SkyRouter. Blue Sky Network Cloud-Based Global Command Center. FLEET COMMAND CENTER for Blue Sky Network s Tracking & Communication Devices

FLEET COMMAND CENTER

for Blue Sky Network’s

Tracking & Communication Devices

Blue Sky Network

Cloud-Based Global Command Center

Secure Web-Portal For Monitoring, Communicating With and Managing Global Fleet Assets

The Industry’s Most Advanced

Cloud-Based Command Center

For Global Fleet Management

Global Monitoring, Communication & Management

SkyRouter is a cloud-based web portal designed and operated by Blue Sky

Network that provides tracking and managing of globally dispersed assets from

any internet-connected device - without having to install additional hardware or

software. Communicating with deployed Blue Sky Network devices, SkyRouter is

a secure website that display GPS position reports, special events, two-way text

messages, emergency SOS, and telemetric data. Boasting the industry’s most

innovative control and mapping functions, you can effectively manage your fleet

in ways you never thought possible. Way beyond tracking, SkyRouter allows asset

managers to monitor, interact, control, and communicate with field assets more

efficiently. This translates into lower operating costs and

improved safety for your personnel—every trip, every voyage,

every flight, every day. SkyRouter and HawkEye SATCOM

products provide the most advanced command center and

management platform available in the industry today.

SkyRouter

HOME

TAB

1

2

3

4

1

2

3

4

6

SkyRouter Notifications Area

Notification area shows any system notifications that have been posted by the SkyRouter System Adminstrators such as maintenance schedules.

Device Alerts

View alerts that have been

configured to occur when specific events happen.

Messages

Shows unread messages from any of your field device operators, and allows you to quickly respond.

Feedback

Provide feedback to Blue Sky Network at any time regarding product improvement. You are directly plugged into our R&D Department and our product improvement process.

7

7

8

Configure 4 clocks to different times zones related to your business

Information & News Ticker

This area may contain recent news from Blue Sky Network about new products, services and general updates about accomplishments or milestones

A Quick Overview Of Your Entire Fleet Operations

Installed Aviation Portable Aviation, Land Mobile & Maritime Installed Land Mobile Hand-Held Aviation, Land Mobile & Maritime

5

Identifies what percentage of your fleet is currently in use.

6

Shows all of your assets on the map at the same time.

5

TRACK

TAB

1

2

3

4

7

2

3

4

5

Move, zoom, measure, and add additional map windows. You can create geo-fences, change map settings

Assets

List of your assets, events and filters that you apply to the lists. Right-click each asset to reveal additional information

Events

List of events that have occured in the last 48 hours

Locations

List of your custom locations and a place where you can add new or edit existing locations

6

5

6

Options

Options for controlling the asset breadcrumbs and map overlays

Geo-Fence

Create radial, polygonal, and Automated Variable Response (AVR) geo-fences to create alarms, events or changes to your tracking system as assets enter or exit specified areas

Monitor & Manage Your Assets on Multiple Maps in Near Real-Time

8

7

8

SkyRouter Map Area

Main map display area for single or multiple maps

Saved Views

Your custom views can be found here as well as other tools for view control.

1

9 Multi-Map Views

View assets on multiple maps by clicking on the Add or Remove Map Tile icon in the Map Tool Bar

MANAGE

TAB

1

3

4

5

Full Adminstrative Control Of Every Device In The Field

6

7

8

9

6

1

2

3

4

List of your assets, events and filters that you apply to the lists. Right-click each asset to reveal additional information

Device Parameters

Update device parameters and reporting intervals for each device

Device Profiles

Update reporting settings and short codes

Locations

List of your custom locations and a place where you can add new or edit existing locations

5

6

PINs

Set up access codes for each user

Groups

Add new user groups or updating existing

7

8

Users

Set up new or edit existing users, manage each user’s access rights, reset passwords, view last activity by user

Alerts

Set up and manage alerts for various types of events, such as take off, landing, enter geo-fence

9

Explorer, add data sharing

2

10

11

12

Flight Plan

Add activities, like ETD, ETA, fuel

Geofences

Set up geofences, such as no-reporting zones and no-go zones

Map Settings

Set up Bing Maps, Traffic, SkyRouter Classic Maps

10 11 12

SkyRouter

Cloud-Based Command Center

Improving Operational Efficiency & Safety For

REPORT

TAB

1

2

3

4

1

2

3

4

5

Status report provides a quick up-date into the status of your fleet, such as last known location

Device Event

Choose the device you want to include in a custom report

Device Inventory

View device types, firmware versions, time of last report

Google Earth

View trips and tracking on a 3D Google Earth background

6

5

6

Playback

View past trips on a timeline map view that allows you to control the speed of the playback

Group Association

View and filter associations between groups, devices, users

Generate Multiple Pre-Formatted Reports and Export To PDF or CSV

7

8

7

Automatic reports such as delivery stops, geofence events, utilization, speeding & travel time

8

Generate trip reports and export them as PDF or CSV files

COMMUNICATION

TAB

1

2

3

2

3

View your mailbox structure just like a standard email client

Folders Content Window

List of all the items in the selected folder

Menu Bar

Create new emails, specify

device, delete, reply, forward, edit, rename, etc.

Write, Edit, & Forward All Communications To And From Field Assets

FORM

TAB

1

2

3

2

Form Listings

Shows a list of the forms available to you

Folders Selection Menu

Select which form you want to use from the pull-down menu

Form - Asset Information

Basic information about the asset and operator

4

Communicate Formatted Data Sets With Customized Forms

3

1

SkyRouter

Know Where Your Assets & People

Are All Of The Time

Tracking of Assets

SkyRouter includes a number of access accounts, so you can set up

password-required access for business employees or for familiy and friends. Give your

employees peace of mind and instant status on their family members, or keep

track of your valuable assets and personnel during any type of worldwide trip or

travel.

Access can be customized per account, allowing certain accounts to see and do

more than others. Divide your fleet into groups, or separate family members from

company employees - specifying what each group can see and do.

Only SkyRouter from Blue Sky Network gives you all this power

and the flexibility to manage your fleet by customizing it

to a much greater degree than other cloud-based tracking

Feature-packed and va

Connections to SkyRouter are secured using HTTPS/TLS1.2, encrypted with AES_256_CBC and utilizing 2048-bit root keys.

SkyRouter servers are hosted in a fully redundant SSAE 16 (SOC1 type 2) data center which has zero operational exceptions for the last 5 consecutive years.

SkyRouter servers comprise fully redundant hardware and access to which is controlled by redundant Enterprise-class Secure Services Gatelway devices.

Iron-Clad Security

Se

With SkyRouter, You Can

Be Confident That Your

Data Is Secure

SkyRouter

Corporate Headquarters

1298 Prospect Street, Suite 1D, La Jolla, CA 92037 +1-858-551-3894

www.blueskynetwork.com

Blue Sky Network is an industry leading developer and supplier of global SATCOM solutions for managing remote aviation, maritime, and land/mobile assets via satellite. Its interactive web portal, SkyRouter, offers extensive tracking, communicating and managing functionality without the expense and difficulty of additional computer hardware/software. Offering detailed mapping options of field assets, Blue Sky Network solutions link enterprises to personnel and assets anywhere on earth using Iridium and GNSS satellite networks. FAA-certified data and voice products enable users to customize features including safety and event reporting. Blue Sky Network’s exceptional customer service and innovative products make us the perfect partner for expanding global communication/ tracking to your transportation fleet and personnel. Call us today for a free consultation with our experienced staff.
