About Amphenol

2 Amphenol was founded in 1932. The company is one of the largest manufacturers of electrical, electronic and

fiber optic connectors, coaxial and flat-ribbon cable. Its activities are geared towards 7 majors markets:

Aerospace/Military, Automotive, Broadband Communication, Industrial, Internet Equipment, MobilePhones and

Wireless Infrastructure. Amphenol is headquartered in Connecticut, USA and employs more than 10,000 people

on a worldwide basis with manufacturing and assembly operations in the Americas, Europe and Asia.

With 40 manufacturing facilities and a presence in more than 30 countries, Amphenol provides interconnect

solutions to customers anywhere around the Globe…

Operations Sales Locations ACC AAO AESO LTD AAL APJ ATX ATE ASF BAR-TEC ADS HQ CNP ACHN AKJ ACT AIPC FOP OPT ARGENTINA BRAZIL SINE TFC ABEN AITA ASPA AMTA APSO MATRIX M & T KONFEKTION E AEAL SWBR AVIN/ASWI AALB AALB GmbH ABS AMEA ASCA AALB APCD MEXICO

For more than 20 years, Amphenol has developed a

strong expertise as a designer, integrator, manufacturer

and solutions provider in the field of High performance

Fiber Optic Interconnection.

Amphenol Fiber Optic Interconnection Solutions are

tailor made to suit the needs of very demanding

customers, manufacturing mission critical or safety

related equipments.

This leads us to a long term commitment and partnership

with our customers and to provide maintenance, repair,

training, technical support, on demand.

Our Fiber Optic Solutions are based on High performance

optical termini, innovative design, and high quality, well

proven connector technology.

Rigorous internal quality assurance systems exceed the

ISO 9001 requirements and ensure consistent quality

products regardless of manufacturing location.

J

_{ABOUT AMPHENOL}

A Q A P - 1 1 0 I S O 9 O O 1

(3)

Optical Link ?

3 Fiber Optic links are ideally suited for High Speed, High

reliability, EMI/RFI immune, digital data transmission in

harsh environment conditions such as airborne

avionics and computers, Commercial telecommunications,

Outside Broadcast, Natural Disaster Search and Rescue

operations, Geophysics, Battlefield communications

and Weapon systems…

In such environments a massive amount of data, voice

and video has to be securely transmitted, sometimes

over long distance, and in Harsh environment.

This is exactly what Fiber Optics Links can do.

Thanks to a very large bandwidth and a very small

diameter, Fiber Optic Links do provide a very fast,

reliable, light weight, quick and easy to deploy means

of transmitting a mind-boggling quantity of information

between various equipments or systems.

Because they only carry light pulses, Fiber Optic Links

are totally immune to Electromagnetic or Radio

Frequency interferences which are always a threat to

the integrity of the information transmitted.

In hazardous environment (i.e post natural disaster

rescue operations) light transmitting Fiber Optic Links

are safe as they can not generate electrical sparks that

could for instance trigger a gas explosion.

As a preferred choice for deployable Battlefield

communication systems, where secrecy is paramount,

Fiber Optic Links are best suited : the light pulses being

transmitted can not be detected, or hacked into making

the link almost “invisible”.

Amphenol extensive range of Connectors for Fiber

Optics Links provide Interconnect Solutions for most

situations and environments : butt joint or expanded

beam technology, single or multi- channel, singlemode

or multimode fibers.

In a basic fiber optic link, information such as video,

voice and data have to be converted from a copper wire

network to and optical one.

The place of origin for all data entering in the optical

network is called a transmitter. It converts coded

electrical signals to equivalently coded light pulses.

Light moves to the first connection, through the fiber

optic link (which might include several connections)

and down to the last termini. Then the receiver decodes

the optical pulses to an electrical signal.

Amphenol supplies the complete interconnect

assem-bly, including the connector, termini, fiber and optional

accessories.

J

_{WHY FIBER OPTICS LINKS ?}

What is an optical link ?

Driver Source Connection

Transmitter

Receiver

Detector Connection Connection termini Output circuit Copper wires Fiber optic

(4)

4

Fiber Optic links for deployable Networks

J

_{AMPHENOL OPTICAL LINKS}

Industrial & public safety networks

AMPHENOL provides customized

solutions in a variety of fields

such as geophysics, industrial

tool interconnections, public

safety with the temporary

set up of an Ethernet

Local Area Network…

Military networks:

AMPHENOL provides solutions, for set up of easy

deployable short and medium distance

interconnections of allied networks, command units

and satellite links. As well as solutions for fixed

applications such as optical connection inside of

shelters, vehicles, buildings…

Allied Network

Satellite

Brigade HQ

Derrick _{Data control}

Industrial tools HQ Command Post Public networks Brigade HQ Transit Network

Amphenol Optical Links

(5)

Glossary

5 “dB” definition :

Expression of an optical power in log base. The 3dB Rule states that

for every added 3dB of attenuation, one looses 50% of the power.

Insertion loss :

Power loss created by an additional element on a link. Under log

base, it is the ratio between the output power Pout and the input Pin.

The lower the number is, the better the insertion loss

(generally measured in dB)

Return loss (single mode applications) :

The return loss is the ratio of the reflected optical power Pback to

the incident power Pin in dB unit. Hence, it is the back reflection

power from a device on a link. The lower the negative value in dB is,

the better (ie –50dB is better than –30dB)

Wavelength :

Considering monochromatic light as a wave, it is the distance

between two peaks of signal (ie 850 and 1300nm for multimode

applications; 1300 and 1550nm for single mode ones)

Bandwidth :

Difference between the high and low frequency of a transmission

band. The higher the number, the better.

Mode :

The light can be described as a wave going upon a specific path.

This path is called a mode. In a multimode fiber, the light goes upon

several paths in the fiber core. A single mode fiber allows the light

to go only upon one way.

Fiber types :

Waveguides are classified, on one hand by the core material index

profile and on the other hand by the mode propagation ability. Single

mode fibers have a constant index profile on the core cross section.

Most multimode fibers are gradient index fibers. As opposed to

traveling in a straight line in single mode fibers, the rays travel in a

spiral form around the optical axis for the multimode ones.

dB Transmitted light (%) 0.01 99.8 0.1 97.7 1 79.4 2 63.1 3 50

J

_{7 DEFINITIONS TO UNDERSTAND EVERYTHING ON LIGHT}

P in P out _n1 n2

P back P in n1 n2

Wavelength Intensity merged pulses MHz 900 0 Mode 1 Mode 2 n1 n2 Cross section Filter type Single mode Step Index Multi mode Gradient Index

Index Ray propagation n(r)

(6)

Back Plane MT

Ferrule MT into rectangular connectors assembled in a special rackable shell

Amphenol Optical Connectors

for Harsh Environment

6 TFOCAtwo

Multiway Hermaphroditic

MFM/HA - MFM

Singleway Fiber Optic Connector Duplex Fiber Optic Connector

STARTOP

TV Multiway Connector

38999

Optical Termini

Size 16 Optical Termini

MBP

Multiway Back Plane Connector

HQM

Hermaphroditic

Quad Miniature Connector

MTC

MT Ferrules into Cylindrical Shell

HDM

Hermaphroditic

Duplex Miniature Connector

HMFM

Hermaphroditic Duplex MFM Connector

J

_{BUTT JOINT CONNECTORS}

The Butt Joint Technology is generally used for indoor or outdoor applications in semi harsh environment.

This connector range is particularly suitable when very low loss links are required. It is also competitively priced.

1 2 3

4 5 6

7 8 9

(7)

7

Amphenol Optical Connectors

for Harsh Environment

J

_{BUTT JOINT CONNECTORS}

RNJOP

Rackable Multiway Connector

SIMOP

Modular Interconnection System Multiway Connector

MTRJ Field TV

MTRJ ruggedized in TV shell

LJTOP

LJT Connector

ECTAOP Metal

ECTA Duplex Connector

TVOP

TV 2-4-6-8 ways Connectors

Amphe-Lite

Ship Board to Quay Expanded Beam Connector

ECTA LX5

LX5 ruggedized in ECTA shell

LC/LX5 Field TV

LC/LX5 ruggedized in TV shell

BDC/MBC

Bayonet Duplex Connector Multiway Bayonet Connector

11 12 13

14 15 16

17 18 19

(8)

8 J

_{EXPANDED BEAM CONNECTORS}

Expanded Beam Lens Technology guarantees insertion loss and stability of transmission links in extremely harsh

environ-ment. The hermaphroditic lensed connectors are recommended where rapid extendable tactical field connections are

required.

CTOS

Tactical 2-4 ways

Expanded Beam Connector + window for protection

CROS

Railway 2-4 ways

Expanded Beam Connector + window for protection

CTOL

Tactical 2-4-6-8 ways Expanded Beam Connector + window for protection

HLM

Tactical Multiway Hermaphroditic Miniature Lensed Connector

PRLC

Ruggedised 38999 Multiway Lensed Connector

LPP

Lensed

Push Pull Connector

HMAtwo

Hemaphroditic expanded Beam Multiway

AXOS-e

Miniature Hermaphroditic Lensed Connector + window for protection

CNOS

Ship Board to Quay Expanded Beam Connector + window for protection

Amphenol Optical Connectors

for Harsh Environment

21 22 23

24 25 26

(9)

9 J

_{OTHER FIBER OPTIC PRODUCTS}

As part of our “Total System Support” policy, Amphenol expertise and support are at your service from R&D to prototyping

and production of transmission links as well as special devices and cabling or repairs.

Active Plug

Optical to electrical conversion

Tactical Deployable Cable Drums

Deployable Cable Drums

Loop Back Accessories

CTOS Shunt Caps STARTOP Loop Back

Special devices and accessories

Impact Splice

Drums, accessories, cables assemblies

b a

Miniature Light Weight & Tactical Mechanical Splice

FTOS

Flexible Tactical Optical Splice

HLM to MFM

adaptator

EMI Protection

Accessories for Harsh Environment

30

31 32

(10)

Railway AMPC Railway-UMTS Bowman USA Army IARRCIS Odette 38.658 (1.522) 32 (1.26) 38.48 (1.514) 27.178 (1.07) TFOCAtwo ECTA LX5 LC/LX5 Field TV HMAtwo

Selection Guide

10

(11)

Selection Guide

11

TFOCAtwo LC/LX5 Field TV ECTA LX5 HMAtwo

(12)

For more informations, please consult our website :

www.amphenol-fiberopticsolutions.com

NORTH AMERICA

AMPHENOL Pcd, Inc. 2 Technology Drive Peabody, MA 01960 Telephone: 1-978-532-8800 Fax: 1-978-532-6800

AMPHENOL AEROSPACE OPERATIONS AMPHENOL INDUSTRIAL OPERATIONS

40-60 Delaware Street

Sidney, New York 13838-1395 - USA Telephone: 1-607-563-5011 Fax: 1-607-563-5157

AMPHENOL BACKPLANE SYSTEMS

18 Celina Avenue

Nashua, New Hampshire 03063 - USA Telephone: 1-603-883-5100 Fax: 1-603-883-0171

AMPHENOL CANADA CORPORATION

20 Melford Drive - Scarborough, Ontario M1B 2X6 Canada

Telephone: 1-416-291-4401 Fax: 1-416-292-0647 1870 boul. des Sources, Suite 204

Pointe Claire, Quebec H9R 5N4 - Canada Telephone: 1-514-630-7242 ext. 225 Fax: 1-514-630-7697

AMPHENOL FIBER OPTIC PRODUCTS-RICHARDSON OPERATION

1778 North Plano Road, Suite 212 Richardson, Texas 75081 Telephone: 1-972-744-9801 Fax: 1-972-744-9022

AMPHENOL FSI

1300 Central Expwy N, Suite 100 Allen, TX 75013 U.S.A.

Toll-Free: 800-472-4225 - Fax: 214-547-9344 [email protected]

EUROPE

AMPHENOL SOCAPEX

MIL-AERO & INDUSTRIAL Business Unit 948 Promenade de l’Arve - B. P. 29 74311 Thyez Cedex - France Telephone: 33-4-5089-2800 Fax: 33-4-5096-1941

AMPHENOL LIMITED WHITSTABLE

Thanet Way, Whitstable - Kent, CT5 3JF United Kingdom

Telephone: 44-1227-773-200 Fax: 44-1227-276-571

AMPHENOL LIMITED NOTTHINGHAM

Unit D1 Crossgate Drive, Queens Drive Industrial Estate - NG2 1LW - Notthingham - United Kingdom Telephone: 44-1159-866-200

Fax: 44-1159-866-212

AMPHENOL AIR LB GmbH

Am Kleinbahnhof 4 - 66740 Saarlouis Germany Telephone: 49-6831-981-00

Fax: 49-6831-981-030

AMPHENOL ITALIA

Via Barbaiana n. 5, 20020 Lainate - Milano - Italy Telephone: 39-293-55-03-71

Fax: 39-348-361-7249

AMPHENOL IBERICA

C/Calderon de la barca, 3 4A, 28 100 Alcobendas, Madrid - Spain

Telephone: 34-91-654-83-52 Fax: 34-91-640-73-07

AMPHENOL SCANDINAVIA

Snosvangen 14 13466 Ingaro - Sweden Telephone: 46-8-571-423-90

Fax: 46-8-571-423-89

AMPHENOL BENELUX

Zadelmaker 121 NL-2401 PD Alphen aan den Rijn The Netherlands

Telephone: 31-172-444-903 Fax: 31-172-240-254

AMPHENOL CENTRAL EUROPE

Topolowa 13, 41 600 Swietochlowice - Poland Telephone: 48-32-3484-201 - Fax: 48-32-3484-202

AMPHENOL EUROPEAN SALES OPERATIONS

Hoofdveste 19 - 3992 DH Houten - The Netherlands Telephone: 31-30-635-8000 - Fax: 31-30-637-7034

ASIA

CHINA (FOP)

3rd Floor, The 4th Ind. District of Ind.

Headquarters Dong Keng Road, Gong Ming Town Shenzen 518132, Guangdong Province - PR China Telephone: 86-755-717-7945

Fax: 86-755-717-7622

AMPHENOL TAIWAN CORPORATION

No. 116, Lane 956, Zhong Shan Road Taoyuan City, R. O. C., 330 - Taiwan Telephone: 886-3-379-5677

Fax: 886-3-360-7259 Sales/CS/Eng./QA/MIS

AMPHENOL EAST ASIA LIMITED

2201 Railway Plaza, 39 Chatham Road South Tsmishatsui, Kowloon - Hong Kong

Telephone: 852-2699-2663 Fax : 852-2691-1774

AMPHENOL INTERCONNECT INDIA PRIVATE LIMITED

105 Bhosari Industrial Area - Pune 411 026 - India Telephone: 91-20-712-0363/0463/0155 Fax: 91-20-712-0581

AMPHENOL JAPAN MIL/AERO INDUSTRIAL

689-1, Iseochi, Ritto-shi Shiga 520-3044 - Japan Telephone: 81-77-553-8501

Fax: 81-77-551-2200

AMPHENOL DAESHIN

558 Sosa, SongNea

Bucheon-city, Kyunggi-Do - Korea 420-130 Telephone : 82-32-610-3800

Fax: 82-32-673-2507/665-6219

REST OF THE WORLD

AMPHENOL MEXICO

Prolongacion Reforma 61-6 B2

Col. Paseo de las Lomas - C.P. 013130 Mexico Telephone : 52-55-5258-9984

Fax: 52-55-5081-6890

AMPHENOL SOUTH AFRICA

30 Impala Road

2196 Chislehurston-Sandton - South Africa Telephone: 27-11-783-9517 - Fax : 27-11-783-9519

BAR TEC LTD

4 Hagavish St, PO Box 279 Kfar Saba 44102 -Israel

Telephone: 972-9-767-4097 Fax: 972-9-767-4324

GESTAS

34630, Besyol Londra Asfalti

Florya is Merkezi Kat.2 - Sefakoy / Istanbul - Turkey Telephone: 90-212-624-52-29

Fax: 90-212-599-30-68

AMPHENOL ARGENTINA

“Av. Callao 930 2do piso Oficina B “Plaza” C1023” - AAP Buenos Aires - Argentina Telephone: 54-11-4815-6886 Fax: 54-11-4814-5779

TFC SOUTH AMERICA BUENOS AIRES, ARGENTINA

Local Sales Office - Tucuman 540 - Suite 28 “C” C1049AAL- Buenos Aires - Argentina

Telephone: 54-11-4325-3471 Fax: 54-11-4327-1339

AMPHENOL AUSTRALIA PTY LIMITED

2 Fiveways Blvd., Keysborough Melbourne, Victoria 3173 - Australia Telephone: 61-3-8796-8888 Fax: 61-3-8796-8801

AMPHENOL DO BRAZIL

Rua Diogo Moreira, 132, 20 andar, rooms 2001-2-3 CEP: 05423-010 Sao Paulo SP - Brazil

Telephone: 55-11-3815-1003 Fax: 55-11-3815-1629

DOC-000501-ANG-B

Amphenol reserves the right to change the content of this document without prior notice

Realisation : wanagen:studios - Steven Kilgallon - 01/2004 Printed in France by MenloPark
