Localizing dynamic websites created from open source content management systems

(1)

www.loctimize.com Loctimize GmbH

Localizing dynamic websites

created from open source

content management systems

memoQfest 2012, May 10, 2012, Budapest

Daniel Zielinski Martin Beuster

(2)

2

Agenda

• Open source content management systems • The localization challenges

• General localization strategies • Conclusions

(3)

3

Open source content management systems

(4)

4

Challenges

Extract content Prepare content Translate content Integrate translated content Test localization Fix bugs Publish localized website Identify content Create / update content

(5)

5

Identify content - Database

• Most of the content is stored in databases • Databases are made up of related tables

• The tables are made up of rows and columns

• The fields contain the content in different formats (Text, HTML, XML, proprietary format) and

• Metadata used for identifying/filtering the relevant content

translate = 0 language = 2 published = 1

(6)

6

Identify content - Database

HTML content Text

(7)

7

Identify content - File system

• Template files (HTML, CSS, JPG, PNG, GIF)

• Configuration files (INI, PHP, PROPERTIES, TXT…)

• Localization files (XLIFF, XML, PHP…)

(8)

8

Identify content - Template files (HTML)

Translatable content?

(9)

9

Identify content - Configuration files – INI Files

• Some of the content is stored in INI files. • It is stored in key-value pairs.

(10)

10

Identify content - Configuration files – PHP Files

• Some of the content is stored in PHP files • It is stored in key-value pairs or arrays

(11)

11

Identify content - Localization files - XML

UI strings

IDs

Language groups

(12)

Extract content – Database

• Manually by copying  • Available extensions

– that understand the I18N/L10N logic of the CMS – that extract and export into a translatable

exchange format

• Develop scripts and exchange formats

– to extract and export the content into a translatable exchange format

(13)

• Joomla! Joom!Fish Plus, Jolomea (XML, XLIFF, PO)

• TYPO3 Localization Manager (XML)

• Drupal i18n, Translation Management, (XML, XLIFF)

• Wordpress Easy Translator Pro (PO) • Wordpress WPML (XLIFF)

(14)

14

Meta data

Page content

(15)

15

(16)

Extract content – Files

• Copy files

• Know the file structure of the CMS • FTP access

• Access to CMS backend with appropriate rights

(17)

17

Automate workflow?

• Use content connector and/or API to pass on the localisable content to memoQ.

(18)

Prepare files

• Defining non-translatable content

– Add additional tags – Defining filter settings

• XML filter • HTML filter

• RegEx text filter • Cascading filters • RegEx tagger

• Joining files

(19)

Translate content

• Lack of context

– Translation of content deltas (updates)

– Translation without visual information (XML, INI)

• Placeholders like %1, $2, {1}, $VAR, \n, \t

(20)

20

Translate content - HTML

• HTML files are added to memoQ using the standard filter.

• Tags and attributes can not be configured (localized hyperlinks).

(21)

21

Translate content - HTML

Preview

Lookup results Editor

(22)

Translate content – XML files

• Add the XML files to memoQ using a pre-defined XML filter (and a cascading HTML/RegEx text

filter).

• Content is grouped by page • Source URL in comments field

(23)

23

Translate content - XML

Preview

Lookup results Editor

(24)

24

Translate content – INI files

• Add the INI files to memoQ using a Regex text filter and a cascading HTML filter.

• The Regex text filter defines paragraphs as

(25)

25

Post-processing translated content – Convert to SQL

• Using a script the HTML files are converted to SQL files.

• The IDs extracted from the tags in the HTML are used to update the correct rows.

(26)

Integrate localised content

• Manually by copying & pasting  • Available extensions

– that understand the I18N/L10N logic of the CMS – that import the localized content

• Develop scripts

– to import the localized content

(27)

27

Importing localised content - Database

• Preview links with login information • Overwrite mode

(28)

Importing localised content - Database

• The translated SQL file is imported into the database.

• The table rows are updated with the translated content along with other settings.

– Original text – Modified date – Published flag – Hashed value

(29)

29

Importing localised content – INI files

• Translated INI files are exported from memoQ • These are stored in the appropriate folders on

(30)

Automate workflow?

• Watch export folders and use CMS API/script to import localized files

(31)

31

Test localised content

• Find the localised content in the website (frontend)

• Proof-read • Layout check

(32)

32

Fix localization bugs

• Find where content to be updated came from • Update content in CMS

• Update bilingual files and/or translation memory

• Modify stylesheets (CSS) • …

(33)

33

Publish localized page

(34)

34

Conclusion

• Complex processes

• Interaction of a lot of people • No standard procedures

• Need to develop processes and tools

• Risk of loosing/missing data when trying to mimic CMS core functionality

(35)

35

Conclusion

Translation Service Provider

• Time consuming

• Scoping is a non trivial first step

• Expertise in CMS, web technology, databases • Develop tools

• Educate client and web developers

• Sponsor development!

Client

• Choose CMS wisely • I18N & L10N strategy • Expect additional costs

for localisation

engineering and/or development

• Time consuming!

(36)

Localizing dynamic websites created from open source content management systems
