TOTAL INTERNAL REFLECTION

(3)

Total Internal Reflection

Occurs when light reflects off of the inside wall of a

denser medium (higher

(4)

Recall:

▪ _{When light passes}

from a dense material into a less dense

medium, light reflects

(5)

As the angle of incidence

increases, the angle of refraction

(6)

Critical Angle

▪ _{At a certain angle, the}

refracted ray follows a path exactly along the

surface of the dense

medium

▪ _{When the}_{angle of}

refraction is at 90o the incident angle is called

(7)

Critical Angle

▪ _{Critical angle} _{is the angle at which}

(8)

Critical Angle determines

▪ If the incident ray is increased beyond the critical angle, the light is no longer refracted

▪ _{Instead, it is}_reflected _{back inside the medium}

▪ _{This is called “}_{total internal reflection}_”

▪ When incident angle is greater than the critical angle (i>C), there is no refracted rays, all

(9)

Total Internal Reflection

▪ _{A light ray hits the inside face}

(10)

▪ _{A light ray hits the inside face of a}

semicircular block as follows.

▪ _{What will happen as the angle of incidence}

increases?

air glass

incident ray reflected ray

(11)

air glass

(12)

Total Internal Reflection

air glass

(13)

air glass

(14)

air glass

(15)

What

happened? air_glass

refracted ray

air glass

(16)

Total Internal Reflection

▪ _{At a small angle of incidence:}

▪ _{Incident ray splits into refracted & reflected}

▪ _{Angle of refraction < 90}o

▪ _{Angle of reflection = angle of incidence}

air glass

(17)

▪ _{As the angle of incidence increases, the}

angle of refraction increases until…

air glass

(18)

Total Internal Reflection

▪ _{Angle of refraction is at 90}o_{, parallel to the}

surface of the medium

▪ _{At this point the angle of incidence = critical}

angle (C)

▪ _{Angle of incidence = C when angle of}

refraction = 90o

air glass

(19)

▪ _{As the angle of incidence increase beyond}

the critical angle (>C), there is no more refracted ray

▪ _{All emergent rays are totally reflected inside}

the medium = Total Internal Reflection (TIR)

air glass

(20)

▪ Light is traveling slower in the first medium than in the second medium (v₁ < v₂)

▪ _{Thus light is moving from medium of higher refractive}

index to one of lower refractive index (n₁ > n₂)

▪ Critical angle (C) is defined when the angle of refraction is 90o to the normal (₂ = 90o)

▪ TIR occurs when angle of incidence is larger than the critical angle (₁ > C)

air glass

(21)

▪ _{Snell’s Law:}_n₁ _sin₁ _{= n}₂ _sin₂

▪ _{Critical angle}_{C =}₁ _{thus solve for}₁

At the critical angle, the refracted ray is a 90o ₌ 2

▪ n₁ sin₁ = n₂ sin90o ₍_sin₉₀o _{= 1}₎

▪ _n₁ _sin₁ _{= n}₂ ₁ ▪ n₁ sin₁ = n₂

Rearrange equation to get:

▪ sin₁ = n₂ / n₁

▪ ₁ _{= sin}-1 _(n

2 / n1)

▪ _{C = sin}-1 _(n

2 / n1)

If medium 2 = air, then n₂ = 1

▪ C = sin-1 ₍₁ _{/ n} 1)

air glass

C = ₁ r

refracted ray

reflected ray incident ray

R = ₂

(22)

Critical angles of different materials

Medium Refractive Index Critical Angle

Glass 1.50-1.70 30o-42o

Water 1.33 49o

Perspex 1.5 42o

(23)

TIR in Diamonds

Sparkling is due to:

1. Cut of diamond faces

2. High index of refraction which means a very small critical angle (n = 2.42, C = 24.4°)

(24)

TIR in Fiber Optics

▪ _{Technology that uses light to}

transmit information along glass cables

▪ _{Fibre optics cable is made up}

of a bundle of glass fibres

▪ _{Sample materials: high-purity}

(25)

TIR in Fiber Optics

▪ _{Fiber optics cable has a small critical angle,} thus a high refractive index

(26)

TIR in Fiber Optics

Light does not escape as it travels along the fiber optics cable because it undergoes total internal reflection

(27)

(28)

TIR in Fiber Optics

Advantages of Fiber Optics

▪ _{Signals are not affected by}

electrical storms.

▪ _{Cable is smaller and lighter}

than copper cable.

▪ _{More signals can be carried}

(29)

Fiber Optics in Endoscopes

▪ _{An endoscope is a}

flexible fibre optic cable through

which internal cavities can be viewed.

▪ _{Routinely used in}

the diagnosis of cancer and ulcers.

(30)

Gastroscopy

▪ _{Endoscopy examination of a}

stomach

▪ Endoscope inserted through the patient's mouth and fed down through throat

▪ Image obtained by endoscope is projected onto a screen

▪ A surgical instrument for

obtaining a biopsy has been fed through the endoscope cable and controlled by the doctor

(31)

Digestive Endoscopy

(32)

Diagnosing Cancer

Doctors using a fibroscope to investigate suspected lung cancer in a patient's bronchi (airways). A fibroscope is a flexible fibre optic cable with a camera on the end,

similar to an endoscope.

(33)

TIR in Prisms

▪ _{Plane mirror = glass + silvered surface}

▪ _{multiple reflection inside the glass}

▪ _{multiple images formed}

▪ _{nuisance in optical instruments}

glass

sheet silvered surface

I

₁

I

₂

I

₃

(34)

45 45 45 45 45 45

Prisms

▪ _{If light rays strike the inside}

face at an angle > 42, glass

prism behaves like a perfect mirror.

▪ _{Prisms are more useful than}

mirrors because it reflects

almost 100% of light internally.

▪ _{Mirrors lose some light}

through absorption.

▪ _{Emergent ray can be 90} _or

(35)

Prisms in Periscopes

▪ _{Instrument for observation from a concealed}

position

▪ _{Uses two triangular prisms (or mirrors) to}

change direction of light by 90

(36)

In War

▪ _{Land Periscope}

used by a

German Staff Officer during 1914

▪ _{Lens was sixteen}

(37)

(38)

Submarines

▪ _American

submarine commander inspects the horizon

through the periscope (1942)

(39)

http://web.mst.edu/~rogersda/military_service/periscopes.jpg Submarines carry all kinds of extendable devices in their

sail which allow them to sense above the ocean's

(40)

Prisms in Binoculars

▪ _{Uses 2 prisms to change direction of light by}

(41)

film mirror

Prisms in Single-lens Camera

▪ _{A five-}_{sided ‘pentaprism’ reflects light from}

(42)

Prisms and Retro-reflectors

▪ _{Device that returns incident light back in}

exactly the same direction from which it came

▪ _{Applications in bike reflectors, reflective strip}

on clothing, road signs

45

(43)

Practice Problems

▪ _{A ray of light traveling in}

the direction EO in air

enters a rectangular block at an angle of incidence =

30. The resulting angle of

refraction = 18.

▪ _{a. Find the refractive index}

of the block.

30

18

E

(44)

a. Find the refractive index of the block.

Given: ₁ = 30, ₂ = 18, n₁ (air) = 1

Required: n₂ (block)

Analysis: n₁ sin₁ = n₂ sin₂

Solution:

1 x sin 30 = n₂ sin 18

n₂ = sin 30 / sin 18 = 1.62

Phrase: The index of refraction of the block is 1.62 30

18

E

O

(45)

Practice Problems

▪ _{b. Find the critical angle C for the block.}

30

18

E

O

Recall: If medium 2 = air, then

(46)

b. Find the critical angle C for the block.

Given: ₂= 90, n₂ (air) = 1, n₁ (block) = 1.62

Required: ₁

Analysis: n₁ sin₁ = n₂ sin₂

Solution:

1.62 x sin ₁ = 1 x sin 90 sin ₁ = 1 / 1.62

₁ = sin-1 ₍_{1 /} _{1.62) = 38.1}

Phrase: The critical angle of the block is 38.1

30

18

E

O

Recall: If medium 2 = air, then

C = 1 = sin-1 (1 / n 1)

(47)

30

A

B

C

D

Practice Problems

▪ _{c. If the ray is incident on surface BC, from}

(48)

30

A

B

C

D

Practice Problems

Given: ₁= 60 n₁ (air) = 1

n₂ (block) = 1.62

Required: ₂

Analysis:

n1 sin1 = n2 sin2

Solution:

1 x sin 60 = 1.62 x sin ₂ sin ₂= 1 x sin 60 / 1.62

₂= sin-1 ₍_{1 x sin}₆₀ _/ _{1.62) = 32.3}

▪ _{c. If the ray is incident}

(49)

c. If the ray is incident on surface BC, from which surface and at what angle will the ray leave the block?

Recall:

Angle of incidence = 60o

Angle of refraction = 32.3o

Critical angle = 38.1o

30

A

B

C

D

32.3 57.7 32.3 60

Draw refracted ray2.

Measure angle of ray2 hitting block. Angle is greater than critical angle of 38.1o _{thus ray3 will reflect. Draw ray3 following Law of Reflection.}

Measure angle of ray3. Since it is the same angle as ray2, it will refract out at the same angle. Thus ray4 refracts at 60o _{from surface AD}_.

(50)

Practice Problems

▪ _{Which of the following angles is the critical}

angle of glass?

A B

(51)

Practice Problems

▪ _{Which of the following angles is the critical}

angle of glass?

A B

(52)

▪ _{A horizontal light ray hits a}

prism as shown.

▪ _{What happens to the light}

ray?

Practice Problems

45

(53)

▪ _{A horizontal light ray hits a}

prism as shown.

▪ _{What happens to the light}

ray?

Practice Problems

45
