Intelligent Power Distribution

(1)

Eaton ePDU

Intelligent Power

Distribution

(2)

Managed ePDUs

Advanced Monitored ePDUs

Managed ePDUs offer data centre managers maximum

functionality and flexibility, with complete understanding

and control of data centre power distribution.

Capabilities include:

Monitoring

Highly accurate individual outlet, branch circuit, and full ePDU monitoring for V, W, A and kWhrs (1% accuracy above 2A). Also temperature and humidity monitoring in the rack via optional sensors.

Switching

Individual outlet, sequencing of outlets with delays or cycling, enables remote reboot of equipment.

Control

Monitor and control remotely over Ethernet or via Advanced LCD screen on the unit. Communication protocols include HTTP/ HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 and IPv6.

Includes Eaton’s patented flexible mounting system, which ensures ePDUs will fit in any standard 42U IT rack, Eaton Managed ePDUs provide reliable, consistent power distribution at temperatures of up to 50°C.

Advanced Monitored ePDUs give the data centre

manager the detailed accurate information and

understanding needed to run the data centre efficiently

and effectively.

Monitoring

Highly accurate individual outlet, branch circuit and full ePDU monitoring for V, W, A and kWhrs (1% accuracy above 2A). Also temperature and humidity monitoring in the rack via optional sensors.

Control

Monitor and measure key properties and alerts remotely over Ethernet or via Advanced LCD screen on the unit. Communication protocols include HTTP/HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 and IPv6.

Includes Eaton’s patented flexible mounting system, which ensures ePDUs will fit in any standard 42U IT rack, Eaton Advanced Monitored ePDUs provide reliable, consistent power distribution at temperatures of up to 50°C.

(3)

Outlet number identifications are color coded to match the outlet section to the appropriate circuit breaker

.

Advanced LCD Display*

This new advanced LCD display provides outlet and section current information, voltage and kilowatt-hour readings, all at a single glance. The display is accompanied with a three-button interface that allows you to navigate through the user-friendly menu structure. Dual-color display blinks when a system alarm is detected, providing local notification.

Environmental Monitoring*

You can utilise the Environmental Monitoring Probe to track internal and external temperatures, humidity and contact closure. This information allows you to operate the ePDU up to 50°C, in turn reducing cooling costs. (Part number EMP001).

Switched ePDUs

Switched ePDUs give control to the data centre manager.

They provide the ability to remotely shut off or restart

equipment ensuring that it starts up in the correct

sequence with the correct delays – together with overall

monitoring for load balancing.

Monitoring

Highly accurate monitoring of the ePDU as a whole for V, W, A and kWhr (1% accuracy above 2A). Also temperature and humidity monitoring in the rack via optional sensors. Monitor over Ethernet or via Advanced LCD screen on the unit.

Switching

On, off and reboot control of individual outlets, together with cycling and sequencing of outlets and branch circuits. Control

Control via Ethernet, with communication protocols including HTTP / HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 and IPv6.

Includes Eaton’s patented flexible mounting system, which ensures ePDUs will fit in any standard 42U IT rack, Eaton swithced ePDUs provide reliable, consistent power distribution at

temperatures of up to 50°C. _{*Applicable only for}

- Managed ePDUs

- Advanced Monitored ePDUs - Switched ePDUs

(4)

Designed for the

Data Centre

All ePDUs are made of

rugged aluminium or steel

chassis and incorporate fully

shrouded circuit breakers and

switches. Eaton ePDUs are

designed for the Data Centre

– to be highly reliable, to

consistently provide power

and designed to last.

Monitored ePDUs

Basic ePDUs

Monitored ePDUs accurately monitor

the current draw of the ePDU and

branch circuit, to allow for

provisioning and load balancing of

servers, and to ensure current draw is

not approaching breaker limits.

Monitoring

Monitor current on input and each branch circuit to ensure accurate load balancing.

Control

Monitor and measure remotely over Ethernet or via the LED interface on the unit, which can automatically scroll through branch circuits.

Includes Eaton’s patented flexible mounting system, which ensures ePDUs will fit in any standard 42U IT rack.

In-Line Monitored

ePDUs

In-line Monitored ePDUs are

designed for new data centres, or for

retrofitting to upgrade an existing

infrastructure which lacks power

monitoring. In-line Monitored ePDUs

provide accurate remote monitoring

solutions for both A and B feeds, with

single and dual-feed capability.

Monitoring

A fuseless and breakerless design allows current monitoring in-line, with no break to upgrade existing basic infrastructure.

Control

Monitor and measure remotely over Ethernet or via the LED interface on the unit.

Retro-fit to existing equipment with A and B feed, while live and without downtime.

Basic ePDUs are designed for

reliable and cost-effective power

distribution. They have the

reliability, form factor and outlet

choices to meet your needs.

(5)

What’s in the box:

• ePDU

• Clip-Feet Mounting Brackets • Keyhole Buttons

• Mounting Screws • Quick Setup Guide • Quick Start Guide Monitoring/Management

Software Quantity of Racks Supported Type of Software Application

Web Browser / Email 1 – 25 Includes required web browser Data closet, Small network, Standalone

SNMP 1 – 1,000 Integrates to 3rd party software Small to large enterprise

IPM 1 – 200 Eaton software (free for up to 10 nodes) Small to medium enterprise

Web Browser/E-mail alerts

Every network-connected ePDU comes standard with built-in web server and e-mail capability, allowing you to connect to any ePDU using a standard web browser.

SNMP

Every network-connected ePDU supports SNMP alerts and has a standard MIB available for third party software integration.

Intelligent Power Manager

Eaton’s Intelligent Power Manager provides you with

monitoring and management capabilities across your network. Ideal for virtualized environments, IPM is fully integrated with VMware’s vCenter Server™ and Microsoft SCVMM™.

www.eaton.com/intelligentpower

Space-saving mounting options — all hardware included

Variable clip-foot mounting

* Network connected ePDU refers to all ePDU models except basic and metered ePDU.

Power Management

Eaton provides software management capabilities for every application. Out-of-the-box Web browser management is built into the ePDU and SNMP allows integration to third party network management. This also allows you to connect to Eaton’s management software options: Intelligent Power® Manager or Power Xpert®_.

(6)

Intelligent Power Distribution

Managed Individual outlet monitoring, switching and control

Monitoring: Individual outlet, branch circuit, and full ePDU monitoring for V, W, A and kWhrs

(1% accuracy above 2A).

Switching: Individual outlet, sequencing of outlets with delays or cycling enables remote reboot

of equipment.

Control: Monitor and control remotely over Ethernet and via Advanced LCD screen on the unit.

Communication via HTTP / HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 & IPv6.

Advanced Monitored Individual outlet monitoring

Monitoring: Individual outlet monitoring, branch circuit monitoring and the ePDU as a whole, for

V, W, A and kWhrs (1% accuracy above 2A).

Control: Monitor and measure key properties and alerts remotely over Ethernet or via Advanced

LCD screen on the unit. Communication via HTTP / HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 & IPv6.

Switched Individual outlet switching

Monitoring: Highly accurate monitoring of the ePDU as a whole for V, W, A and kWhr (1%

accuracy above 2A). Also monitor temperature and humidity in the rack via optional sensors.

Switching: On, off and reboot control of individual outlets, together with cycling and sequencing

of outlets and branch circuits.

Control: Monitor over Ethernet or via Advanced LCD screen on the unit, control via Ethernet.

Communication via HTTP / HTTPS, DHCP, SNMP v1 and v3, SNTP, SMTP, Telnet, IPv4 & IPv6.

Monitored ePDU and branch circuit monitoring (A)

Monitoring: Monitor current on input and each branch circuit to ensure accurate load

balancing.

Control: Remotely over Ethernet or via LED interface on the unit, which can automatically scroll

through branch circuits.

In-Line Monitored Add monitoring to upgrade existing basic power distribution

Monitoring: Monitor current in-line with no break to upgrade existing Basic infrastructure,

single or dual feed.

Control: Monitor and measure remotely over Ethernet or via LED interface on the unit. Retro fit to

existing equipment with A&B feed while live and without downtime.

Basic Reliable and cost effective power distribution

Designed for the Data Centre: All ePDUs, including basic ePDUs, are made of rugged aluminium

or steel chassis and incorporate fully shrouded circuit breakers and switches.

Eaton ePDU Selection Guide

(7)

Feature Managed Advanced

Monitored Switched Monitored In-Line Monitored Basic

Monitoring

Remote monitoring via Ethernet     

-Outlet level monitoring   - - -

-V, W, A, and kWh monitoring    - -

-Branch circuit monitoring   -  

-Temperature and Humidity monitoring (via optional probe)    - -

-Overall ePDU level monitoring     

-Local Ammeter     

-Switching

Remote individual outlet on/off switching  -  - -

-Outlet group switching  -  - -

-Progrmammable delays on outlets for sequencing  -  - -

-Outlet cycling  -  - -

-Control

Remotely control via Ethernet    - -

-SNMP traps     

-Local latest generation LCD display    - -

-Local easy to read LED ammeter - - -  

-Circuit Breaker branch protection* (not fuses)     

-Secure communications    - -

-Outlets

IEC outlets      

Shrouded circuit breaker protection     - 

Single and 3 phase units available      

Chassis

Extruded Aluminium chassis (0U)      

Optional Cable retention     - 

50 degree temperature operation    - -

-Reliable power distribution designed for the Data Centre      

Eaton ePDU Selection Guide

(8)

Eaton ePDU Selection Guide

Eaton e

PDU

For detailed technical specs, visit www.eaton.com/epdu
