PROTOTYPING ELLIPTICALLY PROFILED INVERTED PENDULUM WALLS IN
CROSS-LAMINATED TIMBER (CLT) FOR PASSIVE SELF-CENTERING AND
SEISMIC RESILIENCY
by
Marco Lo Ricco
A Dissertation Submitted in Partial Fulfillment of the Requirements for the Degree of
Doctor of Philosophy
in Engineering
at
The University of Wisconsin-Milwaukee
ii
ABSTRACT
PROTOTYPING ELLIPTICALLY PROFILED INVERTED PENDULUM WALLS IN CROSS-LAMINATED TIMBER (CLT) FOR PASSIVE SELF-CENTERING AND SEISMIC
RESILIENCY by
Marco Lo Ricco
The University of Wisconsin-Milwaukee, 2019 Under the Supervision of Professor Al Ghorbanpoor
Cross-laminated timber (CLT) buildings garnered international attention, nearly a decade ago, for elevating wood construction to new heights on fully panelized assemblies of floors and walls. While highly regarded as a sustainable building material, use of CLT as a structural wall system depends on seismically resilient strategies like controlled rocking. This project prototyped
elliptically profiled CLT panels and slotted-pin steel connections, at full-scale, to produce rolling and slip-friction inverted pendulum wall systems of one-story height and inspired by seismic isolation concepts. Digital fabrication realized elliptical profiles along the loadbearing edges of six 5-ply CLT panels and various customized slot shapes for accompanying steel connections. Pins traveling within V-shaped slots intended only to guide rolling as displacement restraints, in contrast with pins constrained within vertical slots that forced panels into slip-friction
combinations of rolling and sliding. Six CLT panels and two versions of shear transfer
connections yielded a total of 12 full-scale wall prototype configurations for cyclic lateral load-displacement testing that emulated standard quasi-static protocols for seismic isolation. The hysteresis plots generated by the tests confirmed that elliptical eccentricity predictably controlled effective lateral stiffness and displacement capacity, while providing inherent self-centering.
iii
When configured to roll using traction along steel bearing surfaces as the primary mechanism of story shear transfer, CLT panels supported simulated gravity loads as high as 400 kN (90 kips) while achieving story drifts commonly exceeding 10 and even 20 percent. When configured to transfer shear primarily through a pin connection, however, CLT panels slid and sustained damage that limited gravity load capacity to 133 kN (30 kips). Connection constraint, therefore, dictated whether friction essentially transferred story shears transfer or dissipated energy. To help explain implications of friction, Digital Image Correlation (DIC), piezoelectric film pressure mapping, Finite Element Analysis, and fundamental free-body diagrams visualized the behavior of high-pressure contact between timber and steel. Despite the low damping exhibited by rolling and increased damage of slip-friction rocking, both models of elliptically profiled rocking walls can develop into viable options for isolation planes within multistory building schemes, based on the results of this study.
iv
© Copyright by Marco Lo Ricco, 2019 All Rights Reserved
v
To those who encouraged and supported me— especially my wife,
parents, and
all who cared for my sons,
vi
TABLE OF CONTENTS
Abstract ... ii
Table of Contents ... vi
List of Figures ... ix
List of Tables ... xvi
Acknowledgements ... xviii
Agency Sponsors ... xviii
USDA/U.S. Forest Service, Forest Products Laboratory Contributors ... xviii
UWM Affiliated or Invited Contributors ... xix
College of Engineering and Applied Science ... xix
Structural Engineering Laboratory ... xix
Prototype Fabrication ... xx
Computing Resources ... xx
Faculty Committee Members ... xx
Peer Review Consultants ... xxi
Industry Partners in Digital Fabrication ... xxi
I. Introduction ... 1
The Emergence of CLT as a Mass Timber Composite ... 2
The Rise of Cross-Laminated Timber ... 5
II. Literature Review ... 7
Mapping a Comprehensive Seismic Development Strategy ... 9
Inelastic Ductility: The Force-Based Approach ... 10
Controlled Rocking: An Evolving Displacement-Based Alternative ... 12
Mechanics of Inverted Pendulum Rocking ... 12
Evolution of Precast Concrete Panelized Systems ... 13
Timber Adaptations ... 14
Vertically Post-Tensioned Rocking Walls ... 15
Slip-Friction Hold-Downs ... 17
Ductile Anchorage ... 18
Isolation as a Path to Seismic Resiliency ... 19
General Considerations ... 20
III. Methodology ... 23
System Model ... 23
Elliptical Rolling Rod Isolation ... 24
No-Slip Traction Rolling ... 25
Slip-Friction Rocking... 32
Principle of Virtual Work ... 36
vii
Friction: Shear Transfer or Energy Dissipation? ... 38
Geometric Proportioning ... 38
Prototype Testing ... 40
Test Matrix ... 40
Prototype Connections ... 43
Simulating Boundary Conditions ... 45
Prototype Testing Protocol ... 46
Capabilities and Limitations ... 48
Imperfections ... 49
Data Collection ... 49
Scales of Study ... 51
IV. Results, Observations and Findings ... 52
Overview of Test Results ... 52
Hysteresis Plots ... 57
General Notes... 57
Keyed Notes ... 58
Axis Scaling ... 58
Hysteresis Characteristics ... 58
No-Slip Traction Rolling ... 59
e = 0.63 Panel ... 59 e = 0.73 Panel ... 61 e = 0.82 Panel ... 65 e = 0.88 Panel ... 67 e = 0.91 Panel ... 71 e = 0.94 Panel ... 75 Slip-Friction Rocking... 79 e = 0.63 Panel ... 79 e = 0.73 Panel ... 81 e = 0.82 Panel ... 84 e = 0.88 Panel ... 87 e = 0.91 Panel ... 90 e = 0.94 Panel ... 93 Hysteresis Characteristics ... 97 Stability ... 97
Stable Rolling through Variable Vertical Load ... 98
Slip-Friction Rocking Sensitivity to Vertical Loads ... 99
Out-of-Plane Stability ... 103
Restoring Forces ... 104
Predictability ... 105
Stiffness... 105
Track and Roller Imperfections ... 107
Frictional Damping ... 107
Durability ... 108
Rolling Protection ... 109
Slip-Friction Rocking and Mixed Modes ... 109
viii
No-Slip Traction Rolling Effects on Laminations ... 111
Slip-Friction Rocking Effects on Laminations ... 114
Digital Image Correlation Comparisons ... 120
Timber Laminations ... 121
Steel Connections ... 127
Wind Restraint ... 130
V. Summary, Conclusions, and Recommendations ... 131
Summary Results Tables... 132
Conclusions ... 138
Recommendations for Further Development ... 142
Use of the Hysteresis Models ... 144
Design Guidelines for Archetype Development ... 145
References ... 148
Appendix A: Principle of Virtual Work Models... 158
Appendix B: Connection Details ... 165
Appendix C: Precursory Characterizations of Timber-to-Steel Contact ... 179
Finite Element Analysis ... 179
Piezoelectric Pressure Mapping ... 187
Digital Image Correlation ... 193
DIC Objectives... 194
DIC Methodology ... 194
DIC Results ... 197
Timber Bearing Conditions ... 197
Conclusions of Precursory Phase ... 199
