Cloud Data Management for Scientific Workflows: Research Issues,
Methodologies, and State-of-the-Art
Dong Yuan
School of Software and Electrical Engineering,
Swinburne University of Technology, Melbourne, Australia
Lizhen Cui
School of Computer Science and Technology,
Shandong University, Jinan, China [email protected]
Xiao Liu
*Shanghai Key Laboratory of Trustworthy Computing, East China Normal University
Shanghai, China [email protected] Abstract—Data-intensive scientific applications are posing
many challenges in distributed computing systems. In the scientific field, the application data are expected to double every year over the next decade and further. With this continuing data explosion, high performance computing systems are needed to store and process data efficiently, and workflow technologies are facilitated to automate these scientific applications. Scientific workflows are typically very complex. They usually have a large number of tasks and need a long time for execution. Running scientific workflow applications usually need not only high performance computing resources but also massive storage. The emergence of cloud computing technologies offers a new way to develop scientific workflow systems. Scientists can upload their data and launch their applications on the scientific cloud workflow systems from everywhere in the world via the Internet, and they only need to pay for the resources that they use for their applications. As all the data are managed in the cloud, it is easy to share data among scientists. This kind of model is very convenient for users, but remains a big challenge to the system. This paper proposes several research topics of data management in scientific cloud workflow systems, and discusses their research methodologies and state-of-the-art solutions.*
Keywords-Scientific Workflow, Data Management, Cloud Computing, Research Issues
I. INTRODUCTION
Data-intensive scientific applications are posing many challenges in distributed computing systems. In many scientific research fields, like astronomy, high-energy physics and bio-informatics, scientists need to analyse terabytes of data either from existing data resources or collected from physical devices. During these processes, similar amounts of new data might also be generated as intermediate or final products [1]. According to [2], in the scientific field, the application data are expected to double every year over the next decade and further. With this continuing data explosion, high performance computing systems are needed to store and process data efficiently, and workflow technologies are facilitated to automate these scientific applications. Scientific workflows are typically very complex. They usually have a large number of tasks and need a long time for execution. Running scientific workflow applications usually need not only high performance computing resources but also massive storage [1].
*
Corresponding author
Nowadays, popular scientific workflows are often deployed in grid systems [3] because they have high performance and massive storage. However, building a grid system is extremely expensive and it is normally not open for scientists all over the world. The emergence of cloud computing technologies offers a new way to develop scientific workflow systems.
Since late 2007 the concept of cloud computing was proposed [4], it has been utilised in many areas with some success. Cloud computing is deemed as the next generation of IT platforms that can deliver computing as a kind of utility [5]. Foster et al. made a comprehensive comparison of grid computing and cloud computing [6]. Some features of cloud computing also meet the requirements of scientific workflow systems. Cloud computing systems provide the high performance and massive storage required for scientific applications in the same way as grid systems, but with a lower infrastructure construction cost among many other features, because cloud computing systems are composed of data centres which can be clusters of commodity hardware [4]. Research into doing science and data-intensive applications on the cloud has already commenced [7], such as early experiences like Nimbus [8] and Cumulus [9] projects. The work by Deelman et al. [10] shows that cloud computing offers a cost-effective solution for data-intensive applications, such as scientific workflows [11]. Furthermore, cloud computing systems offer a new model that scientists from all over the world can collaborate and conduct their research together. Cloud computing systems are based on the Internet, and so are the scientific workflow systems deployed in the cloud. Scientists can upload their data and launch their applications on the scientific cloud workflow systems from everywhere in the world via the Internet, and they only need to pay for the resources that they use for their applications. As all the data are managed in the cloud, it is easy to share data among scientists. This kind of model is very convenient for users, but remains a big challenge for data management to scientific cloud workflow systems.
Firstly, new data storage strategy is required in cloud scientific workflow systems. In a cloud computing, theoretically, the system can offer unlimited storage resources. All the application data of the scientific workflows can be stored, including the generated intermediate data, if we are willing to pay for the required resources. Storing all the application data in the cloud is
obviously not cost-effective, since some data are seldom used and huge in size. However, in scientific cloud workflow systems, a scientist cannot decide whether a piece of application data should be stored or not, since the data are shared and he is not the only user.
Secondly, new data placement strategy is also required, which means the cloud workflow systems must have the ability to decide where to store the application data. Cloud computing platform contains different cloud service providers with different pricing models, where data transfers between service providers also carry a cost. The cloud scientific workflows are usually distributed, and the data placement strategy will decide where to store the application data, in order to reduce the total system cost.
Last but not least, new data replication strategy should also be designed for cloud scientific workflow systems. A good replication strategy can not only guarantee the security of application data, but also further reduce the system cost by replicating frequently used data in different locations. Replication strategy in the Cloud should be dynamic based on the application data’s usage rate.
II. RELATED WORK
A. Data Management of Scientific Applications in Grid
Systems
1) Data Management in Grid
Grid computing has many similarities with cloud computing [4, 12]. Both of them are heterogeneous computing environments for large scale applications. Data management technology in grid, Data Grid [13] in short, could be a valuable reference of cloud data management. Next, some important features of data grid are briefly summerised and some successful systems are also briefly introduced.
Data Grid [14] primarily deals with providing services and infrastructure for distributed data-intensive applications that need to access, transfer, and modify massive datasets stored in distributed storage resources. Generally speaking, it should have the following capabilities: (a) ability to search through numerous available datasets for the required dataset and to discover suitable data resources for accessing the data, (b) ability to transfer large-size datasets between resources as fast as possible, (c) ability for users to manage multiple copies of their data, (d) ability to select suitable computational resources and process data on them and (e) ability to manage access permissions for the data.
Grid technology was very popular in the late 1990s and early 2000s, because it is suitable for large scale computation and data intensive applications. Many data management systems were developed and gained great success. Some of the most successful ones are listed below and some of them have already been utilised in scientific applications.
Grid DataFarm [15] is a tightly-coupled architecture for storage in the grid environment. The architecture consists of nodes that have large disk space. Between the
nodes there are interconnections via fast Ethernet. It also has a corresponding file system, process scheduler and parallel I/O APIs.
GDMP [16] mainly focuses on replication in the grid environment, which has been utilised in High Energy Physics. It uses the GridFTP technology to achieve high speed data transfer and provides point-to-point replication capability.
GridDB [17] builds an overlay based on relational database, and provides services for large scientific data analysis. It mainly focuses on the software architecture and query processing.
SRB [18] organises data into different virtual collections independent of their physical locations. It could provide a unified view of data files in the distributed environment. It is used in the Kepler workflow system.
RLS (P-RLS) [19, 20] maintains all the copies of data’s physical locations in the system, and provides data discovery services. Newly generated data could dynamically register in RLS, so that it could be discovered by the tasks. It has been used in Pegasus and Triana workflow systems.
GSB [21] is designed to mediate access to distributed resources. It could map tasks to resources and monitor task execution. GSB is the foundation of data management in the Gridbus workflow system.
DaltOn [22] is an infrastructure for Scientific Data Management. It supports the syntactic and semantic integration of data from multiple sources.
Although data grid has some similarities on data management of the cloud, they are essentially different. At the infrastructure level, grid systems are usually composed of several computing nodes built up with supercomputers, and the computing nodes are usually connected by fast Ethernet or dedicate networks, so that in data grid, efficient data management can be easily achieved with the high performance hardware. Cloud systems are based on the Internet and normally composed of data centres built up with commodity hardware, where data management is more challenging. More importantly, at the application level, most clouds are commercial systems while the grids are not. The wide utilisation of the pay-as-you-go model in the cloud makes the issue of cost-effectiveness more important than before.
2) Data Management in Grid Workflows
Scientific applications are typically very complex. They usually have a large number of tasks and need a long time for execution. Workflow technologies are important tools which can be facilitated to automate the executions of applications [1]. Many workflow management systems were developed in grid environments. Some of the most successful ones are listed below, as well as the features of their data management:
Kepler [3] is a scientific workflow management system in the grid environment. It points out that
control-flow orientation and data-control-flow orientation are the difference between business and scientific workflows. Kepler has its own actor-oriented data modelling method that for large data in the grid environment. It has two Grid actors, called FileFetcher and FileStager, respectively. These actors make use of GridFTP [23] to retrieve files from, or move files to, remote locations on the Grid. In the runtime data management, Kepler adopts the SRB system [18].
Pegasus [24] is a workflow management system which mainly focuses on data-intensive scientific applications. It has developed some data management algorithms in the grid environment and uses the RLS [19] system as data management at runtime. In Pegasus, data are asynchronously moved to the tasks on demand to reduce the waiting time of the execution and dynamically delete the data that the task no longer needs to reduce the use of storage.
Gridbus [25] is grid toolkit. In this toolkit, the workflow system has several scheduling algorithms for the data-intensive applications in the grid environment based on a Grid Resource Broker [21]. The algorithms are designed based on different theories (GA, MDP, SCP, Heuristic), to adapt to different use cases.
Taverna [26] is a scientific workflow system for bioinformatics. It proposes a new process definition language, Sculf, which could model application data in a dataflow. It considers workflow as a graph of processors, each of which transfers a set of data inputs into a set of data outputs.
MOTEUR [27] workflow system advances Taverna’s data model. It proposes a data composition strategy by defining some specific operations.
ASKALON [28] is a workflow system designed for scheduling. It puts the computing overhead and data transfer overhead together to get a value “weight”. It does not discriminate the computing resource and data host. ASKALON also has its own process definition language called AGWL.
Triana [29] is a workflow system which is based on a problem-solving environment that enables the data-intensive scientific application to execute. For the grid, it has an independent abstraction middleware layer, called the Grid Application Prototype (GAP), enables users to advertise, discover and communicate with Web and peer-to-peer (P2P) services. Triana also uses the RLS to manage data at runtime.
GridFlow [30] is a workflow system which uses an agent-based system for grid resource management. It considers data transfer to computing resources and archive to storage resources as kinds of workflow tasks. But in this work, they do not discuss these data related workflow tasks.
In summary, for data management, all the workflow systems mentioned above have concerned the modelling of workflow data at build-time. Workflow data modelling
is a long-term research topic in academia with matured theories, including Workflow Data Patterns [31], Dataflow Programming Language [32]. For data management at workflow run-time, most of these workflow systems simply adopt data management technology in data grid. They do not consider the dependencies among the application data. Only Pegasus proposes some strategies for workflow data placement based on dependency [33, 34], but they have not designed specific algorithms to achieve them. As all these workflow systems are in grid computing environment, they neither utilise the pay-as-you-as model nor investigate the issue of cost-effectiveness in deploying the applications.
B. Cost-Effectiveness of Scientific Applications in the Cloud
1) Cost-Effectiveness of Deploying Scientific
Applications in the Cloud
Scientific applications have already been introduced to the cloud and research on deploying applications in the cloud has become popular. Cloud computing system for scientific applications, i.e. science cloud, has already commenced, where some successful and representative ones are as follows.
OpenNebula [35] project facilitates on-premise IaaS cloud computing, offering a complete and comprehensive solution for the management of virtualised data centres to enable private, public and hybrid clouds.
Nimbus Platform [36] is an integrated set of tools that deliver the power and versatility of infrastructure clouds to users. Nimbus Platform allows users to combine Nimbus, OpenStack, Amazon, and other clouds.
Eucalyptus [37] enables the creation of on-premise private clouds, with no requirements for retooling the organisation's existing IT infrastructure or need to introduce specialised hardware.
Foster et al. made a comprehensive comparison of grid computing and cloud computing [6], where two important differences related to this paper are as follows:
Comparing to grid, cloud computing systems can provide the same high performance computing resources and massive storage required for scientific applications, but with a lower infrastructure construction cost among many other features. This is because cloud computing systems are composed of data centres which can be clusters of commodity hardware [4]. Hence, deploying scientific applications in the cloud could be more cost-effective than its grid counterpart.
By utilising the virtualisation technology, cloud computing systems are more scalable and elastic. Because new hardware can be easily added to the data centres, service providers can deliver cloud services based on the pay-as-you-go model and users can dynamically scale up or down the computation and storage resources they use.
Based on the new features of cloud, comparing to the traditional distributed computing systems like cluster and
grid, a cloud computing system has a cost benefit from various aspects [38]. Assunção et al. [39] demonstrate that cloud computing can extend the capacity of clusters with a cost benefit. With Amazon clouds’ cost model and BOINC volunteer computing middleware, the work in [40] analyses the cost benefit of cloud computing versus grid computing. The work by Deelman et al. [10] also applies Amazon clouds’ cost model and demonstrates that cloud computing offers a cost-effective way to deploy scientific applications. In [11], Hoffa et al. conduct simulations of running an astronomy scientific workflow in cloud and clusters, which shows cloud scientific workflows are cost-effective. Meanwhile, Tsakalozos et al. [41] point out that by flexible utilisation of cloud resources, service provider’s profit can also be maximised. Especially, Cho et al. [42] further propose planning algorithms of how to transfer large bulks of scientific data to commercial clouds in order to run the applications.
The above works mainly focus on the comparison of cloud computing systems and the traditional distributed computing paradigms, which show that applications running in the cloud have cost benefits.
2) Trade-Off between Computation and Storage in
the Cloud
This research is mainly inspired by the work in two research areas: cache management and scheduling. With smart caching mechanism [43-45], system performance can be greatly improved. The similarity is that both pre-store some data for future use, while the difference is that caching is to reducing data accessing delay but our work is to reduce the application cost in the cloud. Works in scheduling focus on reducing various costs for either applications [46] or systems [47], but they investigate this issue from the perspective of resource provisioning and utilisation, not from the trade-off between computation and storage. In [48], Garg et al. investigate the trade-off between time and cost in the cloud, where users can reduce the computation time by using expensive CPU instances with higher performance. This trade-off is different to ours which aims to reduce the application cost in the cloud.
As the trade-off between computation and storage is an important issue, some researches have already embarked on this issue to a certain extent. Nectar system [49] is designed for automatic management of data and computation in data centres, where obsolete datasets are deleted and regenerated whenever reused in order to improve resource utilisation. In [10], Deelman et al. present that storing some popular intermediate data can save the cost in comparison to always regenerating them from the input data. In [50], Adams et al. propose a model to represent the trade-off of computation cost and storage cost, but have not given any strategy to find this trade-off.
III. RESEARCH PROBLEMS AND METHODOLOGIES A. Data storage strategy
1) Problem analysis
Traditionally, scientific workflows are deployed on the high performance computing facilities, such as clusters and grids. Scientific workflows are often complex with huge intermediate data generated during their execution. How to store these intermediate data is normally decided by the scientists who use the scientific workflows. This is because the clusters and grids only serve for certain institutions. The scientists may store the intermediate data that are most valuable to them, based on the storage capacity of the system. However, in many scientific workflow systems, the storage capacities are limited, such as the pulsar searching workflow we introduced. The scientists have to delete all the intermediate data because of the storage limitation. This bottleneck of storage can be avoided if we run scientific workflows in the cloud.
In a cloud computing environment, theoretically, the system can offer unlimited storage resources. All the intermediate data generated by scientific cloud workflows can be stored, if we are willing to pay for the required resources. However, in scientific cloud workflow systems, whether to store intermediate data or not is not an easy decision anymore.
a) All the resources in the cloud carry certain costs, so either storing or generating an intermediate dataset, we have to pay for the resources used. The intermediate datasets vary in size, and have different generation cost and usage rate. Some of them may often be used whilst some others may be not. On one hand, it is most likely not cost effective to store all the intermediate data in the cloud. On the other hand, if we delete them all, regeneration of frequently used intermediate datasets imposes a high computation cost. We need a strategy to balance the generation cost and the storage cost of the intermediate data, in order to reduce the total cost of the scientific cloud workflow system.
b) The scientists can not predict the usage rate of the intermediate data anymore. For a single research group, if the data resources of the applications are only used by its own scientists, the scientists may predict the usage rate of the intermediate data and decide whether to store or delete them. However, the scientific cloud workflow system is not developed for a single scientist or institution, rather, developed for scientists from different institutions to collaborate and share data resources. The users of the system could be anonymous from the Internet. We must have a strategy storing the intermediate data based on the needs of all the users that can reduce the cost of the whole system.
Hence, for scientific cloud workflow systems, we need a strategy that can automatically select and store the most appropriate intermediate datasets. Furthermore, this strategy should be cost effective that can reduce the total cost of the whole system.
2) Methodology
Scientific workflows have many computation and data intensive tasks that will generate many intermediate datasets of considerable size. There are dependencies exist
among the intermediate datasets. Data provenance in workflows is a kind of important metadata, in which the dependencies between datasets are recorded. The dependency depicts the derivation relationship between workflow intermediate datasets. For scientific workflows, data provenance is especially important, because after the execution, some intermediate datasets may be deleted, but sometimes the scientists have to regenerate them for either reuse or reanalysis. Data provenance records the information of how the intermediate datasets were generated, which is very important for the scientists. Furthermore, regeneration of the intermediate datasets from the input data may be very time consuming, and therefore carry a high cost. With data provenance information, the regeneration of the demanding dataset may start from some stored intermediated datasets instead. In the scientific cloud workflow system, data provenance is recorded while the workflow execution. Taking advantage of data provenance, we can build a Data Dependency Graph (DDG) based on data provenance. All the intermediate datasets once generated in the system, whether stored or deleted, their references are recorded in the DDG. Based on the DDG, we can calculate the generation cost of every intermediate dataset in the scientific cloud workflows. By comparing the generation cost and storage cost, our strategy can automatically decide whether an intermediate dataset should be stored or deleted in the cloud system, no matter this intermediate dataset is a new dataset, regenerated dataset or stored dataset in the system [51].
Minimum cost benchmarking is to find the theoretical minimum application cost based on the cost model, which is also the best trade-off between computation and storage in the cloud. Due to the pay-as-you-go model in the cloud, cost is one of the most important factors that users care about. As a rapidly increasing number of datasets is generated and stored in the cloud, users need to evaluate the cost effectiveness of their storage strategies. Hence the service providers should be able and need to provide benchmarking services that can inform the minimum cost of storing the application datasets in the cloud [52].
Based on the trade-off between computation and storage, cost-effective storage strategies need to be designed in this paper. Different from benchmarking, in practice, the minimum cost storage strategy may not be the best strategy for the applications, because storage strategies are for users to use at runtime in the cloud and should take users’ preferences into consideration.
Beside cost-effectiveness, storage strategies must be efficient enough to be facilitated at runtime in the cloud. For different applications, the requirements of efficiency may be different. On one hand, some applications may need highly efficient storage strategies with acceptable though not optimal cost-effectiveness. On the other hand, some applications may need highly cost-effective storage strategies with acceptable efficiency. According to different requirements, we need to design corresponding storage strategies [53] [54].
Furthermore, to reflect users’ preferences on the datasets storage [55], we need to incorporate related parameters into the strategies which 1) guarantee all the application datasets’ regenerations can fulfil users’ tolerance of data accessing delay, and 2) allow users to store some datasets according to their preferences [56] [57].
B. Data placement strategy
1) Problem Analysis
Scientific applications are data intensive and usually need collaborations of scientists from different institutions [58], hence application data in scientific workflows are usually distributed and very large. When one task needs to process data from different data centres, moving data becomes a challenge. Some application data are too large to be moved efficiently, some may have fixed locations that are not feasible to be moved and some may have to be located at fixed data centres for processing, but these are only one aspect of this challenge. For the application data that are flexible to be moved, we also cannot move them whenever and wherever we want, since in the cloud computing platform, data centres may belong to different cloud service providers that data movement would result in costs. Furthermore, the infrastructure of cloud computing systems is hidden from their users. They just offer the computation and storage resources required by users for their applications. The users do not know the exact physical locations where their data are stored. This kind of model is very convenient for users, but remains a big challenge for data management to scientific cloud workflow systems.
2) Methodology
In cloud computing systems, the infrastructure is hidden from users [59]. Hence, for most of the application data, the system will decide where to store them. Dependencies exist among these data. In our research, we initially adapt the clustering algorithms for data movement based on data dependency. Clustering algorithms have been used in pattern recognition since 1980s, which can classify patterns into groups without supervision. Today they are widely used to process data streams. In many scientific workflow applications, the intermediate data movement is in data stream format and the newly generated data must be moved to the destination in real-time. We adapt the k-means clustering algorithm for data placement in scientific cloud workflow systems. Scientific workflows can be very complex, one task might require many datasets for execution; furthermore, one dataset might also be required by many tasks. If some datasets are always used together by many tasks, we say that these datasets are dependent on each other. In our strategy, we try to keep these datasets in one data centre, so that when tasks were scheduled to this data centre, most, if not all, of the data they need are stored locally.
Our data placement strategy has two algorithms, one for the build-time stage and one for the runtime stage of scientific workflows [60]. In the build-time stage algorithm, we construct a dependency matrix for all the
application data, which represents the dependencies between all the datasets including the datasets that may have fixed locations. Then we use the BEA algorithm [61] to cluster the matrix and partition it that datasets in every partition are highly dependent upon each other. We distribute the partitions into k data centres, where the partitions have fixed location datasets are also placed in the appropriate data centres. These k data centres are initially as the partitions of the k-means algorithm at runtime stage. At runtime, our clustering algorithm deals with the newly generated data that will be needed by other tasks. For every newly generated dataset, we calculate its dependencies with all k data centres, and move the data to the data centre that has the highest dependency with it.
By placing data with their dependencies, our strategy attempts to minimise the total data movement during the execution of workflows. Based on the optimised placement of data, effective and efficient task scheduling approaches can be derived [62] [63] [64] [64]. Furthermore, as numerous cloud services have been published on Internet, in order to reduce the data storage cost, less frequently used data can be moved to cheap cloud services for storage [65] [66].
C. Data replication strategy
1) Problem Analysis
Data replication is also an important issue for cloud workflow systems as presented by the two points below:
First, a good replication strategy can guarantee fast data access for the cloud workflow system. In the scientific workflows with many parallel tasks will simultaneously access the same dataset on one data centre. The limitation of computing capacity and bandwidth in that data centre would be a bottleneck for the whole cloud workflow system. If we have several replicas in different data centres, this bottleneck will be eliminated.
Second, a good replication strategy can reduce data movement between data centres. For example, if tasks in one data centre always need to retrieve data from the same data set in a remote data centre, it is better to replicate that data set in the local data centre to reduce the data movement.
Third, a good replication strategy can guarantee data reliability for the cloud workflow system. Because data centres in cloud workflow systems are built up with massive cheap commodity hardware, the breakdown of some hardware could happen any time. It is essential to keep several copies of each data in different data centres for reliability.
However, at present, data replication strategies that utilised in cloud data management systems are usually static. For example, in Hadoop, users can manually set the number of replicas, and the system will automatically replicate the application data in different places (racks or clusters, depends on the scale of the system). Static replication can guarantee the data reliability, but in cloud environment, different application data have different
usage rate, where we should have the dynamic strategy to replicate the application data based on their usage rate.
2) Methodology
To cope with the problems discussed above, we propose two cost effective strategies to reduce the cost of data replication in the cloud.
The first strategy is based on dynamic control of replica numbers, i.e. always keep fix number copies of each dataset in different data centres to guarantee reliability and dynamically add new replicas for each dataset to guarantee data availability. We propose a novel cost-effective dynamic data replication strategy named Cost-effective Incremental Replication (CIR) [67]. CIR is a data reliability strategy for Cloud-based applications in which the main focus is for cost-effectively managing the data reliability issue in a data centre. In CIR, an incremental replication approach is proposed for calculating the replica creation time point, which indicates the storage duration that the reliability requirement can be met. By predicting when an additional replica is needed to ensure the reliability requirement, CIR dynamically increases the number of replicas. In this way, the number of replicas can be minimised, so that the cost-effective dynamic data replication management goal can be reached. We have evaluated the effectiveness of our strategy by comparing it with the typical 3-replica data replication strategy. The result of the evaluation indicates that CIR strategy can substantially reduce the number of replicas in a data centre whilst meeting the reliability requirement, thus the storage cost of the entire storage system can be significantly reduced.
The second strategy is based on proactive replica checking, i.e. we proactively check the availability of replicas for maintaining data reliability, in order to keep the minimum number of necessary replicas [68]. This mechanism is able to store the Cloud data with the minimum replication while meeting the reliability requirement of Cloud data. Novel features of this strategy includes: 1) it is able to ensure the data reliability of storage devices with variable disk failure rates; 2) it is able to manage large amounts of data in the Cloud with a negligible running cost; 3) it provides data reliability management in a highly cost-effective way. By applying this strategy, a wide range of data reliability assurance can be provided with the minimum number of replicas, which is no more than two.
IV. CONCLUSION
In this paper, we summarized research issues in cloud data management for scientific workflow systems. We drew three research directions that are data storage, data placement and data replication. In each direction, we briefly analyzed the existing research problems, introduced promising methodologies and summarized state-of-the-art approaches.
V. Acknowledgement
The research work reported in this paper is partly supported by National Natural Science Foundation of China (NSFC) under No. 61300042, No. 61021004, No. 61272241, No. 61303085 and Shanghai Knowledge Service Platform Project No. ZF1213.
