the sMart route
to perForManCe.
Here’s what you’ll appreciate: robust design features like I-beam construction that make Meritor axles the industry standard in reliability, durability and performance.
FH-946 deep drop front non-drive steer axle features include: n Suspension rod attachment points are integral to the I-beam for
simplified bracket design and greater bracket flexibility n Easy Steer king pin bushings and tapered roller thrust bearing
permit easier steering
n A 51-degree turn angle delivers outstanding maneuverability n Meritor Cast Plus™ cam brakes offer added durability and
reliability with a single-piece, cast shoe and extended-life brake linings that provide superior resistance to heat-related wear n Optional EX225-H Severe Service air disc brakes provide
reduced stopping distance, lower maintenance and maximum corrosion protection
Meritor transit Bus and CoaCh axles
GAWR RATING* POUNDS (MT) TRACK INCHES (mm) OVERALL INCHES (mm) WHEEL SIZE INCHES (mm)
BRAKES & SIZES
INCHES (mm) HUBS & DRUMS BOLT CIRCLE DIAMETER INCHES (mm) PAD CENTER INCHES (mm) AXLE BEAM DROP INCHES (mm) TURN ANGLE 16,000 (7) 85.96 (2,184) 102 (2,591) 22.5 (571) 16.5 x 6 (419 x 152) Cast Plus Cam Brake EX225-H Air Disc Brake
10-Stud 11.25 (286)
10-Stud 13.19 (335)
49.82 (1,265) 8.0 (203) 51 Degree
* Permitted uses of axles and components, including capacity ratings where stated, vary with application and service. Applications must be approved by
Meritor Specialty Products and Brake Engineering Departments. Approved ratings may be higher or lower than indicated above, dependent upon engineering review.
the industry’s axle leader.
With more than a century of axle-manufacturing experience, Meritor is one of the world’s largest independent manufacturers of commercial vehicle axles for a broad range of applications. In the North American transit bus and motorcoach markets, Meritor has been a leading axle supplier for decades.
That’s because we engineer outstanding reliability, unmatched durability and low cost of operation into every axle we make. Our specific axle solutions for the transit bus and motorcoach markets mean a more enjoyable and comfortable ride for passengers – and a real competitive edge for you.
We offer a full line of front steer, tag and rear drive axles that deliver the performance you demand – backed by the unequaled service and support you expect from a global axle leader.
Front steer axles.
Meritor offers the exact front steer axle your transit bus or motorcoach operation requires. Low-floor bus design? The Meritor Easy Steer™ FH-946 deep drop front non-drive steer axle answers the call. Ideal for 35-, 40- and 60-foot transit buses and motorcoaches, the FH-946 allows the bus floor to drop up to 20 inches (508 mm) below conventional bus designs – eliminating the need for steps and allowing easier passenger accessibility. Passengers also appreciate how the wide spring mountings maximize aisle width.
standard Floor Buses
For standard floor buses and motorcoaches, Meritor offers the MFs-12-155 and Fh-941 front steer axles. these axles deliver the same durability, performance, reliability and ease of maintenance that have made Meritor axles an industry standard.
Fh-946 specifications:
MC-26000 specifications:
Center and tag axles.
Whether you are building a 60-foot articulated transit bus or a motorcoach, there’s a high-performance Meritor center or tag axle that meets your exact needs.
For low-floor to 60-foot articulated transit buses, the Meritor MC-26000 center non-drive axle features a center drop, no-weld design with integral suspension brackets. The result: increased carrying capacity, comfortable passengers and a more profitable operation.
Brake options include Meritor EX225-H air disc brakes and Meritor 16.5" x 8.625" Cast Plus cam brakes featuring a single-piece cast shoe, extended-life brake linings and an integral return spring mount for unmatched durability, longer life, easy assembly, less maintenance and reduced downtime.
GAWR RATING*
POUNDS (MT) WALL THICKNESSHOUSING SIZE/ BRAKES & SIZES INCHES (mm) HUBS & DRUMS BOLT CIRCLE DIAMETER INCHES (mm)
26,000
(12) Cast IronVarious 16.5 x 6 (419 x 152) Cast Plus Cam Brake
EX225-H Air Disc
10-Stud 11.25 B.C. (286) 10-Stud 13.19 B.C. (335)
* Permitted uses of axles and components, including capacity ratings where stated, vary with application and service.
For motorcoaches, Meritor also has a full lineup of tag axles specifically designed for these applications. The MC-12000, MC-14000 and MC-16000 tag axles are custom-designed for the motorcoach market with integrated suspension connection points directly into the axle. They provide a GAWR from 12,000- to 16,000-lbs. (5.5 to 7.3 tons) and offer both drum and EX225-H disc brake options.
If your motorcoach application requires a steerable tag axle, Meritor offers a choice of proven FH-946 and FH-941 steer axles that feature the capacities and options your vehicles require.
79000 specifications:
rear drive axles.
The Meritor 79000 Series axle is the next generation single reduction drive axle for transit bus and motorcoach vehicles. Performance-engineered, it’s the perfect choice for high stop-and-start duty cycles, demanding retarder loads and periodic axle-overload applications. 79000 key features:
n 28,660-lb. gross axle weight rating offers increased capacity for demanding transit bus and motorcoach applications
n More economical than double reduction axles
n One-piece cast iron housing with integral suspension bracket pads and “bolt-on” torque rod brackets for extra strength and durability
GAWR RATING*
POUNDS (MT) PITCH DIA. INCHES HYPOID GEARSET (mm)
RATIOS HOUSING SIZE/
WALL THICKNESS BRAKES & SIZES INCHES (mm) HUBS & DRUMS BOLT CIRCLE DIAMETER INCHES (mm) 28,660 (13 ) 18.0 (457) 4.10 4.30 4.89 5.13 5.38 5.63 6.14 Various Cast Iron 16.5 x 8.625 (419 x 219) Cast Plus (Std.) 14.5 x 10 “W” Series (368 x 254) (Opt.) EX225-H Air Disc 10-Stud 11.25 B.C. (286) “W” 14.5 x 10 (368 x 254) Brake (Hub & Stud Pilot) 10-Stud 11.25 B.C. (286)
Cast Plus 16.5 x 8.625
(419 x 219) Brake (Hub & Stud Pilot) 10-Stud 13.19 B.C. (335)
Cast Plus 16.5 x 8.625 (419 x 219) Brake (Hub Pilot Only)
* Permitted uses of axles and components, including capacity ratings where stated, vary with application and service. Applications must be approved by
Meritor Specialty Products and Brake Engineering Departments. Approved ratings may be higher or lower than indicated above, dependent upon engineering review.
n The robust MS197 carrier offers increased ring gear width for longer life, higher-capacity spigot bearing for demanding retarder loads, and a bolted differential case and gear for easier assembly and service
n Quiet Ride™ gearing provides a more relaxing ride experience n Industry-leading Cast Plus 16.5" x 8.625" S-cam brakes come
standard, with optional 14.5" x 10" “W” Series cam or EX225-H air disc brakes
n 2-Year/100,000-Mile warranty and optional 5-Year/300,000-Mile warranty
Our representatives have the experience, the expertise and the global support network to provide the assistance you need to get the exact axle systems and components to maintain your competitive edge. With unmatched consultation and follow-through, we can provide you with the guidance needed to optimize your spec based on your vehicle, operating environment and operational goals.
Every Meritor axle comes with unsurpassed global service and support, with distribution centers strategically located to reduce downtime and provide timely and complete aftermarket support. In other words, everything you’d expect from an industry leader. For more, call 866.668.7221 or visit meritor.com.
Meritor transit Bus and CoaCh axles
additional rear drive axle Choices.
For smaller transit buses and motorcoaches, the Meritor RC-23-160 provides the same proven durability of the Meritor 160 Series axle, which has millions of over-the-road miles in Class 8 applications. The RC-23-160 includes upgrades, such as Quiet Ride gearing, that passenger-carrying services demand. If your transit bus operation calls for a double reduction planetary axle, the Meritor MC-27-610 rear drive axle provides a smaller center bowl and deeper ratio coverage.
total axle solutions From the
Worldwide axle leader.
