D A T A B A S EOracle SAP
for
Oracle database for SAP is safe, reliable and scalable
®
®
No. 19 Oracle for SAP, May 2010 www.oracle.com/sap
T E C H N O L O G Y U P D A T E
N E W
Request Exadata V2-Sun
Oracle Database Machine
for your SAP implementation NOW!
Now with the newest release of the Oracle Exadata Storage Server, you can also achieve extreme performance for transaction processing and consolidated mixed application workloads. Exadata Smart Flash Cache addresses the disk random I/O bottleneck problem by transparently moving hot data to Oracle’s Sun FlashFire cards. You get ten times faster I/O response time and use ten times fewer disks for business applications from Oracle and third-party providers.
Exadata Hybrid Columnar Compression
The most advanced data compression technologies are included in Oracle Exadata Storage Servers. Oracle Exadata Hybrid Columnar Compression can, on average, reduce the size of Data Warehousing tables by 10x, and archive tables by 50x. This offers significant savings on disk space for primary, standby and backup databases, and will improve the performance of Data Warehousing queries.
Benefits for SAP Customers
•
Extreme Performance for Business Warehouses—Improves both query performance and concurrency by offloading intensive query processing and data mining scoring from database servers and bringing it closer to the data.•
Extreme Performance for OLTP Applications—Addresses the disk random I/O bottleneck problem by transparently moving hot data to Sun FlashFire. You get ten times faster I/O response time and use ten times fewer disks for business applications from Oracle as well as third-party providers.•
Extreme Performance for Mixed Workloads—Allows you to consolidate data warehousing, transaction processing, and mixed workloads on a massively parallel server grid and eliminate the cost of third-party specialty hardware, security, and management solutions.UNVEILING
ORACLE EXADATA V2
The World’s First OLTP Database Machine
With Sun FlashFire Technology
ORACLE EXADATA V2
The World’s First OLTP Database Machine
With Sun FlashFire Technology
Operating System and version? Database version?
Database size?
SAP Application Modules and release level? Number and type of application servers running on the existing database server?
Number and type of dedicated application servers? Yes / No we are using BI Accelerator?
Name: Company: Address:
E-mail:
Please fill out the Oracle Exadata V2 for SAP request form and send (or fax) it to Faxnr.:
+49 6227 8398 199
To:
Dr. Christian Graf (SAP AG) and Mr. Gerhard Kuppler (Oracle)
Regarding:
Exadata V2 – Sun Oracle Database Machine
Dear Sirs;
The purpose of this request is to express our interest in adopting Exadata V2 – Sun Oracle
Database Machine for our SAP Applications and we are asking you for its immediate
release, once the Oracle Database 11
g
Release 2 for SAP is available.
Send this request to
[email protected]
and
[email protected]
(or fax this page to
+49 6227 8398 199)
and please answer the following questions about
your current Oracle / SAP configurations.
Oracle Corporation
Oracle DB for SAP GTC
Altrottstr. 31
D-69190 Walldorf
Germany
C O N T E N T S
11
3 Editorial
4 Oracle Database 11gRelease 2 for SAP
10 Oracle Real Application Testing (RAT) Option certified for SAP 14 Oracle Real Application Testing (RAT) at Stadtwerke Munich (SWM) 16 SAP Partitioning Engine
18 Relationship Interview – Oracle Database and SAP 20 Benchmark SAP on Oracle with Fujitsu
23 Benchmark SAP on Oracle Database 11gRelease 2 with Fujitsu 24 Benchmark SAP on Oracle-Solaris
28 SAP on Real Application Clusters (RAC) at République Française, Ministère de la Défense 30 SAP on Real Application Clusters (RAC) at Southwest Airlines
34 Oracle Database Vault for SAP customers
36 SAP on Real Application Clusters (RAC) at Coca-Cola Hellenic 39Oracle Index Compression at Tyson Foods
41 SAP on Real Application Clusters (RAC) at Sodexo Brazil 42 SAP on Real Application Clusters (RAC) at Verizon
44 SAP on Real Application Clusters (RAC) at Essent Netherlands 46 SAP on Oracle at Steelcase, HP-UX
50 Oracle Partner – Connectria
52 SAP on Oracle Database at Dow Corning
54 SAP on Real Application Clusters (RAC) at Bauerfeind 58 Hosting on Oracle at Freudenberg IT
61 Oracle Partner – Delta Consulting 62 Oracle Partner – All4IT Group 64 Oracle Data Guard – Freudenberg ITj
70Oracle Advanced Customer Services (ACS) for SAP 74SAP Fast Start with Oracle and HP
77 Oracle Partner – IS4IT, SAP on RAC
78 Useful links Oracle Database for SAP customers 79 Imprint
3 O r a c l e D a t a b a s e f o r S A P – T h e # 1 D a t a b a s e s a f e , r e l i a b l e , s c a l a b l e , o p t i m i z e d f o r S A P c u s t o m e r s
D E A R S A P C U S T O M E R ,
For 21 years Oracle Corporation and SAP AG has maintained an ongoing commitment to our joint customers and have long-standing reseller and customer support agreements in place, which provides enhanced access to Oracle database technology and world class customer support.
In this edition, we focus on Oracle Database 11gRelease 2, and the most important technologies that benefit SAP customers in terms of return on investment, space savings and performance.
Oracle Database 11gRelease 2 Enterprise Edition comes with a wide range of options to extend the world’s #1 database to help grow your business and meet your users’ performance, security and availability service level expectations.
The innovation continues with Oracle Database 11gRelease 2 to lower IT costs and deliver a higher quality of service by: • Consolidating business applications onto fast, reliable and scalable databases (Real Application Clusters RAC) • Maximizing availability and eliminating idle data center redundancy (RAC, Data Guard, online Patching) • Compressing data onto low cost storage partitions for faster performance (Oracle Advanced Compression) • Securely protecting information and enabling compliance (Oracle Advanced Compression, Oracle Database Vault) • Doubling DBA productivity and reducing the risk of change (Diagnostic Pack, integrated in BR* Tools and SAP DBA
Cockpit).
The Exadata V2 – Sun Oracle Database Machine – the world’s fastest for any type of database workload and the only database machine that does online transaction processing (OLTP). Oracle Exadata Storage Software runs on each storage server performing data-intensive processing that reduces the volume of data returned to database servers. Smart Scans, Storage Indexes, Data Mining Model Scoring and Hybrid Columnar Compression are all components of Oracle Exadata Storage Software that enable extreme performance.
If you would like to adopt Exadata V2 – Sun Oracle Database Machine for your SAP Applications please see the Exadata for SAP request form in this edition or on www.oracle.com/sap.
Read more about the benefits, why customers moved from single instance to Oracle Real Application Clusters for SAP (Coca Cola Hellenic) and why Oracle database has the best cost of ownership (Tyson Food, Partitioning and Compression). Compliance and security are getting more and more important today, please see the Oracle Database Vault for SAP article.
Please read more about the Oracle Advanced Customer Services (ACS) for SAP customers, including: database migrations, Oracle-to-Oracle (O2O), performance tuning, health check and internal training workshops. For more information or to see current and previous editions go to: www.oracle.com/sap.
We welcome your comments and questions, please contact us at: [email protected]
Sincerely
Gerhard Kuppler
Senior Director Corporate SAP Account, Oracle Corporation
S A P C E R T I F I E D O R A C L E D A T A B A S E 1 1g
R E L E A S E 2 F U N C T I O N A L I T Y
I N T R O D U C T I O N
Oracle Database 11gRelease 2 Enterprise Edition delivers industry leading performance, scalability, security and reliability on a choice of clustered or single-servers, running Windows, Linux, and UNIX. It provides comprehensive features to easily manage the most demanding transaction processing, business intelligence, and content management applications. Oracle Database 11gRelease 2 Enterprise Edition comes with a wide range of options to extend the world’s #1 database to help grow your business and meet your users performance, security and availability service level expectations.
SAP has certified Oracle Database 11gRelease 2 (please see SAP Note 1398634) with the following details:
Only SAP products based on SAP Kernel 6.40, 7.x and higher are certified with Oracle Database 11.2. The certification and rollout by SAP happens in three waves:
• End of March 2010 (wave 1): major UNIX plat-forms (AIX, HP-UX IA64, Solaris SPARC & x64) and Linux x64 were released (done)
• End of Q2/2010 (wave 2): Windows x64 and HP-UX PA-RISC platforms are planned to be released
• Windows IA64 tbd
Note:
A general release of Oracle Database 11.2 is not pro-vided for earlier SAP releases (SAP R/3 3.1I up to and including SAP R/3 4.6C). Similar to Oracle Database Version 10.2, there will only be a temporary 11.2 release in direct connection with an SAP upgrade project for these older SAP versions.
Oracle Database 11gRelease 2 provides customers more benefits: saving disk space with lower hardware costs, more performance, higher security, better manageability, exceeding productivity and at least in an outstanding high availability/disaster recovery for SAP applications.
The following provides a list of important features available for SAP customers today and many of them are unique to Oracle.
Oracle Real Application Clusters 11gRelease 2 The SAP release of Oracle Database 11.2 RAC occurs at the same time as the general release of Oracle Database 11.2 in the SAP environment. For information about Oracle RAC support, see SAP Note 527843. It contains important details about the released RAC configurations, like the fact that all used software stacks with 10gRAC will continue to stay in place and can be used with 11gRAC, so neither support for raw devices (not supported any more with 11.2) nor ASM is available for 11.2 RAC databases in SAP environ-ments.
OLTP Table Compression
Oracle Database 11gintroduced a new feature called OLTP Table Compression that allows data to be compressed during all types of data manipulation operations, including conventional DML such as INSERT and UPDATE. In addition, OLTP Table Compression reduces the associated compression overhead of write operations making it suitable for transactional or OLTP environments as well. OLTP Table Compression, therefore, extends the benefits of compression to all application workloads.
O r a c l e D a t a b a s e 1 1gR e l e a s e 2 f o r S A P 5
Oracle’s OLTP Table Compression, part of Advanced Compression, uses a unique compression algorithm that eliminates duplicate values within a database block, even across multiple columns. Compressed blocks contain a structure called a symbol table that maintains compression metadata. When a block is compressed, duplicate values are eliminated by first adding a single copy of the duplicate value to the symbol table. When compared with competing com-pression algorithms that maintain a global database symbol table, Oracle’s unique approach offers signifi-cant performance benefits by not introducing addi-tional I/O when accessing compressed data.
The benefits of OLTP Table Compression go beyond just on-disk storage savings. One significant advantage is Oracle’s ability to read compressed blocks directly without having to first uncompress the block. Therefore, there is no measurable performance degra-dation for accessing compressed data. In fact, in many cases performance may improve due to the reduction in I/O since Oracle will have to access fewer blocks. Further, the buffer cache will become more efficient by storing more data without having to add memory. Since Oracle 10.2.0.2, SAP has certified the use of Index compression to save disk space for indexes and reduce total database size on disk. Customer experi-ences show that even after a full database reorganiza-tion has taken place, an addireorganiza-tional 20% of total disk space reduction for the whole database can be achieved using index compression.
SecureFile Data Compression
SecureFiles is a new feature in Oracle Database 11g
that introduces a completely re-engineered large object (LOB) data type to dramatically improve performance, manageability, and ease of application development. SecureFiles data is compressed using industry standard compression algorithms. Compression not only results in significant savings in storage but also improved performance by reducing IO, buffer cache requirements, redo generation and encryption overhead. SecureFile compression provides significant storage and handles in-line and out-of-line LOB data which are getting more and more important in SAP applications and are widely used in SAP products such as SAP CRM, SAP XI, SAP NetWeaver Portal, and even in SAP ERP. Almost all non-cluster tables in SAP ERP use out-of-line LOBs that are unique to the Oracle database.
RMAN Backup Compression
The continuous growth in enterprise databases creates an enormous challenge to database administrators. The storage requirements for maintaining database backups and the performance of the backup procedures are directly impacted by database size. Oracle Advan-ced Compression includes compression technology that can dramatically reduce the storage requirements for backup data. Due to RMAN’s tight integration with Oracle Database, RMAN backup (widely used by SAP customers) data is compressed before it is written to disk or tape and doesn’t need to be uncom-pressed before recovery – providing an enormous reduction in storage costs.
Data Pump Compression
The ability to compress the metadata associated with a Data Pump job was first provided in Oracle Data-base 10gRelease 2. In Oracle Database 11g, this compression capability has been extended so that table data can be compressed on export. Data Pump compression is an inline operation, so the reduced dump file size means a significant savings in disk space. Unlike operating system or file system com-pression utilities, Data Pump comcom-pression is fully inline on the import side as well, so there is no need to uncompress a dump file before importing it. The compressed dump file sets are automatically decom-pressed during import without any additional steps by the Database Administrator.
Data Guard Network Compression
Data Guard provides the management, monitoring, and automation software infrastructure to create, maintain, and monitor one or more standby databa-ses to protect enterprise data from failures, disasters, errors, and data corruptions. Data Guard maintains synchronization of primary and standby databases using redo data (the information required to recover a transaction). As transactions occur in the primary database, redo data is generated and written to the local redo log files. Data Guard Redo Transport Services are used to transfer this redo data to the standby site(s).
11
g
With Advanced Compression, redo data may be transmitted in a compressed format to reduce the network bandwith in an efficient way. Redo transport compression is no longer limited to compressing redo data only when a redo gap is being resolved. When compression is enabled for a destination, all redo data sent to that destination is compressed. Deferred Segment Creation
Beginning in Oracle Database 11gRelease 2, when creating a table in a locally managed tablespace, table segment creation is deferred until the first row is inserted. In addition, creation of segments is deferred for any LOB columns of the table, any indexes created implicitly as part of table creation, and any indexes subsequently explicitly created on the table. The advantages of this space allocation method for customers running Oracle database underneath their SAP applications are the following:
• Empty database objects will not consume any disk space
• Very important for SAP environments as 60-70% of all tables, lobs, indexes and partitions in an SAP installation are empty
• Makes database installation for SAP a lot faster because creation of empty tables, LOBs, and indexes are dramatically faster.
• Oracle Data Dictionary Space queries run substantially faster
Enhanced Add COLUMN Functionality Before Oracle 11gadding new columns with DEFAULT values and NOT NULL constraint required both an exclusive lock on the table and the default value to be stored in all existing records.
Now in Oracle 11gthe database can optimize the resource usage and storage requirements for this operation, default values of columns are maintained in the data dictionary for columns specified as NOT NULL. Adding new columns with DEFAULT values and NOT NULL constraint no longer requires the default value to be stored in all existing records. This not only enables a schema modification in sub-seconds and independent of the existing data volume, it also consumes no space. Especially for large tables, updating table column results in reduced execution time and space saving.
Because add column is very common within SAP BW applications and SAP upgrades, enhanced ADD Column Functionality leads to:
• factor 10-20 performance improvement for SAP BW during add column process
• saving large amount of disk space
Bitmap Indexes
Especially SAP NetWeaver Business Warehouse customers now can use Bitmap Indexes. Bitmap Indexes are high densed indexes which need minimal disk space. This reduces the size of a database very effectively. Oracle is the only database vendor who offers disk-based Bitmap Indexes.
Variable Length Datatype Representation
Also Oracle is the only vendor to provide a compre-hensive Variable Length Datatype Representation. With Variable Length Datatype Representation minimum disk space is allocated. Bitmap Indexes and Variable Length Datatype Representation are the main reasons why the Oracle database is smaller than databases from other vendors.
Compared to Oracle Database 10gthe listed Oracle Database 11gfeatures give the following results: First the size of the 11.2 database will be 3 times smaller. So a 10.2 database with a size of 3 Terabytes will only consume 1 TB in disk space with 11.2. Second backups will also be smaller – up to 10 times smaller.
7
SecureFile Performance
SecureFiles offer the best solution for storing file content, such as images, audio, video, PDFs, and spreadsheets. Traditionally, relational data is stored in a database, while unstructured content—both semi-structured and unstructured—is stored as files in file systems. SecureFiles is a major paradigm shift in the choice of files storage. SecureFiles is specifically engineered to deliver high performance for file data comparable to that of traditional file systems, while retaining the advantages of the Oracle Database. SecureFiles offers the best database and file system architecture attributes for storing unstructured content. SAP customers benefit from SecureFiles because of
• Significantly faster access times compared to LOBs in SAP environments
• Increased transaction throughput on SAP cluster tables especially with RAC
• Prerequisite for compression of SAP tables containing LOBs (e.g. cluster tables)
Overall transaction throughput increases when LOB data is stored in SecureFiles (see figure below). LOB data stored in SecureFiles delivers equal or better performance compared with LOB data stored in LONG or BasicFiles (LOB implementation prior to 11g). SecureFiles improve dramatically the scalability of SAP applications running against Oracle Database 11gRAC but also Oracle Database 11gSingle Instance benefits substantially from SecureFiles. Therefore a clear recommendation is given to migrate all existing LONG and Basicfile LOB data to SecureFiles.Hi Tablespace Encryption
On many agendas security is in the forefront and for customers becoming much more important. Oracle has a lot of features in the area of security. Especially for SAP customers it is now very easy to encrypt sen-sitive data. Included within the Advanced Encryption is the technology to encrypt all data in a tablespace. Prior to 11g, Oracle provided security features such as Column Encryption through Transparent Data Encryption (TDE) and Client Server (SAP Application Server) Network Encryption.g
Additional Encryption
Advanced Encryption within 11gincludes RMAN Backup Encryption, so no one can read data from a (stolen) backup. In addition customers can easily encrypt export file with Oracle Data Pump unstruc-tured LOB data with SecureFile Encryption. DG Secure Network Transport
Data Guard provides a secure environment and prevents tampering with redo data as it is being transferred to the standby database. To enable secure transmission of redo data, set up every database in the Data Guard configuration to use a password file, and set the password for the SYS user identically on every system.
More Security – Database Vault
Oracle Database Vault is also certified for use with SAP applications. With Oracle Database Vault, pro-tective realms around SAP application database objects can be established to prevent privileged database users from accessing sensitive data and to enforce separation of duties among privileged database users.
row size in KB
LONGs (9.2,10.2) LOBs (10.2,11.2) Securefiles 11.2
Per
formance
Improvement Factor
SAP VBDATA Throughput (Insert/Read/Delete)
Real Application Testing (RAT)
• Database Replay provides DBAs and system admi-nistrators with the ability to faithfully, accurately and realistically rerun actual production work-loads, including online user and batch workwork-loads, in test environments. By capturing the full data-base workload from production systems, including all concurrency, dependencies and timing, Database Replay enables you to realistically test system changes by essentially recreating production work-loads on the test system, something that a set of scripts can never duplicate. With Database Replay, DBAs and system administrators can test: Database upgrades, patches, parameter, schema changes, etc.
• Configuration changes such as conversion from a single instance to RAC, ASM, etc.
• Storage, network, interconnect changes
• Operating system, hardware migrations, patches, upgrades, parameter changes
• SQL Performance Analyzer (SPA) can predict and prevent SQL execution performance problems caused by environment changes. SQL Performance Analyzer provides a granular view of the impact of environment changes on SQL execution plans and statistics by running the SQL statements serially before and after the changes
Direct NFS
With Oracle Database 11gRelease 2, you can configure Oracle Database to access NAS devices directly using Oracle Direct NFS Client, rather than using the operating system kernel NFS client. Oracle Database will access files stored on the NFS server directly through the integrated Direct NFS Client eliminating the overhead imposed by the operating system kernel NFS. These files are also accessible via the operating system kernel NFS client thereby allowing seamless administration.
SAP customers can benefit from Direct NFS in the following way:
• Improves throughput of NAS solutions such as NetApp
• Up to 50% more database throughput in NAS environments with multiple NICs
• Up to 20% CPU savings on database server
• Works for Single Instance and Real Application Clusters (RAC)
• Works for UNIX/Linux and Windows Platforms
• Highly Available Network Solution
• Faster, easier and more available than any OS or NAS based bonding or trunking solution
• Direct NFS with NAS may provide higher throughput than traditional, more complex SAN solutions
• Superior to any bonding solution – faster and easier
• Better throughput than most SAN solutions
Online Patching
A regular RDBMS patch is comprised of one or more object files and/or libraries. Installing a regular patch requires shutting down the RDBMS instance, re-linking the oracle binary, and restarting the instance; uninstalling a regular patch requires the same steps. With Oracle Database 11g, it is possible to install single or bundle patches completely online, without requiring the database instance to be shut down, and without requiring RAC or Data Guard configurations. With online patching, which is integrated with OPatch, each process associated with the instance checks for patched code at a safe execution point, and then copies the code into its process space. Snapshot Standby
Easy conversion of a physical standby database to a reporting database – A physical standby database can be opened read/write for reporting purposes, and then flashed back to a point in the past to be easily conver-ted back to a physical standby database. At this point, Data Guard automatically synchronizes the standby database with the primary database. This allows the physical standby database to be utilized for read/write reporting activities for SAP applications e.g. NetWeaver BI.
oracle.com/sap
[email protected]
Only Oracle Database 11
g
Release 2 provides for
SAP customers
Copyright © 2010, Oracle. All rights reserved. Oracle is a registered trademark of Oracle Corporation and/or its a affiliates. Other names may be trademarks of their respective owners.
Oracle – the # 1 Database for Deploying SAP Applications
Oracle other DBs
Best Performance & Scalability
• Fully integrated, platform independent active-active clustering solution for both SAP and database through RAC and Clusterware/SAPCTL
• Dictionary only add column with default
• High Performance NAS Storage through Direct NFS
Best Deployment Flexibility
• Online Patching
• Real Application Testing Option
Best Availability & Reliability
• Updatable Standby Database
• Fully integrated, platform independent active-active clustering solution for both SAP and database through RAC and Clusterware/SAPCTL
Best Support for Very Large Databases
• RMAN Backup Compression
• SecureFile out-of-line LOB data compression
• Deferred Segments Creation
• Disk-Based Bitmap Indexes
• Dictionary only add column with default
• High Performance NAS Storage through Direct NFS
Best Database Security
• Tablespace Encryption
• RMAN Backup Encryption
• Data Guard Secure Network Transport
• Database Vault
Best Manageability & Self-Management
• Real Application Testing Option
• Online Patching
R E A L A P P L I C A T I O N T E S T I N G C E R T I F I E D F O R S A P
Making a change to the SAP database can represent a significant risk to an organization. The effects of an unexpected problem could be widely felt and have serious consequences. For this reason, testing of chan-ges prior to production deployment is considered critical. The cost involved in testing using traditional methods can be very high both in time and money. Even after testing, many problems will only be dis-covered in production, and as a result end-users will suffer from poor performance or possibly even outages. Oracle now has a new and unique testing tool for the Oracle Database called Real Application Testing. This Database option is comprised of two complemen-tary features, SQL Performance Analyzer (SPA) and Database Replay. Together, these features can help ensure that database changes do not negatively impact SAP availability and performance. They significantly improve the quality and lower the cost of testing changes to the SAP database system.
SQL Performance Analyzer (SPA)
One of the key tasks for a DBA is to tune SQL state-ments for optimal performance. Changes to database systems (such as optimizer statistics refresh, database
upgrades, and patches) can cause the performance of previously well tuned SQL statements to regress, which can dramatically impact system performance for end-users. Until now, it was difficult if not impossible to predict how day to day operational changes to the database will impact application SQL performance. With SQL Performance Analyzer, or SPA, you can now know exactly how SQL will behave after routine system changes.
SPA automatically captures production SQL state-ments from your SAP database and re-executes them following a change to measure the impact. The state-ments are executed serially, in isolation from each other and regressed statements are automatically hig-hlighted. Integration with SQL Plan Management and SQL Tuning Advisor enables automatic tuning of these statements to address any regressions prior to a change being implemented in production. Orchestration of the entire SPA process can be done using Enterprise Manager, which provides a number of workflows for testing common operations such as Database Upgrades. There is also a Guided Workflow which enables custom experiments to be conducted.
11
Real Application Testing was introduced in the 11grelease of the Oracle Database, however, SQL Performance Analyzer is also available for previous releases of the Oracle Database. Consequently, SQL Performance Analyzer can be used to test changes in SAP environments even if there are no immediate plans to move to Oracle Database 11g Release 2. Some examples of changes that could be assessed using SQL Performance Analyzer in SAP environ-ments are:
• Upgrade SAP Database from Oracle Database 10g
Release 2 to 11gRelease 2 • Install Database Patchset
• Migration from single instance to RAC • Implement Partitioning
• Implement Advanced Compression
• Changes to FIX_CONTROLS parameter settings • Creation of Histograms on SAP tables
Some of these changes can actually be tested safely on the production system, therefore removing the need for establishing a separate test environment. There are no SAP specific patches required to use SQL Performance Analyzer. Further general informa-tion on using SQL Performance Analyzer can be found in the following documents:
Technical White Paper: SQL Performance Analyzer Viewlet: SQL Performance Analyzer in Oracle Data-base 11g
Oracle Database Real Application Testing User’s Guide
Database Replay
Load testing today is generally done using tools that allow testing teams to generate synthetic workloads based on what they expect users to do on a system. These workloads can then be replayed by application virtual users, which simulate the end users by sub-mitting requests to the application. Although widely used, this approach has a number of shortcomings when it comes to testing database level changes:
• Creating the synthetic workload can take a considerable time and requires programming expertise
• User behaviour is not well understood, so many possible workflows are often missed in the synthetic tests
• Production scale database concurrency is near impossible to simulate with these tools
• A full application stack is required for testing as these tools simulate end users
Database Replay makes it possible to capture a workload on a production system with negligible performance overhead and replay it on a test system with the exact timing, concurrency, and transaction characteristics of the original workload. Database Replay is suitable for testing changes to the database tier and anything below it, such as storage or OS platform. This also means that tiers such as the Web and Application Server tier are not required in the test environment. The Database Replay capture process has been backported and certified for SAP databases running on Oracle Database 10gRelease 2 (10.2.0.4).
Changes that Database Replay could be used to validate include:
• SAP Database upgrade from 10gR2 (10.2.0.4) to 11gR2
• Platform migration such as from Windows to Oracle Solaris
• Database Patchset install
• Changes to FIX_CONTROLS parameter settings • Schema changes
• Migration from single instance to RAC • Implement Partitioning
• Implement Advanced Compression • Database storage changes (e.g. Direct NFS) • Tablespace encryption
• Object Reorganization
Database Replay is included with Oracle Database 11g. In addition, Database Replay capture can be run against Oracle Database 10.2.0.4 and higher version. To use Database Replay in SAP environments, Patch 9233285 is required on the Replay database. For more technical information on using Database Replay please refer to the following whitepaper:
Technical White Paper: Database Replay Viewlet: Database Replay in Oracle Database 11g
Oracle Database Real Application Testing User’s Guide
Results of Testing
The Oracle/SAP Development Team recently conclu-ded comprehensive testing of SAP applications using both SQL Performance Analyzer and Database Replay. The testing consisted of SAP ERP and BW workloads running in-house on the ABAP stack. Further testing was undertaken at a large utilities customer running the SAP IS-U (Industry Specific Utilities) module. The objective was to use Real Application Testing to measure the effects of Advanced Compression for OLTP and SecureFiles on DML operations for SAP ERP. The testing activity consisted of using Database Replay to capture a production workload from a 10.2.0.4 SAP database. This workload was then replayed multiple times against both compressed and non-compressed Oracle Database 11gRelease 2 databases. Key AWR metrics from the replays are shown below. Load Profile Redo size/s Logical reads/s Block changes/s Physical reads/s Physical writes/s User calls/s Parses/s Hard parses/s W/A MB processed/s Executes/s Transactions/s
Instance Efficiency Percentages (Target 100%) Buffer Hit %
Library Hit %
Host CPU (CPUs: 8 Cores: 8 Sockets: 4) %User %System %WIO %Idle 1) 153456,80 18748,80 459,70 3820,60 74,60 1806,50 247,20 32,70 12,50 2572,10 4,50 81,91 95,08 12,30 4,40 12,30 81,80 203407,00 18210,00 595,20 1635,80 72,00 2042,10 254,10 33,60 12,70 2834,60 4,80 91,79 95,52 12,80 4,20 11,20 81,80 32,55 -2,87 29,48 -57,18 -3,49 13,04 2,79 2,75 1,60 10,21 6,67 12,06 0,46 4,07 -4,55 -8,94 0,00 DB size after normal reorg: 3562,00 GB DB size after reorg and OLTP + SecureFiles (med) + Index compression: 1589,00 GB
Space saved (~ 55%) 1973,00 GB
KEY AWR Metrics
Replay without Compression
Replay with
Compression Diff%
O r a c l e R e a l A p p l i c a t i o n Te s t i n g ( R AT ) O p t i o n c e r t i f i e d f o r S A P 13
In order to further analyze the effects of Advanced Compression on DML operations, SQL Performance Analyzer (SPA) was used concurrently with Database Replay. As the workload was being replayed, SPA’s automatic cursor cache capture feature was used to capture the SQL statements into a SQL Tuning Set. SQL Tuning Set contains the text of the SQL statements along with their bind values, execution plans and statistics. This was done for both replays, with compression enabled and without compression. In all over 5000 SQL statements were analyzed. The table below shows the SQL Tuning Set comparison of some the most frequently executed DML operations in the SAP workload.
Overall the test results were very instructive. Key findings are described as follows (note: results will vary according to your workload):
• No significant overhead observed during capture process
• Advanced Compression reduced database size by 50% • Redo generated increased by ~25%
• Physical reads reduced by 60% • CPU usage stayed flat
Problems encountered:
During the testing bug # 9233285 was encountered. Patch for this bug must be applied before using Real Application Testing with SAP systems.
Conclusion
Real Application Testing proved a vital tool for validating upgrade from Oracle Database 10g
Release 2 to 11gRelease 2. The ability to test with production workloads and SQL statements is essential for testing business critical applications like SAP and this feature will significantly mitigate upgrade and change risk when used by experienced DBAs.
Sample SQL Tuning Set Comparison
Compression SQL ID SQL Text Executions Elapsed Time Buffer Gets Disk Reads Module CPU Time
N g9makkh1cnq94 INSERT INTO “ALCLASTOOL” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 37648 180,29 152,97 1136194 32901 SAPLSALU Y g9makkh1cnq94 INSERT INTO “ALCLASTOOL” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 40434 215,54 164,10 1118975 33911 SAPLSALU N 6kxdz6nknay0m INSERT INTO “ALGRPCUSGE” VALUES( :A0 , :A1 ,:A2 , :A3 , :A4... 18257 80,88 71,32 518407 9978 SAPLSALU Y 6kxdz6nknay0m INSERT INTO “ALGRPCUSGE” VALUES( :A0 , :A1 ,:A2 , :A3 , :A4... 18889 92,12 74,99 532217 9615 SAPLSALU N c42810chs804v INSERT INTO “ALGRPCUSPF” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 4100 20,51 16,67 134523 3652 SAPLSALU Y c42810chs804v INSERT INTO “ALGRPCUSPF” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 4202 24,07 17,32 137029 3493 SAPLSALU N 8wz2ywwcrh7c7 INSERT INTO “ALGRPCUSMC” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 2144 12,48 9,08 77571 2758 SAPLSALU Y 8wz2ywwcrh7c7 INSERT INTO “ALGRPCUSMC” VALUES( :A0 , :A1 , :A2 , :A3 , :A4... 1820 13,18 7,94 65849 2289 SAPLSALU
Making a change to the SAP database can represent a significant risk to an organization. The effects of an unexpected problem could be widely felt and have serious consequences. For this reason, testing of changes prior to production deployment is considered critical. The cost involved in testing using traditional methods can be very high both in time and money. Even after testing, many problems will only be discovered in production, and as a result end-users will suffer from poor perfor-mance or possibly even outages.
The Real Application Testing (RAT) Option is comprised of two complementary features, SQL Performance Analyzer (SPA) and Database Replay. Together, these features can help ensure that database changes do not negatively impact SAP availability and performance. They signi-ficantly improve the quality and lower the cost of testing changes to the SAP database system. Facts instead of surprises
The IT specialists at SWM, are among the pioneers who are using the Oracle Database 11g
Release 2 Real Application Testing option together with the SAP application.
SWM Stadtwerke München, a public utility and service company based in the mega city of Munich that offers a wide range of products, has data volumes of more than 3 Terabyte which are being accessed by 1500 to 1800 SAP users. The CPU utilization of the pro-duction systems is therefore extremely high.
For Christian Duschl, SAP Team-Leader System Operations Management, the risks and con-tingencies associated with making changes to the SAP environment were always a high-cost challenge: “Previously, we were not able to determine the dialog load with sufficient precision before commissioning new systems. Surprises were part of our day-to-day work. Having used RAT for the first time and gai-ned some experience with it, we believe that this will finally become a thing of the past.” The test scenario was compressing the database using the Advanced Compression option and to examine the effects on system performance. The production load of two RAC nodes was recorded over two working days and the data-base was transferred to a test server along with the data volume for this period.
In a first step, the database was reorganized in a conventional manner, without being com-pressed. A representative 12 hour section of the recorded production load was then replayed. The replay contained the SAP ERP user load only. Other applications, such as those from the call center area (non-SAP), were not taken into account and were filtered out during replay. The results from the replay were later used as a basis for further analysis. In the next step, all tables and indexes were compressed using OLTP Table, SecureFiles and Index compres-sion. Stadtwerke Munich Services GmbH Industry: Utility/Public Sector Annual Revenue: €4.2 billion Employees: Around 6,800 Im S U C C E S S F U L T E S T O F O R A C L E D A T A B A S E 1 1g R E L E A S E 2 R E A L A P P L I C A T I O N T E S T I N G O P T I O N A T S T A D T W E R K E M U N I C H ( S W M )
“The positive results from using the RAT option for the first time enable us to look to the future and the upcoming changes in a much calmer manner than before.”
– C H R I S T I A N D U S C H L ,
O r a c l e R e a l A p p l i c a t i o n Te s t i n g ( R AT ) a t S t a d t w e r k e M u n i c h ( S W M ) 15
A second run, which included exactly the same dataset as the first run, was then tested against the compressed database and the results were compared with the first run.
No additional costs and less disk space Manfred Fischer, Manager of SAP system maintenance in information and process tech-nology and general coordinator of the RAT project, summarizes the results as follows: “When we were recording the basic data over two days for the test, we couldn’t find any negative effects on the CPU or I/O load of the production system and the dialog response times didn’t change.”
The compression result was quite impressive. The amount of disk space shrunk from almost 3.6 TB to around 1.6 TB, resulting in a space saving of 55%.
“What was even more interesting was the effect on the CPU load when using com-pression. The result was amazing. Thanks to the enormous reduction in I/O of almost 60% and considerably better uti-lization of the main memory, the additio-nal costs expected for compression were compensated in full for the CPU load. Another positive side-effect was a slight increase in transaction throughput. Because the hit rate of the database buffer cache improved considerably, there was less physical I/O to the disk subsystem.”
As the solution does not show any performance impacts, the Advanced Compression option can be used on the SAP ERP production systems at Stadtwerke München if necessary. According to Manfred Fischer, SQL Perfor-mance Analyzer (SPA) also proved to be a key functionality. It was particularly helpful in evaluating the performance of important queries at statement level, which must not be negatively impacted.
Calculated risks and cost savings
In the future, the SAP environment at Stadt-werke München is to be split into three units (Network, Delivery and Coresystem) which will be designed to mirror the data volumes in the production system and various test and security systems, among other things. Because each one of these segments should have the capacity of the current system, the data volumes will triple in the final expansion stage.
Given such complex tasks, Christian Duschl is giving an extremely positive conclusion from the test results with RAT:
“The positive results from using the RAT option for the first time enable us to look to the future and the upcoming changes in a much calmer manner than before.”
Unknown risks when making release changes, growing data volumes or deregulating an entire SAP system, as was the case here, loose their fears for many users at least for the data-base level. Using RAT will enable IT depart-ments to demonstrate extremely positive cost-value results to the controlling depart-ments.
“ S A P P A R T I T I O N I N G E N G I N E ” R E L E A S E D B Y S A P
The “SAP Partitioning Engine” provides a solution for SAP on Oracle database systems that can use a predefined set of about 30 large application tables for partitioning, based on a technology concept from Oracle. SAP Partitioning Engine was released for customers in January 2010. The solution offers full integration of range partitioning into SAP OLTP products (e.g. ERP).
Unlike SAP BI, partitioning is not used by default in the SAP ERP system, for mainly historical reasons. Today, SAP installations typically have database sizes of around 1TB, whereas SAP customers using special functionalities such as the SAP retail module are running databases of 10TB and greater. Such large databases have several challenges: • Old data must be archived, but archiving can have
a negative impact on database performance. Deleting data from the database generates a huge transaction load, affecting normal data processing. • Archiving very large tables can be a never-ending
job. Once archiving is complete, follow-up tasks are needed either to rebuild fragmented indexes and/or to free up space in the tablespaces. These additional tasks occupy maintenance windows for the system, reducing overall availability.
• Response times to user queries and batch processing must be guaranteed. This becomes more and more difficult because the tables are constantly growing in size.
• Processing larger tables uses up much more time and resources on the database as well as on the application servers. Because of the longer runtime, work processes take longer which means that more powerful application servers are needed.
Fully integrated
The principle of partitioning is splitting a large table in smaller parts, called partitions, grouping and separating the rows of the table based on the content of one or more columns. Rows fulfilling the same criteria are placed in the same partition. This also allows queries of a table to execute faster because the data will now be grouped, instead of being distributed across the whole table.
Complex analysis and maintenance jobs of partitioning can be automated. Therefore, Oracle in the initial phase of the project had developed a set of tools that was based on Oracle’s own technologies, mainly PL/SQL procedures. This worked fine for a few installations but, it was a consulting based solution which is useful for non-standard SAP requirements, it should not be necessary for standard environments. To make the innovative method available to more customers SAP has developed their own solution, based on the concept provided by Oracle.
The SAP Partitioning Engine is fully integrated in the SAP system. It offers a predefined set of about 30 application tables to be partitioned based on time based criteria. So existing non-partitioned tables will be converted through ABAP/SAP brtools task. Also partition maintanance is fully automated through the internal SAP SM37 job, requiring no DBA inter-vention.
A partitioning service for non-BI SAP systems has been available from Oracle for several years but, until now was not integrated into SAP’s DB admin tools. The Partitioning Engine will be available with WEB AS 6.20, SAP ECC 5.0/6.0, Business Suite 7, brtools7.10 and running Oracle 10.2.0.4 or higher. For other prerequisits please see SAP Note 1333328. For part-itioning without the Partpart-itioning Engine, please see SAP Note Oracle Partitioning 742243 and SAP note 722188 FAQ.
Dr. Christian Graf, Development Manager, DB Platforms Oracle & Informix, OS Platforms HPUX, Solaris, Tru64 SAP AG
S A P P a r t i t i o n i n g E n g i n e 17
The bulding concept of the SAP Partitioning Engine is based on the following three main parts:
Analysis and Statement Creation
First part is an ABAP program, which analyzes the content of the document column of an application table and creates as output a DDL (Data Definition Language) statement for the table and indexes with suitable partition ranges. This kind of transaction initially generates non-partitioned tables into parti-tioned ones. This includes built-in functionality. Such as well-known SAP tables, their partitioning key as well as an automatic adjustment for partition sizes. Analysis task can be done even on very large tables in short time with the help of the underlaying number-ranges object defined in table NRIV (“NRIV Partitioning”).
Partition Transformation
Second part of partitioning engine is a new function in the brspacetool, which reads the previously created DDL statement and performs the online redefinition. It includes LOB migration if the table contains long field. The new online table generation can be done without downtime, because brspaceuse Oracle Technology (DBMS_REDEFINITION-Package). Partitioning Care Process
Third part is also an ABAP program, specifically for maintaining the partitioning schema. One maintaining task done by this program is that if new transaction data are inserted in the partitioned table automatically additional partitions are created if needed. If the table is archived, the number of rows stored in the oldest partitions will decrease. The transaction of the SAP Partitioning Engine is responsible for freeing up the space no longer used in these partitions. The space is freed by executing a merge operation on the old partitions. The result is one small partition containing the remaining rows and a lot of free space within the tablespace, which can be used for creating new parti-tions. This transaction can also be executed while SAP is up and running.
Advantages and Benefits
The SAP Partitioning Engine avoids negative side-effects when archiving by seperating historic and current application data using range partitioning (Oracle offers several other types of partitioning including: list and hash partitioning, which are normally not suitable for SAP ERP systems). Range Partitioning has a couple of advantages or benefits: • Index and table formatting is restricted to the
partition with the data records to be archieved. • Archiving transactions and running application
transactions access different partitions of the table. • Block usage is improved by avoiding mixing old
data and new data.
• Further advantage, disk space is reclaimed by merging the partitions that are empty after archiving and partitioning can also improve query performance.
Using the SAP Partitioning Engine allows SAP customers to make use of the Oracle partitioning technology, without the need to be familiar with Oracle programming. The predefinition of the most common candidate tables for partitioning allows less experienced Oracle users to benefit from this innova-tive approach.
Starting Partitioning to select a table with SAP Partitioning Engine (Source: SAP)
1.) Mr. Schulte,
the database partnership with Oracle has thrived for more than 20 years. Can you summarize this for us in a few key words? Schulte:
Firstly, our intent is to continue to satisfy the tens of thousands mutual SAP on Oracle database customers. Our joint work has always been characterized by a constant desire to provide mutual customers with efficient service and support solutions for their appli-cation needs in order to bring additional benefit to their business and to offer optimum protection of their investments.
Secondly, continually accelerating and optimizing the use of safe, reliable and scalable database techno-logy in a mission-critical application environment, something we have achieved time and again.
And thirdly, we have enjoyed a very successful service and support partnership with Oracle Corporation. For the benefit of our mutual customers, we have a long term contractual frame work and resources in place driving this forward. The Oracle team suppor-ting our joint relationship has been in place for more than 10 years, this stability in personnel has been very benefical to both SAP and our mutual customers. The Oracle SAP resources include database develop-ment engineers and 24 by 7 follow the sun customer support.
R E L A T I O N S H I P I N T E R V I E W – O R A C L E D A T A B A S E A N D S A P
Horst Udo Schulte,Vice President Global Partner Programs, SAP AG
Gerhard Kuppler,Senior Director Corporate SAP Account, Oracle Corporation Listen to the Oracle webcast at www.oracle.com/sap
2.)Mr. Kuppler,
what importance does Oracle attach to the database technology partnership with SAP? Kuppler:
Satisfied mutual customers !
For more than 20 years Oracle has been the safe, reliable, and scalable database of choice for SAP customers.
The Oracle database is constantly optimized for SAP Business Suite Applications and around the world more than two thirds of all mid-size to high-end SAP customers in every industry, entrust their application deployments to Oracle databases.
Customers are running SAP applications with Oracle databases on the same code base on Unix, Linux and Windows operating systems.
Oracle was one of the technology partners involved in developing SAP R/3, when SAP began developing R/3 in 1988. Oracle’s database technologies and SAP’s solutions are very closely linked and perfectly integrated with one another.
We managed to establish our Oracle database techno-logies as the number one database amongst SAP customers around the globe.
The very large and growing customer base expects a cost benefit from our two companies technologies in the long term and also to receive first-class database support from both of us.
Oracle is deploying a significant amount of resources at SAP HQ Walldorf Germany, Palo Alto and Tokyo to deliver safe, reliable and scalable DB technology and round the clock services with a great long term commitment to the mutual customer base.
19 R e l a t i o n s h i p I n t e r v i e w – O r a c l e D a t a b a s e a n d S A P
3.) Mr. Schulte, Mr. Kuppler,
for you what are the main objectives for both parties continuing to successfully drive this relationship forwards in the future? Schulte:
We are committed to the success of our mutual customers.
Since 1988, SAP AG has been using Oracle as a Tier 1 development database, on which SAP develops, ports and migrates its products to function optimally with Oracle’s database technologies.
This will once again be underlined with the new Oracle Database 11gRelease 2. It will contain various specific functionality designed and implemented for the needs of the SAP Business Suite.
Kuppler:
Let me add, the release strategy of SAP AG for Oracle Database versions is to certify only the terminal release of a new database version. This strategy is based on the overall requests of the SAP customer community to minimize the number of version upgrades in complex SAP environments. It has been proven a successful roll out process with previous terminal releases.
We are committed to maintain a productive Database relationship with SAP to keep the mutual base and also new SAP on Oracle customers satified and provide them with the latest Database innovations like: Real Applications Clusters, Database Vault and new Oracle Database 11gfunctionality.
Resulting in scalable performance, cost savings, better service levels and easy system administration.
4.) Mr. Schulte, Mr. Kuppler,
how frequently does SAP and Oracle renew their partnership agreements?
Schulte:
We have renewed our agreement approximately every 3 years and we plan to continue this process for the benefit of our joint customers.
Kuppler:
With 2/3 of all mid-size to high-end SAP customers running on Oracle databases we have a mutual interest in doing what is best for our joint install base.
In October and December 2009 Oracle and Fujitsu strikingly demonstrated the success of their longstanding partnership with joint press announcements about two world record results in a row with the SAP Business Intelligence Data Mart Standard Application Benchmark. The SAP BI Data Mart Standard Application Benchmark provides a real-world indication of enterprise database performance by measuring system performance in handling high-volume queries to a business warehouse system data-base. The key figure is the number of query navigation steps per hour against an enormous amount of data.
The first announcement was made during Oracle Open World about a two-tier world record result achieved on a system comprised of a single-node Fujitsu PRIMERGY RX300 S5 server(1), Oracle Database and Oracle Real Application Clusters on Linux. The test was also executed on a two-node Fujitsu PRIMERGY RX300 S5 cluster. The one-node result (320, 363 navigation steps per hour) and two-node result(2)(609,349 navigation steps per hour) not only indicated excellent scalability, but also delivered more than 67% higher performance per core and 3.3 times more performance-per-processor than the highest IBM DB2 results(3) on the SAP BI-D Standard Application Bench-mark.
Performance is an important factor when hand-ling a huge amount of data and in ensuring the acceptance of data warehouse application users. However, it is not the only aspect to keep in mind when deciding on a data warehouse environment. The option of starting small and increasing step-by-step as demands grow can be a decisive factor as well as the high availa-bility of the application.
P E R F O R M A N C E M E E T S S O L U T I O N S E X P E R T I S E
Oracle Database on Fujitsu PRIMERGY Cluster Delivers World Record Results with SAP Business Intelligence Data Mart Standard Application Benchmark
Such demands urged Fujitsu and Oracle spe-cialists to think about an advanced concept that aligns performance with scalability and high availability. “The one and two-node benchmark results already revealed the excellent scalability of our PRIMERGY servers in combination with the Oracle Database and Oracle Real Appli-cation Clusters,” says Joachim Witte, Senior Director, Global Fujitsu SAP Competence Center. “Thus it was almost a logical next step to conti-nue tests with more server nodes.”
The following test series underlined the positive results of the first sequence and has resulted in a new world record. On the three-node Fujitsu PRIMERGY RX 300 S5 cluster throughput was increased to 900,309 query navigation steps(3), while a further all-time high of 1,165,742 query navigation steps(4)was achieved by the four-node server cluster. “So Fujitsu and Oracle were once again happily able to jointly announce a new world record on December 1,” says Joachim Witte.
The extremely successful benchmark series is much more than a performance boost. In fact, it is a perfect example of outstanding perfor-mance that is obtained and embedded in using an intelligent concept. In comparison to tradi-tional clusters, the dynamic solution designed by experts from the Global Fujitsu SAP Com-petence Center in Walldorf (Germany) also offers high system availability because Oracle RACs monitor the environment and automati-cally migrate affected processes to other nodes should a particular server fail. Furthermore, customers have the option of starting small with just one server node and growing step-by-step as demands and data volumes increase.
B e n c h m a r k S A P o n O r a c l e w i t h F u j i t s u 21
The successful combination of cost-efficient server technology and innovative database and cluster technology from Oracle also underlines that Fujitsu PRIMERGY x86 servers today are starting to match the high performance of enterprise servers and are thus also suitable as a migration path for enterprise warehousing applications from end-of-life Unix-based systems.
Note:
The latest Fujitsu results on the SAP BI-D Standard Application Benchmark have been certified under the following certification numbers:
2009036 (1) (single node), 2009037 (2) (two nodes) and 2009045 (5) (four nodes). Results as of October 14, 2009. For more details, see http://www.sap.com/benchmark
(1) The SAP BI-D Standard Application Benchmark performed on August 8, 2009 by Fujitsu in Walldorf, Germany has been certified (certification number 2009036) with the following data: Throughput/hour (query navigation steps): 320,363. Operating system, central server: SuSe Linux Enterprise Server 10. RDBMS: Oracle Database 10gReal Application Clusters (RAC). Technology platform release: SAP NetWeaver®7.0
(non-Unicode). Configuration: Central server: Fujitsu PRIMERGY RX300-S5, 2 proces-sors / 8 cores / 16 threads, Intel Xeon Processor X5570, 2.93 GHz, 64 KB L1 cache and 256 KB L2 cache per core, 8 MB L3 cache per processor, 96 GB main memory.
(2) The SAP BI-D Standard Application Benchmark performed on August 11, 2009 by Fujitsu in Walldorf, Germany has been certified (certification number 2009037) with the following data: Throughput/hour (query navigation steps): 609,349.
Operating system all servers: SuSE Linux Enterprise Server 10. RDBMS: Oracle Data-base 10gReal Application Clusters (RAC). Technology platform release: SAP Net-Weaver 7.0 (non-Unicode). Configuration: 2 servers (2 active nodes): Fujitsu PRI-MERGY RX300-S5, 2 processors / 8 cores / 16 threads, Intel Xeon Processor X5570, 2.93 GHz, 64 KB L1 cache and 256 KB L2 cache per core, 8 MB L3 cache per processor, 96 GB main memory. (3) The SAP BI-D Standard Application
Benchmark performed on October 17, 2008 by IBM in Rochester, MN, USA was certified on October 31, 2008 (certification number 2008063) with the following data: Throughput/hour: 182,112 query naviga-tion steps. Operating system, Central server: i 6.1. RDBMS: DB2 for i 6.1. Platform release: SAP NetWeaver 7.0 (non- Unicode). Configuration: Central server: IBM Power System 570, 4 processors / 8 cores / 16 threads, POWER6, 5 GHz, 128 KB L1 cache and 4 MB L2 cache per core, 32 MB L3 cache per processor, 128 GB main memory.
(4) The SAP BI-D Standard Application Benchmark performed on October 14, 2009 by Fujitsu in Walldorf, Germany has been certified (certification number 2009044) with the following data:
Throughput/hour (query navigation steps): 900,309. Operating system, all servers: SuSE Linux Enterprise Server 10. RDBMS: Oracle Database 10gReal Application Clusters (RAC). Technology platform re-lease: SAP NetWeaver 7.0 (non-Unicode). Configuration: 3 servers (3 active nodes): Fujitsu PRIMERGY RX300-S5, 2 proces-sors / 8 cores / 16 threads, Intel Xeon Processor X5570, 2.93 GHz, 64 KB L1 cache and 256 KB L2 cache per core, 8 MB L3 cache per processor, 96 GB main memory.
“So Fujitsu and Oracle were once again happily able to jointly announce a new world record.”
– Joachim Witte, Senior Director, Global Fujitsu
(5) The SAP BI-D Standard Application Benchmark performed on October 13, 2009 by Fujitsu in Walldorf, Germany has been certified (certification number 2009045) with the following data: Through-put/hour (query navigation steps): 1,165,742. Operating system all servers: SuSE Linux Enterprise Server 10. RDBMS: Oracle Dtabase 10gReal Application Clusters (RAC). Technology platform release: SAP NetWeaver 7.0 (non-Unicode). Configuration: 4 servers (4 active nodes): Fujitsu PRIMERGY RX300-S5, 2 processors / 8 cores / 16 threads, Intel Xeon Processor X5570, 2.93 GHz, 64 KB L1 cache and 256 KB L2 cache per core, 8 MB L3 cache per pro-cessor, 96 GB main memory.
About Fujitsu
Fujitsu is a leading provider of IT-based business solutions for the global marketplace. With approximately 175,000 employees supporting customers in 70 countries, Fujitsu combines a worldwide corps of systems and services experts with highly reliable computing and communications products and advanced microelectronics to deliver added value to customers. Headquartered in Tokyo, Fujitsu Limited (TSE:6702) reported consolidated revenues of 4.6 trillion yen (US$47 billion) for the fiscal year ended March 31, 2009. For more information, please see:
http://www.fujitsu.com
About Fujitsu Technology Solution Fujitsu Technology Solutions is the leading European IT infrastructure provider with a presence in all key markets in Europe, the Middle East and Africa, plus India, serving large-, medium- and small-sized companies as well as consumers. With its Dynamic Infra-structures approach, the company offers a full portfolio of IT products, solutions and services, ranging from clients to datacenter solutions, Managed Infrastructure and Infrastructure-as-a-Service. Fujitsu Technology Solutions employs more than 10,000 people and is part of the global Fujitsu Group. For more information, please see: ts.fujitsu.com/aboutus
SAP, SAP NetWeaver and all SAP logos are trademarks or registered trademarks of SAP AG in Germany and in several other countries. All other product and service names mentioned are the trademarks of their respective companies.
23 B e n c h m a r k S A P o n O r a c l e D a t a b a s e 1 1gR e l e a s e 2 w i t h F u j i t s u O R A C L E D A T A B A S E 1 1g D E L I V E R S W O R L D R E C O R D R E S U L T F O R A T W O - T I E R C O N F I G U R A T I O N O N S A P B U S I N E S S I N T E L L I G E N C E - D A T A M A R T S T A N D A R D A P P L I C A T I O N B E N C H M A R K
Oracle Press Release
Oracle Database 11gRunning on New Fujitsu PRIMERGY RX600 S5 Server Raises the Performance Bar for Business Intelligence Application Workloads
Redwood Shores, Calif. – March 30, 2010 News Facts
Oracle Database 11gset a world-record result for a two-tier configuration on the SAP Business Intelligence-Data Mart (BI-D) standard application benchmark(1). On a system comprised of one Fujitsu PRIMERGY RX600 S5 server, equipped with the new Intel Xeon X7560 2.26 GHZ processor, Oracle Database 11gRelease 2 on Linux deli-vered a world-record result of 854,649 query navigation steps per hour on the two-tier SAP BI-D standard application benchmark. Supporting Quotes
“With this benchmark result, Oracle Database 11gRelease 2 demonstrates performance leader-ship on two-tier SAP BI-D standard application benchmark and provides a solid proof-point for customers seeking the best foundation for their business intelligence applications,” said Juan Loaiza, senior vice president, Systems Technology, Oracle.
Supporting Resources • Oracle Database
• Oracle Real Application Clusters • Oracle Benchmarks
• About the SAP BI-Data Mart Standard Application Benchmark
About Oracle
Oracle (NASDAQ: ORCL) is the world’s most complete, open, and integrated business soft-ware and hardsoft-ware systems company. For more information about Oracle, please visit our Web site at http://www.oracle.com.
Trademarks
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their respective owners. SAP, SAP NetWeaver and all SAP logos are trade-marks or registered tradetrade-marks of SAP AG in Germany and in several other countries. Other names may be trademarks of their res-pective owners.
Results as of March 30, 2010. For more infor-mation, please visit
http://www.sap.com/benchmark.
The SAP BI Data Mart (BI-D) Standard Application Benchmark performed on March 07, 2010 by Fujitsu in Walldorf, Germany, has been certified with the following data: • (1) Throughput/hour (query navigation
steps): 854,649
• CPU utilization of central server: 96% (1 node active: 96%)
• Operating system, central server: SuSE Linux Enterprise Server 10
• RDBMS: Oracle Database 11g
• Technology platform release: SAP NetWeaver®7.0 technology platform (non-Unicode)
• Configuration: 1 server (1 active node): Fujitsu Primergy RX600-S5, 4 processors/32 cores /64 threads, Intel Xeon Processor X7560, 2.26 GHz, 64 KB L1 cache and 256 KB L2 cache per core, 24 MB L3 cache per processor, 128 GB main memory Certification number: 2010011. Contact Info: Teri Whitaker Oracle +1.650.506.9914 [email protected] Kristin Reeves Blanc & Otus +1.415.856.5145
The key results are discussed below
How does the combination of SAP and Oracle running on Sun compare with the competition? For comparison purposes we can use the benchmark results for a 2-CPU Intel system and an 8-CPU AMD system. For these we have recent results for Windows with SQL Server, Linux with MaxDB, and Solaris with Oracle, which can be used for comparison.
First, let’s take a look at the 2-CPU results. All results in the above diagram were measured with servers that each had 2 Intel Xeon x5570 CPUs with 8 cores and 16 threads. The speed increase over SQL Server is 11% when compared with Windows/SQL Server and 20% for Linux/MaxDB.
The difference becomes more apparent in larger systems. This demonstrates Sun’s and Oracle’s considerable experience in the operation of large systems. The available results for the 8-processor AMD systems show a speed increase for Oracle/Sun in the range of 21%-25%. With 48 cores and 48 threads, these tested systems have three times as many threads as the 2-processor systems. The combination of Oracle and the Solaris operating system is the best combination for large SAP systems. It offers the best load distribution over the many threads.
If we analyze the current processor roadmaps, we notice a trend towards more threads for all manufacturers. Because future 2-processor systems will also have more threads, customers will benefit from this combination even with smaller systems.
High-End Results
Since July 2008 the list of 2-tier SAP SD benchmarks has been headed by a Sun M9000 system. Naturally, this benchmark used Oracle Database 10gfor the database as this ensures optimum use of the large processing power of the 64 CPUs with 256 cores and 512 threads. The figure of 39,100 SAP SD users is based on the SAP non-Unicode character set.
O R A C L E O N S O L A R I S :
B R E A K I N G S A P B E N C H M A R K R E C O R D S
In multiple SAP benchmark tests, Oracle Database on the Solaris operating system has once again demonstrated its outstanding performance and scaling capabilities.
