Civil 3D Handout 2010

(1)

AutoCAD Civil 3D 2010

P.0

A U T O D E S K @ R H O - E N G . C O M

B Y

S M A D I M .

MSc Transportation Engineering Infra Structures and Highway Design Engineer Autodesk Authorized AutoCAD Civil 3D Instructor

[email protected]

(2)

AutoCAD Civil 3D 2010

Course Name:

Highway Design and Quantity Surveying using AutoCAD Civil 3D 2010

Course Description:

This course will review the basic parameters for highway design, and introduce AutoCAD Civil 3D 2010 as a tool to create a surveying plans, and how to lay out roadways and subdivision lots. The course will focus on the creation of road profiles, corridors and cross sections, also the generation of quantities takeoff sheets for earthworks and pavement layers.

Credit Hours:

18 hours distributed on three weeks

Attendance:

Civil Engineers and Civil Engineering Technicians as: Land Surveyors and Quantity Surveyors

Prerequisites:

 Highway Design Parameters Background

 AutoCAD basic knowledge

 Microsoft office basic knowledge, namely (MS Excels and MS word)

Task:

Each Trainee shall submit a full project as a show case of his proficiency of using AutoCAD Civil 3D.

Certification:

 Each one success to handle the task will receive an Autodesk brand Certificate of completion

Earn a valuable certificate of completion that’s recognized in your profession and validate your product knowledge as an Autodesk Certified User or Autodesk Certified Expert when you take a certification exam at a participating ATC test delivery facility.

(3)

AutoCAD Civil 3D 2010

P.2 Course Outline

Stage –I

6 Hours

Includes:



Road geometrical design overview



Understanding user interface



Importing surveying Data:

o Points

o 3D polylines (GIS, Countours, breaklines)

o Google earth



Creating surfaces and contours



Editing surfaces



Creation of road alignment



Design of horizontal curves



Creating alignment superelevation



Create alignment offsets and widening

Stage -II

12 Hours

Includes:



Working with profiles:

o Creation of road center line existing profile

o Creation of road centerline design profile

o Design of vertical curves

o Tabular output of profile elevations



Working with Corridors

o Creating existing ground cross sections

o Definition of assembly

 Basic assembly

 Super elevation and transition assembly

 Assembly with median

o Creating Coridors

o Creating design cross sections



Compute materials:

o generating cut and fill quantities takeoff sheets

o generating materials quantities



Selected Advanced Topic

(elective topics)

o Working with intersections

o Drawings production

o Takeoff / pay items

o Importing land project

o Design to local codes

o Creating customized subassemblies

o Sharing assemblies (creating palettes and Catalog)

o Parcels & Grading objects

o Combined Cross Sedctions

o Tips & Tricks

(4)

What is the new in AutoCAD Civil 3D comparing to LAND?



Automatic Dynamic link between Plan–Profile–Cross Sections,



Ease to modify plan and/or profile by just moving the vertices (PI’s),



Easier drawing format and production,



Connected to Google earth,



Built-in Cross Sections templates,



Everything in one drawing; No project folders,



Intersection Design Tools,



Extension of existing alignment and/or profile,



Design check



Labeling existing ground for cross sections at grade break



Maintain pavement layers side slope (i.e. 3:1) while changing offset according to super

elevation.

(5)

AutoCAD Civil 3D 2010

P.4

1.1 U

NDERSTAND

U

SER

I

NTERFACE

The application menu contains common

command, such as New, Open and Save.

Quick Access Toolbar Contains frequently used commands

The ribbon provides a single, compact

location for commands that are relevant

to the current task.

The Ribbon is

divided into Task

Based Tabs

Tools in each ribbon tabs are organized in panels.

At the bottom of a ribbon panel, click a

drop-down button to display additional tools.

Tool space enables you to manage the objects, styles, and default

settings in the drawings

The prospector tab provides you

with a categorized view of all

civil objects in the drawing.

As an object created, it is placed

in the appropriate subcategory

The setting tab contains a tree

structure of the object styles and

setting for the drawing. Like the

prospector tab, it has object

collection at several levels.

Use the survey tab to manage

survey projects, data, and

settings.

Tool palettes provide access to a

variety of tools and content. The

default tool palettes contain

corridor subassemblies and

assemblies.

(6)

1.2 E

DIT

D

RAWING

S

ETTINGS

Right click on drawing name in setting tab and select edit drawing settings.

You can change settings from units and zone tab. Also there is a tab to customize the used abbreviations.

1.3 I

MPORTING

S

URVEYING

P

OINTS

Importing points, such as survey point data collected by a data collector, is a quick and effective way to place points into a drawing. Before you import points, you must create a point file format that describes the layout of the point data in the point data file.

To insert points into drawings

To view point’s elevation

Home Tab Import Surveying _Data

Create New Surveying

Database

Specify Data Source Type

Locate Source File Specify point file

format Create new network Specify Import settings Survey Tab in Tool Space Expand Networks Rt. Click Non Control Points points insert points into drawing

Prospector

tab

Point Groups Click LABEL Column (at bottom) Select Preferable Lable Style

(7)

AutoCAD Civil 3D 2010

P.6

Also we can change label style

To Create Point Groups

To Select Point Style

Prospector

tab

Rt. Click Point Groups New

Information

tab

Name point group select point style

Include Tab

number √ with matching

selection set in drawings

(8)

1.4 C

REATING A

T

IN

S

URFACE

The contours will be created automatically as defined in the style above.

Prospector

tab

Drawing

Name

Rt. Click

surface

Create

Surface

Create

Surface

Dialog

Surface

Name

Style

Explore

New Suface

Defenition

Add point File / Point Group

Add

Breaklines/B

(9)

AutoCAD Civil 3D 2010

P.8 Adding Boundary

Contour Labels:

Prospector tab Drawing

Name Rt. Click surface Add Label

Add Labels Dialog Feature: Surface Type: Contour Multible

Add & Draw labe Group sellect Label Group Polyline Label Properties Display Contour Label: False

Non-destructive breakline

Not as breakline

(10)

To view quick profile:

Clicking on the surface will display it’s tab:

Draw

polyline

Rt. Click on

polyline

Quick

Profile

Quick

Profile

Dialog

select

Surface &

Profile View

Type:

Contour

Multible

Note that the created quick

profile is dynamically

linked with the polyline,

i.e. when moving and/or

stretching polyline vertices

the profile will respond

automatically

If you edit a

surface, you

need to

rebuild it

(11)

(12)

1.5 C

REATING

A

LLIGNMENTS

Creat

Allignment

Name Allignment Set Label Style

Design

Criteria

√use criteria-based design Select Default Criteria

Draw

Allignment

Tan-Tan (with Curves) Draw allignment

When selecting

tangents,

allighnment tab is

displayed

Also alignment layout

tool is activated too..

(13)

AutoCAD Civil 3D 2010

P.12 Minimum radius violation:

Alignment

Grid View

Change

Radius

Add

Labels

Label Type:

STA-Offset Sellect Styl

Add

labels

Multiple Segments

Alignment

Tab

Inquiry Select Inquiry type

(14)

Add

Tabels

Add Curve Sellect Label style Locate Curve Table

Click on

Tangent

Allignment Properties

Super

elevation

Tab

Set Super elevation properties

Superelevation:

(15)

AutoCAD Civil 3D 2010

P.14

Design Rules

In this section you specify the tables to use for superelevation rate, transition length, and attainment method.

Design Speed

Displays the design speed for the curve group. This value is derived from the Design Criteria tab of the Alignment Properties. If the curve group has two or more design speeds, the highest design speed is displayed.

Design Criteria File Name

Specifies the name of the design criteria file. This file defines minimum radius tables, superelevation attainment methods and formulae, superelevation rates and transition lengths for various roadway types and design speeds. Click in the cell to browse to the location of the design criteria file.

Superelevation Rate Table

Specifies the name of the superelevation rate table used to determine the maximum superelevation rate for the curve group. Click the arrow to display a list of the superelevation rate tables associated with the specified design criteria file.

Transition Length Table

Specifies the name of the superelevation transition length table used to calculate the transition stations for the curve group. Click the arrow to display a list of the transition length tables associated with the specified superelevation rate table.

Attainment Method

Specifies the name of the superelevation attainment method for the curve group. Click the arrow to display a list of the attainment methods associated with the specified design criteria file.

Default Options

In this section, you specify the general settings used to calculate superelevation specifications.

Corridor Type

Specifies the type of roadway as Undivided (single carriage way) or Divided (dual carriage way).

Cross Section Shape

Specifies the cross sectional shape of the roadway as Planar or Crowned:

 Planar: There is no change in slope between the travel lanes.

 Crowned: When no superelevation is applied, travel lanes slope downward in opposite

directions from a common crown point.

Highside Location

Specifies the default Highside Location for planar roads.

 Left Edge: Specifies that the high side of the roadway is on the left edge on tangent

(unsuperelevated) sections when the corridor type is Undivided and the Cross Section Shape is planar.

 Level: The roadway is level (0% slope) on tangent sections.

 Right Edge: Specifies that the high side of the roadway is on the right edge on tangent

(unsuperelevated) sections, when the corridor type is Undivided and the Cross Section Shape is planar.

(16)

Nominal Width - Pivot To Edge

Specifies the typical width of the roadway from the superelevation pivot point to the outer edge-of-traveled way. Some superelevation attainment methods require that you specify this value in order to calculate the length of the superelevation transition.

Outside Shoulder Superelevation Method

Specifies the method that is applied to the outside shoulder during superelevation:

 Default Slopes: Default slopes are retained and shoulders are not superelevated.  Match Lane Slopes: Shoulder slopes match the slopes applied to the adjacent traveled

ways through out the superelevation process.

 Breakover Removal: Shoulders on the outside edge of the curve are adjusted upward

to match the Normal Lane Slope (%) before the lane begins to superelevate. The high-side shoulder slope matches the high-high-side lane slope throughout the superelevation process, and it then rotates downward back to the Normal Shoulder Slope (%) value when the lanes are back to the un-superelevated condition.

Inside Shoulder Superelevation Method

Specifies the method that is applied to the inside shoulder during superelevation:

 Default Slopes: Default slopes are retained and shoulders are not superelevated.  Match Lane Slopes: Shoulder slopes match the slopes applied to the adjacent traveled

ways through out the superelevation process.

 Breakover Removal: Shoulders on the outside edge of the curve are adjusted upward

to match the Normal Lane Slope (%) before the lane begins to superelevate. The high-side shoulder slope matches the high-high-side lane slope throughout the superelevation process, and it then rotates downward back to the Normal Shoulder Slope (%) value when the lanes are back to the unsuperelevated condition.

R

EPORTS

M

ANAGER

:

Tool

Space

Paletts Tool Box

Reports

Manager Allignment

Incremental

Sta. Report Rt. Clic & Excecute

If you are adding superelevation to any alignments,

do so before creating the corridor. Also, the

superelevation data is not dynamic, so it does not

update if you grip-edit the alignment. Therefore, add

the superelevation after the alignment design is

stable, or be prepared to redo the superelevation if

the alignment is modified.

(17)

AutoCAD Civil 3D 2010

P.16 A

LLIGNMENT

O

FFSET

:

You can also use AutoCAD offset command.

A

LLIGNMENT

W

IDENING

:

Each Created offset are linked to the alignment,

and can be editing for widening application as

shown herebelow:

(18)

2.1 C

REATING

P

ROFILES

Create surface profile:

Home

Tab

Create Design Profile Create Surface Profile Create Profile Tab Select Allignment Select

Surface Press ADD Draw in Profile View

(19)

AutoCAD Civil 3D 2010

P.18 Create Design profile:

Home

Tab

Profile Profile Creation Tool Profile Layout Tool Draw Tangents Select Tangent Free Vertical Curve Profile View Properties HATCH TAB ADD Cut&Fill

Hatch Band Tab

Style: Elevations & Sta.

Profile1: Surface

Profile2: latout

(20)

Rt. Click on

Profile

(Tangent)

Edit Labels Here you can modify Labels

(21)

AutoCAD Civil 3D 2010

P.20

2.1 C

REATING

E

XISTING

C

ROSS

S

ECTIONS

Home

Tab

Sample Line Select Allignment

By range of Stations

(22)

To Change Section Scale:

To Plot Sections by page:

To Modify All sections at once:

Home

Tab

Section Views Create Multiple Views Create Section View Properties Sections Tab Click on Label Column Select Grade Breaks Type EG section offset & Elev.

Add & Change weedings to i.e. 5m

Section View Tab

(Click on section)

Edit Section View

Style Graph Tab ExaggerationVertical

Section View Tab

(Click on section)

View group properties Group: Plot by page Vertical Exaggeration

Section View Tab

(Click on section)

View group

(23)

AutoCAD Civil 3D 2010

P.22

2.2 C

REATING

C

ORRIDOR

A

SSEMBLY

Assembly

_AssemblyCreate _{insertion point}Specify _automaticlywill zoom

Basic Lane

3.60m _widht 0.72m _depth -2.00% _slope

Basic

shoulder

1.80m widht 0.72m depth -4.00% slope

Basic Side slope cut

ditch

set criteria

Mirror

Subassemblies

Home Tab

Corridor Create Simple _Corridor

Selection

Allignment Profile Assembly

Target Maping

Dialog

click here to select all

select existing surface

(24)

2.3 C

REATING

D

ESIGN

C

ROSS

S

ECTIONS

2.4 E

ARTHWORK

Q

UANTITY

Home Tab

Section Views Create Multiple _Views

Section Display

option

as shown

Data Band

select band set:

Major Sta. offset & Elevation

Prospector

Tab

Rt. Click created

Corridor Properties

Surface Tab

Create a corridor _surface _Datumsellect Add

Boundary

Tab

Rt. Click surface name

add

Automaticly daylight ok

Modify Tab

Section _View sample more _sources select any _section

Section

Sources

select available

source: corridor Add ok

Section

View

Tab

Compute materials OK Earthwork Select Exist.

Ground & Datum OK

Analyze

Tab

Total Volume

Table OK

Inset Table(s) into drawing

(25)

AutoCAD Civil 3D 2010

P.24

2.5 C

REATING

C

ORRIDOR ASSEMBLY WITH WIDENING

&

SUPERELEVATION

Assembly

_AssemblyCreate _{insertion point}Specify _automaticlywill zoom

Lanes Tab

Lane outside _super 7.20m _widht 0.62m _layers -2.00% _slope

shoulder Tab

_{Extend all}Shoulde 1.80m _widht 0.62m _layers -4.00% _slope

Daylight Tab

Daylight General

Mirror

Subassemblies

(26)



Widening will be generated and the cross sections will be updated automatically…



We can also make widening using offset allighnment.

Home Tab

Corridor Create Simple _Corridor

Selection

Allignment Profile Assembly _tergetsset all

Target Maping

Dialog

click here to select all select existing surface Set all targets width allignment

select object from

drawing

Rt.

Widening

object

(27)

AutoCAD Civil 3D 2010

P.26

2.6 W

ORKING WITH

I

NTERSECTIONS

Home

Tab

Create Design

Panel Intersection

Select

I/S point Primary _Road

General

Tab

Select Corridor Tpe: Primary Road Crown?

Geometry

Offse Parameter:_{Fix Lane offsets} Curb Return:_{fix raduii}

Corridor Region

Create

Corridor Surface to daylight

Curb Return Assembly Through Assembly Full Assembly Part-Rt. full Half-Rt. Full

(28)

(29)

AutoCAD Civil 3D 2010

P.28

2.7 W

ORKING WITH

P

ARCELS

:

Home Tab

Parcels Create Parcel _{from object} _{polyline ←}select

Create

Parcel

SingleFamily Name, Square meters & Acres

Parcel

Parcel Creation _Tool Free Form Create Slice into _zones

Parcel

Parcel Creation _Tool select Parameters' _Value Slide Line _Create

Multiple Parcels Properties Draw poly crossing parcels Custumize Area lable style Apply to All
