Document:

Migrating Essbase Application

Using LCM Utility

Description:

This document will guide you through the step by step process of

Migrating Essbase Application from one environment to another. It is

focused on how to migrate one Essbase Application to another Essbase

Application and Essbase Application to file system and vice versa.

History:

Version

Description

Change

Author

Publish Date

0.1 Initial Draft

Gaurav Shrivastava

07-Feb-2011

0.1 Review 1

Amit Sharma

18

th

_{Mar 2011}

(2)

Management provides a consistent way for Oracle Hyperion Enterprise Performance Management System products to migrate an application, a repository, or individual artifacts across product environments and operating systems. If there is common environment, then you can migrate directly from application to application. Shared service used for migration when there is common environment. You can take back up of all artifacts through Life Cycle Management utility.

Essbase Artifacts

1. Definitions of all databases within the applications 2. Outlines 3. Substitution Variables 4. Rule Files 5. Calculation Scripts 6. Report Scripts 7. Excel Files 8. Location Aliases 9. Security Filters

(4)

Lifecycle Management for Essbase can be used in the following scenario • Migrating users/groups/roles/privileges migrations

• Backup and recovery for Essbase artifacts.

• Importing and exporting artifacts for editing purposes

• Using Lifecycle Management Utility to export to version control systems

• Application migrations with cross-product artifact dependencies

Migration Types LCM Utility

1. Application to Application Migration – If you have multiple application of Essbase

registered in the same shared services instance, then you can migrate Essbase Application & Database Artifacts to the other Essbase application through the common Shared Services.

Application to Application: You can migrate artifacts from application to application.

Essbase application to application migration is possible if source and target Essbase application in the same shared services.

In the below example there are two Essbase applications “Bisp” and “MDemo”, we will demonstrate how to migrate Application to Application.

Step #1 Open shared services and select Essbase in application then open source

application.

(5)

Select all artifacts and click “Define Migration”.

“Bisp” is my source application and target application is “MDemo”.

Step #3

Description of source application Click Next…….

Step #4

Select destination application Click Next……..

(6)

Final summary of Source and target applications

Select overwrite artifacts options if you want to overwrite on existing artifacts.

Step #6

Complete migration summary

Click on “Execute Migration” then click ok ……..

You can go for “Launch Migration Status Report” and see the status. Launched Migration Report

Validation of Migration Process

Application migration done successfully

(7)

2. Application to File System Migration – If you have multiple Essbase applications

registered in different shared services. Then this utility migrates all the necessary artifacts on to the file system. Then you can move the extracted artifacts to the target machine. In the next step again use the utility from file system to the target application.

Application to file system

This is the Essbase application and database. We will perform LCM operations.

(8)

Step #1

We use shared services for LCM utility. Log in to shared service.

This is the Group of application for different application products.

Step #2

(9)

Essbase applications and their databases

Step #3

Open “Bisp” application and select database with all artifacts. These are the all artifacts of the BispBD database.

(10)

Security file, variable and Text file.

(11)

Step #4

Click on Define migration…….

Step #5

Source Application for migration Click on Next…………

(12)

Step #6

Select the destination for migration; you can simply migrate to any application or into file system. One backup file is created in this example.

Click Next………

Step #7

Description of source and destination applications Click Next………..

Step #8

(13)

Step #9

You can launch migration status report by clicking on “Launch Migration Status Report”………..

Step #9

Migrated report status

Validate

You can see that application is successfully migrated in to file system. One new file created in the file system; it has all migrated artifacts.

(14)

Backed up artifacts

All artifacts folders backed up successfully. Backup files stored in “ \import_export\admini@Native Directory\” folder.

All backup files are in XML format. You can move all this files in other environment; were ever you want.

Calc Script

(15)

Location Aliases

Report Scripts

Rule Files

(16)

Substitution Variables

Text Files

(17)

Some other information also stored inside the info folder.

Listing.xml

Listing file save the entire folder detailed information. This file consists of all resource name, folder id, path, pathAlias, modifiedBy, lastUpdated and description about each folder. Whatever file or folder generated during complete process.

(18)

Source information file save application version, variable, metadata information. This file keep product, product version, project, metadata information and LCMversion information.

File system to application

Step #10

All backup of artifacts is stored in the “BispBackup” file. Select all artifacts to recover application from file system to Essbase application.

(19)

Report Script and Rule Files

(20)

Step #11

Now the source is file system application named “BispBackup”. Click Next………

Step #12

Select destination application click next……

(21)

Destination is new one then no need to check Overwrite Artifacts. If destination application is old one then check the overwrite artifacts.

Click Next…….

Step #14

This is migration summary click on execute the migration summary.

Step #15

To see the migration report launch migration status report.

See the status of report

(22)

Select Essbase and open “LCM” application and check out all migrated artifacts. You can validate that application is migrated successfully.

Migrated application outline.

You can cross check the all files are migrated in to new application. This folder shows migrated files.

You can cross check artifacts list in new “LCM” application. Calc script, excel files and location aliases

(23)

Report script and rule files

(24)

Migration Check List

You can create one migration check list, and check the status after migration.

(25)

(26)

(27)

Log File

One log file creates during migrating application artifacts using LCM utility.

(28)

This log file keeps all the information of migration process.

(29)

(30)

This is the log file

(31)

LCM

The components of Lifecycle Management Utility are installed to

HYPERION_HOME/common/utilities/LCM/9.5.0.0 (referred to as LCM_HOME).

Essbase Role Requirement

Users performing Lifecycle Management operations for Essbase must be assigned the following roles::

1. LCM Administrator 2. Server Access 3. Calc

(32)

Appendix

Lifecycle Management Log Files

Lifecycle Management for Oracle Hyperion Profitability and Cost Management, Fusion Edition are listed in the Oracle Hyperion Enterprise Performance Management

System Installation and Configuration Troubleshooting Guide

Note the following:

• Details are documented in the logging section of S9 Logging.

• For failed migrations, the Migration Status Report provides a link to the Lifecycle Management e engine log file. The product Oracle Hyperion Enterprise Performance Management System Lifecycle Management log files are located with the products. Sample Migration Definition Files

The sample migration definition files provided are for Financial Management Classic application

migrations. The product code used in the migration definition files for Financial Management is HFM and the

sample application is COMMA. All sample migration definition files are provided in LCM_HOME/samples.

Application to Application Migration

<?xml version="1.0" encoding="UTF-8"?>

<Tasks>

</Target> </Task> </Tasks> </Package>

(33)

Exporting to the File System

<Tasks>

Importing from the File System

<ConnectionInfo name="FileSystem-Connection2" type="FileSystem"

filePath="file:/C:\Hyperion\common\import_export\admin@Native Directory\HFM Comma" HSSConnection="MyHSS-Connection1" description="Source Application"/>

</Connections> <Tasks>
