Scalable Private Database Querying for Arbitrary Formulas

(1)

Scalable Private Database Querying

for Arbitrary Formulas

Vladimir Kolesnikov (Bell Labs)

Seung Geol Choi, Angelos Keromytis, Fernando Krell, Tal Malkin, Vasilis Pappas and Binh Vo (Columbia)

Wesley George (UToronto),

(2)

Outline

• Problem description

• The cost of secure computation and how to scale

• Our system

(3)

3

IARPA SPAR: Security and Privacy Assurance

Research

(4)

Required features

100M records, 10TB DB

Preserve query and data privacy

Robust query support:

select * where NAME=Bob AND AGE >20

Boolean query expressions (including at least three conjunctions) Range queries and inequalities for integer numeric, date/time, etc Matching of keywords ―close to a specified value (stemming)

Text fields with many keywords (e.g. 100’s) Matching of values with wildcards

Matching of values with a specified subsequence m-of-n conjunctions

Ranking of results …

Allowed up to 2-10x overhead compared to MySQL

(5)

5

Basic Architecture

•  

Database Owner Encrypted Database Client Index Server (S) S holds permuted encrypted indexed DB

(6)

Overview:

1.  Alice prepares encrypted version C’ of C

2.  Sends encrypted form x’ of her input x

3.  Allows Bob to obtain encrypted form y’ of his input y

4.  Bob can compute from C’,x’,y’ the “encryption” z’ of z=C(x,y)

5.  Bob sends z’ to Alice and she decrypts and reveals to him z

AND OR AND

NOT

OR AND

Alice’s inputs

Bob’s inputs

(7)

7

AND

NOT

OR AND

Alice’s inputs

Bob’s inputs

Secure Computation: Cost

Circuit encryption includes encryption of truth table of gates

For each gate of C, need to compute and send O(4) encryptions (AES needs 50-150 cycles to encrypt 128 bits)

Very fast for small problems

Does not scale for

large functions

(8)

Secure Computation: how to scale

If OK to have some security loss (as efficiency tradeoff):

Identify privacy-critical subroutines and implement them securely Insecure implementation of the rest

(9)

9

Natural Trade Offs

Deterministic encryption

Because of scale, comparison of encrypted values used in search must be very fast. Not clear how to approach with probabilistic encryption

Access patterns

Clearly not a bad leakage. Seems quite expensive to avoid, so natural to live with it.

(10)

Bloom Filter

Constant-time querying

Efficient storage (ca 10 bits per keyword)

Fixed access pattern (same for both match and non-match)

Encrypted BF:

(11)

11 | Columbia U / Bell Labs

Occluded BF

Idea:

Mask BF with a (pseudo-)random pad Let Client know the pad (via seed)

Then Client and Server run SFE for computing match, where C inputs pad. GC is very efficient: 10-20 gates per term, plus gates to implement formula.

Query: C sends Enc(kw), S computes match OK for single keyword searches

(12)

DB Search

… DB records S … C … … … … Solution: Evaluate via Secure Computation

(13)

13

Security Guarantee

We leak to S at most the following access patterns:

- the query pattern of a set of queries (e.g., S can distinguish between simple

and complex queries)

- tree search pattern of each query

- returned records access pattern

Above types of leakage seem necessary to achieve efficient sublinear performance.

(14)

Advanced Queries Based on AND/OR formulas:

Range Queries

We cover the range of our data type With a collection of intervals

(15)

Advanced Queries Based on AND/OR formulas:

Range Queries

(16)

Advanced Queries Based on AND/OR formulas:

Range Queries

To search for any value within a range,

we search for the smallest covering collection of intervals, using an OR formula

(17)

Advanced Queries Based on AND/OR formulas:

Negations

Note that the set of points other than some fixed value, has a small interval cover

(18)

(19)

19

Experimental Results

(20)

Policy Compliance

GC is strategically at the center of our approach because easy to compose. Requirement: secure policy checking:

Policy rejection should look like a query no-match to C and S

implement policy as a GC computation whose output is an input to BF tree node GC computation.

(21)

21

Subtlety 1: inexact data representation by BF

Let A, B, C collide under hash functions of BF, s.t. every index of C is an index for either A or B.

Then !∧"⇒#

Well-known “issue” – BF false positive

Does not reveal knowledge of underlying data, just representation.

A

_B

(22)

Subtlety 1: inexact data representation by BF

Let A, B, C collide under hash functions of BF, s.t. every index of C is an index for either A or B.

Then !∧¬#⇒¬"

Issue: learn B without querying, even in secure eval of !∧¬#

Pertains to original data, not just BF representation We calculate advantage Adv ≤*(+*/,)↑+ 

A

_B

(23)

23

0-1 Result Set Size Indistinguishability

Goal: hide from S whether there was a 0 or 1 match.

S is an airline and C is gov’t querying for POI. Expect 0 hits S learning of a match can cause panic.

Def 1: Consider probability of bad event, prove it’s small

(24)

0-1 Result Set Size Indistinguishability

Goal: hide from S whether there was a 0 or 1 match.

Def 2: If distinguishable, guarantee that D’s confidence is not very high

-  if the a-priori probability of a 1-case is /, then conditioned on any possible

view, the a-posteriori probability of a 1-case is at most (1+0)/).

Solution: C adds p of fake tree-traversal paths. p is a random variable drawn from distribution like this

N paths
