VCSELs and variants

SOME SOLUTIONS only get you so far. Initially, they show promise, providing ground-breaking results. But then they stutter, hit a wall, and never make enough progress to enable a commercial product. This is what happened at Nichia a decade or so ago, when developing a GaN VCSEL. In 2008 it broke new ground when producing the fi rst ever GaN VCSEL operating at room temperature, and

kicked on for the next few years, improving output power. But there were concerns over reliability and reproducibility, with progress appearing to grind to a halt. Nichia did not announce any results for nearly a decade, leaving many to wonder if it had abandoned work on this device for good.

Now we know that’s clearly not the case. At this year’s

Photonics West, the company claimed to have produced the

world’s most effi cient blue and green VCSELs (see p. 50 for details). Now, rather than using a pair of dielectric mirrors for its device, it is combining one of them with another based on the nitrides. This is an approach pioneered by Nicolas Grandjean and co-workers at EPFL, Switzerland, and refi ned by Tetsuya Takeuchi’s team at Meijo University that has recently worked with engineers at Stanley Electric.

Nichia’s recent success comes at a time of great progress for GaN-based VCSELs. Developers of these devices are

making great strides in decreasing the emission wavelength. In this issue you can read about the efforts of a European collaboration, led by researchers at Chalmers University, to realise emission down to a very impressive 310 nm (see p. 34).

The last few months have also witnessed the launch of an alternative to the VCSEL – the photonic crystal surface-emitting laser (PCSEL). Pioneered by Vector Photonics, a Scottish start-up that has drawn on research from the University of Glasgow (see p. 18 for details), the PCSEL is said to combine the best attributes of the edge-emitting laser and the VCSEL. Majoring on its combination of high-speed, low-cost and power, the PCSEL also offers a step change in data rates, and the capability to span a vast spectral range.

Vector Photonics is initially targeting the datacoms markets, arguing that this is the only source capable of meeting the requirements for next-generation, high-data-rate lasers. But plans are also in place to see this device deployed for plastic and metal printing, as well as mobile consumer and sensing applications. Although it is now almost 60 years since the invention of the laser diode, as you’ll continue to see from this magazine’s coverage, device development continues at great pace, leading to improvements in numerous characteristics.
