Session E5: What Should We Know About Behavior of Sturgeons to Provide Their Efficient Passage?

(1)

University of Massachusetts Amherst

ScholarWorks@UMass Amherst

International Conference on Engineering and Ecohydrology for Fish Passage

International Conference on Engineering and Ecohydrology for Fish Passage 2015

Jun 23rd, 2:30 PM - 2:45 PM

Session E5: What Should We Know About

Behavior of Sturgeons to Provide Their Efficient Passage?

Dmitrii Pavlov

A.N. Severtsov Institute of Ecology & Evolution, Russian Academy of Sciences, Moscow, RUSSIA

Victor Mikheev

Mikhail Skorobogatov

Follow this and additional works at:https://scholarworks.umass.edu/fishpassage_conference

Part of theAquaculture and Fisheries Commons, and theHydraulic Engineering Commons

This Event is brought to you for free and open access by the Fish Passage Community at UMass Amherst at ScholarWorks@UMass Amherst. It has been accepted for inclusion in International Conference on Engineering and Ecohydrology for Fish Passage by an authorized administrator of ScholarWorks@UMass Amherst. For more information, please [email protected].

Pavlov, Dmitrii; Mikheev, Victor; and Skorobogatov, Mikhail, "Session E5: What Should We Know About Behavior of Sturgeons to Provide Their Efficient Passage?" (2015).International Conference on Engineering and Ecohydrology for Fish Passage. 35.

(2)

What should we know about behavior of

sturgeons to provide their efficient

passage?

Dmitrii Pavlov, Victor Mikheev & Mikhail Skorobogatov

A.N. Severtsov Institute of Ecology & Evolution, Russian Academy of Sciences, Moscow, RUSSIA

(3)

Main issues:

- Behavior of sturgeons migrating upstream

- Fish passage facilities: structure and

biological basis of operation

- Examples of sturgeon passage in the Volga,

Don and Kuban rivers. Contemporary state.

(4)

Behavioral patterns of pelagic and bottom fish migrating in rivers

Pelagic fish

● Visual orientation

● Low threshold velocity ● High critical velocity ● Diurnal migrations ● Swimming near the

surface or mid-water

Bottom fish

● Tactile orientation

● High threshold velocity ● Low critical velocity ● Nocturnal or

round-the-clock migration

● Swimming near the bottom

Threshold current velosity

(5)

Cross-river distribution of fish in the Lower Volga during spawning migrations Flow velocity at the zone of sampling Acipenser stellatus Acipenser gueldenstaedtii Dep th, m V elo city , sm/s Fis h num b er , %

Location of drift net (cross-section of the river) Distribution of migrating fish Fis h num b er , % 3

(6)

Tracks of Acipenser gueldenstaedtii

in tail water and head water of the Volgograd dam

(from Poddubnyi & Malinin, 1988)

The Volga River

(7)

0.0001 0.001 0.01 0.1 1 10 100 1000 10000 100000 0 10 20 30 40 50 60 70 80 90 100 1 5 9 13 17 21 25 29 33 37 41 45 49 Time of day, hours Fish number, % of max Illumination, Lx 0.0001 0.001 0.01 0.1 1 10 100 1000 10000 100000 0 20 40 60 80 100 13 15 17 19 21 23 1 3 5 7 9 11 13 Fish number, % of max Illumination, Lx

Patterns of dial changes in fish spawning migrations

5

Sturgeons

(8)

Experimental movable fish collector

1 – fish collector, 2 – ramp, 3 – pumps, 4 – movable screen (to concentrate fish)

Transportation mean

(9)

Modifications of the water flow in front of the movable fish collector

Watertight ramp. Small angle

Watertight ramp. Large angle

Ramp with slots (water-permeable). No vortices.

Fish pass

Ramp

Watertight ramp, “hydraulic wing”

Wing

(10)

Velocity of attractive flow influences number of passed fish 100 50 0 250 50 100 150 200 min opt max Flow velocity, sm/s Pas sage ef fi ciency , % 8

(11)

Flow velocity profiles within the fish collector

(12)

Hydraulic schemes of fish attraction Dam Dam Fish pass Fish pass Attractive flow Attractive flow Current velocity Current velocity Fish guiding facility Vc – critical Vt – threshold V attr – attractive V=V attr V>Vc V=V attr V=V attr V=V attr V>Vc V< Vt V>Vc V<Vc Fish guiding facility V<Vc V>Vc V< Vt V<Vc V=Vc V=Vc 10

(13)

Flow velocity patterns in the tale race of Saratov power plant near the fish pass

Fish pass One turbine works Two turbines work 11

(14)

Sturgeons move slower between two dams (Volgograd and Saratov Power Plants)

than other migrants.

А 0 20 40 60 80 100 Б 0 20 40 60 80 100 В 0 20 40 60 80 100 Saratov PP Volgograd PP Alosa Stenodus Sturgeon

May June July August

Fi sh pas sa ge, % of ma x 12

(15)

Kuban River. Tikhovskii Power Plant equipped with fish passage locks (2) to pass sturgeons

(16)

Kuban River. Fedorovskii (A) and Krasnodarskii (B) Power Plants equipped with fish passage facilities

to pass sturgeons

A) B)

(17)

Annual number of passed sturgeons (thousand fish)

Acipenser gueldenstaedti

(Kochetovskii PP, Don River)

A. stellatus

(Fedorovskii PP, Kuban)

A. gueldenstaedti

(Volgogradskii PP, Volga)

(18)

Annual commercial catch of sturgeons in the Russian part of Caspian basin

0 2 4 6 8 10 12 14 16 18 20 1933 1943 1953 1963 1973 1983 1993 2003 Уловы, тыс. т Годы_Years Thou sand tons 16
