Adaptation support in design time through IMS QTI and IMS LD specifications in dotlrn web based learning environment

(1)

aDeNu Research Group

http://adenu.ia.uned.es

Adaptation support in design time

through

IMSQTI

and

IMSLD

specifications in

dotLRN

web

based learning environment

Javier Morales Puerta

Olga C. Santos

(2)

2

aDeNu Research Group

Content

1. Introduction

2. Practical Example

3. Development

4. Application to ADAPTAPlan and EU4ALL

5. Conclusions

6. Future Work

7. Demo

8. Acknowledgment

(3)

3

1. Introduction (I)

Standard Education

Webbased Learning Systems

INTERNET

Guide student’s interaction to educational goals

clearly specified.

Learning tasks that can measure those goals success.

Focused in the

learning process NOT

in the

content

Nowadays, every online course:

to the student's learning process

ADAPTATION

(4)

4

1. Introduction (II)

• Objetive

improve

ADAPTABILITY

of

dotLRN

Learning Management System(LMS)

to the student's learning process

¿ How ?

Integrating

grail (IMSLD)

assessment (IMSQTI)

¿ For what ?

Esssential

process in a University with a large number

to afford a personalization

of students such as

UNED

scalable

flexible

(5)

5

2. Practical Example (I)

(6)

6

2. Practical Example (II)

(7)

7

2. Practical Example (III)

(8)

8

2. Practical Example (IV)

•

Advantages

of development based on IMSLD and IMSQTI:

properties

open/flexible way of representing student's

information

their preferences

their knowledge

their interests

more complicated operations

for groups

collaborative learning activities

synchronization

more adapted context

IMSLD B level

properties update based on

intermediate events

(9)

9

3. Development (I)

Design Time

"IMS Question and Test Interoperability Integration

Guide"

Definition:

IMSLD properties

IMSQTI variables

synchronization

(10)

10

3. Development (II)

IMSLD Property

<imsld:locpersproperty identifier="resourcetest4.score"> <imsld:datatype datatype="integer" />

<imsld:initialvalue>0</imsld:initialvalue> </imsld:locpersproperty>

<imsld:locpers-property identifier="impeval-good-enough"> <imsld:datatype datatype="boolean" />

<imsld:initial-value>false</imsld:initial-value> </imsld:locpers-property>

<imsld:learning-activity identifier="LA-task41">

<imsld:title>4.1. Impressionism Evaluation</imsld:title> <imsld:activity-description>

<imsld:item identifierref="resource-test4" /> </imsld:activity-description>

<imsld:complete-activity>

<imsld:when-property-value-is-set>

<imsld:property-ref ref="impeval-good-enough"/> <imsld:property-value>true</imsld:property-value> </imsld:when-property-value-is-set>

</imsld:complete-activity> </imsld:learning-activity>

(11)

11

aDeNu Research Group

3. Development (III)

<imsld:conditions>

<imsld:if> <imsld:greater-than>

<imsld:property-ref ref="resource-test4.score"/> <imsld:property-value>5</imsld:property-value> </imsld:greater-than>

</imsld:if> <imsld:then>

<imsld:change-property-value>

<property-ref ref="impeval-good-enough" /> <property-value>true</property-value>

</imsld:change-property-value> </imsld:then>

</imsld:conditions>

IMSLD Condition

IMSLD Resource

<resource type="imsqti_item_xmlv2p0" identifier="resource-test4" href="resources/imsqti-impeval.xml">

<file href="resources/imsqti-impeval.xml"/> </resource>

(12)

12

aDeNu Research Group

3. Development (IV)

IMSQTI Score

<decvar vartype="Integer" defaultval="0" varname="score"/>

(13)

13

3. Development (V)

RunTime

1.

Student finishes assessment

2.

Submit

3.

callback with score

4.

grail

catches it

5.

saves score in the property

6.

Continues with the next activity

(14)

14

aDeNu Research Group

3. Development (VI)

• Changes in dotLRN 2.4.0d1

• imsld – 0.22d8

imsldcallbackprocs.tcl

ad_proc public callback imsld::import

ad_proc callback as::session::update impl imsld (new)

imsldparseprocs.tcl

ad_proc public imsld::parse::parse_and_create_resource {

ad_proc public imsld::parse::parse_and_create_item {

ad_proc public imsld::parse::parse_and_create_property {

ad_proc public imsld::parse::parse_and_create_activity_description {

ad_proc public imsld::parse::parse_and_create_learning_activity {

ad_proc public imsld::parse::parse_and_create_imsld_manifest {

(15)

15

http://adenu.ia.uned.es

3. Development (VII)

• assessment – 1.4d

ascallbackprocs.tcl

ad_proc public callback imsld::import impl qti {} {

asqtiprocs.tcl

ad_proc public as::qti::register_object_id

ad_proc public as::qti::register_xml

ad_proc public as::qti::register_xml_object_id

ad_proc public as::qti::parse_qti_xml

ad_proc private as::qti::parse_item

ad_proc public as::qti::register_object_id

(16)

16

4. Application to ADAPTAPlan &

EU4ALL

• ADAPTAPlan

• EU4ALL

IMSLD Learning Courses that use properties to specify:

a)

student learning style

b)

student knowledge

c)

Felder and Silverman Learning Style Model

d)

Bloom's Taxonomy of Educational Objectives

Adapt a course on Object Oriented Programming –

OOPC

presented in

IJCSA08

, to exploit

IMSQTI adaptive functionality

Scenario 1 –

Student registers in a learning course

Scenario 2 – S

tudent gets familiarized with the virtual learning environment

(17)

17

aDeNu Research Group

5. Conclusions

Definitive

integration

between

grail (IMSLD)

and

assessment (IMSQTI)

Application to ADAPTAPlan & EU4ALL projects

dotLRN evolution

Improve

adaptability

to learning processes

thanks to evaluation

(18)

18

6. Future Work

• Code Publishing (UNED and OpenACS)

• Continue with dotLRN evolution

– Improving its adaptability to the student preferences

– Extend

assessment

package developing

IMSQTI

(19)

19

(20)

20

8. Acknowledegments

• Derick Leony

• Olga C. Santos

• Prof. Jesús G. Boticario

• Emmanuelle Raffenne and Dave Bauer

• OpenACS Community

(

every question becomes always an answer

)

(21)

21

thanks
