since 1952
B-151-05.11wa ll panels
The stylish,
maintenance-free,
1526 Casab
lanca Gr
igio
These pages are for your inspiration! With Fibo-Trespo wall panels you can
easily and quickly build your high quality bathroom.
With all these designs and possibilities you can decorate your bathroom just the
way you choose, and still know that you have chosen a safe and secure product.
Fibo-Trespo wall panels are designed and manufactured in Norway and are a
unique system for cladding walls of all types of rooms.
w elcome To The wor ld of
m a inTen ance - fr ee waTer pro of
wa ll panels from fib o - Tr esp o a s
3091 HG F22
White
Tile and 1304 HG F08 Dar
k Blue Tile 2101 F03 HG Red Tile and 3091 F24 HG White Tile
The panels can be mounted
directly on the stud or on
existing walls.
The smooth and strong
sur-face can withstand both direct
water and large temperature
fluctuations, is easy to clean
and little maintenance.
Wall panels are approved
according to standard plumbing.
Follow the simple installation
manual, and you are assured a
result that lasts for years.
We have divided our collection
into 4 groups - by design and
appearance and named them:
cr es cend o
forTissimo
leg aTo
a d a gio
3091 F30 HG Mosaic
Tile and 4054 F03 and F24 HG
Antr asite Tile
Approvals :
Godkendelse MK 7.32/1462 Udstedt: 2007.08.27difference between the tiles and joints.
When fitting Crescendo check alignment of
border prior to final fitting.
1525 Casablanca
Azurra - blue 1529 Casablanca Cielo - latte 1526 Casablanca
Note! Colors may differ slightly from the actual product.
forTissimo
The Fortissimo collection is for everyone
who wants a luxurious look of tiles in an easy
to fit system. You can design combinations
just as you want your bathroom to be!
Our design numbers are illustrated on the
next page showing what designs are available
in different tile sizes. Most panels have the
same seam colour and size between the tiles
and can therefore be combined just as you
would like.
In addition to bathrooms and wet-room
areas, Fibo-Trespo wall panels are ideal for
kitchens, changing rooms, food preparation
areas, laboratories and shower blocks.
The possibilities are many and varied, the
panels are also used in reception areas,
offices and garages.
Add this to the cost saved in installation, and
Fibo-Trespo wall panels becomes not only a
more attractive option but a more practical
one too.
Design F23
Tile size 20 x 30 cm
Design F24
Tile size 60 x 15 cm
Design F22
Tile size 30 x 40 cm
4407 S Sort Eik 3290 SL Dark Slate 1) 3091 HG White Tile 3091 HG White Tile 3091 HG White Tile 3091 HG White Tile 3091 HG White Tile 4501 SL Limousine Slate 3457 S Grani-to Boticello 3448 S Dark Concrete 4393 S Stonewood 4406 S Serengeti 4054 HG Antrasite Tile 4054 HG Antrasite Tile 3290 SL Dark Slate 2091 S White Tile 2101 HG Red Tile 2124 HG Black Tile 2124 HGBlack Tile Beige Slate2156 SL 2122 HG Orange Tile 2586 HG Santiago Tile 2506 HG Toscana Tile 2520 G Ivory Tile
1525 Casablanca Azurro 1526 Casablanca Grigio 1528 Casablanca Artico 1529 Casablanca Cielo See page 6.
Design F05
Tile size 60 x 20 cm
Design F25
Tile size 15 x 15 cm
Design F26
Tile size 15 x 40 cm
Design F30
Tile size 3 x 3 cm
Crescendo
Tile size20 x 30 cm
Design F06
Tile size 15 x 20 cm
m/border
Design F08
Tile size 15 x 20 cm
Design F07
Tile size three - 40 x 60 cm
one - 5x30 cm two - 40 x 60 cm
2091 S White Tile 2091 S
White Tile White Tile2091 S White Tile2091 S
2101 HG Red Tile
2174 HG Creme Tile 1304 HG Dark Blue Tile
2124 HG Black Tile 2156 SL Beige Slate 2156 SL Beige Slate 3492 SL Norwegian Slate 3492 SL Norwegian Slate 4091 SL White Slate 4091 SL White Slate 3091 HG White Tile 3091 HG White Tile 3091 HG White Tile
4393 F01 S Stonew ood and 2091 F01 S White Tile 3290 SL Dark Slate 2091 S
White Tile White Tile3091 HG Dark Concrete 3448 S 3457 S Granito Boticello
Design F01: wall panels
with large tile sizes.
Every tile is 60 x 40 cm
and is great in
combination with other
design numbers.
A fantastic number
of possibilities!
b rin g n a t ure
in s i d e
4501 SL Limousine Slate 3463 S
F02 design is custom made wall panels
that look like 60 x 40 cm tile when
linked. Properly installed, it is virtually
impossible to find the seams, even in
the midst of the "tile".
This design gives you a great calm
surface and is ideal in combination with
other Fibo-Trespo wall panels.
Design F02 also comes with a
milled end so you get a natural
transition to the next panel design.
2091 F02 S White Tile and 2091 F03 S White Tile 2091 S
White Tile 2091 S White Tile F02 with/conclusion 2091 S White Tile F02 without/conclusion
Wall Panel with tile size 30 x 5 cm
in classic and bright colors.
Combine multiple colors or other
tiling and create something unique.
Such a bathroom makes it a
pleasure to get up every morning!
3290 F01 SL Dar k Slate Tile and 3091 F03 HG White Tile 2101 HG Red Tile 2091 S White Tile 1304 HG
Dark Blue Tile Orange Tile2122 HG Black Tile2124 HG
3290 SL Dark Slate 3091 HG
White Tile Antrasite Tile4054 HG
2174 HG Creme Tile 2156 SL
Wall Panel with tile size 60 x 20 cm
for a classic and beautiful badrom.
You may combine and design your
room exactly the way you would prefer.
The possibilities are endless.
2091 S
White Tile Norwegian Slate3492 SL White Slate4091 SL 4091 F05 SL
White Slate
Wall Panel with tile
format15 x 20 cm
and a decorative
border in the middle.
The panels are easy
to customize both
in corners and in
connection with
water / wastewater
systems and el.
forTissimo - design f0 6
2091 F06 S White Tile 2091 S White Tiledecorative
Wall Panel with tile size 60 x 40 cm.
Special panel with one field in the
mid-dle divided into 16 tiles sized 30 x 5 cm.
Se panels below.
2091 S
White Tile Beige Slate2156 SL 2091 F07 S
White
Tile and 2101 F03 HG Red
Tile
t w o d e ko r
Wall Panel with
tile size 15 x 20 cm
Design F08 has the
classic size the
décor, all recognize
and enjoy.
Choose between
6 gorgeous colors.
1304 F08 HG Dar k Blue Tile and 3091 F22 HG White TileforTissimo - design f0 8
2091 SWhite Tile Beige Slate2156 SL White Tile3091 HG 1304 HG
Dark Blue Tile Creme Tile2174 HG White Slate4091 SL
Welcome to your new bathroom!
With our simple installation, you can
get new bathroom walls in a weekend!
Beautiful, safe and waterproof.
Most panels have the same color inte
joint and can thus be used in
combina-tion with each other. An excepcombina-tion
here is 2520 F23 Ivory Tile, Tile
San-tiago 2586 F22 and F23 2506 Tuscany
Tile has a narrower gap between the
"tiles" than the rest of the collection.
2586 HG
Santiago Tile White Tile3091 HG Toscana Tile2506 HG Ivory Tile2520 G White Tile3091 HG
2586 F22 HG Santiago Tile
d
e
s
ig
n
f
2
3
Tile siz
e 20 x 30 cm
d
e
s
ig
n
f
2
2
Tile siz
e 30 x 40 cm
n e w wa ll p a n e l s
- n e w b a t h ro o m
d
e
s
ig
n
f
24
Tile siz
e 60 x 15 cm
4054 F03 and F24 HG Antr asiteTile and 3091 F30 HG Mosaikk
White Tile 3091 HG White Tile 2124 HG BlackTile AntrasiteTile4054 HG
Is a bathroom big or small;
Fibo-Trespo Wall Panels will provide
freedom of choice at an affordable price.
Wall Panel Design F24, F25 and F26
are classic and beautiful. Combine
these designs or one design in the
entire bathroom.
d
e
s
ig
n
f
2
5
Tile siz
e 15 x 15 cm
d
e
s
ig
n
f
2
6
Tile siz
e 15 x 40 cm
2091 F05 S WhiteTile and 3492 F26 SL Norw
egian Slate
3492 SL Norwe-gian Slate 1) 3091 HG
Fibo-Trespo Wall Panel has no devil -
the panels are perfect and is delivered with
garanteed durability.
Wall Panel with tile size 3 x 3 cm
Sleek and smooth mosaic decor suitable
for detailing or the intire wall.
3091 HG White Mosaic 2101 HG
Red Mosaic Black Mosaic2124 HG 2124 F30 HG Black Mosaic and 3091 F22 HG
White
Tile
t h e d e v il i s in
t h e d et a il
Lighting determines how prominent
the delicate floral pattern becomes.
The pattern is ton-ì-tone matte / gloss
- an exclusive choice.
The panels are 60 cm wide
(11 x 2400 x 600 mm) and is best
suited as decor panel on it`s own.
However, the Black Flower panel can
easily be combined with other
Fibo-Trespo Wall Panels.
Black Flower panel comes with
protective plastic so the decor
will be in perfect condition.
b l a ck fl o w e r
0901 P1 Black Flower 0901 P 1 Black Flo w er520 G Ivory 510 G Milano
A little more sophisticated, yet still
delicate and soft. The Adagio
collection is in total 8 decors, all
reflecting modern design trends.
No matter what design from
Fibo-Trespo you choose for your walls
you can be very sure that we never
compromise with quality. This quality
product has been used in thousands
of bathrooms and other wet rooms all
over the Nordic countries for decades.
All of them are supplied with the
Aqua Lock system.
582 S Bør
stet stål and 192 S
Titan
wall molding can be
de-livered in the decor marked
with a red check mark
506 HG Toscana marmor 544 S Frostblå 1)
111 HG Hvit 116 S Sand
Our classic and traditional collection has
lately been used with a lot of success in
modern and minimalistic rooms.
The Legato collection has as standard the
Aqualock system for quick installation on
bathroom walls.
The Legato collection has 5 decors, 43
plain colors and the 192 S Titan, that looks
like a steel surface. All easy to clean and
easy to maintain. This collection is also a
very affordable choice.
111 S Hvit
116 S Sand
s m o ot h s ur fa c e
wall molding can be
de-livered in the decor marked
with a red check mark
172 S Polargrå 192 S Titan
111 S Hvit
Don`t work with plaster, membrane
and tiles. Fibo-Trespo wall panels are
mounted safely and easily.
Follow the installation instructions - and
you can get new walls over a weekend!
l-Shaped
FINIShING
(also known as end caps or stop ends)
Available in White PVC and Brushed Silver
Aluminium,
12.7mm
25.5mm
baSe
ProFILE
Available in Brushed
Silver Aluminium only
12mm 35.98mmStacking
ProFILE
Available in White PVC or
Brushed Silver Aluminium
12mm 35.5mm
*Also available in a 135˚ angle - Silver Aluminium only.
internal
CorNEr ProFILE
*Available in White PVC and Brushed Silver
Aluminium,
10.4mm 1 14mm 2
*Also available in a 135˚ angle - Silver Aluminium only.
external
CorNEr ProFILE
*Available in White PVC and Brushed Silver
Aluminium
21mm 21.6mm 1 21mm 26.6mm 2 34.6mmFibo-Trespo Wall panels have the Aqualock panel-locking system. This makes the installation
very easy and gives a consistent and great end result.
aqualock
For easy installation!
1
2
3
cleaning and maintenance:
Simply wipe with a damp cloth or a mild non-abrasive cream cleaner.
approved sealant
Casco Super Fix
Bostic Maxi Bond
Sikaflex 221
Tech 7
Screws
accessories:
Base Profile
approvals:
32
The last panel on each run of a wall should be cut to size and swung into position with the corner profile attached. The profile is then fastened to the stud or batten. remember to use clear mildew resistant silicone sealant in the corner profile.
For areas higher than 2400 mm a stacking profile should be used.
remember to use clear mildew resistant silicone in the stacking profile.
Where an installation is to go around a room, start by ensuring that the last panel is cut to fit over the door. Fit panels using our Aqualock easy-to-fit tongue and groove system, clicking into place as you go.
Silicone
Silicone
Cut the panel to size and adjust the width so that the nails/screws are countersunk. remember that the panel must be correctly aligned. remember to use clear mildew resistant silicone in the corner profile. The corner profile is fastened to the batten
or stud before the next panel is installed.
Silicone
Silicone respatex wall panels with the Aqualock system are fixed to
battens/walls by nailing or screwing into the groove running the length of the panel using No. 6 screws or 35mm gypsum board nails at a distance of 200mm between each nail/screw. The lowest nail/screw must be fastened a maximum of 20mm from the bottom of the panel.
In areas of high humidity, respatex wall panels must be fitted using a clear mildew resistant silicone sealant in every joint. Apply the sealant when the panel is upright against the wall, next to the previously installed panel. It is then easy to ‘lock’ the two panels together into position without creating any mess. run a bead of sealant along the length of the panel groove with a sufficient amount to provide a good seal for the panels when they are assembled. Excess sealant must be removed at once by washing the joint with white spirit followed immediately by wiping with a damp cloth. This ensures that the joint is virtually invisible with no adhesive showing.
Clear mildew resistant silicon
New
Aqualock
3.
4.
5.
6.
Standard Wall Panel : 600mm x 2400mm x 10.2mm (12kg) heat resistance :
Do not expose the laminate surface to sustained high tem-peratures (max 180°C or 356°F)
Fire certificate :
Fibo-Trespo has a Class 2 Surface Spread of Flame Certifi-cate tested to BS 476 parts 6 & 7.
cleaning and Maintenance :
Simply wipe with a damp cloth or a mild non-abrasive cream cleaner.
guarantee :
Fibo-Trespo offers the domestic consumer a 15 year guarantee,from date of purchase, that the panels will remain watertight and will not crack or delaminate if fitted correct-ly. Base profiles must be used when installing in wet areas to prevent water damage occurring. The guarantee will be void if panels are not fitted according to the manufacturer's instructions. Please check the product carefully for flaws or
colour discrepancies before installation because, if faulty
panels are fitted, any subsequent liability will be restricted to the value of the panel(s) only.
Storage :
The panels should be protected against moisture during transportation and be stored flat in their packaging. iMpOrtant - Panels should be acclimatised in the room
in which they are to be used for at least 3 days prior to
fitting.
Fitting inStrUctiOnS - pleaSe read
careFUllYThe panels are intended for use as wall and ceiling linings on a flat surface.
Ensure that all walls are completely dry and level before starting installation.
If used on an outer wall, a protective plastic film must be used between the wall and the panels.
When installed on a smooth brick or concrete surface, use appropriate screws and wall plugs. remember to counter-sink the nails or screws. Drill holes for the plug through the nailing lip into the concrete then place the plug and fasten the screw.
pleaSe nOte - If installed on steel studs, with or without gypsum boards, please contact our sales office for further instructions.
Before installing panels check that the underlying surface is level and provides a firm nail/screw hold. Panels should be attached to battens. Distance between battens - Vertically: 600mm or 900mm. horizontally: 800mm.
Panels can also be glued to walls providing these are sound. Use a neoprene based glue applied to the back of the panel in a zig-zag pattern. remember to use plastic film between panel and an outer wall. Check that the panels are correctly aligned. Panels have a drip nose at both ends and can be installed either way round.
Approvals: THEORIGINAL W AT ERPROOFPANEL approved sealants:
Maxi-Sikaflex 221 fugemasse 4-5 mm Sikaflex 221fugemasse Maks 35 mm. 600 b. Wet Area
height adjustments should be made where the panel meets the ceiling. Floorcovering material should continue approx. 100 mm up the wall behind the panels.
In wet areas where a shower or a bath is to be installed, a profile and clear mildew resistant silicone must be used. It must also be used between the profile and the floorcovering. Clearance between the base profile and the floor should be 60-80 mm. a. Dry Area
height adjustments should be made where the panel meets the ceiling. Floorcovering material should continue behind the panels approx. 100 mm up the wall. The distance from the bottom of the panel to the floor should be 60-80 mm.
c. on ceramic tile
height adjustments should be made where the panel meets the ceiling. The smallest joint for expansion and mildew clear resistant silicone allowed is 4-5 mm.
9a.
circUlar SaW/JigSaW: Use a firm and stable table or work bench to work on.
decorative side down.
7. Floor treatment
Silicone
Silicone
9. last panel (panel over doorway)
10. cutting panels
2 mm. klaringSikaflex 221 fugemasse 10b.
handSaW:
Use a finetoothed saw. The cut should only be made on the down-mard stroke.
decorative side up.
10c. Filing:
Use file at the shallow angle away from the laminate edge. decorative side up.
10d.
apertUreS FOr pipeS etc: The aperture should have min. 2 mm clearance.
Seal with clear mildew silicon seal-ing even if the pipe is to be fitted with collar
10e.
adaptiOn OF panel: Drill first with as large a drill as pos-sible before cutting.
Silicone 2 mm clearance
Max 35 mm
.
8.
Fitting over bath or shower with base profile
Silicone Silicone 2-3mm Silicone 2-3 mm Base profile Base profile
a . Fitting OVer a bath Or ShOWer traY
Always use a base profile. Clear, mildew-resistant silicone sealant must be applied in front and behind the base profile and the panel as well as between the bottom of the profile and the bath or shower tray. The smallest acceptable gap for expansion is 2-3mm. See illustration A.
b. Fiting behind a bath Or ShOWer traY
Always use a base profile between the panel and the floor.
Follow instructions as in section A. Apply silicone sealant between the panel and bath tub or shower tray as well as between the profile and the floor. The smallest accept-able gap for expansion is 2-3mm.
A.
The last panel to be used in a whole room installation should be cut to fit above the doorway (see fig a)
B.
This panel is fitted by cutting off the tongue prior to fixing above the door (see fig b: x = to be cut off). The panel is then fastened "hidden" under the ceiling and door moulding.
2101 F03 HG Red
Tile and 4054 F03 and F24 HG
Antr asite Tile 2124 F03 HG Black Tile and 2091 F07 S White Tile 2091 F05 S
inspir ed ?
We hope we have given you an idea of the amount of possibilities
wall panels from Fibo-Trespo gives you.
Give yourself a great bathroom with atmosphere for relaxing and comfort,
without compromizing on quality.
The Fibo-Trespo wall panels provide instant waterproof, hygienic walls with a
choice from an attractive range of colours and finishes. The finished design is
only limited by your imagination.
3463 F01 S Pure Concrete and 2091 F02 S
White
Tile
4406 F01 S Serengeti and 2091 F01 S
White
Fibo-Trespo AS
Industriveien 2, 4580 Lyngdal Norway Phone.: (+47) 38 13 71 00 Fax.: (+47)38 13 70 51 www.byggmagroup.com E-mail: byggma@byggma.no
Byggma - for better living
Foto:
P
