MOBILE KITCHEN SOLUTIONS

(1)

INSPIRED BY COMFORT

DOMETIC ORIGO

FOR RV AND MARINE APPLICATIONS

(2)

DOMETIC ON-BOARD COOKING CENTRES

These Dometic all round units will accentuate any galley. No matter where you are, you can now treat your family and yourself to a

delicious home-made meal.

Featuring enamelled burner caps, detachable trivets and integrated black glass lid that will extend the bench top when not needed.

With safetly in mind all gas burners have been fitted with flame failure devices and the cover also features a safety cut off for both

gas and electricity for when the lid is closed and burners are left in use.

Ignition system Electronic, 12 volt Power rating 800 w, electric hotplate Gas consumption Grill: 95 g/h, total 561 g/h Gas supply pressure 2.75 kpa

Number of burners 3 + 1 electric

Dimensions W514 x H292 x D535 mm

Weight 12.2 kg

Test mark SAI Australian gas compliance certificate, Australian certificate of Electricity Safety, EMC compliant

Ignition system Electronic, 12 volt Power rating 800 w, electric hotplate

Gas consumption Oven: 73 g/h Grill: 95 g/h Total 634 g/h Gas supply pressure 2.75 kpa

Number of burners 3 + 1 electric

Weight 23.8 kg

Test mark SAI Australian gas compliance certificate, Australian certificate of Electricity Safety, EMC compliant

Quality features

3 gas burners with 1electric hot plate Electronic ignition

Gas burners fitted with flame failure safety devices

3 gas burners with 1electric hot plate Oven with separate grill compartment Electronic ignition

Black enamel cooktop with a black glass hinged burner cover

Cover features a safety cut off for both gas and electricity

Gas oven with 12 volt turntable

DOMETIC COOKTOP & GRILL

3 burner + 1 electric hotplate + gas grill

DOMETIC OVEN, COOKTOP & GRILL

3 burner + 1 electric hotplate + gas grill + gas oven

Product Ref. No

Dometic cooktop & grill 9102302647

Dometic oven, cooktop & grill 9102302646

DOMETIC’S INTERGRATED SAFTEY FEATURES

Black enamel cooktop with a black glass hinged burner cover

Gas and electric 240 volts

(3)

STYLISH & ELEGANT

DOMETIC STOVE COOKERS

Power rating 6.36 kW total maximum Gas consumption 119 g/h average per burner Gas supply pressure 2.75 kpa

Number of burners 3 x gas, 1 x electric, 1 x grill

Weight 19.3 kg

Test mark AGA

Power rating 7.89 kW total maximum Gas consumption 119 g/h average per burner Gas supply pressure 2.75 kpa

Number of burners 3 x gas, 1 x electric, 1 x grill, 1 x oven burner

Weight 32 kg

Test mark AGA

3 gas burners with 1 electric hot plate (800 watt)

Black enamel cooktop with hinged glass burner cover

Electronic ignition

DOMETIC STOVES 3 + 1 grill

3 gas burner + 1 electric, glass lid height 466 mm, electric hot plate 800 watts, gas 12 volt ignition on all burners & gas safety valves fitted to all

burners.

DOMETIC STOVES 3 + 1 grill + oven

3 gas burner + 1 electric, glass lid height 466 mm, electric hot plate 800 watts, gas 12 volt ignition on all burners, gas safety valves fitted to all burners.

Dometic three plus 1 grill 444447063

Dometic three plus 1 grill + oven 444447064

Black enamel pan support Silver control face and handle Glass door for the grill box

Grill box comes complete with grill tray Aluminium and brass burners with black enamel tops

Dometic provides a range of AGA approved gas cookers in a design to fit your needs, with glass lids to extend the bench top when

not needed. Gas safety valves are fitted to all burners for extra safety, along with fixed burners to eliminate rattle when on the road.

The Dometic stove cookers meet all your mobile cooking needs.

3 gas burners with 1 electric hot plate (800 watt)

Black enamel cooktop with hinged glass burner cover

Electronic ignition

Black enamel pan support Silver control face and handle Glass door for the grill box

Grill box comes complete with grill tray Aluminium and brass burners with black enamel tops 12 volt ignition on all burners One electric hot plate 800 watts Gas safety valve on all burners

Glass lid fitted with safety shut off for all top burners

(4)

Power rating 3.2 kW Gas consumption 233 g/h total Gas supply pressure 2.75 kpa

Number of burners 2

Weight 3.3 kg

Test mark SAI Australian gas compliance certificate,

Ignition system 12 volts

Power rating 4.8 kW

Gas consumption 350 g/h total Gas supply pressure 2.75 kpa

Weight 5.1 kg

Test mark SAI Australian gas compliance certificate

Ignition system 12 volts

Power rating 4.8 kW

Gas consumption 350 g/h total Gas supply pressure 2.75 kpa

Weight 6.1 kg

Test mark SAI Australian gas compliance certificate, Quality features

Integrated heat-resistant safety glass lid Detachable chromed pan supports Stainless steel burner caps

2 Integrated heat-resistant safety glass lid Detachable chromed pan supports Stainless steel burner caps recessed controls

DOMETIC CRAMER 2 burner

2 burner hob with glass lid, Piezo ignition system, gas safety valves fitted to all burners.

DOMETIC CRAMER 3 burner

3 burner hob with glass lid, gas 12 volt ignition on all burners, gas safety valves fitted to all burners.

DOMETIC CRAMER combi unit

3 burner hob/sink combination with glass lids, gas 12 volt ignition on all burners, gas safety valves fitted to all burners.

Dometic CRAMER 1066037 1066037

Dometic CRAMER 1040114 1040114

Dometic CRAMER COMBI 8639 (No tap)

Dometic CRAMER COMBI 8588 (with Hot and Cold mixer tap) Dometic CRAMER COMBI 8589 (with Cold tap)

8639 8588-KIT 8589-KIT Safety ignition system

Recessed controls

Low profile bench top rubber seal

Safety ignition system Recessed controls

Safety ignition system Recessed controls,

Low profile bench top rubber seal Supplied with hole for tap [ Ø 39 mm ].

OPTIMAL

PROTECTION

FOR THE

HOB

Safety ignition system Integrated heat resistant safety glass lid

Detachable pan supports – easy to clean Stainless steel burner caps Gas

(5)

Dimensions W440 x H300 x D120 mm Weight 0.6 kg Dimensions W650 x H130 x D400 mm Weight 2.6 kg Dimensions W185 x H220 x D200 mm Weight 0.8 kg Dimensions W600 x H136 x D445 mm Weight 5.1 kg

CLEAN & TIDY

WITH DOMETIC SINKS & BINS

Integrated heat resistant safety glass lid Removable bin

Integrated heat resistant safety glass lid Integrated waste tray

Tap fitting inside

2 litre capacity

Low profile bench top rubber seal Supplied with hole for top [ Ø 39 mm ]

DOMETIC CRAMER oval washbowl

DOMETIC CRAMER sink/drainer combination

DOMETIC CRAMER waste bin

with glass lid

DOMETIC CRAMER sink/drainer combination

with glass lid

Product Ref. No Dometic CRAMER 8863 8863 Product Ref. No Dometic CRAMER 1023006 1023006 Product Ref. No Dometic CRAMER 1072008 1072008 Product Ref. No

Dometic CRAMER 1058007 (No tap)

Dometic CRAMER 1058008 (with Hot and Cold mixer tap)

Dometic CRAMER 1058009 (with Cold tap)

1058007 1058008-KIT 1058009-KIT

Rinsing, washing and disposing of waste needn’t be a hassle when you’re on the move. Dometic CRAMER sinks are

practical and affordable solutions to complement your kitchen fittings. Waste trays, sinks and washbowls all products

hard-wearing material and refined functionality.

(6)

Dimensions Ø410 x H150 mm Cut out dimensions Ø395 mm

Weight 4.5 kg

Burning time approx 6 to 8 hours

Burner capacity 2000 watts

Boiling time approx. 10 minutes for 1 litre of water Tank capacity 1.2 litres

Weight 3.25 kg

Weight 4.5 kg

Integrated heat resistant safety glass lid Tap fitting inside

Supplied with hole for top [ Ø 39 mm ]

DOMETIC CRAMER round sink

DOMETIC ORIGO 1500

Single burner free standing alcohol stove

DOMETIC ORIGO 2000

Single burner built in alcohol stove

Dometic CRAMER 1078013 (with Cold tap)

Dometic CRAMER 1078014 (with Hot and Cold mixer tap)

1078013-KIT 1078014-KIT

Dometic ORIGO 1500 OH1500

Dometic ORIGO 2000 Glass lid, suits OH2000

OH2000 3880253-83

The efficient single burner freestanding spirit stove for confined spaces. Portable, compact, and built to last. Ideal for motor homes caravans camping and boats.

Practical single burner spirit stove top for building in. Big on safety and efficiency but compact. Optional glass lid available.

MOBILE ALCOHOL STOVES

If you would rather cook using alcohol than with gas, the Dometic ORIGO range has something for you. Dometic ORIGO

alcohol stoves are ideal for those really tight on-board kitchens or for picnics in the open. They come with one or two

burners, have a super compact design and are easy to stow away again after meals. Tried and tested these stoves are safe

and use high performance technology. They are built from stainless steel with a high quality finish and are easy to clean.

(7)

Burner capacity 2000 watts per canister

Boiling time approx. 10 minutes for 1 litre of water Tank capacity 1.2 litres per cannister

Weight 6.5 kg

Boiling time approx. 10 minutes for 1 litre of water Tank capacity 1.2 litres per canister

Weight 7.5 kg

Burner capacity Burners 2000 watts, Oven 1500 watts Boiling time approx. 10 minutes for 1 litre of water Tank capacity 1.2 litres per canister

Weight 25.6 kg

DOMETIC ORIGO 3000

Double burner freestanding alcohol stove.

DOMETIC ORIGO 4100

Built in double burner alcohol stove top.

DOMETIC ORIGO 6000

Built in double burner alcohol stove top.

DOMETIC ORIGO accessories

Dometic ORIGO 4100 Glass lid, suits OH4100

OH4100 3880253-82

Dometic ORIGO 3001 Pot Holder (to suit OH1500, OH3000, OH6000)

OH3001 Dometic CRAMER 3002 Gimbal

(to suit OH1500, OH3000)

OH3002 Dometic ORIGO 4001 Pot Holder

(to suit OH2000, OH4100)

OH4001

The classic two burner freestanding stove suitable for all types of applications including marine. Rugged and reliable.

Handsome two burner built in stove top. Suitable for all types of applications including marine. Optional glass lid available

A complete two burner stove with an oven, which is indispensable for a crew with a healthy appetite. Easily fitted without extra installation work. Gimbal mounting comes as standard. Suitable for all types of applications including marine.

Ideal for indoor and outdoor use High cooking power on burners

Easy access to the alcohol-fuel container – simple and safe to fill

Comprehensive accessories which can be ordered separately simple and safe to fill

(8)

Burning time approx 6 to 8 hours Number of burners 1 x 1200 watts electric element Burner capacity 2000 watts

Weight 3.25 kg

Burner capacity 1500 watts per canister

Dimensions Ø280x H290 mm

Weight 3 kg

Burning time approx 6 to 8 hours Number of burners 2 x 1200 watt electric element Burner capacity 2000 watts each

Boiling time approx. 10 minutes for 1 litre of water Tank capacity 1.2 litres per cannister

Weight 4.5 kg

DOMETIC ORIGO 5100

Heat Pal - The cooking all rounder.

DOMETIC ORIGO OHC100

Electric & alcohol single burner built in stove top.

DOMETIC ORIGO OHC200

Electric & alcohol double burner built in stove top.

Dometic ORIGO C100 OHC100

Dometic ORIGO C200 OHC200

Ideal for caravan, motorhomes and boats. Use the 240 volts when connected to power and alcohol when free camping.

MOBILE DUAL FUEL COOKING

ELECTRIC AND ALCOHOL STOVE TOPS

Designed to look great and to make you feel at home anywhere, the Dometic ORIGO range of stainless steel built cook tops are

compact and run on both 240 volts and alcohol.

COMPACT EASY TO

STOW AWAY DESIGN

Ideal for indoor and outdoor use High cooking power on burners

Easy access to the alcohol-fuel container – simple and safe to fill

Comprehensive accessories which can be ordered separately simple and safe to fill

This all rounder is not only an effective source of heat but also an excellent stove for cooking. Great for the caravan, boat or camping.

Quality features 12 volt ignition

(9)

Voltage 12 volts DC

Capacity 115 m³/h

Power input 30 watts

Cupboard recess W381 x D142 mm

Roof opening Ø105 mm

Roof dome dimensions Ø200 mm x H64

Weight 1.9 kg

Test marks CE, e5, C tick

Capacity 70 / 125 m³/h

Cupboard recess W381 x D142 mm

Roof opening Ø64 x H200 mm

Roof dome dimensions Ø200 x H64 mm

Weight 3 kg

Test marks CE, e5, C tick

Capacity 65/ 105 m³/h

Roof opening Ø105 mm

Roof dome dimensions Ø200 x H170 mm

Weight 0.6 kg

Test marks C tick

DOMETIC CK 150

Flush mounted rangehood with 1-speed fan.

DOMETIC CK 155

Surface mounted rangehood with 2-speed fan.

DOMETIC GY 11

Roof ventilation with motor - Exchanges air even when

fan is switched off.

Product Ref. No Dometic CK 150 CK150 Product Ref. No Dometic CK 155 CK155 Product Ref. No Dometic GY 11 GY11

INTELLIGENT DESIGN

DOMETIC RANGEHOODS

Recirculating rangehoods in the Dometic CK series are designed to quickly draw cooking fumes, odours and moist

air out of the cabin. The compact fan, which is equipped with a 12 volt motor, is integrated into the roof dome and

not into the unit itself. Both the CK 150 & CK 155 are suitable for both conventional and pop top caravans.

Quality features 1-speed fan

Washable metal grease filter

Halogen lamps [ 1 x 20 watts / GU5.3 ] 12 volts

Washable metal grease filter

Robust plastic roof dome

Robust plastic roof dome Flush mount

Recessed model

2 intergrated Halogen lamps [ 2 x 10 watts / GU4 ] 12 volts

Robust plastic roof dome

High performance

Powerful ventilation even when the motor is turned off [ 3 to 12 m³/h at wind speed of 1 to 4 m/s ]

(10)

Motor 12 volts DC, 28,000 rpm

Battery 12 volts DC, 2.6 Ah

Operating time approx. 18 min ± 10% Charging time 10 to 14 hours (automatic cut-off)

Capacity 3.8 litres

Power consumption approx. 90 watts

Cleaning power approx. 400 mm water column (± 10%) Operating temperature 0 °C to +40 °C

Material Handle: ABS, Filter: polyester, Dust container: PP

Weight 2.15 kg

Scope of delivery Vacuum cleaner, hose, attachments for upholstery, rugs and narrow gaps, carrying strap, mains adapter, 12 volt charging cable, operating instructions.

Capacity approx. 0.75 litres

Average power consumption 12 volts: 200 watts

Colour Black/silver

Dimensions W190 x H205 x D125 mm (incl. fixing kit)

Weight 0.8 kg

Test marks e-approved (Automotive EMC Directive), complies with German-Foodstuff and Consumer Goods Act (LMBG)

Scope of delivery Fixing kit for wall or desk mounting

Gross capacity 6 bottles

Power source 12 volts DC / 240 volts AC

Weight approx. 6.5 kg

Cooling control Digital selection from 5 °C to 20 °C

WAECO PerfectKitchen MCK750

12 volt kettle tailor made for mobile use.

WAECO PowerVac PV-100

Wet/dry vacuum cleaner with 12 volt rechargeable

battery. Ideal for cars, caravans, motor homes boats

and around the home

WAECO MyFridge MF-6W

12 volts & 240 volts 6-bottle wine chamber

Product Ref. No PowerVac PV-100 Product Ref. No PerfectKitchen MCK750, 12 volts MCK-750-12/N Product Ref. No MyFridge MF-6W MF-6W

HANDY WAECO APPLIANCES

Quality features Robust relay technology Status indication Wall or bench mounting

Maximum mobility with rechargeable 12 volt battery Rechargable from 12 and 240 volts

Quality features Freestanding

Auto switch off when the boiling temperature has been reached or when there’s no water in the kettle

Easy to clean dust container & fabric filter Cleaning power: 400 mm water column

Temperature variable from 5 °C to 20 °C 12/24 volts DC and 240 volts AC DC+AC

(11)

Voltage 240 volts/50Hz* Circuit protection 10 amp Water heating element 1600 watts

Water consumption 39 litres (60 °C cotton without pre-wash)

Capacity 3.0 kg (Cotton Wash)

Water connection 3/4

Colour White

Weight 54 kg

Test marks Australian Certificate Electrical Safety, EMC, W.E.L.S.

DOMETIC WMD 1050

Space saving 240 volt compact washing machine.

Dometic Compact washing machine WMD1050

DOMESTIC BLISS

DOMETIC WASHING MACHINE

Underbench or freestanding Hot or cold water fill

* Supplied voltage must meet the required 240 volts/50 Hz without excessive variation.

Dometic oven cooktop & grill

WAECO wine chamber

Dometic fridge Dometic awnings Dometic Seitz windows

NEW! Dometic Seitz caravan door

(12)

E & OE

Please note: Dometic Group may introduce modifications to products, therefore details herein are subject to change

Your retailer: Dometic Australia, Queensland 1 1 John Duncan Court Varsity Lakes QLD 4227 Phone: +61 (0)7 5507 6000 Fax: +61 (0)7 5507 6001

Dometic Australia, Queensland 2 2/129 South Pine Road Brendale QLD 4500 Phone: +61 (0)7 3205 7599 Fax: +61 (0)7 3881 1409

Dometic Australia, Victoria

Bldg 3B, Clayton Business Park 1508 Centre Road, Clayton VIC 3168 Phone: +61 (0)3 9239 1000 Fax: +61 (0)3 9239 1099

FREECALL: 1800 21 21 21

Dometic Australia, Western Australia 12 Prosperity Avenue Wangara WA 6065 Phone: +61 (0)8 9303 3555 Fax: +61 (0)8 9303 3577 E-mail: [email protected] Web: www.dometic.com.au
