Huawei IDS2000-S Small
Modular Data Center Solution
With the development and maturity of the IT automation age, rapid development of mobile Internet & cloud computing industry has posed a challenge to the traditional data center construction mode. For large and medium-sized group enterprises, the traditional IDC systems of their branches face challenges such as: without unified planning and standard architecture, hard to purchase, deploy and maintenance because of various vendors, can not be unified managed in the headquarter, etc. The "big center, small branch" group data center concept has been deeply accepted and spread. Therefore, Huawei release IDS2000-S series small modular data center.
IDS2000-S Small data center network location
Group Data Center Concept: big center, small branch
Sales branch
Research branch
Sales branch
Research branch
Sales branch
Research branch
Global MGMT SLA/KPI
IDC large center
(Core business & process) Remote DR
center
Group Management
Region Management
Region Management
Local DR center Production
center
Regional service centers
(Optional, reduce delay)
IDC micro centers in branches
(Office, Light app)
Region MGMT Unified O&M
“Lights-out”
MNGT
Unified Spare
parts
IDS2000-S– Product Introduction
IDS2000-S Basic Version is meant for deployment in normal office buildings, which have cooling facility to ensure ambient temp in the range of 5 ~ 30ºC.
IDS2000-S Basic Version main features
Flexible configuration
Safety and Reliability
Low Cost
& Energy saving
•Modular design to achieve on line flexible expansion
•Variable configuration solutions meets different application scenarios, improves customer value
•Improves facility safety by complete monitoring of all inside conditions of cabinet like temperature, humidity etc.
•Power distribution system supports lighting protection & manual
maintenance bypass to improve system reliability
•Operations cost is saved as the fan speed is automatically adjusted according to the ambient temp
•Heat Dissipation by Fan; Dynamic Cooling load shared by 4 Fans, mutual backup completely support smooth business operations Cooling
Cabinet
Power distribution box
UPS ECC500
Battery
DC variable speed fan is connected with the monitoring system, fan redundancy improves system reliability
Standard 19 inch cabinet, compatible with third- party servers, 42U available user space, 1500kg static load-bearing, aesthetic appearance &
structurally stable
High efficiency & energy saving UPS, customized power supplies offered for different power applications
Monitors internal environment of Cabinet, supports remote management & maintenance and SNMP north interface to global management
Variable backup time as option, continuously offers power supply after mains failure.
Product series
IDS2000-S – Typical Configuration
Notes:
• “×” stands for no configuration, “√”stands for standard configuration
• All above configurations are designed based on condition of the maximum heat dissipation (3kW)
• Main cabinet standard configuration: One set of PDU, monitoring unit, smoke sensor, temp and humidity water leakage detector &
door magnetic switch
• Network cabling cabinet standard configuration: One set of PDU, smoke sensor & door magnetic switch
• Battery standard configuration: One set of smoke sensor & magnetic switch Products
Configuration IT cabinet with UPS I
IT cabinet + Network cabling cabinet
IT cabinet with UPS
＋battery cabinet
IT cabinet with UPS + Network cabling cabinet
+ battery cabinet
Main cabinet user
space 25U 25U 25U 25U
Network cabling
cabinet user space × 42U × 42U
Battery cabinet × × √ √
UPS √ √ √ √
Back up time 30min 30min 30min~4h optional 30min~4h optional
Product Series
Notes:
• IT rated capacity is taken as either max. power supply capacity of UPS (6KVA) or max. heating dissipation, whichever is less.
• The net & gross weight of single cabinet is not more than 220kg and 250kg respectively (excluding IT equipment and batteries)
• 25U IT user space of standard configuration
Items Description IDS2000-S basic type
Power supply 220V, 230, 240/50(60)Hz; 208V(Double firing line)/50(60)Hz
Ambient 5 ~ 30ºC
Humidity 10~90%
Altitude 0~3000m
Certificate CE / RoHS
Cabinet system Dimensions W*H*D(mm): 600×2000×1100
IT user space 25U
Power distribution system
UPS
Capacity 3KVA, 6KVA, 10KVA,
Configuration Single UPS
Certificate CE
rPDU Installation type vertical installation
Mode 32A single phase(20*C13+4*C19)
Battery Capacity 7Ah, 9Ah, 40Ah, 65Ah, 100Ah
Backup time 10 mins, 15 mins, 30 mins, 60 mins, 120 mins
Monitoring system
Monitoring unit ECC500 Monitoring
components
Smoke sensor(Available for cabinet inside & outside)/Temp & humidity sensor/ water leakage sensor /video/ door switch
Function Web remote management / supports connection with NetEco / Access customer network management, SMS notification, cabinet equipment & micro-environmental monitoring
Cooling Fan Installation location 4 No fans located on the top of cabinet
Type DC variable speed fan, automatically adjusted fan speed
Dimension/weight
Packaging dimensions W*D*H(mm)734×1268×2200
Gross weight 250kg
Net weight 220kg
Product Series
IDS2000-S – Specifications
NetHos cabinet with high reliability/high security/high compatibility can be easily installed, also meets different customized requirements.
Key Sub-system
Cabinet
Key Sub-system – Cabinet
High reliability
High security
High compatibility
Environment friendly
•High strength & corrosion resistance to ensure the enclosure mechanical strength and corrosion resistance
•High heat dissipation capacity: overhead variable fan speed, dynamically adjusting the cooling rate through cabinet holes to maintain adequate ventilation air ratio
•Special antistatic wrist design
•Comprehensive ground protection
•Supports Huawei IT equipment installation
•complies with 3rd 19 inchIT equipment installation standards
•Complies with RoHS requirements
•Complies with IEC60297-2 requirements
Huawei power distribution system of small modular data center with flexible configuration / high performance design / high reliable etc. can be easily deployed in different customized scenarios.
Various UPS capacity available
UPS type Standard 19-inch rack
UPS capacity 3KVA 6KVA 10KVA
UPS efficiency >93.5%
Output power factor 0.7 0.9 0.9
Input power factor 0.99 0.99 0.99
Flexible configuration
•Various backup time are available to meet customized requirements
•Flexible UPS configuration to meet different application scenarios
High performance
design
•Complies with EN 62040- & EN 62040-2 standards, CB and CE certified
•High input co-efficiency: PFC control technology to improve electricity utilization
High reliability
•Manual bypass to support on line maintenance
•C class level lighting protection to improve system reliability
Key Sub-system – Power Distribution System
Key Sub-system
Power Distribution System
Small DC monitor’s the cabinet’s microenvironment such as power distribution, battery, cooling, etc. It supports remote access via the Web interface, SMS notification via the GPRS module and near-end & far-end maintenance via the alarm function.
Key Sub-system – Monitoring system
Key Sub-system
Monitoring system
Smoke sensor (In cabinet)
Smokesensor (In room)
(option) SPD
(option)
Door status sensor Video
alarm
Water sensor (option)
Air inlet temperature and humidity
sensor
Fans (option) UPS
Camera
Web access (local or remote)
Collector (ECC500)
-48 V DC power adapter
LAN
Key Sub-system
Monitoring system
Monitoring system – Features
SMS notification for
Maintenance
User Friendly Operator Interface Supports
Micro environment management
Standard Interfaces of
Monitoring System supports
•Fault alarm SMS notification to achieve unattached for reducing maintenance cost
•Local & remote web interface operations
•15 users rights and hierarchical management
•Multi-user concurrent access
•Complete cabinet environment management supported by water sensor/smoke sensor/door switch/temp & humidity sensor, improves reliability.
•Supports Free Cooling and local & remote management of UPS
•Global Unified access management
•North SNMP/BIN access to connect with NetEco
Huawei IDS2000-s series small modular data center solutions have been successfully applied in Netherlands; China Branch Bank; Venezuela WORKSHOW; Chile – CODELCO; German Telecommunications show; India-NXTGEN etc. more than 10 projects.
Success Stories
Venezuela WORKSHOW
Netherlands
Branch China Bank
Chile
- CODELCO
•More than 10-year data center service experiences, Mora than 30 global main stream partners about data center, serving top-level customers
Success Stories
India - NXTGEN
German Telecommunications show
Tanzania police station
Singapore Metallurgical Group
Wuhan
Huawei Office
