Thyssocontrol Multican TCM Intelligent Elevators. The Control Concept Where the System Leads the Way.

Thyssocontrol Multican

®

TCM –

Intelligent Elevators.

The Control Concept Where

the System Leads the Way.

Performance Takes a Leading Role.

Peak Performance is Achieved Through a

Holistic Approach and Orientation Towards

the Future.

Advanced, practical elevator systems

are characterised by innovative

technologies and expertise. The

elevator controller is the most

important component in this respect:

Thyssocontrol Multican

(TCM).

The guiding principle.

The development of our eleva-tor systems is based around a universal quality aspiration. Efficiency, safety, future-proof, comfort and reliability are important aspects of this aspi-ration. This is put into effect in the form of market-oriented, dynamic development process-es that combine all elevator components into perfectly matched and intelligent system solutions.

The system leads the way.

Thyssocontrol Multican® employs modern IT manage-ment in the shape of the CAN bus. Combined with the latest microprocessor technology and project-oriented software, the result is an optimum data flow. All based around a distributed system configuration. This type of configuration reduces the load on the controller processor and is a prerequisite for fast data communication.

It also brings advantages that in turn lead to results. Results, e.g. in respect of high availabil-ity, exemplary ride qualavailabil-ity, short travel and waiting times.

Safe options.

If required, the functionality of Thyssocontrol Multican®_{can be} extended in a variety of cost effective ways. Monitoring allows the elevator to be visu-alised at any time. The system records and analyses all move-ments, identifies sources of faults and permits manual intervention.

Teleservice uses data commu-nication to monitor the elevator system round the clock. Faults are remedied automatically or forwarded to a Thyssen Service Center.

The TCM family. High-tech, even the low-cost version.

The TCM-MC1 and TCM-MC2 controllers are the high flyers in the Thyssocontrol Multican® family. TCM-MC1 is the high-quality controller with rack that provides all the flexibility you could require. This enables the controller to cover an extraordi-narily wide performance spec-trum that can be adapted to suit practically any requirement. The TCM-MC2 is a single-board controller with attractive cost advantages. It is based around a very good performance spec-trum with fixed boundaries. Two models that offer you all options in various versions.

s

Thyssocontrol Multican®

– always the right choice.

Controllers for every situation.

TCM-MC1 Executive.

The superior controller and rack in modular design and a capacity that can be expand-ed as requirexpand-ed. A tailorexpand-ed controller performance for new systems and modernisa-tion projects.

TCM-MC2 Economy.

The low-cost, compact single board controller that delivers performance you can count on. For the low-cost equip-ping of new systems.

TCM Modernization.

The modernisation controller based on the TCM-MC1 and TCM-MC2. Specially designed for replacement and exten-sions within attractive price boundaries.

TCM destination selection controller DSC Professional.

The innovative high-end ele-vator group controller with a special user interface based on the TCM MC1 controller. Increasing the handling capacity by up to 30 % leads to new levels of efficiency in office buildings.

TCM hydraulic controller.

Thyssocontrol Multican® con-trollers can naturally also be used in hydraulic elevators.

Overlay system.

This system allows elevator controllers of different generations and from differ-ent makers to be combined

s s s s s s

The comprehensive

func-tionality of Thyssocontrol

Multican

. Distinguished

by an excellent data flow

that determines ride

quality, provides

trans-parency and documents

vital elevator functions.

The Fulcrum and Pivot Point.

The Components and Mode of Operation.

Drive.

Thyssocontrol Multican®_{controls advanced} and reliable drive technology in perfect har-mony with the rest of the system.

Voice announce-ment.

Information, such as the current landing, can be announced. These verbal announcements also help disabled people operate the lift and leave it at the correct landing.

Control and indica-tor elements. Comfort and informa-tion at the press of a button. User-friendly and individually designed, the control elements blend in with the design of the elevator and the prop-erty. TFT display. Thyssocontrol Multican®_{uses a} full-colour TFT (thin film transistor) display to output textual information. Frequency-con-trolled door drive. The gearless asyn-chronous motor with frequency controller receives the control signals and operates the various door functions. Almost totally silent, extremely efficient and with an optimised action. Door monitoring systems.

The controller makes full use of high-per-formance door monitoring systems – from light barriers to lobby monitoring. The benefit: safety and security, lasting and effective.

Teleservice. Remote attendance round the clock. A microprocessor integrated in the con-troller monitors and supervises the eleva-tor system and, if required, various building services. All the tasks of an elevator attendant can be handled fully automatically.

Monitoring. An efficient instru-ment for visualising the status of the elevator system through the controller, evaluating traffic lev-els and controlling various elevator func-tions. The indicator system can also be controlled through the monitoring system.

Printer.

The current status of the elevator as deter-mined by the monitor-ing system can easily be documented.

TCM tester. The hand-held diagnostic unit for adjusting controller parameters. Laptop. A laptop simplifies diagnosis of the controller functions and enables indivi-dual parameters to be set or modified.

Suitable for Any Handling Capacity

and Any Application Profile.

Standard Group Controllers and

High End Solutions.

Effective call processing. The diagram illustrates the operation of the direction-sensitive collective-selective controller type 6513.

What are the characteristics of the user group? What require-ments are there when an eleva-tor is used in public, business or private premises, are there any special circumstances? We answer these (and other) ques-tions with the right controller. In other words: various types of controller are available depend-ing on the required handldepend-ing capacity and the relevant traffic pattern requirements. The main criterion is the amount of infor-mation exchanged between the controller, elevator system and user.

The non-direction-sensitive single-button controller type 6511.

With this type of control sys-tem, the elevator is called using a single call button regardless of the direction of travel and landing. For less frequently used residential and office buildings.

The direction-sensitive single-button controller type 6512.

This control system determines the required direction of travel when the elevator is called. The incoming commands are col-lected upwards and downwards and processed downwards towards the main landing. For residential and office buildings with moderate usage.

The direction-sensitive col-lective-selective controller type 6513.

The direct input of the required direction of travel makes for very efficient processing of the commands. A controller for residential and office buildings that is capable of coping with a high handling capacity and traffic requirements.

The direction-sensitive single-button duplex collec-tive controller type 6522.

This duplex control system determines the required direc-tion of travel when the elevator is called. The incoming com-mands are processed upwards and downwards in blocks towards the main landing. The exchange of information between the two controllers ensures optimum and rapid processing of the travel com-mands. For residential and office buildings with normal usage.

The direction-sensitive duplex collective controller for multiple groups type 6526.

Thyssocontrol Multican® com-bines the individual controllers within the groups and super-vises the „teamwork“: each individual controller schedules each elevator in the group in the most effective way and constantly monitors the overall traffic pattern. It reacts imme-diately to any new situations.

Rational and individual: structure and

scope of the controller and traffic flows

according to specific requirements.

The high-end solution – DSC destination selection controller type 6528.

The DSC destination selection controller is a new kind of ele-vator group controller for office blocks. The destination landing is determined when the eleva-tor is called.

The high-end solution „Artificial Intelligence“.

Expanding the system with an AI computer increases the con-trollers learning capacity. The controller gathers important information from the traffic pattern, which it retains for later use. For example, it parks more elevators at popular landings at certain times.

6

3

5

4

3

2

1

E

E

E

6

3

The DSC destination selec-tion controller. 100 % more information results in greater efficiencies in elevator groups.

The Thyssen DSC destination selection controller is based on the TCM-MC1 Thyssocontrol Multican®_{controller. Its special} feature: the exact destination landing (and direction of travel) is established when the call is made using ultra-modern touch screen terminals in the access area.

The controller therefore has all the information it requires; further inputs in the car are unnecessary. The DSC con-troller selects the most suitable elevator and transports the passenger directly to his desti-nation. Intermediate stops and empty car runs are reduced considerably, the handling capacity increases by up to 30 %. 6 5 4 3 2 1 6 5 6 6 5

1

2

3

Elevator 1 Elevator 2 Elevator 3

5 3

Traffic planning using arti-ficial intelligence (AI). For forecasting and maximum availability.

Equipped with the latest soft-ware technology and expand-able with an AI computer, the controllers are able to forecast where elevators should be positioned.

This means that alternative scenarios involving possible changes to the building layout or elevator usage can be analysed and retrieved imme-diately. The result is a clearly balanced and dynamic traffic flow. Destina-tion call Time Parking floor s

Traffic type

Mornings

Ground floor At random Canteen

Canteen Down-peak_outgoing

At random

floors Upper zone ofthe building Up-peak

Efficiency Delivering a High Degree

of Comfort and Low Costs.

Thyssocontrol Multican

in Conjunction

with Our Various Drive Concepts.

The perfect interaction between

con-troller and drive makes for a smooth

ride, protects mechanical components

and means substantial energy savings.

Innovation in motion.

The Thyssocontrol Multican® and the frequency-controlled Thyssen Isostop 60 drives work together as a unit. The compo-nents that provide the ultimate in ride quality: each ride in the elevator takes account of the body’s capacity for sensing movement – the elevator accelerates and stops gently and changes in speed are barely noticeable.

Thyssocontrol Multican®_and the Isostop 60 drive regulation system help reduce the running costs of your elevator system. The energy consumption of the entire system is reduced and its working life and availability increased.

Controller and drive in the Evolution®_.

In our new range of Evo-lution®_{elevators, which} require no machine room, the innovative Thyssen Mini gearless®_drive con-cept and the controller are situated in the vicinity of the headroom and take up very little space. The service platform is inte-grated in the control cabi-net, where it can be easi-ly accessed for

Example of geared drives: The TW 160. Powerful and adaptable.

The TW 160 traction drive with Isostop 60 and Thyssocontrol Multican®

in the machine room is full of the latest technology. Mo-derate dimensions, highly efficient, excellent running properties and an extremely rugged design are the distinguishing features of the drive system.

Example of an hydraulic drive. The alternative when space is at a premium and travel heights are short.

Where short travel heights or building constraints demand space-saving solutions, the hydraulic drive with pump unit and silent immersible motor is the solution.

Example of gearless drives:

The Thyssen Compact Gearless®_.

The smooth transition of medium to long travel heights.

This gearless drive with its very good running properties is destined for the higher performance cate-gories. The wide type range means there is a suitable machine for every performance category.

Isostop 60. As beneficial with geared drives as it is with gearless drives.

Isostop 60 can be employed irrespective of the type of drive. The parameters are transmitted to the Thyssocontrol Multican® through the CAN bus to achieve an optimum data flow. Thyssen Elevators always uses frequency-controlled technolo-gy with traction drive elevators.

Travel time curve of a frequency-controlled drive.

The figure demonstrates the homo-geneous ratio between travel speed (top) and input current (bottom).

The extremely smooth running nature of the motor also con-tributes significantly to the excellent ride quality. The rea-son behind this is the high clock frequency of the Isostop 60. In addition, using a fre-quency controller results in power savings of up to 40 % compared to conventional three-phase controllers. Includ-ing a reduced load on the mains and a low starting

cur-Electromagnetic compatibility.

Thyssocontrol Multican® controller systems comply with the European EMC recommen-dations and legislation. The necessary tests were carried out in Thyssen Elevator’s test laboratory.

Programmed for Individuality.

Productive Data Management.

The system advantages. Information, information.

Behind the integrated overall system of our controller lies more than 20 years’ experience in the field of distributed infor-mation processing. This tech-nology has proved itself over the years in the automotive sector. Reliable process stabili-ty, high transmission speeds and the maximum degree of transmission reliability are the decisive factors in this area. Our CAN bus technology addresses all these factors, for the future as well. Experience counts.

Microprocessors on every land-ing and in the car record the controller signals and process them straight away. The result: troublefree, adaptable traffic management by the shortest route. For a safe return on your investment and economic oper-ation.

Our controller

uses the CAN bus

system

architec-ture – the proven

platform for

intelli-gent

communica-tion.

Flexible software structures.

The modern Thyssocontrol Multican®_{controller responds in} an extremely flexible manner to changes in external circum-stances. All building-specific parameters are stored during a teach-in run while the system is being installed. If the traffic or usage pattern should subse-quently change, the new situa-tion can easily be catered for by performing a new teach-in run or by changing parameters „in situ“.

The diagram illustrates the CAN bus technology and the transfer of data between controller, landings and car.

Car calls, Acceptance signals, Indicators, Additionals Features, Door drives, Door protection systems

TCM-Control System

Communications

processor CPU Subassemblies

Drive speed controller Local bus Group bus Shaft bus Car bus

Information for all.

Top quality TFT colour screens at the accesses to the shafts enable textual information to be output through the monitoring system.

Thyssocontrol Multican

and Monitoring.

Check and Coordinate in a Matter of Seconds.

Focus: Diagnostics.

Only the latest technology is used to provide professional trou-bleshooting services, preventive error detection and the complete configuring of our elevators.

For example, our Windows diagnostics program that runs on a Notebook. For comparison purposes the controller always saves the 100 most recent events.

Monitoring with Windows NT. Thyssen Monitoring uses the latest version of Windows NT. In addition to numerous other analysis options, the monitoring system dis-plays the calls and locations of the elevators in real time. All data and results can naturally be output to a printer.

Monitoring encompasses four performance categories.

Our monitoring system gives you the big picture of your ele-vator system. The four perfor-mance categories covered by the monitoring system are ele-vator monitoring, the control of elevator functions, the acquisi-tion and evaluaacquisi-tion of traffic flow information and the control of the indicator system, for instance flat screens.

Our monitoring system pro-vides meaningful information on the status of the elevator system and visualisation using Windows NT. All critical opera-tional statuses and operaopera-tional faults are displayed on screen in an easy to read format. In addition, elevator move-ments can be clearly displayed and the corresponding traffic levels accurately assessed. Operation of the system is very simple thanks to a clear menu structure.

The Thyssen Elevator monitoring

system provides you with an

overview of your controllers, gathers

valuable information and delivers the

flexibility you require.

Hours

Thyssocontrol Multican

and Teleservice.

Emergency Calls and Remote Attendance Round

the Clock.

Systematically safe.

Teleservice is an intelligent system that permanently moni-tors your elevator systems. Teleservice makes full use of its components and the advan-tages of modern communica-tions technology to ensure your elevator systems run smoothly at all times: a stand-alone microprocessor integrated in the controller records opera-tional data, faults and emer-gency calls. In the event of a complication, Teleservice immediately activates trou-bleshooting functions automati-cally or, if necessary, calls up a Thyssen Service Center.

Remote diagnosis allows the current status of the system to be systematically analysed and the appropriate measures implemented. A countrywide network of service stations is available for this purpose 24 hours a day, 365 days a year.

High-quality solutions deserve the best.

Teleservice has been designed with the requirements of the customer firmly in the forefront and offers the clear advantages of a carefully thought out over-all concept. The commercial benefit derives on the one hand from the fact that the high availability of the systems means the traffic flow in your building is not disrupted. And on the other from the fact that Teleservice effectively takes over the role of the elevator attendant and so reduces your personnel costs.

Teleservice, in

other words,

safety, maximum

availability of your

systems and

significant cost

savings.

Always at your disposal. The Thyssen Service

Remote attendance round the clock.

Performance features

Performance features

Direction sensitive

Single-button common control 6513 Direction sensitive collective-selective control 6522 Direction sensitive Single-button duplex collective controller 6526 Direction sensitive Duplex collective controller for multiple groups 6528

DSC destination selective controller

Doors

Levelling with open doors Nudging device

(depending on type of door) Reduced reopening (depending on type of door) Reopening of the door (closing force limiting) Repeat door closing in case of landing door lock fault Landings

Selective open through Landing limiting Call accepted

LED or incandescent lamp Additions

Switching off of controller and light Occupied (80%) Overload (110%) Electrical recall operation of traction drive elevator Electrical recall operation of hydraulic elevator Priority up to group of 8 max. 60 landings / – – – up to group of 3 – max. 24 entrances /– –

Levelling indicator Traction drive elevator Levelling indicator Hydraulic elevator Adjust Temperature monitoring Lifting motor

Out of order indicator Collective fault signal Anti-creep device Standby supply Start interlocking Hours run counter Trip counter

Battery driven evacuation device

Fire service function Peak traffic Earthquake circuit Misuse „maximum number of passengers“ Misuse „empty car“ Misuse „internal call dele-tion at terminal landing“ Misuse „internal call dele-tion against direcdele-tion of movement“

Internal call deletion by user Door open button

Door close button Door safety system Load weighing

Position indication in the car Flashing car position indicator on arrival Special travel

Position indicator at the entrances

Door open time for internal and external calls and at the main landing Travel continues to next landing if door does not open

Continuation of group operation in the event of an elevator fault Preferred call assignment to elevator with least loading Home landing Encoding of landings – – only in main landing

Incomparable.

Features of the TCM-MC1

and the TCM-MC2.

Performance features

Voice announcement Door reopening as result of external call

Automatic return Call option for preferred elevator (3rd call button) Landing codes Automatic blocking of landings Call by key taster

Call by key switch and switch off

Immediate call assignment in the case of groups Arrival gong

Flashing position indica-tion / hall lantern Two-way intercom system Teleservice

TFT display (thin film transistor) AI group control computer Monitoring system Overlay system (for replacement phase) Implementation of any desired customer-specific requirements and functionality by means of contract-specific program expansions = standard = optional –= not available

All the features of our Thyssocontrol Multican® controllers can be provided to you as a detailed overview.

Please contact: ochur e c an be only be viewed essly in writing. Thyssen Aufzugswerke GmbH
