Java SE 6 Update 10. la piattaforma Java per le RIA. Corrado De Bari. Sun Microsystems Italia Spa. Software & Java Ambassador

(1)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Javaday Roma III Edizione – 24 gennaio 2009

Sun Microsystems Proprietary

Java SE 6 Update 10

& JavaFX:

la piattaforma Java

per le RIA

1

Corrado De Bari

Software & Java Ambassador

(2)

Corrado De Bari - [email protected] - Sun Microsystems Italia

2

Sun Microsystems Proprietary

Agenda

●

What's news in Java Runtime Environment

●

JavaFX Technology

–

Key Features

–

Architecture & Tools

–

JavaFX Script tutorial

(3)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

New Features in 6u10

●

JavaKernel: faster download and install

●

Java Quick Starter: faster applet start

●

Rewritten Java Plugin

–

Applets run in own JVM

–

Unified desktop / browser deployment

–

Draggable Applet

–

Scriptable applets

–

Direct3D© support

(4)

Corrado De Bari - [email protected] - Sun Microsystems Italia

4

Sun Microsystems Proprietary

Architectural Overview

HTML Web Page

Applet 1

Applet 2

(5)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

●

Ground-up rewrite of the support for applets in the web browser

●

Applets are no longer executed in a Java Virtual Machine (JVM™) inside the

web browser

●

Instead, a separate JVM machine process is launched to execute the applets

●

By default, only one JVM machine is launched

–

Same resource consumption and sharing properties as the “classic”

Java technology-based Plug-In

●

Opportunity to launch more than one JVM machine

–

To support per-applet command-line arguments, heap size requests, and

more

●

Architectural similarities to Java Web Start software, but tighter browser

(6)

Corrado De Bari - [email protected] - Sun Microsystems Italia

6

Sun Microsystems Proprietary

Thin Server JVM

Client JVM 1

Client JVM 2

OS Process 1

OS Process 2

OS Process 3

(7)

Corrado De Bari - [email protected] - Sun Microsystems Italia

7

Sun Microsystems Proprietary

Compatibility

●

Backward compatibility based on runs of hundreds of

applets from throughout the web

●

Applet lifecycle unchanged

–

init(), start(), stop(), destroy()

●

All services supported:

Browser proxy settings

Browser certificate store

Browser authenticator

Browser cookie store

showDocument() support

Printing

(8)

Corrado De Bari - [email protected] - Sun Microsystems Italia

8

Sun Microsystems Proprietary

JNLP Support

●

Most significant new feature

●

Unifies deployment between Java Web Start and the

Java Plug-In

–

Simply choose the top-level container (Frame /

Applet)

●

Incorporate JNLP extensions trivially in applets

–

JavaFX run-time libraries, JOGL, Java 3D, JAI

●

Use JNLP APIs from applets

–

PersistenceService, DownloadService, ...

●

Full support for JVM command-line arguments, JRE

(9)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Basic JNLP Example

<param name=”jnlp_href”

value=”my_applet.jnlp”>

(10)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Basic JNLP Example

<?xml version=”1.0” encoding=”UTF-8”?>

<title=”My Applet”>

<vendor>My Company, Inc.</vendor>

<offline-allowed />

</information>

<j2se version=”1.4+”

href=”http://java.sun.com/products/autodl/j2se” />

<jar href=”my_jar_2.jar” />

</resources>

<applet-desc name=”My Applet”

main-class=”com.mycompany.MyApplet”

width=”1”

height=”1” />

</jnlp>

(11)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Applet-Desc Tag

<?xml version=”1.0” encoding=”UTF-8”?>

<title=”My Applet”>

<vendor>My Company, Inc.</vendor>

<offline-allowed />

</information>

<j2se version=”1.4+”

href=”http://java.sun.com/products/autodl/j2se” />

<jar href=”my_jar_2.jar” />

</resources>

<applet-desc name=”My Applet”

main-class=”com.mycompany.MyApplet”

width=”1”

height=”1” />

(12)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Applet-Desc Tag

●

width and height are ignored

–

Browser always overrides because it knows best how

big the applet needs to be

–

Relative width and height supported in applet tag (i.e.,

“50%”)

●

main-class parameter always used

–

code parameter from applet tag is ignored

–

Enables backward compatibility mechanisms

(13)

Corrado De Bari - [email protected] - Sun Microsystems Italia

13

Sun Microsystems Proprietary

Java / JavaScript Support

●

Completely rewritten Java / JavaScript integration

●

More complete, reliable and portable than before

●

Formerly Mozilla-specific functionality now working in

Internet Explorer

–

Static method access

–

Construction of new Java objects from JavaScript

(14)

Corrado De Bari - [email protected] - Sun Microsystems Italia

14

Sun Microsystems Proprietary

DOM Access

Enables AJAX-style web apps using Java language

●

DOM access via W3C APIs has been rewritten

–

Built on top of new Java/JavaScript support

●

New, much simpler bootstrapping entry point

org.w3c.dom.Document doc =

com.sun.java.browser.plugin2.DOM.

getDocument(applet);

●

Can then cast to HTMLDocument and descend into the DOM

●

Perform operations from any thread

(15)

Corrado De Bari - [email protected] - Sun Microsystems Italia

15

Sun Microsystems Proprietary

Support for Advanced Applets

●

Control over Java heap size

●

Control over Java 2D acceleration parameters

●

Ideal environment for running 3D content

●

JOGL applet examples

–

NASA World Wind Java:

●

http://download.java.net/javadesktop/plugin2/wwj/

–

Jake2 – Bytonic Software:

(16)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

JavaFX

JavaFX is

THE

platform for creating and

delivering

Rich Internet Applications

across all the screens of your life

(17)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Key Features

✔

One-stop shop RIA platform for all screens:

✔

Build engaging visual experiences across desktop,

browser and mobile with a unified development and

deployment model.

✔

Broadest market reach:

✔

Distribute RIAs easily across billions of devices with the

power of Java.

✔

Designer-developer workflow:

✔

Dramatically shorten your production cycle for design

(18)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Key Features (Continued)

✔

Powerful runtime:

✔

Leverage the extreme ubiquity, power, performance

and security of the Java runtime.

✔

Break free from the browser:

✔

Drag-and drop a JavaFX application from the browser

to deploy to the desktop.

✔

Java technology compatibility:

✔

Preserve your investment by enabling the use of any

(19)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

What you can do: Simple Video Player

•

Incorporating video in your application is as simple

as creating an instance of this component, setting a

few variables and including a link to your video

(20)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

3-D Display Shelf: the

PerspectiveTransform

•

The PerspectiveTransform built into JavaFX

(21)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Flying Saucer

•

The new out-of-process Java applet plugin

in Java SE 6 update 10 enables you to make

applets which can run outside of the browser.

(22)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Demo: JavaFX apps

http://www.javafx.com/samples/EffectsPlayground/webstart/EffectsPlayground.jnlp

http://www.javafx.com/samples/DraggableMP3Player/webstart/DraggableMP3Player.jnlp

http://www.javafx.com/samples/BrickBreaker/webstart/BrickBreaker.jnlp

(23)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

(24)

Corrado De Bari - [email protected] - Sun Microsystems Italia

24

Sun Microsystems Proprietary

JavaFX roadmap

JavaFX

Desktop

(Winter 2008)

JavaFX

Mobile

(Spring 2009)

JavaFX TV

(Summer 2009)

Desktop Product Line

Mobile Product Line

TV Product Line

(25)

Corrado De Bari - [email protected] - Sun Microsystems Italia

25

Sun Microsystems Proprietary

(26)

Corrado De Bari - [email protected] - Sun Microsystems Italia

26

Sun Microsystems Proprietary

JavaFX Tools

JavaFX 1.0 Plugin for Adobe

Photoshop and JavaFX 1.0

Plugin for Adobe Illustrator

JavaFX 1.0 Media Factory

✔

SVG Converter

✔

Viewer

(27)

Corrado De Bari - [email protected] - Sun Microsystems Italia

27

Sun Microsystems Proprietary

How to Deploy

●

Java Plugin

●

Java Web Start

(28)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

JavaFX APIs

●

JavaFX Scene

–

Node based GUI framework

●

JavaFX Media

–

Media player, native and cross platform codecs

●

JavaFX Web Services

–

REST-ful

●

JavaFX Profiles

–

Common

–

Desktop

(29)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

JavaFX Script

●

Created for rapid and easy GUI creation

●

Object-oriented

–

Namespaces, Classes, attributes, functions and

operations

●

Declarative syntax

●

Both static-typing & type-inference

●

Animation, data binding and event handing

(30)

Corrado De Bari - [email protected] - Sun Microsystems Italia

30

Sun Microsystems Proprietary

Example: Hello World in Swing

import javax.swing.*;

public class HelloWorldSwing {

public static void main(String[] args) {

JFrame frame = new JFrame("HelloWorld Swing");

final JLabel label = new JLabel("Hello World");

frame.getContentPane().add(label);

frame.setDefaultCloseOperation(

JFrame.EXIT_ON_CLOSE);

frame.pack();

frame.setVisible(true);

}

(31)

Corrado De Bari - [email protected] - Sun Microsystems Italia

31

Sun Microsystems Proprietary

Example: Hello World in JavaFX

Declarative Syntax

Frame {

title: "Hello World JavaFX"

width: 200

height: 100

visible: true

stage: Stage {

content: [Text {

font: Font {

size: 24

style: FontStyle.PLAIN

}

x: 10, y: 30

content: "Hello World"

}]

}

(32)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Class Definition

•

Address class definition: The Address class

declares street, city, state, and zip instance

variables all of type String

class Address

{

var street: String;

var city: String;

var state: String;

var zip: String;

}

(33)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Class Definition

•

Customer class definition with functions -

functions are like methods in Java

class Customer

{

var firstName: String;

var lastName: String;

var phoneNum: String;

var address: Address;

function printName() {

println("Name: {firstName} {lastName}");

}

function printPhoneNum(){

println("Phone: {phoneNum}");

}

(34)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Create an Object

•

Nesting Address object inside Customer

object

def customer =

Customer

{

firstName: "John";

lastName: "Doe";

phoneNum: "(408) 555-1212";

address:

Address

{

street: "1 Main Street";

city: "Santa Clara";

state: "CA";

zip: "95050";

}

(35)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Step by Step Process of Creating

a simple GUI

•

JavaFX application that renders a green

rounded rectangle and a white circle with red

outline on the top of the rectangle

(36)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Step by Step Process of

Creating a GUI

1.

Add necessary imports

2.

Create an Application window

3.

Set the Scene

4.

Create a Rectangle

5.

Create a Circle

6.

Change the code (so that the Circle gets

(37)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

1. Add Necessary Imports

import javafx.stage.Stage; // required to render a window

import javafx.scene.Scene; // required to display a circle and

// rectangle on a window

import javafx.scene.shape.Rectangle; // required to render the

rectangle

import javafx.scene.paint.Color; // required to fill and stroke the

// rectangle and circle with color

import javafx.scene.shape.Circle; // required to render the circle

(38)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

2. Create an Application Window

•

In order to display the graphics, you need to create a

window through

Stage

object literal

// Create a Stage object literal. Stage is required to render any object.

// The window should be big enough to display all of the rectangle and

// the circle. In this example, the window is a rectangle of 249 by 251

// pixels. To create a window of this size, with a "Declaring is Easy" title,

// declare these values within the curly brackets using the following

code:

Stage {

title: "Declaring Is Easy!"

width: 249

height: 251

visible: true

}

(39)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

3. Set the Scene

•

Within the stage, set the scene to hold

Node

objects such as a circle or a rectangle

•

The scene is a root area where you place

objects of the node type.

•

The scene has

content

variable that is used

to hold the nodes.

•

There are many different kinds of nodes,

such as graphical objects, text, and GUI

components.

(40)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

3. Set the Scene (Continued)

•

// The content of the window becomes filled with white

because

// white is a default fill color for a scene. The scene is

placed on top

// of the window

.

Stage {

...

scene: Scene {

content: [ ]

}

(41)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

4. Create a Rectangle

Stage {

...

scene: Scene {

content: [

// The x and y instance variables specify the pixel location of the

// rectangle, arcWidth and arcHeight define the roundness of

// corners, and the fill variable defines the color that fills the rectangle.

Rectangle {

x: 45 y: 35

width: 150 height: 150

arcWidth: 15 arcHeight: 15

fill: Color.GREEN

}

]

}

(42)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

5. Create a Circle

Stage {

...

scene: Scene {

content: [

Rectangle {

...

},

// Because the rectangle is declared before any other objects, it is painted

// first. The rectangle will be behind any other objects painted later.

Circle{

centerX: 118

centerY: 110

radius: 83

fill: Color.WHITE

stroke: Color.RED

}

]

}

(43)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

6. Place Circle Underneath Rectangle

Stage {

...

scene: Scene {

content: [

// Place the circle underneath the square. To do so, switch the order

// of the circle and square

Circle{

....

},

Rectangle {

...

}

]

}

(44)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Effects: DropShadow

Text {

effect: DropShadow {

offsetY: 3

color: Color.color(0.4, 0.4, 0.4)

};

...

},

Circle {

effect: DropShadow {

offsetY: 4

},

...

}

(45)

Corrado De Bari - [email protected] - Sun Microsystems Italia

45

Sun Microsystems Proprietary

Images

ImageView = ImageView {

clip: Rectangle {

y: 30 x: 50

width: 350 height: 100

}

image: Image { url: "..."}

}

(46)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

JavaFX Script: Data Binding

// will be modified elsewhere

var count:Integer = new Integer();

// The label text is bound to the count

Label {

text:

bind

count.value.toString( )

(47)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

JavaFX Script: Event Triggers

// Triggering validation of the

// number of wheels on a vehicle

attribute numWheels:Integer = 4

on replace

(oldValue) {

if (numWheels <= 0) {

System.out.println("{numWheels} wheels not valid,

changing back to {oldValue}!");

numWheels = oldValue;

}

(48)

Corrado De Bari - [email protected] - Sun Microsystems Italia

48

Sun Microsystems Proprietary

Resources

●

JavaPassion Trainings (Source of this presentation):

–

http://www.javapassion.com/javafx

●

http://www.javafx.com/

●

http://java.sun.com/javase/downloads/index.jsp

●

http://java.sun.com/javase/6/webnotes/6u10.html

●

http://scenegraph.dev.java.net/

●

http://jogl.dev.java.net/

(49)

Corrado De Bari - [email protected] - Sun Microsystems Italia

Sun Microsystems Proprietary

Java SE 6 Update 10

& JavaFX:

la piattaforma Java

per le RIA

49

Corrado De Bari

Software & Java Ambassador

http://java.sun.com/products/autodl/j2se”

http://download.java.net/javadesktop/plugin2/wwj/

http://www.bytonic.de/downloads/jake2_jogl11.jnlp

http://www.javafx.com/samples/EffectsPlayground/webstart/EffectsPlayground.jnlp

http://www.javafx.com/samples/BrickBreaker/webstart/BrickBreaker.jnlp

http://www.javapassion.com/javafx

http://www.javafx.com/

http://java.sun.com/javase/downloads/index.jsp

http://java.sun.com/javase/6/webnotes/6u10.html

http://scenegraph.dev.java.net/

http://jogl.dev.java.net/
