CO2 Engineering Manual-ANSUL

(1)

COMPONENTS, DESIGN, INSTALLATION,

RECHARGE AND MAINTENANCE

ANSUL

®

(2)

6-19-98 1-1.1 New Page 6-19-98 1-5.1 New Page 6-19-98 1-8 1 6-19-98 1-8.1 New Page 6-19-98 1-11 1 6-19-98 1-11.1 New Page 6-19-98 1-12 1 6-19-98 1-14 1 6-19-98 1-15 1 6-19-98 1-16 2 6-19-98 1-17 1 6-19-98 1-18 1 6-19-98 1-19 2 6-19-98 1-44 1 6-19-98 1-54 1 6-19-98 1-55 1 6-19-98 2-14 New Page 6-19-98 4-1 1 6-19-98 4-2 1 6-19-98 7-4 1 6-19-98 7-5 1 6-19-98 7-8 2 6-19-98 7-9 1 6-19-98 7-10 1 6-19-98 7-11 1 6-19-98 7-12 1 6-19-98 7-13 1 6-19-98 7-14 1 6-19-98 7-15 1 6-19-98 7-16 1 6-19-98 7-17 1 6-19-98 7-18 1 6-19-98 7-19 1 6-19-98 7-20 1 6-19-98 7-21 1 6-19-98 7-22 1 6-19-98 7-23 1 6-19-98 7-24 1 6-19-98 7-25 1 6-19-98 7-26 1 6-19-98 7-28 1 6-19-98 7-29 2 6-19-98 8-2 1 6-19-98 8-3 1 6-19-98 8-4 1 6-19-98 8-5 1 6-19-98 9-2 1 6-19-98 9-4 2 6-19-98 9-5 2 6-19-98 9-6 1 6-19-98 9-7 1 6-19-98 9-8 1 6-19-98 9-9 1 6-19-98 9-10 1

(3)

6-19-98 9-11 1 6-19-98 9-12 1 6-19-98 9-13 New Page 6-19-98 11-1 1 6-19-98 11-3 1 6-19-98 F-91122 2 2-22-01 1-6 1 2-22-01 1-33.1 New Page 2-22-01 7-7 2 2-22-01 7-27 2

DATE PAGE REV. NO. DATE PAGE REV. NO.

(4)

FORM PAGE

SECTION NO. NO.

1. COMPONENTS

CV90 Valve Cylinder Shipping Assembly F-90110 1-1

CV98 Valve Cylinder Shipping Assembly F-9880 1-1.1

MAX Valve Cylinder Shipping Assembly F-90137 1-2

AP-8 Valve Cylinder Shipping Assembly F-90136 1-3

AUTOPULSE Control System F-90228-1 1-4

HF Electric Actuator F-90182-1 1-5

CV98 Electric Actuator F-9881 1-5.1

CV98/CV90/AP-8 Valve Flexible Discharge Bend F-90132-1 1-6

MAX Valve Flexible Discharge Bend F-90135 1-7

CV90/MAX Valve Stackable/Lever Actuator F-90134-1 1-8

CV98 Lever Release Actuator F-9882 1-8.1

CV90/MAX Valve Manual/Pneumatic Actuator F-90131 1-9

CV90/MAX Valve Pneumatic Actuator F-90133-1 1-10

Discharge Nozzle – Type “D” F-90216-1 1-11

Discharge Nozzle – Type “D” – Corrosion Resistant F-96156 1-11.1

Sealed Nozzle With Strainer F-90217-1 1-12

Bulkhead Mounting Flange F-90218 1-13

Discharge Nozzle – Type “A” F-90219-1 1-14

Discharge Nozzle – Cone Type F-90220-1 1-15

Discharge Nozzle – 4 In. Multi-Discharge Type F-90221-2 1-16

Discharge Nozzle – 6 In. Multi-Discharge Type F-90222-1 1-17

Discharge Nozzle – Regular Type F-90223-1 1-18

Discharge Nozzle – Baffle Type F-90224-2 1-19

Cylinder Bracketing F-90183-1 1-20

Nameplate – MAIN F-90191 1-21

Nameplate – RESERVE F-90190 1-22

Nameplate – Maintenance F-90189 1-23

Warning Plate – Outside Room Without Alarm F-90194 1-24

Pressure Bleeder Plug – 1/4 In. F-90196 1-25

Warning Plate – Outside Room With Alarm F-90193 1-26

Warning Plate – Inside Room With Alarm F-90192 1-27

Connecting Link F-90225 1-28

Lever Release Actuator AP-8 Valve/Selector Valve F-90226-1 1-29

Selector Valves With Pressure Actuator F-90208 1-30

(5)

2-22-01

FORM PAGE

1. COMPONENTS (Continued)

Selector Valves With Lever Actuator F-90210-1 1-32

Direction/Stop Valves F-90211-1 1-33

Lock Handle Stop Valve F-2001045 1-33.1

Manual Pull Box F-90213 1-34

Corner Pulley F-90214 1-35

Check Valves F-90215 1-36

Cable With Swaged End Fitting F-90204 1-37

Dual/Triple Control Boxes F-90206 1-38

Remote Cable Pull Equalizer F-90205 1-39

Quartzoid Bulb Actuator F-90203 1-40

Pneumatic Time Delay F-90207 1-41

AP-8 Valve Enclosed Release Attachment With Flexible Connector F-90227 1-42

Hose Reels F-90195 1-43

Pressure Trip F-90212-1 1-44

Header Safety F-90187 1-45

Header Vent Plug F-90188 1-46

Pressure Operated Siren F-90186-1 1-47

Discharge Indicator F-90185 1-48

Odorizer F-90184 1-49

Pressure Switch – DPST F-90202 1-50

Pressure Switch – 3PST F-90199 1-51

Pressure Switch – SPDT F-90201 1-52

Pressure Switch – DPDT – Explosion-Proof F-90200-1 1-53

Marine Actuation Station – Two Step F-90197-1 1-54

Marine Actuation Station – One Step F-90198-1 1-55

2. APPLICATIONS

Electronic Data Processing – Computer Room and Subfloor F-90171 2-1 Electronic Data Processing – Subfloor F-90164 2-2

Recirculating Turbine Generators F-90106 2-3

Non-Recirculating Turbine Generators F-90162 2-4

Control Rooms F-90177 2-5

Record Storage Rooms F-90175 2-6

Battery Storage F-90174 2-7

(6)

FORM PAGE

2. APPLICATIONS (Continued)

Electrical Cabinets F-90166 2-9

Transformers F-90173 2-10

Wave Solder Machines F-90165 2-11

Industrial Fryers F-90172 2-12

Dip Tanks F-90163 2-13

Open Face Wet Bench and Processing Tool Protection Guide F-97137 2-14

3. SPECIFICATIONS

CSI SPEC-DATA SHEET – Carbon Dioxide Extinguishing Systems F-90181 –

CSI MANU-SPEC SHEET – Carbon Dioxide Extinguishing Systems F-90230 –

4. GENERAL INFORMATION 4-1 – 4-2 Carbon Dioxide 4-1 Personnel Safety 4-1 Types of Systems 4-1 Total Flooding 4-1 Local Application 4-1 Types of Actuation 4-1 Pneumatic 4-1 Mechanical 4-1 Electrical 4-2

Rate of Rise (H.A.D.) 4-2

Types of Detection 4-2

H.A.D. (Rate of Rise) 4-2

Electric 4-2

Mechanical (Fusible Link) 4-2

5. PLANNING 5-1 – 5-4 Application Methods 5-1 Total Flooding 5-1 Local Application 5-1 Hazard Analysis 5-1 – 5-3 Hazard Type 5-1 Hazard Dimensions 5-1 Unclosable Openings 5-1 – 5-2 Types of Fires 5-2 Hazard Atmosphere 5-2 Hazardous Material 5-2 Ventilation Considerations 5-2 Electrical Considerations 5-2 Temperature Range 5-3

(7)

6-19-98

FORM PAGE

6. DESIGN 6-1 – 6-18

Application Method 6-1 – 6-13

Total Flooding 6-1 – 6-5

Local Application 6-5 – 6-13

Hand Hose Lines 6-13

Detection System Requirements 6-13 – 6-14

Mechanical Detectors (Fusible Links) 6-13 – 6-14

Actuation Requirements 6-14 – 6-15

Manual Actuation 6-14

Pneumatic Actuation 6-14

Electric Actuation 6-15

Accessories 6-15 – 6-18

Electric or Mechanical Manual Pull Station 6-15

Selector Valves 6-15 – 6-16

Direction/Stop Valves 6-16

Pressure Operated Siren 6-17

Pressure Switch 6-17

Pressure Trip 6-17

Pneumatic Time Delay 6-17 – 6-18

Alarms 6-18

Reserve System 6-18

Develop Bill of Materials 6-18

Sample Problem 6-18

7. INSTALLATION 7-1 – 7-30

Mounting Components 7-1 – 7-4

Cylinder/Bracket Assembly 7-1 – 7-4

Releasing Devices 7-4

Installing Actuation Piping 7-4 – 7-5

General Piping Requirements 7-4

Actuation Piping Installation 7-5

Installing Distribution Piping 7-5 – 7-7

Hanger Applications 7-5 – 7-6

General Piping Requirements 7-6

Distribution Manifold and Piping Installation 7-7

Main/Reserve System 7-7

Installing Detection/Actuation System 7-8 – 7-17

AUTOPULSE Control System with HF Electric Actuator 7-8

AUTOPULSE Control System with ANSUL AUTOMAN II-C 7-8 – 7-9

with Pneumatic Actuation

ANSUL AUTOMAN II-C Release with Pneumatic Actuation 7-9

H.A.D. Detection with Mechanical Actuation 7-9 – 7-10

Mechanical ANSUL AUTOMAN Release with Fusible Link 7-10 – 7-17

Quartzoid Bulb Actuator (QBA-5) 7-17

Installing Actuators 7-17 – 7-19

Pneumatic 7-17 – 7-18

Manual 7-18

(8)

FORM PAGE

7. INSTALLATION (Continued)

Stacking Actuators 7-19

Installing Accessories 7-20 – 7-29

Manual Pull Station 7-20 – 7-25

Alarms 7-25

Selector Valves 7-25 – 7-27

Lock Handle Stop Valve 7-27

Direction/Stop Valves 7-27 – 7-28

Pressure Trip 7-29

Pressure Switch 7-29

Time Delay 7-29

Pressure Operated Siren 7-29

8. TESTING AND PLACING IN SERVICE 8-1 – 8-6

Testing H.A.D. System 8-1

Testing Pull Station 8-1 – 8-2

Testing Electric Detection System – AUTOPULSE Control System 8-2

Testing Electric Detection System – ANSUL AUTOMAN II-C Release 8-2

Testing Mechanical – ANSUL AUTOMAN Release with Fusible Link 8-2 – 8-3

Testing 60 Second Time Delay 8-4 – 8-5

9. RESETTING AND RECHARGE 9-1 – 9-14

Clear Electrical Equipment 9-1

Check Electrical and Mechanical Equipment 9-1 – 9-2

Piping and Nozzles 9-1

Mechanical Detection System 9-1 – 9-2

Electric Detection System 9-2

H.A.D. Detection System 9-2

Pressure Switch 9-2

Place System Back in Service 9-2 – 9-13

Recharge CO2 Cylinder 9-2 – 9-11

Pneumatic Valve Actuator 9-12

Electric Valve Actuator 9-13

Manual Valve Actuator 9-13

Manual Pull Station 9-13

Replace ANSUL AUTOMAN Cartridge 9-13

10. INSPECTION 10-1 – 10-2

Manual Pull Station 10-1

Detectors 10-1

Control System 10-1

ANSUL AUTOMAN Releasing Device 10-1

Cylinders 10-1

Cylinder Actuator 10-1

Distribution Piping and Nozzles 10-1

Alarms and Sirens 10-1

(9)

6-19-98

FORM PAGE

11. MAINTENANCE 11-1 – 11-6

Semi-Annual Maintenance Examination 11-1 – 11-6

General Information – Weigh Cylinders 11-1 – 11-2

Fusible Link Detection/Mechanical ANSUL AUTOMAN Release 11-2 – 11-3

Thermal Detection/Electric ANSUL AUTOMAN II-C Release 11-4 – 11-5

H.A.D. Detection/Mechanical Control Head 11-5

Electric Detection/AUTOPULSE Control System 11-6

12. TYPICAL APPLICATIONS 12-1 – 12-272

Design Examples 12-1 – 12-271

Example No. 1 – Dip Tanks 12-2 – 12-13

Example No. 2 – Computer Room and Subfloor 12-14 – 12-36

Example No. 3 – Wave Solder Machines 12-37 – 12-60

Example No. 4 – Electrical Cabinets 12-61 – 12-71

Example No. 5 – Transformers 12- 72 – 12-102

Example No. 6 – Subfloor 12-103 – 12-117

Example No. 7 – Battery Storage Vaults 12-118 – 12-126

Example No. 8 – Document Storage 12-127 – 12-138

Example No. 9 – Control Rooms 12-139 – 12-150.1

Example No. 10 – Lube Oil Pits 12-151 – 12-185

Example No. 11 – Generators 12-186 – 12-213

(Recirculating and Non-Recirculating Type)

Example No. 12 – Industrial Fryer 12-214 – 12-272

13. APPENDIX

Proposal Information F-94148

Parts List for Single Row Cylinder Bracketing With Weigh Rail F-9127-1

Parts List for Double Row Cylinder Bracketing With Weigh Rail F-9128-1

Parts List for Back to Back Cylinder Bracketing With Weigh Rail F-9129-1

(10)

CV90 Cylinder Shipping Assembly

Description

The CV90 cylinder is factory filled with carbon dioxide. A single cylinder may be used or multiple cylinders can be manifolded together to obtain the required quantity of agent for total flooding or local application methods. The CV90 cylinder can be actuated electrically, pneumatically, and/or manually with approved valve actuation compo-nents.

The cylinders are shipped with a maintenance record card and protective shipping cap attached to the threaded neck of each cylinder. This cap entirely encloses and protects the valve while in shipment.

The 25, 35, and 50 lb. (11.3, 15.9, and 22.7 kg) cylinders are manufactured with a bent siphon tube which allows for either horizontal or vertical mounting.

Component Material Thread Size/Type Approvals

Cylinder Steel 1-11 1/2 NPT, Female Meets DOT 3A1800 or 3AA1800

CV90 Valve Brass 1-11 1/2 NPT, Male x

1 5/16-12UN-3A Outlet Thread – Male 1.25-18 UNEF-3A Male

Filling Port Thread

Safety Relief Valve Brass .6250-18UNF-3B, Male In Accordance with Bureau of Explosives

Valve/Tank UL (EX-2968), FM Approved, Complies

Assembly with Regulations of the U.S. Coast Guard

(162.038/7/0) and meets requirements of NFPA 12.

Shipping Cap Steel 3.125-11 NS1, Female

Shipping

Assembly _{Weight Of CO2} Approximate Weight Dimension A* Dimension B

Part No. lb. (kg) lb. (kg) in. (cm) in. (cm)

Finish: Red Enamel Paint

79814 25 (11.3) 98 (44.5) 26 1/2 (67) 8 1/2 (21.6)

79816 35 (15.9) 121 (54.9) 35 3/4 (90.8) 8 1/2 (21.6)

79818 50 (22.7) 165 (75) 52 3/4 (128.9) 8 1/2 (21.6)

79820 75 (34.0) 200 (91) 57 3/4 (146.7) 9 1/4 (23.5)

79822 100 (45.4) 300 (136) 59 3/4 (151.8) 10 3/4 (27.3)

Finish: Red Epoxy Paint

79815 25 (11.3) 98 (44.5) 26 1/2 (67) 8 1/2 (21.6) 79817 35 (15.9) 121 (55) 35 3/4 (90.8) 8 1/2 (21.6) 79819 50 (22.7) 165 (75) 52 3/4 (133.9) 8 1/2 (21.6) 79821 75 (34.0) 200 (91) 57 3/4 (146.7) 9 1/4 (23.5) 79823 100 (45.4) 300 (136) 59 3/4 (151.8) 10 3/4 (27.3) *Tolerance ± 1/2 in. (12.7 mm)

(11)

NOTE: Use Flexible Discharge Bend, Part No. 42424, when attaching valve to supply pipe or manifold.

ANSUL is a registered trademark.

ANSUL INCORPORATED, ONE STANTON STREET, MARINETTE, WI 54143-2542 715-735-7411 Form No. F-90110 ©1997 Ansul Incorporated Litho in U.S.A. A HEIGHT TO OUTLET B SAFETY DISC NUT SIPHON TUBE 001416 001816 1 IN. STANDARD PIPE THREAD FILL CHECK RECOIL SEAT RECOIL VALVE MAIN SEAL DISCHARGE BEND OUTLET THREADED FOR SIPHON TUBE THREADED FOR RELEASE ATTACHMENT OR SHIPPING CAP SEAL BODY

SAFETY DISC NUT SAFETY DISC AND WASHER MAIN STEM BACK PRESSURE CHECK VALVE MAIN SEAL SPRING SPRING STOP PLUNGER SPRING PLUNGER SET SCREW ACTUATION INSERT ACTUATION ISOLATOR 2 13/16 IN. (7.14 cm) 6 IN. (15.2 cm) VALVE OUTLET 001417

(12)

CV-98 Cylinder Shipping Assembly

Description

The CV-98 cylinder is factory filled with carbon dioxide. A single cylinder may be used or multiple cylinders can be manifolded together to obtain the required quantity of agent for total flooding or local application methods. The CV-98 cylinder can be actuated electrically, pneumatically, and/or manually with approved valve actuation compo-nents.

The cylinders are shipped with a maintenance record card and protective shipping cap attached to the threaded neck of each cylinder. This cap entirely encloses and protects the valve while in shipment.

The 35 and 50 lb. (15.9 and 22.7 kg) cylinders are manu-factured with a bent siphon tube which allows for either horizontal or vertical mounting.

CV-98 Valve Brass 1-11 1/2 NPT, Male x

1 5/16-12UN-3A Outlet Thread – Male

Safety Relief Valve Brass .6250-18UNF-3B, Male In Accordance with Bureau of

Explosives

Assembly with Regulations of the U.S. Coast

Guard (162.038/7/0) and meets requirements of NFPA 12.

Shipping

Assembly _{Weight Of CO2} Approximate Weight Dimension A Dimension B

Finish: Red Enamel Paint

426242 35 (15.9) 121 (54.9) 35 3/4 (90.8) 8 1/2 (21.6)

426244 50 (22.7) 165 (75) 52 3/4 (128.9) 8 1/2 (21.6)

426246 75 (34.0) 200 (91) 57 3/4 (146.7) 9 1/4 (23.5)

426248 100 (45.4) 300 (136) 59 3/4 (151.8) 10 3/4 (27.3)

Finish: Red Epoxy Paint

426243 35 (15.9) 121 (55) 35 3/4 (90.8) 8 1/2 (21.6)

426245 50 (22.7) 165 (75) 52 3/4 (133.9) 8 1/2 (21.6)

426247 75 (34.0) 200 (91) 57 3/4 (146.7) 9 1/4 (23.5)

(13)

001816

CV-98 CO2 VALVE

The CV-98 valve has a ten (10) year warranty. The valve requires no internal maintenance. The valve is sealed closed and must never be disassembled. If there is ever a malfunction of the CV-98 valve, the complete valve must be sent back to Ansul for warranty replacement. If the external seal is broken, the warranty is voided.

(14)

MAX Valve Cylinder Shipping Assembly

Description

The MAX valve cylinder is factory filled with carbon diox-ide. A single cylinder may be used or multiple cylinders can be manifolded together to obtain the required quantity of agent for total flooding or local application methods. The MAX valve cylinder can be actuated electrically, pneumatically, and/or manually with approved valve actu-ation components.

The cylinders are shipped with a maintenance record card and protective cap attached to the threaded collar on the neck of each cylinder. This cap entirely encloses and pro-tects the valve while in shipment.

MAX Valve Brass 1-11 1/2 NPT, Male

3/4-14 NPSM Outlet Thread, Female

Safety Relief Brass .6250-18UNF-3B, Male In Accordance with Bureau of Explosives

Valve

Shipping

Finish: Red Enamel Paint

70760 50 (22.7) 165 (75) 54 3/4 (139.0) 8 1/2 (21.6)

70761 75 (34) 200 (91) 59 3/4 (151.8) 9 1/4 (23.5)

70762 100 (45.4) 300 (136) 61 3/4 (156.8) 10 3/4 (27.3)

Finish: Red Epoxy Paint

76921 50 (22.7) 165 (75) 54 3/4 (139.0) 8 1/2 (21.6)

76922 75 (34) 200 (91) 59 3/4 (151.8) 9 1/4 (23.5)

76923 100 (45.4) 300 (136) 61 3/4 (156.8) 10 3/4 (27.3)

(15)

CYLINDER COLLAR (THREADED FOR ATTACHMENT OF SHIPPING CAP)

MAX CYLINDER VALVE

BACK-PRESSURE ACTUATOR – REPLACE WITH STACKABLE BACK-PRESSURE ACTUATOR FOR OTHER ACTUATION MEANS PISTON VENT PORT VALVE CORE BALL CHECK PISTON MAIN SEAL VALVE BODY THREADED FOR SIPHON TUBE ADAPTOR 1 IN. STANDARD PIPE THREAD SAFETY RELIEF DEVICE SAFETY DISC AND WASHER 4 1/2 IN. (11.4 cm) CHECK VALVE INSERT 4 1/16 IN. (10.3 cm) VALVE OUTLET STANDARD BACK-PRESSURE ADAPTOR PASSAGE FOR PRESSURE OPERATION ACTUATOR SEAL SIPHON TUBE ADAPTOR SIPHON TUBE A HEIGHT TO OUTLET B DIAMETER TAG 001818 001819 001820

(16)

AP-8 Cylinder Shipping Assembly

Description

The AP-8 cylinder is factory filled with carbon dioxide. A single cylinder may be used or multiple cylinders can be manifolded together to obtain the required quantity of agent for total flooding or local application methods. The AP-8 cylinder can be actuated electrically, pneumatically, and/or manually with approved valve actuation components.

The cylinders are shipped with a maintenance record card and protective cap attached to the threaded collar on the neck of each cylinder. This cap entirely encloses and pro-tects the valve while in shipment.

Shipping

Finish: Red Enamel Paint

46240 50 (22.7) 165 (75) 52 1/4 (132.7) 8 1/2 (21.6)

46242 75 (34) 200 (91) 57 1/4 (145.4) 9 1/4 (23.5)

46244 100 (45.4) 300 (136) 59 1/4 (150.5) 10 3/4 (27.3)

Finish: Red Epoxy Paint

76924 50 (22.7) 165 (75) 52 1/4 (132.7) 8 1/2 (21.6) 76925 75 (34) 200 (91) 57 1/4 (145.4) 9 1/4 (23.5) 76926 100 (45.4) 300 (136) 5 1/4 (150.5) 10 3/4 (27.3) *Tolerance ± 1/2 in. (12.7 mm) BONNET CAP BONNET PRESSURE VENT SAFETY DISC NUT RECOIL PREVENTOR CYLINDER COLLAR (THREADED FOR ATTACHMENT OF PROTECTION COVER) CYLINDER MAIN OUTLET 1 IN. STANDARD PIPE THREAD CYLINDER SHIPPING CAP HEIGHT TO OUTLET A AP-8 VALVE RECORD TAG 001821 001822 B

(17)

Safety Relief Valve Brass .6250-18UNF-3B, Male In Accordance with Bureau of Explosives

VALVE IN OPEN POSITION VALVE IN CLOSED POSITION

THREADED FOR RELEASE ATTACHMENT OR BONNET CAP

PASSAGE FOR PRESSURE OPERATION

BONNET CAP CHAIN SAFETY PLUG

SAFETY DISC AND WASHER

MINIMUM AREA OF OUTLET PASSAGE 0.2485 SQ. IN.

THREADED FOR SYPHON TUBE

001823

PRESSURE RELEASE PLUG

CHECK

OUTLET CHECK

1 IN. STANDARD PIPE THREAD DISCHARGE BEND OUTLET

(18)

AUTOPULSE Control System

Description

The AUTOPULSE Control System consists of a micro-processor based panel field programmable for cross-zone, counting-cross-zone, independent or priority-zone (counting) detection circuit applications. Several models of the AUTOPULSE Control System are available depending on the type of hazard being protected. The AUTOPULSE Control System is ideal for industrial, com-mercial and institutional facilities where an automatic electronic control system is required to actuate a fixed suppression system. The control system is listed by UL and ULC, approved by FM, and has been tested to the applicable FCC Rules and Regulations for Class “A” computing devices. The design meets the National Fire Protection Association (NFPA) 72 “National Fire Alarm Code.”

ANSUL and AUTOPULSE are registered trademarks.

See Price List and Installation Maintenance Manual for details and part numbers of individual shipping assemblies.

Component Approvals

AUTOPULSE Control System UL (S-2374)

ULC

FM Approved FCC

1-4

(19)

HF Electric Actuator

Description

Electrical actuation of an agent cylinder is accomplished by an HF electric actuator interfaced through an AUTOPULSE Control System. This actuator can be used in hazardous environments where the ambient tempera-ture range is between 0 °F to 130 °F (–18 °C to 54 °C). The HF electric actuator meets the requirements of N.E.C. Class I, Div. 1, Groups B, C, D and Class II, Div. 1, Groups E, F, G. A maximum of two HF electric actuators can be used on a single AUTOPULSE release circuit. When utilizing only one HF electric actuator, an in-line resistor, Part No. 73606, is required in the supervised release circuit.

The actuator specifications are:

Nominal Rated Voltage

Voltage Minimum Maximum

12 VDC @ 0.57 amps 10.4 VDC* 14.0 VDC

In auxiliary or override applications, a manual-local over-ride valve actuator or a manual cable pull actuator can be installed on top of the HF electric actuator by removing the safety cap.

An arming tool is required to reset the actuator after oper-ation. The actuator contains a standard 1/2 in. threaded female straight connector for electrical conduit hookup.

Shipping Assembly

Part No. Description

73327 HF electric actuator

1-5

HF Electric Actuator Body: 1/2 in. Straight Female UL (EX-2968)

Brass FM Approved

Plunger Stainless Steel

*Minimum operating voltage is 9.0 VDC.

ANSUL and AUTOPULSE are registered trademarks.

2 1/4 IN. (5.7 cm)

(20)

CV-98 Electric Actuator

Description

Electrical actuation of a CV-98 CO2 cylinder valve is

accomplished by a CV-98 electric actuator interfaced through an AUTOPULSE Control System. This actuator can be used in hazardous environments where the ambi-ent temperature range is between 0 °F to 130 °F (–18 °C to 54 °C). The CV-98 electric actuator meets the require-ments of N.E.C. Class I, Div. 1, Groups B, C, D and Class II, Div. 1, Groups E, F, G. A maximum of two CV-98 elec-tric actuators can be used on a single AUTOPULSE release circuit. When using either one or two CV-98 elec-tric actuators, an in-line resistor, Part No. 426001, must always be used.

The actuator specifications are: Nominal Voltage

24 VDC @ 1.5 amps

In auxiliary or override applications, a manual cable pull actuator can be installed on top of the CF-98 electric actuator by removing the safety cap.

The actuator contains a standard 1/2 in. threaded female straight connector for electrical conduit hookup.

The CV-98 electric actuator uses a replaceable METRON PROTRACTOR which is a device designed to produce a high force mechanical output. The actuator is electrically actuated and will operate within milliseconds.

The METRON PROTRACTOR must be replaced after

discharge of the CO2system.

423684 CV-98 Electric Actuator

423958 Replaceable METRON

PROTRACTOR

CV-98 Electric Actuator Body: 1/2 in. Straight Female UL (E91021)

Brass FM Approved

Plunger Stainless Steel

001395

(21)

CV98/CV90/AP-8 Valve Flexible Discharge Bend

Description

The CV98/CV90/AP-8 valve Flexible Discharge Bend (Part No. 427082) is a 5/8 in. (1.59 cm) I.D. extra-heavy flexible hose which connects the valve discharge outlet to the fixed piping or header manifold. The discharge bend has a female 1.3-12-UN-3B thread for connecting to the valve outlet and a male 1/2 in. NPT thread for connecting to the fixed piping or manifold. The discharge bend will withstand a pressure of 9000 psi (621 bar). Its flexible connection allows for easy alignment of multiple cylinder banks to fixed piping. Each bend has a built-in check valve that prevents loss of agent should the system dis-charge while any cylinder is removed.

Thread Size/Type

Component Material Valve End Manifold End Approvals

5/8 in. Flexible SAE 100 R2 1 5/16-12-UN-3B 1/2 NPT Male U.S. Coast Guard (162.038/7/0)

Discharge Bend Type AT Female UL (EX-2968)

FM Approved

1-6 REV. 1

427082 Flexible discharge bend

842430 Washer

ANSUL INCORPORATED, ONE STANTON STREET, MARINETTE, WI 54143-2542 715-735-7411 Form No. F-90132-1 ©1999 Ansul Incorporated Litho in U.S.A. 18 7/8 IN. (47.9 cm) MANIFOLD/END 1/2 IN. NPT MALE COUPLING FEMALE ADAPTOR (THREAD 1 5/16 IN.-12N-3) (BRONZE) VALVE END CHECK SWAGE ON 000658

(22)

MAX Valve Flexible DIscharge Bend

Description

The MAX valve Flexible Discharge Bend (Part No. 68714) is a 5/8 in. (1.59 cm) I.D. extra-heavy flexible hose which connects the valve discharge outlet to the fixed piping or header manifold. The discharge bend has a male 3/4-14 NPSM thread for connecting to the valve outlet and a male 1/2 in. NPT thread for connecting to the fixed piping or manifold. The discharge bend will withstand a pressure of 6000 psi (41370 kPa). Its flexible connection allows for easy alignment of multiple cylinder banks to fixed piping. Each bend has a built-in check valve that prevents loss of agent should the system discharge while any cylinder is removed.

Thread Size/Type

Component Material Valve End Manifold End Approvals

5/8 in. Flexible Double Wire Braided 3/4–14 NPSM, 1/2 NPT Male U.S. Coast Guard (162.038/7/0)

Discharge (Perforated) Rubber Male UL (EX-2968)

Bend – MAX Covered Hose FM Approved

Bronze Couplings

68714 Flexible discharge bend

18 7/8 IN. (47.9 cm) CHECK

O-RING (PART NO. 24235)

1/2 IN. NPT MALE COUPLING (BRONZE) 3/4 IN. MALE ADAPTOR VALVE END MANIFOLD/ PIPE END SWAGE ON 001827

(23)

CV90/MAX Valve Stackable/Lever Actuator

Description

Stackable Actuator – MAX Valve Only: The stackable

actuator is required to attach a valve actuation component to the MAX valve. The slave back-pressure actuator, which comes installed as part of the MAX valve, must be removed in order to attach the stackable back-pressure actuator. In one and two-cylinder systems, one stackable back-pressure actuator is required to attach a valve actu-ation component. In a two cylinder system, the remaining cylinder is actuated by the pressure generated within the distribution manifold.

In three or more cylinder systems, two stackable back-pressure actuators are required to attach valve actuation components. The remaining cylinder(s) is actuated by the pressure generated within the distribution manifold.

Lever Release Actuator – CV90/MAX Valve: The

manu-al lever release actuator provides a manumanu-al means of agent cylinder actuation by direct manual actuation of its pull lever or cable actuation when used in conjunction with a remote manual pull station.

In three or more cylinder systems, a connecting link is required to provide simultaneous actuation of both manu-al cable-pull actuators.

Manual actuation is accomplished by pulling the valve hand lever. The lever design contains a forged mechani-cal detent which secures the lever in the open position when actuated.

Cable-pull actuation is accomplished by using a remote manual pull station. The remote manual pull station sys-tem must contain the components necessary to meet the actuator lever traveling requirements of 7 in. (17.8 cm).

Component Material Approvals

Stackable Brass U.S. Coast Guard

Back-Pressure (162.038/7/0)

Actuator UL (EX-2968)

FM Approved

All Manual Brass with U.S. Coast Guard

Cable-Pull Stainless (162.038/7/0)

Actuators Steel Pin U.L. (EX-2968)

FM Approved

70326 Stackable back-pressure actuator

70846 Manual cable-pull actuator (handle and pin; for local control)

70847 Manual-cable pull actuator (handle, no pin; for remote control)

32098 Manual-cable pull actuator (no handle, no pin; for use with three or more cylinders)

(24)

3 7/8 IN. (9.8 cm) DEPTH: 3 IN. (7.6 cm) PIN 3 7/8 IN. (9.8 cm) FOR USE ON HALON MAX VALVE OR CV90 VALVES ONLY. LABEL NO. 70475 000897 Part No. 70846 Part No. 70326 001828 3 7/8 IN. (9.8 cm) DEPTH: 2 13/16 IN. (7.1 cm) HANDLE 3 7/8 IN. (9.8 cm) 001393b

Part No. 70847 FOR USE ON HALON MAX VALVE OR CV90 VALVES ONLY. LABEL NO. 70475 3 7/8 IN. (9.8 cm) DEPTH: 2 13/16 IN. (7.1 cm) HANDLE 3 7/8 IN. (9.8 cm) 001393b Part No. 32098 FOR USE ON HALON MAX VALVE OR CV90 VALVES ONLY. LABEL NO. 70475

(25)

Description

The manual lever release actuator provides a manual means of CV-98 CO₂ agent cylinder actuation by direct manual actuation of its pull lever or cable actuation when used in conjunction with a remote manual pull station. Manual actuation is accomplished by pulling the actuator hand lever. The lever design contains a forged mechanical detent which secures the lever in the open position when actuated.

Cable-pull actuation is accomplished by using a remote manual pull station. The remote manual pull station system must contain the components necessary to meet the actua-tor lever traveling requirements of 7 in. (17.8 cm).

These lever actuators can also be attached to the top of a CV-98 electric actuator.

Each type actuator has its Part No. stamped on the lever.

All Manual Brass with FMRC Approved Cable-pull Stainless UL Listed Actuators Steel Pin (EX-2968)

423309 Manual cable-pull actuator (handle and pin; for local control) 423310 Manual cable-pull actuator (handle, no pin; for remote control) 423311 Manual cable-pull actuator (no handle, no pin; for remote control)

3 7/8 IN.* (9.8 cm) 3 7/8 IN. (9.8 cm) 3 7/8 IN. (9.8 cm) HANDLE PIN DEPTH: 3 7/8 IN. (7.6 cm) Part No. 423309 DEPTH: 1 13/16 IN. (4.6 cm) Part No. 423311 3 7/8 IN.* (9.8 cm)

CV-98 Lever Release Actuator

1-8.1

000897 002553

* Add 1 9/16 in. (3.9 cm) to height when handle is in the straight up position. 1 1/8 – 18

THREAD

1 1/8 – 18 THREAD

(26)

ANSUL is a registered trademark. 3 7/8 IN. (9.8 cm) DEPTH: 2 13/16 IN. (7.1 cm) Part No. 423310 001420 1 1/8 – 18 THREAD

(27)

CV90/MAX Valve Manual/Pneumatic Actuator

Description

The CV90/MAX valve manual/pneumatic actuator (Part No. 32094) is used where a system design requires manual-local override at the cylinder. The manual actuator can be mounted directly to the release attachment port of the CV90 valve or to the release attachment port on the MAX valve by incorporating the use of a stackable actuator.

When either valve uses an electric actuator, the manual/pneumatic actuator can be mounted directly to the top of the electric actuator, giving the system the capability of manual, pneumatic, and electric actuation.

Operation is accomplished by either removing the ring pin and depressing the red palm button or by supplying a mini-mum of 30 psi (207 kPa) to the inlet port. A swivel connec-tion is provided to facilitate orientaconnec-tion of the inlet port.

Manual/Pneumatic Brass U.S. Coast Guard

Actuator (162.038/7/0)

UL (EX-2968) FM Approved

32094 Manual/pneumatic actuator 1-9 001394 3 3/4 IN. (9.5 cm) INLET PORT 1/4 IN. NPT FEMALE PIPE 1 7/8 IN. (4.8 cm)

(28)

CV90/MAX Valve Pneumatic Actuator

Description

The CV90/MAX valve pneumatic actuator (Part No. 32096) is used where a system design requires pneumat-ic actuation at the cylinder. The pneumatpneumat-ic actuator can be mounted directly to the release attachment port of the CV90 valve or to the release attachment port on the MAX valve by incorporating the use of a stackable actuator. When either valve uses an electric actuator, the pneumat-ic actuator can be mounted directly to the top of the elec-tric actuator, giving the system the capability of both pneumatic and electric actuation.

Operation is accomplished by supplying a minimum of 30 psi (207 kPa) for MAX valve and a minimum of 100 psi (690 kPa) for CV90 valve, to the inlet port of the actuator. A swivel fitting is provided for orientation of piping and to allow for disassembly without breaking the pneumatic connections.

Pneumatic Brass U.S. Coast Guard

Actuator (162.038/7/0)

32096 Pneumatic Actuator 1 5/8 IN. (4.1 cm) 1 7/8 IN. (4.8 cm) INLET PORT 1/4 IN. NPT FEMALE PIPE 001391

(29)

Discharge Nozzle – Type “D”

Description

The type ‘‘D’’ nozzle is used primarily for local application and is also listed and approved for use as a total flooding nozzle. The nozzle shell is drawn sheet steel and the insert is brass. The ‘‘D’’ type nozzle is available in orifice sizes ranging from 1 through 7. The discharge rate of the nozzle depends on the orifice size and nozzle pressure. The area covered in local application is dependent upon

the discharge rate and the height of the nozzle above the surface being protected. Height range: 15 to 91 1/2 in. (38 to 232 cm). Discharge rate: 11 to 48.5 lbs. per minute (5 to 22 kg per minute). See carbon dioxide design manu-al for UL and FM listed area coverage and required flow rates. The nozzle is painted red with chrome or nickel plating available as an option.

Part No. Description Orifice Code

426100 Type ‘‘D’’ nozzle with strainer 1 – 3

426101 Type ‘‘D’’ nozzle 3.5 – 7

426301 Type ‘‘D’’ nozzle, Chrome Plated 3.5 – 7

1-11

Component Material Thread Size/Type Orifice Size Approvals

Type ‘‘D’’ nozzle Shell: 1/2 in. NPT Female 1 through 7 U.S. Coast Guard (162.038/7/0)

Steel UL (EX-2968)

Insert: FM Approved

Brass Strainer:

Monel

(30)

000672a

000671a

000671b 000672b 2 IN. (5 cm) DIAMETER 2 1/2 IN. (6.3 cm) DIAMETER 2 1/2 IN. (6.3 cm) DIAMETER 4 IN. (10.1 cm) 4 IN. (10.1 cm) STRAINER NOZZLE INSERT ORIFICE 3 15/32 IN. (8.8 cm) NOZZLE CODE STAMPED HERE 2 IN. (5 cm) DIAMETER 1/2 IN. NPT BRASS NOZZLE INSERT DRAWN STEEL ORIFICE 3 15/32 IN. (8.8 cm)

(31)

Discharge Nozzle – Type “D”

(Corrosion Resistant)

1-11.1

Type “D” nozzle Shell: Steel 1/2 in. NPT Female 1 through 7 FM Approved*

Insert: Stainless Steel Strainer: Monel

Assembly coated with acid

resistant material (Halar®ECTFE)

Blow Off Cap Teflon®(TFE)

Shipping Assembly Orifice

Part No. Description Code

422647 Type “D” nozzle with strainer 1

422648 Type “D” nozzle with strainer 1+

422650 Type “D” nozzle with strainer 2+

422652 Type “D” nozzle 3+ 422653 Type “D” nozzle 4 422654 Type “D” nozzle 4+ 422655 Type “D” nozzle 5 422656 Type “D” nozzle 5+ 422657 Type “D” nozzle 6 422658 Type “D” nozzle 6+ 422659 Type “D” nozzle 7

422780 Nozzle Tube Adaptor

423256 Spare Blow Off Cap (1)

426206 Cap Installation Tool

Description

The corrosion resistant (CR) type “D” nozzle is used pri-marily for local application wet bench protection but is also approved for use as a total flooding nozzle. The noz-zle shell is drawn sheet steel and the insert is stainless steel. The entire nozzle is coated with a corrosion resistant material which is not effected by the acid type environment of a typical wet bench hazard. The CR “D” type nozzle is available in orifice sizes ranging from 1 through 7. Nozzle shipping assembly includes a blow off cap. Cap should be installed using special tool, Part No. 426206.

Also available is a plastic nozzle tube adaptor which can be threaded on the external nozzle threads and plastic

tubing can be attached to this to cover the discharge pip-ing within the corrosive environment.

The discharge rate of the nozzle depends on the orifice size and nozzle pressure. The area covered in local appli-cation is dependent upon the discharge rate and the height of the nozzle above the surface being protected. Height range: 24 to 33 in. (61 to 84 cm). Discharge rate: 16.4 to 21.8 lbs. per minute (7.4 to 9.9 kg per minute). See carbon dioxide design manual for FM listed area cov-erage and required flow rates

NOTE: For non-typical wet bench environments, contact Ansul Technical Services Department. *FM APPROVAL limited to non-corrosive environments.

ANSUL is a registered trademark, Halar is a registered trademark of Ausimont, Teflon is a registered trademark of DuPont.

ANSUL INCORPORATED, ONE STANTON STREET, MARINETTE, WI 54143-2542 715-735-7411 Form No. F-96156 ©1998 Ansul Incorporated Litho in U.S.A. 2 1/2 IN. DIA. (6.3 cm) 4 IN. (10.2 cm) 1/2 IN. FEMALE NPT BLOW OFF CAP 001538 LOCATION OF ORIFICE SIZE STAMPING 1-16 UN 2A EXTERNAL THREAD

(32)

Sealed Nozzle With Strainer

Description

The sealed nozzle is used primarily in ducts and enclosed machinery spaces. The seal portion of the nozzle is a combination line seal and strainer unit. It is used to pre-vent dirt or vapors from entering the system piping and also to function as a strainer for the system piping. On operation of the carbon dioxide system, the high pressure of the gas released from the cylinders ruptures the thin

sealing disc, allowing an unobstructed flow of gas to the internal discharge nozzle.

The advantage of the sealed nozzle is that it does not require disassembly of the system piping to clean the strainer or replace a ruptured sealing disc. This is accom-plished by removing the hex cap on the nozzle.

426102 Sealed nozzle with strainer 2 – 7

Sealed Nozzle Body: 1/2 in. NPT Female 2 through 7 U.S. Coast Guard (162.038/7/0)

Brass UL (EX-2968) Strainer: FM Approved Monel NOZZLE HEX CAP 2 IN. (5.1 cm)

SPARE SEALING DISCS BODY 1/2 IN. NPT INLET 1/2 IN. STRAIGHT PIPE THREAD CELERON WASHER SEALING DISC

JAM NUT TO BE USED IF DUCT IS TOO THIN TO BE THREADED 3 1/4 IN. (8.3 cm) KNURLED RING SEALING DISC RETAINER MONEL SCREEN – STRAINER 000673

NOTE: When ordering, specify orifice code required: Example – Part No. 426102 – 2.5.

(33)

Bulkhead Mounting Flange

Description

The bulkhead mounting flange, Part No. 42806, is used on the multi-discharge type nozzles. The flange allows the nozzle to be rigidly fastened against a wall or bulkhead of a hazard area, keeping the nozzle outside of the area. This is an advantage on hazard areas where the nozzle cannot be mounted inside the area because of space limi-tations or interference with moving parts. A typical appli-cation is a large exhaust duct where access into the duct is limited.

Also available is a sealing plug, Part No. 42293, which is shipped as a separate unit.

Should a seal be required between the flange and the mounting surface, the fiber seal, Part No. 36550, is avail-able.

Mounting Steel U.S. Coast Guard

Flange (162.038/7/0)

1-13

NOTE: When using mounting flange with a fiber seal, use retaining ring, Part No. 46793.

000670a 000670b NOZZLE CLAMPING RING MOUNTING SCREWS (1/4 IN. – 20 x 5/8 IN. LONG) ASSEMBLY OF MULTI-DISCHARGE NOZZLE WITH MOUNTING RINGS (BULKHEAD NOT SHOWN)

BULKHEAD MOUNTING HOLE 4 1/2 IN. DIAMETER RETAINING RING LOCKWASHER AND NUT PLUG SEAL (OPTIONAL) PART NO. 42293 CLAMPING SCREW

(34)

Discharge Nozzle – Type “A”

Description

The type ‘‘A’’ nozzle is used primarily for local application and is also listed and approved for use as a total flooding nozzle. The nozzle shell is drawn sheet steel and the insert is brass. The ‘‘A’’ type nozzle is available in orifice sizes ranging from 1 through 7. The discharge rate of the nozzle depends on the orifice size and nozzle pressure. The area covered in local application is dependent on the discharge rate of the height of the nozzle above the

surface being protected. Height range: 18 to 72 in. (46 to 183 cm). Discharge rate: 14 to 48.5 lbs. per minute (6 to 22 kg per minute). See carbon dioxide design manual for area coverage and required flow rates.

The nozzle is painted red with chrome or nickel plating available as an option.

426103 Type ‘‘A’’ nozzle with strainer 1 – 3

426104 Type ‘‘A’’ nozzle 3.5 – 7

Type ‘‘A’’ Nozzle Shell: 1/2 in. NPT Female 1 through 7 U.S. Coast Guard (162.038/7/0)

Steel UL (EX-2968)

Insert: FM Approved

Brass Strainer:

Monel

(35)

Carbon Dioxide Type ‘‘A’’ Discharge Nozzle 001829a 001830a 001830b 001829b 3 1/4 IN. (8.2 cm) DIAMETER 3 3/4 IN. (8.2 cm) DIAMETER 4 1/2 IN. (11.4 cm) NOZZLE INSERT ORIFICE 4 23/32 IN. (11.9 cm) NOZZLE CODE STAMPED HERE 3 1/4 IN. (8.2 cm) DIAMETER 3 3/4 IN. (8.2 cm) DIAMETER 4 1/2 IN. (11.4 cm) 1/2 IN. NPT BRASS NOZZLE INSERT DRAWN STEEL ORIFICE 4 23/32 IN. (11.9 cm)

(36)

Discharge Nozzle – Cone Type

Description

The cone nozzle is used primarily for local application and also listed and approved for use as a total flooding nozzle. The nozzle insert is stainless steel and the body is sheet steel. The nozzle is available in orifice sizes ranging from 3 through 11. The discharge rate of the nozzle depends on the orifice size and nozzle pressure. The area covered in local application is dependent upon the discharge rate and the height above the surface being protected.

Height range: 42 to 108 in. (107 to 274 cm). Discharge rate: 21 to 132 lbs. per minute (10 to 60 kg per minute). See carbon dioxide design manual for area coverage and required flow rates.

Cone nozzle Shell: 1/2 in. NPT Female 3 through 11 UL (EX-2968)

Steel FM Approved

Insert: Stainless Steel

Shipping Assembly Orifice

Part No. Description Code

426105 Cone nozzle 3 – 11 9 1/4 IN. (23.4 cm) 4 13/16 IN. (12.2 cm) 001834

NOTE: When ordering, specify orifice code required: Example – Part No.426105 – 3.5.

(37)

Discharge Nozzle – 4 in. Multi-Discharge Type

Description

The 4 in. multi-discharge nozzle is used only for total flood-ing applications. The nozzle insert is brass and the remain-der of the nozzle is steel. The nozzle is available in orifice sizes ranging from 2 through 18. The dischargerate of the

nozzle depends on the orifice size and the nozzle pressure.

4 in. MD Nozzle Nozzle: 1/2 in. NPT Female 2 through 4.5 U.S. Coast Guard (162.038/7/0)

w/Strainer Steel UL (EX-2968)

Insert: FM Approved

Brass

4 in. MD Nozzle Nozzle: 1/2 in. NPT Female 5 through 10 U.S. Coast Guard (162.038/7/0)

Steel UL (EX-2968)

Insert: FM Approved

Brass

4 in. MDL Nozzle Nozzle: 3/4 in. NPT Female 8 through 18 U.S. Coast Guard (162.038/7/0)

Steel UL (EX-2968)

Insert: FM Approved

Brass

1-16

426106 4 in MD nozzle with strainer 2 – 4.5

426107 4 in MD nozzle 5 – 10

426108 4 in MD nozzle 8 – 18

(38)

Multi-Discharge Nozzle – 4 MD and 4 MDL STRAINER 1/2 IN. NPT 5 13/16 (13.1 cm) 3 1/2 IN. (8.8 cm) METAL HORN BRASS NOZZLE INSERT

CODE NO. OF ORIFICE STAMPED ON CONNECTOR 1/2 IN. OR 3/4 IN. NPT (SEE TABLE) 5 13/16 (13.1 cm) 3 1/2 IN. (8.8 cm) 001831a 001831b 001835a

(39)

Discharge Nozzle – 6 in. Multi-Discharge Type

Description

The 6 in. multi-discharge nozzle is used primarily for local application and it is also listed and approved for use as a total flooding nozzle. The nozzle insert is brass and the remainder of the nozzle is steel. The nozzle is available in orifice sizes ranging from 2 through 18. The discharge rate of the nozzle depends on the orifice size and the nozzle pressure. The area covered in local application is depen-dent upon the discharge rate and the height above

the surface being protected. Height range: 36 to 144 in. (91 to 366 cm). Discharge rate: 28.5 to 108 lbs. per minute (13 to 49 kg per minute). See carbon dioxide design manu-al for area coverage and required flow rates.

The nozzle is painted red with chrome and nickel plating available as an option.

6 in. MD Nozzle Nozzle: 1/2 in. NPT Female 2 through 4.5 UL (EX-2968)

w/Strainer Steel FM Approved

Insert: Brass

6 in. MD Nozzle Nozzle: 1/2 in. NPT Female 5 through 10 UL (EX-2968)

Steel FM Approved

Insert: Brass

6 in. MDL Nozzle Nozzle: 3/4 in. NPT Female 8 through 18 UL (EX-2968)

Steel FM Approved

Insert: Brass

1-17

426109 6 in MD nozzle with strainer 2 – 4.5

426110 6 in MD nozzle 5 – 10

426111 6 in MDL nozzle 8 – 18

(40)

Multi-Discharge Nozzle – 6 MD and 6 MDL

000737a

000669a

000669b 000737b STRAINER 1/2 IN. NPT 7 3/4 IN. (19.6 cm) 3 1/2 IN. (8.8 cm)

DRAWN STEEL HORN BRASS NOZZLE

INSERT

CODE NO. OF ORIFICE STAMPED ON CONNECTOR 1/2 IN. OR 3/4 IN. NPT (SEE TABLE) 7 3/4 IN. (19.6 cm) 3 1/2 IN. (8.8 cm)

(41)

Discharge Nozzle – Regular Type

Description

The regular type nozzle is used for total flooding applica-tions only. The nozzle is available in seven different config-urations: regular (1/2 in.), regular RL (3/4 in.), regular sealed with strainer, regular sealed, regular sealed with flange and strainer, regular sealed with flange, and regular RSFL sealed with flange. The sealed type has a sealing disc retaining ring and a frangible seal to prevent foreign matter from entering and plugging the nozzle orifice. The discharge rate of the regular nozzle depends on nozzle

pressure and orifice size. The regular type nozzle provides orifice sizes of 1 through 18.

The nozzle is available with 1/2 in. NPT threads for orifice sizes 1 through 12 and 3/4 in. NPT threads for orifice sized 8 through 18. Nozzles with orifices of 1 through 2+ are sup-plied with a strainer.

The nozzle is supplied in natural brass with chrome or nickel plating available. Stainless steel nozzles are also available.

Regular Type Brass 1/2 in. NPT Male 3 through 12 U.S. Coast Guard (162.038/7/0)

Regular RL Type Brass 3/4 in. NPT Male 8 through 18 U.S. Coast Guard (162.038/7/0)

Regular Sealed Nozzle: 1/2 in. NPT Male 1 through 2.5 U.S. Coast Guard (162.038/7/0)

with Strainer Brass UL (EX-2968)

Strainer: FM Approved

Monel

Regular Sealed Brass 1/2 in. NPT Male 3 through 12 U.S. Coast Guard (162.038/7/0)

Regular Sealed with Nozzle: 1/2 in. NPT Male 1 through 2.5 U.S. Coast Guard (162.038/7/0)

Flange and Strainer Brass UL (EX-2968)

Strainer: FM Approved

Monel Flange: Steel

Regular Sealed Nozzle: 1/2 in. NPT Male 3 through 12 U.S. Coast Guard (162.038/7/0)

with Flange Brass UL (EX-2968)

Flange: FM Approved

Steel

Regular RSFL Nozzle: 3/4 in. NPT Male 8 through 18 U.S. Coast Guard (162.038/7/0)

Sealed with Flange Brass UL (EX-2968)

Flange: FM Approved

Steel

(42)

426114

426115 Regular sealed nozzle 3 – 12

426116 Regular sealed with flange and strainer nozzle 1 – 2.5

426117 Regular sealed with flange nozzle 3 – 12

426118 Regular RSFL sealed with flange nozzle 8 – 18

426299 Regular sealed with flange and strainer nozzle (stainless steel) 1 – 2.5

426300 Regular sealed with flange nozzle (stainless steel) 3 – 12

NOTE: When ordering, specify orifice code required: Example – Part No. 426118 – 9.5.

Regular Type Nozzle – Brass Regular Nozzle – Type RL

29/32 IN. (2.3 cm)

7/16 IN. (1.1 cm)

1/2 IN. STANDARD PIPE THREAD 3/4 IN. STANDARD PIPE THREAD

7/8 IN. HEX

5/8 IN. (1.5 cm)

001836a 001836b 001837a 001837b

ORIFICE CODE NO.

STAMPED ON HEX ORIFICE CODE NO.

STAMPED ON HEX 1 IN.

(2.5 cm) 1 1/8 IN. HEX

Regular Type Sealed Nozzle With or Without Strainer

Regular Sealed Flanged Type Nozzle With or Without Strainer 7/16 IN. (1.1 cm) 1/2 IN. STANDARD PIPE THREAD 000666a 000666b 000667a 000667b FRANGIBLE SEALING DISC STRAINER ORIFICE CODE NO. STAMPED ON HEX 1 1/8 IN. (2.8 cm) 1 1/2 IN. (3.8 cm) 3/16 IN. MOUNTING HOLE 3 IN. (7.6 cm) 2 1/2 IN. (6.3 cm) 2 1/2 IN. (6.3 cm) 3 IN. (7.6 cm) SEAL 1 IN. CLEARANCE HOLE SELF-TAPPING SCREW 1 5/8 IN. (4.1 cm) 1/2 IN. NPT STRAINER

Regular Sealed Flanged Type Nozzle – Type RSFL 000668b 000668a 3 IN. (7.6 cm) 2 1/2 IN. (6.3 cm) 2 1/2 IN. (6.3 cm) 3 IN. (7.6 cm) 3/16 IN. MOUNTING HOLE 1 IN. CLEARANCE HOLE SELF-TAPPING SCREW 1 7/8 IN. (4.7 cm) 3/4 IN. NPT SEAL

(43)

Discharge Nozzle – Baffle Type

Description

The baffle type nozzle is used in total flood applications only. Placed around the outside edge or placed near the ceiling approximately 15 to 20 ft. (4.6 to 6.1 m) on centers in a room or any enclosed space, each nozzle provides a 180° fan spray of CO2, spreading the extinguishing gas quickly and efficiently throughout the protected

space. Discharge rate depends upon nozzle pressure and orifice size. Baffle type nozzles are available in orifice sizes 1 through 16.

This nozzle is supplied in natural brass with chrome or nick-el plating available as an option.

Baffle Type with Nozzle: 1/2 in. NPT Male 1 through 3 U.S. Coast Guard (162.038/7/0)

Strainer Brass UL (EX-2968)

Strainer FM Approved

Monel

Baffle Type Brass 1/2 in. NPT Male 3.5 through 14 U.S. Coast Guard (162.038/7/0)

Baffle Type BL Brass 3/4 in. NPT Male 9 through 16 U.S. Coast Guard (162.038/7/0)

1-19

426119 Baffle type with strainer nozzle 1 – 3

426120 Baffle type nozzle 3.5 – 14

426121 Baffle type BL nozzle 9 – 16

(44)

Baffle Type BL Nozzle

DISCHARGE ORIFICE

ORIFICE SIZE STAMPED ON THIS SURFACE 2 5/8 IN. (6.6 cm) 3/4 IN. NPT FORGED BRASS BODY STAMPED NOZZLE CODE 3 5/16 IN. (84 cm) DISCHARGE ORIFICE 1 3/4 IN. (4.4 cm) 000662a 000662b 000664a

000664b

3 1/4 IN. (8.2 cm)

2 1/4 IN. (5.7 cm)

(45)

Cylinder Bracketing

Description

The cylinder bracketing is designed to rigidly support the installed carbon dioxide cylinders. The bracketing compo-nents are constructed of heavy structual steel. Bracket assemblies are available in modules for two to six cylinders and can also be mated together for any combination over six. Bracketing can be assembled to support single row, double row or back-to-back rows of cylinders. Bracketing uprights and weigh rail supports are also available for weighing cylinders in place. Bracketing components are painted with a red enamel coating. Uprights and back frame assemblies can be bolted or welded together, which ever makes the installation more convenient. For weighing cylinders, a scale and lifting yoke is also available.

1-20

45120 50 lb. (22.7 kg) cylinder strap (single cylinder)

45244 50 lb. (22.7 kg) cylinder channel with nuts and bolts (single cylinder)

45121 75 lb. (34 kg) cylinder strap (single cylinder)

45261 75 lb. (34 kg) cylinder channel with nuts and bolts (single cylinder)

45122 100 lb. (45.4 kg) cylinder strap (single cylinder)

45245 100 lb. (45.4 kg) cylinder channel with nuts and bolts (single cylinder)

79638 Back frame assembly (2 cylinder)

73257 Upright (used either for right or left side)

73553 Single row or back-to-back row bracket foot (left side)

73554 Single row or back-to-back row bracket foot (right side)

73555 Double row bracket foot (left side)

73556 Double row bracket foot (right side)

73256 Center upright (required when weighing seven or more cylinders in a row)

79413 Connector (required to hook together back frames for seven or more cylinders)

73250 10 in. (25.4 cm) carriage bolt with nut (for single row 50 lb. (22.7 kg) cylinders)

73251 10.5 in (26.7 cm) carriage bolt with nut (for single row 75 lb. (34 kg) cylinders)

73252 12 in. (30.5 cm) carriage bolt with nut (for single row 100 lb. (45.4 kg) cylinders)

73253 20 in. (50.8 cm) carriage bolt with nut (for double row 50 lb. (22.7 kg) cylinders)

73254 20.5 in. (52.1 cm) carriage bolt with nut (for double row 75 lb. (34 kg) cylinders)

73255 25 in. (63.5 cm) carriage bolt with nut (for double row 100 lb. (45.4 kg) cylinders)

73266 Weigh rail (two cylinder)

73267 Weigh rail (three cylinder)

73268 Weigh rail (four cylinder)

73269 Weigh rail (five cylinder)

73270 Weigh rail (six cylinder)

73091 Cylinder clamp (2 cylinders)

73092 Cylinder clamp (3 cylinders

Bracketing Steel U.S. Coast Guard

(162.038/7/0) UL (EX-2968) FM Approved

(46)

71684 Weigh rail support (back-to-back)

74241 Scale

69877 Lifting yoke

LEFT BRACKET FOOT

RIGHT BRACKET FOOT BACK FRAME UPRIGHT WEIGH RAIL SUPPORT WEIGH RAIL CARRIAGE BOLT WITH NUT CYLINDER CLAMP 0001838

(47)

Nameplate – MAIN

Description

The ‘‘MAIN’’ nameplate is available for labeling compo-nents and/or remote pull stations to distinguish them from reserve system components. The nameplate is furnished with four mounting holes for ease of installation.

Component Material Mounting Hole Size Approvals

Nameplate Aluminum 13/64 in. (.52 cm) U.S. Coast Guard (162.038/7/0)

41942 Nameplate – MAIN

1-21

ANSUL INCORPORATED, ONE STANTON STREET, MARINETTE, WI 54143-2542 715-735-7411 Form No. F-90191 ©1997 Ansul Incorporated Litho in U.S.A. 1 7/8 IN. (4.7 cm) 4 – 13/64 IN. (.5 cm) DIAMETER HOLES 5/16 IN. (.8 cm) 2 1/2 IN. (6.4 cm) 5 1/2 IN. (13.9 cm) 4 7/8 IN. (12.4 cm)

MAIN

000723 PART NO. 41942

(48)

Nameplate – RESERVE

Description

The “RESERVE’’ nameplate is available for labeling com-ponents and/or remote pull stations to distinguish them from main system components. The nameplate is fur-nished with four mounting holes for ease of installation.

41943 Nameplate – RESERVE 1 7/8 IN. (4.8 cm) 4 – 13/64 IN. (.52 cm) DIAMETER HOLES 5/16 IN. (.8 cm) 2 1/2 IN. (6.4 cm) 5 1/2 IN. (13.9 cm) 4 7/8 IN. (12.4 cm)

RESERVE

000723 PART NO. 41943

(49)

Nameplate – Maintenance

Description

The maintenance nameplate is available for mounting near the system cylinders. This plate gives instructions for performing the semi-annual cylinder weighing require-ments. The nameplate is furnished with four mounting holes for ease of installation.

70449 Nameplate – maintenance

1-23

(12.4 cm)

ANSUL FIRE PROTECTION ONE STANTON STREET MARINETTE, WI 54143-2542 715-735-7411 ANSUL® Part No. 70449 3/16 IN. (.5 cm) 4 1/2 IN. (11.4 cm) 5 3/4 IN. (14.6 cm) 5 3/8 IN. (13.7 cm)

ANSUL CARBON DIOXIDE FIRE

SUPPRESSION SYSTEM

MAINTENANCE INSTRUCTIONS

WEIGH CYLINDERS EVERY SIX MONTHS AND RECORD ON CYLINDER RECORD TAG. IF WEIGHT OF CYLINDER IS

LBS. ( kg) LESS THAN FULL WEIGHT STAMPED ON THE BODY OF CYLINDER VALVE OR ON NECK OF CYLINDER, RECHARGE. WHEN SHIPPING CYLINDER, BE SURE THAT OUTLET PLUG IS SCREWED INTO TOP OF CYLINDER VALVE AND SHIPPING CAP IS SCREWED ON TOP OF CYLINDER. BEFORE WEIGHING CYLINDERS, REMOVE RELEASE ATTACHMENTS FROM THE CONTROL CYLINDERS AND DISCONNECT THE FLEXIBLE DISCHARGE BEND FROM ALL CYLINDERS BEING WEIGHED. BE SURE THAT RELEASE ATTACHMENT IS IN SET POSITION WHEN REPLACING VALVE.

CARBON DIOXIDE GAS HMIS 1-0-0/VERY COLD DISCHARGE. CONTENTS UNDER HIGH PRESSURE.

FOR DETAILS SEE INSTRUCTION BOOK.

®

LISTED 295S

000725

(50)

Warning Plate – Outside Room Without Alarm

Description

The warning plate is available for mounting outside the hazard area to warn personnel that the space is protected by a carbon dioxide system and no one should enter after a discharge without being properly protected. The warn-ing plate is furnished with four mountwarn-ing holes for ease of installation.

Warning Plate Stainless 7/32 in. (.56 cm) U.S. Coast Guard (162.038/7/0)

Steel UL (EX-2968)

FM Approved

41905 Warning plate – outside room

without alarm 5 IN. (12.7 cm) Part No. 41905 1/4 IN. (.63 cm) 4 1/2 IN. (11.4 cm) 8 IN. (20.3 cm) 7 1/2 IN. (19 cm)

WARNING

THIS SPACE IS PROTECTED BY A

CARBON DIOXIDE FIRE SUPPRESSION

SYSTEM. WHEN SYSTEM IS

DISCHARGED, DO NOT ENTER WITHOUT

APPROVED SELF-CONTAINED

BREATHING APPARATUS OR UNTIL

VENTILATION HAS BEEN OPERATED FOR

AT LEAST 15 MINUTES.

000724

(51)

Pressure Bleeder Plug – 1/4 in.

Description

The pressure bleeder plug can be used to relieve the pressure in closed actuation lines. The plug relieves the pressure through a small 1/64 in. (0.4 mm) orifice. This slow relief of pressure does not affect the function of the actuation line.

Bleeder Plug Brass 1/4 in. NPT Male UL (EX-2968)

FM Approved

42175 Pressure bleeder plug

1-25

1/4 IN. NPT

001839b

(52)

Warning Plate – Outside Room With Alarm

Description

The warning plate is available for mounting outside the hazard area to warn personnel not to enter the room when the alarm is sounding. The warning plate is fur-nished with four mounting holes for ease of installation. The plate is constructed of BAKELITE engraving stock with a red finish.

ANSUL is a registered trademark and BAKELITE is a trademark of Union Carbide Corp.

Warning Plate BAKELITE 7/32 in. (.56 cm) U.S. Coast Guard (162.038/7/0)

Molded UL (EX-2968)

Plastic FM Approved

41927 Warning plate – outside room

with alarm 5 IN. (12.7 cm) Part No. 41927 8 IN. (2 cm)

WARNING

DO NOT ENTER ROOM

WHEN ALARM SOUNDS.

CARBON DIOXIDE

BEING RELEASED.

(53)

Warning Plate – Inside Room With Alarm

Description

The warning plate is available for mounting inside the hazard area to warn the personnel to vacate the hazard area when the alarm sounds. The warning plate is fur-nished with four mounting holes for ease of installation. The plate is constructed of BAKELITE engraving stock with a red finish.

ANSUL is a registered trademark and BAKELITE is a trademark of Union Carbide Corp.

Warning Plate BAKELITE 1/4 in. (.64 cm) U.S. Coast Guard (162.038/7/0)

Molded UL (EX-2968)

Plastic FM Approved

41925 Warning plate – inside room

with alarm

1-27

ANSUL INCORPORATED, ONE STANTON STREET, MARINETTE, WI 54143-2542 715-735-7411 Form No. F-90192 ©1997 Ansul Incorporated Litho in U.S.A. 5 IN. (12.7 cm) Part No. 41925 1/4 IN. (.63 cm) 4 1/2 IN. (11.4 cm) 15 1/2 IN. (39.3 cm) 15 IN. (38.1 cm)

WHEN ALARM SOUNDS

VACATE AT ONCE

CARBON DIOXIDE BEING

RELEASED

(54)

Connecting Link

Description

The connecting link is used to connect the lever releases located on the pilot cylinders together. When cable or manual actuation is required, all cylinders will actuate simultaneously. The connecting link can be used on CV90, MAX, or AP-8 Ansul carbon dioxide valves.

One size connecting link is available for all size cylinders.

Connecting Link Steel U.S. Coast Guard

(162.038/7/0) UL (EX-2968)

42514 Connecting link PIVOT PIN 14 1/4 IN. (36.2 cm) 3/4 IN. (19 mm) 15/16 IN. (24 mm) FLEXLOCK HEX NUT

000661a

000661c

(55)

Lever Release Actuator AP-8 Valve/Selector Valve

Description

Lever Release Actuator: The manual lever release

actua-tor can provide a manual means of agent cylinder actuation by direct manual actuation of its pull lever or cable actua-tion when used in conjuncactua-tion with a remote manual pull station.

In three or more cylinder systems, a connecting link is required to provide simultaneous actuation of both lever release actuators.

Manual actuation is accomplished by pulling the valve hand lever. The lever design contains a forged mechanical detent which secures the lever in the open position when actuated. Cable pull actuation is accomplished by using a remote manual pull station. The remote manual pull station

system must provide the components necessary to meet the actuator lever traveling requirements of 7 in. (17.8 cm). Manual actuation for electric or pneumatic selector valves can be accomplished using these lever actuators.

Lever Release Brass U.S. Coast Guard

Actuator With (162.038/7/0)

Stainless UL (EX-2968) Steel FM Approved Stem

42484 Lever release actuator (with handle and pin; for local control)

42485 Lever release actuator (with handle, no pin; for remote control)

42486 Lever release actuator (with no handle, no pin; for use with three or more cylinders)

1-29 3 7/8 IN. (9.8 cm) DEPTH: 3 IN. (7.6 cm) HANDLE PIN 3 7/8 IN. (9.8 cm) FOR USE ON AP-8/SELECTOR VALVES ONLY LABEL NO. 70476 000897 3 7/8 IN. (9.8 cm) DEPTH: 2 13/16 IN. (7.1 cm) HANDLE 3 7/8 IN. (9.8 cm) FOR USE ON AP-8/SELECTOR VALVES ONLY LABEL NO. 70476 001393b

(56)

3 7/8 IN. (9.8 cm) DEPTH: 1 13/16 IN. (4.6 cm)

001393b
