Grey Correlation Analysis of Factors Affecting Wood Drying
in PCM Thermal Storage Solar Drying System
Yu Jie
1, Zheng Maosheng
21
School of Life Science & Technology, Northwest University, Xi'an, China 2
School of Chemical Engineering, Northwest University, Xi'an, China
Email address:
[email protected] (Zheng Maosheng)
To cite this article:
Yu Jie, Zheng Maosheng. Grey Correlation Analysis of Factors Affecting Wood Drying in PCM Thermal Storage Solar Drying System.
Mathematical Modelling and Applications. Vol. 2, No. 3, 2017, pp. 28-32. doi: 10.11648/j.mma.20170203.11
Received: May 10, 2017; Accepted: June 6, 2017; Published: July 14, 2017
Abstract:
The gray correlation analysis is employed to analyze the effect of the row number of thermal storage tubes, the air circulation rate and the air temperature on efficiency of wood drying in solar drying system with phase change material (PCM) thermal storage, the relative order of influencing factors on wood drying process is determined. It indicated that air temperature is the 1st key influencing factor in the solar drying system, followed by the air circulation rate, and then the row number of thermal storage tubes. This result is of practical significance for the optimization of the drying process.Keywords:
Grey Correlation, Solar Wood Drying, Air Temperature, Circulation Rate, Thermal Storage Tube Row1. Introduction
Use of solar energy for drying agricultural products is one of the important production activities, which were carried out very early in human society [1]. In nowadays, the energy shortage and environmental pollution restrict economic development and threat to living environment, so much more attention has been paid to the use of solar energy. The modern solar drying technology refers to the use of hot air to dry materials, while the warm air is obtained by a collector of solar radiation and transfer it into heat energy. Solar drying can not only greatly reduce the drying time and improve product quality, but also can play a role in energy saving.
China has abundant solar energy resources, it has about two-thirds of land with annual irradiation time over 2200 hours [1], the annual total radiation is over 5000 MJ / m2, the total solar radiation in the country is 3340 MJ / m2 ~ 8400 MJ / m2 per year. Especially, it is very suitable to carry out application of solar energy in the region of the latitude range 35 ° ~ 45 °. The areas with plenty of solar energy resource includes Tibetan plateau, northern Gansu, Ningxia, southern Xinjiang, northwestern Hebei, northern Shanxi, Inner Mongolia, central Gansu, eastern Qinghai, southeastern Tibet, etc.
Wood drying is most important process in wood production process, it costs about 40% to 70% of energy consumption of
the whole wood production in China [2]. The use of solar drying in wood production has been launched in many countries [2-5]. However, the total drying capacity of solar drying in China is approximately 0.2% of the drying production [5], so it needs to be improved.
The factors that restrict the use of solar drying include mainly the low energy density of solar resource, the seasonal performance, and poor storage of energy.
Feng et al. studied wood drying by solar technology with phase change thermal storage [6], in which a small test rig with phase change thermal storage system is set up to simulate the drying process of wood drying apparatus. The experimental result gives some rules of the effect of the number of thermal storage pipe rows, the rate and the temperature of circulation air on the drying efficiency, it is useful to optimize the drying system.
Grey theory was proposed by Deng in 1982 [7-14], and it has been applied in many ways, and gratifying results are achieved. The Grey system theory is based on "knowing partial information, unknowing partial information", "small sample", "poor information", and "uncertainty system", it realizes the operation behavior, the correct description and the evolution of a system mainly by extracting valuable information and generation and development of knowing partial information.
In this paper, the gray correlation degree analysis is employed to study the influence of affecting factors on wood drying in solar drying system with phase change thermal storage conducted by [6].
2. Materials and Methods
2.1. Outline of Feng’s Drying Test
In Feng’s test [6], the test material is poplar produced from the Beijing suburb with the initial moisture content in the range of 78% to 83%. The size of test material specifications: 350 × 40 × 40 mm (L × W × H), with volume of 0.01 m3.
A small test bed is employed which contains a thermal storage system [6], a heating system, an air circulation system and a data acquisition system. The thermal storage system consists of a metal box with a number of 10 mm holes in radius for inserting thermal storage aluminum-pipe of paraffin, the air circulation path is formed between the thermal storage aluminum-pipe of paraffin. The phase transition temperature of the paraffin is about 54°C. The electric heater is taken as a supplement for heat energy, the rate and the temperature of the circulation air can be adjusted. The rate of the circulation air is 1.0, 1.5, 2.0 m / s, respectively.
The test is repeated for 9 times for each test condition. Figure 1 shows the arrangement of paraffin tubes in the thermal storage system [6].
Figure 1. Arrangement of paraffin tubes in the thermal storage system.
2.2. Fundamental of Grey Correlation Degree
Since the proposal of Grey theory in his “Control problems of grey systems” by Prof. Deng in 1982 [7], the Grey Correlation Degree theory has been developed gradually [8-14].
It deal with the system with partial information clear and partial unclear, i.e., relatively poor information systems. While, in traditional system theory, more information was need adequately. For some relatively poor information systems, the use of black-box approach also made a more successful experience. However, the research is very inadequate for the system with some internal information ascertain and partial information unknown. This blank area becomes the birthplace of Grey System Theory.
Gray Correlation analysis is a multivariate statistical
analysis method, which is based on the sample data of various factors. If the trends of two factors (orientation, size and speed, etc.) of the sample data are basically the same, the correlation degree between these two factors is greater; on the contrary, a smaller correlation degree. Therefore, the gray correlation method is based on the degree of similarity or dissimilarity between the trends of factors.
The advantage of this approach is thinking clear, reducing loss due to the asymmetric information to a large extent, and less workload.
The basic procedure for analyzing the gray correlation is as follows:
(1) Determining the representing “number of columns” of the system behaviour and the reference “number of columns” of the system;
(2) Non-dimensional treatment for the reference “number of columns” and comparative the “number of columns”;
(3) Calculating the gray correlation coefficient between the reference “number of columns” and compare “number of columns”;
(4) Calculating related degree; (5) Arranged order correlation degree.
3. Analysis of Grey Correlation Degree
3.1. Feng’s Experimental Results
The basic idea of gray correlation analysis is based on the geometric similarity of sequence curves to determine the closeness [13, 14]. The closer the curves, the greater correlation degree of the sequences. The mapping is the 1st step to perform the analysis.
According to the test results of Feng et al. [6], the effect of the influence of affecting factors on drying efficiency is sort out systematically. The effect of the number of tube rows on the wood drying efficiency is represented in Table 1.
Table 1. Effect of number of thermal storage tube rows on drying rate [6].
Number of tube rows 5 7 11 13
Drying rate (%⋅h-1) 1.04 1.11 1.04 0.99
Table 2 shows the effect of the circulation rate of air on the wood drying efficiency under condition of the thermal storage number of tube rows 7 and the air temperature is 60°C [6].
Table 2. Effect of air circulation rate on the wood drying efficiency (thermal storage tube rows number of 7 and the air temperature of 60°C).
Circulation rate of air (m/s) 1.0 1.5 2.0
Drying efficiency (%⋅h-1) 0.68 0.98 0.75
Table 3 shows the influence of temperature of circulation air on drying efficiency under condition of 11 thermal storage tube rows and the air rate of 1.5m/s.
Table 3. The influence of temperature of circulation air on drying efficiency under condition of 11 thermal storage tube rows and air rate of 1.5m/s.
Temperature of circulation air (°C) 55 60 65
3.2. Calculation of Gray Correlation
The drying rate is the target parameter of the drying process [13, 14], yi. While the variables of the system includes, the number of thermal storage tube rows, the temperature and the rate of circulation air, xi.
Therefore, above data processing needs to be rewritten in accordance with the gray theory as
y1 = {1.04, 1.11, 1.04}, x1 = {5, 7, 11}
y2 = {0.68, 0.98, 0.75}, x2 = {1.0, 1.5, 2.0}
y3 = {0.83, 0.95, 1.06}, x3 = {55, 60, 65}
wherein, y1, y2, and y3 represent the target factors, i.e. drying rate. x1, x2, and x3 represent the number of thermal storage
tube rows, rate of the circulating air, the temperature of the circulating air, correspondingly.
3.2.1. Calculation of Grey Generalized Absolute Correlation
According to the gray theory [13, 14], the gray correlation degree can be obtained for the three sets of data of the previous section. Specification follows these steps:
1), Setting a starting point image for each sequence
y01=｛0, 0.07, 0｝, x01=｛0, 2, 6｝
y02=｛0, 0.30, 0.07｝, x02=｛0, 0.5, 1.0｝
y03=｛0, 0.12, 0.23｝, x 0
3=｛0, 5, 10｝
2), Getting
Y
s1 ,X
s1 ,X
s1−
Y
s107 . 0 ) 3 ( y 2 1 ) k ( y Y 2 2 k 0 1 0 1 1
s =
∑
= + =00 . 5 ) 3 ( x 2 1 ) k ( x X 2 2 k 0 1 0 1 1
s =
∑
= + =93
.
4
)]
3
(
y
)
3
(
x
[
2
1
)]
k
(
y
)
k
(
x
[
Y
X
2k 2 100 1 0 1 0 1 1 s 1
s
−
=
∑
=−
+
−
=
3), Calculation of Gray absolute correlation degree
5518 . 0 00 . 11 07 . 6 Y X Y X 1 Y X 1 1 s 1 s 1 s 1 s 1 s 1 s
11 + + + − = =
+ + =
ε
Similarly, it could calculate other gray generalized absolute correlation,
ε11 = 0.5518, ε12 = 0.6900, ε13 = 0.5271
ε21 = 0.5759, ε22 = 0.7783, ε23 = 0.5398
ε31 = 0.5668, ε32 = 0.7450, ε33 = 0.5350
It gives absolute correlation matrix
= = = 5350 . 0 7450 . 0 5668 . 0 5398 . 0 7783 . 0 5759 . 0 5271 . 0 6900 . 0 5518 . 0 ) ( 33 32 31 23 22 21 13 12 11 ε ε ε ε ε ε ε ε ε ε A ij
3.2.2. Calculation of Gray Relative Relation
Similarly, according to the gray theory [13, 14], it can be obtained gray relative relation. The specification follows these steps:
1), Setting initial features and starting image of the sequences [13, 14],
Y1′ = (1.00, 1.07, 1.00), X1′= (1.0, 1.4, 2.2)
Y2′ = (1.00, 1.44, 1.10), X2′ = (1.0, 1.5, 2.0)
Y3′ =(1.00, 1.14, 1.28), X3′ =(1.00, 1.09, 1.18)
2), The starting point image of zero Yi′ and Xj′ are [13, 14],
Y1′0=(0, 0.07, 0), X1′0= (0, 0.4, 1.2)
Y2′0=(0, 0.44, 0.10), X2′0= (0, 0.5, 1.0)
Y3′ 0
= (0, 0.14, 0.28), X3′ 0
=(0, 0.09, 0.18)
3), Getting
Y
si'
,X
si'
andX
si'
−
Y
si'
07
.
0
)
3
(
'
y
2
1
)
k
(
'
y
'
Y
si=
∑
2k=2 1 0+
1 0=
00 . 1 ) 3 ( ' x 2 1 ) k ( ' x '
X 2k 2 0 1 0
1
[
] [
x
'
(
3
)
y
'
(
3
)
]
0
.
93
2
1
)
k
(
'
y
)
k
(
'
x
'
Y
'
X
2 2 k 0 1 0 1 0 1 0 1 sisi
−
=
∑
=−
+
−
=
4) Getting grey relative relation
According to the algorithm of gray relative relation [6], it gives a gray relative relation
6891
.
0
'
Y
'
X
'
X
'
Y
'
X
'
Y
1
1 s 1 s 1 s 1 s 1 s 1 s11
+
+
+
−
=
+
+
=
1
γ
.Similarly, it can be calculated the remaining
γ11 = 0.6891, γ12 = 0.6891, γ13 = 0.9160
γ21 = 0.8309, γ22 = 0.8309, γ23 = 0.8434
γ31 = 0.7611, γ32 = 0.7611, γ33 = 0.9353,
and the relative incidence matrix,
=
=
=
9353
.
0
7611
.
0
7611
.
0
8434
.
0
8309
.
0
8309
.
0
9160
.
0
6891
.
0
6891
.
0
)
(
33 32 31 23 22 21 13 12 11γ
ε
γ
γ
γ
γ
γ
γ
γ
γ
B
ij3.2.3. Getting Comprehensive Correlation Matrix C
According to the definition of comprehensive correlation matrix C, C = θ⋅A+(1-θ)⋅B, it takes θ=0.5 in general [13, 14], then
C = θ⋅A+(1-θ)⋅B = θ⋅εij+(1-θ)⋅γij = ρij
= = 7351 . 0 7530 . 0 6639 . 0 6916 . 0 8041 . 0 7034 . 0 7216 . 0 6896 . 0 6205 . 0 33 32 31 23 22 21 13 12 11 ρ ρ ρ ρ ρ ρ ρ ρ ρ 3.3. Results
Look at the absolute correlation matrix A, it can be found that there exists εi2>εi1>εi3, i=1,2,3; therefore order of priority is X2, X1 and X3, which means that the impact of circulation rate of air is the main affecting factor, followed by the number of thermal storage tube rows, and the air temperature.
While, as to the relative correlation sequence B, it holds γi3
>γi2 = γi1, i = 1,2,3; therefore order of priority is X3, X2 and X1. However, as to the comprehensive correlation matrix C, it
holds,
∑
∑
∑
= =
= > >
3 1
i i1
3 1
i i3
3 1
i ρi2 ρ ρ , therefore order of priority is X2, X3 and X1.
The results of above importance ranking from the previous matrix A, B and C disagree with each other, which is because the calculation algorithm of each correlation degree pays to its special attention. Here the main point is the effect of various factors on the wood drying rate, the relative correlation analysis prevail.
4. Conclusion
In this paper, the use of multifactor gray theory is conducted, which analyze the effect of various affecting factors on the wood drying efficiency in a solar dryer with phase change
thermal storage comprehensively. It was indicated that the air temperature is the 1st key influencing factor in the in solar drying system, followed by the air circulation rate, and the number of thermal storage tube rows. This result is of practical significance for the optimization of the drying process.
