STRUCTURED QUESTION
ANSWERS
FORM 4 CHAPTER 2 THE STRUCTURE OF THE ATOM & CHAPTER 3 CHEMICAL FORMULAE AND EQUATION ANSWER
1 SPM 2003/P2/Q1
(a) It is a formula which shows the simplest ratio of atoms of the elements present
in a compound.
b(i) Mass of magnesium = (26.4 – 24.0)g = 2.4g
Mass of oxygen = (28.0 – 26.4)g = 1.6g
(ii) Number of moles of magnesium atom = 2.4/24
= 0.1 Number of moles of oxygen atom = 1.6 / 16 = 0.1
0.1 mole of magnesium atom combine with 0.1 mole of oxygen atom.
Therefore 1 mole of magnesium atom combines with 1 mole of oxygen atom.
(iii) Empirical formula of magnesium oxide is MgO
(iv) 2Mg + O2 2MgO
(c) To allow oxygen to enter into the crucible. This is to make sure that all magnesium reacts completely with oxygen.
d(i)
(ii) 1. collect some gas into the test tube
2.
place a burning splint near the mouth of the test tube3. no ‘pop sound
2 SPM 2004/ P2/Q1
a(i) Iodine / naphthalene
(ii) Copper
(iii) Solid
(iv) Copper
(v)
dry hydrogen gas
metal X oxide
combustion excess
hydrogen gas
3 SPM 2006/ P2/Q2
ai) H2O
ii) Isotope Carbon-12
bi) Number of mole = 6.0 dm3 / 24 dm3 = 0.25 mol
Mass = 11g
(ii) 0.25 x 6.02 x 1023 = 1.505 x 1023
(iii) 6.0 dm3 of carbon dioxide with the mass of 11g contains of 1.505 x 1023
molecules.
4 SPM 2007/ P2/ Q3
(a) It is a formula which shows the simplest ratio of atoms of the elements present
in a compound.
(b) = number of moles of atom
c(i) Method I
(ii) Magnesium is an active element which burns completely in air.
(iii) To allow oxygen to flow into the crucible. This is to make sure that all magnesium combines completely with oxygen.
d(i) Mass of lead = (113.68 – 64.00 )g
= 49.68g
(ii) Number of moles of lead = 49.68 / 207
= 0.24 mole
(iii) Mass of oxygen = (117. 52 – 113.68)g
= 3.84g
(iv) Number of moles of oxygen = 3.84 / 16
= 0.24 mole
(v) PbO
5 SPM 2007/ P2/ Q5
(a) 11
(bi) In Group 1 and Period 3
b(ii) Contains 1 valence electron and 3 shells filled with electron
c(i) Nucleus attractions towards valence electron in atom X is stronger ,so valence
electron in X is difficult to be released or
Nucleus attraction towards valence electron in atom Y is weaker so valence electron in Y is easier to be released.
c(ii)
Oxygen gas
Substance X / Y
d(i) 2.3/23 = 0.1
d(ii) 4 mol of X 2 mol of X2O
0.1 mol of X 0.05 mol of X2O Mass of X2O = 0.05 x 62g = 3.1g 6 SPM 2008/ P2/ Q3 a(i) Diffusion (ii) Molecule
(iii) The particles are made up of tiny or discrete particles. They are randomly
moving. The particles fill the space between the air particles (iv) Less than 10 minutes
b(i) 0.5 x 32g = 16.0g
(ii) 0.5 x 24 dm3 = 12 dm3
(iii) The number of gas molecules in balloon A and in balloon B is the same
because the number of moles is the same
7 SPM 2004/P3/Q1
(a) Observation Inference
(i) white fumes released
(ii) the mass of crucible and its contents increases
(i) magnesium oxide is formed (ii) magnesium reacts with oxygen
(b) Mass of crucible and lid = 25.35g
Mass of crucible, lid and magnesium ribbon = 27.75g
Mass of crucible, lid and magnesium oxide when cooled = 29.35g
c(i) Mass of Mg = (27.75 – 25.35)g = 2.4g
8 SPM 2005/P3/Q1
(a) Time/ s 0 30 60 90 120 150 180 210
Temperature/°C 95.0 85.0 82.0 80.0 80.0 80.0 78.0 70.0
(b)
c(i) 80°C
(ii) There is no temperature change during the cooling process
(d) The heat released during the formation of bonds balances the heat loss to the
surroundings (e)
(f) Covalent compound Glucose, ethanol, tetrachloromethane
Ionic compound Potassium iodide, copper (II) sulphate,
CHAPTER 4 : PERIODIC TABLE OF THE ELEMENTS 1 SPM 2003/P2/Q2
a) Iron/Ferum
b)
c) 1. Formed compound with different oxidation numbers
2. Formed colored ions or compound 3. Formed complex ions
4. As a catalyst
d) 2.8.2
e) i) 4Al + 3O2 2 Al2O3
ii) Aluminium atom releases 3 electrons to form aluminium ion, (Al3+).
Oxygen atom receive 2 electrons to form oxide ion, (O2-). Two aluminium
atoms release a total of 6 electrons while 3 oxygen atoms receive 2 electrons each. The strong electrostatic force between Al3+ and O2- form aluminium oxide
compound (Al2O3)
f) Helium gas because helium is inert gas
2 SPM 2005/P2/Q1 a) i) Y ii) R iii) X b) R, Q, Y, X and T c) 2.4 d) Y
-e) Both Q and R have the same number of electron shells filled with electrons
f) Red litmus paper turns blue
g) Transition elements
3 SPM 2007/P2/Q5
a) 11
b) i) Period 3, Group 1
ii) The electron arrangement is 2.8.1. X has three electron shells and one
valence electron.
c) i) The size of atom Y is larger than the size of atom X. The distance between
the valence electron and nucleus increases. The force of attraction is
smaller. It is easier for Y to release its valence electron. ii)
+
-d) i) Number of moles of element X
= 2.3/23 = 0.1
ii) Relative molecular mass of X2O
= 46 + 16 = 62 4 moles of X 2 moles of X2O 0.1 mole of X 0.05 mole of X2O Maximum mass of X2O = 0.05 x 62 = 3.1 g 4 SPM 2008/P2/Q2 a) Group 17 b) 2.7
c) The outermost occupied shell of a fluorine atom is nearer to the nucleus. The
strength of the fluorine nucleus to attract electrons is higher. Fluorine atom can accept electron easily to form negative ions.
d) Covalent bond e) i) Ionic bond ii) f) Chemicals KI (aq) + Cl2(aq) / KCl (aq) + Br2(aq) KBr (aq) + KCl (aq)
Na
+Cl
-CHAPTER 5 : CHEMICAL BOND 1 SPM 2006/P2/Q3
a) i) Because argon has 8 valence electron.
ii) Neon (Group 18 elements)
b) i) Sodium ion : Sodium atom donates one electron
(Na Na+ + e)
Chloride ion : Chlorine atom receives one electron from the sodium atom. (Cl + e Cl-)
ii) Electrostatic force
iii) The ions can move freely now
iv) Energy or heat is used to break the ionic bond in sodium chloride
c) Q1
SPM 2007/P2/Q4
a) i) Structure : Molecule
Bonding : Covalent
ii) The molecules in P are held together by weak intermolecular forces. A small
amount of heat energy is needed to overcome the weak intermolecular forces.
b) i) Substance Q : By sharing of electrons
ii) Substance R : By transfer of electrons
c) Solid state :
The negative and positive ions are in fixed positions and they cannot move freely. Molten and aqueous state :
The negative and positive ions can move freely. This enables them to conduct electricity.
d) Substance R is soluble in water
F4 Chapter 6 Electrochemistry F5 Chapter 3 Oxidation & Reduction 1 SPM 2003/P2/Q5
(a) (i) Brown solid is formed.
Blue solution turns colourless.
(ii) Green solution turns brown.
Brown colour of bromine decolorizes. (b) Mg + Cu2+ → Mg2+ + Cu
(c) A substance that receives electron.
(d) (i) 0 → +2
(ii) copper(II) ion // copper(II) sulphate
(e) (i) redox
(ii) 0
(iii) oxidising agent
(iv) chlorine water
2 SPM 2004/P2/Q3
(a) (i) A positively charged ion.
(ii) Electrical → Chemical
(b) (i) Cu2+, SO
42-, H+ , OH
-(ii) In the table below, write the ions in (b)(i) which moved to electrodes X and Y. Electrode X Electrode Y SO4 OH Cu2+ H+ (iii) Electrode X : Oxidation Electrode Y : Reduction
(iv) Brown solid
(v) Blue to colorless. (c) (i) Oxygen (ii) 20___ = 0.0008 mol 24000 (iii) 0.0008 x 6.02 x 1023
3 SPM 2005/P2/Q6
(a) (i)
(ii) A burning splinter gives a ‘pop’ sound.
(iii) Na+ and H+ ions are attracted towards the cathode. H+ ions are selected to be
discharged as hydrogen gas.
(b) (i) MgO
(ii) 2Mg + O2 → 2MgO
(iii) Oxidation number for: Magnesium = +2 Oxygen = -2
4 SPM 2007/P2/Q6
(a) (i) water and oxygen
(ii)
(b) (i) Fe2+ and OH- ions combine to form iron(II) hydroxide.
Iron(II) hydroxide is oxidised to iron(III) hydroxide. Iron(III) hydroxide form hydrated iron(III) oxide/ rust.
(ii) +2 → +3
(c) (i) Zinc is more electropositive than iron.
Zinc atoms lose electrons more easily than iron. Zinc corrodes but iron does not.
5 SPM 2004/P3/Q2 (a) Metal Observations Zinc Magnesium Lead
Moderately bright flame Very bright flame Bright flame (b)
Name of variables Action to be taken
(i) Type of metal (i) Replace the metal with different
metals
(ii) Intensity of the flame (ii) Observe the intensity of the
flame
(iii) Quantity of metal (iii) Use a constant mass of metal
(c) The higher the metal in the reactivity series, the brighter the intensity of the flame.
(d) (i)
Descending order of reactivity of metal towards oxygen.
(ii) Mg, ↓ , Zn, Pb, Cu
(e)
Metals more reactive than carbon
Metals less reactive than carbon Magnesium Sodium Lead Copper 6 SPM 2005/P3/Q2
(a) The blue colour of copper (II) sulphate solution fades.
(b) Manipulated variable:
The metal as negative electrode
Method to manipulate the variable:
Replace the negative electrode with different metals.
Responding variable:
Voltmeter reading
How the variable is responding:
The voltmeter reading changes.
Controlled variable: Method to maintain the
Zn
Pb
Cu
FORM 4 CHAPTER ACIDS AND BASES FORM 4 CHAPTER 8 SALTS
2004/P2/Q5
1 (a) From pink to colourless or intensity of the pink colour decreases or the container of the
mixture becomes warm or hot
(b) (i) To ensure all the the acid react completely with copper(II) oxide
(ii) By filtering
(iii) CuO + H2SO4 CuSO4 + H2O or
CuO + 2H+ Cu2+ + H
2O
(iv) n(H2SO4) = 0.1 x 50/1000 Mass of Cu SO4 = 0.005 x 160
= 0.005 = 8.0 g
(c) 20.0 cm3 or twice the volume of sulphuric acid
(d)
Experiment I Experiment II
• needs filtering
• a mixture between two solutions
• need to add an indicator
• experiment is repeated without
using an indicator
• volume of sulphuric acid is added
accurately
• no need filtering
• a mixture between a solid and
solution
• no need to add an indicator
• no need to repeat the experiment
• solute or CuO is added in excess
2005/P2/Q4
2 (a) cation
(b) Cu2+ ions & SO
42- ions , H+ ions & OH- ions
(c) Na2SO4
(d) (i) Na2SO4 + Pb (NO3)2 2NaNO3 + PbSO4
(ii) I mol of lead(II) nitrate reacts with 1 mol of sodium nitrate to produce 1 mol of
lead(II) sulphate and 2 moles of sodium nitrate (iii) Lead(II) sulphate
(iv) Number of mole = 10/1000 x 0.5 = 0.005
(v) Mass = 0.005 x (207 + 32 + 16 x 4) or 0.005 x 303 = 1.515 g
2006/P2/Q4
3 (a) (i) Concentration – the quantity or amount of solute (grams) dissolves in a
given volume(1 dm3) of solution
(Ii) Molarity – the number of moles of solutes that are present in 1 dm3 of solution.
(iii) n = MV(cm3) /1000 or n = MV(dm3)
(iv) n = 8/40 = 0.2 mole , M = 0.2 x 1000/1000, M = 0.2 mol dm-3
(b) (i) Parameter I : mass / moles of NaOH
Parameter II : volume of solution or distilled water
(ii) No traces of sodium hydroxide is left on the filter funnel or beaker for accurate
concentration or amount of solute used is accurate and not less
(iii) Add distilled water drop by drop until the meniscus is at the calibration mark
(iv) Measures the volume accurately
(v) To prevent evaporation or evaporation of water can cause the changes in concentration or easy to swirl the solution
4 (a) Test Tube P Q R S T U V Volume of lead(II) nitrate
solution 1.0 mol dm-3/cm3 0.5 1.0 1.5 2.0 2.5 3.0 3.5
Height of lead(II) iodide precipitate /cm
1.1 2.2 3.4 4.4 5.5 5.5 5.5
Table 1
(The diagram given is not to scale - please refer to the original SPM question paper for accuracy of readings)
(b)
1.
label of the x-axis – volume(cm3)2. label of the y-axis – height of precipitate(cm) 3. uniform scale
4. size of graph more than 50% 5. all points are transferred correctly 6. smooth graph
(c) (i) Suggested answer:
Height of precipitate (cm)
Volume of lead(II) nitrate(cm3 )
(ii) No. of mole (Pb2+) = 2.5 X 1.0 = 0.0025
1000
No. of mole (I-) = 5 X 1.0 = 0.005
1000
No. of mole of I- reacted with 1 mol of Pb2+ = 2 mole
(iii) Pb2+ + 2I- → PbI 2
(d) The height of precipitate increases gradually from test tubes P to S
The height of precipitate in test tubes T,U,V are the same
(e) In test tubes P, Q, R, and S, more and more yellow precipitate of lead(II) iodide is
formed due to the increasing amount of lead(II) nitrate added to the test tubes or potassium iodide has not completely reacted with lead(II) nitrate solution
In test tubes T,U,and V, potassium iodide/iodide ions have reacted completely or a complete reaction has taken place
(f)
Solution Positive ions Negative ions
Lead(II) nitrate Pb2+ , H+ NO
3- ,OH
-Potassium iodide K+ , H+ I-, OH
-FORM 4 CHAPTER 9 MANUFACTURED SUBSTANCES IN INDUSTRY Minimum volume- must be written on the graph (2.5cm3)
Question 1 2003/P2/Q3
(a) Contact Process (b) Sulphur trioxide
(c) The reaction gives off a lot of heat. (or Large cloud of sulphuric acid formed) (d) H2S2O7 + H2O → 2H2SO4
(e) Substance Y: ammonia
Fertilizer Z : ammonium sulphate (f) 2SO2 + O2 + 2H2O → 2H2SO4 or
SO2 + H2O → H2SO3 Question 2 2006/P2/Q5
(a) N2 + 3H2 → 2NH3
(b) (i) Percentage of ammonia produced from factory Q is higher than factory P.
(ii) At a lower temperature, percentage of ammonia produced is higher.
(iii) The pipes might explode or break.
(iv) By using tanks or pipes that can withstand high pressure
(c) (i) Use as explosives or cold pack
(ii) NH3 + HNO3 → NH4NO3(s)
(iii)
Question 3 2007/P2/Q2
(a) X : Contact process
Y : Haber process
(b) 1. Sulphur
2. Air (or oxygen) 3. Water
(c) (i) H2SO4 + 2NH3 → (NH4)2SO4
(ii) Sulphuric acid: 1 mole
Ammonia : 2 moles
(d) Ammonium sulphate is use as fertilizer
Question 4 2008/P2/Q1
(a) Contact process
(b) Vanadium(V) oxide (or vanadium pentoxide)
(c) (i) Oleum
(ii) SO3 + H2SO4 → H2S2O7
(d) Waste gas dissolve in rain water and produces acid rain
(or waste gas react with water vapour in the air and produces acid rain.)
(e) (i) Ammonium sulphate (or potassium sulphate)
1. SPM 2006/P2/Q6 (a
)
Total surface area of reactant
(b )
(i) Carbon dioxide, CO2.
(ii) Because the changes in the volume of CO2 can be measured easily.
(c) 1. Concentration of hydrochloric acid. 2. Temperature of the reactants. 3. Mass of calcium carbonate. * any two
(d )
(i) Gradient of the curve of Experiment II is steeper than the gradient of the curve of
experiment I.
(ii) All the reactants have reacted completely within time x.
(iii) Both experiments produced the same amount of products. (e
)
The greater the total surface area the higher is the rate of reaction. (f)
- descending pattern of curve - best fit curve
2. SPM 2008/P2/Q5 (a
)
Change of quantity of reactant/product Time taken
(b )
(i) Draw the tangent at 120 s
Rate of reaction = (0.12- 0.18) cm3s-1
(ii) 0.267 cm3s-1
(c) Because the concentration of hydrochloric acid decreases (d
)
(i) Curve II : catalyst/ temperature
Curve III : concentration
(ii) Repeat the experiment as in set I
Reduce the concentration of hydrochloric acid The volume of hydrochloric acid remains unchanged
(iii) Because the number of mole of hydrochloric acid used is half of set I Concentration of dilute
hydrochloric acid
Time taken to collect a fixed quantity of product
3. SPM 2003/P3/Q1 (a ) t1 = 55.0 s t2 = 48.0 s t3 = 42.0 s t4 = 37.0 s t5 = 33.0 s (b
) Temperature/ oC Time/ s 1/time/ s-1 30 35 40 45 50 55.0 48.0 42.0 37.0 33.0 0.018 0.021 0.024 0.027 0.030 (c) (i) Graph :
- X and Y axes labeled and unit
- Correct scale, size more than 50%
- All points transferred correctly
- Smooth graph
(ii) Rate of reaction is directly proportional to the temperature (d
)
Time = 30.3 s (e
)
(i) Manipulated variable : temperature of sodium thiosulphate
Responding variable : time for the ‘X’ mark disappear from sight or rate of reaction Controlled variable : volume and concentration of acid
(ii) Heat the sodium thiosulphate solution with different temperature while the volume and
concentration of sodium thiosulphate and acid remains constant.
(f) The higher the temperature the higher the rate of reaction
(g )
The lower the temperature the lower the rate of food turns bad 3. SPM 2003/P3/Q1 (a ) t1 = 55.0 s t2 = 48.0 s t3 = 42.0 s t4 = 37.0 s t5 = 33.0 s (b
(c) (i) Graph :
- X and Y axes labeled and unit
- Correct scale, size more than 50%
- All points transferred correctly
- Smooth graph
(ii) Rate of reaction is directly proportional to the temperature (d
)
Time = 30.3 s (e
)
(i) Manipulated variable : temperature of sodium thiosulphate
Responding variable : time for the ‘X’ mark disappear from sight or rate of reaction Controlled variable : volume and concentration of acid
(ii) Heat the sodium thiosulphate solution with different temperature while the volume
and concentration of sodium thiosulphate and acid remains constant.
(f) The higher the temperature the higher the rate of reaction
(g )
The lower the temperature the lower the rate of food turns bad
FORM 5 CHAPTERR 2 CARBON COMPOUNDS Question 1 2003/P2/Q4
(a)
(b) Heat supplied is uniform (or prevents the solution from evaporating too fast)
(c) (i) Esterification
(ii) C2H5OH + CH3COOH → CH3COOC2H5 + H2O
(d) (i) Propyl ethanoate
(ii) [Note: Choose any one of the following answers]
1. Fruity smell 2. Colourless liquid 3. Low boiling point (volatile) 4. Insoluble in water (e) (i) C2H5OH → C2H4 + H2O
(ii) C2H5OH + 2[O] → CH3COOH + H2O
(f) Butane
Question 2 2004/P2/Q6
(a) (i) Hydrogenation
(ii) Vegetable oil changes from liquid to solid (or changes vegetable oil from unsaturated
fats to saturated fats or changes double bond in vegetable oil molecule to single bond)
(b) (i) Catalyst X : Nickel (or platinum)
Temperature : 100oC (or 200oC)
(ii)
1.
Presence of catalyst reduces the activation energy2.
At a high temperature, particles possess high kinetic energy and3.
hence effective collision increases and rate of reaction increases(iii)
(c) Palm oil (or coconut oil or corn oil or other named oil example) Question 3 2008/P2/Q4
(a) Ethanol
(b) CnH2n+1OH
(c) (i) Carbon dioxide
(ii) m = 3 , n = 2
(d) (i) Ethyl ethanoate
(ii)
(e) (i) [Choose any one of the following answers]
Porcelain chips or phosphoric acid or aluminium oxide (ii)
Question 4 2008/P3/Q1
(a) Acid coagulates latex while alkali does not coagulate latex.
(b) Set I: 5 minutes
Set II: 6 hours or 300 minutes (c)
(d) Set I: A white solid lump is formed. (or latex coagulated)
Set II: There is no visible change observed. (or latex does not coagulate) Set III: A white solid lump is formed. (or latex coagulated)
(e) Operational definition for the coagulation of latex is latex becomes solid when acid is
added or when exposed to air.
(f) (i) The manipulated variable : Ethanoic acid and ammonia solution
(ii) The responding variable : Latex coagulates or does not coagulate. (or time taken
for coagulation of latex)
(iii) The constant variable : Volume of latex, volume and concentration of acid and
ammonia solution. Temperature
(g) (i) Latex coagulates after excess hydrochloric acid is added. (or latex becomes solid
after excess hydrochloric acid is added.)
Set
Time taken / minute
I
5
(i) (i) Latex in Set I coagulates faster than the latex in Set III because the concentration
of H+ ions is higher in Set I. (ii)
CHAPTER 4 : THERMOCHEMISTRY
1. SPM 2003/P2/Q6
(a) Heat change when 1 mol of metal is displaced from its salt solution by a more electropositive metal.
(b) Initial temperature and highest temperature.
(c) 1. Stir the mixture.
2. Add the two solutions as quickly as possible. 3. Use polystyrene or plastic cup
(any one)
(d) (i) 1. Grey solid is deposited
2. Colourless solution turns blue
3. The thermometer reading rises or the container becomes hot or warm. (any one)
(ii) 1. Silver metal is produced
2. copper(II) ion is produced
3. exothermic reaction/ heat is released to the surroundings
(e) (i) = 0.5 x 100 = 0.05 mol
1000 (ii) = 0.05 x 105 kJ = 5250 J (iii) Ө = 5.25 x 1000 = 12.5 oC 100 x 4.2 (f)
Can coagulate latex
Cannot coagulate latex
Nitric acid
Methanoic acid
Potassium hydroxide
Sodium hydroxide
Energy Cu + Ag+ Cu2+ + Ag ∆H = -105 kJ mol-1(g)
1.
Mol of Ag+ = 1 x 100 = 0.1 mol1000
2.
Heat change, Ө = 0.1 x 10500 = 25 oC100 x 4.2
3.
Number of mol of Ag+ is double or concentration of silver nitrate is double.2. SPM 2004/P2/Q4 (a
)
To reduce the heat loss to the surroundings. (b
)
(i) Exothermic reaction
(ii) Total energy of products is less than total energy of reactants (c) Mix the solutions quickly and stir the reaction mixture.
(d )
(i) Number of moles Ag+ = 25 x 0.5
100
= 0.0125 mol
(ii) The heat change = mcө
= 50 x 4.2 x (31.5-29.0) = 525 J
(iii) 0.0125 mol of Ag+ ions that reacted with Cl- ions released 525 J
1 mol of Ag+ ions that reacted with Cl- ions released =
525
0.0125
J= 42000 J Heat of precipitation = -42 kJmol-1
(e )
Heat is released to surroundings. 3. SPM 2005/P2/Q3 (a ) Zn2+ + Cu (b ) (i) ∆H = 100 x 4.2 x 20 = 8400 J
(ii) Number of moles CuSO4 reacted = 0.5 x 100 = 0.05 mol
1000
Heat of displacement = ___ m cө_______ Number of moles
(c)
(d
)
1.
2.
Use a plastic / polystyrene cup add the zinc powder quickly.3.
stir the solution(any one) (e
)
The heat released when 1 mole of copper is displaced from its solution.
(f) Tin (Sn)
4. SPM 2005/P2/Q5 (a
)
The heat released when 1 mole of alcohol is completely burnt in excess oxygen. (b
)
(i)
1.
all points are transferred correctly2.
draw a straight line(ii) The greater the number of carbon dioxide molecules, more products are formed which
causes more heat to be released during the formation of bonds. (iii) Relative molecular mass of ethanol
= (12 x 2) + (1 x 6) + 16 = 46
Number of moles ethanol = 2.3 = 0.05 mol 46 Heat released = 0.05 x 1376 = 68.8 kJ = 68 800 J (c) (d ) - Ethanol
- The freezing point of ethanol is -117 oC, which is lower than -100 oC.
5. SPM 2006/P3/Q1 (a
)
Initial temperature of mixture : 28.0 oC
Highest temperature of mixture : 40.0 oC
Change in temperature : 12.0 oC
Energy
Zn2+ + Cu
Zn2+ + Cu ∆H = -168 kJ mol-1
(b
) Experiment Experiment I Experiment II
Initial temperature of mixture/ oC 28.0 T1 Highest l temperature of mixture/ oC 40.0 T2 Change in temperature/ oC 12.0 T 3
(c) Strong acid produces higher heat of neutralization than weak acid. (d
)
12.5 oC - 15.0 oC
(e )
To enable us to obtain the change in temperature for both experiments.
(f) Change in temperature = Highest temperature of mixture - Initial temperature of mixture
(g
) 1. A colourless mixture of solution is obtained.2. The vinegar smell of ethanoic acid disappears. 3. The polysterene cup becomes hot.
4. Thermometer reading is rises (h
)
1. The volumes of the acid and the alkali. 2. The concentrations of the acid and the alkali. 3. The type of cup used in the experiment.
(i) (i) The heat of neutralization is defined as the amount of heat released when 1 mole of
water is produced.
(ii) Experiment II uses a strong acid whereas Experiment I uses a weak acid.
(j)
Name of acid Type of acid
Ethanoic acid Weak acid
Hydrochloric acid Strong acid
Methanoic acid Weak acid
6. SPM 2007/P3/Q1 (a ) (i) Initial temperature (oC) Highest temperature (oC) Experiment I 28.0 36.0 Experiment II 29.0 25.0 Experiment III 27.0 32.0 Experiment IV 30.0 27.0
(iii) Exothermic reaction Endothermic reaction
Experiment I Experiment II
Experiment III Experiment IV
(b )
(i) 1. The mass of sodium hydroxide.
2. the volume of water in the cup. 3. The size of the polystyrene cup.
(ii) The reaction between sodium hydroxide and water is an exothermic reaction.
(c) (i) Temperature change = 4 oC
Reason 1 :
Heat energy is absorbed by the reactants from the surroundings. Reason 2 :
The energy of the products is more than the energy of the reactants.
(ii) The decrease in temperature shows that endothermic reaction happens where heat
energy is absorbed from the surroundings. (d ) 1. 37 oC 2. 32 oC 3. 30 oC (e )
(i) 1. Final temperature is lower than the initial temperature.
2. The temperature reading decreases. 3. Bubbles of gas are released.
(ii) Heat energy is absorbed when hydrochloric acid reacts with sodium hydrogen
carbonate to produce sodium chloride, carbon dioxide and water. (iii)
7. SPM 2008/P2/Q6 (a
)
Heat change when 1 mole of hydrogen ions reacts with 1 mole of hydroxide ions to form
1 mole of water. (b
)
Observation : the mixture becomes hot or temperature increase Volume of carbon
dioxide gas,/cm3
Explanation : the reaction is exothermic
(c) (i) No. of moles of NaOH = 100 x 2 = 0.2 mol
1000 Energy released = 0.2 x 57.3 = 11.46 kJ
(ii) Temperature change = 11.46 x 1000
200 x 4.2 = 13.6 oC
(d )
(e
)
1.
Ethanoic acid is a weak acid which partially ionize in water, nitric acid is strong acid that ionize completely in water. 2. energy is used to ionize/dissociate weak acid.CHAPTER 5 : CHEMICAL FOR CONSUMERS 1 SPM 2004/P2/Q2
a) i) Sodium hydroxide/potassium hydroxide
ii) To reduce the solubility of soap in water or to precipitate the soap formed.
b) Procedure of the experiment :
1.
Two beakers are filled with hard water2.
Soap is added to one beaker and detergent is added to another beaker3.
The socks are dipped into each of the beakers and wash by scrubbing oragitated
Observation :
Detergent in hard water Soap in hard water
1. Socks is clean easily 1. Socks still dirty
2. No formation of scum 2. Scum forms
3. The water turns dirty 3. Water is less dirty
Conclusion :
Detergent cleans stains more effectively compared to soap in hard water. Detergent can still performed its cleansing action and more effective than soap in hard water.
Energy
NaOH + HNO3
Na NO3 + H2O
2 SPM 2005/P2/Q2
a) Saponification
b) i) Ester
ii) COO
-c) Concentrated potassium hydroxide solution
d) i) Hydrophobic part or hydrocarbon part
ii) - Detergent ions reduce the surface tension of water - Hydrophilic dissolves in water
- Hydrophobic dissolves in grease
- Mechanical agitation or scrubbing helps pull the grease free
(Refer to Chemistry Text Book Pg 185) iii)
3 SPM 2006/P2/Q1
a) i)
ii) Stomach pain due to wind in stomach iii) Extract the juice from the rhizome and drink
b) i) X : Analgesics
Y : Antibiotics
Z : Psychotherapeutic medicine ii) Can cause bleeding in the stomach
iii) The bacteria becomes immune to medicine iv) Get rid of anxiety
4 SPM 2007/P2/Q1
a) i) Saponification
ii) Glycerol
iii) To reduce the solubility of soap in water or to precipitate the soap
b) i) J : Soap
K : Detergent
ii) The insoluble precipitate formed when soap react with magnesium and calcium ions (hard water)
iii) 1. Magnesium ion 2. Calcium ion iv) J is biodegradable
