HIGH FREQUENCY RECTIFIERS 24 & 48 VDC

(1)

HIGH FREQUENCY

RECTIFIERS

(2)

RECTICUR S.L. C/. Verano, 42 – POL. IND. “LAS MONJAS” – TORREJON DE ARDOZ – 28850 MADRID - ESPAÑA Teléfono: +34 916 770 065 – Fax: +34 916 770 551 – E-mail: [email protected]

NIF: B-80486236 Registro Mercantil de Madrid Tomo 5424, Libro 0, Folio 209, Sección 8, Hoja M-88807, Inscripción 1ª

RAF TELCOM

&

RAF IND

&

AF-N

&

AFC-N

System based on

norm

RAF Telcom rectifiers gather the highest technology to secure telecommunication services with any scale against fluctuations and interruptions of the grid. The efficiencies reached by the RAF Telcom are leaders in the market, achieving values up to 96%.

The RAF Telcom integrates the powerful control by microprocessor Orion, which allows it to have a great versatility. The redundancy supervision allows an easy monitoring of the

system availability, and the battery

management system allows it to surveil its status at any moment.

Via the Orion you will be able to integrate the rectifiers in any SNMP or Modbus monitoring system. The parameters visualization and rectifier configuration is very easy, both via the LCD display and the web server included. Thanks to this system we will be able to design the RAF Telcom according to any specification.

Our system’s reliability is verified based on the operation of supplied units for multiple reference projects and customers . These are

some that already know the RAF Telcom

advantages

HIGHLIGHTED FEATURES

 Very high efficiency

 Very high power density

 Control by microprocessor

 Versatility and easy monitoring

 Reliability and easy maintenance

 Redundancy N+X

(3)

SPECIFICATIONS

Nominal input voltage Single phase 230 Vac Three phase 400 Vac

Input voltage range

_{88 ~ 300 Vac}

Nominal output

voltage

24/48 Vdc

Nominal output current According to requirements

Float charge voltage Configurable b/w 42 ~ 58 Vcc

Equalization charge

voltage Configurable b/w _{42 ~ 58 Vcc} Deep charge voltage Configurable b/w

42 ~ 58 Vcc

Battery current limit According to the battery Ripple

_{≤ 100 mVpp}

ENVIRONMENT

Working temperature

_{-25~+75 °C}

Relative humidity 95% non-condensing Working altitude 2800 m @ 100% power

PROTECTIONS

Overvoltage Electronical Shortcircuit Electronical Input 1+N MCB for each

rectifier module

Battery Fuse/MCB Output Fuse/MCB

UPS based on

norm (DC & AC

output)

(4)

ACCESORIES

DES Input and/or output arrester for protection against atmospheric surges

LVD Low voltage battery disconection to avoid battery overdischarge

RC Heating resistor

ST Temperature probe for battery charge voltage compensation SNE Electrolyte level probe

DD Decoupling diode to allow connection in parallel with other systems

DRT Voltage reduction diodes

CD Output MCB distribution panel

AUX Auxiliary contactors for MCB open/trip signalling

DT Ground fault detection

In Recticur we are characterized by designing

systems tailored to any technical specification. Do not hesítate to ask the system’s customization possibilities.

SIGNALLING

STATUS

Float/exceptional charge Digital display Mains fault

Rectifier module fault Overload Discharging battery Minimum battery capacity Maximum/mínimum output voltage Maximum/mínimum battery voltage Battery overtemperature (optional)

Optionally analogical or digital measurement devices can be included to monitor multiple parameters.

(5)

The Orion control unit provides 5 completely configurable LED. Optionally additional LED can be added to complete the local signalling based on your needs. Do not hesitate to require alarms different than the ones listed below:

ALARMS

LED Remote contact Urgent alarm std. std. Non-urgent alarm std. std.

Mains input OK std. opt.

Rectifier failure opt. opt.

Mains input failure opt. std.

High output voltage opt. opt.

Low output voltage opt. opt.

Ground fault + opt. opt.

Ground fault - opt. opt.

Low voltage disconnection opt. opt. Battery/output fuse open opt. opt.

Input MCB open opt. opt.

Battery/output MCB open opt. opt.

Discharging battery opt. opt.

End of autonomy opt. opt.

CONTROL FEATURES

 Integrated PLC dedicated to DC systems

control with versatile configurations  Digital control bus system

 Remote monitoring via LAN network  Improvement of the battery management  Integrated web server

 Communication via SNMP agent  Optional fibre optic communications  Advanced monitoring and control system  Charge method control (float, exceptional

and deep charge)

 Battery temperature compensation according to external temperature  Battery current limitation  Advanced battery capacity test  Control of low battery voltage

disconection to avoid overdischarge

 Very simple user interface

 Peripheral LCD display located on the front door

(6)

MECHANICAL FEATURES

Type Floor-mounted /portable/compact/

19’’ subrack… Height [mm]

approximate Several options

Width [mm]

Depth [mm]

Shelves Fixed, extendables or _{external battery rack} Weight [kg]

approximate According to power

Color Any RAL

Protection

degree Any IP

CABINET CUSTOMIZATIONS

IP[X] Protection degree IP[X]

Z[x] Seismic reinforcement for zone X

RUE Portable cabinet with wheels

Recticur

’s philosophy of manufacturing tailored systems allows to offer multiple mechanical formats. These are some of the formats that we have built so far. If you do not find what you are looking for yet, do not hesitate to make your proposal.

RAF Telcom 19’’

In

Recticur

we know that on multiple occasions the economical resources are limited. That’s why we offer the

RAF Telcom

in rack format, with all the usual accesories integrated on the subrack itself: MCB, LVD, remote alarms…

With the

RAF Telcom

19’

’ you will be able to update old systems, keeping the existing cabinet and other elements. It is also an option when the project demands to integrate the rectifier in an existing rack along with other devices of an entire system.

RAF Telcom 19’’ based on norm

AF-N

&

AFC-N

There are occasions when the available space is reduced and it is necessary to make the most of it. The high power density of our rectifier modules allow us to design the

AF-N

and

AFC-N

models, which provide large powers in a minimum space.

(7)

NIF: B-80486236 Registro Mercantil de Madrid Tomo 5424, Libro 0, Folio 209, Sección 8, Hoja M-88807, Inscripción 1ª With this compact format you can include the

rectifier modules along with small batteries, external protections, remote alarms and other accesories

AFC-N based on norm, with 850W N+1 or

1700W.

AFC-N based on norm, with 1600W N+1 or

3200W.

RAF Telcom PORTABLE

Throughout our career our customers have transmitted us the need to have portable systems, at the technician’s disposal, to carry out maintenance duties or being able to take them urgently to facilites in an emergency situation.

In

Recticur

we have developed several formats easy to carry by only one or two persons and inside a van.

Suitcase version

(8)

RAF Telcom/Ind SPECIALS

Several applications require specialized specifications. If this is the case we will study it and we will be able to offer the specific solution for your field.

RAF Telcom for helicopters startup

RAF Telcom NORMALIZED

These are some of the normalized systems that

Recticur

has currently in its portfolio:

System based on norm

(9)

LEAD BATTERIES

Lead standard  Lead-acid sealed batteries

 VRLA (valve regulated lead-acid batteries)  AGM (Absorbed glass mat)

 Container material resistant to impacts Front access lead standard  Lead-acid sealed AGM VRLA batteries

 12+ years design life at 25ºC with plates resistant to rust.

 Front access terminals for easier installation and higher safety during manipulation. Lead gel

 Longer design life 12 years at 25ºC temperature

 Uniform distribution of the electrolyte by the use of great quality silica. Lead acid open

 15 or 20 years design life at 20ºC

 Low water consumption, water refill interval largely extended  Low self discharge

 Quick and easy acid refill and level checking. Lead acid sealed

 15 or 18 years design life at 20ºC

 Electrolyte in gel form: maintenance free and optional horizontal operation  Tubular plate: long life in cyclic operation (1200 cycles)

 Low self discharge Pure lead

 Pure lead grid in positive and negative plates  15 years design life at stablished conditions  High Energy density

 Up to two years for storage

 Wide temperatura range: -40~50 ºC

 Container resistant to impacts and flame arrestor according to UL94 V-0  Leak resistant terminals by means of double sealing

Lead Planté plate

 Planté plate: excellent behavior with high currents

 Pure lead technology and low electrolyte density to provide a large design life: up to 25 years.

 Terminals insesitive to corrosión and protected agains short circuits, even during installation

 Optional AquaGen to extend largely the water refilling interval; practically maintenance free.

(10)

Thanks to the fact that the

RAF Telcom

allows to carry out deep charges, it can work both with lead and nickel cadmium batteries, in all their forms.

NICKEL-CADMIUM BATTERIES

Nickel-Cadmium pocket plate

 Pocket plate technology for low, medium and quick discharge.  Non-existing risk of sudden death

 20 years of estimated life  Insensitive to deep discharges

 Polypropylene recipient, traslucent to allow checking the electrolyte level and facilitate the maintenance operation

 Recipient welded by termical sealing with high mechanical and electrical resistance  IEC 60623 compliant

Nickel-Cadmium low maintenance

 Pocket plate technology for low, medium and quick discharge.  Non-existing risk of sudden death

 20 years of estimated life  Gas recombination technology

 Only one water refill throughout its life, and deep charge not necessary

 Half of the charge current with respect to the NiCd conventional batteries

 Insensitive to deep discharges

 Polypropylene recipient, traslucent to allow checking the electrolyte level and facilitate the maintenance operation

 Recipient welded by termical sealing with high mechanical and electrical resistance  IEC 60623 compliant

Nickel-Cadmium fibre plate

 Fibre plate and gas recombination technology  Minimum water refill interval: 20 years

 Large electrolyte reserve for protection against drying in case of rectifier failure  Insensitive to terminals deterioration

 Extended temperatura range: -50~60 ºC

 Translucent polyproline recipient with optional flame arrestor according to UL94 V0 norm

In

Recticur

we have a wide experience on stationary batteries and can adapt the rectifier to the battery technology that each application requires. We just need that you indicate us what power and autonomy you require and we will offer you the battery that best suits your application.

(11)

ESPECIFICACIONES TÉCNICAS

Rectifier modules DPR850-48 DPR1600-48 DPR2900-48 DPR3500-24 DPR4000-48 INPUT Mains voltage _{80~300 V}_rms _{88 ~ 310 V}_rms _{80~300 V}_rms Mains frequency _{50/60 Hz} Harmonic distortion THD _5%

EMI (conducted) _{EN 55022, clase B}

Internal fuse protection _2x8A _2x15A _20A _2x30A

AC over voltage protection _{Includes loss of neutral}

OUTPUT

Nominal system voltage _{53,5 V}_dc _{54 V}_dc _{26,7 V}_dc _{53,5 V}_dc

Operating voltage range _{42~58 V}_dc _{21 ~ 29 V}_dc _{42~58 V}_dc

Power limitation _{850 W} _{1600 W} _{2900 W} _{3190 W} _{4050 W}

Current limitation _{17,7 A} _{33,4 A} _{56,25 A} _{110 A} _{83,3 A}

Overvoltage protection _{59 V}_cc _{29,5 V}_cc _{59 V}_cc

EMI (conducted) _{EN 55022, class A}

Load sharing _Yes

Protection _{Internal fuse}

GENERAL

Efficiency 95,2% 92% 96,2% 92% 95,2%

Power density 30 W/in2 _{24 W/in}2 _{36,5 W/in}2 _{21,8 W/in}2 _{27,3 W/in}2

Control and monitoring Orion

User interface Estado Estado

Corriente salida Estado Corriente salida Estado Estado Corriente salida

Dimensions (WxHxD) [mm] 51,8x40x247,2 132x40,8x232,5 125,5x41x269,9 82x86,9x377,9

Weight 0,6 kg 1,25 kg 2,0 kg 3,5 kg

Safety standards EN/IEC/UL 60950, CAN/CSA-C22,2

EMI (radiated) standards EN55022, clase B

Environment standards RoHS compliant

Cooling Fan cooled

Acoustics 44 dBA 48 dBA 55 dBA 50 dBA

Operating temperature -40~75 ºC

(12)

Controller module Orion

INPUT

Mains voltage 18 ~ 75 Vdc

Current 0,8 Adc (maximum)

Protection Internal fuse 2 A

GENERAL

Dimensiones (WxHxD) 83,4 x 40,0 x 175 mm

Weight 0,6 kg

STANDARDS

Safety EN / IEC 60950, class I; UL 60950; CAN / CSA –C22.2

EMC EN 55022, class B; ETSI EN 300386 compliant

Cooling Natural air flow

Operating temperature 0 ~ 75 ºC

Relative humidity 95% non-condensing

FUNCTIONS

System PLC functionality for customization and supervision and control of

auxiliary devices

AC measurement (internal / external)

Mains failure/phase failure detection and alarming LVD and PLD functions

Advanced genset functions for fuel savings Configurable event and data log

Battery Temperature compensated float charge / Boost and equalize charge

Charging current limitation (advanced) Low voltage disconnection

State of charge supervision and display Backup time supervision / Life time prediction

Automatic capacity test

Symmetry supervision for voltage and currents Block voltage supervision (optional)

Rectifier Individual rectifier information and control

Sequential start-up / system soft start

Efficiency mode with advanced rectifier cycling Redundancy and power capacity supervision

(13)

Controller module Orion

FEATURES

Rectifier interface Digital, CAN-based

Number of rectifiers Up to 128

Digital input 4 ~ 227

Relay output 6 ~ 99

Temperature 2 ~ 98

Voltage, current Up to 99

Display 1 integrated, up to 2 user interface modules

Local monitoring LAN/Web browser

Remote monitoring LAN/modem, GSM, GPRS, web browser

Remote alarming Dry contacts/SNMP

Languages Multilanguage

USER INTERFACE

Local user interface 5 configurable LED; LCD display, keypad

UIM (optional) 5 configurable LED; LCD display, keypad; buzzer

Web Four different access levels; More than 200 dynamic WEB pages; SW

and setup updates locally and remotely

SNMP Remote alarms using traps; Dial-out feature together with modems
