1. Introduction

1.1 Document objective

This document explains load balancing and high availability concepts for hardware devices and their operation and configuration for the GateDefender Performa 8000 series.

1.2 Target readership

The content of this document is designed for technical personnel, network administrators, systems administrators, etc. of companies whose network has a high level of traffic either from web browsing or volume of e-mail and which therefore need to guarantee protection through GateDefender Performa in conditions superior to standard ones.

1.3 Executive Summary

Panda GateDefender Performa supports native load balancing and automatic configuration to offer users a high availability of services. The system administrator only has to activate the load balancing operation and GateDefender Performa units take care of the rest of the actions to be performed, such as role configuration, intelligent load distribution, etc.

The performance obtained when connecting various load balancing units has an almost linear progression according to the units connected.

2. Definitions

2.1 Load balancing

Load balancing consists in installing various hardware devices in parallel to share the work between them and therefore guarantee a high availability of services rendered by the devices.

There are different methods to implement load balancing between devices, depending on the configuration each manufacturer includes in their hardware devices:

Using load balancing hardware

This consists in separately acquiring a specific device to bring into contact other devices which, by default, are not capable of performing load balancing. These hardware load balancing devices are normally very expensive and this cost needs to be added to that of other devices which provide the service.

Balancing with software

There are programs capable of load balancing between hardware devices. This balancing solution is more economical than the hardware solution. However, it means investment in hardware, since the balancing program needs to be installed in a computer or network server. In addition, since they are generic programs, installation and configuration time are factors to be considered.

Native load balancing

(4)

2.2 High availability

High availability is a direct consequence of good load balancing. It consists in knowing for certain that the system and services which the devices offer will not be affected by problems such as the sudden increase in traffic or that any of the devices will stop working accidentally, interrupting services offered up to that point.

3. GateDefender Performa Operation

It is possible to install more than one GateDefender Performa in parallel in order to achieve greater performance and high availability. No additional hardware or software device is necessary to install a load balancing system with various GateDefender Performa devices. Start-up is very straightforward as hardly any configuration is required by the user. Once the devices have been connected adequately, the load balancing system starts operating automatically.

To interconnect the GateDefender Performas in parallel, any type of local network concentrator can be used, either switches or hubs, although the use of switches is highly recommended as these devices produce fewer collisions than hubs. No specific hardware or software or third-party hardware or software needs to be used.

3.1 Increasing performance – Scalability

The use of multiple GateDefender Performas helps to increase performance and processing capacity. If processing needs grow, due to a rise for example in the number of users or expansion in connection bandwidth resulting from business mergers or expansion, simply increase the number of GateDefender Performas used.

Consequently, GateDefender Performa adapts to any type of company whatever its size and its perimeter protection needs. As will be seen below, the performance obtained by using more than one GateDefender Performa increases almost linearly.

3.2 Service guarantee

Apart from improving performance, another of the advantages of installing various load balancing GateDefender Performa units is to guarantee network connectivity in case of failure or collapse of one of the units.

(5)

3.3 Load balancing in GateDefender Performa

Load balancing consists in sharing out the work between the different GateDefender Performa units installed. Each unit can assume one of the two existing roles: master or

slave.

Master functions:

• It decides which GateDefender Performa is responsible for processing a certain connection. The master GateDefender Performa implements a load balancing algorithm to redirect the connections to different slave units in order to balance the system load.

• It also scans connections as well as distributing the load.

• It lets protocol traffic that the administrator decides not to scan pass transparently.

• It provides an outlet for malware-free traffic received from the slave units. • It controls the availability of slave units, listening to messages or

“heartbeats” which they send it periodically.

Slave functions:

• It scans connections redirected by the master, returning malware-free traffic to the master.

• It does not let traffic pass. It only responds to requests from the master GateDefender Performa.

Only one of the units will assume the role of master. The rest of the GateDefender Performa devices will assume the role of slave. This assumption of roles is automatically negotiated between the connected devices, without any user intervention. From the GateDefender Performa console it is possible to see all the units that make up the load balancing system as well as their individual operation mode.

When various GateDefender Performas are installed in parallel, the role negotiation or operation mode of each of them automatically begins. If a new device is subsequently added, the operation modes will be automatically negotiated once more.

(6)

The following figure shows an outline of the internal operation of two load balancing GateDefender Performa units.

Figure 1 Diagram of internal operation of two load balancing devices

3.3.1 Automatic recognition between devices

When GateDefender Performas are connected in parallel and the load balancing activated, the search process commences for new GateDefender Performas as well as the role negotiation or operation mode each one will have.

(7)

This process is performed by means of the STP (Spanning Tree Protocol). This protocol is determined by the IEEE in the 802.1D1 standard. The following functions are carried out through this protocol:

• Detecting / finding other GateDefender Performas installed in parallel. • Determining which unit is the master and which are the slaves. • Detecting when another unit becomes the master.

All the devices periodically exchange STP BPDU packets which include, among other things, the MAC (Medium Access Control) address of each unit installed in parallel. These packets enable the slaves to find out which is the master unit, and the master to find out which slave units are available.2

If a new GateDefender Performa is connected, the roles of each unit will be

automatically reconfigured or renegotiated as soon as its presence is detected. As a

result, the new GateDefender Performa can become the slave or the new master. 3.3.2 Load distribution

The master GateDefender Performa implements a load balancing algorithm and becomes responsible for sharing out and redirecting the connections to the different slave GateDefender Performa units.

The algorithm used is weighted round-robin. The weights used in the load balancing algorithm are static and vary according to the model (8100, 8200) in order to be able to adapt better to the needs of each network.

The master GateDefender Performa distributes the connections between the slaves but also processes and scans some connections.

The master is aware of the load index of the slaves through ‘heartbeats’ which it receives from the slaves. The slaves periodically send to the master heartbeats which include their load index3. Apart from informing the master of the availability of the slaves, it is also aware of the load index of each slave at that particular moment. The only GateDefender Performa that truly acts as a bridge is the one operating as the master. The slave GateDefender Performas only respond to the requests of the master and do not allow the passage of any connections received or intercepted not belonging to the master.

When a frame belonging to a new connection arrives, the master decides that GateDefender Performa will process this connection, with this being performed either by itself or one of the slaves.

If it is a slave, the master is responsible for encapsulating the frames of the original connection and redirecting them to the slave which will be responsible for processing it.4

The slave decapsulates the frames received from the master and processes the original connection. Once the connection has been processed, the slave encapsulates

1

STP is a level 2 protocol (ISO/OSI model) designed for bridges and switches. The STP communication occurs by sending multicast frames to level 2 (Ethernet). These frames receive the name of the BPDU (Bridge Protocol Data Unit). To find out the availability of the slaves, “heartbeats” or activity pulses not belonging to the STP protocol are used. These will be looked at later on in this document.

2

RARP (Reverse Address Resolution Protocol- RFC 2390) is also used to obtain the IP address, from the MAC address, of each of the devices.

3

Heartbeats are sent via UDP to the 6694 port. 4

(8)

the resulting frames again and sends them to the master. These frames are now malware-free traffic.

When the master receives the slave frames, it decapsulates them in order to pass them to the network as clean traffic.

If a connection should not be scanned as a result of being a protocol not selected, the master will let it pass without redirecting it to the slaves.

3.4 High availability in GateDefender Performa

The operation of the high availability system implemented is based on the sending of heartbeats and the STP (Spanning Tree Protocol). The heartbeats inform the master of the availability of the slaves. However, slaves also use STP to find out the availability of the master.

A series of concepts and data related to high availability are outlined below: 3.4.1 Heartbeats

The slaves send heartbeats to the master every 10 seconds. If the master does not receive this heartbeat in 30 seconds, the slave will be considered as missing.

When the master determines that a slave has stopped responding, it will no longer redirect it connections.

The master also periodically sends heartbeats to slaves so they are aware of the master’s name. This name is accessible from the slave administration console.

3.4.2 STP

All the units installed in parallel periodically exchange the STP BPDU packets which, among other things, include the MAC address of each one. These packets also enable the slaves to know which the master GateDefender Performa is and the master to know which GateDefender Performa slaves are available.

If the master fails, no longer sending BDPUs, the rest of the units decide which will be the new master device. The time it takes to complete this operation and begin the normal operation of the load balancing system will be 12 seconds approximately. No connection will be accepted or processed during this time.

3.4.3 Failure of master

(9)

3.4.4 Failure of a slave

If a slave GateDefender Performa fails, the connections that were being managed by the slave at that particular time will be lost, but not those of the master or the rest of the slaves. The master will be responsible for redirecting connections to alternative devices.

The following figure shows an example of redundancy in a system with various load balancing units.

(10)

3.5 Installation and configuration

The following figure shows a network diagram before with just one GateDefender Performa, and the same diagram with various load balancing GateDefender Performa units.

Figure 3. Installation of load balancing GateDefender Performa unit

The slaves do not let traffic enter the network. The only device that really acts as a bridge is the master GateDefender Performa.

Hubs instead of switches can be used for the connection between GateDefender Performa units. However, switches are recommended as they increase performance, reducing the number of collisions.

The use of Gigabit connections is also recommended for models that support it (8100 and 8200), as well as verifying that the ports of the GateDefender Performa units work in Full-Duplex mode, which allows simultaneous bi-directional communication.

(11)

4. Performance

tests

In the performance tests carried out, up to 4 load balancing GateDefender Performa 8100 units were installed with an improvement in performance in 1, 2 and 3 load balancing devices. Technically, no maximum theoretical limit was established to connect GateDefender Performa balancing units. Some performance test graphs are shown below.

GateDefender Performa without load balancing

The following graph shows the number of transactions / second (of http web traffic) that GateDefender Performa 8100 is capable of managing. It can be observed that the Panda GateDefender Performa 8100 model is capable of managing more than 700 transactions / second, although in the same situation the number of transactions / second continues to increase.

(12)

Two load balancing GateDefender Performa units

The following graph shows the effect on the number of transactions / second managed correctly in the test environment with 2 load balancing GateDefender Performa 8100. It is observed that if with a single Panda GateDefender Performa 8100 the saturation level is reached with a little more than 700 transactions per second, 1400 sustained transactions / second is achieved by installing two load balancing units.

(13)

Four load balancing GateDefender Performa units

The following graph shows the effect on the number of transactions / second managed correctly in the test environment with 4 load balancing GateDefender Performa 8100.

Figure 6. Effect in the load balancing transactions / second metrics for 4 GateDefender Performa 8100.

5. Characteristics of a load balancing system

The current load balancing system and fail-over has the following characteristics:

• The units should be configured separately as they are independent devices in the network. • Separate scan reports for each unit can be obtained.

• Each device is updated independently to the others.

• The status and statistics of the load balancing units is seen individually.

(14)

6 Glossary of technical terms

Appliance.- Any hardware device with one or more specific functionalities. Other synonyms

used in this document are unit or device.

Bridge.- Link device between different network sections which avoids unnecessary traffic from

one section to another.

Ethernet.- IT network connection method.

Full Duplex.- Data transmission mode through a circuit capable of sending and receiving data

simultaneously.

Heartbeat.- Active status signal sent by devices in a network every 10 seconds.

Hub.- Connection device between devices belonging to a network which concentrates the

connections between devices and passes the information traffic from one to all the other devices connected.

Malware.- Any type of malicious software (viruses, worms, Trojans etc.). Multicast.- Messages aimed at a group of computers in a network.

Round Robin.- Method of managing concurrent processes which consists in cyclically

alternating tasks yet to be performed, according to their priority.

Switch.- Connection device between devices belonging to a network, capable of directing the

traffic from one device to another connected to it, excluding the other devices connected.

Frame.- Structure which contains information sent through a network.

7 Glossary

of

abbreviations

BPDU.- Bridge Protocol Data Unit. This is a type of message used by bridges to exchange

control and administration information.

RARP.- Reverse Address Resolution Protocol. Protocol used to find out the IP addresses of a

device through its MAC address.

MAC.- Medium Access Control. Internal address which identifies all a network’s devices. OSI Open Systems Interconnection. Reference model which specifies the different network

levels.
