Interactive
Combining LED touch screen technology with interactivity, Vestel Interactive Flat Panel Display is an interactive, dynamic, and engaging solution for education and business environment.
Suitable for both schools and business offices, the interactive flat panel display technology facilitates learning, information sharing, and encourages interactive communication. Vestel IFPD is an excellent product to connect teachers and students, as well as presenters and attendees. Vestel offers 65” and 84” wall-mountable and stand alone solutions with motorised stand for businesses and learning instituions who have
3
What You Can Do
•
Write on the screen with your finger or a pen, and erase•
Touch the screen to navigate through documents, videos, presentations, or websites•
Make notes, draw shapes, move, scale, or rotate the images with a finger touch•
Save your notes, graphs, text, audio files to print, e-mail, or share them•
Switch from writing notes to navigating applications and back•
Create video or audio files to teach an application or a lecture to be posted•
Record instructions as video files and post the materials for review by student•
Control the PCs / tablets in the classroom from the display (*)Education Solutions
Vestel Interactive Flat Panel Display is an innovative and user-friendly product solution that has been designed to enhance the education process, helping instructors to create an engaging and responsive learning environment for their students. Offering LED touch screen technology, end users can write on the board with a pen or even their fingers. Documents, presentations, videos and websites can also be navigated and scrolled through, simply by touching the screen. A versatile product solution, the white board can save notes, graphs, text and audio files, enabling end users to print, e-mail or share them instantly or at a later time.
Office Solutions
Vestel IFPD with high picture quality and interactivity functions is also suitable for the business applications. It can simply be installed in meeting rooms to be used for presentations, video conferences, interactive lectures , and seminars . It helps business executives to have effective and distraction free presentations by facilitating interaction between the presenter and the audience. The product can play a variety of media content including images, videos, and power point presentations. The presenters and participants can share files and other materials with audience devices . In addition, presenters can control the devices of the attendees during sessions.
7 Equipped with LED touch screen technology, Interactive Flat Panel Display is an excellent choice for businesses to deliver dynamic presentations and seminars , encouraging interactive communication and ehhancing the audience experience.
LED Monitor Features
•
Screen Size : 65” LED, 84’’ LED•
65” : 1920 x 1080p full HD resolution•
84” : 3840 x 2160p 4K ready•
Contrast ratio 4000:1 / 1400:1•
Brightness Level : 350 cd/m2•
178 ° viewing angle ensuring a great view from any seat in the classroom•
Multi- touch•
Anti reflective tempered glass9
Built-in PC Features
•
Easy Plug for integrated PC module (Compatible with Intel OPS)•
Intel Ivy Bridge 3rd generation processors (i3, i5, i7)•
Exchangeable HDD•
Storage : Various sizes HDD (optional) , SSD Storage Unit 220 MB/sec Read, 110 MB/sec Write, mSATA (optional)•
Operating System: Windows 8, Pardus•
2 built-in USB ports to connect additional peripherals to the LCD screen•
Built-in WiFi•
Wired or wireless network connection•
LAN: 10/100/1000 Mbps LAN support1428.48(Active Area) 803.52(Active Area) 1562.2 959. 6 93.2 IR LENS ASSEMBL Y/ DISASSEMBL Y 41.05 41. 05 41.05 41.05 IR LED LENS OPS BOX OPEN/CLOSE HDMI USB VGA AUDIO AUDIO
65”
65” Office Board
84”
Product Weight: 57 kg Product Weight: 63 kg11
Panel Specifications
65” IFPD 65” OFFICE BOARD 84” IFPD
Resolution: 1920 x 1080 1920 x 1080 3840 x 2160
Frequency: 50 Hz 50 Hz 100 Hz
Brightness: 350 cd/m2 350 cd/m2 350 cd/m2
Contrast: 4000 : 1 4000 : 1 1400 : 1
Response Time: 5 ms 5 ms 5 ms
View Angle: Hor:178o, Ver:178o Hor:178o, Ver:178o Hor:178o, Ver:178o
Color Palette: 1.07 billion 1.07 billion 1.07 billion
Monitor Specifications
Control Buttons
PC On/Off Source Select
Touch Screen Enable/Disable Brightness Level Decrease Brightness Level Increase Volume Level Decrease Volume Level Increase
Touch Screen
Infrared Touch Screen
65” 4 point touch (6 point is opt) 84” 6 point touch (10 point is opt)
Glass 4 mm tempered, anti-reflective glass (Anti-Glare is opt)
I/O Ports 1 x VGA In
2 x HDMI In
1 x USB B-type connector (for external touch screen usage only) 1 x Line In
1 x Line Out RS232
PC Board Specifications
Processor Intel Ivy Bridge 3rd generation processors (i3, i5, i7)
Chipset Intel 7 Series Panther Point Chipset
System Memory 4GB, 8 GB 1333/1600MHz DDR-3 RAM (up to 16GB RAM support)
Network (Wired/Wireless)
LAN: 10/100/1000 Mbps LAN support
WLAN : 802.11 a/b/g/n wireless support with MIMO
Data Storage SSD Storage Unit 220 MB/sec Read, 110 MB/sec Write (opt)
Various sizes HDD (optional) mSATA (optional)
Audio 30W Audio Output Power
I/O Ports 1 x RJ45, 10/100/1000 Mbps Ethernet
2 x USB 3.0 ports 1 x Microphone “In 1 x Headphone Out 2 x WiFi Antenna Connector
Software Specifications
