Scalable storage for heterogeneous LAN environments
IBM TotalStorage
Network Attached Storage 200
Models 201/226
Highlights
Dedicated — Fully-integrated, optimized storage solution, so your general-purpose servers can focus on other applications
Open — Open-system design enables a smooth integration into your existing network and an easy expansion as your storage needs grow
Scalable — Storage capacity from 109.2 GB up to 3.5 2TB1 to affordably meet your current and future storage requirements
Affordable — Low-cost entry into network-attached storage (NAS) for those who are reducing their use of general-purpose servers for storage
IBM, NAS and Storage Networking
IBM TotalStorageTM Network Attached
Storage 200 products are just one part of the overall IBM Storage Networking offering of hardware, software and services. IBM NAS products provide you with one more building block to increase the flexibility, efficiency and effectiveness of your storage network-ing solutions and deployments. Also, because our NAS products are based on an open-system concept, their storage is designed to be as easy to expand in the future as the system is to install now, into both heteroge-neous and homogeheteroge-neous network environments.
Task-optimized storage appliances
The IBM NAS 200 series models are LAN-attached, high-performance appliances designed to provide shared storage to both clients and servers in Windows, UNIX or mixed environments. The affordability and scalability of the IBM NAS 200 series make it an excellent choice for those who are reducing their use of general-purpose servers for storage.
With its multiprotocol support, the IBM NAS 200 series enables clients to share files in a heterogeneous environment with Windows and UNIX. This multiple-platform support eliminates the need for separate storage for each protocol. IBM Network Attached Storage 200 (rack model)
Flexible — Multiple file protocol support (Windows® [CIFS], UNIX® [NFS], HTTP, FTP , AppleTalk and NetWare) means clients and servers can easily share informa-tion from different platforms
Reliable — Hot-swap disk drives, redundant components and IBM Advanced Systems Management designed to keep these systems up and running
Simple — LAN installation through an easy-to-use Web browser interface simplifies setup and ongoing systems management
Data protection — Instant file and volume restore capability utilizing any one of a possible 250 True Images to recover corrupted/ deleted data.
High-reliability design
Hot-swap and redundant hard disk drives and power supplies mean that the IBM NAS 200 series is built for reliability. This redundancy means that you do not have to take the system off-line to add or replace a failed compo-nent, adding to overall reliability and uptime.
The IBM NAS 200 provides up to 250 persistent True Image views of a virtual drive's file data. Using Persistent Storage Manager (PSM), these point-in-time views can be created on a scheduled basis, and with the proper permissions, users can restore previous file levels without administra-tor involvement. Administraadministra-tors can also restore entire drives and volumes in a single step, saving precious IT time by eliminating the need to drag and drop thousands of files back to the original location. By incorporating its own open file manager, PSM also helps provide the safe and consistent backup of in-use files. The IBM NAS 200 is designed to provide:
• Protection against accidental file deletions
• Client and administrator file restorals • Administrator volume restorals • Continued access to files during backup • 24 x 7 data access
The IBM NAS 200 series also provides the following features within the Advanced Systems Management package to help ensure your system achieves maximum uptime:
• Light-Path Diagnostics for quick determination of a failed part through LEDs • Predictive Failure Analysis® monitoring
on CPUs, memory, fans and power supplies with user-selectable alert levels • Remote connect for automated paging The optional Remote Supervisor PCI adapter also allows network alerts through IBM Director.
Scalable storage systems
As storage networks become more complex, organizations are faced with finding cost-effective ways to manage
Features Benefits
Affordability Provides low initial investment and low total cost of ownership for workgroups and departmental environments.
Windows Powered OS Preconfigured and tuned for storage-specific tasks, designed to maximize compatibility with other Windows systems and improve performance and reliability.
Data protection and backup Persistent Storage Manager creates True Image data views that allow instant file and volume restoration
Scalability Allows storage capacity to be increased as needs grow.
Simplified installation Provides simplified installation to deliver storage quickly, without tying up valuable IT resources.
Versatility Support for multiple network protocols, enabling better data integration across the enterprise and eliminating the need for a separate file server for each format.
Reliability Hot-swap, redundant power supplies and hard disk drives, as well as Advanced Systems Management protect against system downtime.
Performance Provides excellent performance for Windows users and exceptional overall performance for multiprotocol environments.
their exponential growth. To effectively prepare for short- and long-term storage requirements, companies must have scalable storage systems that grow as networking capacity needs increase. The IBM Network Attached Storage 200 series provides solutions for these growing storage requirements.
The tower version of the IBM NAS 200 series is ideal for workgroup and small departmental settings. The tower delivers from 109.2 GB to 440.4 GB of storage and is well suited for deploy-ment in remote or branch-office environments. The rack version provides from 109.2 GB to 3.52 TB of storage and is ideal for use in a department or regional office. Both the tower and rack provide excellent performance for Windows and mixed Windows/UNIX environments. So, if you need affordably priced storage for 10 people in a branch office or 100 people in a regional location, the IBM NAS 200 series should meet your requirements.
The IBM NAS 200 series is well suited for the following tasks:
• Storage for remote workgroup, branch and regional office e-mail and client backups
• ISP e-mail storage or video file serving • ASP workfile storage
• SSP general-purpose storage • Internet data center deployment
Tower configuration—Storage where you need it
Whether you need additional storage in a remote location or for a workgroup within your main building or campus, the IBM NAS 200 series tower version offers many features found in larger systems, but at an affordable, entry-level price. This single-engine tower configuration is powered by a 1.13-GHz Pentium® III processor with a
single-channel hardware RAID controller and six internal storage bays. For enhanced performance, an additional 1.13-GHz Pentium III processor can be added. With a basic storage capacity of 109.2 GB, this model can be expanded up to 440.4 GB by using 73.4 GB hot-swappable hard disk drives.
Rack configuration—For more performance and storage-intensive environments
The IBM NAS 200 series rack model is a high-capacity appliance engineered to expand storage in a small footprint for larger client/server networks. The rack model offers an affordable alternative to other, more expensive departmental-level NAS solutions. With its two 1.13-GHz Pentium III processors and a four-channel hardware RAID controller, the single-engine IBM NAS 200 rack is designed to provide the performance required in more data-intensive applications. The IBM NAS 200 rack also provides excellent storage scalability. Starting at 109.2 GB, the IBM NAS 200 rack can be scaled up to 3.52 TB by using 73.4 GB hot-swappable hard disk drives.
Preloaded system software
The IBM Network Attached Storage 200 series is preloaded with tightly integrated base operating and system software. This preloaded software simplifies the installation, configuration and management of the IBM NAS 200 compared to general-purpose servers and other storage systems. The software is loaded to the engine's hard disk drive with a backup copy provided on a CD-ROM. In addition to its
operating system and NAS application programming, the provided software includes:
• Universal Manageability Services (Web-based GUI) and Microsoft® Terminal Services for local or remote setup and administration
• Advanced Appliance Configuration Utility provides headless setup and configuration
• Windows NT® Backup
• IBM Director agent for system administration
• Tivoli® Storage Manager client for storage management and backups • Columbia Data Products Persistent
Storage Manager for True Image data views of files (backup enablement)
Network Attached Storage 200 at a glance
IBM NAS 200 tower (5194 Model 201) IBM NAS 200 rack (5194 Model 226) Packaging
Form Factor Tower 2 Rack (customer-provided)
Disk type / capacity / speed Ultra160 SCSI/36.4 GB/10 000 rpm Ultra160 SCSI/36.4 GB/10 000 rpm Ultra160 SCSI/73.4 GB/10 000 rpm Ultra160 SCSI/73.4 GB/10 000 rpm Number of disks / capacity (min.) 3 x 36.4 GB/109.2 GB 3 x 36.4 GB/109.2 GB
Number of disks / capacity (max.) 6 x 73.4 GB/440.4 GB 48 x 73.4 GB/3.52 TB 3
Power supply Three 250-W auto-ranging Three 250-W auto-ranging
Tape backup Optional through internal or external SCSI Optional through internal or external SCSI External Fibre Channel
Physical dimensions Engine: Engine:
217 mm W x 700 mm D x 440 mm H 440 mm W x 688 mm D x 217 mm H (8.5 in. W x 27.5 in. D x 17.3 in. H ) (17.3 in. W x 27.1 in. D x 8.5 in. H)
Min. 26.58 kg (58.6 lb), max. 37.5 kg (82.7 lb) Min. 25.24 kg (55.7 lb), max. 36.2 kg (79.8 lb)
Storage Unit:
444 mm W x 519 mm D x 127.5 mm H (17.5 in. W x 20.4 in. D x 5.0 in. H) 34.5 kg (76 lb) with hard disk drives
Operating environment
Temperature 10° to 35°C (50° to 95°F) at 0 to 914 m (0 to 3000 ft) 10° to 32°C (50° to 90°F) 914 m - 2133 m (3000 to 7000 ft) Relative humidity (non-condensing) 8% to 80%
Maximum altitude 2133 m (7000 ft)
Electrical 100 - 240 V ac; 50 Hz - 60 Hz; 5 - 2.5 A (at min. - max. voltage)
Performance
Processor One 1.13-GHz Pentium III with 133-MHz Two 1.13-GHz Pentium III with 133-MHz front-side bus 4 (second processor available) front-side bus 4
Level 2 cache per processor 512 KB 512 KB ECC SDRAM memory (standard/max) 512 MB/2.5 GB 1 GB/3 GB
RAID Accelerator ServeRAID™ 4LX with 32 MB ECC cache ServeRAID 4H with 128 MB ECC cache
(0, 1, 1E, 5, 5E, 00, 10, 1E0 and 50 RAID supported) (0, 1, 1E, 5, 5E, 00, 10, 1E0 and 50 RAID supported) File protocols supported CIFS, NFS, HTTP, NetWare, AppleTalk, FTP CIFS, NFS, HTTP, NetWare, AppleTalk, FTP
Integrated Advanced Systems Yes Yes
Management Processor
NetBench See 5 See 5
SPECsfs See 5 See 5
Connectivity
PCI slots available 4 (1x64-bit/33MHz, 1x32-bit/33MHz and 4 (1x64-bit/33MHz, 1x32-bit/33MHz and 2x64-bit/66MHz) 2x64-bit/66MHz)
Ethernet connections 1 - 10/100 planar port (std.) 1 - 10/100 planar port (std.)
Up to 7 additional 10/100 PCI ports (opt.) Up to 7 additional 10/100 PCI ports (opt.) Up to 2 Gigabit PCI ports (opt.) Up to 2 Gigabit PCI ports (opt.)
Maximum Ethernet connections 8 (1 planar, 7 PCI) 8 (1 planar, 7 PCI)
External Tape Backup PCI Options SCSI SE or SCSI LVD/SE SCSI SE, SCSI LVD/SE or Fibre Channel
Software
Operating system Windows Powered OS Windows Powered OS
Backup Windows NTBackup Windows NT Backup
Tivoli Storage Manager client (V4.2) Tivoli Storage Manager client (V4.2)
Columbia Data Products Persistent Storage Columbia Data Products Persistent Storage Manager (V2.1) enables point-in-time backup Manager (V2.1) enables point-in-time backup Storage management Tivoli Storage Manager client (V4.2) Tivoli Storage Manager client (V4.2)
Systems management IBM Director 2.2 agent IBM Director 2.2 agent
Remote administration Universal Manageability Services Universal Manageability Services Microsoft Terminal Services Microsoft Terminal Services Configuration tools IBM ServeRAID Manager IBM ServeRAID Manager
Network Attached Storage 200 at a glance
High-availability Hot-swap, redundant power supplies Hot-swap, redundant disk drives Advanced Systems Management • Light-Path Diagnostics • Predictive Failure Analysis • Remote connect automated paging
Standards MPS 1.4, PCI specification 2.1, ISO 9241 Part 3 MIBS supported MIB-II
Approvals and safety FCC Class A Part 15, Canada ICES-003 issue 3 Class A, UL 1950, CSA C22.2 No. 950, NOM-018
Support features IBM Start Up Support
Services from IBM Global Services:
• IBM Hardware Services - IBM installation services for IBM TotalStorage • IBM operational support services - support line
Configuration Rack:
Minimum (109.2 GB)
1 engine (RAID controller and internal storage with two 1.13-GHz Pentium III processors)
Maximum (3.52 TB)
1 engine (two 1.13-GHz Pentium III processors)
• Internal RAID controller and internal storage (6 x 73.4 GB HDD, 440.4 GB) 3 storage units (14 x 73.4 GB HDD, 1.03 TB each)
Tower:
Minimum (109.2 GB) and maximum (440.4 GB): 1 engine (RAID controller and storage internal with up to two 1.13-GHz Pentium III processors)
Backup interoperability IBM has tested the IBM NAS 200 series for interoperability with a variety of backup devices and software. Visit ibm.com/storage/nas for the most current list of tested vendors.
Options and accessories 5194 Storage Unit Model EXP (226 only) 36.4-GB Ultra 160 SCSI hot-swap SL HDD 73.4-GB Ultra 160 SCSI hot-swap SL HDD
1.13-GHz/133-MHz FSB/512-KB upgrade processor (tower version only) 200 tower is upgradable to total engine memory sizes of 1 GB, 1.5 GB and 2.5 GB 200 rack is upgradable to total engine memory sizes of 2 GB and 3GB
1 port 10/100 Ethernet Adapter or 4 port 10/100 Ethernet Adapter 10/100/1000 TX 1 port Ethernet Adapter
Gigabit Ethernet SX Adapter
5U x 24D tower-to-rack conversion kit (tower version only)* SCSI SE PCI card or SCSI LVD/SE PCI card
Fibre Channel HBA (rack only) Remote Supervisor Adapter
Warranty 3 year parts/1year labor warranty (warranty upgrades available)
* Note: Use of the tower-to-rack conversion kit does not transform a Model 201 into a Model 226. It is simply a means of converting the Model 201 from a tower configuration into a rack configuration.
For more information
To find out more about the IBM NAS offerings and other high-performance IBM Storage Networking products, contact your IBM representative or call IBM Direct at 1 800 IBM-CALL
(1 800 426-2255) or visit ibm.com/storage/nas
© Copyright IBM Corporation 2001 IBM America
Department CNPA PO Box 12195
Research Triangle Park NC 27709 U.S.A.
10-01
All Rights Reserved
References in this publication to IBM products or services do not imply that IBM intends to make them available in all countries in which IBM operates.
IBM, the IBM logo, Predictive Failure Analysis, ServeRAID, Tivoli and TotalStorage are trademarks of International Business Machines Corporation or Tivoli Systems, Inc. in the United States, other countries or both.
Intel and Pentium are trademarks of Intel Corporation in the United States, or other countries, or both.
Microsoft, Windows, Windows NT, and the Windows logo are trademarks of Microsoft Corporation in the United States, other countries, or both.
UNIX is a registered trademark of The Open Group in the United States and other countries.
Other company, product and service names may be trademarks or service marks of other companies.
1 All references to storage capacity refer to raw
storage. Usable storage is dependent upon the RAID level and number of hot spares employed.
2 Rack conversion kit option available.
3 Base system has six drive bays. Up to three
optional 14-bay external enclosures can be added for a total of 48 drives.
4 MHz only measures microprocessor internal clock
speed, not application performance.
5 At the time of publication, NetBench and SPECsfs
performance determination was in progress. Please check ibm.com/storage/nas for the current status.
