Tiptronic® Engine
Cylinders 4 4 4 4 4 4
Capacity (cm3) 1,398 1,398 1,598 1,598 1,598 1,598
Bore/Stroke (mm) 76.5 / 75.6 76.5 / 75.6 76.5 / 86.9 76.5 / 86.9 76.5 / 86.9 79.5 / 80.5
Valves (per cylinder) 4 4 4 4 4 4
Compression Ratio 10.5 10.5 10.5 10.5 10.5 16.5
Power output (kW @ r/min) 63 @ 5,000 63 @ 5,000 77 @ 5,250 77 @ 5,250 77 @ 5,250 77 @ 4,400
Torque (Nm @ r/min) 132 @ 3,600 132 @ 3,600 155 @3,500 155 @3,500 155 @3,500 250 @ 1,500 - 2,500 Fuel Injection X X X X X -Common Rail - - - X Turbocharged - - - X Emissions Level EU 2 EU 2 EU 4 EU 4 EU 4 EU 4 CO2 Emissions (g/km)* 139 139 143 143 154 120 Transmission 5-speed manual X X X X - X 6-speed automatic - - - - X -Gear Ratios 1st gear 3.455 3.455 3.455 3.455 4.15 3.778 2nd gear 1.955 1.955 1.955 1.955 2.37 2.118 3rd gear 1.281 1.281 1.281 1.281 1.56 1.36 4th gear 0.881 0.881 0.881 0.881 1.15 0.971 5th gear 0.673 0.673 0.673 0.673 0.86 0.733 6th gear - - - - 0.69 -Reverse 3.18 3.18 3.18 3.18 3.39 3.6
Final Drive Ratio 4.533 4.533 4.533 4.533 3.68 3.647
Performance
Acceleration in seconds (0 - 100 km/h) 12.8 12.8 11.1 11.1 12.3 10.7
Top speed (km/h) 178 178 190 190 187 187
Fuel consumption (litres / 100 km)*
Extra-urban 4.8 4.8 4.9 4.9 5.3 3.8
Urban cycle 7.7 7.7 8.0 8.0 8.6 6.1
Combined 5.9 5.9 6.0 6.0 6.5 4.6
Running Gear
Front axle:
Suspension struts, wishbone X X X X X X
Rear axle:
Tiptronic® Brakes
ABS with EBD X X X X X X
Brake fluid warning indicator X X X X X X
Electronic Stability Programme (ESP) - - - O O X
Front discs brakes X X X X X X
Rear drums brakes X X X X X X
Wheelrims / Tyres
Steel 5Jx14" (175/70 R14) X - X - -
-Alloy 6Jx15" Riverside (185/60 R15) - X - X X X
Lockable wheelbolts - X - X X X
Full size steel spare wheel X - X - -
-Steel spare wheel for temporary use - X - X X X
Tool kit & jack X X X X X X
Dimensions / Capacities
Fuel tank (in litres) 55 55 55 55 55 55
Luggage compartment volume (in litres) 454 454 454 454 454 454
DIN Kerb Weight (kg)** 1,106 1,106 1,111 1,111 1,182 1,187
Length (mm) 4,384 4,384 4,384 4,384 4,384 4,384 Width (mm) 1,699 1,699 1,699 1,699 1,699 1,699 Height (mm) 1,466 1,466 1,466 1,466 1,466 1,466 Track - front (mm) 1,460 1,460 1,460 1,460 1,460 1,460 Track - rear (mm) 1,498 1,498 1,498 1,498 1,498 1,498 Turning circle (m) 10.8 10.8 10.8 10.8 10.8 10.8 Wheel base (mm) 2,552 2,552 2,552 2,552 2,552 2,552 Drag co-efficient (Cd) 0.327 0.327 0.327 0.327 0.327 0.327 Ground Clearance (mm) 170 170 170 170 170 170 Safety
Dual front airbags with passenger airbag deactivation X X X X X X
Side airbags X X X X X X
Height adjustable seatbelts for driver and front passenger X X X X X X
3-point seatbelt for rear outer seat X X X X X X
3-point seatbelt for centre rear seat X X X X X X
ISOFIX child seat mounting points X X X X X X
Childproof locks on rear doors X X X X X X
High level brake light X X X X X X
Warning triangle in boot X X X X X X
Park Distance Control O O O O O O
Audio & Communication
RCD-220 Radio/CD with MP3, USB, SD-Card, Aux-in X - X - -
-RCD-320 Radio/CD with Bluetooth, MP3, USB, SD-Card, Aux-in - X - X X X
Tiptronic® Security
Alarm with back-up horn, towing protection and ultrasonic interior monitoring X X X X X X
Immobiliser X X X X X X
Remote central locking X X X X X X
Seats
Standard comfort front seats X X X X X X
"Metric" interior cloth trim for seats X - X - -
-"Livon" comfort interior cloth trim for seats - X - X X X
Height adjustable driver's seat X X X X X X
Height adjustable passenger's seat - X - X X X
Height adjustable front head restraints, crash-optimised X X X X X X
Three rear head restraints X X X X X X
Foldable rear seats (split 60/40) X X X X X X
Storage pockets on the rear of front seats X X X X X X
Windows
Side & rear windows in heat insulating glass X X X X X X
Electric windows, front and rear X X X X X X
Heated rear window X X X X X X
Mirrors
Manually adjustable from interior X X X X X X
Colour-coded exterior mirrors - X - X X X
Manual anti-dazzle rear view mirror X X X X X X
Vanity mirrors with covers, driver and passenger X X X X X X
Wiper System
Wiper system with intermittant control (4-speed potentiometer) X X X X X X
Interior Features
Manual air-conditioner X X X X X X
Dust & pollen filter X X X X X X
Standard instrument cluster with speedometer, tachometer, digital clock,
fuel level and temperature indicators X - X - -
-Comfort instrument cluster including chrome trim and multi-function display O**** X O**** X X X
12V power socket in centre console X X X X X X
Smoker's package: cigarette lighter and ashtrays O O O O O O
Headlight range adjustment, electrical X X X X X X
Dimmable illumination - X - X X X
Cruise Control O X O X X X
Cup holders, 2 integrated into centre console, front X X X X X X
Radio preparation including 4 speakers and EU Bee-sting antenna X - X - -
-Front door pockets X X X X X X
Front & rear floor mats - X - X X X
Tiptronic® Interior Features (continued)
Reach adjustable steering column X X X X X X
Standard 3-spoke plastic steering wheel X - X - -
-Leather multi-function 3-spoke steering wheel with matt chrome insert - X - X X X
Leather gearshift knob & handbrake cover - X - X X X
Dual tone hooter X X X X X X
Lights on warning buzzer X X X X X X
Interior courtesy light with delay X X X X X X
Reading lights 2 front, 1 rear X X X X X X
Luggage compartment lighting X X X X X X
Power steering X X X X X X
Footwell lighting - X - X X X
Glove compartment with pen, notes, coins and sunglass holders X X X X X X
Chrome door handles X X X X X X
Interior chrome package: Handbrake knob, gear boot frame, air-vent frames, rotary
switch sides and switch bezel edges - X - X X X
Exterior Features
"Bee-sting" roof antenna X X X X X X
Single lamp headlights with high / low beam in chromed housing X - X - -
-Twin lamp headlights in darkened sports-appearance housing - X - X X X
Chrome trim strip for bootlid - X - X X X
Chrome trim on louvres (x2) on front upper grille X X X X X X
Chrome trim edging on front lower grille - X - X X X
Front foglights with chrome trim surround - X - X X X
Rear foglight X X X X X X
Side indicators located in front fender X X X X X X
Side and rear windows in heat-insulating glass X X X X X X
Colour-coded door handles - X - X X X
Tiptronic® Guarantees
Warranty (3yr / 120 000km) X X X X X X
Anti-corrosion warranty (12yr) X X X X X X
Volkswagen Automotion Maintenance Plan (5yr / 60 000km) O O O O O O
Volkswagen Service Plan (5yr / 60 000km) O O O O O O
Service intervals (15 000km) X X X X X X
*Fuel Consumption and Carbon Dioxide Emission Figures
The figures reflected were obtained in accordance with prescribed uniform measuring standards (SANS 20101: 2006 / ECE R101: 2005 in their currently applicable versions) under laboratory type conditions. The measuring standards are stipulated by law. They do not apply to a specific vehicle and are provided to enable comparison between different vehicle models tested using the same uniform measuring standard. The values are accordingly not necessarily representative of real-life driving conditions. Factors such as driving style, vehicle load, road conditions, tyre size, traffic and ambient conditions may result in different fuel consumption and carbon dioxide emission levels to those achieved under the test parameters referred to above. More details are contained in the owner’s manual.
Based on lightest variable (no options) and 90% tank filling. Weight may vary depending on options fitted to vehicle. Dimensions, capacities and abilities apply to standard vehicles.
