Vinyl windows & Patio doors The brilliance of simplicity

(1)

Vinyl windows & Patio doors

t h e b r i l l i a n c e o f s i m P l i c i t y

(2)

meet the windows that make life easier.

reliable Jeld-wen®_{vinyl windows and patio doors are energy efficient, secure} and most importantly, low-maintenance.

each one of our windows and patio doors is built to last. we prove this by supporting each product with our industry-leading lifetime warranty. review the complete warranty at www.jeld-wen.com/resources.

(3)

creating reliability

Jeld-wen®_{vinyl windows and patio doors include features that ensure durability and lasting visual} appeal. they’re built from high-quality extruded vinyl that resists fading so they never need to be painted and are virtually maintenance-free. all our vinyl windows are designed to meet the demands of the regions where they’ll be installed.

Neat

®

_Glass

Feature of Brickmould Vinyl, Builders Vinyl and Flat Casing Vinyl

this glass option gives you the convenience of natural cleaning. by harnessing the sun’s UV rays (even when the sky is cloudy) to loosen dirt from the glass, rain water can easily rinse away grime. no manual activation is required.

Low-E and LoE–

3

_{-366 insulating glass}

our standard high-performance low-e insulating glass lowers energy costs, helps homes stay cooler in the summer and warmer in the winter, prevents fading of interior furnishings, and reduces condensation. it also delivers greater visible light transmittance than tinted glass. we also offer optional loe–3_{-366 glass, which provides more protection against solar heat gain,} as well as greater energy savings.

windows and patio doors with low-e or loe–3_{-366 glass are}_energy_star®_{qualified, which} means they exceed the minimum energy efficiency criteria for the climate region you live in (by as much as 40 percent).

in warm weather, low-e glass reflects the sun’s energy and prevents it from entering the home.

in cold weather, low-e glass reduces the amount of heat lost by reflecting it back inside.

(5)

Actual colors may var y from the samples displayed.

5

KEy FEaTurEs aNd opTioNs

design options

with Jeld-wen vinyl windows and patio doors, you’ll enjoy an ample assortment of design options. this includes our versatile, enduring vinyl color choices. or for even greater visual appeal to Premium Vinyl windows and patio doors, choose evertone™ —an exterior color process engineered to provide unparalleled resistance to the elements in a selection of hues designed to remain vivid. you can also select a divided lite option with either flat or contour grilles in various sizes and patterns. for options available in your area, contact your local Jeld-wen dealer.

we offer two internal grille options. flat grilles feature a clean look, and contour grilles offer added character.

Flat grille

Contour grille

White almond desert sand

MaG-Lock

®

Feature of Premium Vinyl

with maG-lock, the industry’s first magnetic one-touch automatic lock, our single-hung and sliding windows are more secure and easier to use. the integrated, ergonomic pull handle makes it easy to unlock and open the window in one movement and it locks automatically in the closed position —creating an audible click. for added security, the lock is only visible from the inside of the home.

WEN-Lock

®

Feature of Brickmould Vinyl, Builders Vinyl and Flat Casing Vinyl

single-hung and slider windows lock automatically with wen-lock. this locking system has a slim profile that’s easy to engage, as well as a tamper-resistant design. in fact, this lock has passed all forced-entry resistance tests. it also includes a visible latch indicator (Vli) that lets you know if a window is locked; the Vli can only be seen from indoors.

(6)

6

making the right choice

regardless of where you live, we offer the perfect products and options to meet your region’s specific performance and architectural needs. see which Jeld-wen®_{Vinyl windows} and patio doors are available in your area, and then learn more about those products by referencing the page number under each collection’s availability listing.

(7)

All styles are available

Single-Hung and Sliding styles are not available

7 J e l d - w e n . c o m J e l d - w e n . c o m

avaiLabiLiTy by sTaTE

Premium Vinyl windows and patio doors

Windows available in the following states: alaska, arizona, arkansas, california, colorado, hawaii, idaho, illinois, indiana, iowa, Kansas, Kentucky, michigan, minnesota, missouri, louisiana, montana, nebraska, nevada, new mexico, north dakota, ohio, oklahoma, oregon, south dakota, texas, Utah, washington, wisconsin, west Virginia and wyoming.

Premium atlantic Vinyl windows and patio doors

Available in the following areas: alabama, florida, Georgia, southern louisiana, mississippi, north carolina, south carolina, tennessee,

massachusetts, rhode island, Virginia, maryland, delaware, new Jersey, long island, connecticut and the eastern texas coast.

Patio doors, casement, awning, fixed, radius and geometric are available in all states except Florida. To learn more about Premium Vinyl, see page 12.

all styles are available single-hung and sliding style

(8)

8

flat casing Vinyl windows and patio doors

Available in the following states: connecticut, delaware, maine, maryland, massachusetts, new hampshire, new Jersey, new york, north carolina, Pennsylvania, rhode island, Vermont, Virginia and west Virginia.

brickmould Vinyl windows

Available in the following states: alabama, arkansas, colorado, connecticut, delaware, Georgia, illinois, indiana, iowa, Kansas, Kentucky, louisiana, maine, maryland, massachusetts, michigan, minnesota, mississippi, missouri, montana, nebraska, new hampshire, new Jersey, new york, north carolina, north dakota, ohio, oklahoma, Pennsylvania, rhode island, south carolina, south dakota, tennessee, texas, Vermont, Virginia, west Virginia, wisconsin and wyoming.

To learn more about Brickmould Vinyl, see page 18. To learn more about Flat Casing Vinyl, see page 16.

(9)

builders Vinyl windows and patio doors

Available in all states except Florida.

windowmaster

™

_{Vinyl windows and patio doors}

Available in the following areas: arizona, california (imperial, Kern, los angeles, orange, riverside, san bernadino, san diego, san luis obispo, santa barbara and Ventura counties), hawaii, nevada (clark county) and new mexico.

9 J e l d - w e n . c o m

To learn more about Builders Vinyl, see page 20. To learn more about Windowmaster Vinyl, see page 22.

(10)

10 J e l d - w e n®_{w i n d o w s & d o o r s}

inspiring selection

Jeld-wen produces various window styles to meet both your aesthetic and performance needs. we’ve included definitions of these styles here to help you make the appropriate choice for your home.

(11)

11 J e l d - w e n . c o m

sTyLE GLossary

For styles available in your area, contact your local JELD-WEN dealer.

Fixed, radius and Geometric

every fixed, radius and geometric window is unique. they’re available in a wide variety of shapes, with either curved or straight frames. they can be used as freestanding units or in combination with other styles.

Garden

with a garden window, you can add a little greenhouse to any room. this window is a projecting, three-sided window that includes one shelf, a glass top and a single-hung window on each side for maximum air circulation.

single-Hung

a single-hung window provides a classic appearance to any home. it features a stationary top sash and a bottom sash that slides vertically. we offer single-hung windows with tilt or side-load removable sash for easy cleaning.

slider

each of our slider windows features clean lines for a streamlined look. this type of window has one stationary sash and one sash that moves to the right or left in grooves or on tracks. It may also be referred to as a roller or sliding window.

sliding patio door

this streamlined type of patio door is perfect for nearly any patio or deck. it opens by sliding along horizontal tracks.

swinging patio door

add an element of drama to your home, on either a small or grand scale, with a swinging patio door. these doors are available with one or two panels that swing either out or in on side hinges.

awning

an awning window is perfect for many architectural styles, and it looks intriguing when grouped with other window types. it is hinged at the top and opens out from the bottom in an upward swing.

bay

this type of window is ideal for traditional or Victorian architecture, and it increases the sense of openness in any room. a bay window is composed of three individual units. the center unit is parallel to the exterior wall with side or flanking units aligned at 30- or 45-degree angles.

bow

bow windows subtly increase interior spaces by extending outward to create the illusion of a rounded exterior wall. a bow window consists of a series of four or more adjoining window units that are installed on a radius from the wall of the building.

Casement

a casement window perfectly complements the simplicity of modern design. this type of window is hinged on either side so that the sash opens outward, to the right or left, in a swinging motion.

double-Hung

this window is best suited to traditional architectural styles. double-hung windows feature an upper and lower sash that slide vertically past each other in a single frame. both sash tilt in for convenient cleaning.

(12)

Product availability:

To see if this line is available in your state, refer to the map on page 7.

Premium Vinyl

windows and patio doors

remarkably versatile

for low-maintenance durability and generous design options, choose Premium Vinyl windows and patio doors. each one is available with optional even sight lines that create a clean, architecturally accurate look. this allows them to be used seamlessly in combination with Jeld-wen®_{wood windows. they also} offer character-enhancing options that will coordinate with any architectural style. with a dP 35 rating, these windows are appropriate for commercial applications.

(13)

13 J e l d - w e n . c o m

prEMiuM viNyL

available styles: awning, casement, fixed, radius and geometric, sliding, single-hung; and sliding patio doors

our simulated divided lites (sdl) feature bars permanently adhered to the interior and exterior glass, with an optional shadow bar between the panes of glass.

color: desert sand sliding window, color: white

Key features

colors: white or •

optional desert sand evertone

• ™_exterior

color process new maG-lock

• ®

one-touch automatic lock for single-hung and sliding windows sliding windows include •

machined delrin™_rollers

for smooth operation optional even sight lines •

energystar

• ®_qualified

with standard energy efficient low-e glass optional simulated •

divided lites with 7/8", 1-1/8", 1-3/8" or 2-1/8" contour grilles

optional grilles between •

the glass with 5/8" flat or 1" contour grilles dP 35 rating •

To learn more about our Premium Vinyl windows and patio doors, request the Premium Vinyl

catalog at www.jeld-wen.com. MAG-Lock® the maG-lock automatic locking system has an ergonomic handle, making it easy to unlock and open the window in one movement. Delrin™_rollers our sliding windows feature delrin rollers, which allow sash to move smoothly along monorail tracks.

Optional even sight lines even sight lines ensure that our Premium Vinyl windows are symmetrical for a clean, architecturally correct look.

(14)

Product availability

Premium atlantic Vinyl

windows and patio doors

beautiful strength

our Premium atlantic Vinyl windows and patio doors provide you with the lasting durability you need and the aesthetic features you want. they’re designed to be an architecturally accurate choice with a range of design options that will add visual interest to any home. these windows and patio doors are available with impactGard® protection for areas prone to hurricanes.

(15)

available styles: awning, casement, double-hung, fixed, radius and geometric, roller, single-hung; sliding patio doors and swinging patio doors J e l d - w e n . c o m 15 available styles: awning, casement, double-hung, fixed, radius and geometric, roller, single-hung; sliding patio doors and swinging patio doors

prEMiuM aTLaNTiC viNyL

Key features

• Colors: White or optional desert sand

• energystar® qualified with optional

energy efficient low-e glass • Optional ImpactGard®_protection

• Optional 1" simulated divided lites • Optional grilles between the glass

with 5/8" or 7/8" flat or 5/8" or 1" contour grilles

Casement window, color: desert sand

our simulated divided lites (sdl) feature bars permanently adhered to the interior and exterior glass.

ImpactGard protection this option includes impact-resistant glass that stands up to strong impacts from wind-borne debris, as well as harsh conditions inherent to coastal areas. in fact, it features the industry’s leading laminated glass technology that can withstand a nine-pound piece of lumber striking it head-on at approximately 34 miles per hour. it also reduces sound transmission, blocks up to 95 percent of harmful UV rays, and enhances home security.

Color: White To learn more about our Premium

Atlantic Vinyl windows and patio doors, request the Premium Atlantic Vinyl

(16)

lasting authenticity

with flat casing Vinyl windows and patio doors, the look of traditional wood windows is within reach. each window features a sloped sill and three full sides of 3-1/2" casing for architectural accuracy; coordinating patio doors include flat casing on the sides of the frame. these products are ideal replacement options for american colonial-style homes, and they can greatly reduce the cost of exterior trim for new homes.

flat casing Vinyl

(17)

17 J e l d - w e n . c o m available styles: awning, casement, double-hung, fixed, radius and geometric; and sliding patio doors

FLaT CasiNG viNyL

available styles: awning, casement, double-hung, fixed, radius and geometric; and sliding patio doors

the integral flat casing J-channel allows siding to slip between the casing and nailing fin for a clean look.

double-hung window, color: White Color: desert sand

Flat grille

Key features

• 3-1/2" flat casing • Architecturally correct

sill nosing

• Frames come standard with integral flat casing J-channel • energystar® qualified with

standard energy efficient low-e glass

• Optional grilles between the glass with 5/8" or 7/8" flat or 5/8" or 1" contour grilles

(18)

brickmould Vinyl windows

traditional durability

bring the visual appeal of Georgian architecture home with brickmould Vinyl windows. their design includes integral brickmould profiles for the look of traditional wood windows. this feature also creates a look that’s as clean as it is architecturally appropriate.

(19)

To learn more about our Brickmould Vinyl windows, request the Brickmould Vinyl

catalog at www.jeld-wen.com.

19 J e l d - w e n . c o m

briCKMouLd viNyL

Geometric window, color: desert sand

the integral brickmould J-channel allows siding to slip between the brickmould and nailing fin for a clean look.

Color: White

Key features

• Frames come standard with integral brickmould J-channel • Exclusive WEN-Lock®_(for

single-hung and slider) • energystar® qualified with

standard energy efficient low-e glass

• Optional grilles between the glass with 5/8" or 7/8" flat or 5/8" or 1" contour grilles

J-channel Flat grille

(20)

builders Vinyl windows and patio doors

affordable design

builders Vinyl windows and patio doors are built to deliver steadfast durability and will fit any budget. they’re available with a range of design options, and we offer plenty of replacement accessories to make replacing your old windows easier.

(21)

21 J e l d - w e n . c o m

buiLdErs viNyL

available styles: bay, bow, double-hung, fixed, radius and geometric, garden, single-hung, slider; and sliding patio doors single-hung window, color: White

Key features

• Colors: White or optional desert sand or almond* • Exclusive WEN-Lock®_(for

single-hung and slider) • energystar® qualified

with standard energy efficient low-e glass • Optional grilles between

the glass with 5/8" or 7/8" flat or 5/8" or 1" contour grilles*

*Options and styles are subject to regional availability. Contact your local JELD-WEN dealer for more information.

WEN-Lock® the wen-lock (shown unlocked at left) is our automatic locking system, which has a slim profile that’s easy to engage and a tamper-resistant design.

To learn more about our Builders Vinyl windows and patio doors, request the Builders Vinyl

catalog at www.jeld-wen.com.

Actual colors may vary from the samples displayed.

desert sand

almond WEN-Lock

(22)

windowmaster

™

_{Vinyl windows and patio doors}

enduring choices

for a traditional look with solid energy efficiency or a streamlined design well-suited to more modern homes, windowmaster™ Vinyl windows and patio doors are the ideal choice. made with only the highest-quality extruded vinyl, these windows and patio doors will ensure low- maintenance durability and distinctive design options.

(23)

23 J e l d - w e n . c o m

WiNdoWMasTEr viNyL

available styles: awning, bay, casement, double-hung, fixed, radius and geometric, rolling, single-hung; and sliding patio doors double-hung window, color: White

Key features

• Colors: White or optional desert sand*

• Four frame types to meet specific new construction or remodeling needs • Designed with even

sight lines

• Standard energy efficient low-e glass

• Optional grilles between the glass with 5/8" flat or 1" contour grilles*

desert sand

Actual colors may vary from the samples displayed. *Options and styles are subject to regional

availability. Contact your local JELD-WEN dealer for more information.

To learn more about our Windowmaster Vinyl windows and patio doors, request the

(24)

©2009, 2004 Jeld-wen, inc.; Jeld-wen, the Jw icon, impactGard, maG-lock, reliability for real life, wen-lock and windowmaster are trademarks or registered trademarks of Jeld-wen, inc., oregon, Usa. all other trademarks are the property of their respective owners. Jeld-wen reserves the right to change product specifications without notice.

Please check our website, www.jeld-wen.com,for current information. 11-423 06/09 (sb 5m 2873_16)
