Split units TH with hermetic compressors

(1)

INTERCOM DEEC GmbH Schachtweg 3 D95659 Arzberg Seite 1 Tel.: +49 (0)9233/715570 Fax: +49 (0)9233/7155711 EMail: [email protected] Internet: www.bergcold.com

Errors, misprints and technical changes excepted. Status as of: 07.2013

with hermetic compressors

Split units series THM

Temperature range for normal refrigeration: 5°C / +12°C

Split units series THL

Temperature range for deep freezing: 15°C / 25°C

General features

• Selfsupporting soundinsulated weatherproof housing • R404A or R134a

• Electronic control panel with temperature display • Remote control panel

• Hermetic compressors with thermic protection • Evaporator as Cu/Alu finned heat exchanger • Aircooled or watercooled condenser • Expansion with capillary tube • Programmable automatic defrosting

• Condensing water direct discharge incl. heating • Winter controller

• Refrigerant charge for devices with screw terminals • Nitrogen gas for devices with solder terminals

Options

• Door contact switch • Cold room light • Different voltage • Master/Slave Function

• Data gathering and remote control

• CE approval • PED conformity • TÜF certification

Refrigeration units in split variant. Available with screw or solder terminal. Condensing unit with soundinsulated weatherproof housing for outdoor installation.

Cooling capacity calculation basis series THM

• Cold room insulation: 80 mm (100 mm from THM 470) • Product entering temperature: +25°C

• Product cooling time per day: 18 St. • Load density: 250 Kg/m³

• Product daily turnover: 10%

• Product specific heat (meat): 3,22 J/Kg°C

Cooling capacity calculation basis series THL

• Cold room insulation: 100 mm (120 mm from THL 300) • Product entering temperature: 7°C

• Product cooling time per day: 18 St. • Load density: 250 Kg/m³

• Product daily turnover: 10%

(2)

(*) These values relate only to the condensing unit

Optional items

A2 Precharged connection pipe 2,5 m A5 Precharged connection pipe 5 m A10 Precharged connection pipe 10 m A15 Precharged connection pipe 15 m AB Connection piece for refrigerant lines AC Brackets for wall mounting

AD Oil separator Type THM 100 THM 120 THM 150 Electrical values Voltage Volt / Ph / Hz Input W Current consumption A 230 / 1 / 50 654 3,44 230 / 1 / 50 853 4,18 230 / 1 / 50 911 4,24 THM 80 230 / 1 / 50 569 2,96 Compressor Type Power kW hermetic 0,370 hermetic 0,370 hermetic 0,440 hermetic 0,295 Condenser Fan: number / Ø mm Air volume: m³ / h 1 x 350 1945 1 x 350 1945 1 x 350 1699 1 x 350 1945 Pressure/Suction line Ø mm 10 / 12 10 / 12 10 / 12 10 / 12 Cooling capacity W

Cold room temperature °C at +32°C ambient temperature at +43°C ambient temperature +5 / 0 / 5 1167 / 1023 / 878 963 / 846 / 727 +5 / 0 / 5 1392 / 1230 / 1022 1136 / 1006 / 842 +5 / 0 / 5 1743 / 1519 / 1233 1449 / 1262 / 1028 +5 / 0 / 5 967 / 844 / 721 807 / 704 / 600 Evaporator Fan: number / Ø mm Air volume: m³ / h Air throw m Expansion 1 x 200 630 3 expansion valve 2 x 200 1230 3,5 expansion valve 2 x 200 1230 3,5 expansion valve 1 x 200 630 3 expansion valve

Sound level dba 10 m (*) 33 33 33 35

Kind of defrosting electrical electrical electrical electrical

Weight Kg 61 63 66 77

Cooling capacity m³

Cold room temperature °C at +32°C ambient temperature at +43°C ambient temperature +5 / 0 / 5 10,5 / 6,8 / 5,3 7,5 / 4,8 / 3,9 +5 / 0 / 5 13,4 / 8,9 / 6,7 9,5 / 6,2 / 4,8 +5 / 0 / 5 17,9 / 11,8 / 8,7 13,1 / 8,6 / 6,4 +5 / 0 / 5 8,0 / 5,1 / 4,1 5,8 / 3,7 / 3,1

B Model with R134a C Different voltage L Voltage monitor

M Differential thermomagnetic switch N Master/Slave Function

O Data gathering and remote control

Construction type 1A 1A 1B 1B THM 170 230 / 1 / 50 1078 5,01 hermetic 0,735 1 x 350 1699 10 / 16 +5 / 0 / 5 1992 / 1748 / 1415 1660 / 1458 / 1191 2 x 200 1230 3,5 expansion valve 36 electrical 78 +5 / 0 / 5 21,3 / 14,2 / 10,5 15,6 / 10,4 / 7,8 1B • Screw or solder terminals

(3)

(4)

THM 200 THM 250 THM 340 230 / 1 / 50 1303 5,94 230 / 1 / 50 1433 6,89 400 / 3 / 50 1904 5,18 hermetic 0,825 hermetic 0,920 hermetic 1,100 1 x 400 2734 1 x 400 2734 1 x 400 2580 10 / 16 10 / 16 10 / 16 +5 / 0 / 5 2628 / 2261 / 1895 2209 / 1895 / 1582 +5 / 0 / 5 2907 / 2527 / 2156 2448 / 2126 / 1811 +5 / 0 / 5 3923 / 3410 / 2898 3277 / 2850 / 2421 2 x 200 1170 3,5 expansion valve 2 x 250 1602 7,5 expansion valve 3 x 250 2364 7,5 expansion valve 38 40 41

electrical electrical electrical

96 103 117 +5 / 0 / 5 30,6 / 19,9 / 15,6 22,6 / 14,6 / 11,4 +5 / 0 / 5 34,8 / 22,9 / 18,2 25,8 / 17,0 / 13,6 +5 / 0 / 5 50,8 / 33,7 / 26,8 37,5 / 24,8 / 19,7 1B 2A 2B THM 370 400 / 3 / 50 2029 5,32 hermetic 1,470 1 x 400 2580 10 / 16 +5 / 0 / 5 4339 / 3777 / 3224 3581 / 3090 / 2601 3 x 250 2364 7,5 expansion valve 42 electrical 124 +5 / 0 / 5 57,3 / 38,2 / 30,5 41,8 / 27,5 / 21,6 2B Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

Cold room temperature °C at +32°C ambient temperature at +43°C ambient temperature Evaporator Fan: number / Ø mm Air volume: m³ / h Air throw m Expansion

Sound level dba 10 m (*) Kind of defrosting Weight Kg

Cold room temperature °C at +32°C ambient temperature at +43°C ambient temperature

Construction type

(*) These values relate only to the condensing unit • Screw or solder terminals

• Evaporator

Optional items

AD Oil separator

B Model with R134a C Different voltage L Voltage monitor

(5)

(6)

THM 470 400 / 3 / 50 2579 6,16 hermetic 1,840 1 x 450 4266 10 / 22 +5 / 0 / 5 5474 / 4752 / 4023 4537 / 3910 / 3273 3 x 250 2167 7 expansion valve 45 electrical 138 +5 / 0 / 5 75,3 / 50,8 / 40,1 55,6 / 36,8 / 28,7 2B THM 600 400 / 3 / 50 3411 8,91 hermetic 2,200 1 x 450 4031 10 / 22 +5 / 0 / 5 7151 / 6337 / 5546 5857 / 5135 / 4421 4 x 250 2890 7 expansion valve 48 electrical 155 +5 / 0 / 5 104 / 78,9 / 62,6 75,1 / 54,4 / 42,9 2C Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

Optional items

AC Brackets for wall mounting AD Oil separator

B Model with R134a C Different voltage

L Voltage monitor

O Data gathering and remote control • Solder terminals

(7)

(8)

THM 730 400 / 3 / 50 3775 8,41 hermetic 3,310 2 x 450 7906 12 / 22 +5 / 0 / 5 8470 / 7313 / 6177 7000 / 5979 / 4975 3 x 350 4078 13,9 expansion valve 52 electrical 188 +5 / 0 / 5 127 / 95,2 / 75 93,3 / 68,4 / 50,5 3A THM 880 400 / 3 / 50 4507 10,10 hermetic 3,675 2 x 450 7906 12 / 28 +5 / 0 / 5 10138 / 8840 / 7596 8285 / 7148 / 6050 3 x 350 5990 16,2 expansion valve 53 electrical 202 +5 / 0 / 5 157 / 118 / 94,5 113 / 84,4 / 67,1 3B THM 1000 400 / 3 / 50 5223 11,59 hermetic 4,410 2 x 450 7125 12 / 28 +5 / 0 / 5 11973 / 10536 / 9175 9731 / 8472 / 7267 4 x 350 7987 20,7 expansion valve 53 electrical 226 +5 / 0 / 5 190 / 144 / 115 136 / 102 / 80,6 3C Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

(*) These values relate only to the condensing unit • Solder terminals

• Evaporator

Optional items

B Model with R134a C Different voltage

L Voltage monitor

(9)

(10)

THL 50 THL 58 THL 88 230 / 1 / 50 665 4,11 230 / 1 / 50 710 3,41 230 / 1 / 50 1059 4,95 THL 45 230 / 1 / 50 574 3,63 hermetic 0,440 hermetic 0,550 hermetic 0,735 hermetic 0,370 1 x 350 1945 1 x 350 1945 1 x 350 1699 1 x 350 1945 10 / 12 10 / 12 10 / 12 10 / 12 15 / 20 / 25 617 / 511 / 414 487 / 400 / 319 15 / 20 / 25 707 / 589 / 478 561 / 463 / 371 15 / 20 / 25 1061 / 885 / 723 865 / 717 / 580 15 / 20 / 25 566 / 479 / 397 445 / 372 / 303 1 x 200 630 3 expansion valve 1 x 200 630 3 expansion valve 1 x 200 600 3 expansion valve 1 x 200 630 3 expansion valve 33 34 38 31

electrical electrical electrical

electrical 69 70 74 61 15 / 20 / 25 3,3 / 2,5 / 1,5 2,3 / 1,7 / 1,1 15 / 20 / 25 4,0 / 3,0 / 1,9 2,8 / 2,0 / 1,4 15 / 20 / 25 7,2 / 5,7 / 3,8 4,9 / 3,7 / 2,4 15 / 20 / 25 3,1 / 2,4 / 1,5 2,1 / 1,6 / 1,1 1A 1A 1A 1A THL 100 230 / 1 / 50 1415 6,62 hermetic 1,100 1 x 350 1699 10 / 16 15 / 20 / 25 1339 / 1119 / 913 1086 / 906 / 735 3 x 200 684 3,5 expansion valve 40 electrical 78 15 / 20 / 25 10,6 / 8,4 / 5,6 7,2 / 5,6 / 3,7 1B Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

Optional items

AD Oil separator C Different voltage L Voltage monitor

O Data gathering and remote control • Screw or solder terminals

(11)

(12)

THL 150 THL 230 400 / 3 / 50 1969 4,23 400 / 3 / 50 2397 5,41 hermetic 1,470 hermetic 2,200 1 x 400 2734 1 x 400 2734 10 / 16 10 / 16 15 / 20 / 25 1945 / 1590 / 1261 1565 / 1267 / 993 15 / 20 / 25 2724 / 2309 / 1947 2148 / 1796 / 1484 2 x 250 1602 7,5 expansion valve 3 x 250 2364 7,5 expansion valve 41 42 electrical electrical 115 123 15 / 20 / 25 19,6 / 15,1 / 9,5 13,1 / 10,0 / 6,2 15 / 20 / 25 33,5 / 27,7 / 19,5 22,1 / 17,9 / 12,2 2A 2B Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

(*) These values relate only to the condensing unit • Solder terminals

• Evaporator

Optional items

AD Oil separator C Different voltage L Voltage monitor

(13)

(14)

THL 300 THL 380 400 / 3 / 50 3357 7,08 400 / 3 / 50 4054 9,08 hermetic 2,940 hermetic 3,675 1 x 450 4266 1 x 450 4266 12 / 22 12 / 22 15 / 20 / 25 3631 / 3019 / 2482 2925 / 2411 / 1956 15 / 20 / 25 4567 / 3870 / 3257 3587 / 3009 / 2491 3 x 250 2167 7 expansion valve 4 x 250 2890 7 expansion valve 45 46 electrical electrical 152 164 15 / 20 / 25 52 / 41,3 / 28 35,3 / 27,9 / 18,6 15 / 20 / 25 73,8 / 63,6 / 42,2 48,4 / 38,8 / 26,8 2B 2C Type Electrical values Voltage Volt / Ph / Hz Input W Current consumption A Compressor Type Power kW Condenser Fan: number / Ø mm Air volume: m³ / h Pressure/Suction line Ø mm Cooling capacity W

Optional items

C Different voltage L Voltage monitor

O Data gathering and remote control • Solder terminals

(15)
