Creating Your Dream Home

F

or over 50 years, Thermal Industries’ roots have been in the design and manufacture of energy-conserving window and patio door products. Our philosophy is simple: provide our customers with energy-efficient, maintenance-free products that help lower their energy bills. From our environmentally sensitive manu-facturing processes to our recycled content, our goal is to produce high-performance products that meet or exceed current energy-efficiency standards. The result? You get exactly what you need in your windows — and so does the environment.

The Replacement Window Pioneers...

Thermal Industries, Inc.

1960

1970

Industry’s First Vinyl Storm Window

Circa 1962

Dual-Glazed, Tilting Insulating Glass Custom Vinyl Replacement Window

Industry’s First Custom Vinyl Replacement Window

Thermal Industries proudly manufactures our window and door products here in the U.S., creating jobs for thousands of American workers. Unlike other window manufacturers, our vinyl extrusion and glass components are 100% made in the USA!

Over 50 Years of Innovation...

1970

1980

1990

2000

2010

Dual-Glazed, Tilting Insulating Glass Custom Vinyl Replacement Window

Industry’s First Custom

Bow & Bay Window Custom Garden Window Legance Sliding Glass Patio Door DreamWood and Vinyl Window®Wood Custom

DreamGlas®System Crystal Achievement Award

Charter Member

DOE R-5 Window Program Vendor

Industry’s First Custom Casement Window with Fusion-Welded Frame and Sash

Industry’s First Custom

V-Bow Window DreamspacE® 3000 Enclosure System Natural WoodGrain Crystal Achievement Award

...helping to create

your Dream® Home.

Double Hung Windows

H

omeowners like you have many reasons for choosing replacement windows for their home: low maintenance, lighting, ventilation and decorative flair. However, a window’s function does not end there. Well-designed windows provide warmth during winter’s chilly days and keep your home cool during summer’s intense heat.

Thermal Industries’ Double Hung vinyl windows are available in a variety of styles — with options to fit every budget. Standard features, including precision engineered frames and sashes, provide added insulation. Optional high-performance, insulating glass packages, designed specifically for your climate, provide increased R-Values, improving the comfort of your home, while saving you money on heating and cooling bills. They are also better for the environment because lowering your energy use means less air pollution from power plants. Additionally, our windows and doors are backed by one of the industry’s strongest lifetime warranties.

Double Hung Features

Photo left: Double Hung Windows with the following options: Honey Oak Finish, Brass Hardware, and Ice Border DreamGlas® panels.

Paint or stain our Dream®Wood Double Hung Windows to complement your home’s interior woodwork and decor.

Cross-section view of a Thermal Industries Double Hung window model.

Top and bottom sashes on all Thermal Industries’ double hung windows tilt into the home for easy and safer cleaning.

0.0 0.2 0.4 0.6 0.8 1.0 1.2

Parallel I-Beam Construction

Provides increased strength, durability and structural integrity. Fully Welded, Weeped and Sloped Weather-Trac Sill

A weather-inhibiting pocket that significantly improves water drainage and air infiltration ratings; 300% stronger than the average cut and notch style window. Thermal Weight Management System with Draft Sentry

Assures a lifetime of easy operation.

5

Equal Sash Sight Lines with Beaded Cove-Cut Glazing Aesthetically pleasing picture frame design.

Safety Night Latches For carefree ventilation Locking Zinc Tilt Pins

Sliding Windows

E

njoy an expansive view of the outdoors with a horizontal sliding window from Thermal Industries. Mounted on brass wheels, each panel glides easily along its raised track, enabling you to effortlessly open your window and enjoy fresh air.

Little details that

make your life easier.

Photo left: Two-Section, White Sliding Window.

Accu-Track System with Dual Weather Loc Finseal Weather-Stripping Virtually eliminates air and water infiltration.

Monorail Track System Provides easy sash operation. Double Wall Sash Slide Rails Full height rails assure easy sash operation.

Full Vinyl Interlock For security and elimination of air infiltration at meeting rail.

Sliding Window Features

Multiple Brass Roller Wheels

Self-aligning tandem rollers reduce friction and operating force when opening/closing sashes. Exclusive Removable Vinyl

Track Liners for easy cleaning.

Two-Section, Earthtone Sliding Windows.

Three-Section, Earthtone Sliding Window.

Our sliding windows glide smoothly along their monorail track system.

Casement and

Awning Windows

S

earching for a sleek, classic look to accentuate the architecture of your home? Thermal Industries makes it happen with our Casement windows.

Our Casement style provides superior protection against the extremes of wind and cold with dual protective exterior Q-Lon seals and interior weather- stripping. Concealed hinge hardware — engineered to provide smooth and virtually effortless sash operation — enables your window to open past 90* degrees for easy cleaning and maximum ventilation.

For added security, our casements feature a multi-point locking system. Stylish folding handles provide extra room for today’s win-dow treatments. Add one of our optional high-performance glass packages to maxi-mize your home’s energy savings.

Superior protection

against the elements.

Hardware Finishes

Brass Brushed Nickel

Photo left: Earthtone Casement Windows.

Awning replacement windows are a top-hinged window system that swing out-ward to offer maximum ventilation even on rainy days.

Dual Protective Color-Coordinated Exterior Q-Lon Seal with Interior Weather-Stripping Virtually eliminates air and water infiltration. Corrosion Resistant E-Gard® Hardware

Encore Nested Folding Handle MaximTM Multi-Point Locking System

Security and peace of mind.

Awning Windows feature MaximTM Single

Point Locks and Keepers along with E-Z Clean Release Latches.

Exterior view of Earthtone Awning Windows with optional DreamGlas.®

Casement Window Features

Hardware Finishes

Unique Integral Mullion System Flush-Mount Fiberglass Screen

Bay and Bow Windows

A

dd a beautiful focal point to your home with a custom-sized Bay or Bow Window from Thermal Industries. Run your fingers over the smooth, hand-sanded furniture-grade finish of either birch or optional oak veneer. Choose casement or double hung vents to enhance the appeal of your home. Expand your decorating horizons even further with custom shingled or metal — hip or shed — style roofs. You can also select from a variety of bracing options.

Bring a richness to

your home no other

window can match.

Four-section White Bow Window.

1-1/4” Exterior Grade Hardwood Header and Seat with Birch Veneer Interior

Complimentary Colonial-Style Casing Hand-Sanded 1-1/4” Birch Veneer Surround; Optional High-Grade 1-1/4” Oak Veneer Surround also available.

Corrosion-Resistant Hardware Over-the-Edge Exterior Design Custom Depths Available

Custom Hip or Shed Roofs (Shingle or Metal) Pre-Finished Wood Option Package

Integral, Hidden Cable Supports (Optional)

External Aluminum Knee Brace Supports (Optional) Sill Muffler for increased thermal efficiency (Optional) Box Bay or V-Bow configurations

While other bay and bow windows allow water, dust and grime to collect on the outside sill, Thermal Industries’ maintenance-free, exclusive Over-The-Edge Design keeps your exterior surfaces cleaner. For even greater insulating value, optional

Sill Mufflers are available. Comfort, energy savings and style are built into every Thermal Industries’ Bay and Bow Window.

Bay and Bow Window Features

Five-Section White Bow Window with soffit roof.

Matching Earthtone Bay Windows featuring Colonial grids and Coppertone, standing seam metal hip roofs.

Note: Use of a Thermal Industries bracing system is required on all Bay and Bow Windows for warranty purposes.

Honey and Caramel Oak Bay and Bow Windows are available with the convenient pre-finished option package. The seat, sides, header wood and 3-1/2 inch Oak Wood Casing are stained to match either the Honey Oak or Caramel Oak Windows.

L

et the sun shine all year round with a beautiful Garden Window from Thermal Industries. Our beautiful Garden Windows allow an abundance of light to shine through the window’s contempo-rary, trapezoid-shaped Casement vents. Add an optional acrylic shelf to your Garden Window and dazzle family and friends with exotic plants blooming in the middle of winter. You will feel like you are on a tropical vacation every day gazing through your Thermal Industries Garden Window!

Garden Windows

Garden Window Features

Dual Trapezoid-Shaped Casement Vents Sanded 1-1/4” Birch Veneer Surround Colonial Pine Casing

MaximTM _{Multi-Point Locking System}

Security and peace of mind.

Encore Nested Folding Handle Corrosion-Resistant Hardware Wood Knee Brace Supports

Safety Laminated Glass Roof

Add light and space to your

home with a Garden Window.

Specialty Shapes

Basement Windows

Thermal Industries offers a wide variety of picture windows and specialty-shaped vinyl replacement windows. Our designs look unique as stand-alone windows. Or, they can be combined with other window styles in multi-window configurations, adding a decorative accent or enhancing your home’s architecture. Select from full-circle windows, quarter arch windows, and parallelogram-shaped windows — just to name a few.

Basement windows — also called hopper windows — are vinyl replace-ment windows that are bottom-hinged and open inward for ventilation. For added safety and security, consider replacing low-to-the-ground windows with our basement windows featuring

T

he LeganceTM _{Patio Door offers} homeowners strength and energy efficiency for the largest opening in their home. The fully-welded construction, aluminum and steel reinforcement and security wedge interlock provide a tight seal between the panels, keeping the outside elements at bay. The exclusive, pocketed Monorail Track Design enables smooth, easy operation. In addition, the top-hung screen provides ease of operation with minimal maintenance.

Designed and

detailed for lasting

performance.

Monorail Track Design enables your door to glide smoothly. Heavy duty hanging screen with Accu-Track Anti-Racking System.

Legance

TM

Patio Door

Standard Dual-Point Grappling Hook Lock increases security by drawing the sash tight to the frame. Shown with optional Brushed Nickel hardware.

Recessed Security Bolt is conveniently mounted on the trailing edge of the operating sash, enhancing the security of your patio door. Available in Brass or Brushed Nickel. j k l m j Security is a definite priority in the design of the

LeganceTM _{Patio Door. A dual-point keyed lock and} a mounted, recessed security bolt on the trailing edge of the operating panel are standard features on our door. To further enhance security, multi-point locks may be added (Brass handle only).

Fully-Welded Construction for rigid, long lasting performance Grooved Aluminum Walking Plate provides an area to scrape off dirt and soil, keeping your home cleaner

External Key Lock

13/16” Dual Glaze Tempered Insulating Glass featuring Warm-Edge Technology

j k l m

Superior Wedging Interlock for increased security and reduced weather infiltration

5’, 6’ and 8’ two-panel configurations; 9’ and 12’ three-panel configurations NFRC certified and tested to AAMA’s strict standards

Legance Patio Door Features

Brass

(Option) Brushed Nickel (Option) (Standard with Honey Oak Mocha and Caramel Oak WoodGrain Finishes)

Handle Set Finishes Pet Screen

Legance Patio Door featuring Sunshine Border DreamGlas. Legance Patio Door with glass transom. Optional between-the-glass Mini Blinds raise, lower and tilt effortlessly. Cross-section view of Legance Patio Door.

Options | Color and WoodGrain Finishes

White Interior/Exterior (Standard) White Paintable/Stainable (Option) Dream®Wood** Brown Exterior/ White Interior (Option) Safari Brown* Earthtone Earthtone Interior/Exterior (Option) Earthtone Earthtone Earthtone WoodGrain Finish (Option) Paintable/Stainable

(Option) WoodGrain Finish (Option)

Natural WoodGrain

Oak** Honey Oak Caramel Oak

American Clay

Green Brick Red Safari Brown*

Terratone Gray

NOTE: PRINTED COLORS MAY VARY FROM ACTUAL PRODUCT.

*The availability of the “Brown” color option varies by window and door style and may be manufactured as an extruded vinyl, laminate or painted exterior finish. Color may vary according to finish type. Ask your sales representative for details.

NOTE: The availability of dark color options may vary by region. Ask your sales representative for details.

**The DreamWood and Natural WoodGrain Oak finish options must have the exterior surface painted if Earthtone or Brown colors are desired. Additional charges apply. The Honey and Caramel Oak finish options must have the exterior surface painted if the Brown color is desired. Additional charges apply.

WoodGrain Interiors

If you prefer the rich look and texture of natural wood, consider the DreamWood or Natural WoodGrain interior options. Both WoodGrain laminates give you complete flexibility. You can paint to achieve the interior color of choice, stain to complement existing wood trim, or maintain its natural look by simply applying a protective coat-ing. Want a stained wood look without the work? Choose from our Honey Oak and Caramel Oak WoodGrain Finishes.

Painted Exterior Finishes

Coordinate your windows to the distinct architecture of your home with our painted exterior finishes. This environmentally friendly water-based paint system provides years of performance — due to its high scratch resistance, superior hardness and excellent color retention. Available with matching Internal Grids for White, Earthtone, Honey and Caramel Oak Interiors. Brushed Nickel Locking Door Handles are stan-dard on painted doors.

Vinyl Colors

All Thermal Industries Vinyl Replacement Windows are available in White (standard) and optional Earthtone colors. Select window models are available in an optional Vycap Safari Brown or Brown Laminate exterior color.

Options | Decorative Grids

Decorative Grids

Choose from a wide variety of decorative grid patterns to enhance the architecture of your home. Our grids are sealed between the panes of glass within the insulating glass units, making them maintenance-free. Select from Colonial, Prairie and Circle Sash styles.

17

Brass Pencil Grid

Contour Narrow Grid

Colonial Style Prairie Style Circle Sash Grid Design

DreamGlas® panels capture the distinct textured look of stained glass in an insulating glass unit. Unlike most available decorative glass, DreamGlas® panels are pro-duced using a unique application process that does not require a third pane of glass. The variety of available patterns and colors enable homeowners to create their own unique look and style. Choose from a selection of beautiful Jewel Cut, Etched, Colored and Camed designs.

DreamGlas® Gallery Collection

White Bay Window with Casement vents featuring Ice Diamonds DreamGlas®. Right: Flanker Set Window with Casement vents featuring Crystal Arrows DreamGlas panels and Jewel Cut Colonial Grids in the center lite. The Circle Top Window features a Jewel Cut Sunburst panel.

Earthtone Bow Window with Casements and Deadlites featuring Gentle Blossom

Jewel Cut Glass

A V-shaped path cut precisely into the glass surface, Jewel Cut is available polished or unpolished. When polished, the cut path is exposed to the inside living surface of the window and refracts light into brilliant colors. Unpolished designs appear frosted or opaque and the jewel cut path remains protected between the glass.

Or, choose from one of our Frostline Cut patterns, which are a combination of an unpolished ground surface flanked on both sides with Jewel Cut grooves. The Frostline Cut is located on the inside surface between the glass lites, and is available in select designs. All of these designs will accent and enhance the beauty of your home.

Florentine Infinity Galaxy

Jewel Gothic

Floral Spray

Sunburst* Starburst* Double Prairie Camelot

Lancelot

Queen’s Arch*

King Arthur

Colonial *Note: All patterns are _{available in Jewel Cut} polished or unpolished. Select patterns are available in Frostline Cut.

Galaxy Pattern

Diamond Pattern Center Accent Patterns available in Jewel Cut only.

Prairie Spring Flower Prism

Free Spirit Rosevine

High-Performance Glass...Which is best for your home?

Windows provide many great benefits, but did you know they can also account for up to 30% of the annual energy consumed in a home? Glass makes up almost 80% of a window and largely dictates how that window will perform. So, it’s important to choose the right glass package when replacing windows in your home.

Low-E Glass allows natural light to freely enter your home as shown in the diagram below. During winter months, long wave heat energy radiating from indoor objects is reflected back into the house, keeping your home warm while lowering heating costs.

In the summer, outdoor long-wave heat energy radiating from objects, is reflected back outside, lowering cooling costs. It also reduces the harmful effects of ultra-violet rays by minimizing fading of your carpet and draperies.

Low-E Glass Coatings

How They Work

Warm-Edge Spacers

Insulating Gases

In winter, our insulating glass spacer systems keep

the edges of the glass warmer, dramatically reducing condensation while holding warm air in and cold air out (Diagram B). The

sealant systems flex with the glass during extreme tempera-ture swings to help prevent seal failure (Diagram C).

Insulating gases, such as Argon or Krypton, are added to the air spaces in our glass units. Both gases are denser than air and prevent the formation of convection air currents,

reducing heat transfer between the inside and outside of your home. This improves your home’s comfort while lowering your heating and cooling bills. Diagram B — Warm Edge Spacers

block heat escape paths.

Diagram C — shows the flexibility of the Super Spacer technology and sealant system used in our triple pane glass systems and how it reacts during temperature changes.

20

High-Performance Glass...Which is best for your home?

Peak Performance

TM

_{Eco Performance}

TM

_Plus

Peak Performance

TM

_LE

Peak Performance

TM

_Ultra

_{Super Peak Performance}

TM

Window Style U-Factor SHGC Casement 0.28 0.25 Double Hung 0.30 0.28 Patio Door 0.29 0.28 Slider 0.30 0.28 Window Style U-Factor SHGC Casement 0.27 0.19 Double Hung 0.30 0.20 Patio Door 0.28 0.21 Slider 0.30 0.21 Window Style U-Factor SHGC Casement 0.27 0.23 Double Hung 0.30 0.25 Patio Door 0.29 0.26 Slider 0.29 0.26 Window Style U-Factor SHGC Casement 0.22 0.21 Double Hung 0.24 0.24 Patio Door 0.25 0.24 Slider 0.24 0.24 Window Style U-Factor SHGC Casement 0.18 0.21 Double Hung 0.20 0.24 Patio Door 0.20 0.24 Slider 0.19 0.24

GOOD

BETTER

BEST

A window’s energy performance is rated by two measurements. The first performance rating is the U-Factor. U-Factor measures heat transfer through a window and tells you how well the wdow insulates. The lower the U-Factor, the better the winwdow in-sulates. For example, during cooler months, the lower a window’s overall U-Factor, the less heat you will lose through that window, and the less energy will be needed to heat your home.

NFRC Certified Test Results

The second performance rating is the Solar Heat Gain Coefficient (SHGC). This measures how much solar heat is admitted into your home through the window, and tells you how well the window blocks heat caused by sunlight. The lower the SHGC, the better the window is at blocking heat. During summer months, a lower SHGC means less solar radiation enters through your windows, keeping your home cooler, and saving you money on air conditioning costs.

Thermal Industries is committed to manufacturing the highest quality products. To back this commit-ment, Thermal Industries warrants to the original purchaser of our Replacement Windows and/or Sliding Glass Doors that these products will be free from defects in materials and workmanship under normal use and service, for as long as you own and reside in the home in which the products were installed.

Our vinyl manufacturing processes blend

environmental sensitivity with high-quality finished products. We recycle our vinyl,

glass and aluminum scrap, often selling it to companies outside our industry, such as PVC pipe manufacturers and post-industrial recyclers.

With Thermal Industries’ high-performance window technology, you have a proven solution to resist the sun’s heat in the summer

and welcome it in the winter. Energy-efficient Thermal Industries windows are engineered to accommodate almost any budget, provid-ing the highest levels of year-round comfort and energy savings, making them well-suited for virtually any climate zone.

In fact, Thermal Industries’ Super Peak Performance Glass has received the GreenSpec® Listed designa-tion by BuildingGreen, Inc., an independent company committed to providing accurate, unbiased, and timely information on building industry products. The

GreenSpec® Directory lists product descriptions for over 2,100 environmen-tally preferable products.

Why Thermal Industries Windows & Doors?

Lifetime Warranty

Green Manufacturing

Energy Efficient Products

Utilizing vinyl provides our customers products with sustainable life spans, keeping them out of landfills. Our lead-free PVC vinyl is not petroleum-based; its production requires no burning and generates no harmful gases. When it comes to environmentally sensitive manufacturing, our vinyl production methods are among the most advanced in the industry.

Thermal Industries is a participant in the National Fenestration Rating Council’s Certification Program — a uniform national rating system for energy performance of fenestration products. All Thermal Industries Window and Patio Door products are NFRC tested, certified and labeled.

Thermal Industries is proud to be an ENERGY STAR® Partner and offer our customers vinyl replace-ment windows and sliding glass patio doors with the ENERGY STAR label. ENERGY STAR is the symbol for energy efficiency.

ENERGY STAR qualified windows and doors save you energy and money, increase the comfort of your home, and protect your valuable possessions from sun damage. They are also better for the envi-ronment because lowering your energy use means less air pollution from power plants, and a cleaner, greener world for everyone.

Did you know that you can completely transform the look of your home simply by choosing different window shapes and styles when replacing your current windows? You can choose from our assort-ment of V-Bow, Flanker, Oriel and Picture Windows. To brighten a dark room, you can add a Wall of Windows to give you that great outdoors feel. Our replacement window styles can offer your home a unique new look, or accommodate any special architectural requirements your home may have. Plus, our wide variety of

options can make your new vinyl replacement windows as unique as you are.

Transform Your Home

Industry Partners

©Copyright 2012 • XL 008I • 06/12 • 18M

DreamspacE, Dream and DreamGlas are registered trademarks of Thermal Industries, Inc. Performance, Circle Sash, and Legance are trademarks of Thermal Industries, Inc. Invisi-Screen is a registered trademark of Atrium Corporation. Intercept is a registered trademark of PPG Industries. Super Spacer is a regis-tered trademark of Edgetech. The ENERGY STAR name and logo are regisregis-tered US marks and owned by the United States Government. GreenSpec is a registered trademark of BuildingGreen, Inc.

Thermal Industries, Inc. 5450 Second Avenue Pittsburgh, PA 15207 800-245-1540
