The mission of the Johanson Companies is to

translate our customer needs into quality electronic

components, produced in factories that are models

of excellence, supported by innovative service. With

over 30 years of experience, Johanson Dielectrics

provides both standard and custom technology

solu-tions tailored to your specific electronic applicasolu-tions.

Our standard product range includes High Voltage

and AC Safety Capacitors providing solutions for

Lighting, IT and Business Equipment designs. Our

X2Y® Capacitor line provides advanced EMI

fil-tering and IC decoupling solutions and our High

Capacitance Tanceram® products provide the highest

capacitance values in the smallest cases sizes.

Customized solutions in the areas of High

Tem-perature and High AC power ceramic capacitors are

available to customers who require a partnered

tech-nology solution.

Johanson Dielectrics design and manufacturing

operations are located in Sylmar, California and

Zhoaqing, PRC. Our quality minded management

system utilizes continuous improvement programs

focused on increased product reliability,

manufac-turing through-put, and product performance. Our

broad experience, applications support, and

respon-sive service enhance our ability to drive down your

total cost of procurement and speed your time to

market.

Johanson Dielectrics, Inc. reserves the right to make design and price changes without notice. All sales

are subject to the Johanson terms and conditions, including a limited warranty and remedies for

non-conforming goods or defective goods. Download the Johanson terms and conditions from our website at

http://www.johansondielectrics.com/purchasing-terms-and-conditions.html.

H

IGH

F

REQUENCY

C

ERAMIC

S

OLUTIONS

Johanson Technology Inc., Camarillo CA. Products

include High Q Capacitors, Ceramic and

Wire-wound Chip Inductors, and a broad range of LTCC

based RF IPCs such as Antennas, Filters, Baluns,

Couplers, Matched Filter Baluns, etc.

www.johansontechnology.com

I

NDEX

OF

P

RODUCTS

S

URFACE

M

OUNT

C

ERAMIC

C

APACITORS

Ceramic Capacitor Prototyping Kits

4-5

High Voltage Capacitors 250 - 6,000 VDC

6-7

Safety Capacitors 250 VAC, Y2, Y3, Japan Standard

8-9

EMI - X2Y

®

_{Filter & Decoupling Capacitors}

_10-13

Low Inductance Capacitors

14

Chip Feedthru Filter Capacitors

15

High Temperature - 200°C Capacitors

16-17

High Capacitance Tanceram

®

_Capacitors

_18-19

SMT Multi-layer Ceramic Capacitors 10 - 200 VDC

20-21

L

EADED

C

ERAMIC

C

APACITORS

SMPS Stacked Capacitors, 125°C & 200°C versions

22-23

Mini-SMPS Stacked Capacitors

24-25

BME Mini SMPS Capacitors

26-27

Switch-mode Radial Leaded Capacitors

28-29

High Voltage Radial Leaded Capacitors, 125°C, 200°C, 250°C versions

30-31

P

RECISION

P

OWER

R

ESISTORS

Resistor Wirewound Precision

32-33

Resistor Wirewound Precision SMT

34-35

Resistor Wirewound High Power Rating

36-39

Resistor Wirewound Chasis Mount

40-42

Resistor Thin Film Precision

43-46

Resistor Thin Film Current Sense

47-49

Resistor High Power Low Inductance

50-52

Resistor Thick Film, High Temperature

53-55

Resistor Metal Element Current Sense

56-57

Resistor Power Thin Film

58-60

P

OWER

I

NDUCTORS

Semi-shielded (Coated)

61-68

P

LANAR

C

APACITORS

& C

USTOM

C

ERAMIC

S

OLUTIONS

Planar Array Capacitors

69-70

C

APSTRATE

& C

USTOMER

C

ERAMIC

S

OLUTIONS

CapStrate

®

_{& Customer Ceramic Solutions}

_71-72

P

ART

N

UMBER

, D

IELECTRIC

, P

ACKAGING

S

PECIFICATIONS

Capacitor General Electrical Characteristics and PN breakdown

70

Capacitor Packaging, Power Inductor, Semi-Shielded (Coated) Packaging

73-74

C

ERTIFICATIONS

& C

ORPORATE

R

ESPONSIBILITY

4

www.johanson dielectrics.com

Johanson may from time-time adjust actual kit contents based on design demand trends.

Check the Johanson web site for design kit updates and kit content changes.

C

ERAMIC

C

APACITOR

E

NGINEERING

D

ESIGN

K

ITS

Johanson Dielectrics, Inc. offers a variety of multi-layer chip capacitor

sample kits for proto-type design work. Each kit is grouped by type,

size, or voltage and contains a selection of popular values and

tolerances. The chips are individually packaged in labeled plastic

compartments for easy access. The general range of kit contents

is described below. Specific part number details may be found at

www.johansondielectrics.com

0402 Ceramic Chip Capacitor Kit

P/N: S-0402

1400 piece sample assortment of selected values from 1.0pF to 0.22µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0402

50 VDC - 6.3 VDC

NP0, X7R,Y5V

1.0pF to 0.22µF

50 pcs

1400 pcs

0603 Ceramic Chip Capacitor Kit

P/N: S-0603

1400 piece sample assortment of selected values from 1.0pF to 0.22µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0603

50 VDC - 16 VDC

NP0, X7R,Y5V

10pF to 0.22µF

50 pcs

1400 pcs

0805 Ceramic Chip Capacitor Kit

P/N: S-0805

1400 piece sample assortment of selected values from 1.0pF to 0.47µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0805

100 VDC - 16 VDC

NP0, X7R

10pF to 0.47µF

50 pcs

1400 pcs

TANCERAM

®

_{HIGH CAPACITANCE Ceramic Chip Capacitor Kit}

_{P/N: S-TAN-X5R}

500 piece sample assortment of selected values from 1.0µF to 100µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0402, 0603, 0805

1206, 1210

25 VDC - 6.3 VDC

X5R

1.0µF - 100µF

10 - 25 pcs

500 pcs

500 VDC Ceramic Chip Capacitor Kit

P/N: S-500

400 piece sample assortment of selected values from 33pF to 0.1µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0805 - 1812

500 VDC

NP0, X7R

33pF to 0.1µF

10-20 pcs

400 pcs

1000 VDC Ceramic Chip Capacitor Kit

P/N: S-1KV

400 piece sample assortment of selected values from 22pF to 0.1µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

C

ERAMIC

C

APACITOR

E

NGINEERING

D

ESIGN

K

ITS

2000 VDC Ceramic Chip Capacitor Kit

P/N: S-2KV

300 piece sample assortment of selected values from 22pF to 0.022µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

1206 - 2225

2000 VDC

NP0, X7R

22pF to 0.022µF

10-20 pcs

300 pcs

X2/Y3 SAFETY CERTIFIED Ceramic Chip Capacitor Kit

P/N: S-SY3

240 piece sample assortment of selected values from 10pF to 1500 pF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

1808

3KV DC / 250 AC

NP0, X7R

10pF to 1500 pF

20 pcs

240 pcs

X1/Y2 SAFETY CERTIFIED Ceramic Chip Capacitor Kit

P/N: S-SY2

200 piece sample assortment of selected values from 10pF to 2200 pF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

1808 - 2220

5KV DC / 250 AC

NP0, X7R

10pF to 2200pF

20 pcs

200 pcs

X2Y

®

_{EMI FILTER Capacitor Kit - 0402 Size}

_{P/N: S-X07CBK}

600 piece sample assortment of selected values from 1.0pF to 0.01µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0402

10 - 50 VDC

NP0, X7R

1.0pF to 0.01µF

50 pcs

600 pcs

X2Y

®

_{EMI FILTER Capacitor Kit - 0603 Size}

_{P/N: S-X14CBK}

700 piece sample assortment of selected values from 1.0pF to 0.01µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0603

50 - 100 VDC

NP0, X7R

1.0pF to 0.01µF

50 pcs

700 pcs

X2Y

®

_{EMI FILTER Capacitor Kit - 0805 Size}

_{P/N: S-X15-EMI}

300 piece sample assortment of selected values from 1.0pF to 0.01µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0805

50 - 100 VDC

NP0, X7R

1.0pF to 0.01µF

20 pcs

300 pcs

X2Y

®

_{POWER BYPASS Capacitor Kit - 0603 Size}

_{P/N: S-X14-PBP}

300 piece sample assortment of selected values from 1.0nF to 1.0µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

0603

6.3 - 100 VDC

X7R, X5R

1.0nF to 1.0µF

20 pcs

300 pcs

X2Y

®

_{DC MOTOR FILTER Capacitor Kit}

_{P/N: S-X2Y-MTR}

300 piece sample assortment of selected values from 0.10µF to 0.47µF

Chip Size

Voltage Rating

Dielectric

Capacitance Range

Qty / Value

Total Qty

1206 - 1812

100 VDC

X7R

0.10µF to 0.47µF

30 pcs

300 pcs

Johanson may from time-time adjust actual kit contents based on design demand trends.

Check the Johanson web site for design kit updates and kit content changes.

6

www.johanson dielectrics.com

CASE SIZE
