Project "Amazon" - Citrix

MetaFrame XP Server with Feature

Release 3 - Management

Functionality

Project "Amazon" - Citrix

MetaFrame XP Server with Feature

Release 3 - Management

Functionality

Stephane Lalonde Systems Engineer

Citrix Systems Inc.

Stephane Lalonde Systems Engineer

(3)

Citrix Confidential

Non Disclosure Agreement

•

This presentation is

(4)

Citrix Confidential

Agenda

• _{Installation Manager for MetaFrame XP}

Improvements

• _{Resource Manager for MetaFrame XP}

Improvements

• _{MetaFrame XP Management Pack for}

Microsoft Operations Manager

• _{Resource Manager & Microsoft}

(5)

Installation Manager for

MetaFrame XP – New Features in FR3

Installation Manager for

(6)

Citrix Confidential

Installation Manager for MetaFrame XP

• _{Support for:}

– _.NET

– Windows Server 2003 – _{Windows 2003 Server} – Microsoft Server 2003

– The server built on Windows 2000 Server that was built on NT

– The server formerly known as Windows .NET

• _{Command line utility – Published Application}

Wizard

(7)

Resource Manager for MetaFrame –

New Features in FR 3

(8)

Citrix Confidential

Resource Manager for MetaFrame XP

• _{Improved Billing}

• _{Apply to Folder support}

• _{Alert using SMTP Mail support}

• _{Database User-definable installation} • _{Improved snapshot report}

• _{Improved server reboot} • _{Alert on Yellow}

• _{Printing of reports}

• _{Improved SNMP traps}

(9)

Citrix Confidential

Improved billing

• Set Fee Profiles and Cost Centers

• Fee Profile = currency and fees

• Cost Center = users and fee group

• Unlimited type of fees can be set based on time of day and day of week

• You cannot create a bill with more than 1 currency.

(10)

Citrix Confidential

Improved billing (Step 1)

(11)

Citrix Confidential

Improved billing (Step 2)

(12)

Citrix Confidential

Improved billing (Step 3)

(13)

Citrix Confidential

Apply to folder support

• Changes to server or application metrics

settings applied to the folder structure in the CMC

• Makes the selection of servers/application much more intuitive

(14)

Citrix Confidential

(15)

Citrix Confidential

Alert using SMTP Mail support

• To be able to alert via SMTP

• MAPI:

– Can be difficult to configure

– Greatly limits the number of e-mail packages

than can be utilised.

• SMTP:

– Easier to configure

– Does not require an e-mail package to be

(16)

Citrix Confidential

SMTP Mail support

(17)

Citrix Confidential

(18)

Citrix Confidential

Database User Definable Installation

• Allow an administrator to specify during set-up where the local database will be installed

• Separate operating system and data

(19)

Citrix Confidential

User Definable Installation

• _{Advanced Concept Guide will detail how to}

(20)

Citrix Confidential

Improved snapshot report

• Displays more problem solving information in the snapshot report

• Shows the processes using more than 5% of the processor or memory.

• Prior a separate report for every process that was running at the time was required

(21)

(22)

Citrix Confidential

Improved server reboot

(23)

Citrix Confidential

Improved Server Reboot

(24)

Citrix Confidential

Improved Server Reboot

• Will also allow the reboots of the selected machines to be staggered

• Staggered reboot give a time period in

(25)

Citrix Confidential

Printing of reports

• Offer administrators the ability to print reports that are generated in Resource Manager including billing reports

(26)

Citrix Confidential

Summary Database folders and zones

• Add the recording of the zone or group (as defined in the CMC) to the summary

database

• Groups of servers in the CMC can be used to produce specific reports on those

individual groups

• Allows performance of the group to be

(27)

Citrix Confidential

Improved SNMP Traps

• SNMP traps unique for a specific type of RM alert (green<->yellow<->red)

• Allows administrators to configure 3rd party

consoles to perform specific actions based on the type of RM alert received.

(28)

Citrix Confidential

Alert on yellow

• Ability to raise an alert when a yellow threshold has been crossed

• This enables to proactively fix the problem

• Can also alert if state changes from:

– Green -> yellow

– Yellow -> Red

– Red -> Yellow

(29)

Citrix Confidential

(30)

Microsoft Operations Manager -

Overview

(31)

Citrix Confidential

A New MetaFrame XPe component

• On October 8th, 2002 Citrix launched

– MetaFrame XP Management Pack for MOM

– MetaFrame XP Provider for WMI

• Together, these give administrators the

ability to monitor MetaFrame XP

e

servers from Microsoft Operations Manager

(32)

Citrix Confidential

MOM – A quick overview

• _{Microsoft Operations Manager (MOM) 2000}

is a management solution for Microsoft Windows 2000 server deployments.

• Comprehensive event management,

proactive monitoring and alerting, reporting, and trend analysis.

• Extensive product support knowledge base, with links to Knowledge Base articles white papers and end-user knowledge

(33)

Citrix Confidential

MOM – A quick overview

• Hardware and software packages to be monitored from a single point

• Monitor your HP servers, Windows 2000 operating system, your SQL database and MetaFrame XPe.

(34)

Citrix Confidential

Microsoft Operations Manager Licenses

• Base Processor License (Base Management Pack)

– Requires a base processor license for each

processor on each server on which it's installed

– Requires for each processor on each device it

manages.

– The base processor license entitles to deploy

(35)

Citrix Confidential

Microsoft Operations Manager Licenses

• Application Management Pack Processor License

– Manage Microsoft BackOffice® or .NET

Enterprise Server applications

– In addition to the base processor license

– Required for each processor on each managed

device running Microsoft BackOffice or .NET

Enterprise Server applications that is monitored and/or managed by the Microsoft Operations

(36)

Citrix Confidential

Base Management Pack Modules

• Active Directory directory service

• Component Services (Transaction Server 2.0)

• Default event collection

• DHCP service (2000)

• _{DNS service}

• _{Internet Information Services (IIS)} • _{Message Queuing (MSMQ)}

• Microsoft Distributed Transaction Coordinator (MSDTC)

• Microsoft Operations Manager 2000

(37)

Citrix Confidential

Base Management Pack Modules

• Microsoft Operations Manager 2000

• Microsoft .NET Framework

• Network Load Balancing (NLB)

• Routing and Remote Access Service (RRAS)

• _{Server Clusters}

• Systems Management Server 2.0

• Terminal Services 2000

• _{Windows Internet Name Service (WINS)} • Windows NT 4.0 operating system

(38)

Citrix Confidential

Application Management Pack Licensing

• Application Center 2000

• Commerce Server 2000

• Exchange Server 5.5

• _{Exchange Server 2000}

• Host Integration Server 2000

• Internet Security and Acceleration Server 2000 (ISA)

• Proxy Server 2.0

• Site Server 3.0

• SNA Server 4.0

(39)

Citrix Confidential

Why Integrate with MOM?

• _{According to Gartner:}

– By 2005, the Windows management market will

more than double in size from 2000’s $2.7 billion to $6.6 billion.

– By 2005, Microsoft will be the largest supplier of management products for Windows server

environments.

• According to a Citrix 2002 Management Survey:

– _{62% of Citrix customers with 16 servers or more}

(40)

Citrix Confidential

Why Integrate with MOM?

• Citrix is extending the number of manageability options available to customers

(41)

Citrix Confidential

MetaFrame XP Management Pack

for MOM

• _{View managed servers,}

product versions and hotfix levels

MetaFrame Views

Health Monitoring

Knowledge

Configurable Rules

• Context sensitive help in response to a MetaFrame Alert

• Produce alerts on

configurable conditions

(42)

(43)

(44)

Citrix Confidential

• The information in the knowledge base should be enough for an administrator to realise why the error is being seen

• Internal policy will dictate whether this is a breach

• The correct user can be contacted or settings changed

(45)

(46)

Citrix Confidential

Detected errors

Rate of disconnections

Session idle too long

Pooled / assigned license usage

Rate of zone elections

Number of servers in zone

IMA service not running

Printer errors Client update errors

Too many instances of published app

(47)

Citrix Confidential

Target Audience

• Customers that use MetaFrame XP and are either using or evaluating MOM

(48)

Resource Manager for MetaFrame

XP - Overview

(49)

Citrix Confidential

Resource Manager for MetaFrame XP

• Real-time monitoring and recording of data

• Track user activity

• Track application usage

• Produce Billing reports

(50)

Citrix Confidential

Real-time monitoring

• _{Stores metric details every 15 seconds}

– Used for troubleshooting problems

• _{Send e-mail, pager, SNMP, or run a file} • _{Stored for 4 days}

• Summarised daily

– _{Max value, Min Value, Standard Deviation, Mean}

and Median

• _{Long term data used for sizing and}

forecasting

(51)

Citrix Confidential

(52)

Citrix Confidential

(53)

Citrix Confidential

Track User and Application Activity

• Migrating Applications?

• Supporting multiple versions of the same app?

• Track which users run which applications

• Detail concurrency for licensing

(54)

(55)

(56)

Citrix Confidential

Billing Reports

• Detailed reports of application usage

• Assign costs by CPU, memory, session time, process loaded / active

(57)

Citrix Confidential

Customised reporting

• 16 Crystal Reports templates available for download from Citrix.com

(58)

Citrix Confidential

(59)

XP & Microsoft Operations Manager

(60)

Citrix Confidential

Strengths - MOM

One place for everything

Ease of escalation

The Knowledge! Centralized Support

Strengths - RM

User Auditing

Application Tracking

Billing

Data Drill Down

(61)

Summary

(62)

Citrix Confidential

Summary

• Windows 2003 server support included

• Many Resource Manager improvements

– Provides information before, during and after

problems arise

– Flexible billing system

– Reduce configuration time

• MOM provides rule based alerts

• MOM links to knowledgebase

(63)

Access Central Citrix Technology Lab Access Central Citrix Technology Lab

Sago Ballroom

(64)

Resource Manager for MetaFrame

XP - Schema Modification

(65)

Citrix Confidential

(66)

Citrix Confidential

Resource Manager Local Database

• New Process_History Table

– PID

– TimeStamp

– CPU

(67)

Citrix Confidential

Resource Manager Summary Database

• _{New LU_ServerInf Table}

– PK_ServerInfID

– Folder

– _Zone

• FK_ServerInfID added to SDB_Metrics

• _{New info added to SDB_Scratch}

– Session_Start

– _{Session_Duration}

– Session_Total_Time
