Using Atlas Import Wizard
Use the Atlas Import Wizard to create media plans when you have large campaigns or
campaigns that use many different URLs and ads. This job aid covers the basic information you
will need to get started with the Atlas Import Wizard. For more detailed information, see
ʺAbout Atlas Import Wizardʺ in Media Console Help.
Before you start
You must install the Import Wizard, and, if needed, Microsoft .NET Framework.
• The Import Wizard is available at
http://atlas.atlassolutions.com/atlas/bin/import/importinstall.msi
• .NET Framework is available from the Microsoft Download Center at
http://www.microsoft.com/beta/downloads/Default.aspx
Important
If you already have the necessary templates, skip the following section.
Create an Import Template
1. After you have installed the Atlas Import Wizard, log on.
2. Click Create Import Template.
3. On the menu, select one of the following import template types:
• Action Management
• Ad Assignment, Ad and Creative Creation
• Ad Update
• Category List
• Create Placement
• Media Creation
• Add Placements to Buy
4. Click Create and then click Save.
The file is saved as a .csv (comma separated values) file.
After you have created your template, open the spreadsheet editor and enter your information.
The wizard can import either Microsoft Excel (XLS) or CSV files. If you are not using Excel, you
should save the file in CSV format. For additional information, see Media Console Help.
Notes
• If the file name of an uploaded creative contains a space, Media Console replaces
it with an underscore.
• Entries for Atlas Imports must be exact, with the correct information in the
correct columns. Any errors will cause the import to fail.
• Duplicate rows are reported as an error and cause the import to fail.
Import a worksheet
1. Open the Import Wizard.
2. Select Import Existing Worksheet and click Next.
3. Type the worksheet name or click Browse to open.
4. Select the import template type from the list and click Next.
The import process starts.
5. If you receive validation errors, you can do the following:
a. Without closing the wizard, open your worksheet, correct any errors, and save
the file.
b. In the wizard, click Validate.
The worksheet is revalidated.
6. Click Import. If there are not any validation errors, or when you have fixed them all, the
import button will be active.
Tip
During the import process, the worksheet is validated again. The first validation
checks to make sure the worksheet has the correct cells filled in. The second
validation checks to make sure the information in the cells is correct.
7. If there are any errors at this stage, you can do the following:
a. Fix the errors in the worksheet and then save.
b. In the Wizard, click Validate and then click Import again.
Tip
During this validation step, the wizard stops if it finds an error and displays the
information about that error. It only displays one error line number at a time.
After you have fixed the error, you may want to check your spreadsheet for
similar errors.
8. When the import has been successfully completed, you can select Import/Create another
spreadsheet or click Finish to exit the wizard.
Notes
• You cannot activate placements by using the wizard; you must do that in the
Media Console interface.
• The import wizard does not warn you of potential problems, as Media Console
does. For example, you will not be alerted if you do one of the following:
o
Remove the last ad from a placement. (Make sure to set up default ads!)
o
Assign a 120x120 ad to a 468x60 placement.
Atlas Import wizard templates
For information about the templates, including names of the template columns, information
about the values, and whether the columns are optional or required, see the following tables.
Create Placement template
Action Management template
Ad assignment, Ad and Creative Creation template
Ad Update template
Add Placement to Buy template
Category List template
Media Creation template
Create Placement template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here, but columns do not need to be in the order shown.
The form for money is integer and with two decimals; 1.00
The form for decimal is two places; .00
The form for integer is a whole number; 1
Column name
Description and values
Required or optional
Command CP to create a placement RequiredBuy GUID Also know as Buy Unique Identifier. Required Placement Name The name of the placement. Maximum of 70 characters Required Creative Category Display, streaming, expanding toplayer, floating toplayer, or custom toplayer. Required Accepted Creative Use one or more of the following values separated by a semi‐colon: gif, jpeg, html, flash, java, html with javascript, dhtml, shoshkeles, unicast, streaming: realplayer, streaming: windows media player, streaming: quicktime, streaming: other, eyeblaster, pointroll, flash banner, expanding toplayer, floating toplayer, and custom toplayer. Required Delivery Method Valid values for this column are standard, IFrame, click tracking, and JavaScript. Required Placement Width The width of the placement Integer Required for all creatives but keywords and text links Placement Height The height of the placement Integer Required for all but keywords and text links creatives Secure? Y for yes or N for no. Default is N Optional Enable Placement Media Code? Y for yes or N for no. Default is N Optional
Placement Media Code Maximum of 100 characters Required if Enable Placement Media Code is set to YES. Media Code Separator Separates the placement and creative media codes
! $ ’ * + ‐ / : ; = ? @ _
Column name
Description and values
Required or optional
Existing Package? If the value is NO, a new package is created, even if the supplied Package Name currently exists If the value is YES, the existing package is used if the supplied Package Name is found (if more than one package have same name, import will create placement under first package found). If the package name is not found, an error is displayed. Default is NO. Optional Package Name If blank, PlacementName is used. Maximum of 70 characters Optional Site Alias From the stie properties in site profile. If blank, placementId is used. Optional Site Code RequiredCost Method CPM, CPC, CPA, Time, Upfront, or Value Add. Not required if ExistingPackage is set to YES. Ad Serving Fee Cost Method CPM, CPC, CPM Capped, CPC Capped, Exclude, or blank. Default is CPM Optional Use Publisher Counts? Valid values for this column are TRUE, which is Publisher, and FALSE, which is Atlas If empty, the default value is taken from Buy. Optional Ad Serving Fee The default value is taken from Buy. Decimal (for 20% enter .20) Required if Ad Serving Fee Cost Method is not EXCLUDE or blank. Agency Fee Markup Decimal Optional
CPA Action Tag The unique action tag code for the action tag Required if
CostMethodID is set to CPA. Media Costs Capped? YES, NO, or blank. • YES will set the value to Spend • NO will set the value to None • Blank will set the value to None Optional Flighting General, Monthly, Daily or blank. If blank, the default value is taken from Buy. Not required if ExistingPackage is set to YES. Start Date If blank, the default value is taken from MediaPlan Use mm/dd/yyyy Optional End Date If blank, the default value is taken from MediaPlan. Use mm/dd/yyyy Optional Calculated Value This column determines which of the three costing values is calculated: Total Quantity, Net Media Cost, or Net Cost Basis. Valid values for this column are: ʺTotal Quantityʺ ʺNet Media Costʺ and ʺNet Cost Basisʺ. Default is ʺTotal Quantityʺ. Optional
Column name
Description and values
Required or optional
Net Cost Basis Not required if ExistingPackage is set to YES. Required if either Total Quantity or Net Media Cost is missing. Optional Net Media Cost Not required if ExistingPackage is set to YES. Required if either Net Cost Basis or Total Quantity is missing. Optional Total Quantity Not required if ExistingPackage is set to YES. Required if either Net Cost Basis or Net Media Cost is missing. Optional Ad Serving Quantity RequiredAction Management template
The following table lists the individual names of the template columns, information about the values for
the columns, and specifies whether they are required or optional. You must have the column names
exactly as they are shown here.
Notes
• The Action Import can support up to 1,000 rows.
• Action Management import does not support metric or category properties, nor does it
support the JavaScript Insert Window field.
Column name
Description
Optional or required
Command C for create action or U for update action RequiredBranch Code Required Advertiser Code Required Action Tag ID Required for updates Unique Action Tag Code Optional Description Required URL location for Action Tag Optional Click Action Landing Page URL Required if Tag Type is set to Click
Tag Type Javascript, IFrame, Image, Click Required Tag Category Homepage, Registration, Registration confirmation, Product pages, Promotional product pages, Information, Sales confirmation, Order process, Download, or Other Required View Conversion Window (Max 90 Days) Integer Optional
View Conversion Window Unit Seconds, minutes, hours, or days Optional Click Conversion Window (Max 90
Days)
Integer Optional
Click Conversion Window Unit Seconds, minutes, hours, or days Optional Repeat Conversion Window (Max 90
Days)
Integer Optional
Repeat Conversion Window Unit Seconds, minutes, hours, or days Optional Generate Secure Tag (HTTPS) (Y/N) YES or NO Required Report Start Date Only relevant if conversion tracking is
enabled
Optional
Enable Conversion Tracking (Y/N) YES or NO Required Filter Conversions By Order ID
(Y/N)
Ad Assignment, Ad and Creative Creation template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here.
You can use this template for the following commands:
• CC for Create Creative
• Non‐TPL file creatives
• TPL file creative
• External creative
• Tracking pixel creative
• CA for Create Ad
• R for Remove Ad
• U for Update sequence or weight
• CC‐CA‐A for Create Creative, Create Ad, and Assign Ad
• CA‐A for Create Ad, Assign Ad
Notes
• There is no CC‐CA command. You must use two rows, one with a CC command and one
with a CA command.
• If you want to create multiple ads with the same creative and click‐through URL, you must
use an ad tag in the CA command.
Column name
Commands Description
Required or optional
Branch Code CC, CA, R, U Branch GUID Advertiser Code CC, CA, R, U Advertiser GUID Either Advertiser code OR Advertiser GUID Required Command CC, CA, R, U Required Placement GUID Site Alias A, R, U CA Use either Creative Description and Clickthrough URL OR just Ad Tag to identify the ad for assignment. For multi‐click‐through ads use the creative description and ONE of the click‐through URLS. See also note following table. Required if you are creating a multi‐click‐ through URL advertisement, optional otherwise. Ad Tag A, R, U Use either Creative Description and Clickthrough URL OR just Ad Tag to identify the ad for assignment. For multi‐click‐through ads use the creative description and ONE of the click‐through URLS.Column name
Commands Description
Required or optional
CC For File creative defaults to the file name. Required if you are creating Tracking pixel or External creative. Creative Description A, R, U Use either Creative Description and Clickthrough URL OR just Ad Tag alone to identify the ad for assignment. For multi‐click‐through ads you can use the creative description and ONE of the click‐ through URLS. Creative Class CC Defaults to File creative File creative, Tracking pixel creative, External creative or file, tracking, external Required if you are creating Tracking pixel or External creative. Creative File Location CC . Required only if you are creating an external creative File Name CC Required if you are creating an external creative. The files must already have been uploaded into Media Console. Creative Type CC Required if you are creating a TPL, tracking, or external creative Creative Delivery Method CC IFrame, JavaScript Required if you are creating a TPL, tracking, or external creative File Size (KB) CC Optional Creative Width CC Required if you are creating a TPL, tracking, or external creative Creative Height CC Required if you are creating a TPL, tracking, or external creative Animated? CC YES or NO OptionalAnimation Loops CC Unlimited or 1‐9999 Optional Length of Animation CC 1‐9999 Optional Frequency Limit CC Unlimited or 1‐9999 Optional Post Cap? CC YES or NO Optional Creative Schedule Name CC Optional Creative Hidden? CC YES or NO Optional Enable Creative Media Code? CC YES or NO Optional Creative Media Code CC ! $ ’ * + ‐ / : ; = ? @ _ Required if Enable Creative Media Code is set to YES
Sequence A, U Enter either Sequence OR Weight, Max = 99999 Max = 9999
Optional Weight A, U Enter either Sequence OR Weight, Max =
99999 Max = 9999
Column name
Commands Description
Required or optional
CA Must start with http or https. For multi‐ click‐through URL ads, include one row per click‐through ad. Required Clickthrough URL (Multi‐click Ads) A, R, U Use either Creative Description plus Clickthrough URL OR Ad Tag alone to identify the ad for assignment. For multi‐ click‐through ads you can use the creative description plus ONE of the click‐through URLS. Clickthrough URL column must exist if you specify Ad Tag, but it may be left blank.Event Description CA Optional
Note
If your import template includes a CA‐A command that does not include an ad tag, imports will
check the database for existing ads that use that creative and click‐through URL:
• If an ad with the creative and click‐through URL does not already exist, import will
create the ad and assign it to the placement.
• If an ad with the creative and click‐through URL does already exist, import will find the
existing ad and assign it to the placement.
• If more than one ad with the same creative and click‐through URL already exists, then
the CA command will fail and report an error that there are multiple ads using the same
creative and click‐through URL. The error message will tell you to use the ad tag to
identify the specific ad to assign. You will need to update the spreadsheet with the
correct ad tag and change the command to A.
If your import includes a CA‐A command that does include an ad tag, imports will always
attempt to create the ad, then assign it. If the ad tag already exists, the command will fail since
you cannot create an ad with a duplicate ad tag. If this is the case, try it again using the A
command by itself.
Ad Update template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here.
Column name
Description
Required or optional
Branch Code Advertiser Code Advertiser GUID Required: Branch Code and Advertiser code OR Advertiser GUID Branch GUID Optional Ad Tag Required Click Tag (sortable) Required Clickthrough URL Clickthrough URL (Multi‐click Ads) Must be left blank for interaction updates Required Event Description RequiredAdd Placements to a Buy template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here.
Note
Placements created using the Import Wizard are in the New Ad serving state. You must use Media
Console to activate the placements.
The form for money is integer and with two decimals; 1.00
The form for decimal is two places; .00
The form for integer is a whole number; 1
Agency, Branch and Advertiser columns
Column name
Description
Required or optional
Agency Code Branch Code Advertiser Code Advertiser GUID Required: Agency code, Branch code, and Advertiser code, OR Advertiser GUIDBuy columns
Column name
Description
Required or optional
Buy GUID From the publisher in the media plan. It is listed as ʹBuyUnique Identifierʹ
Required
Package columns
Column name
Description
Required or optional
Package Name If blank defaults to Placement Name. Maximum is 70 characters. Optional Contract Start Date Use mm/dd/yyyy Default from Media Plan Required Contract End Date Use mm/dd/yyyy Default from Media Plan RequiredFlighting Type General or Monthly Required Site Code From the site properties in site profile Required Cost Method CPM, CPC, CPA, Time, or Upfront Required Cost Basis Money Required Billing Period Quantities One quantity is required for each billing period.
Separate quantities with semicolon (;)
Column name
Description
Required or optional
Billing Period Ad Serving Quantities One quantity is required for each billing period. Separate quantities with semicolon (;) Required ASF Cost Method CPM or CPC Default is CPM Optional Value Add? YES or NO Default is NO Optional Whose Count Atlas or Publisher Default is inherited from Buy Optional Package Hidden From Reports? YES or NO Default is NO Optional Keyword Package? YES or NO Default is NO OptionalKeyword Total Inventory Integer Optional Keyword Available Inventory Integer Optional Advertiser Pays ASF? YES or NO Default is inherited from Buy Optional Ad Serving Capped? YES or NO Default is inherited from Buy Optional Media Costs Capped? YES or NO Default is inherited from media plan Optional Ad Serving Fee Money Default is inherited from Buy Optional CPA Action Tag Values are advertiser specific. Must specify a unique action *tag*, not description Required if Cost Method is set to CPA.
Placement columns
Column name
Description
Required or optional
Placement Name If you are creating a stand‐alone placement, the package name and placement name must match. Maximum is 70 characters Required Creative Category Graphic, Interstitial, Streaming, or Text link See Notes below Required Placement Type RON, ROS, ROC, Section, Page, Sponsorship, Newsletter, Search Listing, Email, Other, Keyword. RequiredDelivery Method IFrame, JavaScript, or standard Required Placement Width Integer Required Placement Height Integer Required
Column name
Description
Required or optional
Accepted Media Types TopLayer: Banner; GIF; JPEG; Flash; Java; HTML; HTML with JavaScript; DHTML; Eyeblaster; PointRoll; Shoshkeles; Text link Separate multiple types with a semicolon (;). RequiredPlacement Interstitial Type Pop‐up; pop‐under; transitional Required if Creative Category is set to Interstitial Placement URL Must be valid URL and include http:// Optional Placement Content Category Default is inherited from publisher Optional Horizontal Position Combination Left Center Right Optional Vertical Position Above the fold Below the fold Combination Optional Other Placement Type Required if Placement Type is set to Other Loop Count 1‐10, No animation, unlimited Optional
Site Alias Placement URL Optional Placement Alt Text Text Optional Static? YES or NO Default is NO Optional Secure? YES or NO Default is NO Optional
Max File Size (KB) Integer Optional Max Text Lines Integer Optional Max Text Characters Integer Optional Keyword YES or NO Default is NO Required if Placement Type is set to Keyword Right of First Refusal? YES or NO Default is NO Optional Exclusive Keyword Purchaser? YES or NO Default is NO Optional
Other Creative Information Text Optional Placement Hidden From Reports? YES or NO Default is NO Optional Enable Placement Media Code? YES or NO Default is NO Optional Placement Media Code Maximum is 100 characters (total for both placement and creative media codes) Required if enable media codes is YES
Column name
Description
Required or optional
Media Code Separator Goes between the placement and the creative media codes. Default is & ! $ ’ * + ‐ / : ; = ? @ _ OptionalNotes
If Creative Placement is set to:
• Graphic−you must specify at least one non‐streaming accepted media type
• Interstitial−you must specify at least one accepted media interstitial type
• Streaming−you must specify at least one streaming accepted media type
• Text link−you must specify Accepted Media Type as Text link
Category List template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here.
The commands for this template are as follows:
• CC for Create category
• U for Update category
• D for Delete category from existing list
Column name
Required or optional
Branch Code Required Branch GUID Optional Advertiser Code Required Advertiser GUID Optional List GUID Optional List Name Required List Description Optional Is List Active? Optional Command Required Category Code Required Category Name Required Category Description OptionalMedia Creation template
The following table lists the individual names of the template columns and a description of their values.
It also specifies whether the columns are optional or required. You must have the names exactly as they
are shown here.
Note
Buys created using the Import Wizard are in the Drafted Buy state and the placements are in the New
ad serving state, you must use Media Console to activate the placements.
The form for money is integer and with two decimals; 1.00
The form for decimal is two places; .00
The form for integer is a whole number; 1
Agency, branch, and advertiser columns
Column name
Description
Required or optional
Agency Code Branch Code 3 characters Advertiser Code 3 characters Advertiser GUID Required: Agency Code, Branch Code, and Advertiser Code OR Advertiser GUIDMedia Plan columns
Column name
Description
Required or optional
Media Plan Name The plan name RequiredMedia Plan Projected Start Date Use mm/dd/yyyy Required Media Plan Projected End Date Use mm/dd/yyyy Required Media Plan Budget Amount Money; 1.00 Optional Media Plan Product Name Default is 01 standard ad serving Optional Media Plan Hidden From Reports? YES or NO Default is NO Optional Media Plan Media Costs Capped? YES or NO Default is inherited from Advertiser Optional
Media Plan Ad Serving Capped? YES or NO Optional Media Plan Agency Fee Decimal Default is inherited from Advertiser Optional Media Plan Advertiser Pays ASF? YES or NO Default is inherited from Advertiser Optional Media Plan CPM ASF Money Default is inherited from Advertiser Required if Media Plan Advertiser Pays ASF is YES
Column name
Description
Required or optional
Media Plan CPC ASF Money Default is inherited from Advertiser Required if Media Plan Advertiser Pays ASF is YES.Buy columns
Column name
Description
Required or optional
Publisher Code From publisher properties in the siteprofile
Required
RFP Due Date Use mm/dd/yyyy Optional Expiration Date Use mm/dd/yyyy Optional Special Terms Optional Buy Whose Count Atlas or Publisher Default is inherited from publisher Optional Buy Advertiser Pays ASF? YES or NO Default is inherited from media plan Optional Buy CPM ASF Money Default is inherited from media plan Required if Buy Advertiser Pays ASF is YES. Buy CPC ASF Money Default is inherited from media plan Required if Buy Advertiser Pays ASF is YES. Buy Ad Serving Capped? YES or NO Default is inherited from media plan Optional
Package columns
Column name
Description
Required or optional
Package Name Maximum is 70 characters RequiredContract Start Date Use mm/dd/yyyy Required Contract End Date Use mm/dd/yyyy Required Flighting Type General or Monthly Required Site Code From the site properties in site profile Required Cost Method CPM, CPC, CPA, Time, or Upfront Required Cost Basis Money Required Billing Period Quantities One quantity is required for each billing period. Separate quantities with semicolon (;) Required Billing Period Ad Serving Quantities One quantity is required for each billing period. Separate quantities with semicolon (;) Required ASF Cost Method CPM or CPC Default is CPM Optional
Column name
Description
Required or optional
Value Add? YES or NO Default is NO Optional Whose Count Atlas or Publisher Default is inherited from Buy Optional Package Hidden From Reports? YES or NO Default is NO Optional Keyword Package? YES or NO Default is NO OptionalKeyword Total Inventory Integer Optional Keyword Available Inventory Integer Optional Advertiser Pays ASF? YES or NO Default is inherited from Buy Optional Ad Serving Capped? YES or NO Default is inherited from Buy Optional Media Costs Capped? YES or NO Default is inherited from media plan Optional Ad Serving Fee Money Default is inherited from Buy Optional CPA Action Tag Values are advertiser specific Must specify action *tag*, not description Required if Cost Method is set to CPA
Placement Columns
Column name
Description
Required or optional
Placement Name If you are creating a stand‐alone placement, the package name and placement name must match. Maximum is 70 characters Required Creative Category Graphic, Interstitial, Streaming, or Text link See Notes below Required Placement Type RON, ROS, ROC, Section, Page, Sponsorship, Newsletter, Search Listing, Email, Other, Keyword. RequiredDelivery Method IFrame, JavaScript, or standard Required Placement Width Integer Required Placement Height Integer Required
Column name
Description
Required or optional
Accepted Media Types TopLayer: Banner; GIF; JPEG; Flash; Java; HTML; HTML with JavaScript; DHTML; Eyeblaster; PointRoll; Shoshkeles; Text link Separate multiple types with a semicolon (;). RequiredPlacement Interstitial Type Pop‐up; pop‐under; transitional Required if Creative Category is set to Interstitial Placement URL Must be valid URL and include http:// Optional Placement Content Category Default is inherited from publisher Optional Horizontal Position Combination Left Center right Optional Vertical Position Above the fold Below the fold Combination Optional Other Placement Type Required if Placement Type is set to Other. Loop Count 1‐10, NO animation, unlimited Optional
Site Alias URL where the placement is located Optional Placement Alt Text Text Optional Static? YES or NO Default is NO Optional Secure? YES or NO Default is NO Optional
Max File Size (KB) Integer Optional Max Text Lines Integer Optional Max Text Characters Integer Optional Keyword YES or NO Default is NO Required if Placement Type is set to Keyword Right of First Refusal? YES or NO Default is NO Optional Exclusive Keyword Purchaser? YES or NO Default is NO Optional
Other Creative Information Text Optional Placement Hidden From Reports? YES or NO Default is NO Optional Enable Placement Media Code? YES or NO Default is NO Optional
