN 34 x 20 BLACK L BFB04LB 34 x 20 WHITE L

(46)

CODE I mA POWER W Input min V Input max V H mm P x L mm BDF6 350 6 200 240 10,7 45 x 88

Super slim LED Driver in corrente costante 350mA classe II, morsetti a vite

Super-slim 350mA constant current LED driver, class II, screw terminal

BDF6

ALIMENTATORI LED – DRIVER LED

CODE _mAI POWER_W _{min V}Input _{max V}Input _mmH P x L_mm BDF15 350 15 200 240 13,7 50 x 118

BDF15

CODE _mAI POWER_W _{min V}Input _{max V}Input _mmH P x L_mm BDF20 350 20 200 240 15 50 x 144

(47)

CODE V dc POWER W Input min V Input max V H mm P x L mm BPF6 12 6 200 240 10,7 45 x 88

Alimentatore led super slim in tensione costante 12V classe II, morsetti a vite

Super-slim 12V constant voltage LED power supply, class II, screw terminal

BPF6

ALIMENTATORI LED – DRIVER LED

CODE _dcV POWER_W _{min V}Input _{max V}Input _mmH P x L_mm BPF20 12 20 200 240 15 50 x 144

BPF20

(48)

CODE V dc POWER W Input min V Input max V H mm P x L mm BPF75 12 75 200 240 22 63 x 174

BPF75

ALIMENTATORI LED – DRIVER LED

CODE _dcV POWER_W _{min V}Input _{max V}Input _mmH P x L_mm BPH5 12 5 200 240 22 40 x 49

Alimentatore led in tensione costante 12V classe II, morsetti a vite IP20

12V constant voltage LED Power supply, class II, screw terminal IP20

BPH5

(49)

CODE V dc POWER W Cable in Mm Cable out mm H mm P x L mm BPFK6 12 6 1000 1000 10,7 45x88 BPFK15 12 15 1000 1000 13 51x128

Alimentatore led super slim in tensione costante 12V classe II, morsetti a vite con cablaggio IP20

Super-slim 12V constant voltage LED power supply, class II, screw terminal with wiring IP20

BPFK6 – BPFK15

ALIMENTATORI LED – DRIVER LED

Alimentatore led super slim in tensione costante 12V classe II, morsetti a vite con cavo IP20

Super-slim 12V constant voltage LED power supply, class II, screw terminal with wiring IP20

BPFK30 – BPFK50

CODE _dcV POWER_W Cable in_mm Cable out_mm _mmH P x L_mm BPFK30 12 30 1000 1000 18 58x160

(50)

ALIMENTATORI LED – DRIVER LED

CODE _dcV POWER_W Input _V IP _mmH P x L_mm BPH20 12 20 100/240 67 22 30 x 153

Alimentatore per led in tensione costante 12V con cavi di connessione 200 mm IP67

12V costant voltage LED driver with 200 mm connection cables IP67

BPH20

CODE _dcV POWER_W Input_V IP _mmH P x L_mm BPH36 12 36 170/250 67 32 41 x 152

BPH60 12 60 170/250 67 53 67 x 200

BPH36 – BPH60

CODE V dc POWER W Input V IP H mm P x L mm BPH80 12 80 220 67 45 45 x 180 BPH150 12 150 220 67 57 120 x 232

BPH80 – BPH150

(51)

BPH30

ALIMENTATORI LED – DRIVER LED

CODE _dcV POWER_W Input _min Input _max _mmH P x L_mm BPH6 12 6 200 240 20 42 x 92 BPH12 12 12 200 240 20 42 x 92 BPH15 12 15 200 240 20 42 x 92
