A completed Ser 1 E-Type body shell built to system 3 specifications ready for the paint process

(1)

(2)

Martin Robey Engineering

Limited have been producing

completely new Body Shells for

E Type Jaguars since 1982, after

restoring several Body Shells it

was apparent that they all suffered

were removed it only revealed

further corrosion and undesirable

repairs, there never seemed much

of the original body left before the

rebuild could take effect, therefore

it was decided to produce the few

remaining panels that were not in

production at the time and start

producing all New Body Shells.

To accommodate customers

with some of their own parts

such as Doors, Boot Lids and

Bonnets the “System One, Two

and Three” processes came about.

“Floor Units” & “Sub-Assemblies”

are also available for the

experienced who wish to rebuild

their Body Shell or complete a “Sub

Assembly” using “Our Panel Kits”.

The Body Shells use high quality

Martin Robey Body Panels

that are Pressed Out, Laser

Profiled and assembled using

Motor Industry Methods and

equipment, quality appearance

and dimensional accuracy to

the original specification is an

important feature of the Martin

Robey Panels and Body Shells.

The build process involves using

sub units such as Bulkheads,

Floors, Rear End Assemblies

etc., which are all assembled

Ser.1-2 and 3 Models are

available in both Drop Head

and Fixed head versions.

the completed Bodies are

Lead Loaded Cleaned off, the

door seals are fitted to give a

better than original fit to

Door, Bonnet gaps etc.

External Chrome work is trial

fitted prior to leaving the works

where the Body Shells can be

ready for the Paint Process.

Martin Robey Engineering Ltd. recently installed its very first Robot. The Robot is the latest of many of the company’s machines that are fully computerised.

A completed Ser 1 E-Type body shell built to system 3 specifications ready for the paint process

(3)

08/2015

Full Body Shells are available in several variation we call them “System Rebuilds”.

“System I” is a complete Body Shell, all new with a Bulkhead fitted and all welded with your

Doors and Bootlid Fitted, Lead Loaded and cleaned back, all fully jig Built.

Series

1

3.8

DHC

models

£26,794.43*

Series

1

4.2

DHC

models

£26,834.50*

Series

2

4.2

DHC

models

£26,840.24*

“System II” is a System I with a Doors and Boot Lid Supplied and Fitted

Series

1

3.8

DHC

models

£28,703.04*

Series

1

4.2

DHC

models

£28,743.26*

Series

2

4.2

DHC

models

£28,229.77*

“System III” is a System II with a Bonnet supplied and fitted with front-rear lights, Bumpers,

Door chromes and trial fitting.

Series

1

3.8

DHC

models

£36,398.36*

Series

1

4.2

DHC

models

£36,438.54*

Series

2

4.2

DHC

models

£36,418.58*

Fixed Head Models

Prices shown are for Ser.1-2 Drop Head Coupe Models. For Fixed Head Coupes please add

£9,500 based upon customer supplying roof assembly and rear hatch unit in suitable

con-dition.

All Prices are EX-Works and subject to VAT if applicable *Aug 2015 - Jul 2016

System Re-Builds are available normally in approximately 18-26 weeks from order and deposit.

The prices given do not include any Fixtures, Fittings, Hinges, Locks, Engine Frames etc, or

Packing or Shipping.

Additional Equipment: Inner Sill Reinforcing

£150.00, Inner Seat Belt Kit £100.00, Early 3.8

Features Can Be Incorporated Into Systems

and Sub Assembly units.

A Ser.1 3.8 DHC restored at the works using a complete Martin Robey Body Shell to System 3 Specifications.

(4)

vehicles exactly the same in the first few

days-weeks of production. It must be

remembered that some vehicles will have

undergone factory upgrades or as part of

general servicing or restoration during the

life of the vehicle.

It must be also remembered that

many more vehicles were exported to the USA that upgrades may have been incorporated to Federal

Specification Cars that UK Cars built in the same period so dates of manufacture is not the only

consideration to be made, Chassis or VIN Number is the most important Allie in identifying early features,

there are several books available that list most, but not every feature by relevance to chassis Number.

We offer most of the important Early Features for the Ser.1 3.8 models, we offer them as a Fixed Price

Supplement and can usually accommodate other less well known features that may have been fitted to a

very smaller number of vehicles or perhaps just the one.

Early Features 3.8 Ser.1

Bonnet (Front End)

Separate Louvre Panels

Spot Weld Air Valence Panels

Seam Welded Centre Panel Nose Section

Side Locking Mechanism

Bulkhead Unit

Bolt On Mirror Rod Bracket Fixings

Pop Riveted Brake-Clutch Reservoir Bracket

Side Locking ‘A’ Post Without Pressing For Lock Rod

Transmission Tunnel Side Panel RH Plain Pressing

Inner Sill

Weld Nuts For Side Locking Bonnet Catches

Floor Panels

Flat Floors Without Footwell Including Separate (2 Part) Radius Cup Mounting

Plate

Rear Bulkhead Panel

Straight One Piece Without Separate Weld For Extra Seat Movement

Door Assembly

Early Style Door Inner Panel, FHC & DHC

Early Style Drip Tray, FHC & DHC

Door Skin 2 Part With Spot Welded Top Section For Slim Early Top Door

Chromes Finisher (DHC Only)

Boot Floor & Rear End

Assembly

Pop Riveted Reversing Light Pod With Boot Floor Rails One Piece Spot Welded

Pop Riveted Reversing Light Pod With Boot Floor Stiffeners 3 Part Style With

Centre One Pop Riveted In Position

Pop Riveted Reversing Light Pod With All Rails 3 Part Style All Pop Riveted In

Position

Water Drain Tubes

1 Central One Fitted On LH Side Of Reversing Light Pod

1 Central Plus 1 Further On RH Rear Quarter Panel

Number Plate Panel

Small Aperture For Rear Light Access

Fuel Filler Box

Fuel Filler Box without Reinforcing Indentation top Half Of filler Box And

Without Drawn Tube To Fuel Box

Please Note:

There are other early features to the Body Shell Units

Please do not hesitate to talk to us about your Motor Car; we can usually accomodate these even if not

listed

(5)

08/2015

A “Sub Assembly Unit” is a Body Shell with a New Bulkhead supplied and fitted but

without the outer body panels supplied and fitted.

“Ser 1 3.8 Sub Assembly Unit” with Bulkhead

£ 14,192.25*

£ 14,232.25*

£ 14,291.59*

The Sub Assembly is designed for the experienced amateur Body Builder or the Professional

Body Shop. These Units are mostly welded together and can be completed without the

use of a Full Assembly Jig.

Sub Assembly without Bulkhead and without the Outer Body Panels Fitted.

“Ser 1 3.8 DHC Sub Assembly Unit” without Bulkhead £9,488.98*

Delivery is usually approximately 6-10 weeks from Order.

The cost of a new bulkhead not fitted is

£4,703.27*

The outer Body Panels that are not fitted are available in Kits.

Being:

Ser 1 DHC 3.8 & 4.2 “Alpha” Base Kit (See list of Parts)

£2,187.57*

Ser 1 DHC 3.8 & 4.2 “Beta” Alpha Kit plus Door and Bootlid

£4,090.08*

Ser 1 DHC 3.8 & 4.2 “Delta” which is a Beta plus a Bonnet

£9,514.40*

All prices are ex works and subject to Value Added Tax for European Sales.

* Aug 2015 - July 2016

ADDITIONAL EQUIPMENT

Inner Sill Reinforcing £150.00

Inner Seat Belt Kit £100.00

Early 3.8 Features Can Be Incorporated Into

Sub Assembly Also

(6)

Series 1 and Series 2-3 E-type models, we can

vary the content of the unit to suit to vehicle

requirements. Therefore any prices shown are

to guide only.

Guide price with new bulkhead supplied and fitted £13,701.15 + VAT

They are designed for fitting

the roof assembly and outer panels by

a professional restorer or experienced

enthu-siast. They can be supplied with a either a new

bulkhead supplied and fitted, using a reconditioned

bulkhead or using a suitable bulkhead supplied by a

customer.

(7)

08/2015

Floor Units

Full floor unit For Series 1 3.8 flat floor model

3.8 Footwell floor assembly

Available for series 1&2 Drop Head and Fixed Head models

£1,313.57*

(Ex.VAT)

£3,025.12*

(Ex.VAT)

Call for more information!

+44 (024) 76386903

(8)

SUB ASSEMBLY UNIT FOR SER.1 3.8

ROADSTER WITH REAR END ASSEMBLY

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

The above are mostly welded in place except for some items that may require slight adjustment before welding.

This Assembly is Jig Built and can be supplied with a Kit of Outer Body Panels that are not Fitted to the above Sub Assembly.

SUB ASSEMBLY WITHOUT BULKHEAD £9,488.98

SUB ASSEMBLY WITH BULKHEAD £14,192.25 3.8 shown for illustration only._{Unit Fitted}

With Inner Sill Reinforcings

Qty Part Number Description Individual Price Combined Price

1 X BULKHEAD BULKHEAD UNIT INCLUDING TOP SKUTTLE PANEL £4,703.27 £4,703.27 2 X BD16008F/R FUEL TANK MTG BRACKET £16.15 £32.30

1 X BD16212 REINFORCING TONNEAU £59.78 £59.78

2 X BD18949/50 BOOT HINGE MTG BRACKET £13.06 £26.12 1 X BD18963 INTERIOR LIGHT SHIELD £29.34 £29.34 1 X BD27181 FUEL PUMP MTG BRACKET £19.11 £19.11 2 X MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 2 X MRE112ALH/BRH TRANSMISSION TUNNEL SIDE PANELS £62.81 £125.62

1 X MRE115 TUNNEL STIFFENER £47.92 £47.92

2 X MRE117LH/RH STIFFENERS £40.99 £81.98

2 X MRE118LH/RH CLOSING PANEL £22.41 £44.82

1 X MRE119 CENTRAL TUNNEL FACING £68.59 £68.59

2 X MRE120LH/RH TUNNEL FWD SIDE £103.66 £207.32

2 X MRE121LH/RH INNER PEDAL SIDE £13.23 £26.46

1 X MRE122RH OUTER PEDAL £13.06 £13.06

1 X MRE122ELH OUTER PEDAL SIDE 3.8 £21.67 £21.67

2 X MRE14LH/RH FULL FLOOR £210.42 £420.84

2 X MRE15LH/RH INNER SILLS £81.10 £162.20

2 X MRE19 FRONT STIFFENERS £17.81 £35.62

2 X MRE20RH/LH REAR STIFFENERS £17.81 £35.62

1 X MRE24A CROSSMEMBER TO FULL FLOOR £68.01 £68.01

2 X MRE29RH/RH INN ARCH LH £255.93 £511.86

2 X MRE2LH/RH BHD TO SILL £21.29 £42.58

2 X MRE30RH/LH DOOR SHUT FACE PANEL ASSY £41.75 £83.50 1 X MRE3ARH RH 3.8 BULKHEAD PANEL £37.58 £37.58 1 X MRE4ALH LH 3.8 BULKHEAD PANEL £37.58 £37.58

1 X MRE42A CLOSING PANEL £44.18 £44.18

1 X MRE58 UPPER FLOOR £293.96 £293.96

2 X MRE59LH/RH FLOOR STIFFENER BRACKETS £23.61 £47.22

1 X MRE60 TUNNEL ASSEMBLY £224.51 £224.51

1 X MRE61 TOP PANEL REAR FLOOR £77.26 £77.26

1 X MRE62 PANEL FRONT TO BOOT FLOOR £59.50 £59.50

1 X MRE63 PANEL ASSEMBLY £85.52 £85.52

1 X MRE64 REAR BULKHEAD £170.06 £170.06

1 X MRE65 REINF CHANNEL £146.54 £146.54

1 X MRE68BRH RH 38 ARCH VALANCE £140.83 £140.83

1 X MRE68LH INN VALANCE LH £140.83 £140.83

2 X MRE69LH/RH ARCH FWD £135.53 £271.06

2 X MRE71LH/RH TOP PANEL INNER £77.61 £155.22

2 X MRE72LH/RH REAR CHASSIS LEGS £230.36 £460.72 2 X MRE73A RADIUS ARM CUPS (RIVETED) £50.01 £100.02 2 X MRE76LH/RH INNER PANEL DOOR SHUT FACE £57.37 £114.74 1 X MRE96A REAR END ASSEMBLY D.H.C. £889.93 £889.93 Bulkhead £4,703.27 Parts Total Excl Bulkhead £5,738.98 Labour For Assembly £3,750.00 Total Sub Assembly Cost £14,192.25

(9)

08/2015

Pool Road,

Camphill Industrial Estate, Nuneaton, Warwickshire CV10 9AE England TELEPHONE No. +44 (024) 76 386903 FAX No. +44 (024) 76 345302 E-MAIL [email protected] WEBSITE www.martinrobey.com COMPANY REG No. 1980684

VAT REG No. GB 487 666 775

SUB ASSEMBLY UNIT FOR SER.1

4.2 ROADSTER WITH REAR END ASSEMBLY

Qty Part Number Description Individual Price Combined Price

1 x BULKHEAD BULK HEAD UNIT INCLUDING SKUTTLE PANEL £4,703.21 £4,703.21 2 x BD16008F/R FUEL TANK MTG BRACKET £16.15 £32.30 1 x BD27181 FUEL PUMP MTG BRACKET £19.11 £19.11 2 x MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 1 x MRE112C TRANSMISSION TUNNEL SIDE PANELS SER.1 £62.81 £62.81 1 x MRE112D TRANSMISSION TUNNEL SIDE PANELS SER.1 £62.81 £62.81

1 x MRE115 TUNNEL STIFFENER £47.92 £47.92

2 x MRE117LH/RH STIFFENERS £40.99 £81.98

2 x MRE118LH/RH CLOSING PANEL £22.41 £44.82

1 x MRE119A CENTRAL TUNNEL FACING SER.2 £68.59 £68.59

1 x MRE120RH TUNNEL FORWARD SIDE £103.66 £103.66

1 x MRE120LH TUNNEL FWD SIDE £103.66 £103.66

2 x MRE121LH/RH INNER PEDAL SIDE £13.23 £26.46

2 x MRE122LH/RH OUTER PEDAL £13.06 £26.12

2 x MRE14LH/RH FULL FLOOR £210.42 £420.84

2 x MRE15LH/RH INNER SILLS £81.10 £162.20

2 x MRE19 FRONT STIFFENERS £17.81 £35.62

2 x MRE20LH/RH REAR STIFFENERS £17.81 £35.62

1 x MRE25A CROSSMEMBER SLANT FULL £68.11 £68.11

2 x MRE29LH/RH INN ARCH LH £255.93 £511.86

2 x MRE2LH/RH BHD TO SILL £21.29 £42.58

2 x MRE30LH/RH DOOR SHUT PANEL SER.2 £41.75 £83.50

1 x MRE3RH BULKHEAD PANEL £37.58 £37.58

1 x MRE42 CLOSING PANEL SER.1 DHC £61.02 £61.02 1 x MRE4LH BULKHEAD PANEL 4.2 EARLY £37.58 £37.58

1 x MRE58 UPPER FLOOR £293.96 £293.96

2 x MRE59LH/RH FLOOR STIFFENER BRACKETS £23.61 £47.22

1 x MRE60 TUNNEL ASSEMBLY £224.51 £224.51

1 x MRE61 TOP PANNEL REAR FLOOR £77.26 £77.26

1 x MRE62A PANEL TO BOOT FLOOR 4.2 £59.50 £59.50

1 x MRE63 PANEL ASSEMBLY £86.52 £86.52

1 x MRE64 REAR BULKHEAD £170.06 £170.06

1 x MRE65 REINFORCED CHANNEL £146.54 £146.54

1 x MRE66 REINFORCING CHANNEL TONNEAU £114.79 £114.79

2 x MRE68LH/RH INN VALANCE £140.83 £281.66

2 x MRE69LH/RH ARCH FWD £135.53 £271.06

2 x MRE71LH/RH TOP PANEL INNER £77.61 £155.22

2 x MRE72LH/RH REAR CHASSIS LEGS £230.36 £460.72 2 x MRE73A RADIUS ARM CUPS (RIVETED) £50.01 £100.02 2 x MRE76LH/RH INNER PANEL DOOR SHUT FACE £57.37 £114.74

2 x MRE9ALH/ARH BULKHEAD D PANEL £15.59 £31.18

1 x MRE96A REAR END ASSY D.H.C. £889.93 £889.93 Bulkhead £4,703.21 Parts Total Excl Bulhead £5,779.04 Labour For Assembly £3,750.00 Total Sub Assembly Cost £14,232.25

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

This Assembly is Jig Built and can be supplied with a Kit of Outer Body Panels that are not Fitted to the above Sub As-sembly.

SUB ASSEMBLY WITHOUT BULKHEAD £9,529.04 SUB ASSEMBLY WITH BULKHEAD £14,232.25

3.8 shown for illustration only. Unit Fitted With Inner Sill Reinforcings

(10)

SUB ASSEMBLY UNIT FOR SER.2

4.2 ROADSTER WITH REAR END ASSEMBLY

Qty Part Number Description Individual Price Combined Price

1 x BULKHEAD BULK HEAD UNIT INCLUDING SKUTTLE PANEL £4,707.27 £4,707.27 2 x BD16008F/R FUEL TANK MTG BRACKET £16.15 £32.30 1 x BD27181 FUEL PUMP MTG BRACKET £19.11 £19.11 2 x MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 1 x MRE112C TRANSMISSION TUNNEL SIDE PANELS SER.2 £62.81 £62.81 1 x MRE112E TRANSMISSION TUNNEL SIDE PANELS SER.2 £62.81 £62.81

2 x MRE118LH/RH CLOSING PANEL £22.41 £44.82

1 x MRE119A CENTRAL TUNNEL FACING SER.2 £68.59 £68.59 1 x MRE120RH TUNNEL FORWARD SIDE £103.66 £103.66

1 x MRE120LH TUNNEL FWD SIDE £103.66 £103.66

2 x MRE121LH/RH INNER PEDAL SIDE £13.23 £26.46

2 x MRE122LH/RH OUTER PEDAL £13.06 £26.12

1 x MRE25A CROSSMEMBER SLANT FULL £68.11 £68.11

2 x MRE29LH/RH INN ARCH LH £255.93 £511.86

2 x MRE32LH/RH DOOR SHUT PANEL SER.2 £65.39 £130.78

1 x MRE42 CLOSING PANEL SER.1 DHC £61.02 £61.02 1 x MRE4LH BULKHEAD PANEL 4.2 EARLY £37.58 £37.58

1 x MRE58 UPPER FLOOR £293.96 £293.96

1 x MRE62A PANEL TO BOOT FLOOR 4.2 £59.50 £59.50

1 x MRE64 REAR BULKHEAD £170.06 £170.06

1 x MRE65 REINFORCED CHANNEL £146.54 £146.54

1 x MRE66 REINFORCING CHANNEL TONNEAU £114.79 £114.79

2 x MRE68LH/RH INN VALANCE £140.83 £281.66

2 x MRE69LH/RH ARCH FWD £135.53 £271.06

2 x MRE71LH/RH TOP PANEL INNER £77.61 £155.22

2 x MRE72LH/RH REAR CHASSIS LEGS £230.36 £460.72 2 x MRE73A RADIUS ARM CUPS (RIVETED) £50.01 £100.02 2 x MRE76LH/RH INNER PANEL DOOR SHUT FACE £57.37 £114.74

2 x MRE9ALH/ARH BULKHEAD D PANEL £15.59 £31.18

1 x MRE96C REAR END ASSY D.H.C. £889.93 £889.93 Bulkhead £4,707.27 Parts Total Excl Bulhead £5,826.32 Labour For Assembly £3,758.00 Total Sub Assembly Cost £14,291.59

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

SUB ASSEMBLY WITHOUT BULKHEAD £9,584.32 SUB ASSEMBLY WITH BULKHEAD £14,291.59

(11)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

SUB ASSEMBLY UNIT FOR JAGUAR E TYPE SER.1

3.8 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 x BULKHEAD BULK HEAD UNIT INCLUDING SKUTTLE PANEL £4,703.27 £4,703.27 2 x MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 2 x MRE112ALH/BRH TRANSMISSION TUNNEL SIDE PANELS £62.81 £125.62

2 x MRE118ALH CLOSING PANEL LH £18.69 £37.38

1 x MRE118ARH CLOSING PANEL £18.69 £18.69

1 x MRE24A CROSSMEMBER TO FULL FLOOR £68.01 £68.01 2 x MRE28LH/RH INNER WHEEL ARCH SECTION FORWARD £177.99 £355.98

2 x MRE29BLH/RH INN ARCH LH £266.98 £533.96

2 x MRE30LH/RH DOOR SHUT PANEL FHC £41.75 £83.50

1 x MRE42 CLOSING PANEL SER.1 £61.02 £61.02

1 x MRE4LH BULKHEAD PANEL £37.58 £37.58

1 x MRE58 UPPER FLOOR £293.96 £293.96

1 x MRE62 PANEL TO BOOT FLOOR £59.50 £59.50

2 x MRE72LH/RH REAR CHASSIS LEGS £230.36 £460.72 2 x MRE73A RADIUS ARM CUPS (RIVETED IN POSITION) £50.01 £100.02

2 x MRE76ALH/RH INN SHUT RH/LH £62.91 £125.82

2 x MRE78LH/RH INN VALANCE LH £387.41 £774.82

1 x MRE96B REAR END ASSEMBLY, COMPLETE WITH BOOT FLOOR

NUMBER PLATE PANEL ETC SER.1 FHC £889.93 £889.93 2 x MRE9ARH/ALH FRONT INNER BULKHEAD PABEL £15.39 £30.78 2 x MRE9BLH/BRH INNER BULKHEAD PANEL SIDE £44.18 £88.36

1 x MRE43 REAR CLOSING PANEL £59.80 £59.80

Bulkhead £4,703.27 Parts Total Excl Bulhead £5,582.70 Labour For Assembly £3,415.18 Total Sub Assembly Cost £13,701.15

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

SUB ASSEMBLY WITHOUT BULKHEAD £ 8,832.70

SUB ASSEMBLY WITH BULKHEAD £13,535.97 _{3.8 shown for illustration only.}

Unit Fitted With Inner Sill Reinforcings

(12)

SUB ASSEMBLY UNIT FOR JAGUAR E TYPE SER.1

Qty Part Number Description Individual Price Combined Price

1 x BULKHEAD BULK HEAD UNIT INCLUDING SKUTTLE PANEL £4,703.27 £4,703.27 2 x MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 2 x MRE112C/D TRANSMISSION TUNNEL SIDE PANELS £62.81 £125.62

1 x MRE42 CLOSING PANEL SER.1 £61.22 £61.22

1 x MRE58 UPPER FLOOR £279.96 £279.96

1 x MRE96B REAR END ASSEMBLY, COMPLETE WITH BOOT FLOOR

NUMBER PLATE PANEL ETC SER.1 FHC £889.93 £889.93 2 x MRE9ARH/ALH FRONT INNER BULKHEAD PABEL £15.59 £31.18 2 x MRE9BLH/BRH INNER BULKHEAD PANEL SIDE £44.18 £88.36

Bulkhead £4,703.27 Parts Total Excl Bulhead £5,570.10 Labour For Assembly £3,250.00 Total Sub Assembly Cost £13,523.37

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

SUB ASSEMBLY WITHOUT BULKHEAD £ 8,820.10

SUB ASSEMBLY WITH BULKHEAD £ 13,523.37 3.8 shown for illustration only._{Unit Fitted}

(13)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

SUB ASSEMBLY UNIT FOR JAGUAR E TYPE SER.2

ALL PRICES SUBJECT TO VAT AS APPLICABLE AND IN GBP

SUB ASSEMBLY WITHOUT BULKHEAD £ 8,819.86 SUB ASSEMBLY WITH BULKHEAD £13,523.13

Qty Part Number Description Individual Price Combined Price

1 x BULKHEAD BULK HEAD UNIT INCLUDING SKUTTLE PANEL £4,703.27 £4,703.27 2 x MRE10LH/RH SIDE FRAME LOWER MTG BRACKETS £38.70 £77.40 2 x MRE112C/E TRANSMISSION TUNNEL SIDE PANELS £62.81 £125.62

1 x MRE58 UPPER FLOOR £293.96 £293.96

1 x MRE96C REAR END ASSEMBLY, COMPLETE WITH BOOT FLOOR NUMBER PLATE PANEL ETC SER.1 FHC

£889.93 £889.93 2 x MRE9ARH/ALH FRONT INNER BULKHEAD PABEL £15.59 £31.18 2 x MRE9BLH/BRH INNER BULKHEAD PANEL SIDE £44.18 £88.36

Bulkhead £4,703.27 Parts Total Excl Bulhead £5,569.86 Labour For Assembly £3,250.00 Total Sub Assembly Cost £13,523.13

(14)

ALPHA PANEL KIT SERIES 1 3.8 & 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

2 X MRE1LH/RH SILL END CLOSING PANELS 14.74 29.48

2 X MRE2LH/RH BULKHEAD TO SILL PANELS 21.29 42.58

2 X MRE5-6 BATT-AIR CLEANER MTG BKTS 16.26 32.52

2 X MRE9LH/RH BULKHEAD SIDE PANELS 51.58 103.16

2 X MRE17LH/RH OUTER SILLS 85.52 171.04

2 X MRE38LH/RH STIFFENERS FROM LOWER QTRS TO No. PLATE 18.74 37.48

1 X MRE44A REAR TONNEAU PANEL 171.72 171.72

1 X MRE67 TONNEAU TOP PANELS 119.15 119.15

2 X MRE70LH/RH TOP PANEL TO HOOD 50.77 101.54

1 X MRE75LH REAR OUTER WING 523.49 523.49

1 X MRE75RH REAR OUTER WING 523.49 523.49

2 X MRE98LH/RH REAR LIGHT FILLETS 50.56 101.12

1 X BD15933 FUEL FILLER BOX 204.24 204.24

2 X BD19532-33 MOUNTING BRACKETS 6.74 13.48

Total Excluding VAT £2,187.57

VAT @ 20% £437.51

Total Inc. VAT £2,625.08

(15)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

ALPHA PANEL KIT SERIES 1 3.8 & 4.2 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 X MRE44 REAR TONNEAU PANEL 171.72 171.72

1 X MRE75ALH REAR OUTER WING 785.24 785.24

1 X MRE75ARH REAR OUTER WING 785.24 785.24

2 X MRE98LH/RH REAR LIGHT FILLETS 50.56 101.12

Total Excluding VAT £2,492.38

VAT @ 20% £498.48

Total Inc. VAT £2,990.86

(16)

ALPHA PANEL KIT SERIES 2 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

1 X MRE44C REAR TONNEAU PANEL 207.06 207.06

1 X MRE67 TONNEAU TOP PANELS 119.15 119.15

1 X MRE75LH REAR OUTER WING 523.49 523.49

2 X BD35684/3 REAR LIGHT FILLETS 73.65 147.3

2 X BD35620/1 MOUNTING BRACKETS 9.32 18.64

Total Excluding VAT £ 2,173.32

VAT @ 20% £ 434.66

Total Inc. VAT £ 2,607.98

(17)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

Qty Part Number Description Individual Price Combined Price

1 X MRE44B REAR TONNEAU PANEL 150.79 150.79

1 X MRE75ALH REAR OUTER WING 785.24 785.24

1 X MRE75ARH REAR OUTER WING 785.24 785.24

2 X BD35620/1 MOUNTING BRACKET 9.32 18.64

VAT @ 20% £ 493.97

Total Inc. VAT £ 2,963.83

ALPHA PANEL KIT SERIES 2 4.2 FIXED HEAD COUPE

(18)

BETA PANEL KIT SERIES 1 3.8 & 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

2 X MRE1LH/RH SILL END CLOSING PANELS £14.74 £29.48

2 X MRE2LH/RH BULKHEAD TO SILL PANELS £21.29 £42.58

2 X MRE5-6 BATT-AIR CLEANER MTG BKTS £16.26 £32.52

2 X MRE9LH/RH BULKHEAD SIDE PANELS £51.58 £103.16

2 X MRE17LH/RH OUTER SILLS £86.52 £173.04

2 X MRE38LH/RH STIFFENERS FROM LOWER QTRS TO No. PLATE £18.74 £37.48

1 X MRE44A REAR TONNEAU PANEL £171.72 £171.72

1 X MRE67 TONNEAU TOP PANELS £119.15 £119.15

2 X MRE70LH/RH TOP PANEL TO HOOD £50.77 £101.54

1 X MRE75LH REAR OUTER WING £523.49 £523.49

1 X MRE75RH REAR OUTER WING £471.12 £471.12

2 X MRE98LH/RH RREAR LIGHT FILLETS £50.56 £101.12

1 X BD15933 FUEL FILLER BOX £204.24 £204.24

2 X BD19532-33 MOUNTING BRACKETS £6.74 £13.48

2 X BD25409-10 MOUNTING BRACKETS £6.54 £13.08

2 X MRE79ALH/RH DOOR COMPLETE £733.99 £1,467.98

1 X MRE104A BOOTLID £484.90 £484.90

VAT @ 20% £ 818.02

Total Inc. VAT £ 4,908.10

(19)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

BETA PANEL KIT SERIES 1 3.8 & 4.2 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 X MRE75ALH REAR OUTER WING 785.24 785.24

2 X MRE98LH/RH RREAR LIGHT FILLETS 50.56 101.12

2 X MRE79BLH/RH DOOR COMPLETE 733.99 1467.98

VAT @ 20% £ 791.60

Total Inc. VAT £ 4,749.59

(20)

BETA PANEL KIT SERIES 2 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

1 X MRE75LH REAR OUTER WING 523.49 523.49

2 X MRE79CLH/RH DOOR COMPLETE 733.99 1467.98

1 x MRE104A BOOT LID 484.9 484.9

Total Excluding VAT £4,126.20

VAT @ 20% £825.24

Total Inc. VAT £4,951.44

(21)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

BETA PANEL KIT SERIES 2 4.2 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 X MRE75ARH REAR OUTER WING 785.24 785.24

2 X MRE79DLH/RH DOOR COMPLETE 733.99 1467.98

VAT @ 20% £ 808.35

Total Inc. VAT £ 4,850.10

(22)

DELTA PANEL KIT SERIES 1 3.8 & 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

1 X MRE44A REAR TONNEAU PANEL 171.72 171.72

1 X MRE67 TONNEAU TOP PANELS 119.15 119.15

1 X MRE75LH REAR OUTER WING 523.49 523.49

2 X MRE79ALH/RH DOOR COMPLETE 733.99 1467.98

1 X MRE104A BOOTLID 484.9 484.9

1 X BD36166 BONNET COMPLETE 5424.32 5424.32

VAT @ 20% £ 1,902.88

Total Inc. VAT £ 11,417.28

(23)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

DELTA PANEL KIT SERIES 1 3.8 & 4.2 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 X MRE75ALH REAR OUTER WING 785.24 785.24

2 X MRE79BLH/RH DOOR COMPLETE 733.99 1467.98

1 X MRE104A BOOT LID ASSEMBLY 484.9 484.9

VAT @ 20% £ 1,973.44

Total Inc. VAT £ 11,840.65

(24)

DELTA PANEL KIT SERIES 2 4.2 ROADSTER

Qty Part Number Description Individual Price Combined Price

1 X MRE75LH REAR OUTER WING 523.49 523.49

2 X MRE79CLH/RH DOOR COMPLETE 733.99 1467.98

1 X MRE104A BOOT LID ASSEMBLY 484.9 484.9

VAT @ 20% £ 1,895.37

Total Inc. VAT

£ 11,372.24

(25)

08/2015

Pool Road,

VAT REG No. GB 487 666 775

DELTA PANEL KIT SERIES 2 4.2 FIXED HEAD COUPE

Qty Part Number Description Individual Price Combined Price

1 X MRE75ALH REAR OUTER WING 785.24 785.24

2 X MRE79DLH/RH DOOR COMPLETE 733.99 1467.98

VAT @ 20% £ 1,842.96

Total Inc. VAT £ 11,057.76

(26)

(27)

(28)
