Master Components Selector Guide
SG388/D
Rev. 7, September−2005
Analog, Clock and Data Management, Standard Logic, Discrete,
Power MOSFET and Integrated Function Products
© SCILLC, 2005 Previous Edition © 2004 “All Rights Reserved”
ON Semiconductor and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further notice to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. “Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer.
HDTMOS, HVTMOS and SMART REGULATOR are registered trademarks of Semiconductor Components Industries, LLC (SCILLC).
All brand names and product names appearing in this document are registered trademarks or trademarks of their respective holders.
PUBLICATION ORDERING INFORMATION
ACE Loop, AnyLevel, BERS, Bullet−Proof, CHIPSCRETES, DUOWATT, E−FET, EASY SWITCHER, ECLinPS, ECLinPS Lite, ECLinPS MAX, ECLinPS Plus, EpiBase, Epicap, EZFET, FASTMOS, FLEXMOS, FULLPAK, GEMFET, GigaComm, HDPlus, ICePAK, L2TMOS, MCCS, MDTL, MECL, MEGAHERTZ, MHTL, MicroIntegration, MicroLeadless, MiniGate,
MiniMOS, MiniMOSORB, MOSORB, MRTL, MTTL, Multi−Pak, NOCAP, ON−Demand, PInPAK, PMODE, PowerBase, POWERSENSE, POWERTAP, Quake, SCANSWITCH, SENSEFET, SLEEPMODE, SMALLBLOCK, SMARTDISCRETES, SMART HotPlug, SMARTswitch, SUPERBRIDGES, SuperLock, SURMETIC, SWITCHMODE, Thermopad, Thermowatt, TMOS, TMOS & Design Device, TMOS Stylized, Unibloc, UNIWATT, WAVEFET, Z−Switch and ZIP R TRIM are trademarks of Semiconductor Components Industries, LLC (SCILLC).
http://onsemi.com 3 Page
Analog ICs
Family Tree. . . 9 Signal Conditioning . . . 10 Power Management . . . 20 Interfaces . . . 103 Special Functions . . . 105Application Specific Standard Products. . . 106
Clock and Data Management
Signal Translators . . . 121 Clock Distribution. . . 123 Clock Generation. . . 125 Skew Management . . . 126 Prescalers. . . 127 Clock Synthesizers . . . 127Zero Delay Buffers . . . 128
EMI Suppression Clocks . . . 130
VCO (PLL) . . . 130 Phase/Frequency Detectors . . . 130 Flip−Flops. . . 131 Latches . . . 133 Shift Registers . . . 134 Multiplexers . . . 135
Serial/Parallel Converter and Parallel/Serial Converters . . . 136 Gates. . . 137 Counters . . . 138 Comparators. . . 139 Parity Checkers . . . 139 Drivers/Receivers . . . 140 Drivers/Buffers . . . 143
Standard Logic Devices
Family Tree . . . 147 Ordering Information . . . 148 Selection by Family Analog Switches. . . 151 MiniGates . . . 152 VHC One−Gates . . . 152 HC One−Gates . . . 152 LCX One−Gates . . . 153LCX Two− and Three−Gates. . . 153
VCX One Gates. . . 154
Low Voltage Standard Logic. . . 155
VCX. . . 155
VHC. . . 155
LCX . . . 156
LVX . . . 157
5.0 V and Greater Standard Logic. . . 159
High Speed CMOS: HC . . . 159
AC/ACT. . . 161
Metal Gate CMOS. . . 164
Logic Special Functions. . . 166
Page
Discretes
Family Tree. . . 170Small Signal Transistors, FETs and Diodes . . . 172
TVS/Zeners . . . 199
Bipolar Power Transistors . . . 242
Rectifiers . . . 253
Thyristors, Triggers and Surge Suppressors. . . 268
Power MOSFET Products
Power MOSFET Products . . . 279SC−75 N−Channel . . . 280 SC−75 P−Channel . . . 280 SC−89 N−Channel . . . 280 SC−89 P−Channel . . . 280 SOT−563 N−Channel . . . 280 SOT−563 P−Channel. . . 280 SOT−563 Complementary . . . 280 SC−70 N−Channel . . . 280 SC−70 P−Channel . . . 280 SC−88 N−Channel . . . 280 SC−88 P−Channel . . . 280 SC−88 Complementary. . . 281
SC−88 Integrated Load Switch P−Channel . . . 281
ChipFETt N−Channel . . . 281
ChipFET P−Channel . . . 281
ChipFET Complementary . . . 281
ChipFET FETKYt N−Channel . . . 281
ChipFET FETKY P−Channel . . . 281
SOT−23 N−Channel. . . 281
SOT−23 P−Channel. . . 282
TSOP−6 N−Channel . . . 282
TSOP−6 P−Channel . . . 282
TSOP−6 Integrated Load Switch P−Channel. . . 282
Micro8t Leadless N−Channel. . . 282
Micro8 P−Channel . . . 282
TSSOP−8 N−Channel . . . 282
TSSOP−8 P−Channel . . . 282
SO−8 Flat Lead . . . 283
SO−8 N−Channel . . . 283
SO−8 P−Channel . . . 283
SO−8 Complementary. . . 283
SO−8 FETKY N−Channel . . . 283
SO−8 FETKY P−Channel . . . 283
SOT−223 N−Channel . . . 284 SOT−223 P−Channel. . . 284 DPAK N−Channel. . . 284 DPAK P−Channel. . . 285 D2PAK N−Channel. . . 285 D2PAK P−Channel . . . 285 PlnPAKt N−Channel. . . 285 TO−92 N−Channel . . . 286 TO−220AB N−Channel . . . 286 TO−220AB P−Channel . . . 286 TO−264 N−Channel . . . 286
Ignition IGBT Products . . . 287
SmartDiscretet Products . . . 288
Table of Contents (continued)
Page
Integrated Functions
Integrated Functions
Protection Circuits . . . 297
TVS Arrays in Surface Mount . . . 297
TVS Low Capacitance Surface Mount for USB 2.0 and 1.1. . . 300
TVS Low Capacitance Surface Mount for High Speed Data Lines . . . 302
EMI Filter Circuits Data Line Protection . . . 303
Audio Line Protection . . . 307
USB DATA Line Protection . . . 308
Relay Drivers . . . 310
LED Drivers. . . 313
Integrated PNP/NPN Digital Transistor Array . . . 313
Inrush Current Limiter . . . 314
SMART HotPlugt. . . 314
Hybrid Diode IC . . . 316
Floating, Regulated Charge Pump . . . 316
MOSFET with Buffered Gate . . . 317
OVP IC with Integrated MOSFET . . . 317
Page
Alphanumeric Parts Index
318 . . .
NOTE: The Tape & Reel Specification information has been moved to its own publication. Please see ON Semiconductor brochure, BRD8011/D, for information on Tape & Reel.
http://onsemi.com
http://onsemi.com 7
FAMILY TREE
. . .
9
SIGNAL CONDITIONING
. . .
10
Operational Amplifiers. . . 10 Comparators. . . 17POWER MANAGEMENT
. . .
20
Battery Management. . . 20 Charge Controllers. . . 20Overvoltage Charge Protection . . . 20
AC−DC/Isolated Switching Controllers. . . 27
Power Factor Correction . . . 27
Flyback (Low Power) . . . 31
Forward (Low Power). . . 45
Half−Bridge (Medium Power) . . . 48
Push−Pull (High Power) . . . 50
DC−DC/Non−Isolated Switching Controllers. . . 54
DC−DC Switching . . . 73
CPU Controllers . . . 73
Voltage References. . . 74
Linear Voltage Regulators . . . 76
General Purpose Linear Voltage Regulators . . . 76
Low Dropout Linear Voltage Regulators. . . 79
Application Specific Linear Regulators. . . 90
Automotive. . . 90
Voltage Supervisory . . . 96
Drivers. . . 99
Alternator Voltage Regulator Darlington Drivers . . . 99 MOSFET/IGBT Drivers . . . 99 Load/Relay Drivers. . . 99 Dedicated Drivers. . . 99
INTERFACES
. . .
103
Data Transmission. . . 103 Transistor Arrays . . . 103SPECIAL FUNCTIONS
. . .
105
Timers . . . 105 Balanced Modulator/Demodulator . . . 105APPLICATION SPECIFIC
STANDARD PRODUCTS
. . .
106
Industrial/Appliances/Motor Control . . . 107 Automotive . . . 108 Networking/Computing . . . 114Wireless & Portable. . . 115
http://onsemi.com
9
ON Semiconductor’s Analog Integrated Circuits
Operational
Amplifiers
Power
Management
Interfaces
Special
Functions
ASSP*
for . . .
Comparators
Controllers
Charge
DC−DC Switching
Cuk (Inverting)
Display
Drivers
Data
Transmission
Timers
Wireless
&
Portable
Industrial /
Appliances /
Motor Control
Flyback Controllers (Low Power)
Voltage References
Low Dropout Linear Voltage Regulators
Supervisory ICs
Smart
Cards
Automotive
Signal
Conditioning
AC−DC Switching
Linear Voltage Regulators
Networking /
Computing
*ASSP: Application Specific
Standard Products
Multi−Topology (Step−Up,
Down, or Inverting)
Buck (Step−Down)
PFC/PWM Combo Controllers
Power Factor Correction Controllers
General Purpose Linear Voltage Regulators
MOSFET/IGBT Drivers
Load/Relay Drivers
Display Drivers
Smart Drivers
Balanced
Modulator/
Demodulator
Battery
Management
Overvoltage
Charge Protection
Transistor
Arrays
Application Specific Low Dropout Voltage Regulators
Boost (Step−Up)
Drivers
Forward Controllers (Low Power)
Half−Bridge Controllers (Medium Power)
Push−Pull Controllers (High Power)
CPU DC−DC Controllers
ON Semiconductor Selector Guide − Analog Integrated Circuits
Signal Conditioning
Operational Amplifiers
High Current
General Purpose
Low Power
Low Cost
General Purpose
MC33201
MC33202
MC33204
MC33501
MC33502
MC33503
NCS2001
NCS2002
NCS7101
NE5230
MC33171
MC33172
MC33174
MC33178
MC33179
TCA0372
LM833
MC33077
MC33078
MC33079
MC33178
MC33179
NE5532(A)
NE5534(A)
MC33071
MC33072
MC33074
MC34071
MC34072
MC34074
LM201A
LM224
LM258
LM2902
LM2904
LM301A
LM324
LM358
MC3303
MC3403
Low Voltage
Rail−to−Rail
MC33272A
MC33274A
NE592
Low Noise
Compandors
NE570
SA571
SA572
SA575
High Speed
Transconductance
Amplifiers
NE5517
Digital to Analog
Converters
DAC−08
MC1408
http://onsemi.com
11
Single Operational Amplifiers
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description
LM201A ±3.0 ±22 1.0 0.5 2.0 30 1.8 −25 to +85 96 − 1 Split DIP−8, SO−8 General Purpose, Precision Non Compensated LM201AV ±3.0 ±22 1.0 0.5 2.0 30 1.8 −40 to +105 96 − 1 Split DIP−8, SO−8 General Purpose, Precision Non Compensated
LM301A ±3.0 ±18 1.0 0.5 7.5 70 1.8 0 to 70 90 − 1 Split DIP−8,
SO−8 General Purpose, Non Compensated MC33071 3.0 or ±1.5 44 4.5 13* 5.0 100 1.6 −40 to +85 97 32 1 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC33071A 3.0 or ±1.5 44 4.5 13* 3.0 100 1.6 −40 to +85 97 32 1 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC33171 3.0 or ±1.5 44 or ±22 1.8 2.1 5.0 20 0.18 −40 to +85 90 32 1 Single, Split DIP−8, SO−8
Low Power, Single Supply, Two Voltage
Ranges MC33201 1.8 or ±0.9 12 2.2 1.0 6.0 80 0.9 −40 to +105 90 20 1 Single, Split DIP−8, SO−8 Low Voltage, Rail−to−Rail MC33201V 1.8 or ±0.9 12 2.2 1.0 6.0 80 0.9 −55 to +125 90 20 1 Single, Split DIP−8, SO−8 Low Voltage, Rail−to−Rail, Extended Temp. Range MC33501 1.0 or ±0.5 7.0 or ±3.5 4 @ Vs = 5 3.0 5.0 0.04 pA 1.2 @ Vs = 1 V −40 to +105 75 30 1 Single, Split
TSOP−5† One Volt
SMARTMOSt, Rail−to−Rail MC33503 1.0 or ±0.5 7.0 or ±3.5 4 @ Vs = 5 3.0 5.0 0.04 pA 1.2 @ Vs = 1 V −40 to +105 75 30 1 Single, Split
TSOP−5† One Volt
SMARTMOS, Rail−to−Rail †TSOP−5 − Also known as Thin SOT23−5.
ON Semiconductor Selector Guide − Analog Integrated Circuits
Single Operational Amplifiers (continued)
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description MC34071 3.0 or ±1.5 44 4.5 13* 5.0 100 1.6 0 to 70 97 32 1 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC34071A 3.0 or ±1.5 44 4.5 13* 3.0 100 1.6 0 to 70 97 32 1 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 NCS2001 0.9 or ±0.45 7.0 or ±3.5 1.4 1.6 6.0 10 pA .80 −40 to +105 70 100 1 Single, Split TSOP−5†, SC70−5
One Volt, CMOS Rail−to−Rail NCS2002 0.9 or ±0.45 7.0 or ±3.5 0.8 1.2 6.0 10 pA .80 −40 to +105 82 100 1 Single, Split
TSOP−6† One Volt, CMOS Rail−to−Rail with Enable NCS7101 1.8 or ±0.9 10 or ±5.0 1.0 1.2 7.0 1.0 pA 1.1 −40 to +85 65 (min) 140 1 Single, Split
TSOP−5† Low Voltage, Rail−to−Rail NCV2002 0.9 or ±0.45 7.0 or ±3.5 0.8 1.2 6.0 10 pA .80 −40 to +125 82 100 1 Single, Split
TSOP−6† One Volt, CMOS Rail−to−Rail with Enable NE5230 ±0.9 or 1.8 ±7.5 or 15 0.6 0.25 3.0 40 0.6 0 to 70 95 30 1 Single, Split SOIC−8, PDIP−8 Single Low Voltage Op Amp NE5534 ±3.0 ±20 10 13 4.0* 500 4.0 0 to 70 100 4.0 1 Single, Split SOIC−8, PDIP−8
Single Low Noise Op Amp
NE5534A ±3.0 ±20 10 13 4.0* 500 4.0 0 to 70 100 3.5 1 Single,
Split
SOIC−8, PDIP−8
Single Low Noise Op Amp SA5230 ±0.9 or 1.8 ±7.5 or 15 0.6 0.25 3.0 40 0.6 −40 to 85 95 30 1 Single, Split SOIC−8, PDIP−8 Single Low Voltage Op Amp SA5534 ±3.0 ±20 10 13 4.0* 500 4.0 −40 to 85 100 4.0 1 Single, Split
PDIP−8 Single Low Noise Op Amp SA5534A ±3.0 ±20 10 13 4.0* 500 4.0 −40 to 85 100 3.5 1 Single, Split SOIC−8, PDIP−8
Single Low Noise Op Amp
http://onsemi.com
13
Dual Operational Amplifiers
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID* (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description
LM258 3.0 or ±1.5 32 or ±18 1.0 0.6 5.0 45 0.7 −25 to +85 85 − 2 Single, Split DIP−8, SO−8, Micro8 Low Noise LM358 3.0 or ±1.5 32 or ±18 1.0 0.6 7.0 45 0.7 0 to 70 70 − 2 Single, Split DIP−8, SO−8, Micro8 Low Noise LM833 ±2.5 36 15 7.0 5.0 300 4.0 −40 to +85 100 4.5 2 Single, Split DIP−8, SO−8 Low Noise LM2904 3.0 or ±1.5 26 or ±13 1.0 0.6 7.0 45 0.7 −40 to +105 70 − 2 Single, Split DIP−8, SO−8, Micro8 Low Power LM2904V 3.0 or ±1.5 26 or ±13 1.0 0.6 7.0 45 0.7 −40 to +125 70 − 2 Single, Split DIP−8, SO−8, Micro8 Low Power MC33072 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 3.2 −40 to +85 97 32 2 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC33072A 3.0 or ±1.5 44 or ±22 4.5 13* 3.0 100 3.2 −40 to +85 97 32 2 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0
MC33077 ±2.5 ±18 37 11 1 @ Vs = ±15 V 280 3.5 −40 to +85 107 4.4 2 Split DIP−8, SO−8 Low Noise MC33078 ±5.0 ±18 16 7.0 2.0 300 4.1 −40 to +85 100 4.5 2 Split DIP−8, SO−8 Low Noise MC33172 3.0 or ±1.5 44 or ±22 1.8 2.1 5.0 20 0.36 −40 to +85 90 32 2 Single, Split DIP−8, SO−8
Low Power, Single Supply, Two Voltage
Ranges MC33172V 3.0 or ±1.5 44 or ±22 1.8 2.1 5.0 20 0.36 −40 to +105 90 32 2 Single, Split
SO−8 Low Power, Single Supply, Two Voltage Ranges, Extended Temp.
Range
MC33178 ±2.0 ±18 5.0 2.0 3.0 100 .85 −40 to +85 110 7.5 2 Split DIP−8,
SO−8
High Output Current, Low Power, Low Noise *ID typical for total device (all channels)
ON Semiconductor Selector Guide − Analog Integrated Circuits
Dual Operational Amplifiers (continued)
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID* (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description
MC33202 1.8 or ±0.9 12 or ±6 2.2 1.0 8.0 80 1.8 −40 to +105 90 20 2 Single, Split DIP−8, SO−8, Micro8t
Low Voltage, Rail−to−Rail
MC33202V 1.8 or ±0.9 12 or ±6 2.2 1.0 8.0 80 1.8 −55 to +125 90 20 2 Single, Split DIP−8, SO−8 Low Voltage, Rail−to−Rail, Extended Temp. Range MC33272A 3.0 or ±1.5 36 or ±18 24 10 1 @ Vs = ±15 V 2 @ Vs = 5.0 V 300 4.30 −40 to +85 100 18 2 Single, Split DIP−8, SO−8
Single Supply, High SR, Low Input Offset Voltage
MC33502 1.0 7.0 5.0 3.0 5.0 0.04 pA 3.3 −40 to +105 75 30 2 Single, Split DIP−8, SO−8
One Volt SMARTMOS, Rail−to−Rail MC34072 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 3.2 0 to 70 97 32 2 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC34072A 3.0 or ±1.5 44 or ±22 4.5 13* 3.0 100 3.2 0 to 70 97 32 2 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, *Av = −1.0 MC34072V 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 3.2 −40 to +125 97 32 2 Single, Split DIP−8, SO−8 High SR, Wide BW, Single Supply, Extended Temp. Range, *Av = −1.0
NE592 −8.0 +8.0 90 − − 9.0 mA 18 0−70 86 − 2 − SO−8, 14 PDIP−8, 14 Video Amplifier
NE5532/A ±3.0 ±20 10 9.0 4.0 @ ±15 V 200 8.0 0 to 70 100 8.0 2 Split DIP−8,
SO−8, SO−16W
Low Noise
SA5532 ±3.0 ±20 10 9.0 4.0 @ ±15 V 200 8.0 −40 to 85 100 8.0 2 Split DIP−8 Low Noise
SE5532/A ±3.0 ±20 10 9.0 2.0 @ ±15 V 200 8.0 −55 to 125 100 8.0 2 Split DIP−8,
SO−8 Low Noise TCA0372 5.0 or ±2.5 40 or ±20 1.4 1.4 15 @ ±15 V 100 5.0 −40 to +125 90 22 2 Single, Split SOP (12+2+2)
http://onsemi.com
15
Quad Operational Amplifiers
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID* (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description
LM224 3.0 ±1.5 32 ±16 1.0 0.6 5.0 90 − −25 to +85 85 − 4 Single, Split DIP−14, SO−14 Low Power LM324 3.0 ±1.5 32 ±16 1.0 0.6 7.0 90 − 0 to 70 70 − 4 Single, Split DIP−14, SO−14 Low Power LM324A 3.0 ±1.5 32 ±16 1.0 0.6 3.0 45 0.7 0 to 70 70 − 4 Single, Split DIP−14, SO−14 Low Power LM2902 3.0 ±1.5 26 ±13 1.0 0.6 7.0 90 − −40 to +105 70 − 4 Single, Split DIP−14, SO−14 Low Power LM2902V 3.0 ±1.5 26 ±13 1.0 0.6 7.0 90 − −40 to +125 70 − 4 Single, Split DIP−14, SO−14 Low Power, Extended Temp. Range MC3303 3.0 ±1.5 36 ±18 1.0 0.6 8.0 200 2.8 −40 to +85 90 − 4 Single, Split DIP−14, SO−14 Low Power MC33074 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 6.4 −40 to +85 97 32 4 Single, Split DIP−14, SO−14, TSSOP−14 High SR, Wide BW, Single Supply, *AV = −1.0 MC33074A 3.0 or ±1.5 44 or ±22 4.5 13* 3.0 100 6.4 −40 to +85 97 32 4 Single, Split DIP−14, SO−14, TSSOP−14 High SR, Wide BW, Single Supply, *AV = −1.0 MC33079 ±5.0 ±18 16 7.0 2.5 300 8.4 −40 to +85 100 4.5 4 Split DIP−14, SO−14 Low Noise MC33174 3.0 or ±1.5 44 or ±22 1.8 2.1 5.0 20 0.72 −40 to +85 90 32 4 Single, Split DIP−14, SO−14, TSSOP−14
Low Power, Single Supply, Two Voltage Ranges MC33174V 3.0 or ±1.5 44 or ±22 1.8 2.1 5.0 20 0.72 −40 to +105 90 32 4 Single, Split DIP−14, SO−14
Low Power, Single Supply, Two Voltage Ranges, Extended Temp. Range MC33179 ±2.0 ±18 5.0 2.0 3.0 100 1.7 −40 to +85 110 7.5 4 Split DIP−14, SO−14 High Output Current, Low Power, Low Noise
ON Semiconductor Selector Guide − Analog Integrated Circuits
Quad Operational Amplifiers (continued)
Device Name VCC (min) (V) VCC (max) (V) GBW (typ) (MHz) Slew Rate (typ) (V/us) VIO (max @ 25_C, Vs = 5.0 V) (mV) IIB (typ) (nA) ID* (typ) (mA) Temp Range (_C) CMR (typ) (dB) en (typical)
ǒ
nVńǸHzǓ
@ f = 1.0 kHz Number of Channels SupplyType Package Description
MC33204 1.8 or ±0.9 12 or ±6.0 2.2 1.0 10 80 3.6 −40 to +105 90 20 4 Single, Split DIP−14, SO−14, TSSOP−14 Low Voltage, Rail−to−Rail MC33204V 1.8 or ±0.9 12 or ±6.0 2.2 1.0 10 80 3.6 −55 to +125 90 20 4 Single, Split DIP−14, SO−14 Low Voltage, Rail−to−Rail, Extended Temp. Range MC33274A 3.0 or ±1.5 36 or ±18 24 10 1.0 @ Vs = ±15 V 2.0 @ Vs = 5.0 V 300 8.6 −40 to +85 100 18 4 Single, Split DIP−14, SO−14 Single Supply, High SR, Low Input Offset Voltage MC3403 3.0 ±1.5 36 ±18 1.0 0.6 10 200 2.8 0 to 70 90 − 4 Single, Split DIP−14, SO−14 Low Power MC34074 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 6.4 0 to 70 97 32 4 Single, Split DIP−14, SO−14 High SR, Wide BW, Single Supply, *AV = −1.0 MC34074A 3.0 or ±1.5 44 or ±22 4.5 13* 3.0 100 6.4 0 to 70 97 32 4 Single, Split DIP−14, SO−14 High SR, Wide BW, Single Supply, *AV = −1.0 MC34074V 3.0 or ±1.5 44 or ±22 4.5 13* 5.0 100 6.4 −40 to +125 97 32 4 Single, Split DIP−14, SO−14 High SR, Wide BW, Single Supply, *AV = −1.0 NCV33274A 3.0 or ±1.5 36 or ±18 24 10 3.5 @ Vs = ±15 V 2.0 @ Vs = ±5.0 V 300 8.6 −40 to +125 100 18 4 Single, Split DIP−14, SO−14 Single Supply, High SR, Low Input Offset Voltage *ID typical for total device (all channels)
http://onsemi.com 17
Signal Conditioning
Comparators
LM211
LM311
NCS2200
NCS2201
NCS2202
NCS2203
LM293
LM393
LM2903
LM239
LM339
LM2901
MC3302
Single
Dual
Quad
MC10E1651
MC10E1652
NE521
NE522
High Speed
ON Semiconductor Selector Guide − Analog Integrated Circuits
Single Comparators
Device Name VCC (min) VCC (max) VIO (max) (mV) Iio (max) (nA) IlB (typ) (nA) Iq (typ) (mA) Temp Range (_C) Response Time (ns) Supply Type Number ofChannels Package Description
LM211 5.0 or ±2.5 36 or ±15 3.0 10 45 2.4 −25 to +85 200 Single Split
1 SO−8 Highly Flexible Voltage
LM311 5.0 or ±2.5 36 or ±15 7.5 50 45 2.4 0 to 70 200 Single Split 1 SO−8 DIP−8
Highly Flexible Voltage
NCS2200 0.85 or ±0.425 6.0 or ±3.0 +8.0 − 1.0 pA 10 −40 to 105 700 Single Split 1 SOT23−5 QFN 2x2.2
Low Voltage CMOS
NCS2201 0.85 or ±0.425 6.0 or ±3.0 +8.0 − 1.0 pA 10 −40 to 105 700 Single Split
1 SOT23−6 Low Voltage CMOS with Enable
NCS2202 0.85 or ±0.425 6.0 or ±3.0 +8.0 − 1.0 pA 10 −40 to 105 700 Single Split
1 SOT23−5 Low Voltage CMOS
NCS2203 0.85 or ±0.425 6.0 or ±3.0 +8.0 − 1.0 pA 10 −40 to 105 700 Single Split
1 SOT23−6 Low Voltage CMOS with Enable
Dual Comparators
Device Name VCC (min) VCC (max) VIO (max) (mV) Iio (max) (nA) IlB (typ) (nA) Iq* (typ) (mA) Temp Range (_C) Response Time (ns) Supply Type Number ofChannels Package Description
LM293 2.0 or ±1.0 36 or ±18 5.0 50 25 0.4 −25 to +85 1300 Single Split
2 SO−8 Low Offset Voltage
LM393 2.0 or ±1.0 36 or ±18 5.0 50 25 0.4 0 to 70 1300 Single Split 2 SO−8 DIP−8
Low Offset Voltage
LM2903 2.0 or ±1.0 36 or ±18 7.0 50 25 0.4 −40 to +105 1500 Single Split 2 SO−8 DIP−8
Low Offset Voltage
LM2903V 2.0 or ±1.0 36 or ±18 7.0 50 25 0.4 −40 to +125 1500 Single Split 2 SO−8 DIP−8
Low Offset Voltage
http://onsemi.com 19
Quad Comparators
Device Name VCC (min) VCC (max) VIO (max) (mV) Iio (max) (nA) IlB (typ) (nA) Iq* (typ) (mA) Temp Range (_C) Response Time (ns) Supply Type Number ofChannels Package Description
LM239 3.0 or ±1.5 36 or ±18 5.0 50 25 0.8 −25 to +85 1300 Single Split 4 SO−14 DIP−14 TTL and CMOS Compatible LM339 3.0 or ±1.5 36 or ±18 5.0 50 25 0.8 0 to 70 1300 Single Split 4 SO−14 DIP−14 TTL and CMOS Compatible LM2901 3.0 or ±1.5 36 or ±18 7.0 50 25 0.8 −40 to +105 1300 Single Split 4 SO−14 DIP−14 TTL and CMOS Compatible LM2901V 3.0 or ±1.5 36 or ±18 7.0 50 25 0.8 −40 to +125 1300 Single Split 4 SO−14 DIP−14 TTL and CMOS Compatible MC3302 3.0 or ±1.5 30 or ±15 20 100 25 0.8 −40 to +85 1300 Single Split 4 SO−14 DIP−14 TTL and CMOS Compatible *Iq typical for total device (all channels)
ON Semiconductor Selector Guide − Analog Integrated Circuits
Battery Management
Charge Controllers
Voltage & Current
Regulation
NiCd / NiMH
MC33340
MC33342
MC33341
Overvoltage Charger
Protection
NCP345
NCP346
Power Management
Single Cell Li−ion
NCP1800
NCP1835/B
http://onsemi.com
21
ON Semiconductor Switching Controllers Selection Tables
Boost
Pre−Regulator
AC−DC/Isolated Switching Controllers
Continuous Mode
NCP1653 Follower Boost
Power Factor Correction
Combo
PFC + PWM
Single−Stage
Flyback
NCP1650
Critical Mode
MC33260 Follower Boost
MC33262
MC34262
MC33368
Critical Mode/DCM
NCP1601
Critical Mode/DCM
NCP1603
Continuous Mode
NCP1651
Our products are also offered in lead−free (Pb−Free) packages. A “G’’ suffix is added at the end of the part number to recognize them.
Please consult our web site for more information.
CRM: Critical Conduction Mode CCM: Continuous Conduction Mode DCM: Discontinuous Conduction Mode
http://onsemi.com
23
Buck
(Step−Down)
DC−DC/Non−Isolated Switching Controllers
Multi−Topology
(Step−Up, Down,
or Inverting)
Boost
(Step−Up)
Cuk
(Inverting)
Coming Soon
General
Sync Rect
Single, External Switch
CS5211#
NCP1571
NCP1575
NCP1580
Single, Internal Switch
NCV8800*
NCP1595
Dual
NCP5422
NCP5425
Low Voltage/Low Power
NCP1500
NCP1530
NCP1508
NCP1510A
NCP1501
NCP1550
NCP1509
NCP1511
Non−Sync Rect
External Switch
CS51031
CS51033
Internal Switch
CS51411/2/3/4
MC33166/7
MC34166/7
LM2574/5/6
General
CS5171
CS5173
With 5 V/100 mA
Linear Regulator
CS5112*
Low Voltage/Low Power
NCP1400A
NCP1403
NCP1410
NCP1422
NCP1450A
NCP1402
NCP1406
NCP1411
NCP1421
NCP1423
CS5172
CS5174
External Switch
MC33060A
MC34060A
Internal Switch
MC33063A
MC34063A
NCV33063A*
MC33163
MC34163
NCV33163*
*Automotive
#Computer
Switching Capacitors
(Charge Pumps)
MAX828
MAX829
MAX1720
NCP1729
NCP5603
Our products are also offered in lead−free (Pb−Free) packages. A “G’’ suffix is added at the end of the part number to recognize them.
Please consult our web site for more information.
ON Semiconductor Selector Guide − Analog Integrated Circuits
BuckPWM Topology Overview
− + L C R Vout Vout+DVin DȀ +1*D+ Toff Ton)Toff+ Toff Ts Duty Cycle+D+ TonTon)Toff+ Ton
Ts
Vin
Attributes: Step down only MOSFET stress = Vin Boost − + L C R Vout Vin Vout+D1ȀVin Attributes: Step up only
Used for power factor correction MOSFET stress = Vout
− + C R Vout Vout+ *DDȀ Vin Vin − + Attributes: Buck−Boost Ton Toff Ts
NOTE: In all circuits, equations for Vout apply to the continuous conduction case.
− + C R Vout Vin Vout+nDDȀVin Flyback n:1 L
http://onsemi.com
25
PWM Topology Overview (continued)
− +
R Vout
Vin
Attributes:
Step up, step down, or inverting More complex transformer Reset winding is needed (m t n) Potentially more than 50% duty cycle Up to 200 W power level MOSFET stress u Vin Forward C n:1 Vout+Dn Vin L m − + R Vout Vin Attributes:
Step up, step down, or inverting Useful for low input voltage applications Up to 1.0 kW power level
More complex transformer Duty cycle t 50% MOSFET stress = 2.0 Vin Push−Pull C Vout+Dn Vin L n n 1 1 − + R Vout Vin Attributes:
Step up, step down, or inverting Up to 500 W power level Simple transformer construction
Primary winding is also the reset winding, so duty cycle t 50% MOSFET stress = Vin
Two−Transistor Forward
C n:1
Vout+Dn Vin D max+0.5 L
Lp
Attributes:
Step up, step down, or inverting Simple transformer construction Potentially more than 50% duty cycle Up to 500 W power level
MOSFET stress > Vin
Active Clamp Forward
C Vout+Dn Vin − + n:1 Vin −+ R Vout L
ON Semiconductor Selector Guide − Analog Integrated Circuits
PWM Topology Overview (continued)
−
+ R Vout
Vin
Attributes:
Step up, step down, or inverting Alternative to 2−transistor forward Up to 500 W power level Duty cycle t 50% MOSFET stress = Vin Half−Bridge C Vout+2nDVin L 1 1 n − + R Vout Vin Attributes:
High power applications Step up, step down, or inverting Up to 2.0 kW power level Duty cycle t 50%
Phase−shifted version possible for high density
Current doubler version useful for very high output currents MOSFET stress = Vin Full−Bridge C Vout+Dn Vin L 1 1 n
SEPIC (Single−Ended Primary Inductor Converter)
C R Vout
Vout+DDȀVin −
+ Vin
C4uk (By Slobodan C4uk)
− + C R Vout Vin Vout+ *DDȀVin + − + −
http://onsemi.com
27
CRM: Critical Conduction Mode CCM: Continuous Conduction Mode DCM: Discontinuous Conduction Mode
ON Semiconductor Selector Guide − Analog Integrated Circuits
PFC/PWM Combo Controllers
Power
Level PFC Stage PWM Stage Temp. Range Package Part No. Features
Up to
200 W Integrated single−stage CCM or DCM flyback
−40 to +125°C (TJ) SO−16 NCP1651DR2 SLossless 500 V startup SProgrammable frequency 20 to 250 kHz SExternal shutdown SThermal shutdown (110/140_C) Up to 250 W Fixed−frequency DCM or critical mode 100 kHz 80% max duty DCM/CCM flyback −40 to +125°C (TJ) SO−16 NCP1603D100R2 SLossless 500 V startup
SPFC section shutdown while standby
SPWM section in skipping cycle operation while standby
SOptional synchronization capability
SOptional OVP latch CRM: Critical Conduction Mode
CCM: Continuous Conduction Mode DCM: Discontinuous Conduction Mode
http://onsemi.com
29
CRM: Critical Conduction Mode CCM: Continuous Conduction Mode DCM: Discontinuous Conduction Mode
ON Semiconductor Selector Guide − Analog Integrated Circuits
Power Factor Correction Controllers
Power
Level PFC Methodology Operating Mode Temp. Range Package Part No. Features
Up to 400 W
Voltage−mode boost DCM or critical modeFixed frequency −40 to +125(T °C J)
SO−8 NCP1601ADR2 SSynchronization capability or programmable frequency
SOvervoltage protection
SProgrammable overcurrent protection
SThermal shutdown (95/140_C) SNCP1601A: VCC UVLO = 4.75 V SNCP1601B: VCC UVLO = 1.5 V DIP−8 NCP1601AP SO−8 NCP1601BDR2 DIP−8 NCP1601BP Follower boost Critical conduction mode −40 to +105°C (TJ) SO−8 MC33260DR2 S
Fixed 500 kHz frequency clamp
SProgrammable overcurrent limitation
SOvervoltage protection
SUndervoltage protection
SMaximum on−time limitation
SThermal shutdown (120/150_C) DIP−8 MC33260P Peak current−mode boost −40 to +105°C (TA)
SO−8 MC33262DR2 SOvercurrent limitation
SRestart delay after fault
SOvervoltage protection DIP−8 MC33262P 0 to +85°C (TA) SO−8 MC34262D DIP−8 MC34262P −25 to +125°C (TA)
SO−16 MC33368DR2 SAll features of MC33262
SLossless 500 V startup
SProgrammable restart delay
SProgrammable frequency clamp
DIP−16 MC33368P Up to 3.0 kW Average current−mode or peak I−mode follower boost 100 kHz CCM −40 to +125(T _C J)
SO−8 NCP1653DR2 SSOvervoltage protectionUndervoltage protection or shutdown
SProgrammable overcurrent protection
SProgrammable overpower limitation
SThermal Shutdown (120/150_C) DIP−8 NCP1653P Average current−mode boost Fixed frequency CCM or DCM −40 to +125_C (TJ) SO−16 NCP1650DR2
STrue power limiting circuit maintains excellent power factor in constant power mode
S25 to 250 kHz fixed frequency
SOvervoltage protection
SBrownout protection
SExternal shutdown CRM: Critical Conduction Mode
http://onsemi.com
31 auto tag
ON Semiconductor Selector Guide − Analog Integrated Circuits
Flyback Regulators (Integrated High−Voltage Startup, Internal Switch, Fixed Freq., Dynamic Self Supply)
IC Operating Voltage
Startup
Limits Switch
Output
Voltage Control Temp. Package
Max.
Duty Freq.
RDS(ON)
@ TJ =
255C Part No. Features
UVLO: 4.7/7.5/ 8.5 V Max: 10 V 30/ 700 V 700 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) DIP−7 67% Suffix xx = 06, 10, or 13 for 65, 100, or 130 kHz Typ. 22 W
NCP1010APxx SAll features in NCP105x and... SLatching overvoltage protection (needs auxiliary winding) SThermal shutdown (100/150_C) SGullwing package is coming soon 100 mA SOT−223 NCP1010STxxT3 700 V DIP−7 NCP1011APxx 250 mA SOT−223 NCP1011STxxT3 700 V DIP−7 Typ. 11 W NCP1012APxx 250 mA SOT−223 NCP1012STxxT3 700 V DIP−7 NCP1013APxx 350 mA SOT−223 NCP1013STxxT3 700 V DIP−7 NCP1014APxx 450 mA SOT−223 NCP1014STxxT3 UVLO: 4.5/7.5/ 8.5 V Max: 10 V 20/ 700 V 700 V (Vref = external or 4.6 V) Burst mode V−mode −40 to +125_C (TJ) DIP−7 77% Suffix xx = 44, 100, or 136 for 44, 100, or 136 kHz Typ. 22 W NCP1050Pxx SFrequency jittering reduces EMI
SAuto restart fault protection
SThermal shutdown (85/160_C)
SStandby operation due to burst mode 100 mA SOT−223 NCP1050STxxT3 700 V DIP−7 NCP1051Pxx 200m A SOT−223 NCP1051STxxT3 700 V DIP−7 NCP1052Pxx 300m A SOT−223 NCP1052STxxT3 700 V DIP−7 Typ. 10 W NCP1053Pxx 400 mA SOT−223 NCP1053STxxT3 700 V DIP−7 NCP1054Pxx 530m A SOT−223 NCP1054STxxT3 700 V DIP−7 NCP1055Pxx 680 mA SOT−223 NCP1055STxxT3 UVLO: 6.6/7.6/ 10.2 V Max: 16 V 16.8/ 200 V 200 V 0.5 A (Vref = 2.5 V) PWM V−mode −40 to +125_C (TJ) Micro8t 75% Up to 1.0 MHz Typ. 4.1 W NCP1030DMR2 SExternal Synchronization SThermal shutdown (105/150_C) 200 V SO−8 Typ. NCP1031DR2
http://onsemi.com
ON Semiconductor Selector Guide − Analog Integrated Circuits
Flyback Regulators (Integrated High−Voltage Startup, Internal Switch, Fixed Freq., No Dynamic Self Supply)
IC Operating Voltage
Startup
Limits Switch
Output
Voltage Control Temp. Package
Max.
Duty Freq.
RDS(ON)
@ TJ =
255C Part No. Features
UVL: 9.5/15.2 V Max: 40 V TBD/ 500 V 700 V 0.72 A (Vref = 2.6 V) PWM V−mode −25 to +150_C (TJ) SO−16W 50% 300 kHzUp to Typ. 15 W MC33363BDW SOVP SThermal shutdown (145/155_C for 63A & 62, 105/135_C for 63B) UVLO: 9.5/14.9 V Max: 40 V TBD/ 500 V 700 V 0.9 A DIP−16 Typ. 7.5 W MC33363AP SO−16W MC33363ADW UVLO: 9.5/14.5 V Max: 40 V TBD/ 400 V 500 V 0.9 A DIP−16 Typ. 4.4 W MC33362P SO−16W MC33362DW UVLO: 7.5/8.5 V Max: 10 V 20/ 700 V* 700 V 0.5 A (External ref.) PWM V−mode −40 to +125_C (TJ) DIP−8 72% 100 kHz Typ. 13 W NCP1000P SOpto fail−safe shutdown (OVP) S*(700 V is guaranteed by design) SThermal shutdown (110/140_C) 700 V 1.0 A Typ. 7.0 W NCP1001P 700 V 1.5 A Typ. 4.0 W NCP1002P
http://onsemi.com
ON Semiconductor Selector Guide − Analog Integrated Circuits
Flyback Controllers (Integrated High−Voltage Startup, External Switch, Fixed Freq., No Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp.
Drive Output
Max.
Duty Freq. Package Part No. Features
UVLO: 6.6/ 10/13.1 V Max: 16 V 50/ 500 V (External ref.) PWM V−mode /Sec reconfig standby −25 to +85_C (TA) TBD 82% 40 DIP−8 MC44608P40 SOvercurrent limitation SOver VCC protection
SOvertemperature protection with hysteresis (130_C/160_C) 75 MC44608P75 UVLO: 4.9/ 7.8/ 12 V Max: 16 V 30/ 500 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) 250 mA 80% 40
DIP−8 NCP1203P40 SModification of NCP1200A without DSS SThermal shutdown (140/170_C) SO−8 NCP1203D40R2 60 DIP−8 NCP1203P60 SO−8 NCP1203D60R2 100 DIP−8 NCP1203P100 SO−8 NCP1203D100R2 UVLO: 5.6/ 7.6/ 12.8 V Max: 16 V TBD/ 500 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) 500 mA 74%
65 DIP−7 NCP1217P65 SSInternal ramp compensationLatching OVP protection
SThermal shutdown (125/155_C) SO−8 NCP1217D65R2 100 DIP−7 NCP1217P100 SO−8 NCP1217D100R2 133 DIP−7 NCP1217P133 SO−8 NCP1217D133R2 UVLO: 5.6/ 7.7/ 12.6 V Max: 18 V 20 500 V (External ref.) PWM I−mode/ Skip cycle standby −40 to +125_C (TJ) +500/ −800 mA 80%
65 DIP−7 NCP1230P65 SEvent management schemedisables PFC_VCC output during standby, or overload condition
SLatching OVP protection
SThermal shutdown (140/165_C)
SFiltering dithering for EMI
SO−8 NCP1230D65R2 100 DIP−7 NCP1230P100 SO−8 NCP1230D100R2 133 DIP−7 NCP1230P133 SO−8 NCP1230D133R2 UVLO: 11.2/ 16.4 V Max: 36 V TBD/ 500 V (External ref.) (*) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) +500/ −800 mA 80% Adjustable up to 250 kHz SO−16 NCP1239FDR2
SGo−to−standby signal for PFC
SAdjustable skip−cycle capability
SSelectable soft−start period
SThermal shutdown (110/140_C)
SFrequency dithering for EMI
SBrown−out protection
SInternal ramp compensation
http://onsemi.com
ON Semiconductor Selector Guide − Analog Integrated Circuits
Flyback Controllers (Integrated High−Voltage Startup, External Switch, Fixed Freq., Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp.
Drive Output
Max. Duty
Freq.
(kHz) Package Part No. Features
UVLO: 6.3/9.8/ 11.4 V Max: 16 V 30/ 500 V (External ref.) PWM I−mode/ Skip cycle standby −25 to +125_C (TJ) 250 mA 80%
40 DIP−8 NCP1200P40 SAdjustable peak skipping current for lowlevel of audible noise
SInternal output short−circuit protection
SThermal shutdown (140_C) SFrequency jittering SO−8 NCP1200D40R2 60 DIP−8 NCP1200P60 SO−8 NCP1200D60R2 100 DIP−8 NCP1200P100 SO−8 NCP1200D100R2 UVLO: 10.5/ 12.5 V Max: 16 V TBD/ 500 V (External ref.) PWM I−mode/ Skip cycle standby −25 to +125_C (TJ) 250 mA 83% 60 DIP−8 NCP1201P60 S
Modification of NCP1200A with Brownout Detect Protection, BOK function but fixed skip−cycle level
SLatch−off fault protection
SFrequency jittering SO−8 NCP1201D60R2 10 DIP−8 NCP1201P100 SO−8 NCP1201D100R2 UVLO: 5.6/10/ 12.2 V Max: 16 V 30/ 500 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) 500 mA 75%
65 DIP−7 NCP1216P65 SSInternal ramp compensationThermal shutdown (125/155_C)
SO−8 NCP1216D65R2 100 DIP−7 NCP1216P100 SO−8 NCP1216D100R2 133 DIP−7 NCP1216P133 SO−8 NCP1216D133R2
http://onsemi.com
39
Flyback Controllers (Integrated High−Voltage Startup, External Switch, Variable Freq., Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp. Option Package Part No. Features
UVLO: 10/12 V Max: 16 V 40/ 500 V (External ref.) I−mode/ Skip cycle standby 0 to +125_C (TJ) 8.0 ms minimum off−time Freq Clamp SO−8 NCP1207ADR2
SDynamic Self−Supply which needs no auxiliary winding and startup resistor
SAdjustable skip−cycle capability
SThermal shutdown (125/155_C)
SLatched overvoltage protection
S500 mA output peak current capability
SThermal shutdown
DIP−8 NCP1207AP
Flyback Controllers (Integrated High−Voltage Startup, External Switch, Variable Freq., No Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp. Option Package Part No. Features
UVLO: 7.6/15 V Max: 16 V TBD/ 700 V (External ref.) I−mode/ Critical mode −25 to +125_C (TJ)
Variable FC SO−16 MC33364D SOvercurrent limitation
SThermal shutdown (130/180_C)
SRestart delay after fault Fixed FC SO−8 MC33364D1 No Freq Clamp (FC) MC33364D2 UVLO: 7.2/15 V Max: 45 V TBD/ 500 V (Vref = 2.5 V) I−mode/ Freq foldback standby −25 to +125_C (TJ)
− DIP−8 NCP1205P S250 mA output peak current capability
SAdjustable maximum switching frequency Adjustable OVP DIP−14 NCP1205P2 SO−16 NCP1205DR2 UVLO: 7.5/12.5 V Max: 16 V 40/ 500 V (External ref.) I−mode/ Skip cycle standby 0 to +125_C (TJ) (*) 4.5 ms/ 8.0 ms
DIP−7 NCP1377P S(*) The time are sampling delay for OVP and minimum off−time SThermal shutdown (125/155_C) SO−8 NCP1377DR2 (*) 1.5 ms/ 3.0 ms DIP−7 NCP1377BP SO−8 NCP1377BDR2 UVLO: 7.5/8.4 V Max: 16 V TBD/ 500 V (External ref.) I−mode/ Skip cycle standby 0 to +125_C (TJ) 8.0 ms minimum off−time Freq Clamp
DIP−7 NCP1378P SNCP1377 with lower OVP level
(5.2 V against 7.2 V)
SThermal shutdown (125/155_C)
http://onsemi.com
41
Flyback Controllers (External Startup, UC3843 Pin−Compatible)
IC Max Operating Voltage UVLO Max. Duty Temp. (TA)
Max. Startup Current
Package/Part No.
DIP−8 SO−8 SO−14
40 V 7.4/ 8.0 V Typ. 96% −40 to +85°C 1.0 mA CS2841BEN8 CS2841BED14 30 V 10/16 V 0 to +70°C 1.0 mA UC3842AN UC3842ADR2
0.5 mA UC3842BN UC3842BD1R2 UC3842BDR2
−25 to +85°C 1.0 mA UC2842AN UC2842ADR2
0.5 mA UC2842BN UC2842BD1R2 UC2842BDR2
−40 to +105°C 0.5 mA UC3842BVD1R2
7.6/8.4 V
0 to +70°C 1.0 mA UC3843AN UC3843ADR2
0.5 mA UC3843BN UC3843BD1R2 UC3843BDR2
−25 to +85°C 1.0 mA UC2843AN UC2843AD1R2 UC2843ADR2
0.5 mA UC2843BN UC2843BD1R2 UC2843BDR2
−40 to +105°C 0.5 mA UC3843BVN UC3843BVD1R2 UC3843BVDR2
−40 to +125°C 0.5 mA NCV3843BVDR2
10/16 V
50%
0 to +70°C 1.0 mA UC3844N UC3844DR2
0.5 mA UC3844BN UC3844BD1R2 UC3844BDR2
−25 to +85°C 1.0 mA UC2844N UC2844DR2
0.5 mA UC2844BN UC2844BD1R2 UC2844BDR2
−40 to +105°C 0.5 mA UC3844BVN UC3844BVD1R2 UC3844BVDR2
7.6/ 8.4 V
0 to +70°C 1.0 mA UC3845N UC3845DR2
0.5 mA UC3845BN UC3845BD1R2 UC3845BDR2
−25 to +85°C 1.0 mA UC2845N UC2845DR2
0.5 mA UC2845BN UC2845BD1R2 UC2845BDR2
http://onsemi.com
43
Flyback Controllers (External Startup, Non−UC3843 Pin−Compatible)
IC Operating Voltage Freq. Temp. (TA) Output Voltage Drive Capability Max.
Duty Control Package Part No. Features
UVLO: 7.5/9.0/14.5 V Max: 18 V Up to 250 kHz −25 to +85_C (Vref = 2.5 V) 750 mA 80% Fixed freq. or critical mode with standby
SOP−16 MC44603DW SOvervoltage protection
SThermal shutdown
SProgrammable soft−start
SFoldback pin for overload protection
SAdjustable maximum duty
SLow switching frequency in standby (not for MC44604 which goes to pulse mode in standby)
DIP−16 MC44603P SOP−16 MC44603ADW DIP−16 MC44603AP DIP−16 MC44604P Up to 250 kHz or SYNC 75% Fixed freq or
critical mode DIP−16 MC44605P
SOvervoltage protection
SWinding short circuit detection programming
SOverheating detection
SProgrammable soft−start
SMaximum power limitation
UVLO: 3.8/4.6 V Max: 15 V Up to 1.0 MHz −40 to +85_C (Vref = 1.263 V) (*) 1.0 A 85% PWM Feed−forward V−mode SO−16 CS51221EDR16
SLow startup current (<75 mA)
SPulse−by−pulse current limit
SThermal shutdown
SProgrammable soft−start
SUndervoltage protection
SOvervoltage protection with programmable hysteresis SBidirectional synchronization S(*) 3.3 V 3% reference pin UVLO: 7.7/8.25 V Max: 20 V −40 to +85_C (Vref = 2.515 V) 1.0 A 77% PWM I−mode SO−16 CS51021AEDR16
SLow startup current (<75 mA)
SInput undervoltage protection, input overvoltage protection
SDual overcurrent protection with delayed restart
SProgrammable soft−start
SSynchronous option for CS51021 or sleep option for CS51022
CS51022AED16 UVLO: 10/15 V OVLO: 25 V Max: 28 V Up to 200 kHz −25 to +105_C (TJ) (External ref.) 100 mA sink 300 mA source 48%/ 82% PWM I−mode
DIP−8 NCP1212P SSelectable max duty
SBrownout detect (BOK)
SOvervoltage protection by OVLO
SProgrammable soft−start
ON Semiconductor Selector Guide − Analog Integrated Circuits
Flyback Controllers (External Startup, Non−UC3843 Pin−Compatible) (continued)
IC Operating Voltage Freq. Temp. (TA) Output Voltage Drive Capability Max.
Duty Control Package Part No. Features
UVLO: 9.0/12.5 V Max: 18 V N/A 0 to +105_C (External ref.) 30 mA N/A Quasi−fixed on−time variable off−time
SO−8 NCP1215ADR2 SLow−cost solution for 2 X 5 W
SFrequency foldback in light load
SNegative primary current sensing
SVery low startup current (<6.5 mA)
TSOP−6 NCP1215ASNT1 UVLO: 8.4/9.2 V Max: 30 V Up to 1.0 MHz −40 to +105_C (External ref.) (*) 200 mA 90% PWM I−mode
SO−16W MC33023DW SCycle−by−cycle current limitation
SSoft−start
SFunctionally similar to UC3823
S(*) 5.1 V reference pin 0 to +70_C DIP−16 MC34023P UVLO: 7.3/7.7 V Max: 20 V Fixed 400 kHz −40 to +105_C (External ref.) TBD 82.5% PWM I−mode SO−8 CS5124XDR8
SDesign for very few external components
SThermal shutdown
SProgrammable soft−start
SSleep pin
SDual overcurrent protection
http://onsemi.com
45 auto tag
ON Semiconductor Selector Guide − Analog Integrated Circuits
Forward Controllers (Integrated High−Voltage Startup, External Switch, Fixed Freq., Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp.
Drive Output
Max. Duty
Freq.
(kHz) Package Part No. Features
UVLO: 5.6/10/ 12.2 V Max: 16 V 30/ 500 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) 500 mA 46.5%
65 DIP−7 NCP1216AP65 SSInternal ramp compensationThermal shutdown (125/155_C) S1.0 ms soft−start SO−8 NCP1216AD65R2 100 DIP−7 NCP1216AP100 SO−8 NCP1216AD100R2 133 DIP−7 NCP1216AP133 SO−8 NCP1216AD133R2 UVLO: 7.0/11 V Max: 16 V 25/ 700 V (External ref.) (*) PWM Sync. Rect. V−mode Active clamp −40 to +125_C (TJ) 10 mA (Adj) 80% Adjustable up to 500 kHz SO−16 NCP1280DR2
SLine UV/ OV shutdown
SCurrent limit
SProgrammable soft−start
SProgrammable FET non−overlap
S(*) 5.0 V reference pin
Forward Controllers (Integrated High−Voltage Startup, External Switch, Fixed Freq., No Dynamic Self Supply)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp.
Drive Output
Max. Duty
Freq.
(kHz) Package Part No. Features
UVLO: 5.6/7.6/ 12.8 V Max: 16 V 30/ 500 V (External ref.) PWM I−mode/ Skip cycle standby 0 to +125_C (TJ) 500 mA 46.5% 65
DIP−7 NCP1217AP65 SInternal ramp compensation
SLatching OVP protection
SThermal shutdown (125/155_C) S1.0 ms soft−start SO−8 NCP1217AD65R2 100 DIP−7 NCP1217AP100 SO−8 NCP1217AD100R2 133 DIP−7 NCP1217AP133 SO−8 NCP1217AD133R2 UVLO: 11.2/ 16.4 V TBD/ (External PWM I−mode/ 0 to +125_C +500/ (Adj) Adjustable up to SO−16 NCP1239VDR2
SGo−to−standby signal for PFC
SAdjustable skip−cycle capability
SSelectable soft−start period
http://onsemi.com
47
Forward Controllers (External Startup, External Switch, Fixed Freq.)
IC Operating Voltage
Startup Limits
Output
Voltage Control Temp.
Max.
Duty Freq. Package Part No. Features
UVLO: 10/15 V OVLO: 25 V Max: 28 V Not available (External ref.) PWM I−mode/ Skip cycle standby −25 to +105_C (TJ) 48%/ 82% Adjustable up to 200 kHz DIP−8 NCP1212P
SSelectable max duty for forward or flyback
SBrownout detect (BOK)
SOvervoltage protection by OVLO
SProgrammable soft−start
http://onsemi.com
49
Half−Bridge/Resonant Controllers
IC Operating
Voltage Freq. Control Temp. (TA) Package Part No. Features
UVLO: 9.0/16 V Max: 20 V Typ. 525 kHz to 2050 kHz ZVS − modulated constant off−time 0 to +70_C
SO−16W MC34067DWR2 SProgrammable soft−start circuitry
SPrecise re−triggerable one−shot timer
DIP−16 MC34067P −40 to +85_C SO−16W MC33067DWR2 DIP−16 MC33067P UVLO: 7.0/10.3 V Max: 16 V Adj up to 250 kHz PWM feedforward V−mode or I−mode −40 to +125_C (TJ) SO−16 NCP1561DR2
ON Semiconductor Selector Guide − Analog Integrated Circuits
http://onsemi.com 51
Push−Pull Controllers
IC Operating Voltage Freq. Output Voltage Drive Capability Control Max.Duty Temp. (TA) Package Part No. Features
8.0 to 35 V Up to 400 kHz OR SYNC (External ref.) (*) 400 mA peak PWM I mode or V mode 49% 0 to +70_C
DIP−16 SG3525AN SProgrammable dead time
SProgrammable soft−start SShutdown S(*) 5.0 V 1% reference pin SO−16W SG3525ADWR2 UVLO: 8.4/9.2 V Max: 30 V Up to 1.0 MHz OR SYNC (External ref.) (*) 200 mA 45% 0 to +70_C
SO−16W MC34025DW SCurrent limit/shutdown
SSoft−start
S(*) 5.1 V reference pin
SFunctionally similar to the UC3825
DIP−16 MC34025P −40 to +105_C SO−16W MC33025DW DIP−16 MC33025P UVLO: 6.43 V Max: 42 V Up to 200 kHz (External ref.) (*) 200 mA 48%/ 45% 0 to +70_C
SO−16 TL494CD SAdjustable dead time
S(*) 5.0 V 5% reference pin DIP−16 TL494CN −40 to +85_C DIP−16 TL494IN −40 to +125_C SO−16 NCV494BD UVLO: 5.05/5.2 V Max: 42 V (External ref.) (*) 200 mA 48%/ 45% −25 to +85_C
SO−16 TL594CD SAdjustable dead time
S(*) 5.0 V 1.5% reference pin DIP−16 TL594CN TSSOP−16 TL594CDTB UVLO: 7.0/10.3 V Max: 16 V Adj. up to 250 kHz (External ref.) (*) 10 mA PWM FF V−mode or I−mode Adj. up to 50% (**) −40 to +125_C (TJ) SO−16 NCP1561DR2 S21.5/150 V Integrated Startup SUndervoltage detector
SDual mode overcurrent
SThermal shutdown
SProgrammable soft−start
S(*) 5.0 V reference pin
http://onsemi.com
53
Multi−Output Flyback Secondary Side Post Regulation
IC Operating Voltage Converter Input Voltage Output Voltage Output
Driver Freq. Temp. (TA) Package Part No. Features
ULVO: 7.0/8.0 V Max: 45 V (Vgate max: 75 V) (Vref = 2.0 V) 1.5 A SYNC −40 to +85_C SO−16L CS5101EDW16 S Voltage mode
SConfigured as either buck or boost with external NFET
SExternally programmable overcurrent protection
S5.0 V 2% reference pin
DIP−14 CS5101EN14
Synchronous Buck Post Regulator Controller − Forward Topologies
Temp. (Tj) Package Part No.
−40 to +125_C SO−8 NCP4330DR2
Secondary Controller for Multi−Output Quasi−Resonant Switch−Mode Power Supplies
Temp. (Tj) Package Part No.
http://onsemi.com
55
Boost Controllers (Low−Voltage, Low−Power/Portable Applications)
Converter/IC Min. Input
Voltage
Switch
Current Control Freq. Temp. (TA) Package
Converter Output
Voltage Part No. Features
0.8 V 100 mA PWM 180 kHz −40 to +85_C TSOP−5
1.9 V NCP1400ASN19T1 SCE pin (chip enable)
2.2 V NCP1400ASN22T1 2.5 V NCP1400ASN25T1 2.7 V NCP1400ASN27T1 3.0 V NCP1400ASN30T1 3.3 V NCP1400ASN33T1 3.8 V NCP1400ASN38T1 4.5 V NCP1400ASN45T1 5.0 V NCP1400ASN50T1 0.8 V 200 mA PFM Max 180 kHz −40 to +85_C TSOP−5
1.9 V NCP1402SN19T1 SCE pin (chip enable)
2.7 V NCP1402SN27T1 3.0 V NCP1402SN30T1 3.3 V NCP1402SN33T1 5.0 V NCP1402SN50T1 0.8 V Ext. N−FET PWM 180 kHz −40 to +85_C
1.9 V NCP1450ASN19T1 SCE pin (chip enable)
2.7 V NCP1450ASN27T1
3.0 V NCP1450ASN30T1
3.3 V NCP1450ASN33T1
5.0 V NCP1450ASN50T1
1.0 V 250 mA Sync. Rect.PFM 600 kHzMax −40 to +85_C Micro8 1.5 V to5.5 V NCP1411DMR2
SLow−battery detector
SRing killer for efficiency NCP1410DMR2 SLow−battery detector 0.8 V 400 mA Sync. Rect. PFM Max 600 kz −40 to +85_C Micro10 1.8 V to 3.3 V NCP1423DMR2 STrue−cutoff
SRing killer for efficiency
SLow battery detect input/output
SAuto discharge input
ON Semiconductor Selector Guide − Analog Integrated Circuits
Boost Controllers (Low−Voltage, Low−Power/Portable Applications) (continued)
Converter/IC Min. Input
Voltage
Switch
Current Control Freq. Temp. (TA) Package
Converter Output
Voltage Part No. Features
1.0 V 600 mA Sync. Rect.PFM 1.2 MHzMax −40 to +85_C Micro8 1.5 V to5.0 V NCP1421DMR2
STrue−cutoff
SRing killer for efficiency
SLow battery detect 1.0 V 800 mA Sync. Rect.PFM 1.2 MHzMax −40 to +85_C DFN−10 1.5 V to5.0 V NCP1422MNR2
SRing killer for efficiency
SLow battery detector
SThermal shutdown
1.8 V 100 mA PFM 300 kHzMax −40 to +85_C TSOP−5 Up to 15 V NCP1403SNT1 SCE pin (chip enable)
http://onsemi.com
ON Semiconductor Selector Guide − Analog Integrated Circuits
Buck Controllers (Low−Voltage, Low−Power/Portable Applications)
Converter Input Voltage
Switch
Current Control Freq. Temp. Package
Converter Output
Voltage Part No. Features
2.5 to 5.2 V 500 mA Sync. Rect. PWM/ Pulsed 1.0 MHz or sync 450 kHz to 1.0 MHz −30 to +85_C (TA) Micro Bump−9 1.05 V, 1.35 V, 1.57 V, 1.8 V NCP1510AFCT1
SUltra low 14 mA quiescent current at light load
SOperation depends on SYNC pin in three modes (Pulsed, PWM or synchronized)
SSuffix G for Lead−free package
S(Coming soon) 1.0 V, 1.3 V, 1.5 V, 1.89 V NCP1511FCT1 DFN−10 1.0 V, 1.3 V, 1.5 V, 1.89 V NCP1508MNR2 1.35 V, 1.57 V, 1.8 V NCP1509MNR2 1.1 * Vout to 5.5 V 600 mA PFM/ PWM 600 kHz −40 to +85_C (TA) Micro8 2.5 V NCP1530DM25R2 SExternal sync up to 1.2 MHz 2.7 V NCP1530DM27R2 3.0 V NCP1530DM30R2 3.3 V NCP1530DM33R2 2.7 to 5.4 V 800 mA Linear/ PFM/ PWM Sync 270 to 630 kHz −40 to +85_C (TA) Micro8 1.0 V, 1.3 V, 1.5 V, 1.8 V Digitally programmable NCP1500DMR2 SShutdown pin SThermal shutdown
SLinear/switching mode options
SNo internal oscillator 2.7 to 5.2 V Sync. Rect. PWM/ Linear Sync 500 kHz to 1.0 MHz −30 to +85_C (TA) 1.05 V, 1.35 V, 1.57 V, 1.8 V NCP1501DMR2 UVLO: 2.15/ 2.2 V Max: 5.5 V Ext. P−FET PFM/ PWM 600 kHz −40 to +85_C (TA) TSOP−5
1.8 V NCP1550SN18T1 SCE pin (chip enable)
SCircuit operates at PFM at light load to maintain high efficiency
1.9 V NCP1550SN19T1
2.5 V NCP1550SN25T1
2.7 V NCP1550SN27T1
http://onsemi.com
ON Semiconductor Selector Guide − Analog Integrated Circuits
Buck Controllers (Sync. Rect., Single, External Switch)
IC Operating Voltage Converter Input Voltage Output
Voltage Freq. Temp. Control Package Part No. Features
UVLO: 3.9/ 4.05 V Max. 16 V (Vgate max: 20 V) Min. 1.0 V 150 to 750 kHz −40 to +85_C (TA) Sync. Rect. PWM V2 mode SO−14
CS5211ED14 SDriving dual N−FET
SProgrammable soft−start
SHiccup mode short circuit protection
0 to +70_C (TA) CS5211GD14 UVLO: 2.7/ 2.8 V Max: 4 V −40 to +85_C (TA) CS5212ED14 0 to +70_C (TA) CS5212GD14 UVLO: 7.5/ 8.5 V Max: 15 V (Vgate max: 15 V) Min. 0.980 V Fixed 200 kHz 0 to +125_C (TJ) SO−8 NCP1571D
SDriving dual N−FET
SPower good
SProgrammable power good delay
SProgrammable soft−start (Not for NCP1573) SOvervoltage protection Max: 15 V Min. 0.980 V NCP1573D UVLO: 7.5/ 8.5 V Max: 20 V (Vgate max: 20 V) Min. 0.980 V Adjustable 200 to 500 kHz NCP1575D
SDriving dual N−FET
SProgrammable soft−start SOvervoltage protection UVLO: 3.7/ 4.2 V Max: 15 V (Vgate max: 30 V) Min. 0.8 V Fixed 350 kHz −40 to +125_C (TJ) PWM V−mode SO−8 NCP1580DR2
SDriving dual N−FET
S1.5 A gate drivers
SInternal soft−start
SAdaptive non−overlap
SThermal shutdown (160_C)
Buck Regulators (Sync. Rect., Single, Internal Switch)
IC Operating Voltage
Converter Output
Voltage Switch Freq. Temp. Control Option Package Part No. Features
Sequenced: 3.5 to 16 V High Voltage: 6.0 to 16 V 2.6 V (1.6 A Current limit) Fixed 200 kHz −40 to +125_C (TJ) Sync. Rect. PWM V2 mode Sequenced SO−16L NCV8800SDW26 SReset pin SEnable pin SThermal shutdown High Voltage NCV8800HDW26 3.3 V Sequenced NCV8800SDW33 High Voltage NCV8800HDW33
http://onsemi.com
61
Buck Controllers (Sync. Rect., Dual)
IC Operating Voltage Converter Input Voltage Output
Voltage Freq. Temp. Control Package Part No. Features
UVLO: 7.8/ 8.6 V Max: 16 V (Vgate max: 20 V) Min. 1.0 V 15 to 600 kHz 0 to +70_C (TA) Sync. Rect. PWM V2 mode SO−16 NCP5422ADR2
SOut−of−phase for ripple cancellation
SDriving dual N−FET
SProgrammable soft−start
SHiccup mode overcurrent protection in NCP5422A
SSingle or dual output mode pin in NCP5425 UVLO: 4.0/ 4.2 V Max: 16 V (Vgate max: 20 V) Min. 0.8 V 150 to 750 kHz 0 to +125_C (TA) TSSOP−20 NCP5425DB
http://onsemi.com
63
Buck Controllers (Non−Sync. Rect., Internal Switch)
Converter Input Voltage
Converter Output
Voltage Switch Freq. Temp. (TA)
Max.
Duty Control Package Part No. Features
4.5 to 40 V (Boots−trap pin max 40 V) Min. 1.276 V 1.5 A Fixed 260 kHz −40 to +85_C 90% VPWM2 mode SO−8
CS51411ED8 SFrequency decrease of 4:1 in short−circuit conditions
SSoft−start
SThermal shutdown
SShutdown
SSynchronous option of CS51411/3 or bias option for CS51412/4 CS51412ED8 0 to +70_C CS51411GD8 CS51412GD8 Fixed 520 kHz −40 to +85_C CS51413ED8 CS51414ED8 0 to +70_C CS51413GD8 CS51414GD8 4.75 to 40 V Fixed 3.3 V 0.5 A Fixed 52 kHz −40 to +125_C 98% PWM V mode DIP−8 LM2574N−3.3 SON/OFF SThermal shutdown
SCurrent limit protection 1.0 A D2PAK−5 LM2575D2T−3.3 TO−220−5 LM2575T−3.3 TO−220−5 VER LM2575TV−3.3 6.0 to 40 V 3.0 A D2PAK−5 LM2576D2T−3.3 TO−220−5 LM2576T−3.3 7.0 to 40 V Fixed 5.0 V 0.5 A Fixed 52 kHz −40 to +125_C 98% PWM V mode DIP−8 LM2574N−5 SON/OFF SThermal shutdown
SCurrent limit protection
8.0 to 40 V 1.0 A D2PAK−5 LM2575D2T−5 TO−220−5 LM2575T−5 TO−220−5 VER LM2575TV−5 3.0 A D2PAK−5 LM2576D2T−5 TO−220−5 LM2576T−5
ON Semiconductor Selector Guide − Analog Integrated Circuits
Buck Controllers (Non−Sync. Rect., Internal Switch) (continued)
Converter Input Voltage
Converter Output
Voltage Switch Freq. Temp. (TA)
Max.
Duty Control Package Part No. Features
UVLO: 5.9/ 6.8 V Max: 40 V Min. 5.0 V 3.0 A Fixed 72 kHz −40 to +85_C 95% PWM V mode
D2PAK−5 MC33166D2T SCompensation pin
SInternal thermal shutdown
SCycle−by−cycle current limiting
TO−220−5 MC33166T TO−220−5 HOR MC33166TH TO−220−5 VER MC33166TV 0 to +70_C D2PAK−5 MC34166D2T TO−220−5 MC34166T TO−220−5 HOR MC34166TH TO−220−5 VER MC34166TV 5.0 A −40 to +85_C 95% D2PAK−5 MC33167D2T TO−220−5 MC33167T TO−220−5 HOR MC33167TH TO−220−5 VER MC33167TV 0 to +70_C D2PAK−5 MC34167D2T TO−220−5 MC34167T TO−220−5 HOR MC34167TH TO−220−5 VER MC34167TV
