What can you expect to receive? pg 3. CribMaster 9 pg 4 CMScan pg 6

Table of Contents

End-User Benefits

What can you expect to receive?

pg 3

Software

CribMaster 9

pg 4

CMScan

pg 6

Passive Issue

Weigh Station

pg 7

AccuCab

pg 8

AccuCab 2D

pg 9

Hybrid AccuCab

pg 10

AccuPort

pg 11

AccuDrawer

pg 13

Traditional Vending

ToolBox

pg 15

ProStock

pg 17

CabLock

pg 20

ToolCube

pg 23

ModuLock

pg 24

MultiStore

pg 25

Other Solutions

Portable Asset Dispensing Device (PADD)

pg 26

Mobile Tool Facility (MTF)

pg 27

Last Point Read System (LPR)

pg 29

End-User Benefits

What can you expect to receive?

CribMaster Benefits Overview

By installing CribMaster you will discover benefits in many areas of your operation:

Purchasing Benefits:

Automate the replenishment of your inventory Notify suppliers of needed items

Keep a lower on-hand supply

Make well-informed decisions based on history Store order information to fit each supplier Store multiple price breaks for each supplier Effectively manage blanket purchase orders Effectively purchase with buyer groups Effectively track by LIFO or FIFO accounting Reduce labor by 8hr per employee weekly Easily analyze order points for each item location Greatly reduce paper work with email or EDI Reduce time in processing orders

Immediately notify suppliers of critical inventory

Suggest transfers from other cribs, vending or locations rather than purchase new

Management Benefits:

Reduce on-hand inventory by an average of 30% Save an average of 80% on lost items & pilferage Associate item usage with up to 6 cost centers report item usage with 170 standard reports Reduce soft costs (travel time) to the store room Use barcoding to better organize storage areas instantly show item location to eliminate searching Manage inventory by crib or by entire facility eliminate surplus inventory

easily identify excess inventory

effectively manage consigned inventory contracts Reduce labor and effort for physical inventory Effectively manage calibration schedules

manage items through the rework / re-grind process Effectively track serialized items

eliminate duplicate item entries in system effectively manage multiple suppliers easily analyze supplier performance

Effectively manage and rebuild kits and assemblies Effectively track labor and parts used in work order tasks

Store Room / Tool Crib Benefits

Reduce labor by 10hrs per employee weekly Organize storage bins with barcodes

Eliminate stock-outs

Identify serialized items with barcodes Easily send gauges to calibration Easily send items to rework / regrind Speed item issues using barcodes Easily identify high-use items Locate high-use items at point-of-use Greatly reduce item search times

Work hands free with radio frequency scanners Locate items of any type on the shop floor Effectively build and replenish kits & assemblies Control item access by class codes or employee Establish item limits for a given time period

Effectively control replenishment of bulk issued items Track transfers to and from satellite crib locations Track transefrs to and from other facilities Reserve items for future use

Speed the receive process of items with barcoded POs Track and correctly adjust for over and under receives Effectively schedule and track work orders

Issue work order parts with a single barcode scan Track required FOD processes

Greatly improve communications with your suppliers Eliminate duplicate item entries

Search by item attributes

Software

CribMaster 9

CribMaster 9 Software

How does the best indirect material software get better? Here are the top ways the latest and greatest version of CribMaster has been improved. Find out the top reasons why you should evaluate, and why you should take advantage of the new evolution of indirect material management systems.

Major Usability Differences

Ribbon Features – new clean look...same great functionality Explorer View – more ways to navigate through CribMaster Modeless Features…immediate data validation notices ...no more

annoying pop up boxes

Quick Access ToolBar – shortcuts to where you need to go Dashboard - Customize your home page view to show important

reports and stats everytime you login

Other New Features and Usability

Roaming Profiles – your unique settings are stored in the

database not the registry – your settings and customized views now follow you everywhere

In Grid Editing and Data Validation - we listened and now your

data editing is faster than ever

In Grid Lookups - dynamic content is now in dropdown menus as

opposed to lookup screens

Print Grids and New Data Exporting Features – now we have a

true print screen feature that gives you all the data from your search...another request from our users

Custom Views – create your own custom data view in CribMaster

whenever you need it

New Extensive Search and Filtering Capabilities – good search

capabilities just got a lot better and now you have the ability to save your searches

User Interface Customizations – Column Chooser, Group By –

only the data you need to see in all your views

Create Your Own Custom System Status – you decide what’s

important

Add Your Own Reports to the DashBoard – custom start page

tells you what you need to know

SQL Script Execution Allows Select Statements and Export Capabilities – more ways to extract data quickly from the

CribMaster system

New Delete Functionality – lets you clean up those records from

one place in CribMaster

CMServer is Now CMAgent - installs and runs as a Service

automatically

REX Files – New Custom scheduled export feature – build your

own exports for CSV, fixed length, XML, EDI formats etc….

Software

CribMaster 9

Now CribMaster Can be Deployed in a True N-tier Environment

New Connection Methods - CribMaster9 has the ability to connect to 4 different types of Remote Data Portals (Web Services, WCF, .NET

Remoting and Enterprise Services Hosting)

ADO.NET vs ODBC Connections - a more secure and faster database connection

CMScan

The CribMaster scanner is a ruggedized mobile computer for use with the CribMaster software in very rugged environments. If your facility is in need of a scanner that can withstand the rugged daily environment of your facility, this is your scanner. The CribMaster scanner is a mobile device that can withstand high level drops and intense impact.

CMScan works with both Windows CE and Windows Mobile 5 applications and allows the scanner to become an integral part of the CribMaster software and increases CribMaster scanner functionality. Several functions come standard with the scanner, which adds great capability to your scanner usage.

CribMaster Scanner Functions, Features, and Benefits:

Single-handed wireless data collection Durable, rugged, and reliable design Easy-to-use size and shape

Long battery life Windows CE device 802.11B communication Barcode or key enter data

Communicate real time with CribMaster Communicate in batch mode

Expand coverage and range as needed Issue and receive items

Return used items Cycle count Quantity adjustments * Assemble kits Replenish kits * Transfer * Relocate *

* Feature only available on a CMScan Windows CE Device

Software

CMScan

Passive Issue

Weigh Station

CribMaster Weigh Station

Passive issue means that users simply identify themselves and take what they need, the system can handle the rest. The system will take care of the counting, ordering, communicating with the supply chain, reporting who has used what, providing accurate cost accounting, and much more. The whole concept of passive issue is simple. We design solutions to make it easy for workers to do the right thing because it is non-intrusive and does not cause additional steps to be taken. Passive issue devices give management the ability to deal with the exceptions rather than lock down inventory which can cause frustration and additional processes to be required.

The CribMaster Weigh Station is a passive issue device that includes a very accurate scale and bin technology to immediately count when an item has been removed or returned into a bin. This device allows for a highly flexible design to be achieved while benefitting from the most robust inventory management system available for managing tools, MRO, PPE, and other indirect material. The restocking is as simple as receiving the line item on the purchase order on the touchscreen, opening the door and putting your items in the bin. The Weigh Station requires no repackaging or no tagging and is great for bulk issue (hardware, fasteners, bolts, etc.) If you are a distributor this is a great solution for management of consignment inventory to be managed remotely and provide great service to your accounts.

Weigh Station Functions, Features, and Benefits:

No repackaging needed Great for bulk issue items

Very accurate issue and return counts Automated ordering based on weight

Great solution for high-use consumable inventory or MRO inventory or safety items

Can combine both large and small items

Configurable up to 60 bins - 25lbs weight capacity Larger bins available up to 50lbs weight capacity Multiple bin width and depths available

190+ Standard CribMaster reports with scheduling

Dimensions: Inside 75” Tall x 58” Wide x 32” Deep

Passive Issue

AccuCab

CribMaster AccuCab

Imagine your employees walk up to a cabinet that stores tooling, maintenance parts, kits or even hazmat materials. Like all of our CribMaster point-of-use devices, the employee is required to identify himself or herself. The door unlocks using an electromagnetic lock and inside are shelves that contain the items they need to complete their task. Each item is identified with a passive Gen2 RFID tag and when the item is removed, inventory is automatically adjusted and monitored through CribMaster.

The AccuCab is a great solution for managing kits at point-of-use, tracking the usage of durable items, or tracking maintenance items to work orders and tasks. The only additional step to employees is identifying who they are by a password on the touch screen or a barcode scan. No inventory to scan or transactions to log. Transactions are automatically recorded when inventory is removed from the cabinet.

AccuCab Functions, Features, and Benefits:

Simple “plug and play” self contained RFID device (COTS) Touch screen control allows for User ID log in

Configurable shelving to accommodate different size items Total kit tracking and replenishment process tracking Lot number and expiration date tracking and notification Ability to remove an entire bin of items and retain high accuracy

Durable 100% made in the USA 16 gauge steel construction Direct email or EDI communication with suppliers

190+ standard CribMaster reports with scheduling Custom report configurable with Crystal Reports

Complete work order system and ability to track inventory to work orders

Item reservation and predictive ordering Reduced misuse of inventory

Improved inventory accuracy

Dimensions: Inside 75” Tall x 58” Wide x 32” Deep

Passive Issue

AccuCab 2D

CribMaster AccuCab2D

Same great technology as the original AccuCab but with a more visual front and a 2-door design. The AccuCab2D works well in environments where the larger, more industrial single door cabinet doesn't make sense. For instance, in a less industrial atmosphere like an office environment or lab the AccuCab2D is a much better fit.

Imagine your employees walk up to a cabinet that stores tooling, maintenance parts, kits, or even hazmat materials. Like all of our CribMaster point-of-use devices, the employee is required to identify himself or herself. The door unlocks and inside are shelves that contain the items they need to complete their task. Each item is identified with a passive Gen2 RFID tag and when the item is removed, inventory is automatically adjusted and monitored through CribMaster.

AccuCab Functions, Features, and Benefits:

Simple “plug and play” self contained RFID device (COTS) Touch screen control allows for User ID log in

Configurable shelving to accommodate different size items Total kit tracking and replenishment process tracking Lot number and expiration date tracking and notification Ability to remove an entire bin of items and retain high accuracy

Durable 100% made in the USA 16 gauge steel construction 190+ standard CribMaster reports with scheduling

Custom report configurable with Crystal Reports

Complete work order system and ability to track inventory to work orders

Item reservation and predictive ordering

Reduced misuse of inventory & Improved inventory accuracy

AccuCab2D Differences from Standard AccuCab

Brighter cabinet and more visible Lighter weight doors

Better shelf labeling space Smaller footprint

More appealing in less industrial environments Dimensions: Inside 79” Tall x 52” Wide x 26” Deep Useable Shelf Space Per Shelf: 44”W x 21”D

Standard 5 Shelves Per Cabinet but could accommodate many more depending on shelf height setting and product placement.

Passive Issue

Hybrid AccuCab

CribMaster Hybrid AccuCab

The Hybrid AccuCab is a point-of-use device that combines two of the most cutting edge technologies, the scale-and-bin technology as used in the Weigh Station and RFID as used in the AccuCab. Our goal was to create a dual solution by combining multiple tracking methods to accurately manage both bench stock, MRO, PPE, and other consumables and durable types of inventories all in a single device. This point-of-use device allows the ability to easily retrieve bench stock such as fasteners and bolts and to track issues and returns of serialized and durable items all with a high level of accuracy. When a user walks up to the Hybrid AccuCab, he or she must identify themselves prior to the door being unlocked. They can do this by using a touch screen monitor mounted on the door or with a barcode or proximity badge scan. Once the door is unlocked, the user opens the door to find bulk inventory in bins and inventory (that is tagged using Passive Gen2 Tags) on adjustable shelving. The user removes the inventory and shuts the door. The inventory is automatically adjusted and the inventory is properly accounted.

Hybrid AccuCab Functions, Features, and Benefits:

Simple “plug and play” self contained RFID device (COTS) Touch screen control allows for User ID log in

Configurable shelving to accommodate different size items Lot number and expiration date tracking and notification Ability to monitor a bin of items and retain high accuracy Durable 100% made in the USA 16 gauge steel construction Direct email or EDI communication with suppliers

190+ standard CribMaster reports with scheduling Custom report configurable with Crystal Reports

Complete work order system and ability to track inventory to work orders

Item reservation and predictive ordering Reduced misuse of inventory

Improved inventory accuracy

Great solution for high-use tools or MRO inventory

Dimensions: Inside 75” Tall x 58” Wide x 32” Deep

Passive Issue

AccuPor t

CribMaster AccuPort

Imagine your employees walk up to a caged area containing tools, MRO items, safety products, maintenance parts, or any indirect material used to keep your facility going. As they enter the doorway, their name badge is read from wherever they may have it on their person. Their name sounds off audibly, the door is unlocked (given they have permission to enter the crib), and they enter to retrieve their items. The employee gathers all the needed items, presses the exit button to unlock the door, and walks back through the AccuPort which records the transaction for each item as they walk away.

Your employees don’t have to scan, vend, or even concern themselves with any aspect of retrieving items other than carrying them through the port. Everything is done automatically, in real time, and will continue to contain all of the features that CribMaster applies to any inventory item. Serialized items, durable items, expendable items, kits and assemblies, maintenance parts, or inventory assigned to a work order...it’s just another way to issue items to employees and cost centers... except this one is hands free!

AccuPort Functions, Features, and Benefits:

Touch screen control allows for non-auto ID log in Electromagnetically controlled door with a lock that withstands 600lbs of pressure

Digital photo capture available for improved management Multiple cage sizes and label packages

Easily expandable cage sections to increase storage capability

Automatic RFID identification of employee and items Ability to carry an entire bin or cart of items through the AccuPort and accurately track every item

Durable 100% made in the USA 16 gauge steel construction 190+ standard CribMaster reports

Custom report configurable with Crystal Reports Reduce misuse of inventory

Eliminate pilferage

Improve inventory accuracy

Passive Issue

AccuPor t

The system uses CribMaster software and may be used in front of a caged/fenced area or in front of a tool room/store room door. The AccuPort reads passive RFID labels or tags applied to the inventory with the 3 RFID readers which are mounted in the walls of the AccuPort. Any item that has the label attached will be read and the transaction recorded with CribMaster software as it passes through the portal. The type of item is not important, only the tag affixed to the item is used to determine what item was removed, returned, or restocked inside the crib. Many types of inventory can be managed effectively with the CribMaster software including; expendable, durable, serialized, gauges, reworkable, hazmat, etc. CribMaster has auto replenishment features and can communicate with most purchasing systems via a flat file export. • ATR - Automated Tool Room - Touch Screen included - includes one Admin module

• 500 RFID Tags included - these are reusable and may be assigned to other items

• RFID tags may be affixed to individual tools directly or smaller items may be placed in RFID containers/packages (reusable)

• Each employee would have an RFID badge - as they come through the portal into the crib, they will automatically be welcomed by name and the item with the RFID tag taken from the crib will be tracked automatically by CribMaster • Technical Support for one year is included

• CribMaster Cameras also available - images may be viewed in real time or viewed later as stored images directly from your PC, as an added security measure. CribMaster Cameras may be configured for images to be taken as frequently as every 30 seconds

Passive Issue

AccuDrawer

CribMaster AccuDrawer

Imagine your employees walk up to a cabinet that stores tooling, maintenance parts, kits or even hazmat materials. Like all of our CribMaster point-of-use devices, the employee is required to identify himself or herself. The drawer unlocks using an electromagnetic lock and inside are the items they need to complete their task. Each item is identified with a passive Gen2 RFID tag or the location is monitored with a patented RFID switch. When the item is removed, inventory is automatically adjusted and monitored through CribMaster.

The AccuDrawer is a great solution for managing kits at point-of-use, tracking the usage of durable items, tracking maintenance items to work orders and tasks, and monitoring of inventory in FOD critical areas. There is no inventory to scan or transactions to log. Transactions are automatically recorded when inventory is removed from the cabinet and when items are missing from the cabinet the touch screen displays “items out” on the ATR screen, making FOD checks easy, fast, and accurate.

AccuDrawer Functions, Features, and Benefits:

Simple “plug and play” self contained RFID device (COTS) Touch screen control allows for User ID log in

Configurable drawer sizes allow for multiple product sizes Total kit tracking and replenishment process tracking Lot number and expiration date tracking and notification Durable 100% made in the USA 16 gauge steel construction Direct email or EDI communication with suppliers

190+ standard CribMaster reports with scheduling Custom report configurable with Crystal Reports

Complete work order system and ability to track inventory to work orders

Battery powered option with 24hr battery Reduced misuse of inventory

Passive Issue

AccuDrawer

The Original AccuDrawer

8 Drawers

72.5” Tall x 46.25” Wide x 28.5” Deep

The AccuDrawer Mini

6 Drawers

64” Tall x 46.25” Wide x 28.5” Deep

The AccuDrawer Mobile

8 Drawers

72.5” Tall x 30.25” Wide x 28.5” Deep

The AccuDrawer Mini Mobile

6 Drawers

64.25” Tall x 30.5” Wide x 28.5” Deep

8 Drawer Units

Foam Screws 500

Blue Foam Strips .5 x .75 x 48 30 Blue Foam Strips .75 x .75 x 48 12

6 Drawer Units

Foam Screws 400

Blue Foam Strips .5 x .75 x 48 25 Blue Foam Strips .75 x .75 x 48 10

Traditional Vending

ToolBox

CribMaster ToolBox

The CribMaster ToolBox is the grandfather of all of the vending solutions. WinWare developed the first ToolBox vending solution in the early 1990’s and it is still the dominate player in the marketplace because of its features, reliability, and total solution expandability. We have combined the world’s leading tool crib automation software, CribMaster, with durable and reliable electronically controlled hardware. This is one of many CribMaster software driven devices and can be used in combination with other point-of-use solutions to completely satisfy all of your indirect material dispensing needs.

If you need high security dispensing for the following recommended product types, the ToolBox is for you:

- Batteries (all sizes) - Box Knives

- Gloves (kevlar, gauntlet, hyflex, etc) - Abrasive Disks

- Filters - Tape

- PPE - Marking Pens

- Cutting Tools - Safety Glasses

- Locktite - Fasteners

- Flashlights

Toolbox Functions, Features, and Benefits:

View tool image or tool specs prior to dispensing Barcodes, HID readers, and magnetic swipe options

Return locations can be defined for inspected tools, returned tools to collect for rework, etc.

Many configurations, many options No keypad wear issues

Many technology configurations, CMOL, replication, network, hybrid, air card options available

Ability to add CM9 software to manage items within tool crib and preventive maintenance software

Flexible security/product access control

20+ point-of-use devices to expand into for larger items, durable items, FOD control, serialized items, gauges, kits, shelf life, lot numbers

Provides secure point-of-use distribution Easily and immediately access your tools

Eliminate overuse by employee, department, machine, etc. Automate your replenishment

Above is a screen shot of the ATR9 software that runs the ToolBox and many other point-of-use solutions. The real power of any CribMaster device is the software and expandability.

Traditional Vending

ToolBox

CribMaster ToolBox Specifications

Maximum product width: Double Wide Tray - 5” (5 across)

Single Wide Tray - 2.5” (10 across)

Custom Tray - 5” - 20” Maximum product height: 7.75”

Double Wide and Custom Tray Helix Options

Dual Helix Configuration

5 Count Helix - *Slot Depth 4.20” 7 Count Helix - *Slot Depth 3.06” 10 Count Helix - *Slot Depth 2.18” 12 Count Helix - *Slot Depth 1.82” 15 Count Helix - *Slot Depth 1.46” 18 Count Helix - *Slot Depth 1.21” Single 3” Helix Configuration

6 Count Helix - *Slot Depth 3.5” 6 Count Helix - *Slot Depth 3.2” Single 3.75” Helix Configuration

4 Count Helix - *Slot Depth 4.26” 5 Count Helix - *Slot Depth 3.61” 7 Count Helix - *Slot Depth 2.74” 9 Count Helix - *Slot Depth 2.21” 10 Count Helix - *Slot Depth 2.01” 12 Count Helix - *Slot Depth 1.71” 15 Count Helix - *Slot Depth 1.41”

Single Wide Tray Helix Options

5 Count Helix - *Slot Depth 4.20” 7 Count Helix - *Slot Depth 3.06” 8 Count Helix - *Slot Depth 2.67” 10 Count Helix - *Slot Depth 2.18” 12 Count Helix - *Slot Depth 1.82” 15 Count Helix - *Slot Depth 1.46” 18 Count Helix - *Slot Depth 1.21” 24 Count Helix - *Slot Depth .91” 32 Count Helix - *Slot Depth .69”

* Not the actual size of opening. Slot depth is measured from the peak of one spiral pitch to the next

Dimensions (including touchscreen and barcode scanner):

72” Tall x 39” Wide x 36” Deep Weight: Approx. 700 lbs unstocked

Power Requirements: 115 volts AC, 60 Hz, 3 Amps CSA. UL Listed

Flexible Configuration

The CribMaster ToolBox comes with a very flexible dispensing layout to allow for many types of products to be dispensed. If a certain product is not well suited for a ToolBox, one of the many other CribMaster point-of-use devices can help. Certain items can be problematic for helix style vending. You need additional solutions to handle those items and CribMaster has over 20 solutions to handle every dispensing need.

Batteries in a 12 count single helix

Safety glasses from multiple vendors dispensed from a 10 count single helix

Leather welding gloves and kevlar gloves stored and dispensed in french fry containers to ensure proper vending

Welding tips, locks, and brite mark pens dispensed from multiple helix sizes

Traditional Vending

ProStock

CribMaster ProStock

So you want a device that takes up very little space, has the flexibility to handle multiple sized products, is easily reconfigured and provides high-secure, single item dispensing? You have now found it.

Take the ease and security of carousel dispensing and add flexible carousel sizes, simple on-site reconfigurability and high capacity in a very small footprint, and you have the CribMaster ProStock. If you work in a cellular work design, why would you keep the necessary production tooling right next to the machine? Reduce hoarding, stock-outs, overstock situations, and travel time to the tool crib.

ProStock Functions, Features, and Benefits:

Easy to use touch screen interface

Tracking with multi-category usage & accounting – Up to seven (six user definable) classifications for tracking and reporting

Flexible automatic reordering and resupply

Item issue security – limit access to prevent incorrect usage or unauthorized access

Item issue efficiency – improved productivity by issuing nearer to job sites with fast item issue speeds

Manufacturing efficiency help – machine usage is improved by minimizing downtimes because of inventory shortage Eliminate stock-outs with features like critical alerts and automated optimum order levels

Add inventory dispensing to your work cells for a leaner work flow

Reduce tool usage 20 - 40% or more

Automate replenishment with direct communication to your distributors

Dimensions: 82” Tall x 34” Wide x 34.75” Deep Weight: Approx. 625 lbs unstocked

Traditional Vending

ProStock

Traditional Vending

ProStock

lockers replace one carousel

Usable Carousel Bin Dimensions

(up to 10 space door opening)*

Section Divide

* can utilize up to 1/4 carousel (14 spaces) but door opens to only 10. If access and removal can take place through the 10 door measurement 1/4 carousel division can be used.

Depth In. Height In. Front Width Back Width

1 9.6 4.75 1.2 0 2 9.6 4.75 2.4 .19 3 9.6 4.75 3.6 .38 4 9.6 4.75 4.8 .56 5 9.6 4.75 6 .75 6 9.6 4.75 7.2 .94 7 9.6 4.75 8.4 1.13 8 9.6 4.75 9.6 1.32 9 9.6 4.75 10.8 1.51 10 9.6 4.75 12 1.70

Locker Depth In. Height In. Width

Usable Locker Dimensions

(Inside useable space dimensions)

1-door 2-door 3-door 6-door 28" 4" 23.5" 28" 4" 11" 28" 4" 7.5" 28" 4" 3.5"

Traditional Vending

CabLock

CribMaster CabLock

The CribMaster CabLock modular cabinet storage system combines a proven electronically controlled locking modular cabinet with CribMaster Software to enable controlled distribution of inventory. Modular cabinets controlled by CribMaster enable a medium security distribution method that eliminates paper tracking and provides effective replenishment and usage tracking.

CribMaster has partnered with Stanley Vidmar, who has been creating modular cabinets in the US since the early 1950’s to provide proven and reliable hardware. This combination of reliable hardware and the leading indirect material inventory management software, provides a management system that is second to none.

CabLock Functions, Features, and Benefits:

13 standard drawer sizes Up to 15 drawer units CribMaster is fully integrated

Works with existing employee badges, proximity badges, or card swipes

Tracking of reworkable items Gauge calibration tracking FOD control features

Control access to modular cabinets Expand control of your CribMaster system Scan barcodes for access to inventory

Utilize all CribMaster inventory management features Benefit from semi-secure distribution

Create accountability among users

Establish accurate and timely replenishment with supplier

Pictured is the model 245 set up as a master with a self contained control unit, barcode scanner, and CribMaster ATR

Traditional Vending

CabLock

Cabinets

Each cabinet starts with one of four cabinet housing sizes. Housings are available in four heights. Each height receives a model number:

33” high - Model 175 37” high - Model 200 44” high - Model 245 59” high - Model 340

So if you need a Standard cabinet that is 59 in. high,the model number for the cabinet would be Standard cabinet Model 340.

Drawers

The next step to building a cabinet is the drawers. Like the model number given to each housing height, the drawers also have model numbers ranging from Model 20 up to Model 90. Each drawer model number represents a different drawer height. First choose one of the 4 standard height cabinets and make note of the model number. If you add up all the drawer model numbers for each cabinet, the sum total must equal the cabinet height model number. Thus, if you have a standard cabinet Model 340 (59” high) with the below seven drawer model numbers, the sum total of those drawer model numbers should equal the 340 Model number used for the height of the cabinet. If the total sum of the drawer model numbers does not equal the cabinet height model number, then the drawers will not fit in the cabinet housing. (see below)

Model 175 33” (838mm) Tall 30” (762mm) Wide 27.75” (705mm) Deep Model 200 37” (838mm) Tall 30” (762mm) Wide 27.75” (705mm) Deep Model 245 44” (838mm) Tall 30” (762mm) Wide 27.75” (705mm) Deep Model 340 59” (838mm) Tall 30” (762mm) Wide 27.75” (705mm) Deep

Drawer Model Numbers Useable Height

+40 5.375” +50 7” +50 7” +50 7” +50 7” +50 7” +50 7” Model 340

Traditional Vending

CabLock

Interiors

Loading Diagrams

Drawers fit items of all sizes as indicated by the usable height of each model. All drawer interiors are gray. All drawer interiors are delivered completely installed with partitions fastened to drawer bottoms and dividers placed in appropriate slots according to the Loading Diagrams.

Drawer depths, widths, and usable space are consistent through all drawer usable heights. Refer to the drawing below for these dimensions.

Standard Drawer Features

• Drawer sizes are designed around average human reach (25.125” square [638 mm]) for easy access.

• Drawer heights range from 2.25” to 13.25” (57 to 336 mm) usable height.

• Drawers hold up to 400 lbs (181 kg).

• Drawers glide easily on a ball bearing carriage system which is guaranteed against failure. • Drawers are interchangeable with other

drawers in cabinet housings of the same style.

• Each drawer has slotted walls for partitions and dividers, providing infinite configurations. • Each drawer pull has a large label and plastic

shield for quick, easy-to-read identification of contents.

Traditional Vending

ToolCube

CribMaster ToolCube

Every now and then a product comes along that completely changes the way things are done. The ToolCube is one of those products! Like all of the CribMaster point-of-use distribution devices, control, security and ease of access to your tools and supplies are the benefits you see most. With the ToolCube we’ve combined this security, control, and ease of distribution into a unique modular storage system that controls access to drawers and individual storage spaces.

Operation is simple. The employee scans his or her badge and selects the item. CribMaster then provides access to only the approved quantity of the exact item requested. Drawers come with moveable dividers and can easily be adjusted to accomodate many different types of inventory. ToolCube compartments can contain unique items or kits of items and each master ToolCube is network ready and has all the features of CribMaster including reports, purchasing, and gauge management.

As your operation grows and your control tightens, you may need to add on cubes to store different items. You can even add a ToolCube to your countertop to help your tool crib attendant distribute costly items. It’s about time you got your tools under control and the ToolCube is just the machine to do it!

ToolCube Functions, Features, and Benefits:

Securely store and distribute items Open drawers to specified locations Handle heavy items

Vend items without repackaging Dispense items without dropping

Configure drawers and add drawer sections as needed Barcode scanners

Handle consignment/non-consignment Track usage history

Flexible security/product access control

Multiple individual drawer sizes and configurations Configurable drawer dividers and access region Handle integrated supply

Traditional Vending

ModuLock

1 - Door Master

14.5”H x 16.5”W 1 - Door Module30.125”H x 16.5”W 2 - Door Module (h)14.5”H x 16.5”W

3 - Door Module (h) 9.5”H x 16.5”W 4 - Door Module 6.875”H x 16.5”W(h) 2 - Door Module (v) 30.125”H x 7”W 4 - Door Module (v) 14.5”H x 7”W 6 - Door Module (h) 9.5”H x 7”W 9 - Door Module (v)9.5”H x 3.625”W 12 - Door Module (v) 6.875”H x 3.625”W 18 - Door Module (h)4.35”H x 3.625”W 6 - Door Module (v) 14.5”H x 3.625”W 3 - Door Module (v) 30.125”H x 3.625”W 8 - Door Module (h) 6.875”H x 7”W 12 - Door Module (h) 4.35” x 7”W

* Drawer Dimensions Below are Interior Dimensions

CribMaster ModuLock

The CribMaster ModuLock lockers have all the benefits of our other locker systems with the added flexibility of door sizes and configurations. Similar to the ToolCubes, our modular lockers simply connect to each other to create an expandable bay of lockers to dispense whatever items you require. With these modular lockers, adding to your configuration is as simple as plugging in a phone cable to expand your control.

ModuLock Functions, Features, and Benefits:

Store large items Store returnable items Return used or durable Items Return items requiring rework Manage serialized items and gauges Track tool usage by cost center

Benefit from secure point-of-use distribution Handle integrated supply inventory

Handle consignment/non-consignment Flexible security/product access control Works with exisiting employee badges Touchscreen interface

Barcode scanners

ModuLock Specifications:

1-Door Module 1-Door Master Module 2-Door Module (h) 2-Door Module (v) 3-Door Module (h) 3-Door Module (v) 4-Door Module (h) 4-Door Module (v) 6-Door Module (h) 6-Door Module (v) 8-Door Module (h) 9-Door Module (v) 12-Door Module (h) 12-Door Module (v) 18-Door Module (h)

**(h) horizontal (v) vertical

Traditional Vending

MultiStore

CribMaster MultiStore

The MultiStore is a medium security device with automated distribution well-suited for MRO items, safety products, and other various indirect materials. The system provides comprehensive tracking and usage information for more effective inventory management. The MultiStore delivers point-of-use material management as well as usage transaction information that allows electronic reordering. The system significantly reduces inventory, delivery, and restocking activities. Lighted cabinets and see-through doors with shelves and shelf dividers enhance visibility and simplify supply location and access.

MultiStore Functions, Features, and Benefits:

Touchscreen interface

Lighted cabinets and see-through doors, shelves, and shelf dividers let you access items quickly

With inventory available in one convenient location, there’s less time spent waiting and searching for supplies

Inventory can easily be grouped together on the shelves Various sizes and shapes of materials can be stored Secured doors for user-defined, medium security, single door/shelf access

Visible shelves simplify access to materials Multiple users or tool cribs

Barcode enabled No repackaging

Other Solutions

Por table Asset Dispensing Device

CribMaster PADD

The Portable Asset Dispensing Device (P.A.D.D.) is an industrial grade, secured point-of-use dispensing device that delivers inventory control, maximizes productivity and yields operational efficiencies. The P.A.D.D. utilizes highly accurate bin scale technology and CribMaster inventory software to immediately count and record inventory levels when an item transaction occurs.

The PADD comes in various models including indoor and outdoor models. There are three standard sizes of eight, ten, and twenty feet model. Custom bin configurations are available on customer request. This is a great device for managing consumables, PPE, MRO inventory, tools and other indirect material.

PADD Functions, Features, and Benefits:

Increases Employee Safety - Enables management to stock PPE near active work areas to provide employees with easy access to required safety equipment.

Maximizes Employee Productivity - Device can be strategically placed on floor in close proximity to work area to reduce employee trip and wait time that occurs from travelling back and forth to centralized store room.

Reduces Inventory Loss - System tracks inventory usage by employee by transaction enabling management to monitor activity.

Increases Stocking Efficiency - Authorized personnel selects the appropriate item for restock on the touch screen interface, opens the door and places the items in the correct bin. No need for repackaging or tagging.

Automated Replenishment - System maintains accurate inventory levels by monitoring user defined reorder points by item type.

Inventory Alerts - Electronic notifications are generated when item minimum bin quantity is achieved.

Other Solutions

Mobile Tool Facility

CribMaster Automated MTF

Are you a distributor who needs to supply tools and other supplies during a turn-around or during a construction project? Do you need a better way to control tool usage and establish accountability during these events? Need more supplies and tools and you are out of floor space? Need more floor space to manufacture and you can’t because the tool crib or supply room is in the way?

We now have the automated solution that will provide you with mobility and thanks to CribMaster and RFID will provide you with all the control and accountability you require as an end-user or supplier. The CribMaster Automated MTF uses the CribMaster AccuPort RFID technology combined with the best wireless connectivity available to enable a fully functional, unmanned, mobile tool facility that provides a high level of accountability and accuracy. If you have problem controlling tools and supplies on a job site, the MTF is for you.

MTF Functions, Features, and Benefits:

Control tools and supplies during turnovers or shut downs Provide a high level of accountability for users

Automate tool issue and return without personnel Reduce stockouts with automated purchasing Provide accountability for contractor activity Monitor costs by user defined cost centers Automatically notify vendors of low inventory

Monitor expendable, durable, and serialized inventory Assign tools to jobs or tasks and report on misused inventory

Control access based on permissions Provide accurate usage reports Manage kits and their replenishment Monitor and control calibrated equipment Eliminate pilferage

Provide 190+ standard reports Easily locate missing items

Driver’s Side

Other Solutions

Mobile Tool Facility

Mobile Tool Facility Specs

Pre-Owned 53ft Trailer

Reconditioned refrigerated units

Side interior walls-new fiberglass reinforced poly Rear interior doors-new white aluminum sheeting White aluminum portal wall

3/4” cushioned, non-skid rubber flooring Safety Features

Illuminated emergency lighting Fire/Smoke detector

Battery back-up exit signs Fire extinguisher

MSDS safety box

Shelving Units (8 Units with Base) Dimensions- 84¨ (H) x 36¨ (W) x 24¨ (D) 3¨ high bin fronts

500lb weight capacity per shelf Welded sides

Bolt-top and bottom shelves Clipped middle shelves Side Door

Dimensions - 7’ x 3’ Spring loaded coil

Access point for adjoining trailer Steps

Diamond plate aluminum steps Non-skid tread

Safety railing HVAC System

Package unit

Galvanize steel ductwork Cooling-1.5 ton

Heating-5kw Digital thermostat Electrical System

Powered by 200 amp service (2) 20 amp duplex GFCI receptacles

(13) 4ft. safety shielded, surface mounted lights Electrical wiring in sealed pvc conduit

Computer Processing Units (2 Units)

Primary and Secondary Units Rugged steel chassis Locking front door

Side cooling fans w filter Ruggedized Keyboard

Environmentally sealed against splashing liquids, dust, and dirt

ABS Polycarbonate frame with 8-32 mounting studs Integrated touchpad pointing device

Exhaust fan located in computer cabinet Thermostat controlled

Network Connectivity

Wireless network and internet connectivity Network data cable access port

JSR Trailer RF Shielding System UPS Battery Back-up System

Protects CPU and electronic components against blackouts, voltage fluctuations, and transient surges 2200 VA/1600 watt output capacity

Email notification of power problems Video Surveillance System

IP Dome Camera captures still images of employees entering and exiting portal

Box Camera located in nose of trailer High resolution color cameras Remote, pan/tilt/zoom digital control Real time streaming video

Email alert and notification system Network remote connectivity Motion sensor detection Audio component

Audible Door Alarm System

Audible alarm is activated when portal door is disengaged or propped open

Email notification alert sent to assigned personnel

Mobile Tool Facility Options

Additional Shelving Units

Dimensions- 84¨ (H) x 36¨ (W) x 24¨ (D) 3¨ high bin fronts

500lb weight capacity per shelf Welded sides

Bolt-top and bottom shelves Clipped middle shelves Metal Peg Board

20 gauge steel

Baked-on rust and scratch resistant finish Slot and peg hole panels

Plastic Bins

Variety of sizes available Vidmar Cabinets

Reconditioned (variety of sizes available) Heavy Duty Work Table

Hoist and rigging rack system Customer Signage (Decals)

Company name/logo

Other Solutions

Last Point Read System

CribMaster Last Point Read (LPR)

Do you need to take your CribMaster RFID solution one step farther? Do you need additional accountability for your indirect materials and mobile assets? Do you want to track and monitor tools as they move through your facility so that you can reduce search time if certain items go missing? We have the solution! If you need to take your AccuCab, AccuDrawer, or AccuPort to the next level, the CribMaster LPR system is for you. CribMaster LPR attached to any of our RFID devices allows you to easily monitor tools or other mobile assets as they move through your facility. The idea is simple. With any of our CribMaster RFID devices, we trigger transactions at the time of issue, which may include up to 6 user-defined cost centers. With this we may know you were taking inventory to a certain department for a certain job, but we really don’t know if it ever made it. What if it didn’t? Where was it last seen? By strategically placing CribMaster LPR stations in walkways across your facility, we now know a little more about where that inventory has been and where it may be currently.

For high accountability environments like aerospace manufacturing, food manufacturing, aircraft maintenance and more, the CribMaster LPR is the next step to improving processes.

LPR Functions, Features, and Benefits:

Track tools and other mobile assets across your facility Determine where they were last seen, who had them, and which direction they were moving

Reduce search times for tools and assets dramatically Increase accountability

Other Solutions

RFID Scanner & Near Field Readers

CribMaster RFID Scanner & Near Field Readers

Oftentimes the process you establish to maintain your RFID installation requires the need for mobility. Let’s face it, sometimes managing inventory requires the ability to perform tasks outside of a portal or cabinet. In this case, we have worked with Motorola to provide an RFID scanner that is driven by CribMaster and allows you to perform multiple functions while away from the crib, storeroom, or point-of-use device. We also provide unique near field RFID readers that enable remote tag assignment.

Assigning Tags

Prior to the scanner or the near field readers, users of the AccuPort, AccuCab, and AccuDrawer devices could only assign tags through ATR using the RFID reader built into the devices. While the operators are using the devices to assign the tags, the devices are not available for normal ISSUE transactions. Equipment out on the shop floor had to be transported to the device for the assignment process and to determine if the tag was affixed in a readable manner. With the scanner and the near field reader the assignment process can be done in any location. So items can be tagged in an office or out on the shop floor and the CribMaster RFID devices are not interrupted.

Testing Tags

This function provides an indication that the tag is affixed in an RFID friendly manner. If the scanner can read an applied tag easily then the RFID used in the AccuPort, AccuCab, or AccuDrawer should be able to read the tag.

Finding a Specific Serialized Item

The scanner can be used to locate a specific tag. This can be valuable in areas sensitive to FOD regulations or where locating assets is critical. CribMaster will recognize that a particular serialized item is missing. An operator can move the scanner systematically through an area until the reader detects the tag and sounds an alarm. Imagine trying to find a small gauge somewhere inside a plane’s fuselage or a misplaced piece of inventory from a warm crib in a nuclear power generation facility.

Cycle Counting an AccuPort Crib/Store Room

An AccuPort crib or store room might hold thousands of tagged items. Periodically the items should be physically counted. The scanner can be used in conjunction with CribMaster’s cycle counting software to count an entire crib just by moving the reader though the crib in a systematic fashion. The reader provides audible and visual indications of how many unique tags have been read. The tags are summarized by item and the quantities are entered on the Cycle Counting tables in the CribMaster database for review.
