Server 2003 Designing Network Infrastructure

Copyright © 2009 by PrepLogic, LLC.

Product ID: 1113

Production Date: May 22, 2009

Total Questions: 240

All rights reserved. No part of this document shall be stored in a retrieval system

or transmitted by any means, electronic, mechanical, photocopying, recording, or

otherwise, without written permission from the publisher. No patent liability is

assumed with respect to the use of the information contained herein.

Warning and Disclaimer

Every effort has been made to make this document as complete and as accurate as

possible, but no warranty or fitness is implied. The publisher and authors assume

no responsibility for errors or omissions. The information provided is on an "as

is" basis. The authors and the publisher shall have neither liability nor

responsibility to any person or entity with respect to any loss or damages arising

from the information contained in this document.

Volume, Corporate, and Educational Sales

PrepLogic offers favorable discounts on all products when ordered in quantity.

For more information, please contact PrepLogic directly:

1-800-418-6789

(6)

Case Study 1

Background

Neo Press is a large publishing company that publishes books on a variety of different computing topics. Neo Press is acquiring one of its printing companies. The printing company, Pisces Printing, has its own domain and Internet presence. Pisces Printing currently uses the domain name of piscesprinting.com. The company will continue to operate independently of Neo Press.

Organization

The corporate headquarters is located in Los Angeles. There are approximately500 users located in this office including the IT department. The company has three regional offices located in New York, Chicago, and Vancouver. Several branch sales offices exist in Boston, Columbus, and Denver, and each sales office connects to the closest regional office. Each regional office has approximately 200 users. Branch offices host approximately 50 users each.

Existing LAN/WAN Environment

Most client computers run Windows 95. New computers in the corporate headquarters run Windows 2000 Professional. All mobile computers run Windows XP Professional. All servers run Windows NT 4.0. DHCP, DNS, and WINS servers are located in the headquarters office and regional offices.

Each of the regional offices connects to the corporate headquarters office using 1.544-Mbps lines. Each sales office connects to its closest regional office using 56-Kbps lines.

Currently, two Windows NT 4.0 domains exist. The corporate, regional, and branch offices are all part of the same domain (NeoPressNA). For security purposes, the accounting department has been configured in its own domain (NeoPressAcc).

Each domain has different password requirements. Users in the NeoPressNA domain are required to change their password every 42 days, whereas users in the NeoPressAcc domain are required to change their password every 30 days.

Active Directory Commentary

CEO: We recently acquired a new printing company. This company should remain independent of our

company. The printing company will continue to use its own IT group and administer its own users and resources. However, the two companies must be able to share resources. We would like to maintain a single global directory for both companies.

(7)

IT Manager: There are currently too many users with administrative authority. Many of these users are

inexperienced. We would like to reduce technical support overhead by limiting the administrative ability of local administrators.

1. Which of the following will have an impact on the number of domains that are created?

Select two.

A. A separate password policy is required for users in the accounting department.

B. There are approximately 200 users within each region. C. Pisces Printing must remain independent of Neo Press.

D. Pisces Printing and Neo Press must be able to share resources.

Find the Answerp. 135

2. Based on the business requirements outlined in the scenario, how many forests are required for the Neo Press Active Directory infrastructure?

Select the best answer. A. 1

B. 2 C. 3 D. 4

(8)

3. Which of the following statements correctly defines an Active Directory domain? Select the best answer.

A. The domain is the administrative and security boundary within an Active Directory hierarchy.

B. A domain is a group of well-connected IP subnets. C. A domain is the administrative boundary.

D. A domain is the security boundary within an Active Directory hierarchy.

4. Neo Press is implementing Exchange 2000. Bob, an administrator in one of the regional offices, attempts to install Exchange 2000 on one of the member servers. The installation fails. What could be causing the problem?

Select the best answer.

A. Bob must configure the member server as a schema master. B. Bob is not a member of the Schema Admins group.

C. Bob is not a member of the Domain Admins group.

D. Bob must update the schema on the server functioning as the schema master.

5. Once the upgrade is complete, how many WINS servers will be required? Select the best answer.

A. Zero B. One C. Four D. Seven

(9)

Answers: Case Study 1

1. A, C Review Questionp. 2 Detailed Explanationp. 152

2. A Review Questionp. 2 Detailed Explanationp. 152

4. B Review Questionp. 3 Detailed Explanationp. 153

6. D Review Questionp. 4 Detailed Explanationp. 154

7. C Review Questionp. 4 Detailed Explanationp. 154

9. B, D Review Questionp. 5 Detailed Explanationp. 155

(10)

Explanations: Case Study 1

1. Review Questionp. 2

Answers: A, C

Explanation A. The domain is the security boundary within Active Directory. A

password policy must be configured at the domain level. Unique password policy requirements will therefore impact the number of domains.

Explanation B. Active Directory can support millions of objects; therefore, the number

of users will not impact the number of domains created.

Explanation C. If certain areas within an organization require autonomy, this will

impact the number of domains that are created.

Explanation D. Resources can be shared within a domain, between domains, and

between forests with the appropriate trusts established. Therefore, the need to share resources will not impact the number of domains created.

Answers: A

Explanation A. Only a single forest is required. None of the business requirements

would result in the creation of multiple forests.

Explanation B. Only a single forest is required. None of the business requirements

Explanation C. Only a single forest is required. None of the business requirements

Explanation D. Only a single forest is required. None of the business requirements

Answers: A

Explanation A. A domain is the administrative and security boundary. The rights of

domain administrators do not cross the domain boundary unless explicitly granted.

(11)

Security policies are configured at the domain level.

Explanation B. A site is a group of well-connected IP subnets.

Explanation C. A domain is the administrative and security boundary. The rights of

domain administrators do not cross the domain boundary unless explicitly granted. Security policies are configured at the domain level.

Explanation D. A domain is the administrative and security boundary. The rights of

domain administrators do not cross the domain boundary unless explicitly granted. Security policies are configured at the domain level.

Answers: B

Explanation A. The first domain controller within the forest assumes the role of the

schema master. There is only one schema master per forest. The role can be seized by another domain controller.

Explanation B. Some applications will update the schema. To update the schema, you

must be a member of the Schema Admins group.

Explanation C. You must be a member of the Schema Admins group to update the

schema.

Explanation D. You do not need to extend the schema from the schema master.

Answers: A

Explanation A. Windows 2000 and Windows Server 2003 use DNS as the primary

name resolution service. Neither operating system relies on NetBIOS for locating network resources. Therefore, after the upgrade is complete, if there is no legacy software being used, WINS servers will no longer be required.

Explanation B. Windows 2000 and Windows Server 2003 use DNS as the primary

name resolution service. Neither operating system relies on NetBIOS for locating network resources. Therefore, after the upgrade is complete, WINS servers will no longer be required.

(12)

Explanation C. Windows 2000 and Windows Server 2003 use DNS as the primary

Explanation D. Windows 2000 and Windows Server 2003 use DNS as the primary

Answers: D

Explanation A. Ntdsutil is used to seize the schema master role.

Explanation B. Ntdsutil is used to seize the schema master role.

Explanation C. Ntdsutil is used to seize the schema master role.

Explanation D. Ntdsutil is used to seize the Schema Master role.

Answers: C

Explanation A. A single domain will not meet the security requirements.

Explanation B. Pisces Press must also be included in the design.

Explanation C. Three domains are required to meet the administrative and security

requirements.

Explanation D. Neo Press wants to maintain centralized administration; therefore,

regional domains should not be established.

Answers: B

Explanation A. This will not allow the company to continue using its current domain
