Huawei Oceanstor
TM
Storage Product Portfolio
SSD Storage
• 1-2 controller • 2-4GB Cache
• Up to 12 x 1Gbit/s iSCSI ports onboard • 1-2x I/O modules (each module 4x 8Gbps FC ports) • SAS/NL SAS/SATA
• 132 drives
High Availability
•
100% redundancy
•
Integrated UPS and Data Coffer
High Performance
•
SmartCache SSD acceleration
•
Proven SSD technology inside
•
Validated Performance by Industry
Benchmark
Efficiency
•
Green technologies
•
Unified management (ISM) cross entire
systems
Intelligent Software
•
Dynamic Multi-Pathing(DMP)
•
Dynamic Storage Tiering(DST)
•
SmartCache/SmartTiering/HyperImage/
HyperClone/ HyperMirror/Hyper-Thin
Simple SW License Model
•
One-off licensing
Chassis
BBU module
Fan module
Power supply
module
Control module
I/O modules
Dorado5100
• Up to 12 I/O modules ( each module 4X 8Gbps FC port) • SLC/eMLC SSD • Up to 1,000,000 IOPS • Up to 4x 9.6TB Capacity
Dorado2100
• 8 x 8Gbps FC ports onboard • 2 I/O modules (4x 8Gbps FC) • SLC/eMLC SSD • Up to 200,000 IOPS • Up to 9.6TB CapacityN8300
• 2-6 active-active clustered NAS engine • Multi-protocol support • SSD/SAS/SATA/NL SAS • Supports up to 7PBN8500
• 2-16 active-active clustered NAS engine • Multi-protocol support • SSD/SAS/SATA/NL SAS • Supports up to 15PBS5600T/ S5800T/ S6800T
• 24-192GB Cache • Up to 10-12x I/O modules • SAS/NL SAS/SATA/SSD • 576-1440 drives •8- 32GB Cache •8 x 8Gbps FC ports onboard•2x I/O modules (each module 4X 8Gbps FC/2X10GE ports)
• 8-16GB Cache
• 12 x 1Gbit/s iSCSI ports onboard
• 2x I/O modules (each module 4x 8Gbps FC/4x 1Gbit/s iSCSI/2x 10GE iSCSI ports)
OceanStor S2200T/S2600T
– SAN Storage Solutions for SMB
Huawei OceanStor S2200T/S2600T is a brand new storage product designed for
entry-level storage applications in enterprises. It provides industry-leading hardware
specifications and incorporates a rich set of advanced features and technologies,
including miscellaneous interface integration, flexible networking and hot swapping
(TurboModule), three-layer performance acceleration (TurboBoost), and multi-level
data protection.
• Industry-Leading Hardware Specifications:
64-bit multi-core processors, 8GB FC /10GE Front-end port ,SAS 2.0 wide-port rear-end port
• Multiple Supported Disk Types:
SAS, NL SAS, SATA, and SSD disks.
• Customizable Performance Acceleration:
SmartCache technology , SSD-based RAID groups.
• Integrated Data Protection:
HyperImage , HostAgent , HyperClone , HyperCopy and HyperMirror.
OceanStor S2200T
Scenario
Description
Centralized storage Storage system for database and mail applications for SMBs Data backup Backup medium
Video surveillance Back-end storage
OceanStor S2600T
Technical Specifications
Model
S2200T
S2600T
Hardware Specifications
Storage processor Multi-core processors Several Multi-core processors Cache capacity For a single controller: 2 GB, For dual controllers: 4 GB 8GB/16GB
Number of controllers Single controller or Dual controllers 2
Front-end port types 8 Gbps FC or 1 Gbps iSCSI 8Gbit/s FC, GE/10GE (iSCSI) Back-end port types SAS 2.0 wide port SAS 2.0 wide port Host connectivity For a single controller: 6x1 Gbps iSCSI port,
12 x 1 Gbit/s iSCSI port or 12 x 1 Gbit/s iSCSI port + 8 x 8 Gbit/s FC port/4X 10GE port
Maximum supported number of disk 132 204
Supported disk types SAS, NL SAS, SATA SAS, NL SAS, SATA, SSD
Software Features
Supported RAID levels 0, 1, 3, 5, 6, 10, 50 0, 1, 3, 5, 6, 10, 50
Maximum number of snapshots 256 256
Maximum number of LUNs 512 512
TurboModule Supported. Yes
Functional software
HyperImage(Snapshot), HyperCopy(LUN Copy), HyperMirror/S(Synchronous data remote replication), HyperMirror/ A(Asynchronous data remote replication), UltraPath(Multi-pathing Software) HyperImage, HyperCopy, HyperClone, HyperMirror,HyperThin, UltraPath, DiskGuard, SmartCache
Supported operating systems AIX, HP-UX, Solaris, Linux, Windows AIX, HP-UX, Solaris, Linux, Windows, VMware
Physical Specifications
Power supply AC: 100 V~127 V or 200 V~240 VDC: –48 V~ –60 V AC: 100V~127V or 200V~ 240VDC: –48V~ –60V
Power consumption
2U controller enclosure (fully configured with 600 GB SAS disks) ≤ 365W 4U disk enclosure (fully configured with 600 GB SAS disks) ≤ 441W
OceanStor S5000T Series& S6800T
– Enterprise-class SAN Storage Solution
S5600T S5800T S6800T
Huawei OceanStor T series is a new generation of mid-range and high-end storage
systems. Based on its industry leading hardware specification, T series integrates the
Advanced technologies of high-density disk design, TurboModule(high-density and
hot swappable I/O modules), and TurboBoost( three-level performance boost), and
multi-level data protection, satisfying the application requirement of large OLTP/OLAP
database, high-performance computing, digital media, Internet operation, centralized
storage, backup, disaster recovery and data migration.
• Flexibility :
Up to 12 hot swappable I/O modules, flexible networking according to various
applications.
• High Performance and Scalability :
8Gb FC, 6Gb SAS2.0, PCI-E2.0, 10Gb/s Ethernet I/O
channels, new generation 64bit multi-core CPU; SSD acceleration technologies; up to 1440
disks and 192GB cache.
• High Availability :
Bad sector repair, disk pre-copy technology reduce disk failure and data loss.
• Easy to Manage :
Unified management using ISM, only 5 steps are needed for initial
configuration.
• Green Technologies :
Disk spin-down, Intelligent 16-step fan speed tuning technology,
Intelligent CPU speed adjusting.
Model
S5500T
S5600T
S5800T
S6800T
Hardware Specifications
Storage processor Multi-core processors
Cache capacity 8 GB/16 GB/32 GB 24 GB/48 GB 48 GB/96 GB 48 GB/96 GB/192 GB
Number of controllers 2 2 2 2
Front-end port types 8 Gb FC, GE/10GE (iSCSI) 8 Gb FC, GE/10GE (iSCSI) 8 Gb FC, GE/10GE (iSCSI) 8 Gb FC, GE/10GE (iSCSI) Back-end port types 6 Gb SAS 2.0 wide ports 4 Gb FC, 6 Gb SAS 2.0 wide
ports 4 Gb FC, 6 Gb SAS 2.0 wide ports 4 Gb FC, 6 Gb SAS 2.0 wide ports Number of onboard I/ O ports 8*8 Gb FC ports (front-end) and 4*SAS 2.0 wide ports (back-end)
None None None
Maximum number of
I/O modules 2 10 12 12
Maximum number of
disk slots 288 576 1152 1440
Supported disk types SAS, NL SAS, SATA, SSD FC, SAS, NL SAS, SATA, SSD FC, SAS, NL SAS, SATA, SSD
Software Feature RAID levels 0, 1, 3, 5, 6, 10, 50 0, 1, 3, 5, 6, 10, 50 0, 1, 3, 5, 6, 10, 50 0, 1, 3, 5, 6, 10, 50 Maximum number of hosts 512 1024 1024 1024 Maximum number of snapshots 1024 2048 2048 2048
Application Scenarios
Description
Centralized storage Scalable storage system for database, mail, media, file sharing applications etc. Disaster recovery Disaster recovery solution for DC/IDC or enterprise
Video surveillance Back-end storage for video surveillance solution
OceanStor N8000
– Clustered NAS Storage Solution
Application Scenarios
Description
Media and entertainment industry application
Centralized storage for TV stations, Postproduction, Animation, backup and archiving etc.
File service Mass small files storage for NSP
High performance computing High performance storage system for research and design institutes
Unified storage Convergence of NAS and SAN for Database, mail, file, media applications etc.
Huawei OceanStor N8000 clustered NAS storage
system is a leading unified storage platform
designed for medium -range and high-end
storage application. N8000 features advanced
architecture ,robust reliability , superb scalability,
high performance and easy management. It
meets the needs of telecom operators, digital
media, high-performance computing, government
entities and educational and scientific research
industries for high performance, high expansion,
effective data management and unified storage.
• Industry Leading Performance:
Ranked among
top in SPECsfs2008 benchmark; delivers linear
performance improvement as the NAS engine
increases
• Unified Storage:
Convergence of SAN and NAS. Clustered architecture design supports
online expansion of capacity up to 15PB on demand
• Efficient:
Dynamic Storage Tiering (Policy-based data migration reduces the initial
investment costs) and de-duplication
• Rich File-level/Block-level Data Protection:
Snapshot, Mirror and remote replication
• Symantec NetBackup Client Built-in:
Symantec NetBackup Client built in NAS Nodes
Oceanstor N8300 Oceanstor N8500
Model
N8300
N8500
Hardware SpecificationsSystem architecture Multi-node Active-Active cluster architecture
Number of nodes 2 ~ 6 2 ~16
Cache/node Standard Version: 16GB,up to 24GBEnterprise Version: 16GB,up to 32GB,48GB Basic Version: 16GB; Standard Version: 24GBEnterprise Version: 48GB; Enhanced Version: 96GB
GE ports/node Standard configuration: 4 x GE, up to 12 x GE Standard configuration: 4 x GE, up to 16 x GE
10 GE ports/node Up to 2 x 10 GE Up to 2 x 10 GE
Disk type SSD,FC,SAS,SATA,NL SAS
Physical storage capacity Dynamically expansible, up to 7 PB Dynamically expansible, up to 15 PB
Supported Protocols
Storage network protocols FC, iSCSI, NFS, CIFS, FTP, HTTP
Access control NIS, Microsoft Active Directory, LDAP
Other protocols NDMP, SNMP, NTP
Software Specifications
RAID level RAID 0,1,3,5,6,10,50
File system size Dynamically expansible, up to 256 TB
Value-added functions
DST(dynamic storage tiering),De-duplication,Snapshot,Mirror,Quota,Replication, SmartCache (dynamic data cache technology), embedded Symantec NetBackup Client, HyperThin(thin provisioning),HyperImage (snapshot), HyperCopy (LUN copy), HyperClone (split mirror),HyperMirror (synchronous/asynchronous remote replication)
Quota NFS/CIFS soft/hard quota management
Maximum number of snapshots 512 (each file system)
Management mode GUI, CLI
Supported operating systems Windows, Linux, Mac OS, Solaris, AIX, and HP-UX
Fault alarm modes E-mail, SNMP, Syslog
Physical Specifications
Power AC: 100V ~ 127V/200V ~ 240V AC: 100V ~ 127V/200V ~ 240V
Power consumption
Engine ≤ 870 W (single node) ≤ 830 W (dual-node cluster)
Storage unit Controller enclosure: ≤ 830 W; Disk enclosure: ≤ 550 W
Dimensions
Engine 2U,86.4mm(H) % 482.4mm(W) % 720.6mm(D) (single node) 4U,175mm(H) % 446mm(W) % 502mm(D)(dual-node cluster)
Storage unit
2U, Controller enclosure: 86.1mm(H) % 446mm(W) % 582mm(D); 4U, Controller enclosure: 175mm(H) % 446mm(W) % 502mm(D); 2U, Disk enclosure: 86.1mm(H) % 446mm(W) % 412mm(D); 4U, Disk enclosure: 175mm(H) % 446mm(W) % 412mm(D)
Cabinet 42U, 205cm(H) % 57.5cm(W) % 118cm(D)
Weight
Engine Clustered NAS engine: ≤ 26 kg/node Dual-node clustered NAS engine: ≤ 43.6 kg
Storageunit
(in full 2U, Controller enclosure ≤29.9Kg/enclosure; 4U, Controller enclosure ≤43.6Kg/enclosure2U, Disk enclosure ≤26.5Kg/ enclosure; 4U,Disk enclosure ≤42.64Kg/enclosure
OceanStor Dorado2100
– Full SSD Storage Solution for High
Performance Application
Oceanstor Dorado2100
Huawei OceanStor Dorado2100 is an FC SAN solid state storage array for the
enterprise-class high performance market. The Dorado2100 relies entirely on
solid-state storage technology, and features advanced cache management and an advanced
I/O scheduling algorithm to deliver unsurpassed performance. It increases application
memory requirements for querying and searching large databases, as well as for
processor-intense calculations and image editing.
• High Performance:
Full SSD architecture, delivers up to 100,000 IOPS (SPC-1), and low access latency( 600 μs)
• SLC/eMLC Flash Technology:
Both SLC and eMLC supported, up to 9.6 TB capacity
• Energy Efficient:
Save energy by up to 90% compared to traditional storage, intelligent fan speed control and
intelligent CPU clock speed control
• High Availability:
Dual controller architecture, multiple media protection mechanism and data protection
mechanism ensures data safety
• Low TCO:
Save the cabinet space and reduce management cost
Model
Dorado2100
Hardware Features
Front-end port type 8Gbps FC
Back-end port type 6Gbps SAS 2.0 wide ports Number of onboard I/O ports 8 x 8Gbps FC Maximum number of expansion
I/O modules 2
Number of expansion I/O module
ports 4 x 8Gbps FC
Supported Capacity SLC:1.2TB/2.4TB/4.8TB eMLC:4.8TB/9.6TB
Performance Maximum bandwidth 5.6GB/s Maximum IOPS 200,000 SPC-1 IOPS™ 100,051.99 Access latency 600μs Software Features RAID support 0, 1, 3, 5, 6, 10, 50 Number of hosts supported 512
Number of LUNs supported 2,048 Multipath software UltraPath
Physical Specifications
Power AC:100V ~ 127V or 200V ~ 240V
Typical power consumption SLC:350W eMLC:410W Dimensions (H%W% D) 2U, 86.1mm%582mm%446mm
Weight ≤27.5kg
Operating temperature When the altitude is lower than 1800m: 5°C ~ 40°CWhen the altitude is 1800m ~ 3000m: 5°C ~ 30°C
Technical Specifications
Application Scenarios
Description
Database application acceleration High-performance SSDs for high IOPS and low latency High performance computing (HPC) High performance storage system for research and design institutes
OceanStor Dorado5100
– Full SSD Storage Solution for High
Performance Application
Oceanstor Dorado5100
Huawei OceanStor Dorado5100 is an FC-SAN solid-state storage array for the
enterprise-class high performance storage market. The Dorado5100 can meet the
requirements of various applications such as large-scale database, high-performance
computing, and VDI for highly reliable and high-performance storage.
• Outstanding Performance:
1,000,000 IOPS — a performance equal to traditional arrays with 1400 15K RPM SAS disks;
Access latency is as low as 500 us.
• Energy Savings:
As low as 160 W, energy savings up to 90% over traditional arrays with equivalent
performance.
Model
Dorado5100
Hardware Features
Front-end port type 8Gbps FC
Back-end port type 6Gbps SAS 2.0 wide ports Maximum number of expansion
I/O modules 12
Disk enclosure type SLC: 2.4 -4.8TB/enclosureeMLC: 4.8 -9.6TB/enclosure Max. number of disk enclosures 4
Performance Max. bandwidth 12GB/s Max. IOPS 1,000,000 Access latency 500μs Software Features RAID support 0, 1, 5, 10
Number of hosts supported 1024 Number of LUNs supported 2,048 Multipathing software UltraPath
Physical Specifications
Power AC: 100V ~ 127V or 200V ~ 240V
Operating temperature When the altitude is lower than 1800m: 5°C ~ 40°CWhen the altitude is1800m ~ 3000m: 5°C ~ 30°C Operating humidity 5% ~ 90% R.H
Dimensions (H%W%D) Controller enclosure: 175mm%446mm%502mmDisk enclosure: 86.1mm%446mm%412mm
Application Scenarios
Description
Database application acceleration High-performance SSDs for high IOPS and low latency High performance computing (HPC) High performance storage system for research and design institutes
Video editing and processing Powerful I/O processing capability and short latency for video editing system Storage tiering Act as the primary tier
ISM- Integrated Storage Manager
– Software that Manages all Huawei Storage
Software suite:
• ISM device management software
• ISM cloud storage management software
• ISM storage network management software
• ISM disaster recovery management software
Unified Management
• Support up to 512 management nodes of
all Huawei storage devices
Flexibility
• Alarm export
• Log query
Easy Management
• Support SMI-S,SNMP Protocol
• One-click upgrade through JWS (Java
Web Start)
Features
Types of storage equipment S2200T/S2600T/S5500T/S5600T/S5800T/S6800T/N8300/N8500/Dorado2100/Dorado5100 Max. number of management
nodes 512
Equipment discovery Discovery by IP address, IP address segment, or subnet
Performance statistics Live performance statistics of host ports, logical LUNs, and links
Disk information collection Disk health analysis (DHA); export and remote transfer of the analysis result
Topology view Level-specific and layer-specific topology by subnet or geographical location
User authentication Permission-specific management Different users' concurrent login
Storage resource management Query and statistics of OceanStor storage arrays
Ethernet switch management Monitoring of Ethernet switches' ports
Host management Query of basic host information
Event alarming
Dynamic display of current events; automatic matching for recovered faults; deletion, filtering, and statistics of events Event alarming through SMS or email
Automatic dumping of alarm information in 90 day
Central Management
One management platform
Efficient Data Services
Virtual provisioning, file de-duplication and compression, file replication
Optimized for Virtulization Application
VAAI and Hper-V integration
Software solution
One-off licensing
Performance
New multi-core Intel CPUs and 6 Gb/s NL backend SAS
Easy Upgrade
Start with file or block and unification-based upgrade
High Availability
99.9999% availability
Unified Platform
One platform for files, blocks and objects
Software features
Software feature
Description
HyperImage Snapshot
HyperCopy Copy all the data on the source LUN to the target LUN
HyperClone Create a complete point-in-time LUN copy
HyperMirror Remote copy of LUNs across disk arrays by synchronous or asynchronous mode
HyperThin Extend storage capacity automatically and increase disk usage, allowing storage
purchase on demand and maximize the return on investment (ROI)
UltraPath Multi-pathing management
SmartCache Read performance acceleration using SSDs as a cache pool
Dynamic LUN Expansion Increase the LUN capacity online. This function is not restricted by the RAID group
Dynamic RAID Expansion Online RAID group expansion
DiskGuard Disk protection in Windows environment
VAAI Integration Transfer I/O operations processed on VMware ESX servers to the disk array, saving
virtual machine resources and improving the virtual machine performance
