Metal-Clad Vacuum Breaker Switchgear—VacClad-W—Medium Voltage

General Description . . . 5.1-1

5 and 15 kV Switchgear—36.00-Inch Wide . . . 5.1-4

5 kV Switchgear—26.00-Inch Wide . . . 5.1-8

27 kV Switchgear—36.00-Inch Wide . . . 5.1-9

38 kV Switchgear—42.00-Inch Wide . . . 5.1-10

Arc-Resistant Switchgear . . . 5.2-1

Partial Discharge Sensing and Monitoring for Switchgear . . . 5.3-1

Technical Data. . . 5.4-1

Circuit Breakers . . . 5.4-1

Switchgear . . . 5.4-13

Standard Metal-Clad Switchgear Assembly Ratings . . . 5.4-15

Arc-Resistant Switchgear Assembly Ratings . . . 5.4-16

Surge Protection . . . 5.4-17

Control Equipment . . . 5.4-22

Control Schematics . . . 5.4-24

Relays—Device Numbers, Type and Function . . . 5.4-26

Main-Tie-Main Arrangements . . . 5.4-29

Layout Dimensions . . . 5.5-1

5 and 15 kV (Standard Metal-Clad) . . . 5.5-1

27 kV (Standard Metal-Clad). . . 5.5-11

38 kV (Standard Metal-Clad). . . 5.5-15

5 and 15 kV (Arc-Resistant Metal-Clad) . . . 5.5-19

27 kV (Arc-Resistant Metal-Clad) . . . 5.5-30

38 kV (Arc-Resistant Metal-Clad) . . . 5.5-34

Arc Exhaust Chamber (Plenum) Room Layouts . . . 5.5-38 Transfer Switches—Medium Voltage . . . See Tab 12 Specifications
