Long Range
Initiation System
UZAK
Long Range Initiation SystemGeneral Features
kzmekatronik.comDeveloped according to current conditions and needs with
it’s innovative design, UZAK is a versatile wireless initiation
system that is able to control the durability of the line and
fuse connected to the connection terminals, and send
UZAK
Long Range Initiation SystemSet Content
kzmekatronik.com1 transmitter unit and its antenna 6 receiver units and their antennas
1 charging unit and charging cables (vehicle charging cable, mains supply cable, charging output cable) 1 transfer bag
Radio frequency communication between transmitter and receivers AES128 encrypted communication
Communication distance of up to 12 km in line of sight (LOS)
Communication distance of up to 1200 m in residential areas (NLOS) Ability to view the battery, fuse and initiation status of the receiver units on the OLED screen on the transmitter
Ability to send initiation commands to the receivers individually, in groups or to all of them at the same time
UZAK
Long Range Initiation SystemGeneral Features
kzmekatronik.com1200 meters
Long Range Initiation System
Tra ns m itt er -rec eive r com
Password personalization feature
UZAK
Long Range Initiation SystemTransmitter Unit Features
kzmekatronik.comImpact, water and dust resistant.
OLED screen with adjustable brightness feature and day
and night modes Ability to cancel task
Login with password
Ability to define new receivers instead of expensed ones
Quick change antennas
Rechargeable battery that can be charged from the grid or vehicle
IP67 impermeability standard MIL-STD810-G standard
MIL - STD461-G electromagnetic compatibility standard
UZAK
Long Range Initiation SystemReceiver Unit Features
kzmekatronik.comControllable with a command sent from the identified transmitter only
Highest Level of User Security
Low fuse test current (fuse electrical safety measure) Electromechanical switch system to break the
fuse connection physically for user safety
Electronic discharge gear to discharge ignition voltage when receiver is on standby or off.
Capability to standby for 7 days (168 hours) in standby mode
Capability to rapidly reach ignition voltage
9
Parallel and serial multi-fuse initiation capability IP67 impermeability standard
MIL-STD810-G standard
MIL - STD461-G electromagnetic compatibility standard Rechargeable battery
UZAK
Long Range Initiation SystemTransmitter
kzmekatronik.comCharging connector
Action button for all receivers
A
Device On/Off Number 1 receiver button1
Number 2 receiver button Number 2 receiver button2
Number 3 receiver button3
Number 4 receiver button4
Number 5 receiver button5
Number 6 receiver button6
Antenna connector Detonate Cancel task Prepare for task Screen brightness + Screen brightness-The embossed icons on the frame that can be felt with the fingers enables the user to control the transmitter in the dark, under stress or in all situations where the screen cannot be viewed.
User Friendly Design
Receiver serial number
UZAK
Long Range Initiation SystemReceiver
kzmekatronik.comDevice On/Off
Antenna connector
Fuse safety switch
Fuse connectors
User Friendly Design
UZAK
Long Range Initiation SystemBattery
kzmekatronik.com Charge output Charge level display screen 12V DC vehicle charge inputUZAK
Long Range Initiation SystemRapor No / Report No: EMC-144-01 CGS TEST HİZMETLERİ TEKNİK KONTROL VE BELGELENDİRME ANONİM ŞİRKETİ
KAYIŞDAĞI MAH. GÜLÇİN SOK. NO:۲/۲ ATAŞEHİR/İSTANBUL/TURKİYE Page 1 / 36
CGS TEST HİZMETLERİ TEKNİK KONTROL VE BELGELENDİRME ANONİM
ŞİRKETİ KAYIŞDAĞI MAH. GÜLÇİN SOK. NO:۲/۲
ATAŞEHİR/İSTANBUL/TÜRKİYE Deney Raporu
Test Report
EMC-۱٤٤-۰۱ ۰۹-۲۰ Müşterinin adı /adresi:
Customer name/address KZ MEKATRONİK SANAYİ VE TİCARET LİMİTED ŞİRKETİ P.ALANI M.Y. SANAYİ SİTESİ 27. SOK. 32 A BALIKESİR Üretici/ Üretim Yeri:
Manufacturer/ Manufacturing Location KZ MEKATRONİK SANAYİ VE TİCARET LİMİTED ŞİRKETİ P.ALANI M.Y. SANAYİ SİTESİ 27. SOK. 32 A BALIKESİR İstek Numarası:
Order no. 27072020nkk1 Numunenin Adı ve Tarifi:
Name and identity of test item V01V ; Uzaktan Komutalı Ateşleme Cihazı Verici Ünite V01A ; Uzaktan Komutalı Ateşleme Cihazı Alıcı Ünite Numunenin Kabul tarihi:
The date of receipt of test item 17-08-2020 Açıklamalar:
Remarks Ürün ilgili testlerden geçmiştir, lütfen raporu inceleyiniz. / The product passes related tests, see report below. Deneyin yapıldığı tarih:
Date of Test 17-08-2020 to 08-09-2020 Deneyin Yapıldığı Yer:
Testing Location Kayışdağı Mah. Gülçin Sok. No:2/2 Ataşehir/İstanbul Büyük Selçuklu Cd. No:06930 ,3 Sincan/Ankara Deney Standartı
Test Standard MIL-STD-461G & EN 55032:2015/A11:2020 Raporun Sayfa Sayısı:
Number of pages of the Report 36 sayfa/pages Tarih
Date 09-09-2020
Deney Sorumlusu Person in charge of test Naim Koralp KARAKOÇ
Laboratuvar Müdürü Head of Testing Laboratory
Timur GÜSER
Bu rapor laboratuvarın izni olmadan kısmen kopyalanıp çoğaltılamaz. İmzasız ve mühürsüz raporlar geçersizdir.
This report shall not be reproduced other than in full except with the permission of the laboratory Testing reports without signature and seal are not valid.
