LOT 6: VOL 3 - BILLS OF QUANTITIES: SECURITY
WORKS
ITEM BILL No. 1 - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST
Supply, erect, connect & commision the following:
BILL 1/1: CCTV SYSTEM INSTALLATION
- The system shall be based on the Intelligent Video Motion Detection(IVMD) software algorithm to detect movement of objects in the environment.
-Contractor shall include report, brochures and schematic diagrams including method statement for this service. Non compliance may disqualify bid -Client to give final approval on equipment and material product specifications/selection before orders are placed.
- All products to be cisco or approved equal.
-Installer/supplier to ensure that equipment selection are carried out such appropriate hierearchy are maintained at all times
-All products to be supplied c/w the propreitary software, accessories etc. -All products and software to be the the most recent/current at the time of delivery.
- All servers to be supplied c/w appropriate/approved software and license
Conduit, Cables & Accessory boxes
1 25mm dia upvc conduit c/w draw wire to each camera, trigger device etc and
from Patchpanel, VDR, power supply etc. 75 No. 2 Cat 7 utp cable to each ip-camera, hubs, switches etc.
c/w termination kits, couplers, etc 75 " 3 Multicore power supply cables to all the equipment including lugs, termination kits etc. Lots 4 Outdoor, rodent resistant 4 core color coded optic fibre cable Lots
c/w termination kits, transceivers etc.
5 Allow for any other accessory, equipment, appliance necessary for the
complete installation of the entire system Lots
Software and Licenses
6 VIDOS Video Management Software IVDM configuration manager
complete with license Lot 7 Network client for Management of the intellex on the network Lot 8 Allow for any third party software including system integration
requirement and video compression software Lot 9 4-port Firewall system Router 1 no. 10 24-port stackable 100Mbps MMF fast ethernet switch c/w patchpanel 1 "
ITEM BILL No. 1(Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST BILL 1/1 : CCTV SYSTEM INSTALLATION (contn'd)
Network Equipment and Wiring accessories
11 12-port Power Over LAN edge switch complete with all required accessories
including software 7 No.
12 12-port stackable patchpanel for the above. 7 " 13 3.2Ghz, 2Gb RAM, 3x73SCSI Dual RAID , DVDRW rack mounted
system server c/w all proprietry softwares including item 6 to 8 above. 1 " 14 10/100/1000Mbps Gigabit, IP Digital Video Recorder with MPEG-4 video
format, 600TB hard drive with the following interfaces/ports;
3xvideo out (front/rear), 3xRCA, 3xmicrophone, 8xsensor In, 8xsensor Out, 3xRJ45 NIC, 4xUSB, 1xTS-232 serial etc. for control and management of all the
IP cameras on the network 1 " 15 Free standing and 43U Telecommunication cabinet (rack) c/w multi-outlet
power supply, earthing set etc. 1 " 16 21" colour CCTV monitor 2 " 17 42" colour CCTV TFT monitor 1 " 18 Propreitary keyboard controller, touch tracker, controls etc. 3 " 19 128 camera x 6 Monitor Full Matrix Switcher systems combining switching
and computer technology. Programmable to display the video from any camera on any monitor, either manually or via independent automatic switching sequences. Alarm Handling Capabilities, SalvoSwitching®
and SatelliteSwitch® Capability, with PC Based Software Package 1 "
CAMERAS
20 ip-based PTZ autodome colour camera. 28x optical zoom Day/night, 100/100/1000 base T. With IP66 enclosure & tinted bubble. With autotrack/IVMD, fibre with auto track, 230Vac, 50Hz.
Pole mounting with appropriate supports. 8 " 21 4.5m H galvanised steel pole c/w terminal blocks, brackets arms,
media converters etc. 8 " 22 ip-based fixed indoor autodome colour camera with auto iris lens. Day/night and
ITEM BILL No. 1 (Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST BILL 2/2: INTRUSION SYSTEM INSTALLATION
-Contractor shall include report, brochures and schematic diagrams including method statement for this service. Non compliance may disqualify bid -Client to give final approval on equipment and material product specifications/selection before orders are placed.
- All products to be cisco or approved equal.
-Installer/supplier to ensure that equipment selection are carried out such appropriate hierearchy are maintained at all times
-All products to be supplied c/w the propreitary software, accessories etc. -All products and software to be the the most recent/current at the time of delivery.
- All servers to be supplied c/w appropriate/approved software and license
Conduit, Cables & Accessory boxes
1 25mm dia. uPVC conduit c/w draw wire to each equipment/accessories position from
the multiplexer c/w accessories, draw boxes , couplers, locknuts etc. 50 No. 2 2.5mm2 c Security copper cable to each trigger device and
alarm location from the security panel 50 "
Equipment
3 Intruder Panic button 17 " 4 Electric motor driven siren with flashing light and weatherproof housing 5 " 5 2-zone microprocessor base Intruder Alarm Control Panel 1 " 6 Door interlock system security panel e.g Raytel, c/w conduits and cabling 15 " 7 Self-supervised 30m short range microwave instrusion link with a field changeable
antenna element c/w transmitter, receiver and universal swivel ball mounting bracket
ITEM BILL No. 1 (Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST BILL 1/3: ACCESS CONTROL SYSTEM INSTALLATION
-Contractor shall include report, brochures and schematic diagrams including method statement for this service. Non compliance may disqualify bid -Client to give final approval on equipment and material product specifications/selection before orders are placed.
- All products to be cisco or approved equal.
-Installer/supplier to ensure that equipment selection are carried out such appropriate hierearchy are maintained at all times
-All products to be supplied c/w the propreitary software, accessories etc. -All products and software to be the the most recent/current at the time of delivery.
- All servers to be supplied c/w appropriate/approved software and license
Conduits, cables and accessories
1 25mm dia upvc conduit c/w draw wire to each Access Points, patchpanel, hubs,
outlets, switches etc. 27 Nos. 2 Cat 7 utp cable to each outlet from switches, hubs, patchpanels etc 27 " 3 2x4 core optic fibre cable(back-bone) c/w termination kits 27 "
Equipment and Wiring Accessories
4 4-port Firewall system Router 1 " 5 12-port stackable 1000Mbps MMF ethernet core switch c/w media converter 1 " 6 12-port Fiber optic patchpanel for the above 1 " 7 8-port stackable 10/100Mbps ethernet switch (c/w media converter)
with 8-port patchpanel for cat 7 utp cable. 1 " 8 12-port stackable WLAN controller for cat 7 utp c/w optic fibre module 1 " 9 Dual Band WLAN Lightwieght Managed Access Point(minimum of 300m radius
of coverage) 5 "
10 24-way door controller c/w power supply, user software, interface,
enclosures,suppressor kit etc. 1 " 11 800mmx800mmD, 19" 43u equipment rack with openable front glass cover with
key lock c/w integral fan at the top, 10x2Pole BS power supply unit, earthing set,
required accessories, 6xshelves, document holder, vertical cable supports etc 1 " 12 3.2Ghz, 2Gb RAM, 3x73SCSI Dual RAID , DVDRW rack mounted
ITEM BILL No. 1 (Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST BILL 1/3(Contn'd): ACCESS CONTROL SYSTEM INSTALLATION
13 Proximity reader programmed for dual swipe control 14 14 Proximity reader programmed for interlock 9 15 Combination biometric/proximity cardreader(for the turnstiles, gate and arm barriers 5 16 HID Mutlitechnology proximity Card (Including E purse and Access control functionality Lots 17 Heavy duty electric door strike c/w security access contact relays 16 18 Heavy Duty Solenoid Electric Lock 16 19 Power supply unit for Electric lock 16 20 Door Magnet complete with bracket 16 21 Power supply unit for Magnetic Lock 16
22 Door Contacts 16
22 Crash Bar ( panic bar - vertical) 16 23 Exit door release ( Push button) 19 24 Shatterproof emergency locked-in break glass 10
25 Suppressor Kit Lots
26 Complete workstation c/w access control and monitoring software and PC interface capable of real-time status display e.g Panasonic, Vintage or approved equal
(System shall operate in compliance with the attached door security schedule). 1 27 Security ID Card Printer (single sided, high quality true colour) c/w
magstripe encoder and customisable holokote) 1 28 CCTV camera Control interphase software panel 1 29 17" Flat Screen remote system monitor 1 30 High security, 3.50m Long, RAL2000 rising arm barrier
Builders work associated with the installation(at 5%)
photo-electric cell (Tx/Rx), 2xred boom lighting, 400mm STOP traffic sign, limit switch (IP65), security lock/crank hole closing plate, raised base, remote push button box (open/close/stop in gate house), impact release arm, dampers, integral battery
ITEM BILL No. 1 (Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST BILL 1/3(Contn'd): ACCESS CONTROL SYSTEM INSTALLATION
31 Stand-alone Half way housing/pillar for the above, RAL2000 with raised base, card reader (proximity and suitable for outdoor), NIC ( for
connection to networrk), counting device etc.(Main Gate, IN/OUT) 1 32 Waist-High, bi-directional brushed stainless steel gate with proximity/biometric card reader and
NIC (for network connection), integral battery back-up etc. Other details as follows; - 1200mm Arm in 33mmDia (12 guage) stainless
- Handicappped Accessible - 304 stainless steel/No. 4 satin finish
- Electronic control head for controlled traffic in both directions
- Complete power supply system for fail-safe operation(opens when power fails) -Interfacing to card readers, computer attendance, push buttons
and wireless remote controls (Main office building) 1 33 Waist-high, bi-directional, 3-arm, 1200mm brushed stainless steel turnstile with
proximity/biometric card reader and NIC (for network connection), integralbattery back-up etc. Other details are as follows; - 304 stainless steel/No. 4 satin finish
- Electronic control head for controlled traffic in both directions
- Complete power supply system for fail-safe operation(opens when power fails) -Interfacing to card readers, computer attendance, push
buttons and wireless remote controls (Main office building) 2 34 Full height, bi-directional, 3-arm, 1200mm brushed stainless steel turnstile
with proximity card reader and NIC (for network connection), integral
battery back-up etc 1
35 Full height, bi-directional, 3-arm, 1200mm brushed stainless steel turnstile
for manual operation 1
36 Enhanced Multizone walk-through metal detector with battery backup,
network integration including software, automatic/manual calibration etc 1 37 Enhanced Baggage and parcel x-ray machine with the following;
- Tunnel size: 950x650mm (minimum)
- Dual energy imaging: for automatic colour coding of materials - Conveyor Speed: 0.2m/sec
- Conveyor load: 165Kg
- computer with 128MB RAM, 64MB VGA memory, 80GB hard drive DVD/DVV/+/-RW, 17" LCD flat screen etc
- Network display station
ITEM BILL No. 1 (Contn'd) - ELECTRICAL SERVICES: SECURITY SYSTEM INSTALLATION
DESCRIPTION QTY UNIT BASIC FIXED TOTAL RATE RATE COST
COLLECTION Page 1/1 Page 1/2 Page 1/3 Page 1/4 Page 1/5 Page 1/6
1 Bill No. 1 - SECURITY SYSTEM
