1: CLIP, TUBE
(P.C.V) Area Code AC 216098-001 $1.31 2: CANISTER
Area Code AC 181094-001 $239.35 3: VALVE, PURGE CONTROL
Area Code AC 181563-001 $70.71 4: RUBBER Area Code AC 181636-001 $7.45 5: PLUG Area Code AC 74195-001 $5.91 6: COLLAR, SETTING 115960-001 $4.36 7: RUBBER Area Code AC 115251-001 $2.18 8: CLIP, CABLE (10MM) (10MM) 240732-001 $1.60 9: CLIP, TUBE (B7) (B7) 250428-001 $0.60 10: CLIP, TUBE (B8) (B8) 250430-001 $0.60 11: CLIP, TUBE (B10) (B10) 250433-001 $0.68 12: CLIP, TUBE (B12.5) (B12.5) 250439-001 $0.45 13: BULK HOSE (3.5X8000) (3.5x8000) (3.5x150) 251090-001 $40.16 14: BULK HOSE (4.5X8000) (4.5X8000) (4.5X320) Area Code A 252309-001 $74.67 16: BULK HOSE (5.5X8000) (5.5X8000) (5.3X375) Area Code AC 252642-001 $69.12 17: BULK HOSE (8X8000) (8X8000) (8X380) Area Code AC 252880-001 $90.38 19: BOLT, FLANGE (6X25) (6X25) 253370-001 $0.76
Created by eDocPrinter PDF Pro!!
1: CLIP, BREATHER TUBE Area Code AC 216089-001 $2.49 2: HOLDER, ELEMENT Area Code A 229361-001 $35.60 3: SEAL 230342-001 $5.29 4: COVER, A/CLNR HSG 230472-001 $36.58 5: GROMMET, TUBE 230908-001 $1.64
6: HOUSING, AIR CLEANER 231136-001 $90.15 7: DUCT, AIR CLEANER 231781-001 $18.47 8: TUBE 232237-001 $15.84 9: TUBE, DRAIN 182508-001 $6.74 10: CHAMBER, BREATHER 182692-001 $8.71 11: COVER, BR. CHAMBER 182729-001 $8.13
12: TUBE, BREATHER JOINT 180806-001 $7.24
14: TUBE, BREATHER 180895-001 $2.82
15: CLIP, BREATHER TUBE 180914-001 $2.15
16: PLUG, BREATHER TUBE 180920-001 $2.33
18: BOLT, FLANGE (6MM) (6MM) 233552-001 $3.62 19: NUT, SPECIAL (6X7) 115253-001 $2.64 20: BAND, A/CLNR TUBE 240460-001 $8.20 21: SEAL, BR. CHAMBER 243956-001 $2.87 23: SCREW-WASHER (6X28) 247945-001 $0.67 24: SCREW-WASHER (6X35) (6X35) 247947-001 $0.55 24: SCREW, TAP (4X10) 248324-001 $0.37 25: SCREW, TAP (5X20) 248433-001 $0.29 26: CLIP, TUBE (B12.5) (B12.5) 250439-001 $0.45 27: CLIP, TUBE (10.5MM) (10.5MM) 250459-001 $0.95 28: BULK HOSE, VINYL
(8X12X8000) (8X12X280) 250757-001 $31.12
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: GENERATOR, PULSE 173238-001 $47.87 3: FLYWHEEL 171129-001 $222.49 4: STATOR 169757-001 $203.00 5: CLAMP, WIRE 161446-001 $3.45 6: GROMMET B 161574-001 $4.09 7: BOLT, SOCKET (5X12) (5x12) 2326-001 $1.82 8: BOLT, SOCKET (5X32) (5X32) 233927-001 $1.22 9: BOLT, ROTOR SETTING 234590-001 $6.96
10: WASHER, PLAIN (12MM) 237872-001 $2.25
11: BOLT, SOCKET (6X20) (6X20) 254595-001 $0.65
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: BATTERY (YTX7L-BS) (YTX7L-BS) (YUASA) 166863-001 $76.50 2: BATTERY (YTX7L-BS) (YTX7L-BS) (YUASA) 166863-001 $76.50 3: CABLE 162623-001 $17.44 4: COVER 162790-001 $5.67 5: SWITCH ASSY. 154293-001 $58.16 6: RUBBER 154355-001 $6.05 7: TRAY, BATTERY 131607-001 $88.24 8: RUBBER, BATTERY 131697-001 $17.09 9: BAND, BATTERY TRAY 131742-001 $25.05 10: BOX, TOOL 95655-001 $21.05 11: PLATE 95765-001 $4.22 12: BODY, KEY 93944-001 $1.93 12: STOPPER, KEY BODY 93955-001 $1.65
13: RUBBER, BATTERY BOX 93813-001 $1.07 14: CLIP, TUBE 80153-001 $1.60 15: BOLT, SOCKET (5X9) 233627-001 $1.51 16: NUT, FLANGE (6MM) (6MM) 249194-001 $0.58 17: NUT, FLANGE (6MM) (6MM) 249195-001 $0.10 18: PIN, SPRING (2X14) 249481-001 $0.62 19: BOLT, FLANGE (6X10) (6x10) 253328-001 $0.58 20: FUSE, BLADE (20A) (20A) 255303-001 $0.50
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SPROCKET, CAM (38T) (38T) 210442-001 $22.75 2: CHAIN, CAM
210564-001 $95.31 3: TENSIONER, CAM CHAIN 211115-001 $101.33 4: SPRING
211271-001 $3.95 5: TUBE
211408-001 $1.68 6: GUIDE, CAM CHAIN 211501-001 $22.80 7: BOLT (7X12) 79663-001 $1.53 8: BOLT, SPECIAL (6X28) 234705-001 $2.23 9: WASHER (6MM) (6MM) 237864-001 $0.80 10: WASHER A, TACHOMETER 237962-001 $1.40 11: PIN, LOCK (6MM) (6MM) 249416-001 $0.38
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SEAL, VALVE STEM (ARAI) 201790-001 $8.35 2: BUSH, CAMSHAFT 202139-001 $20.27 3: CAMSHAFT ASSY. 209560-001 $133.20 4: ARM, VALVE ROCKER 210739-001 $24.00 5: SHAFT 210934-001 $8.36 6: SPRING 211024-001 $2.25 7: VALVE, IN. 211966-001 $18.11 8: VALVE, EX. 212154-001 $36.62 9: SPRING, VALVE 212424-001 $6.87 10: SPRING, VALVE (NIPPON HATSUJO) 212539-001 $4.85 11: RETAINER, VLV SPR 212656-001 $5.05 12: SEAT, VALVE SPRING 212722-001 $2.44 13: COTTER, VALVE
Fr_Sr_No_To 2114642 212820-001 $1.95 14: SCREW, TAPPET ADJ.
80275-001 $2.09 15: NUT, TAPPET ADJ. 236168-001 $1.24 16: WASHER (20MM) 237281-001 $2.18 17: PIN, DOWEL (5X5.5) 240832-001 $2.02 18: CIRCLIP (20MM) 249607-001 $0.55
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: GASKET SET A 216272-001 $18.45 2: NEEDLE SET, JET 216777-001 $29.47 3: FLOAT SET
216984-001 $32.84 4: CHAMBER SET, FLOAT 217275-001 $82.67 5: SCREW SET A 217534-001 $11.25 6: LINK SET
217628-001 $23.24 7: ROD SET, PUMP 217728-001 $13.95 8: DIAPHRAGM SET, PUMP 217864-001 $62.65 9: T-JOINT
218220-001 $23.65 10: SCREW SET 218356-001 $22.22 11: PLATE SET, VALVE 218631-001 $12.71 13: SPRING
218989-001 $10.78
14: CARBURETOR (VE35A A)
(VE35A A) Area Code A 219794-001 $325.24 14: CARBURETOR (VE36A A)
(VE36A A) Area Code AC 219795-001 $325.24 15: TOP 222047-001 $26.36 16: PISTON, VACUUM 222210-001 $105.35 17: TUBE 222858-001 $3.67 18: TUBE Area Code AC 222866-001 $3.50 19: TUBE 222906-001 $7.31 20: CAP, CABLE SEALING 222984-001 $10.11 21: VALVE, FLOAT 223126-001 $23.93 22: CLIP, TUBE
Area Code A 223250-001 $0.56 23: HOLDER, NEEDLE JET 223382-001 $22.38 24: JOINT 223861-001 $9.78 25: PLATE, SET 223939-001 $3.04 26: TUBE, OVERFLOW 224244-001 $5.02 27: TUBE 224410-001 $7.31 28: SCREW, PAN (4X8) (4x8) 247125-001 $0.35 29: SCREW, PAN (4X14)
Created by eDocPrinter PDF Pro!!
(4x14) 247148-001 $0.37 30: SCREW-WASHER (4X12) (4x12) 247974-001 $0.29 31: CLIP, TUBE (B8) (B8) 250430-001 $0.60 32: JET, MAIN (#110) Area Code A 255544-001 $5.67 33: JET, SLOW (#35) (# 35) 255943-001 $11.45 34: O-RING (2.4X29) (2.4X29) 219139-001 $4.93
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: WASHER, LOCK (16MM) (16MM) 215005-001 $2.84 2: CLUTCH OUTER 63885-001 $150.93 3: GUIDE, CLUTCH 65519-001 $13.55 4: CENTER, CLUTCH Fr_Sr_No_To 5206426 65173-001 $50.64 5: SEAT, JUDDER SPRING
65258-001 $7.20 6: DISK, CL FRICTION 65381-001 $10.22 6: DISK, CL FRICTION 65383-001 $9.40 7: PLATE, CLUTCH 64514-001 $7.78 8: PLATE, CLU PRESS 64417-001 $25.82 9: PLATE, CLUTCH LIFTER 64706-001 $10.96
10: COLR, CLUTCH LIFTER 64758-001 $13.02
11: SPRING, CLUTCH 64058-001 $3.07 12: SPRING, JUDDER 64102-001 $16.71 13: PIN, CLUTCH LIFTER 60297-001 $3.22 14: BOLT (6X22) (6X22) 79307-001 $2.09 15: NUT, LOCK (16MM) (16MM) 236241-001 $2.80 16: WASHER (12MM) (TOYO) 238104-001 $2.18 17: WASHER (20MM) 238382-001 $3.47 18: WASHER B (20MM) (20MM) 238397-001 $3.64 19: BEARING (12MM) (TOMUSON 5644-001 $7.69 20: CLIP (12MM) (12MM) 241979-001 $1.89
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
2: GASKET, CRANKCASE 197190-001 $12.73 3: CRANKCASE, L. 197434-001 $268.82 4: BOLT, CYLINDER STUD 80933-001 $7.58 5: BOLT (12MM) [DRAIN PLUG] 246210-001 $1.50 6: WASHER (12MM) [DRAIN PLUG] 2266-001 $0.45 7: DOWEL PIN (8X14) (8x14) 2267-001 $0.88 8: DOWEL PIN (12X20) 249445-001 $1.05 9: BOLT, FLANGE (6X40) (6X40) 253395-001 $0.70 10: BOLT, FLANGE (6X65) 253417-001 $0.93 11: BOLT, FLANGE (6X40) (6x40) 2484-001 $0.90
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CRANKSHAFT
Fr_Sr_No_To 5122917 203961-001 $595.62 2: RING SET (STD)
(STD) 204218-001 $27.16 2: RING SET (OS 0.25) (0.25) 204704-001 $27.16 2: RING SET (OS 0.50) (0.50) 204889-001 $27.16 3: PISTON (STD) (STD) 205538-001 $34.64 3: PISTON (OS 0.25) (0.25) 205912-001 $34.33 3: PISTON (OS 0.50) (0.50) 206237-001 $34.33 4: PIN, PISTON 206787-001 $10.73 5: PLATE, OIL THROUGH 208949-001 $18.36 6: GEAR B (20T)
(20T) 214757-001 $30.20 7: THROUGH, OIL
214970-001 $6.78 8: SPRING, OIL THROUGH 214991-001 $1.69 9: GEAR (19T) (19T) 59430-001 $37.69 10: BOLT, FLANGE (8X35) (8X35) 81679-001 $1.80 11: BOLT, STUD (7X32) 81093-001 $1.64 12: NUT, HUB (16MM) (16MM) 236089-001 $2.24 13: WASHER, LOCK 237171-001 $3.16 14: PIN, DOWEL (4X4.4) 240864-001 $2.33 15: BEARING (6305) (6305)(NACHI) 241513-001 $28.49 15: BEARING (6305) 241579-001 $26.85 16: OIL SEAL (35X52X7) (35X52X7) 242679-001 $7.95 17: O-RING (6X3) 244177-001 $1.53 18: SCREW, FLAT (6X16) (6X16) 247590-001 $0.40 19: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57 20: CLIP (15MM) (15MM) 2285-001 $0.62 21: ROLLER (2X13.8) (2X13.8) 254344-001 $0.31
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CYLINDER 200896-001 $375.29 2: GASKET, CYLINDER 201287-001 $7.49 3: NUT, HEX. (6MM) (6MM) 6093-001 $0.50 4: DOWEL PIN (10X16) (10x16) 2268-001 $1.05
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: GUIDE, VALVE
(O.S) 200577-001 $6.80 2: GUIDE, VALVE
200632-001 $10.85 3: CYLINDER HEAD SET 201555-001 $542.60 4: GASKET, CYL HD 202329-001 $21.25 5: GASKET Area Code A 225415-001 $5.56 6: MANIFOLD, IN. 228863-001 $56.98 7: STAY Area Code AC 181624-001 $3.11 8: BOLT, STUD (6X32) 81046-001 $1.42 9: BOLT, STUD (6X40) (6X40) 81084-001 $3.04 10: BOLT, STUD (6X33) 81085-001 $1.58 10: BOLT, STUD (6X33) (6X33) 81101-001 $1.38 11: BOLT, FLANGE (6X145) (6X145) 79292-001 $5.11 12: BOLT 2, STUD (6X18) 246226-001 $1.15 13: O-RING (25.5X2.5) (25.5X2.5) (ARAI) 243714-001 $2.64 14: O-RING (10X1.6) (10X1.6) 243665-001 $1.93 15: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57 16: BOLT, FLANGE (6X65) 253417-001 $0.93
17: SPARK PLUG (CR5HSA)
(CRASHSA NGK) 255046-001 $2.11 17: S/PLG (U16FSR-U)
(U16FSR-U) 255047-001 $3.08 17: SPARK PLUG (CR6HSA) (CR6HSA) 255055-001 $2.11 17: SPARK PLUG (CR7HSA)
(CR7HSA NGK) 255060-001 $2.11 17: S/PLG (U22FSR-U)
(U22FSR-U) (ND) 255062-001 $3.08
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: HOLDER, CAMSHAFT 202114-001 $61.62 3: COVER, CYLINDER HEAD 202791-001 $80.69 4: GASKET, CYL HD CVR 203462-001 $15.38 5: BOLT, FLANGE (6X33) 79087-001 $5.65 6: WASHER (8MM) (8MM) Area Code A 238661-001 $1.09 7: RUBBER, SETTING 239786-001 $3.00 8: PIN, DOWEL (10X28) 240764-001 $2.22 9: NUT, HEX. (8MM) (8MM) 5908-001 $0.47 10: DOWEL PIN (10X16) (10x16) 2268-001 $1.05
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CLIP, CABLE 136705-001 $4.02 2: FRAME *NH1*
(BLACK) Area Code A 133358-001 $996.09 2: FRAME *NH1*
(BLACK) Area Code AC 133359-001 $996.09 3: PLATE, FR. *NH1* (BLACK) 130075-001 $32.18 4: PLATE, R. ENG HGR (UPPER) 130247-001 $14.47 5: PLATE, L. ENG HGR (UPPER) 130311-001 $9.09 6: GUARD, WIND 130567-001 $15.16 7: BOLT, FLG (10X110) 80620-001 $4.49 8: BOLT, FLANGE (8X37) (8x37) 234177-001 $2.47 9: NUT, CAP (8MM) (8MM) 237926-001 $2.09 10: CLIP, SPLASH 240559-001 $2.32 11: CLIP, CABLE (10MM) (10MM) 240732-001 $1.60 12: CLIP, CABLE (15MM) (15MM) 240733-001 $1.60 13: CLIP, CABLE (20MM) (20MM) 240734-001 $1.60 14: BOLT, CAP (8X75) (8X75) 246064-001 $2.05 15: NUT, FLANGE (8MM) (8MM) 2299-001 $0.57 16: NUT, FLANGE (10MM) (10MM) 249201-001 $0.78 17: WASHER, PLAIN (8MM) (8MM) 249244-001 $0.35 18: BOLT, FLANGE (6X12) (6x12) 253333-001 $0.57 19: BOLT, FLANGE (8X60) 253529-001 $0.93 20: BOLT,FLANGE (8X65) 363877-001 $1.89
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SHOE SET, BRAKE 184909-001 $27.60 2: INDICATOR, RR. BRAKE 142111-001 $3.56 3: SPRING, RR. 142197-001 $2.09 4: GEAR, SPEEDOMETER 140110-001 $19.29 5: WASHER 140181-001 $1.40 6: PANEL SUB, FR. BRAKE 139034-001 $97.80 7: DUST SEAL, BRAKE CAM 136988-001 $1.80 8: CAM, FR. BRAKE 137055-001 $17.22 9: ARM, FR. BRAKE 136115-001 $12.00 9: ARM, FR. BRAKE 136124-001 $11.31 10: SPRING, FR. 136227-001 $3.27 11: SPRING, FR. 136230-001 $2.40 12: WASHER A Area Code AC 239566-001 $1.04 13: OIL SEAL (54X66X7) 243171-001 $7.29 14: SCREW, OVAL (5X16) 247711-001 $0.40 15: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57 16: PIN, COTTER (2.0X35) (2.0x22) 249381-001 $0.38 17: JOINT, BRAKE ARM 253111-001 $0.49 18: NUT B
253113-001 $1.40 19: BOLT, FLANGE (6X35) (6X35) 253388-001 $0.62
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: REFLECTOR, FR. 158192-001 $11.16 2: GROMMET, WIRE 136466-001 $6.04 3: FENDER, FR. *NH1* (BLACK) 117195-001 $122.28 3: FENDER, FR. *R107CU*
(CANDY BOURGOGNE RED) 117197-001 $122.28 4: NUT, FLANGE (5MM) (5MM) 249190-001 $0.42 5: WASHER, PLAIN (6MM) 249306-001 $0.25 6: BOLT, FLANGE (6X16) (6x16) 253345-001 $0.58
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: DISCONTINUED (SHOWA) 125536-001 $999.99 2: SPRING, FR. FORK (SHOWA) 124117-001 $43.53 3: PIPE, FR. FORK (SHOWA) 124793-001 $182.36 4: RING, BACK-UP 122948-001 $4.20 5: SPRING, FR. (SHOWA) 122916-001 $2.44 6: CASE, R. (LOWER) (LOWER) 123390-001 $155.31 7: PIECE, OIL LOCKING
123658-001 $16.80 8: RING, PISTON
(SHOWA) 123810-001 $5.15 9: PIPE, SEAT
(SHOWA) 122411-001 $34.78 10: SEAL SET, FR. FORK 122521-001 $15.95 11: FORK ASSY., L. FR. 122866-001 $306.96 12: CASE, L. (LOWER) (SHOWA) 56325-001 $157.00 13: BOLT, SOCKET (8MM) 234017-001 $3.27 14: GASKET, FR. 239817-001 $1.29 15: WASHER (8MM) 239835-001 $1.67 16: RING, OIL SEAL STOP 240105-001 $3.27 17: DUST SEAL 243343-001 $10.38 18: BOLT, HEX. (6X8) 245590-001 $0.52 20: O-RING (23X2.8) 249810-001 $0.76
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: TUBE (275/300-18) (DUNLOP) (2.75/3.00/3.60-18) 144313-001 $7.84 2: FLAP, TIRE (1.40X18) (1.40X18 DUNLOP) 144340-001 $4.00 3: AXLE, FR. WHEEL 142007-001 $18.35 4: COLR, FR. WHEEL SIDE 140329-001 $7.16 5: HUB, FR. WHEEL 140474-001 $179.02 6: BALANCER (20G) (20G) 140589-001 $3.04 7: COLLAR, FR. 140752-001 $5.40 8: WHEEL SET, FR. 140953-001 $644.67 9: RIM, RR. WHEEL 145269-001 $70.44 10: TIRE (90/100-18) (90/100-18) (54S) (DUNLOP) 139774-001 $83.81 11: NUT, U (14MM) (14MM) 236659-001 $3.76 12: OIL SEAL (26X42X7) 243232-001 $6.45 14: BEARING (6302UU) 254312-001 $10.31 15: SPOKE SET A (10X159) (10X160.5) (INSIDE) 254848-001 $1.89 16: SPOKE SET A (10X160) (OUTSIDE) 254960-001 $1.89
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: GASKET 223748-001 $4.22 2: PETCOCK ASSY. 227722-001 $69.09 3: SCREEN 227988-001 $19.47 4: CUP SET 228068-001 $17.87 5: O-RING (10.6X1.3) (10.6X1.3) 224124-001 $1.98 6: FILTER, CUP 228342-001 $11.33 8: TANK *NH1* (TYPE7)
(TYPE7) (WL) (BLACK) Area Code A 49508-001 $612.71 8: TANK SET *R107CU*
(TYPE6) (WL) (CANDY BOURGOFNE RED) Area Code A 49517-001 $612.71 8: TANK *NH1* (TYPE7)
(TYPE7) (WL) (BLACK) Area Code AC 49558-001 $632.15 8: TANK SET *R107CU*
(TYPE6) (WL) (CANDY BOURGOFNE RED) Area Code AC 49559-001 $632.15 9: RUBBER, FR.
77564-001 $2.67 10: RUBBER, RR. 77476-001 $12.69 11: CAP, FUEL FILLER 76878-001 $72.75 11: CAP, FUEL FILLER 77007-001 $57.82 12: TUBE, FUEL 78064-001 $5.02 14: COLLAR 237007-001 $4.49 15: CLIP, TUBE (B10) (B10) 250433-001 $0.68 16: BOLT, FLANGE (8X22) (8X22) 253483-001 $0.83
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: FORK, R. GEARSHIFT 50338-001 $44.56 2: FORK, L. GEARSHIFT 50548-001 $44.56 3: FORK 50572-001 $38.27 4: SHAFT 50451-001 $9.07 5: DRUM, GEARSHIFT 49790-001 $68.36 6: PIN, GEARSHIFT DRUM 177774-001 $3.65 7: STOPPER
177876-001 $9.44 8: PLATE
178009-001 $5.82
8: PLATE, DRUM STOPPER 178022-001 $5.08 9: SPRING 178080-001 $2.36 10: SPINDLE, GEARSHIFT 178395-001 $54.00 11: SPRING 178620-001 $1.58 12: SPRING 178647-001 $3.45 13: PIN 176663-001 $2.53 14: ROTOR 154159-001 $1.49 15: BOLT 80740-001 $1.20
16: WASHER, DRUM STOPPER 2327-001 $1.27
17: OIL SEAL
(ARAI) 243078-001 $2.56 18: BOLT, FLANGE (6X20) (6x20) 253356-001 $0.48
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CABLE A, THROTTLE 77931-001 $16.81 2: CABLE B, THROTTLE 76132-001 $16.81 3: CABLE, CHOKE 75391-001 $17.38 4: CABLE, CLUTCH 59819-001 $18.32 5: SWITCH, STARTER KILL 156310-001 $78.53 6: SWITCH, TURN SIGNAL 156704-001 $91.04 7: SWITCH, FR. LEVER 155402-001 $13.44 8: CABLE, FR. BRAKE 136439-001 $18.96 9: GRIP, R. 120394-001 $16.82 11: GRIP, R. HANDLE 120826-001 $8.96 12: GRIP, L. HANDLE 120917-001 $8.96 13: COVER, R. 121098-001 $6.09 14: COVER, L. 121146-001 $5.18 15: LEVER, R. HANDLEBAR 119446-001 $19.67 16: LEVER, L. HANDLEBAR 119591-001 $17.69 17: BOLT, CABLE ADJ. 119751-001 $5.11 18: BOLT 119754-001 $5.22 19: MIRROR ASSY., R. 82371-001 $43.48 20: MIRROR ASSY., L. 82604-001 $41.22 21: BOLT 233849-001 $2.16 22: NUT, CAP (6MM) (6MM) 236016-001 $1.58 23: NUT, FIXING 236977-001 $4.67 24: BAND, WIRE 2436-001 $2.58 25: SCREW-WASHER (5X25) 248024-001 $0.55 26: SCREW-WASHER (5X28) 248028-001 $0.53 27: SCREW-WASHER (5X35) 248037-001 $0.55
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: LOCK SET 157057-001 $144.89 1: LOCK SET Area Code AC 157058-001 $144.89 2: SWITCH, COMBINATION 157522-001 $43.27 3: KEY, BLANK (TYPE1) (TYPE1) 156162-001 $6.60 3: KEY, BLANK (TYPE2) (TYPE2) 156189-001 $6.60 4: HANDLEBAR Area Code A 54988-001 $60.04 5: WEIGHT, HANDLEBAR (B) 53139-001 $14.05 6: WEIGHT, HANDLEBAR 53110-001 $13.55 7: RUBBER A 54631-001 $2.51 8: RING 54595-001 $3.93 9: HOLDER, HANDLE 54795-001 $17.71 10: CVR, IGNITION SWITCH 121346-001 $12.38 11: BRIDGE, FORK TOP 119069-001 $108.00 12: SCREW, OVAL (6X65) (6X65) 235980-001 $3.15 13: NUT, STEERING STEM 236546-001 $4.67 14: WASHER 238998-001 $1.65 15: CAP, SOCKET BOLT 244642-001 $2.18 16: SCREW, PAN (6X12) 247353-001 $0.40 17: NUT, FLANGE (8MM) (8MM) 2299-001 $0.57 18: BOLT, FLANGE (8X55) (8X55) 254479-001 $1.23 19: BOLT, SOCKET (8X32) (8X32) 254624-001 $1.07
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: HEADLIGHT ASSY. 161791-001 $88.85 2: RIM, HEADLIGHT 161929-001 $41.04 3: SCREW (4MM) 162008-001 $3.27 4: SPRING 162083-001 $1.15 5: NUT 162190-001 $1.60 6: WASHER 162208-001 $1.55 7: HEADLIGHT UNIT (12V 50/35W) 162239-001 $40.06 8: NUT, UNIT HOLDER
160490-001 $1.67 9: COVER, SCREW 160567-001 $1.15 10: HORN ASSY. (HIGH) (BLACK) 150434-001 $38.15 11: CASE *NH1*
115064-001 $51.31
12: COLR, HEADLIGHT CASE 115185-001 $3.11 13: NUT, L. 115221-001 $8.80 14: COLLAR 115247-001 $6.31 15: RUBBER Area Code AC 115251-001 $2.18 16: STAY, HEADLIGHT 115488-001 $120.24 17: BOOT 115536-001 $1.47 18: BOLT (12X25) (12X25) 234712-001 $14.35 19: COLLAR (6.2X11) (6.2X11) 238791-001 $3.64 20: SCREW, PAN (5X8) 247224-001 $0.37 21: SCREW-WASHER (5X16) 248012-001 $0.48 22: BOLT, FLANGE (6X12) (6x12) 253336-001 $0.52 23: BOLT, FLANGE (6X25) (6x25) 254107-001 $0.68
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: COVER, L. CASE 198727-001 $113.93 2: SPACER, L. SIDE 199329-001 $53.05 3: GASKET, L. 199541-001 $4.76 4: GASKET, L. 199649-001 $8.88 5: PLATE 175912-001 $1.80 6: CAP, ALTERNATOR 79623-001 $7.07 7: CAP (30MM) (30MM) 79675-001 $12.11 8: O-RING (27.4X2.4) (27.4X2.4) 243926-001 $4.09 8: O-RING (27.4X2.4) (ARAI) 243789-001 $4.76 9: O-RING (13.8X2.5) 243849-001 $2.78 9: O-RING (13.8X2.5) (13.8X2.5) 243878-001 $2.31 10: BOLT, HEX. (6X10) (6X10) 245593-001 $0.52 11: DOWEL PIN (8X14) (8x14) 2267-001 $0.88 12: BOLT, FLANGE (6X20) (6x20) 2300-001 $0.70 13: BOLT, FLANGE (6X40) (6x40) 2484-001 $0.90 14: BOLT, FLANGE (6X50) (6x50) 2271-001 $1.05 15: BOLT, FLANGE (6X65) 254130-001 $1.24
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: MARK, R. (TYPE6) (TYPE6) 49464-001 $15.02 1: MARK, R. (TYPE7) (TYPE7) 73351-001 $15.02 2: MARK, L. (TYPE6) (TYPE6) 73374-001 $9.62 2: MARK, L. (TYPE7) (TYPE7) 73405-001 $9.62 4: MARK, R. (TYPE1) (TYPE1) 92200-001 $15.71 4: MARK, R. (TYPE2) (TYPE2) 92201-001 $23.18 6: MARK, L. (TYPE1) (TYPE1) 92949-001 $15.71 6: MARK, L. (TYPE2) (TYPE2) 92950-001 $23.18 7: MARK, RR. (TYPE6) (TYPE6) 91057-001 $8.09 7: MARK, RR. (TYPE7) (TYPE7) 91058-001 $8.09
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: JOINT, EX. PIPE 76485-001 $20.07 2: COLR, EX. PIPE JOINT 76786-001 $3.95 3: GASKET, EX. PIPE (A) 76424-001 $2.36 5: PROTECTOR, MUFFLER 70310-001 $20.93 6: COLLAR, R. MUFF MT 69727-001 $7.75 7: BAND, EX. PIPE 72220-001 $21.11 8: GASKET, MUFFLER 71442-001 $7.13 9: MUFFLER, L. EX. 71569-001 $252.24 10: COLLAR, L. 70993-001 $7.75 11: RUBBER 129183-001 $3.53 12: RUBBER 128003-001 $2.44 13: BOLT, FLANGE (6X6) (6X6) 234774-001 $1.35 14: NUT, CAP (6MM) 236568-001 $4.53 15: BOLT, FLANGE (8X20) (8X20) 253477-001 $0.70
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: PUMP ASSY., OIL 213747-001 $120.35 5: GASKET, OIL PUMP
(YAMADA) 214100-001 $1.45 6: GEAR A (40T)
(40T) 214159-001 $40.35 8: ROTOR, OIL PUMP
(INNER) 214711-001 $9.04 9: ROTOR, OIL PUMP
214737-001 $12.20 10: HOLDER, SCREEN 214892-001 $5.47 11: SCREEN, OIL FILTER 214910-001 $5.58 12: O-RING (6X3) 244177-001 $1.53 13: BOLT, HEX. (5X20) Area Code AN 245578-001 $0.37 14: SCREW, PAN (5X10) (5x10) 247228-001 $0.37 15: SCREW, FLAT (6X32) (6X32) 247612-001 $0.55 16: PIN C, DOWEL (4X6.5) (4X6.5) 249464-001 $0.80
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: PEDAL, GEARSHIFT 176984-001 $24.24
2: RUBBER, CHANGE PEDAL 177228-001 $2.13
3: SWITCH, RR. STOP 155484-001 $11.84 4: SPRING, STOP SWITCH 155668-001 $3.00 5: COVER, RR. 142798-001 $3.89 6: ROD, RR. BRAKE 141287-001 $11.96 7: PEDAL, RR. BRAKE 135582-001 $47.25 8: SPRING, BRAKE PEDAL 134118-001 $6.11 9: SHAFT, RR. 134210-001 $43.96 10: BOLT, HEX. (6X25) 235388-001 $2.13 11: BOLT, HEX. (8X28) 245886-001 $0.70 12: NUT, HEX. (6MM) (6MM) 249039-001 $1.48 13: PIN, COTTER (2.0X12) 249378-001 $0.37
14: SPRING A, BRAKE ROD 253098-001 $0.53
15: JOINT, BRAKE ARM 253111-001 $0.49 16: NUT B 253113-001 $1.40 17: PIN, JOINT Fr_Sr_No_To KS002359 253116-001 $2.20 18: BOLT, FLANGE (6X20) 253359-001 $0.48
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SHOE SET, BRAKE 184788-001 $15.97 2: AXLE, RR. WHEEL 147427-001 $19.02 3: COLLAR, RR. 145843-001 $10.53 4: PANEL, RR. BRAKE 143293-001 $96.98 5: CAM, FR. BRAKE 143910-001 $15.76 6: INDICATOR, RR. BRAKE 142141-001 $3.69 7: SPRING, RR. 142197-001 $2.09 8: ARM, RR. BRAKE 142667-001 $12.18 9: RUBBER 142970-001 $1.64
10: DUST SEAL, BRAKE CAM 136988-001 $1.80 11: WASHER A Area Code AC 239566-001 $1.04 13: BOLT A 246213-001 $2.00 14: NUT, HEX. (8MM) (8MM) 5908-001 $0.47 15: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57 16: PIN, SPLIT (2.0X15) (2.0x15) 249379-001 $0.25 17: PIN, COTTER (2.0X35) (2.0x22) 249381-001 $0.38 18: BOLT, FLANGE (6X35) (6X35) 253388-001 $0.62
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: COLLAR, SETTING 115960-001 $4.36
2: RUBBER, SIDE SHELTER (B) 111994-001 $2.87 3: FENDER, RR.
101383-001 $99.67 4: BAG, OWNER'S MANUAL 92146-001 $14.91 5: BRKT, NUMBER PLATE 91446-001 $11.36 6: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57 7: WASHER, PLAIN (6MM) (6MM) 249239-001 $0.18 7: WASHER, PLAIN (6MM) (6MM) 249243-001 $0.18 8: WASHER, PLAIN (6MM) 249306-001 $0.25 9: BOLT, FLANGE (6X22) (6x22) 253361-001 $0.67 10: BOLT, FLANGE (6X25) (6X25) 253366-001 $0.68
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SHOCK ABSORBER, RR. (SHOWA) 57478-001 $177.36 2: COLLAR, RR. 54079-001 $2.47 3: COLLAR, RR. SHOCK 54093-001 $4.49 4: BUSH, RR. SHOCK 54456-001 $3.04 5: NUT, FLANGE (10MM) (10MM) 249201-001 $0.78 6: WASHER, FLAT (10MM) 249312-001 $0.49 7: BOLT,WASHER BASED (90105-10739-00 ) [BOLT,WASHER BASED] 342969-001 $3.10
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SPROCKET (33T) (33T) 148042-001 $63.66 2: WASHER (58X67X2)
(58X67X2) 148378-001 $3.27 3: COLR, RR. WHEEL SIDE 145783-001 $8.80 4: SPOKE SET B (9X133.0) 254992-001 $3.60 5: SPOKE SET B 254869-001 $3.60 6: COLLAR, RR. 144719-001 $9.45 7: WHEEL SET, RR. 144970-001 $512.20 8: RIM, RR. WHEEL 145337-001 $65.24 9: TIRE (120/90-16) (120/90-16) (63S) 144168-001 $102.90 10: TUBE, TIRE (4.60-16) (4.60S-16 YOKOHAMA) 144288-001 $18.59 11: FLAP, TIRE (2.15X16) (DUNLOP) 144345-001 $3.55 12: BALANCER (20G) (20G) 140589-001 $3.04 13: BOLT, FLANGE (10X66) (10X66) 234882-001 $4.25 14: NUT, U (10MM) (10MM) 236583-001 $2.96 15: NUT, U (14MM) (14MM) 236659-001 $3.76 16: WASHER, RR. AXLE 239100-001 $3.15 17: CIRCLIP (58MM) 240603-001 $3.22 18: OIL SEAL (28X42X7) (ARAI) 243494-001 $6.91 19: BEARING (6302UU) 254312-001 $10.31 20: HUB SUB-ASSY., RR. 144883-001 $317.75
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: COVER, R. CRANKCASE 198224-001 $132.25 2: GASKET, R. 199474-001 $10.48 3: DIPSTICK, OIL 215721-001 $8.04 4: LEVER, CLUTCH 58957-001 $26.11
5: SPRING, CLUTCH LEVER 60259-001 $2.51 6: RECEIVER 60510-001 $13.11 7: OIL SEAL (12X18X5) (12x18x5) (ARAI) 242941-001 $3.22 8: O-RING (18X3) 244003-001 $1.73 8: O-RING (18X3) (18X3) (ARAI) 244014-001 $1.69 9: DOWEL PIN (8X14) (8x14) 2267-001 $0.88 10: BOLT, FLANGE (6X40) (6x40) 2484-001 $0.90
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: LOCK ASSY., SEAT 104245-001 $48.58 2: PLATE
104256-001 $4.56 3: CABLE, SEAT LOCK 104338-001 $4.11 4: SEAT ASSY.
102697-001 $265.96 5: RUBBER, SEAT SETTING 103208-001 $3.45
6: RUBBER, SEAT 103210-001 $4.60 7: HOOK, SEAT CATCH 101661-001 $28.22 8: BOLT (6MM) (6MM) 80098-001 $4.36 9: CIRCLIP (6MM) (6MM) 240252-001 $1.16 10: BOLT, FLANGE (6X16) (6x16) 253345-001 $0.58
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: RUBBER
148610-001 $2.84 2: NUT, CLIP (4MM)
(4MM) 108040-001 $1.73 3: GROMMET, SEAT COWL 101640-001 $1.82 4: GROMMET, A/CLNR HSG 94405-001 $2.56 5: GROMMET, A/CLNR HSG 94402-001 $2.96 6: CVR *R107CU* (TYPE1)
(TYPE1) (WL) (CANDY BOURGDGNE RED) 94825-001 $182.84 6: CVR *NH1* (TYPE2)
(TYPE2) (WL) (BLACK) 94826-001 $182.84 7: COLR, COVER SETTING
Area Code A 93075-001 $3.22 8: COVER SET (TYPE1)
(TYPE1) (WL) 92519-001 $182.84 8: CVR *NH1* (TYPE2)
(TYPE2) (WL) (BLACK) 92520-001 $182.84 9: CVR *R107CU* (TYPE6)
(TYPE6) (WL) (CANDY BOURGDGNE RED) 91050-001 $66.13 9: CVR *NH1* (TYPE7) (TYPE7) (WL) (BLACK) 91051-001 $66.13 10: SCREW-WASHER (4X12) 247841-001 $0.48 11: BOLT, FLANGE (6X20) 253359-001 $0.48
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: COLLAR A, A/CLNR 231708-001 $3.49 2: BULB (12V3.4W2CP) (12V3.4W) (158) 152654-001 $2.27 3: SPEEDOMETER ASSY. (MPH) (NS) 153709-001 $274.24 4: RING, R. 152325-001 $21.33 5: RING, L. 152378-001 $21.33 6: SOCKET 152515-001 $30.35 7: SOCKET 152539-001 $9.05 8: RUBBER, METER 152715-001 $10.07 9: RUBBER 152752-001 $1.47 10: INDICATOR ASSY. 151983-001 $120.62 11: CABLE, SPEEDOMETER 138689-001 $17.67 12: CABLE, SPEEDOMETER (INNER) 138780-001 $3.77 13: BOLT, METER SETTING 235697-001 $2.02 14: NUT (8MM) (8MM) 236190-001 $1.82 15: WASHER (6.5X18) 239860-001 $1.44 16: NUT, CAP (6MM) (6MM) 249134-001 $0.80 17: WASHER, PLAIN (8MM) (8MM) 249244-001 $0.35
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: SWITCH, SIDE STAND 155914-001 $44.40 2: STAND, MAIN 129073-001 $63.31 3: SPRING, MAIN STAND
Area Code A 129202-001 $4.33 4: PLATE
Area Code A 129309-001 $4.22 5: SHAFT
Area Code A 129366-001 $9.40 6: BAR, SIDE STAND
129502-001 $52.56 7: SPRING, SIDE STAND 129802-001 $4.91 8: BAR, STEP 128167-001 $35.62 9: BOLT, HEX. (8X132) 79639-001 $3.85 10: BOLT 233351-001 $4.96 11: BOLT, SPECIAL (6X16) (6x16) 235311-001 $1.49 12: NUT, SIDE STAND 236139-001 $2.25 13: WASHER, PLAIN (8MM) (8MM) 249244-001 $0.35 14: PIN, COTTER (3.0X45) (3.0X45) 249394-001 $0.37
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CHAIN, STARTER 175715-001 $22.16 2: SPROCKET (38T) (38T) 175805-001 $56.36 3: CLUTCH OUTER 175927-001 $52.67 4: SPRING 176010-001 $3.36 5: CAP 176045-001 $2.87 6: PLATE 176062-001 $3.58 7: SUB-CABLE A 163945-001 $5.91 7: SUB-CABLE A Fr_Sr_No_From 2023651 163946-001 $4.78 8: CONTACT ASSY. (DAIICHI) 154105-001 $5.29 8: CONTACT 154110-001 $4.89 9: PLATE 154132-001 $3.07 10: O-RING (7X1.7) (7X1.7) 244108-001 $1.48 10: O-RING (7X1.6) 151420-001 $2.16 11: PIN, KNOCK (6X17.5) (6X17.5) 240757-001 $1.47 12: ROLLER (10.2X9.5) (10.2X9.5) 242493-001 $2.33 13: OIL SEAL (22X31X5) (22x31x5) (ARAI) 242987-001 $4.71 14: SCREW, FLAT (6X20) (6X20) 247598-001 $0.40 15: BOLT, FLANGE (6X12) (6x12) 253333-001 $0.57
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: MOTOR ASSY., STARTER (MITSUBA) 168708-001 $327.33 2: TERMINAL SET, BRUSH
(USE FOR MITSUBA STARTER) 168833-001 $14.29 3: SPROCKET
168849-001 $27.44
5: SPRING, CARBON BRUSH 168927-001 $2.20
6: BOLT, SETTING 168955-001 $3.73 7: HOLDER SET, BRUSH 168999-001 $14.29 8: RING
169016-001 $2.58 9: RING, SEAL 169008-001 $2.67
10: CABLE, STARTER MOTOR 162836-001 $24.35
11: COVER
162918-001 $5.60 12: CABLE
163267-001 $13.49 13: O-RING, PINION CAP 119372-001 $3.16 14: NUT-WASHER (6MM) (6MM) 79473-001 $1.53 15: O-RING 244184-001 $1.82 16: BOLT, FLANGE (6X25) (6X25) 254105-001 $0.83 17: BOLT, FLANGE (6X65) 254130-001 $1.24
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: RACE
131047-001 $7.20 2: STEM, STEERING *NH1* (BLACK) 119954-001 $150.89 3: RACE, STEERING CONE Area Code A 118553-001 $6.18 4: DUST SEAL 118583-001 $2.05 6: WASHER 118599-001 $1.91 7: THREAD 118657-001 $9.69 8: LOCK, HANDLEBAR (HONDALOCK) 117411-001 $27.62 9: SCREW (6X12) (6x12) 235781-001 $1.00 10: BALL (#6) (3/16) (3/16) 254331-001 $0.18 11: BOLT, FLANGE (8X40) (8X40) 254474-001 $1.07
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: HOLDER, R. STEP 129889-001 $89.36 2: PIN
127952-001 $3.16 3: BAR, R. MAIN STEP 128300-001 $13.49 4: BRACKET, R. STEP 128408-001 $19.24 5: PLATE 128410-001 $2.56 6: BRACKET, L. STEP 128507-001 $19.24 7: COLLAR (6.5X11X3) 128769-001 $2.09 10: COLLAR (6.4X10X7) (6.4X10X7) 127182-001 $1.22 12: BAR, L. MAIN STEP
127519-001 $13.49 13: RUBBER, MAIN STEP 127670-001 $6.58 14: HOLDER, L. STEP 127745-001 $89.36 15: RUBBER, PILLION STEP 127855-001 $8.71
17: BRACKET, L. 125921-001 $14.51 18: PLATE
125961-001 $1.95 19: BAR, R. PILLION STEP 126013-001 $13.71 20: BAR, L. PILLION STEP 126087-001 $13.71 21: BOLT, FLANGE (10X40) (10X40) 232924-001 $3.04 22: BOLT, FLANGE (10X50) (10X50) 233057-001 $3.15 23: BOLT, HEX. (6X12) (6X12) 245857-001 $0.60 23: BOLT, FLANGE (6X12) (6X12) 254097-001 $0.65 24: NUT, CAP (6MM) 249135-001 $0.49 25: WASHER, PLAIN (6MM) (6MM) 249243-001 $0.18 26: WASHER, PLAIN (8MM) (8MM) 249244-001 $0.35 27: PIN, COTTER (1.6X25) 249376-001 $0.42 29: PIN B 253125-001 $1.58 30: BOLT, FLANGE (8X38) (8X38) 253912-001 $0.83
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CHAIN SET, DRIVE
(DAIDO) 147543-001 $137.87 1: CHAIN SET, DRIVE
(RK EXCEL) 147544-001 $146.26 2: CASE, DRIVE CHAIN
148559-001 $46.29 3: ADJUSTER, CHAIN 149214-001 $20.91 4: RETAINER 147535-001 $8.45 5: ARM, RR. 142883-001 $8.53 7: BUSH, SWINGARM 56763-001 $10.53 8: COLLAR, R. SWINGARM 57014-001 $47.31 9: DUST SEAL (NOK) 58476-001 $6.44 10: SLIDER, CHAIN 58781-001 $31.69
11: WASHER, CHAIN SLIDER 58625-001 $1.51 12: SLIDER, CHAIN (LOWER) 58587-001 $9.40 13: SWINGARM SET 58653-001 $204.95 14: BOLT, RR. 234433-001 $23.27 15: NUT, U (14MM) (14MM) 236659-001 $3.76 16: WASHER 239333-001 $1.85 16: WASHER (6X20) 239347-001 $1.89 17: WASHER (6X9) 239364-001 $0.98 18: WASHER, RR. 239603-001 $1.91 19: BOLT A 246216-001 $2.29 20: SCREW, TAP (5X12) (5X12) 248357-001 $0.37 21: NUT, HEX. (6MM) (6MM) 6093-001 $0.50 22: NUT, HEX. (8MM) (8MM) 5908-001 $0.47 24: WASHER, SPRING (8MM) (8MM) 249352-001 $0.48 25: PIN, SPLIT (2.0X15) (2.0x15) 249379-001 $0.25 26: BOLT, FLANGE (6X10) (6x10) 253327-001 $0.55 27: BOLT, FLANGE (6X14)
(6x14) 253343-001 $0.49
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: GASKET, SEAL 159922-001 $1.85 2: TAILLIGHT UNIT 159142-001 $179.05 3: WIRE, TAILLIGHT 159465-001 $12.62 4: TAILLIGHT SUB-ASSY. 157634-001 $99.07 5: REFLECTOR, R. RR. 158224-001 $12.18 6: REFLECTOR, L. RR. 158247-001 $12.18 7: BULB (12V27/8W) (12V 27/8W) (STANLEY) 158592-001 $2.68 8: COLLAR, FR. FENDER 116041-001 $2.18 9: SCREW, TAP (5X12) 248710-001 $0.37 10: NUT, FLANGE (6MM) (6MM) 2298-001 $0.57
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: MAINSHAFT (13T) (13T) 61235-001 $62.45 2: COUNTERSHAFT (32T) (32T) 62522-001 $113.40 3: GEAR (37T) (37T) 61349-001 $67.82 4: BUSH (16.5MM) (16.5MM) 61341-001 $10.76 6: GEAR (21T) (21T) 50641-001 $44.98 7: GEAR (28T) (28T) 179171-001 $49.87 8: GEAR (24T) (24T) 179330-001 $55.62 9: GEAR (26T) (26T) Fr_Sr_No_From 5207693 179550-001 $50.24 10: GEAR (23T) (23T) 179772-001 $49.84 11: GEAR (21T) (21T) Fr_Sr_No_From 5207693 179902-001 $60.58 12: SPROCKET (14T) (14T) 51776-001 $27.78 13: PLATE A2, FIXING 51700-001 $2.89 14: COLLAR (15MM) (15MM) 51089-001 $3.60 15: WASHER (15MM) (15MM) 238023-001 $1.09 16: WASHER A (20MM) (20MM) 238239-001 $1.09 17: SET-RING (20MM) (20MM) 240288-001 $1.69 18: BEARING (22X47X14) (22X47X14) 241733-001 $28.31 19: BEARING (6202) 241824-001 $14.15 20: OIL SEAL (22X34X7) 243053-001 $3.11 21: BOLT, HEX. (6X10) (6X10) 245593-001 $0.52 22: BEARING (6304) 254210-001 $9.47
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: TURN SIGNAL ASSY.
(12V 32CP) 160762-001 $49.19 3: LENS, TURN SIGNAL
161045-001 $6.79 4: GASKET, LENS 161176-001 $3.76 7: TURN SIGNAL ASSY.
(12V 23W) 159860-001 $52.93 8: TURN SIGNAL ASSY.
(12V 23W) 159932-001 $52.93 11: BULB (12V23W32CP) (12V 23W) 158576-001 $2.25 12: STAY, R. RR. 132478-001 $9.25 13: STAY, L. RR. 132480-001 $9.25 14: NUT, FLANGE (10MM) (10MM) 236791-001 $3.15 15: SCREW, TAP (3X25) 245157-001 $1.58 16: BOLT, FLANGE (8X14) (8X14) 253463-001 $0.76
Created by eDocPrinter PDF Pro!!
Created by eDocPrinter PDF Pro!!
1: CUSHION
173617-001 $3.13 2: MODULE, IGN CONT
(CDI) (SHINDENGEN) 172045-001 $121.51 3: SUSPENSION 172500-001 $7.89 4: COIL, IGNITION 172576-001 $48.51 5: CAP ASSY. 171383-001 $11.78 6: RECTIFIER, REGULATOR 167400-001 $194.18 7: RECTIFIER, SILICON (STANLEY) 165969-001 $17.42 8: RECTIFIER 165974-001 $20.76 9: WIRE HARNESS 165246-001 $259.71 10: FUSE, SPARE 150674-001 $10.60 11: CASE, FUSE (2P) (2P) 150847-001 $6.27 12: RELAY, TURN SIGNAL (MITSUBA) 150993-001 $24.36 13: SUSPENSION
Area Code A 151028-001 $2.47 14: STAY, REGULATOR
132037-001 $15.31 15: BAND, WIRE HARNESS 240417-001 $2.78 16: BOLT, FLANGE (6X12) (6x12) 253337-001 $0.18 17: BOLT, FLANGE (6X16) (6x16) 2358-001 $0.62 18: FUSE, BLADE (10A) (10A) 255301-001 $0.50 19: FUSE, BLADE (20A) (20A) 255303-001 $0.50
