HP Client Virtualization

(1)

HP Client Virtualization

HP to deliver an accelerated path to a virtualized

enterprise

Johan Benning

HP EG ESSN

(2)

Build your business mobility environment with HP

Devices

Network

Security

ePrint

Integrations

Services

Cloud

Applications

(3)

Information access is expanding…

What’s happening now?

• 42% of commercial users have

3 or more compute devices!

–

Citrix poll

• 243 million tablets

expected by 2015 –

iSuppli

• Windows 8 will likely be in third place

behind Android and Apple

-

Gartner

Desktop

Applications

SaaS

Smart Device Apps

DaaS

Next Generation Virtual Workspace

Anytime, Anywhere, Any Device

--- User Virtualized ---

The PC Era

The Cloud Era

User tied to device

(4)

Mobility

Control Portal

Access

Devices

Hybrid Cloud

Public Cloud <--- > Traditional

Sharing

data

SBC

/ VDI

App store

SBC/VDI

(5)

Agenda

IT and Business Challenges

Introducing Client Virtualization

HP Reference Architectures for Client Virtualization

HP Blade Graphics Server

(6)

(7)

Provisioning new service today

Weeks to months

Set approvals,

Access controls

Test and quality

Activate service

Coordinate

install process

• Many people

• Many steps

• Prone to errors

• Much time

Business selects

application

Patch VMs, OSs,

applications

IT planning

meetings

Set up

networks

Purchase

assets

Set up Facilities

Set up

storage

Load OS

Load OSs

Load VMs

Install servers

Deploy

(8)

Faster than rate of babies born in the U.S.

10 VMs STARTED EVERY MINUTE

6 vMOTIONS PER SECOND

More VMs are in motion than planes in flight.

20 MILLION VMs

If they were physical machines they

would stretch

2x

length of

Great Wall of

China

Virtualization exploding to cloud

86 million VDI seats by 2014

Virtualized physical servers

deployed for HVD workloads to

reach ~17%

(9)

How does IT address this new environment?

• Devices for both personal &

work

• Windows and mobile

applications

• Maintain PC experience

anywhere

• Client device

administrative challenges

• Security & Compliance

• Unmanaged endpoints

• OS migration (e.g.

(10)

What we have: Devices…lots of devices

(11)

(12)

HP – Leading the Next Wave

Comprehensive Portfolio and Strategy

Servers

Storage

Heterogeneous Management & Security

Application Services

Client

Comprehensive Services: Strategy – Consulting – DC Outsourcing – Virtual Desktop

•Consolidate tools

•Automate management and

provisioning

•Performance Viewer

•Secure Virtualization Framework

•Single Security Model for

Physical/Virtual Data Center

•Compute and virtualize without

compromise

•Better density/ performance/

efficiency/economics

•3PAR StoreServ - Double VM density

per server, guaranteed

•StoreVirtual – Software-defined

storage, simple, scalable

• Best performance - User experience

• Smart Zero Clients – open, scalable

• Powerful device management

•Strategy – Assessment – Design – Capacity Advisor

Security

Management

(13)

• Primarily text based

applications

Task Worker

• Requires graphics

performance

• Some compute intense

apps

Desktop Power User

• Limited graphics and

minimal multimedia

Productivity & Knowledge

Worker

• 3D graphics applications

• Compute intensive

applications

Performance User

Adding graphics acceleration for VDI

Solution

Type

Clients

per host

Virtual Desktop

Infrastructure

Session

virtualization

> 200:1

~ 100:1

Software rendered graphics

Microsoft RemoteFX

HP Multi-GPU Pass-through

Multi-Dedicated

Graphics

Shared graphics

cards

~ 50:1

2+:1

Up to 8:1 Using HP Multi-Graphics Carrier (Gorgon)

Density

Performance /

Cost per user

(14)

(15)

RETHINKING DESKTOP ARCHITECTURES

Primary PC Challenge: PC components are bound

together, making hardware & software difficult &

expensive to replace

Data &

User Settings

Applications

Operating

System

Hardware

User Virtualization

Isolate and centralize user data & state

Application Virtualization

Isolate and centralize applications management &

deployment

OS Virtualization

Isolate OS management & deployment

Server Hosted

Client Hosted

Solution: Decouple layers and deploy virtualization

and management solutions

(16)

HP Storage (P2000, P4000, EVA, 3PAR)

HP Workstation Blades

HP Blades

VMWare vSphere

Microsoft Hyper-V

Citrix XenServer

Vmware vCenter

Microsoft SCVMM

Citrix XenCenter

Citrix XenDesktop

Windows Server 2012 RDS

Vmware View

Microsoft

RDP 6/7

Microsoft

RemoteFX

Citrix

ICA-HDX

Vmware

PCoIP

HP

RGS

Citrix XenApp

Microsoft RDS

Microsoft App-V

Vmware ThinApp

Citrix User

Profile Manager

AppSense Environment Manager

RES Workspace Manager

RTO

Virtual Profiles

CLIENT VIRTUALIZATION : YOU HAVE THE CHOICE

(17)

Only HP Reference Architectures are Proven End to End

Mobile

phone

HP Services

HP Client & Insight Control Management Tools with Plug-Ins

Thin Client

Tablet

Laptop

LAN/WAN

Servers

Network

Storage

User &

Desktop

Virtualization

Application

Virtualization

HP Client Virtualization

Reference Architecture for

(18)

SERVERS

STORAGE

NETWORKING

SOFTWARE

_APPSYSTEM

CLOUDSYSTEM

Best in class

HP Converged Systems

VIRTUALSYSTEM

(19)

Deploy

Test and

adjust

design as

required

Install and

update all

firmware

and

software

Perform

complex

assembly of

parts

Order large

collection of

parts

Develop

proposed

complex

design

Research

many

component

products

Remove complexity, implement quickly, deploy with confidence

HP Reference Architecture: the fastest time to value

Build Your Own

_{Find your mistakes and start over}

Success

Deploy

Test and

adjust

design as

required

Install and

update all

firmware

and

software

Perform

complex

assembly of

parts

Order large

collection of

parts

Select

Reference

Architecture

Reference

Architectures

VirtualSystem

(20)

HP Client Virtualization Gen8 Enterprise Reference

Architecture

What is it?

• Whitepaper for building a HP solution

for client virtualization workloads

• Sizing: For POC and Building Blocks

• BOM

• Performance using LoginVSI scripts

• Design for persistent or non-persistent

VM’s

www.hp.com/go/cv

(21)

HP Proliant BL460c Gen8 Blade Scalablity

HP Client Virtualization Reference Architecture

• 2 Intel XEON E5-2680 CPUs

• 256GB RAM

• Windows 7 64-bit VMs

• 1vCPU, 2GB Memory

User Type VSImax

Light

242 145 – 157

Medium

195 117 – 127

Heavy

164 82 – 90

User Type VSImax

Light

236 141 – 165

Medium

214 128 - 139

Heavy

174 95 - 104

VMware

(22)

Client virtualization reference architectures

Gen8 SMB

• 50 to 600 VM increments

• Simplified for smaller enterprises or branches

• Leverages same virtualization as Enterprise

Gen8 ENTERPRISE

• UP TO 3,250 VM’s

(23)

Improvements from G7 to Gen8 RA

Customer savings with Gen8 technology

• 45% fewer servers to support same number of users

• 30% less power used for compute

• 25% less rack space

• 50% less switching

• 50% less blade infrastructure to manage

Gen8 CV RA for:

• VMware View

• Citrix XenDesktop on MS Hyper-V

• Citrix XenDesktop on VMware vSphere

(24)

HP Client Virtualization Enterprise RA

(25)

Client virtualization reference architectures

Gen8 SMB

• 50 to 600 VM increments

• Simplified for smaller enterprises or branches

• Leverages same virtualization as Enterprise

Gen8 ENTERPRISE

• UP TO 3,250 VM’s

(26)

Built on NEW HP ProLiant DL380p Gen8

What’s New

• Up to 80% improved performance with 2X more memory capacity

• HP SmartDrives with 100%* more storage capacity and 200%

performance boost with new HP Smart Array controllers

• Networking choice with new network solutions (FlexibleLOM)

• Enhanced serviceability with fast access PCIe riser solutions and HP

Smart Socket guides

8SFF Model w/optional 8SFF

8LFF Model

8SFF Model w/locking bezel

* Available mid 2012

8SFF Model

25SFF Model

(27)

HP Client Virtualization SMB Reference Architecture

• Whitepaper for building a HP solution for

client virtualization workloads

• Performance using LoginVSI and VMware

Planner (VMware)

• Design for Persistent or non-persistent

VM’s

• Provide Sizing

• Provide BOM

Simple, affordable,

all-in-one configuration for mobile productivity and BYOD

HP DL 380p Gen8

(28)

SAN Storage

Active

VM Manager

Connection

Broker

Full Redundancy for High-Availability

Load Balancer

Enterprise architecture

(29)

Active

User Data

SMB architecture

Simplifying the VDI environment

All key features are

built-in:

 Connection brokering

 Dynamic provisioning

 High-availability

 Load balancing

 On-demand scaling

(30)

Rapidly deploy an easy, affordable configuration that scales from just 50 users with

predictable repeatable costs and performance.

HP CV SMB Reference Architecture for

Citrix VDI-in-a-Box

Key Features

• All-in-one design for 50 or 100 productivity users

• Predictable, repeatable costs

• Easy to deploy and scale

• Simplify remote and branch office IT operations

75 Productivity Users

HP ProLiant DL380p Gen8 Server

1 Intel Xeon E5-2680 @ 2.70GHz

128GB RAM - 16GB DDR3 DIMMs, 1333 MHz

6x 300GB + 2x 200GB 6G SAS 10kRPM 2.5in, RAID0+1

150 Productivity Users

1 HP ProLiant DL380p Gen8 Server

2 Intel Xeon E5-2680 @ 2.70GHz

256GB RAM - 16GB DDR3 DIMMs, 1333 MHz

(31)

Deploy an scalable, affordable configuration that leverages the same tools as

enterprise users with predictable, repeatable costs and performance.

HP CV SMB Reference Architecture for

VMware View

Key Features

• All-in-one design for 200 productivity users/server up to 3 servers

• Easy to deploy and scale based on same View software as enterprise

200 Productivity Users

1HP ProLiant DL380p Gen8 Server

2 Intel Xeon E5-2680 @ 2.70GHz

256GB RAM - 16GB DDR3 DIMMs, 1333 MHz

4 300GB 6G SAS 10kRPM 2.5in, RAID0+1

1 HP 365GB IO Accelerator Cards

1 HP Lefthand VSA Software

600 Productivity Users

3 HP ProLiant DL380p Gen8 Server

2/server Intel Xeon E5-2680 @ 2.70GHz

192GB RAM/ server - 16GB DDR3 DIMMs, 1333 MHz

4 300GB/server 6G SAS 10kRPM 2.5in, RAID0+1

1 HP 365GB/server IO Accelerator Cards

(32)

HP Client Virtualization SMB RA

• Up to

150 – 180

users per server

• Simplified for smaller enterprises or

branches

• Repeatable, predictable performance

and costs

• Microsoft Remote FX

• Efficient Management with Remote

Desktop Services

HP Proliant DL380p Gen8

2 Intel Xeon E5-2680 @ 2.7 GHz

256 GB RAM (DDR3, 1333 MHz)

2 x 200 GB SSD, RAID 1 (used for OS

and golden image)

6 x 300 GB 15k SAS, RAID 5 (used for

differential virtual hard disks)

4 x 1 GbE connections

(33)

HP Portfolio – the Thinclient you need

Easiest to Deploy & Manage

Zero

No-touch,

plug-n-play productivity

Smart Client

Zero configuration, Zero management,

Zero compromise

Flexible

Simple, secure, reliable computing

Mobility

t310

Teradici II

Ultimate PCoIP

performance

t410

Low footprint, great

experience in all

environment

t410 AiO

The world’s first

13-watt, one wire,

Power over Ethernet

t510 Series

Price/Performance

Optimized

t610 Series

Desktop performance and

maximum expansion

mt40 Series

Lightweight,

professional design

Greater Hardware & Software Flexibility, Performance

Smart zero, ThinPRO, Windows Embedded Standard 09, WES 7

(34)

Giving users choice

Hybrids

(35)

(36)

HP ElitePad Ecosystem

Expansion Jacket

Docking Station

Rugged

Case

Adapters &

Smart A/C Cable

Retail Jacket

ElitePad

Case

Productivity

Jacket

Executive

Tablet Pen

Multi-Tablet

Charging Module

(37)

(38)

HP Blade Graphics Server

Dedicated high performance computing for your most demanding uses:

• CAD engineers

• Imaging analysts

Traditional Desk Side Workstation

Benefits:

Provide workstation class attributes,

+



Improved security



Supplier and contractor access



Work from remote site or home office



Improved management & availability



Flexible disaster recovery



Enable engineering IT consolidation

• Financial traders

• Command & control

DCC

Engineering

Sciences

Command &

Control

Gaming

(39)

LAN or WAN

Capture, compress &

encrypt video

Thin Client

Provides workstation

dual / quad monitor

performance

Complex 3D & 2D, Client OS

applications run with

NVIDIA Quadro graphics

acceleration

Server

HP BL460c

Blade Server

Access broker

Capture keyboard,

mouse & USB

Network

HP Virtual

Connect Flex10

3D HP ws460c

Management

HP Insight Software

Complete control and availability, deep partner

integration, built in support automation.

3D Protocols

• HP RGS

• Citrix HDX 3D

• MS RemoteFX

• PCoIP

HP Blade Graphics Server WS460c

(40)

HP Multi-GPU Graphics

• 6x Q3000 or 8x Q1000 (using Multi GPU carrier)

• 16 physical cores, 512GB memory

• Windows on hypervisor; OGL & DirectX

HP Blade Graphics Server- Device Options

Now thru 2013

Dedicated Blade – available now

• One user per blade, Range of graphics, 16 cores, 512GB memory

• Windows or Linux on bare metal; OGL & DirectX

Microsoft RemoteFX

• API Intercept

• Up to 40 light graphics users per blade, Windows only on Hyper-V; DirectX only

NVIDIA GRID– available May-June

• K1 for shared graphics (API Intercept); targeted for media rich PC or light 3D

• K2 for direct mapped or virtualized GPU; two GPUs each equiv to a K5000

• Windows on hypervisor; OGL or DirectX

Number of

VMs dependent on

virtualization mode

K1

K2

K

E

P

L

E

R

(41)

(42)

The Desktop Transformation Journey…

Discover

Assess

Design

Pilot

Deploy/Manage

New World

Secure Mobile Collaboration

…Any device, anytime, anywhere, secure

Validate

(43)

Desktop transformation timeline

Activities

Timeline

1-2 Weeks

Prod/ Pilot

4-6 Weeks

Initial VDI Intro

Review Customer

Goals and

Objectives

Gather Details of

Customer

Environment

Install

Assessment

Software

Collect Data

Analyze Data

Present findings

Detailed Design

Based on CVAM

Assessment

Develop a POC

plan / SOW

Develop Success

Criteria

Configure, Install,

Integrate -Lab

Environment

Ensure Success

Criteria is Met

Define 1

st

Segment of Users

to Virt

Plan for All

Different User

Segmentation

Groups and Full

Deployment

Begin

Virtualization of

Users

30 –45 Days

5-7 days

1

st

_{Stage of}

Deployment 6-9

Months

Discover

CVAM

Design

POC

Deploy

Review POC

Results

Design VDI

Solution to Deploy

Knowledge

Transfer

Knowledge

Transfer

Share HP

Capabilities

Agree Upon Next

Steps

(44)

(45)

RESOURCES

HP Client Virtualization Portal

www.hp.com/go/clientvirtualization

or

www.hp.com/go/cv

Client Virtualization ROI Calculator

http://roianalyst.hp.com/roianalyst/Welcome.do

Client Virtualization Best Practices:

http://h30431.www3.hp.com/?fr_story=bb819a9bc4c2c9f77f6bbeb57fb087f363ee2eda&rf=bm

(46)

Bookmark and visit

The HP Client Virtualization portal on www.hp.com/go/cv

Thank you
