Automated selling. August 2020

"Lemgo" vending machine

• integrated lift for particularly gentle product delivery

• dispensing compartment at mid-height • individual configuration of the compartment widths

• temperature control from 4 °C to 20 °C • different payment options:

coin, bill, GiroCard, Credit Card, NFC such as GooglePay and ApplePay

• machine lighting with LEDs

• "shopping basket option" – select several products and pay only once

• no assortment commitment

• display time-controlled special offers and discounts

• stocks and sales statistics can be called up online • save images and descriptions in the cloud

• set up languages for individual language selections • products can be grouped on the screen or

displayed randomly

• split screen display possible (e.g. for advertising videos)

• adjustable feet for optimum alignment • machine dimensions: 1.850 x 1.410 x 815 mm (H x W x D) • article number: 74.0018.1 Price: € 9,950.00 plus VAT click here or scan!

Graphic film / Branding

Do you want an individual vending machine, adapted to your existing design, product-specific or simply striking?

We would be pleased to create your design according to your requirements for the "Lemgo" vending machine!

• article number premium branding: 74.0035.1 • article number basic branding: 74.0035.2

premium branding (Full foil) price: 890,00 € basic branding (foliation without profile frame) price: 590,00 €

Selectable configuration for "Lemgo" vending machine

Tray with conveyor belts

• 10 conveyor belts per tray • belt length 350 mm each

• combination of up to 4 conveyor belts • possible compartment widths:

- 75 mm - 150 mm - 225 mm - 300 mm

• article number: 74.0007.3

Tray with spirals

• 10 spirals per tray

• spirals for product depths - 30 mm

- 50 mm - 70 mm

• other special dimensions possible • 2 spirals combinable for wider products • article number: 74.0007.2

Impact proof pane

• material: polycarbonate • high impact strength • high flexibility

• clear as glass transparency • flame resistance

• 3 mm thick

• article number: 74.0024.1

Impact protection film

safeguard against vandalism, e.g. stone throwing. • 400 μm material thickness

• tensile strength ASTM D 882: 2.110 kg / cm² • elongation ASTM D882: >100 %

• tensile strength at break ASTM D 882: 77 kg / cm • article number: 74.0030.2

optional accessories for "Lemgo" vending machine

UV protection film

Sunscreen film for top quality standards.

The extra high light transmission makes the film on the glass almost invisible. Combination of maximum thermal radiation eduction with simultaneous lowest light loss combines to produce outstanding visual clarity.

• article number: 74.0030.1 Price: € 315,60 plus VAT Price: € 315,60 plus VAT Price: € 390,00 plus VAT

Privacy filter

In combination with the age verification, if the age check is confirmed, the opaque film becomes transparent.

• enables the sale of products with statutory age check and additional privacy protection

• transparency: <4 % (on) > 90 % (off) • 99 % UV protection

• article number: 74.0030.3

Age verification

• enables the sale of products with statutory age check • checking of ID cards

• machine remains disabled until the age has been confirmed • can be retrofitted on Lemgo vending machines

• article number: 74.0020.4

Price: € 699,00 plus VAT

Price: € 936,00 plus VAT

The "FlexVend" vending machine combines the proven sales interface, which is already used on the "Lemgo" vending machine on it's intuitive touch display. With dispensing modules, cooled or uncooled, you can offer a variety of products for sale. An optimal choice of the modules with the control unit as well as the dispen-sing compartments is made according to your requirements. The configuration of the modules can also be changed or extended at any time at a later date.

Request your personal offer.

"Control" module

• 21,5" touch screen

• "shopping basket option" -

select several products and pay only once • no assortment commitment

• stock and sales statistics can be called up online • save images and product descriptions in the cloud • products can be grouped on the screen or

displayed randomly

• split screen display possible (e.g. for advertising videos) • different payment options:

coin, bill, GiroCard, credit card, NFC such as GooglePay and ApplePay

• optional: age verification

• machine dimensions: 500 x 1950 x 600 (W x H x D) • article number: 74.0037.1

"unchilled" compartment module

• compartment in different sizes • LED interior lighting

• machine dimension: 1000 x 1950 x 600 (W x H x D)

"chilled" compartment module

• products can be kept chilled from 2°C to 10°C • LED interior lighting

• machine dimension: 1400 x 1950 x 600 (W x H x D)

Price on request

"Single" and "triple" cloth vending machine

"Single" cloth vending machine

• easy to operate thanks to simple mechanism

• accepts euros & tokens

• holds 24 microfibre cloths for use on vehicles

• robust and simple design

• incl. accessories: coin tester, 2x locks • individual stickers / wrap possible • machine dimensions:

1.065 x 170 x 315 mm (H x W x D) • article number: 74.0026.1

"Triple" cloth vending machine

• holds 3x 24 products

• easy to operate thanks to simple mechanism • accepts euros & tokens

• individual selling prices

• can be set in several languages • robust and simple design

• incl. accessories: coin tester, 2x locks • individual stickers / wrap possible

• machine dimensions: 1.070 x 490 x 315 mm (H x W x D) • article number: 74.0026.2 Price: € 4,160.00 plus VAT Price: € 2,640.00 plus VAT

• for handover of products at any time • shown here using the example for a pharmacist’s

• products can be kept chilled from 2 °C to 10 °C

• silent refrigeration

• automatic defrost and water evaporation • compartment doors secured by

PIN code locks

• 8 compartments for parcel size up to 260 x 200 x 280 mm (H x W x D) • machine dimensions:

1.250 x 600 x 610 mm (H x W x D) • incl. extra base; Height: 555 mm • article number: 74.0027.2

Handover / service point, unchilled

Handover / service station, chilled

• shown here using the example for a pharmacist’s

• compartment doors secured by PIN code locks

• 3 compartments for parcel size up to 350 x 240 x 290 mm (H x W x D)

• 6 compartments for parcel size up to 160 x 240 x 290 mm (H x W x D) • machine dimensions: 1.350 x 590 x 380 mm (H x W x D) • article number: 74.0027.3 Price: € 2,995.00 plus VAT Price: € 3,795.00

Offers many features:

• receive parcels regardless of delivery company • deposit and collect parcels to and from customers • independent of its own opening hours - 24/7

• automatic email notification when parcels are deposited • simple compartment (locker) opening using QR-code

• opening and status detection of the compartments by electronic locks • cloud based customer management

• online compartment reservation

• API interface for integration into the ERP-system • "Last-Mile-Solution"

"Stationary" pick-up station

click here or scan!

Web platform with dashboard

"Technology" type module

outside dimensions per module: 1.800 x 500 x 600 mm (H x W x D)

• 14" touchscreen for convenient operation

• QR code scanner for reliable detection, including from smartphone

• incl. 2 "S" type compartments (lockers) for parcels up to 300 x 400 x 570 mm (H x W x S)

• article number: 74.0027.4

• Price plus monthly service cost charged based on time and material

Price: € 4,995.00

"Technology" type module

Module type "L" Module type "M" Module type "S" Module type "S"

• 5 size "S" compartments for parcels up to 300 x 400 x 570 mm (H x W x S) • article number:

74.0027.5

Module type "M"

• 3 size "M" compartments for parcels up to 520 x 400 x 570 mm (H x W x D) • article number:

74.0027.6

Module type "L"

• 2 size "L" compartments for parcels up to 800 x 400 x 570 mm (H x W x D) • article number: 74.0027.7 Price: € 1,295.00 plus VAT Price: € 1,145.00 plus VAT Price: € 995,00 plus VAT

The pick-up station can be individually configured by selecting the compartment modules according to your needs. In addition, the modules can be designed as required.

click here or scan

• Parcels are delivered to a delivery company near the town or city

• mobile point is filled from the inside

• towed by an electronic towing vehicle, the collection point reaches its installation site free from emissions

• positioning in central, easy to access sites

• customers and retailers rend compartments / lockers • parcels can be sent and received

• the compartments are secured from the outside by PIN code locks

At the installation site, the trailer is no longer recognised as such due to: • installation of the trailer at ground level by pneumatically retracting the wheels / axle

• fold up and stow away the towing bar

• article number: 74.0027.1

• size: ca. 2,500 x 5,060 x 2,560 mm (W x H x D) (with drawbar folded and axle retracted)

• weight: 1,75t

Price on request

Individual branding possible. Electronic door lock on request.

Booth - for one / two "Lemgo" vending machines

The booths are equipped with ready-to-plug-in electronics (power sockets for vending machines, lighting, preparation for electric heating).

They are also equipped with:

• thermal insulation sandwich panels

• ventilation grille for vending machine exhaust • generously sized glass front

Price on request

Stops and service points

The modules have a monopitch roof and are insulated with sandwich panels. The rooms also have an elect-ric installation and a heat module.

Display windows and glass doors can be fitted with electronic locks on request. Ventilation can be installed. The hardened surface must be provided on site.

• fitout on request • lettering on request

• size: 2.500 x 6.000 x 2.500 mm (H x W x D)

Stops and service points can be installed at trans-port nodal points / interchanges, bus and train stations, petrol stations, etc.

Due to their individual fitout options, they are as flexible and usable for diverse purposes as they are easy to assemble and install. Let the following examples inspire you!

Price on request

Stop and service point, with vending machine and seating

Stop and service point, with collection point

Stop and service point, with several vending machines

article number: 74.0028.6 article number: 74.0028.3 article number: 74.0028.2

Stop and service point, with vending machines for daily use

Stop and service point, with charger for e-scooters

Stop and service point - combination of 3 modules

Stop and service point - combination of 4 modules

Digital outdoor customer stopper

City Packer

The new way to transport! • range up to 100 km • payload up to 150 kg • max. speed 45 km / h • motor output 2.000 W

• LiFePO4 rechargeable battery 48 V / 75 Ah • 40" screen diagonal

• 1.080 x 1.920 px resolution • 500 cd / m² brightness

• up to 14-hour rechargeable battery operation • for outdoor use

• supported file formats: JPEG, BMP, PNG, MP3, MPEG I / II / IV, H264

• size: 1.000 x 420 x 560 mm (H x W x D) • article number: 89.0002.189

• large load volume (up to 125 kg)

• Bafang Max Drive 250 W mid-drive motor

• 36 V / 13 Ah, 481 Wh lithium ion rechargeable battery • up to 70 km range

• Schimano Nexus 7-gear change • lightweight aluminium frame • article number: 76.0009.145

"Carry 3" e-bike transport

Price: € 3,795.00 plus VAT Price: € 2,105.19 plus VAT Price: € 8,059.50 plus VAT
