LED LIGHTING SOLUTIONS Executive Overview

LED Evolution

Globally existing Installations are upgrading from Legacy Bulb Lamps to Solid State Green LED Lights and nearly all New Installations built since early 2010 are going directly to LED Lighting.

Many people ask why is this evolution only happening now – well the answer is simple – its primarily due to Global Environmental Pressures to Reduce Carbon Footprints and secondly because it’s only been since the start of 2010 that the development and production of High-Power White LED Lights have matured, and production volumes increased enough to lower the purchase costs to commercially acceptable levels.

Today MALAYSIA Is Ranked No. 30 out of 178 Global Countries Emitting 123.6 Million Metric Tons Of CO2 Every Year. As lighting consumes approximately 30% of the nations total Electricity, this means that 30% of our Carbon Footprint is coming from Legacy Bulb Lighting.

At Copenhagen our Malaysian Prime Minister committed to a REDUCTION of 40% of all our CO2 Emission by 2020. Upgrading to LED Lighting Solutions HALVES the CO2 Footprint >> REDUCING a whopping 15% off our national CO2 usage – leaving another 25% to be achieved from other sources.

Tomorrows LED Lighting Solutions Today

LED Market Growth

Be Part Of The LED Lighting Evolution

As illustrated below, starting from January 2010 McKinsey forecast the Global Growth of LED Light Solutions in terms of UNITS and VALUE shipped where by 2016 22% of all Lights installed will be LED amounting to 58% of the total Lighting VALUE and by 2020 46% of all lights installed will be LED amounting to 78% of the total lighting VALUE.

This global growth not only shows the MATURITY of LED Lighting but also

the rapid Retrofit programs that are projected to take place across the globe

over the next 10 years.

LED Technologies

Instant Start - No Flickering - No Humming - >50,000 Hours Life

Solid State Environment Friendly LED Light Source,

Long >50,000 Hr Life and High Lm/W Performance of LED’s from Epistar (Taiwan), Osram (Malaysia), Philips (USA), Bridgelux (USA) and Cree (USA),

>50,000 Hr High Quality Power Drivers from Meanwell (Taiwan),

NIGHT-TIME LED Light Efficiency is 20-100% BETTER than Gas Bulbs because of our SCOTOPIC Human Eye Night Vision.

LED LIGHTS

GAS LIGHTS

LED Light Classes

FOCUS LED Lights are selected for Reliability & Operational Life As illustrated below, LED Lights are split into four different CLASSES in terms of Purchase Cost, LED Efficiency, Power Driver, Operation Life and Period of Defect Warranty.

All LED Lights decay in brightness over time and when they have lost 30% of their Brightness (Light Maintenance of 70%) then its time to change them.

Whilst most Malaysian Light Shops sell the 25,000 Hour 1 Year Warranty

Products, FOCUS only supplies three Classes of LED Light Fittings that use NON

CHINA Brand LED’s with three ranges of Lm/W Efficiency to cover 50,000 /

65,000 / 100,000 Hours of LM70 Operation with 3 / 5 / 10 Years Factory Defect

Warranties.

LED & Driver Ranking

INDUSTRY LED and Power DRIVER Quality RANKINGS

As per LED Light CLASSES, FOCUS offers Low, Medium & High Power Fittings that use a variety of LED and Power DRIVER BRANDS according to the Lm/W Output and Quality requirements.

As per the following Quality RANKING Table its important to note that FOCUS uses EPISTAR LED’s and RUBYCON Power Drivers for Low Power LED Lights and BRIDGELUX LED’s and MEANWELL Power Drivers for High Power LED Lights.

NOTE that PHILIPS OEM all their Low Power Lights from Best-In-

Class China Manufactures with 1 YMDW and for their High Power

LED Lights they use their own LED’s combined with INVTRONICS

Power Drivers with 3 YMDW.

LED Lumen Maintenance

FOCUS LED Lights have SLOW Lm LOSS and LONG Life Cycles When designing a installation involving the retrofitting of legacy Gas Incandescent, Fluorescent, Metal Halide or High-Pressure Sodium Lights to LED Lights - its important to take into account the Lumen Maintenance Cycles of the respective Lights as graphed below.

Note that with a recommended REPLACEMENT of Light Fittings when they reach LM70 (Lost 30% of original light level) its important to choose the right Light Fitting for your environment.

These performance characteristics influence light level comparisons

(must compare new to new lights) and when calculating LM70

REPLACEMENT Costs and Return On Investment periods..

FOCUS LED Light Solutions

Bulbs

Flood Street Tubes

Garden Downs &

Panels Strips

High Bay

& Canopy

Our LED Light OEM’s

GS TUV (Europe & Asia)

UL (USA) CE

ISO

ETL ROHS

INTERNATIONAL QUALITY & SAFETY CERTIFICATIONS

Our LED Advantages

Major benefits in replacing inefficient legacy Gas Tube Lights with Solid State LED Lighting Solutions include:

REDUCE CO2 Emissions by 52 -92%,

REDUCE ELECTRICITY Consumption by 52-92%,

REDUCE MAINTENANCE Costs by 80-97 % over 10+ Years,

PROVIDE FACTORY PRODUCT DEFECT WARRANTY PLANS from 3-5 Years for our Indoor and Power Light Series and 5-10 Years for our Street Light Series,

PROVIDE RETURN ON INVESTMENT (ROI) between 0.1 to 7 Years of operation,

PROVIDE NATURAL Full Spectrum Lighting with HIGH UNIFORMITY and IMPROVED SAFETY & SECURITY.

Environmentally GREEN

with no UV, IR, Lead or Mercury

Our Design Services

Professional DIALUX LED Lighting DESIGN Services

FOCUS has access to all Manufacturers and individual Light IES Files that enable us to offer Professional DIALUX Design Services to all our valuable Resellers and Customers.

An example of our expertise is the following Design of LED Flood Lighting solution for a International Soccer Field.

So no matter whether you are RETROFITTING existing GAS Light

Fittings or installing new LED Light fittings, FOCUS can provide the

necessary experienced consulting DESIGN services to generate the

required LUX Level DIALUX Reports and Return On Investment

Analysis to support your business case/s.

Our LED References

MEX Highway Malaysia

MRRII Highway

Malaysia

Our LED References

Tabung Haji

AIROD Hangers Sunway

Monash University

ARAN International

Our LED References

Sunway

Pedestrian Walkway Sunway

Entry Arch

Sunway

Pyramid Hotel

Masjid Jamek Petaling Jaya

Our LED References

DESIGN

Professional DiaLUX LED Lighting Design Services

QUALITY

ISO Manufacturing Standards

SAVINGS

Highest Electricity Savings & Fastest ROI

WARRANTY

Factory Defect Warranty Plans From 3 to 5 Years

TECHNOLOGY

Advanced 4

Generation LED Lighting Technologies With Many World Firsts

MALAYSIAN COMPLIANCE

TUV Certified LED Street Lighting Complies With Malaysian SIRIM & JKR Standards

Why Choose Us

TOMORROWS LED LIGHTING

SOLUTIONS TODAY

Contact Us Now
