Libelium Products Catalogue

(1)

2011

wireless sensor networks

catalogo

_catalogue

(2)

Products Catalogue

Index

Waspmote

1. 1.1 1.2 1.2.1 1.2.2 1.3 1.4 1.5 1.6

Meshlium

2. 2.1 2.2 2.3

Orders

3. Waspmote Connectivity Sensor integration

Sensor integration boards Sensors

Waspmote enclosures Custom hardware design Power supply options Extracting the data

Meshlium

Meshlium models Storage

Power supply options

Order placement 4 7 12 13 14 18 19 20 21 26 28 30 31 33

(3)

Products Catalogue

Waspmote

Sensing anywhere

Sensing anytime

(4)

Products Catalogue

1. Waspmote

Waspmote is a sensor device developers oriented. It works with different communicaction protocols (ZigBee, Bluetooth and GPRS) and frequencies (2.4GHz, 868MHz, 900MHz) and create links up to 12Km. Using the hibernate low power mode (0.7uA) it can save battery energy when not transmitting and be able to work even for years. Waspmote is compatible with more than 50 sensors and its open source IDE makes really easy to start working with it.

If you are facing a project on sensor networks for the first time, you can check on the following link http://www.libelium.com/applications. This section describes success stories and examples of network topologies used, sensors used, application services, etc.

This catalog shows step by step all the configuration settings available for sensor networks formed by Waspmote: Step 1: Radio connectivity Step 5: Data extraction Step 2: Optional complements Step 3:

Boards and sensor integration

Step 4: Power supply options

Waspmote sensor device

(5)

Products Catalogue

Waspmote

Waspmote specifications:

Microcontroller ATmega1281 Power 3.3V - 4.2V

Frequency 8MHz Input / Output 7 x analog 8 x digital (I/O) 1 x PWM 2 x UART 1 x I2C 1 x USB SRAM 8KB FLASH 128KB EEPROM 4KB Power consumption Hibernate g 0.7uA Sleep g 62uA Deep Sleep g 62uA ON g 9mA SD card 2GB Waspmote sensors on board Temperature [-40ºC, 85ºC] Accelerometer ± 2g (1024LSb/g) / ± 6g (340LSBb/g) Temperature range -20ºC, +65ºC Weight 20g Dimensions 73.5 x 51 x 13mm Certificacions:

CE (Europe), FCC (USA), IC (Canada).

Programming environment:

Programming with Waspmote has a fast learning curve. The programming language used is C + +, widely known by developers of embedded devices. In addition, Waspmote offers an Open Source API to program using high level functions without having to deal with hardware-specific commands.

(6)

Products Catalogue

Getting support:

• For more information on specifications, see the documents online Waspmote:

Technical Guide and Waspmote: Datasheet found in the Support section:

http://www.libelium.com/support/waspmote

• Once you purchase the product, technical questions can be resolved completely free of charge through our forum: http://www.libelium.com/forum/

• In the Development section (http://www.libelium.com/development/waspmote) you can download the compiler, available for Windows, Linux and Mac-OS, the latest version of the API libraries, programming guides of all the Waspmote modules and accessories, code samples and tutorials.

• Finally, we offer training and consulting services to help all those who wish to develop projects with our products. For inquiries, please contact our sales department: [email protected]

Additionally, we offer optimization services and hardware customization, in order to obtain a board with the minimum and essential components for the desired background. More information: http://www.libelium.com/products/services

i

(7)

Products Catalogue

1.1 Connectivity

Waspmote models:

Waspmote model is determined by the selected radio communication. The following table compares the features of all available options according to protocol, frequency and type of antenna connector:

Communication

radio Frequency

Use

zone Protocol

SMA A) _UFLB) _On-chipC)

Power Distance1 _Power _Distance2 _Power _Distance3

802.15.4 2.4GHz World Wide 802.15.4 1mW 500m 1mW 430m 1mW 100m 802.15.4 - PRO 63mW 7Km 63mW 5.95Km 63mW 360m ZB _{ZigBee -} Pro 2mW 500m 2mW 430m 2mW 100m ZB - Pro 50mW 7Km 50mW 5.95Km 50mW 360m 868 868MHz Europe RF 315mW 12Km 315mW 10.2Km - -900 900MHz USA & Canada 50mW 10Km 50mW 8.5Km - -XSC 100mW 12Km 100mW 10.2Km - -Bluetooth 2.4GHz World Wide Bluetooth 2.0 1.78mW 250m - - -

-* Mini-USB cable for programming Waspmote included in all models.

A) SMA antenna connector B) UFL antenna connector C) On-chip antenna

1. Tests performed with 5dBi omnidirectional antennas and line of sight.

2. Tests performed with 5dBi omnidirectional antennas and line of sight. Pigtail has an impedance of 50ohm. 3. Distance measurements were made with integrated fractal antenna.

(8)

Products Catalogue

Waspmote price chart depending on model:

As seen in the following chart, each Waspmote model can have 2 types of antennas: 2dBi or 5dBi for 2.4GHz models and 0dBi or 4.5 dBi for the rest of frequencies.

Model Ref. Price Ref. (5 pack) Price (5 pack)

Waspmote 802.15.4 SMA 2dBi W802-SMA2 135 € W802-SMA2-P5 675 € Waspmote 802.15.4 SMA 5dBi W802-SMA5 138 € W802-SMA5-P5 690 € Waspmote 802.15.4 UFL 2dBi W802-UFL2 135 € W802-UFL2-P5 675 € Waspmote 802.15.4 UFL 5dBi W802-UFL5 138 € W802-UFL5-P5 690 € Waspmote 802.15.4 on chip W802-CHIP 130 € W802-CHIP-P5 650 € Waspmote 802.15.4-PRO SMA 2dBi W802P-SMA2 155 € W802P-SMA2-P5 775 € Waspmote 802.15.4-PRO SMA 5dBi W802P-SMA5 158 € W802P-SMA5-P5 790 € Waspmote 802.15.4-PRO UFL 2dBi W802P-UFL2 155 € W802P-UFL2-P5 775 € Waspmote 802.15.4-PRO UFL 5dBi W802P-UFL5 158 € W802P-UFL5-P5 790 € Waspmote 802.15.4-PRO on chip W802P-CHIP 150 € W802P-CHIP-P5 750 € Waspmote ZB SMA 2dBi WZB-SMA2 135 € WZB-SMA2-P5 675 € Waspmote ZB SMA 5dBi WZB-SMA5 138 € WZB-SMA5-P5 690 € Waspmote ZB UFL 2dBi WZB-UFL2 135 € WZB-UFL2-P5 675 € Waspmote ZB UFL 5dBi WZB-UFL5 138 € WZB-UFL5-P5 690 € Waspmote ZB on chip WZB-CHIP 130 € WZB-CHIP-P5 650 € Waspmote ZB-PRO SMA 2dBi WZBP-SMA2 155 € WZBP-SMA2-P5 775 € Waspmote ZB-PRO SMA 5dBi WZBP-SMA5 158 € WZBP-SMA5-P5 790 € Waspmote ZB-PRO UFL 2dBi WZBP-UFL2 155 € WZBP-UFL2-P5 775 € Waspmote ZB-PRO UFL 5dBi WZBP-UFL5 158 € WZBP-UFL5-P5 790 € Waspmote ZB-PRO on chip WZBP-CHIP 150 € WZBP-CHIP-P5 750 €

(9)

Products Catalogue

Waspmote 868 SMA 0dBi W868-SMA0 233 € W868-SMA0-P5 1165 € Waspmote 868 SMA 4.5dBi W868-SMA4 233 € W868-SMA4-P5 1165 € Waspmote 868 UFL 0dBi W868-UFL0 233 € W868-UFL0-P5 1165 € Waspmote 868 UFL 4.5dBi W868-UFL4 233 € W868-UFL4-P5 1165 € Waspmote 900 SMA 0dBi W900-SMA0 183 € W900-SMA0-P5 915 € Waspmote 900 SMA 4.5dBi W900-SMA4 183 € W900-SMA4-P5 915 € Waspmote 900 UFL 0dBi W900-UFL0 183 € W900-UFL0-P5 915 € Waspmote 900 UFL 4.5dBi W900-UFL4 183 € W900-UFL4-P5 915 € Waspmote XSC SMA 0dBi WXSC-SMA0 183 € WXSC-SMA0-P5 915 € Waspmote XSC SMA 4.5dBi WXSC-SMA4 183 € WXSC-SMA4-P5 915 € Waspmote XSC UFL 0dBi WXSC-UFL0 183 € WXSC-UFL0-P5 915 € Waspmote XSC UFL 4.5dBi WXSC-UFL4 183 € WXSC-UFL4-P5 915 € Waspmote Bluetooth SMA 2dBi WBT-SMA2 140 € WBT-SMA2-P5 700 € Waspmote Bluetooth SMA 5dBi WBT-SMA5 143 € WBT-SMA5-P5 715 €

Waspmote

Waspmote price chart depending on model (continuation):

(10)

Products Catalogue

Optional complements for Waspmote:

Module Characteristics Ref. Price

GSM / GPRS

Model: HiLo (Sagem)

Quadband: 850MHz / 900MHz / 1800MHz

/ 1900MHz (worldwide usage)

Sensitivity: -106dBm External antenna: 0dBi (UFL) Actions: make/receive calls, SMS,

TCP/IP sockets

WGPRS 85 €

GPS

Model: A1084 (Vincotech) Sensitivity in motion: -159dBm Acquisition sensitivity: -142dBm Hot Start: <1s

External antenna: 2.4dBi (UFL) Available information: latitude,

longitude, altitude, speed, heading, date / time and handling of events.

WGPS 65 €

SD card 2 GB (5 cards pack) WSD 40 € Expansion Radio Board This board enables to connect two radios in

order to work with them at the same time. WEXP 40 €

Waspmote GSM / GPRS module Waspmote GPS module

(11)

Products Catalogue

Expansion Radio board

This board enables to connect two radios in order to work with them at the same time. Possible connection examples:

• 802.15.4/ZigBee (2.4GHz) - 802.15.4/ZigBee (868MHz/900MHz) • 802.15.4/ZigBee - Bluetooth

• 802.15.4/ZigBee - RFID • Bluetooth - RFID

One of the applications you can do is:

• Using short-range modules mixed with long-range modules (ZigBee-2.4GHz and 868 MHz for example) it is possible to deploy local WSNs that are connected to the Gateway through the backbone network.

Expansion Radio Board: ZigBee - Bluetooth connection

(12)

Products Catalogue

1.2 Sensor integration

To make it easier the deployment of sensor networks we have created 8 sensor boards to integrate more than 50 different sensors. Sensors compatible with each board can be seen in the section 1.2.2.

Gases Board Events Board

Smart Cities Board _{Smart Parking Board}

Agriculture / Agriculture PRO Board Radiation Board

(13)

Products Catalogue

Smart Metering Board Prototyping Board

1.2.1 Sensor integration boards

Sensor integration boards price chart:

Gases WGAS 115 € WGAS-P5 575 € Events WEVENTS 105 € WEVENTS-P5 525 € Smart Cities WCITIES 120 € WCITIES-P5 600 € Smart Parking WPARKING 60 € WPARKING-P5 300 € Agriculture WAGR 130 € WAGR-P5 650 € Agriculture PRO WAGRPRO 250 € WAGRPRO-P5 1250 € Radiation (Sensor Board + Geiger tube) WRADIATION 115 € WRADIATION-P5 575 € Smart Metering WSMART 250 € WSMART-P5 1250 € Prototyping WPROT 75 € WPROT-P5 375 €

(14)

Products Catalogue

1.2.2 Sensors

Sensors price chart:

Sensor G ases Ev en ts Smar t C ities A gricultur e A gricultur e PRO Smar t M et ering Pr ot ot

yping Ref. Price

Temperature P P P P P P 9203 3 € Humidity P P P P P 9204 20 € Luminosity P P P P P P 9205 3 € Microphone (dBSPLA) P 9259 8 € Crack detection gauge P 9321 8 € Crack propagation gauge P 9322 25 € Linear displacement P 9319 300 € Dust - PM-10 P 9320 20 € Pressure/ Weight P P P P 9219 40 € Bend P P P P P 9218 30 € Stretch P P P P P 9217 20 € Presence (PIR) P 9212 15 € Horizontal liquid level

(combustibles) P P P P P 9239 20 € Horizontal liquid level

(water) P P P P P 9240 20 € Vertical liquid level (water) P P P P P 9242 20 € Water pressence P P P P P 9243 15 € Tilt, vibration and impact 4 _P _P _P ₉₂₀₆ _{15 €}

Waspmote

(15)

Products Catalogue

Waspmote

Hall effect 5 _P _P _P _P _P ₉₂₀₇ _{15 €} Vibration (lamina) P 9221 8 € Vibration (thread) P 9222 8 € Atmospheric pressure P P P 9250 25 € CO P 9229 25 € CO₂ P 9230 49 € O₂ P 9231 125 € CH₄ P 9232 30 € NH₃ P 9233 70 € NO₂6 _P ₉₂₃₈ _{15 €} Ozone-O₃6 _P ₉₂₅₈ _{25 €} Volatile Organic Compounds 6 P 9201 15 € Liquified petroleum gases (H₂, CH₄, ethanol &

isobutane) P 9234 30 € Air pollutants-I (NH₃, SH₂,

ethanol and toluene) P 9235 30 € Air pollutants-II (H₂,

CH₄, CO, ethanol and

isobutane) P

9236 25 € Solvent vapors (H₂,

CH₄, CO, ethanol and

isobutane) P

9237 30 €

5. For doors and windows.ç

6. NO₂, O₃ and VOC sensors are connected to the same socket, thus, it is not possible to have them working at the same time within

(16)

Products Catalogue

Current 0 - 5A P 9263 125 € Current 0 - 50A P 9264 150 € Current 0 - 150A P 9265 175 € Current 0 - 90A P 9266 20 € Load 0 - 3Kg P 9260 20 € Load 0 - 50Kg P 9261 15 € Load 0 - 600Kg P 9262 40 € Ultrasound (indoor) P P P P P P 9213 30 € Ultrasound (outdoor IP67) P P P P P P 9246 95 € Distancie

(by metalic pressure) P P P P P P 9267 30 € Distancie (by pressure) P P P P P P 9268 40 € Water flow 0,15 - 2,5 l/min P 9296 15 € Water flow 0,5 - 25 l/min P 9297 20 € Water flow 1 - 60 l/min P 9298 25 € Soil temperature P 9255 30 € Solar radiation P 9251 250 € Trunk diameter P 9252 500 € Stem diameter P 9253 500 € Fruit diameter P 9254 500 € Anemometer + wind vane

+ pluviometer P 9256 125 €

Waspmote

(17)

Products Catalogue

Ultravilotet radiation P 9257 325 € Temperature + humidity (sensirion) P P 9247 65 € Soil moisture 7 _P _P ₉₂₄₈ _{45 €} Leaf wetness P P P P P 9249 10 € Relay 10A P 9208 3 €

7. In each agriculture board 3 soil moistures can be connected in order to measure the parameter in different depth levels.

Humidity sensor Presence sensor Indoor ultrasound sensor

O₃ sensor CO₂sensor Soil moisture sensor

Waspmote

(18)

Products Catalogue

1.3 Waspmote enclosures

Waspmote enclosures price chart:

Enclosure Characteristics Ref. Price

Smart Parking enclosure

Max. Height = 107mm Usable Height = 90mm Max. Diameter = 121mm Usable Diameter = 100mm

WPARKING-ENC 20 €

Libelium supplies other types of enclosures for different Ad Hoc applications. For further information, please contact our sales department: [email protected]

Smart Parking enclosure

i

(19)

Products Catalogue

1.4 Custom hardware design

Despite of modularity in hardware Libelium products, sometimes they must be adapted to meet the specifications of a particular project.

Some examples of these adaptations are:

• Integration of new sensors on the Waspmote platform. • Optimization of designs for specific applications. • Integration of new communication modules.

For further information, please contact our sales department: [email protected]

i

(20)

Products Catalogue

1.5 Power supply options

Power supply Battery Ref. Price Ref. (5 pack) Price (5 pack)

Battery Li - Ion rechargeable 1150mAh 6014 19 € 6055 95 € 2300mAh 6015 25 € 6056 125 € 6600mAh 6041 35 € 6066 175 € Non - rechargeable 13000mAh 6016 75 € 6057 375 € Solar panel

Rigid 7V – 500mA 6020 30 € 6061 150 € Flexible 7.2V – 100mA 6021 34 € 6062 170 € USB connector

USB – 220V 6006 5 € 6063 25 € USB – car lighter 6007 5 € 6064 25 €

Rigid solar panel 7V - 500mA Flexible solar panel 7.2V - 100mA

(21)

Products Catalogue

1.6 Extracting the data

The last point for configuring a sensor network is to decide the manner in which to access the data. With Waspmote, there are 3 alternatives:

• Waspmote Gateway connected by USB to a computer. This is recommended for applications of few

nodes that are indoors or for testing while configuring the network. The Waspmote Gateway is also used to send commands to the sensor network, thus at least one unit should be purchased with the the first kit of Waspmotes.

• Waspmote GPRS/ GSM. This option can be used in small networks placed in difficult access locations,

when using a single point of data collection alone or in combination with the other two options, using the GPRS radio only to send SMS alert messages.

• Meshlium, the multiprotocol router with wireless (2.4GHz, 5GHz), ZigBee, GPRS, Bluetooth and

Ethernet. This is the most recommended option for outdoor networks and / or larger, since it allows to distribute the analysis of the data collected by the nodes. Once the Meshlium receives the sensor data from Waspmote, 5 actions can be performed:

1. Store the data in Meshlium file system. 2. Store the data in Meshlium local database.

3. Store the data in an external database (of an Intranet or Internet).

4. Send the information to the Internet via Ethernet or wireless LAN connection. 5. Send the information to the Internet via data connection using GPRS.

Waspmote Gateway

(22)

Products Catalogue

Meshlium storage options

Meshlium connection options

(23)

Products Catalogue

Waspmote

For more information on sensor networks formed by Waspmote and Meshlium, see the document Wireless Sensor Networks with Waspmote & Meshlium, in the Support section: (http://www.libelium.com/support/waspmote).

Sensor network with Waspmote and Meshlium

(24)

Products Catalogue

Waspmote price chart depending on data extraction:

Data extraction option Ref. Price

Waspmote Gateway 802.15.4 SMA 2dBi WG802-SMA2 65 € Waspmote Gateway 802.15.4 SMA 5dBi WG802-SMA5 68 € Waspmote Gateway 802.15.4-PRO SMA 2dBi WG802P-SMA2 80 € Waspmote Gateway 802.15.4-PRO SMA 5dBi WG802P-SMA5 83 € Waspmote Gateway ZB SMA 2dBi WGZB-SMA2 65 € Waspmote Gateway ZB SMA 5dBi WGZB-SMA5 68 € Waspmote Gateway ZB-PRO SMA 2dBi WGZBP-SMA2 80 € Waspmote Gateway ZB-PRO SMA 5dBi WGZBP-SMA5 83 € Waspmote Gateway 868 SMA 0dBi WG868-SMA0 138 € Waspmote Gateway 868 SMA 4.5dBi WG868-SMA4 138 € Waspmote Gateway 900 SMA 0dBi WG900-SMA0 103 € Waspmote Gateway 900 SMA 4.5dBi WG900-SMA4 103 € Waspmote Gateway XSC SMA 0dBi WGXSC-SMA0 103 € Waspmote Gateway XSC SMA 4.5dBi WGXSC-SMA4 103 € Waspmote Gateway Bluetooth SMA 2dBi WGBT-SMA2 75 € Waspmote Gateway Bluetooth SMA 5dBi WGBT-SMA5 78 € Módulo Waspmote GSM/ GPRS WGPRS 85 € Meshlium (see next section)

(25)

Products Catalogue

Meshlium

Five technologies

One single device

(26)

Products Catalogue

2. Meshlium

Meshlium is a Linux mesh router that can integrate 5 different communication interfaces: Wifi 2.4GHz, Wifi 5GHz, GPRS, Bluetooth and ZigBee. In addition, Meshlium may include a GPS module for mobile or vehicular applications and use solar or battery power. These features, along with its robust IP65 enclosure allows Meshlium to be installed anywhere.

As Waspmote, Meshlium is highly modular. This section shows you step by step all the possible configuration options: Step 1: Model Step 2: Complements Step 3: Optional modules Step 4: Storage options Step 5: Power supply options Meshlium specifications:

Processor 500MHz (x86) Power 5W (18V) - POE

RAM 256MB (DDR) Storage 8GB / 16GB / 32GB

Power consumption 270mA – 450mA Max. Power current 1.5A

Temperature range -20ºC, +50ºC Enclosure IP65

Time to respond ping

over ethernet 60s Service start time 90s

Weight 1.2Kg Dimensions 210 x 175 x 50mm Wifi AP 802.11b/g - 20dBm - 2.4GHz - 500m Wifi Mesh 802.11 a/b/g - 20dBm - 2.4GHz/5GHz - 2Km Bluetooth 17dBm - 100m GSM/GPRS Quadband: 850MHz / 900MHz / 1800MHz / 1900MHz (World Wide Usage) 802.15.4 / ZigBee / RF 1-100mW (2.4GHz - 868MHz - 900MHz) GPS -159dBm sensibility - 1s hot start Certificacions: CE (Europe).

Meshlium

(27)

Products Catalogue

Configuration software:

Meshlium includes a management software (Manager System) to configure through a GUI all the parameters of its communication interfaces (WiFi, ZigBee, GPRS and Bluetooth) and manage the storage of sensor data received. It also allows to load factory settings to make installation easier. Its operating system is Linux and the configuration software is open source:

Manager System 2.0

Getting support:

• For more information on specifications, see the documents Meshlium: Technical Guide and

Meshlium: Datasheet in the Support section: http://www.libelium.com/support/meshlium

• Once you purchase the product, technical questions can be resolved completely free of charge through our forum: http://www.libelium.com/forum/

• Finally, we offer training and consulting services to help all those who wish to develop projects with our products. For inquiries, please contact our sales department: [email protected]

• In the Development section (http://www.libelium.com/development/meshlium) you can access to a demo of the software and see examples of code, tutorials, etc.

i

(28)

Products Catalogue

2.1 Meshlium models

Each Meshlium model is pre-configured from the factory with a configuration preset, making it easier the initial installation. For more information on these presets, see the Technical Guide in the support section: http://www.libelium.com/support/meshlium

Meshlium price chart depending on model:

Model Ethernet Wifi AP _(2.4GHz) Wifi Mesh (2.4GHz / 5GHz) 802.15.4 ZigBee Radio GPRS Possible optional modules (Bluetooth and/or GPS) Ref. Price Meshlium AP P P 2 MAP 470 € Meshlium GPRS-AP P P P 2 MGPRS 620 € Meshlium Mesh-AP P P P 2 MM 670 € Meshlium Mesh-GPRS-AP P P P P 1 MMGPRS 820 € Meshlium XSC-AP P P P 2 MXSC 770 € Meshlium 900-AP P P P 2 M900 770 € Meshlium 868-AP P P P 2 M868 810 € Meshlium ZigBee-PRO-AP P P P 2 MZ 670 € Meshlium 802.15.4-PRO-AP P P P 2 M802 670 € Meshlium XSC-GPRS-AP P P P P 1 MXSCGPRS 920 € Meshlium 900-GPRS-AP P P P P 1 M900GPRS 920 € Meshlium 868-GPRS-AP P P P P 1 M868GPRS 960 € Meshlium ZigBee-PRO-GPRS-AP P P P P 1 MZGPRS 820 €

Meshlium

(29)

Products Catalogue

Model Ethernet Wifi AP _(2.4GHz) Wifi Mesh (2.4GHz / 5GHz) 802.15.4 ZigBee Radio GPRS Possible optional modules (Bluetooth and/or GPS) Ref. Price Meshlium 802.15.4-PRO-GPRS-AP P P P P 1 M802GPRS 820 € Meshlium XSC-Mesh-AP P P P P 1 MMXSC 970 € Meshlium 900-Mesh-AP P P P P 1 MM900 970 € Meshlium 868-Mesh-AP P P P P 1 MM868 1.010 € Meshlium ZigBee-PRO-Mesh-AP P P P P 1 MMZ 870 € Meshlium 802.15.4-PRO-Mesh-AP P P P P 1 MM802 870 € Meshlium XSC-Mesh-GPRS-AP P P P P P - MMXSCGPRS 1.120 € Meshlium 900-Mesh-GPRS-AP P P P P P - MM900GPRS 1.120 € Meshlium 868-Mesh-GPRS-AP P P P P P - MM868GPRS 1.160 € Meshlium ZigBee-PRO-Mesh-GPRS-AP P P P P P - MMZGPRS 1.020 € Meshlium 802.15.4-PRO-Mesh-GPRS-AP P P P P P - MM802GPRS 1.020 € Complements:

Complement Description Ref. Price Ref. (4 pack) Price (4 pack)

Antennas elbow connectors

It accommodates Meshlium antennas so that it can be placed

horizontally. 6044 8 € 6067 32 €

Meshlium

(30)

Products Catalogue

Meshlium

Meshlium optional modules:

Module Characteristics Ref. Price

GPS

Model: A1084 (Vincotech) Sensitivity in motion: -159dBm Acquisition sensitivity: -142dBm External Antenna: 26dBi (SMA)

Available information: latitude, longitude,

altitude, speed, heading, date / time and handling of events. MGPS 120 € Bluetooth Model: BT100 – IEEE 802.15.1 Emission power: 17dBm Throughput: 721Kbps Antenna: 5dBi MBT 95 €

2.2 Storage

All Meshlium include 8GB for storing the operating system. You can change the storage device with another with higher capacity adding a supplement:

Capacity Ref. Price

16GB M16GB 25 € 32GB M32GB 65 €

(31)

Products Catalogue

2.3 Power supply options

All Meshlium include a 18V - 220V power supplier and a POE. Following accessories are available as options:

Power supply Ref. Price

POE – car lighter (12V) MCAR 25 € 220V AC adaptor– battery / car lighter connector

(12V - 300W) M220 70 € Solar kit (12V - 20W) MSOLAR 450 €

More information about these accessories in Meshlium: accesories guide, available in: http://www.libelium.com/support/meshlium

i

(32)

Products Catalogue

(33)

Products Catalogue

3. Order placement

To place an order, you must complete the form available in: http://www.libelium.com/downloads/order-form.pdf and send it back to: [email protected].

You can consult our Terms & Conditios in: http://www.libelium.com/legal. Should you have any doubt, please, contact with our commercial department.

• E-mail: [email protected] • Tlf: +34 976 54 74 92
