Content Tables
1. INTRODUCTION... 1
2. WTHA'S NEW?...2
3. MAIN FEATURES... 3
4. APPLICATIONS... 4
5. SPECIFICATIONS... 5
6. INSTALLATION... 6
7. OPERATION... 12
8. SET THE AUTHORIZED NUMBERS...14
9. DELETE AUTHORIZED NUMBERS... 14
10. GET POSITION SMS... 15
11. LISTEN IN AND TWO-WAY VOICE COMMUNICATION... 15
12. GPRS SETTING(BASED ON A FIXED PLATFORM)... 16
13. TRACKING SOFTWARE...16
1. INTRODUCTION
1.1.
Product name
GPS / GPRS / GSM dual-controlled microcomputer car anti-theft alarm
Model: TL208
1.2.
Product description
This tracking system integrates GPS/GSM/GPRS is a double MCU control car
anti-theft alarm device. It is a Hi-Tech auto electronic security cutting-edge product
which replaces ordinary single and double way car anti-theft alarm products. It make
full using of GPRS/GSM communications technologies, Global Positioning System
(GPS), Universal To Code technology and MCU processing tech, which fulfills
real-time tracking, anti-theft and many functions of interactions between the owner and
their vehicle, such as: automatic vehicles alarm function which can call your mobile/Tel
automatically, Fortify and removal, cut oil/electricity, remote starting, remote listen in
without distance limit via mobile phone and tracking platform, it can locate and find
your vehicle after stolen or rob, phone call via tracker, more than 30 functions, true 24
hours escort for your car. Gain the location and driving data automatically, transmit the
data to the platform via GPRS module, it compatible with various monitoring software,
tracker also can send this data via SMS, and then you can do locating and monitoring
on Google Earth.
2. WTHA'S NEW?
Support the salvation platform of government department
Support hand-free phone call between driver and call center. This function is very
useful for taxi, rental vehicle, ambulance and police car.
Easy to assemble: design for a built-in relays, simplify the complex installation
procedures.
The server software is especially designed for tracking a large quantity of trackers.
It can support more than 10 thousands users.
Information can be stored in blind area for at least 15 hours
3. MAIN FEATURES
Tracker
Software
Real-time locating and tracking via phone/pc Compatible with the original car alarms 2-way voice communication
Listen in feature Door detective
ACC(ignition) detective SOS alarm
In/out Geo-fence alarm Speeding/Power-lost alarm Locate information storage
Remote fuel/power control (External Relay) Remote switch engine on (Preheated ahead) Multi-function remote (effective scope: 20M) Car door & trunk remote control
Acousto-optic anti-theft alarm
Detecting input voltage via Software setting Trigger memory hint
Parking warning Acoustic quick reports Build-in vibration sensor
SMS/GPRS/PC three ways to refresh data Travel mileage modification
Connect original car anti-theft system Customizations are welcome
Server based
Based on Google map/Google earth Support multi-users
Support more than 10000 trackers Support online configuration Real-time locating and tracking Set continuous tracking History track replay SOS alarm
Over speed alarm
Remote starting engine via platform GEO fence alarm(five groups) Power-lost alarm
Low power alarm Online navigation Driving record
Fleet dispatching management Vehicles state real-time display Support reports information download Offer 30 days online storage
3 years free upgrade services
Weather forecast, and other functions Instant power & oil cut off processing Chinese/English
4. APPLICATIONS
Rental vehicle monitoring and management
Taxi/ ambulance/police car dispatch management
Real-time tracking, guard against theft, telephone navigation to make sure safe
journey
Fleet dispatching management in large companies, such as nearby scheduling, Oil
mass, maintain reminders
GPS tracking server and management software
Traffic control center platform, which can prevent congestion effectively and
reduce traffic accidents
Entertainment industry, communication system industry, transportation industry
and so on
Express, logistic team, travel agencies, hotels
Government organizations: police administration unit, public transportation
Special vehicle management (dump truck, tanker, container, etc.)
Offer navigate and locate service on platform
5. SPECIFICATIONS
Content Specs.
Dimension 91* 64* 25mm
Weight 150g
GSM Band: Dual band: 900MHz/1800MHz
Quad band:850/900/1800/1900MHz GPRS/GSM Module serial interface voltage: 3.8V GPRS/GSM Module attended to current: 11-25mA
Operating control distance: Valid in where GSM signal is available Static current: 10mA
GPS Based on Sirf III, Sensitivity/accuracy: -154dBm/5-10M（Depending
on the GPS satellite, weather, geographical position）
Start time Cold start 60S
Warm start 40S Hot start 1S
Output voltage of interface Turn off: disconnect（Built-in blackouts relays） Alarm LED:12V
Alarm horn:12V
Input voltage of interface Door detecting voltage: 0V/12V（positive/negative configurable triggering）
The keys detecting: 12V（that is ACC input voltage） The foot brake detecting: 12V
Input Voltage 9-30V
quiescent current 60mA -80 mA (Plus GPRS/GSM and GPS modules) Fortification/removal operating
frequency
300MHz-350MHz
Remote Control Operating Voltage:12V（A 12V battery type A27） operating frequency: 300MHz-350MHz
Fortification/removal remote distance: Over 20m quiescent current: 10uA
Battery Chargeable 3.7V 850mAh
Standby Time 50-60Hours
Power Consumption ≤50mA
Work Environment Storage Tem: -40°C - +85°C Working Tem:-40°C - +75°C
6. INSTALLATION
6.1. Installation of the Sim Card
Please ensure that Sim Card has incoming call display function, no call forwarding service and PIN code is off
A. With pointed shaped object touches the card slot switch, let SIM card slot out B. Put the sim card with the meter side down in the deck, as per the picture below,
C. Insert the card slot into the device, it will be switched on automatically.
After the device starting, GPS and GSM signal LED will be light for a while. A minute later, the tracker finishes the initialized process. GSM (red) LED will flash once every three seconds. GPS (green) LED will flash once every three seconds after finding the signal.
6.2. Installation schematic
GSM signal led GPS signal led
SIM card slot switch
Remote control antenna GPS antenna GSM antenna Microphone Speaker
Start principle and steps, simulate to ignite with key
1. ACC must be on 12V and keep 12V after starting 2. On must be on 12V and keep 12V after starting3. Start must be on 12V keep 1S or less (Start the engine only)
4. If the engine run well, purple line(Be winded around the High Volt line) will receive enough induced voltage, it show us everything goes well.
Central lock system wiring diagram
1. Chart 1 show us the internal principle of the central lock, it also define the line’s color.
2. Chart 2- chart 5 is the working process which include: negative trigger (chart 2), positive trigger (chart 3), positive or negative trigger (chart 4), positive main loop trigger (chart 5)
7. Operation
7.1. Emergency alarm (SOS)
The owner can press the "SOS button" for help in any state.
Press "SOS button" for 3 seconds: The system will dial the SOS number automatically for help, and send coordinate information to the preset number or platform (platform is prior). Note, the device is silent when it calling SOS number.
7.2. Two-way communication
Authorization number call the tracker, it will pick up the phone automatically. The communication would be easier; it is also very convenient for management center to schedule. (As per chapter twelve)
7.3. Listen-in
Authorization number call the tracker, it will pick up the phone automatically. Then you can check the inside situation of the vehicle by monitoring the sound environment. (Refer to chapter 12)
7.4. SMS and Platform
You can operate and control the vehicle via SMS or Platform, about the SMS command (Refer to chapter 16), and about the platform operation (Refer to chapter 13)
7.5. Ante-theft Alarm triggers mode and response mode 7.5.1. LED warning light response mode
(1) In the alert: LED lights flash 2 times, stop 1 second...
(2) Triggered by the vibrations: LED lights flash 3 times, stop 1 second... (3) Triggered by the switch: LED lights 2 seconds, stop 2 seconds…
7.5.2. Trigger alarm (triggered by opening car doors, starting the vehicle, pressing on the foot brake)
(1) Open any door under setting alarm status: starting and pressing on the foot brake will trigger the alarm.
(2) Response pattern: A. Horn sounding
direction indicator lamp flashes 5s synchronously. If it trigger vibration again within 15 seconds, horn tolls and light flashes 25s synchronously.
● Quiet alert state: at the first vibration triggering, turn signals synchronous flash 5s; if vibration triggered again within 15 seconds, turn signals flash sync 25 seconds, the system immediately pre-set alarm phone call.
7.5.4. Power off alarm and line cut alarm
In fortification state, this host interface control once be cut, or automotive systems power off, the host will be alarmed within 10 seconds.
7.5.5. Triggering the memory tips
When the alarm is off, if the horn tolls for a long time and warning light slakes after 3s, it indicate the vehicle was triggered.
7.5.6. Parking alerts
When you park, open the door then the direction light will flash for 15 seconds immediately and automatically to remind the cars in the back, avoiding accidents.
7.6. Automatic functions
7.6.1. When the door doesn’t be opened after withdrawing fortification, it will recover fortification.
The door doesn’t be opened within 25s after withdrawing fortification, system predicate misoperation, it will recover fortification automatically
7.6.2. Reminding fortification
The owner don’t fortify after closing the door at parking, the system will sound three ‘Di’, ’Di’, ’Di’ to remind for fortification, direction indicator lamp flash together synchronously
7.6.3. Fortify automatically after closing the door
Doesn’t fortify with 50s after the fortification reminding, system will be state of alert automatically, but the door won’t lock.
7.6.4. Reminding closing door
Fortify when the door doesn’t close after parking, horn will ring three times, and turn signal blink synchronously, the owner should withdrawing fortification then fortification again, otherwise horn will takq 10s later
7.6.5. Automatic central door lock
Pressing foot brake after the car driving 15s, it will lock automatically. It also can unlock automatically after the car flameout. On driving, press to lock, press to unlock.
7.6.6. Electric/pneumatic locking conversion
7.7. Remote control operation
7.7.1. Fortification/removal via remote
A. Press shortly→fortification（horn ring once and turn signal blink once）→lock the door and into acousto-optic alert mode
B. Press shortly→removal（horn ring twice and turn signal blink twice）→unlock the door C. Press shortly→fortification（turn signal blink once only）→lock the door and into mute alert
7.7.2. Finding car via remote control
Press car horn ring and turn signal blink, point out where the car is. It will end ring and blink after 25s or press any button
7.7.3. Remote lock/unlock central lock
Press to lock and press to unlock at driving
8. Set the authorized numbers
SMS command: PasswordA1 (1~4), +country code phone number
E.g. 123456A1, +8613512345678 set 13512345678 as the first authorized number 123456A4, +8613612345678 set 13612345678 as the forth authorized number
SOS function
Press SOS button for 3s before releasing, the tracker will complete three functions as follow: 1. Tracker will send "help me & GPS information” to the three (A1, A2, A3) authorized numbers; 2. If the GPRS is online, tracker will send SOS signal to the server only (skip 1 step);
3. Tracker will call A1, A2 and A3 until be answered by any one of them or repeat 30 times.
Note: 123456 is the default password. ‘A’ must be capital and make sure there is no space in the command. Phone number must include the country code
E.g. send SMS 123456A1, +8613812345678 to set 13812345678 as the first SOS number. +86 is the country code of China. Please do not use 00 instead of +.
10. Get position SMS
10.1. You can use the authorized phone number to call the tracker for three times ringtone, and then hang up before the tracker answer it. The tracker will reply a position SMS with its coordinate and the map URL. You can click the URL directly or input the coordinate into Google map to search for the position.
The tracker will reply position SMS to any incoming call number if you haven’t set the authorized numbers yet. Once you have set the authorized number, the tracker will just reply SMS position to the authorized numbers.
10.2. Send commands to tracker via SMS
E.g. Send SMS “123456F” to the tracker from authorized number, it will reply a position SMS also.
Note: ‘F’ must be a capital, and the device will respond SMS only when receiving commands from authorized numbers.
11. Listen in and two-way voice communication
11.1. Listen in or two-way voice communication modes
These two modes can be switched via SMS. The default mode is two-way voice communication mode.
SMS command: Send SMS 123456U1 to switch to the listen in mode
Send SMS 123456U0 to switch to two-way voice communication mode
11.2. Listen in function (Please switch to listen in mode first)
Call the device with any authorized number, and then the device will answer automatically. You can listen in the voices around tracker.
11.3.Two-way voice communication function (Switch to this mode if you use listen in function before)
Call the device with any authorized number, and then the device will answer automatically. You can speak to the device.
11.4. It is Two-way voice communication if there is a call from tracker A. Two-way voice communication in SOS state
Locator will repeat call the three authorized number until any one answer or call 30 times. B. Two-way voice communication in talk-Listen button
Press ‘Call 1’ button for 3s and then tracker will call the fourth authorized phone number. Press ‘Call 2’ button for 3s and then tracker will call the fifth authorized phone number.
12. GPRS setting (based on a fixed platform)
12.1. Make sure the GPRS function of the SIM CARD is opened 12.2. Get APN from your cellular carrier (GPRS access point name).
12.3. Send the device 123456B to get IMEI number and make sure this IMEI number has been registered on the platform, if not, please send it to the seller, let them contact factory.
12.4. Set the APN, IP & PORT
Send SMS “123456C$$$$,IP:Port” to set the APN, IP and port. IP and port is about the server you use.
Note: Make sure that the IP should be the public IP. If your pc is in Internet, you must know your public IP.
E.g. send SMS “123456CCMNET,119.122.101.91:9289” . CMNET is the APN of China Mobile company, please set the APN of the cellular company you use. 119.122.101.91:9289is the IP & PORT of our own server.
12.5. Send command 123456D to open GPRS Send command 123456E to close GPRS
Recommend using the GPRS, it is more convenient to monitor your people or fleet.
13. Tracking software
After activating the GPRS function, the tracker will send data to the preset IP. You can see the position of your target on the platform.
1 Download and install Google Earth, website:http://earth.google.com/
2.You can login: http://ditu.google.cn/ directly and input the coordinate which you get from tracker.
This platform which has powerful function is based on Google Map. User can select the features according to their needs.Note: ‘Distance’ is distance measurement
When you use the 3D map for the first time, it will prompt you to download the Google Earth.
The main function you will use it frequently: A. Real time tracking
B. History replay
C. Remote navigate via device D. Report download
